Admiral 28 & 30

Rider Scrubbers

The Power of Clean

PowerBoss, Inc.

175 Anderson Street Aberdeen, NC 28315

Phone: 910-944-2105 Fax: 910-944-7409

A Member of the Hako Group

Come Visit our Website at

www.powerboss.com

983124

Working width 28” (71cm) 30” (76cm)

Effective suction width 38” (96cm) 38” (96cm)

Area performance up to 51, 666 sq ft/h (4.800m2/h) 51, 666 sq ft/h (4.800m2/h)

Working speed, up to 4mph (6,5km/h) 4mph (6,5km/h)

Air volume, vacuum 69.5 Cfm (118m3/h) 69.5 Cfm (118m3/h)

Waterlift 69” (170mbar) 69” (170mbar)

Capacity drive motor 1hp (800W) 1hp (800W)

Capacity plate brush motor 1hp (820W) 1hp (820W)

Capacity brush motor 2(1hp) (2x820W) 2(1hp) (2x820W)

Capacity suction motor 3/4hp (550W) 3/4hp (550W)

Tank clean/dirty water 30. G (116/116 L) 30. G (116/116 L)

Dirt hopper sweeping 1.3 G (5 L) 1.3 G (5 L)

Brush Versions: Cylindrical Disc

Number of brushes 2 2

Brush diameter 6” (15cm) 15” (38cm)

Brush revolutions rpm 850 195

Brush pressure 110 lbs (50kg) 110 lbs (50kg)

Dimensions and Weights:

Length with squeegee 65” (166cm) 65” (166cm)

Height 57” (144cm) 57” (144cm)

Width with squeegee 38” (96cm) 38” (96cm)

Width without squeegee 31.5” (80cm) 31.5” (80cm)

Turning circle in aisles 66.5” (169cm) 66.5” (169cm)

Weight without batteries 750 lbs (340kg) 750 lbs (340kg)

Total weight, ready for operation 1,578 lbs (716kg) 1,578 lbs (716kg)6

Specifications

• Water Conservation – Aqua-Stop saves water usage by 50%, water is released through a pump

system providing greater control of water usage than gravity systems

• Clean Air - High-performance filter system dramatically reduces the release of dust and debris

back into the air, dust vacuum ensures that dust is put directly into the hopper, bristle pattern on

main broom increases dust control

• Lower Emissions – All gas and LP engines meet Tier 2 specifications, catalyst mufflers, battery

operated available, diesel operated available, bio-diesel fuel can be used in Kubota engine

• Safer Work Environment – Orange machines are highly visible to others in the workplace, simple

controls reduce operator error, one-button scrub, horn, fire in hopper indicator, effective

braking system, “belly bar” prevents operator from being pinned behind machine when in

reverse, parabolic squeegee picks up all water leaving the scrub path virtually dry for traffic, seat

equipped with safety shut-off switch, also available: overhead guard, back-up alarm, warning beacon

• Clean Energy – Battery operated available, bio-diesel fuel can be used in Kubota engines

• Lower Chemical Reliance – Aqua-Stop saves chemical usage by 50%, pump system for water and

chemical release allows for better control of chemical usage, chemical metering system is

available as an option and regulates chemical usage to the correct dose

Features listed are general for PowerBoss equipment; each machine has different features and therefore, may or

may not fill all of the features listed above.

BLUE

Admiral 30

Disc

Admiral 28

Cylindrical

PowerBoss is proud to be BLUE!

What does it mean to be BLUE?

Admiral 28 & 30:

The additional cost of

purchase is compensated

for within the second year!

Purchase

costs

Savings as a result of increased productivity

when compared

with

walk-behind

machines.

Additional

Investment

Year 1 Year 2 Year 3 Year 4 Year 5

Reason 2

Even more maneuverable

than walk-behind

machines: turning radius of

66.5” in aisles. Intelligent

construction provides

”rear turning” and special

squeegee kinematics.

Reason 4

Covers more ground because

of the economical, electro-

nicallly controlled water

dosage with memory func-

tion and Aqua-Control System

(ACS).

Reason 3

Cylindrical brush with inte-

grated sweeping function

saves additional work.

Optimum scrubbing perform-

ance even on structured

floors and tiled surfaces.

Reason 5

Ergonomically designed

workplace with optimum

view of the working tools and

the area to be cleaned.

Reason 1

Excellent price/

performance ratio. Increased

productivity = savings.

The Admiral 28 and 30 offer optimum operator

comfort with excellent view of all operational con-

trols.

Equipped with disc (Admiral 30) or cylindrical

(Admiral 28) brush unit these scrubbers power

through industrial applications.

Clearly laid out control

panel

All operational controls are in

direct view and reach of the

operator. These controls are

easy to understand and easy

to use.

Aqua-Stop

Up to 50% savings of water and

cleaning agents. Electronically

controlled water dosage with

memory function.

Handy

Mountings and storage area for

any cleaning utensils to be

transported and outlet valves

for quick, clean tank emptying.

Highly maneuverable

Turning radius 66.5” in aisles.

Rear turning,parabolic squeegee

and front wheel drive with 90°

steering angle in both direc-

tions.

Strong

The large volume tank helps cut

down on filling time and increases

run time. Large tank opening for

cleaning.

Safe

The parabolic squeegee vacu-

ums up all the water complete-

ly. The floor is dry enough to

walk on.

A choice of brush systems

Disc or cylindrical brushes

ensure that the machine can be

adapted to suit the specific

application conditions.

Optimum scrubbing even on

structured floors and tiled sur-

faces.

There are Many Great Reasons to

Own an Admiral 28 or 30.

Comfortable operators compartment Large solution/recovery tanks

Choice of disc (Admiral 30) or cylin-

drical (Admiral 28)

Clearly laid out control

panel for ease of operation

Single front wheel drive for

optimum turning radius

Parabolic squeegee vacuums

up all water completely
