Tennant Company | 701 N. Lilac Drive | P.O. Box 1452 | Minneapolis MN 55440-1452 | 800.553.8033 | www.tennantco.com | info@tennantco.com
Specifications subject to change without notice. REV 5.16.05
Feature
Sweeping System
Cleaning path 60-inch 1,525 mm
Main sweeping brush
Speed (2 speeds)
Main brush length
Side sweeping brush
Speed (2 speeds)
Side brush diameter
400/500 rpm
45-inch
85/105 rpm
23-inch
400/500 rpm
1,145 mm
85/105 rpm
585 mm
Debris hopper
Volume capacity
Weight capacity
Dump height (variable to)
14 ft³
1,200 lb
60-inch
396 liter
545 kg
1,525 mm
Dust Control System
Filter system (dual stage, to 3 microns)
Stage 1
Stage 2
Perma-Filter™
74 ft² panel filter
Perma-Filter™
7 m² panel filter
Scrubbing System
Cleaning path 48-inch 1,220 mm
Solution tank 60 gallon 227 liter
Disk scrub head
Speed
Down pressure weight (3 speeds)
Brush diameter (3)
180 rpm
150, 300, 450 lb
16-inch
180 rpm
70, 140, 210 kg
405 mm
Recovery System
Recovery tank 60 gallon 227 liter
Vacuum fan speed 11,000 rpm 11,000 rpm
Vacuum water lift 40-inch 1,015 mm
Propelling System
Propel speed forward (variable to) 8.0 mph 12.9 km/h
Propel speed reverse (variable to) 3.0 mph 4.8 km/h
Engine-gasoline/LPG 83.0 hp GM 62.0 kW GM
Engine-diesel 49.0 hp Kubota 36.5 kW Kubota
Gradeability
Transport at gross weight
Working (scrubbing)
8 deg/14.1%
6 deg/10.5%
8 deg/14.1%
6 deg/10.5%
Machine Dimensions
Length-gasoline/diesel
Length-LPG
With 33 lb (15 kg) tank
With 43 lb (20 kg) tank
117-inch
121-inch
125-inch
2,970 mm
3,075 mm
3,175 mm
Width
With side brush
Rear squeegee
63.5-inch
60-inch
1,610 mm
1,525 mm
Height
With overhead guard 64-inch
83.5-inch 1,625mm
2,120 mm
Weight 5,050 lb 2,290 kg
Minimum aisle turn 139-inch 3,530mm
Warranty Please refer to your local Tennant representative for information.
Model 8410 Specifications
INDUSTRIAL RIDING SWEEPER-SCRUBBER
