SC351

PARTS LIST

Advance model: 9087342020

9099868000(1)2013-03

02 D10II ADVANCE 9099868000(1).indd 1 24-Apr-13 11:21:22

02 D10II ADVANCE 9099868000(1).indd 2 24-Apr-13 11:21:22

PARTS LIST

03/2013 9099868000 - SC351 1

ENG PAGE

GENERAL VIEW 2 - 3

COVER AND TANKS 4 - 5

FRAME SYSTEM 6 - 7

HANDLE SUPPORT SYSTEM 8 - 9

HANDLE BAR SYSTEM 10 - 11

MOTOR AND DECK SYSTEM 12 - 13

BRUSH DECK SYSTEM 14 - 15

ACCESSORIES 16 - 17

ELECTRICAL DIAGRAM 18 - 19

RECOMMENDED SPARE PARTS 20

OPTIONALS AND ACCESSORIES 21

WHEN ORDERING PARTS

* Use the part numbers from the “Ref. No.” columns in this parts list.

* Specify the model and serial number of the machine.

* Use the space below to record the model and serial number for future reference.

Model Serial No.

* = Optional

#= Modied item No. or New item No.

[ ] = Not shown

TABLE OF CONTENTS

02 D10II ADVANCE 9099868000(1).indd 1 24-Apr-13 11:21:22

PARTS LIST

2SC351 - 9099868000 03/2013

GENERAL VIEW

6

4

2

8

5

79

3

11

1

12

13

10

02 D10II ADVANCE 9099868000(1).indd 2 24-Apr-13 11:21:25

PARTS LIST

03/2013 9099868000 - SC351 3

GENERAL VIEW

KIT ITEM REF. NO. QTY DESCRIPTION

1 - 1 BRUSH DECK

2 - 1 SOLUTION TANK

3 - 1 COVER TANK

4 - 1 FRAME

5 - 1 BATTERY COVER

6 - 1 RECOVERY TANK

7 - 1 HANDLE

8 9100000080 1 DECALS ADVANCE SC351 KIT

9 1464853000 1 BATTERY 12V 84AhC5 AGM

10 9099301000 1 HARDWARE GENERAL VIEW KIT

11 9096914000 1 CABLE EXTENSION US

12 9099706000 1 VACUUM PIPE D.25

13 9098991000 1 RINGS SPRING KIT

02 D10II ADVANCE 9099868000(1).indd 3 24-Apr-13 11:21:25

PARTS LIST

4SC351 - 9099868000 03/2013

COVER AND TANKS

2

4

6

1

5

3

7

10

9

8

11 12

13

16

17

24

18

15

20

21

22

23

14

K1

11

19

02 D10II ADVANCE 9099868000(1).indd 4 24-Apr-13 11:21:26

PARTS LIST

03/2013 9099868000 - SC351 5

COVER AND TANKS

KIT ITEM REF. NO. QTY DESCRIPTION

K1 1 1 COVER TANK

K1 2 1 CAGE FLOAT

K1-K2 3 6 SCREW 3.5X10 THD FORMING

K1 4 1 BALL FLOATING

K1 5 1 CAP TANK COVER

K1 6 9099127000 1 GASKET TANK COVER KIT

K1 7 1 GASKET MOUSSE D.4MM

89098318000 1 BATTERY COVER

9 145 1147 000 1 WASHER 10,2X18,8X0,35

10 146 2449 000 1 PLUNGER INDEXING

K2 11 10 SCREW CYL HD 5X16 SELF L.

K2 12 6 WASHER

K2 13 2 BUSH

14 9098309000 1 SUPPORT BATTERY COVER

15 9098149000 1 TANK SOLUTION RAL 7001

16 9100000104 1HANDLE DETERGENT TANK

17 9099155000 1 CAP THREADED 70X5

18 9098621000 2PLATE HANDLE TANK

19 9098473000 2 COVER PIN

K2 20 4WASHER M4 UNI6592

K2 21 4 SCREW 3.5X12

22 9098148000 1TANK RECOVERY RAL 7001

23 9100000103 1 HANDLE RECOVERY TANK

24* 9099011000 1 HOSE FILLING KIT

K1 9098989000 1 COVER KIT

[K2] 9098990000 1 HARDWARE COVER AND TANKS KIT

02 D10II ADVANCE 9099868000(1).indd 5 24-Apr-13 11:21:26

PARTS LIST

6SC351 - 9099868000 03/2013

FRAME SYSTEM

20

16

28

19

17

25

K1

47

IN

OUT

5

23

14

2

13

22 18

24

9

29

15

12

8

6

11

3

21

26 1 10 27

02 D10II ADVANCE 9099868000(1).indd 6 24-Apr-13 11:21:27

PARTS LIST

03/2013 9099868000 - SC351 7

FRAME SYSTEM

KIT ITEM REF. NO. QTY DESCRIPTION

K1 1 1 REDUCTION WATER

K2 2 2 WASHER FLAT XL 6.6X24.0X2.0

K2 3 2 SCREW, PAN PHIL THD FORM PU 3.9X9.5

K2 4 3 NUT SELF L. M6 UNI7474 SS

K2 5 2 PLUG BLACK CLICK d.38.1

K2 6 2 WASHER 6X18 UNI6592

K2 7 2 SCREW M6X20 UNI5731

K2 8 3 WASHER

K2 9 4 SCREW SOC. HD M5X30

K1 10 1 FITTING

K2 11 2 WASHER, EXT. SHPRF Ø 4 SS

K2 12 2 SCREW

13 9099732000 2 WHEEL Ø214

K2 14 2 WASHER, SPLIT LOCK d.6

15 9099794000 1 CHARGER BATTERY 12V 12A (CH)

16 9098319000 1 GASKET

17 146 3054 000 1 BELT BATTERY FIXING

K1 18 1 CLAMP

19 9099719000 1 SUPPORT FOR GASKET

20 9098697000 1 VALVE WATER COMPLETE

K2 21 2 SCREW THREAD ROLLING 5x16

K1 22 1 HOSE D.12 L=500 MM

K2 23 2 SCREW, HEX THD TO HD M6x16

K2 24 2 WASHER 12.5X34X3 NYLON

25 9099352000 1 PIN WHEEL

K1 26 1 HOSE D. 12

K1 27 1 PIPE 6X11

K2 28 1 CLAMP 290X4.8

K2 29 4 WASHER FLAT XL 5.5X15.0X1.6 SS

K1 9098992000 1 PIPES KIT

[K2] 9100000083 1 HARDWARE FRAME KIT

02 D10II ADVANCE 9099868000(1).indd 7 24-Apr-13 11:21:27

PARTS LIST

8SC351 - 9099868000 03/2013

HANDLE SUPPORT SYSTEM

15

16

2

32

31

512

13 3

26

25

21

44

1

43

19

14

6

39

8

10

22

11

38

41

17

10

17

34

20

37

36

35

28

18

24

27

23

97

29 33 414

4030 3 42

02 D10II ADVANCE 9099868000(1).indd 8 24-Apr-13 11:21:28

PARTS LIST

03/2013 9099868000 - SC351 9

HANDLE SUPPORT SYSTEM

KIT ITEM REF. NO. QTY DESCRIPTION

1 9098760000 2 CONNECTOR 50A GREY

2 9098924000 2 FUSE HOLDER

K1 3 5 NUT SELFLOCKING LOW M8 UN

4 909 6542 000 2 GROMMET

K1 5 2 SCREW M3X16 UNI7687

K1 6 3 SCREW 3.5X10 THD FORMING

K1 7 4 WASHER M8 UNI6592 SS

K1 88 NUT SELF L. M6 UNI7474 SS

K1 9 4 SCREW M8X20 UNI5739 SS

K1 10 8 WASHER M6 UNI6592 SS

K1 11 2 SCREW SOC. HD M6X16

K1 12 2 WASHER, EXT. SHPRF Ø 3 SS

K1 13 2 SCREW, CARRIAGE M6x35

14 9098441000 1 RELAY 12V (K2)

K1 15 2 SCREW, HEX THD TO HD M6x16 SS

16 9099802000 1 BREAKER CIRCUIT 35A (F1)

K1 17 4 SCREW M5X10 DIN7500

18 9098111000 1 MOTOR VACUUM 12V 200W (M2)

19 9098112000 1 SOLENOID VALVE 12V (EV)

20 9098185000 2 BRACKET HANDLE

21 9098267000 1 SUPPORT HANDLE

22 9098268000 1 SUPPORT VACUUM MOTOR

23 9098319000 1 GASKET

24 9098327000 1 GASKET VACUUM MOTOR

25 9098365000 1 COVER RELAY

26 9098482000 1 BRACKET PLUNGER BLOCK

27 9098483000 1 COVER VACUUM MOTOR

28 9098554000 1 GASKET VACUUM MOTOR

29 9098375000 1 TIMER CYCLICAL (KT1)

K1 30 2 CLAMP

31 145 8513 000 1 FUSE BLADE 30A UL (F2)

32 145 9852 000 1 FUSE 5A (F3)

33 146 3113 000 1 RELAY 12V (K1)

34 9099731000 1 CIRCUIT BRAKE SUPPORT

K1 35 2 SCREW M6X12 UNI5931 SS

K1 36 3 WASHER, EXT. SHPRF Ø 6 SS

37 9098559000 1 SPACER SUPPORT VACUUM MOTOR

38 9098656000 1 CASING VACUUM MOTOR

39 9098925000 1 CASING LOWER VACUUM MOTOR

K1 40 1 SCREW, BUTTON SOC M8X55

K1 41 4 CLAMP

K1 42 2 SCREW, BUTTON SOC M 10X25 SS

43 9099330000 1 HARNESS MACHINE

44 9098849000 1 HARNESS BATTERY

[K1] 9100000084 1 HARDWARE HANDLE BAR SUPP. KIT

02 D10II ADVANCE 9099868000(1).indd 9 24-Apr-13 11:21:28

PARTS LIST

10 SC351 - 9099868000 03/2013

HANDLE SYSTEM

54

48

1

51

47

43

25

19

29

46

30

31

50

55

37

42

38

44 6

52

26

33

K1

K3

13

23

24

20

34

28K4 49 27 45 53 40 32 36 41

8

12

7

4

10

9

35

14

15

17

16

11 18

20 21

2322 5

57

58 56

39

K5

K5

K5

K2

K5

02 D10II ADVANCE 9099868000(1).indd 10 24-Apr-13 11:21:34

PARTS LIST

03/2013 9099868000 - SC351 11

HANDLE SYSTEM

KIT ITEM REF. NO. QTY DESCRIPTION

K3 1 3 WASHER

2 L08603153 1 SWITCH PUMP (SW3)

3 L08603154 1 CAP PROTECTION

K5 4 2 WASHER 6X18X1.5 UNI6593

K5 5 2 SCREW M3X8 UNI7688

K5 6 1 CLAMP 290X4.8

K5 7 2 WASHER

K5 8 2 CLAMP

K5 9 2 SCREW 3.9X9.5 UNI6955

K5 10 2 INSERT M6X15 UNI9203

11 146 3073 000 1 BOARD. LED (EB1)

K5 12 2 SCREW M6X16 UNI7687 SS

13 909 5149 000 1 SUPPORT CABLE

14 9097283000 1 KNOB CONTROL FUNCTIONS

K5 15 1 SCREW GRUB M3X3 DIN916

K5 16 2 SCREW 2.9X25 UNI6954 THD

K5 17 1 SEAL O-RING

18 9099331000 1 HARNESS HANDLE BAR

19 9099332000 1 SWITCH ROTATIVE 4 POSITIONS (SW1)

20 9100000101 1 COVERS HANDLE GREY KIT

21 9099733000 1 DECAL CONTROL PANEL

22 9098616000 1 DECAL BATTERY LED

23 9098812000 1 CAP FOR HANDLE

24 9098813000 1 CAP D.18.5/D.40MM BLACK

25 9098835000 1 TUBE HANDLE

26 9098836000 1 ROD INDEX

K4 27 2 LEVER SWITCH

K4 28 1 LEVER

K1 29 1 CAP RUBBER

K1 30 1 COVER REAR

K1 31 1 COVER FRONT

K4 32 1 BUTTON INTERLOCK

33 VF47033 1 RETAINER

34 VF54041 1 HANDLE PLUG

35 40263A 1 SWITCH DPDT (SW2)

K4 36 1 SPRING INTERLOCK BUTTON

K2 37 1 SPRING COMPRESSION

K2 38 1 GEAR

K2 39 1 HOUSING GEAR INDEX

K4 40 1 CLAMP CORD

K4 41 4 PIN HANDLE SUPPORT

K2 42 1 GEAR INDEX

K3 43 1 HANDLE SUPPORT

K2 44 2 PLATE, GEAR HOUSING

K4 45 2 SCREW M3X25

K1 46 4 SCREW ST4.2-1.4

K3 47 1 SCREW M5X43

K3 48 1 NUT LOCK M5 SS HEX

K4 49 1 NUT LOCK M4 SS HEX

K2 50 4 NUT LOCK M6 SS HEX

K3 51 1 SCREW M5X40 SS PAN HEAD PHILLIPS

K5 52 2 SCREW M4X8 UNI7688

K4 53 3 SCREW M4X10 SS PAN HEAD PHILLIPS

K3 54 6 SCREW M5X12 TRUSS HEAD PHILLIPS

K2 55 4 SCREW M6X40 SS HEX HEAD

56 80398A 2 SCREW M5x35 SS HEAD PHILLIPS

57 VV13609 1 NUT LOCK M6 SS HEX

58 80407A 4 SCREW M5X25 SS FLAT HEAD PHILLIPS

K1 11271A 1 LOWER COVER KIT

K2 11272A 1 BOX HOUSING GEARS KIT

K3 11273A 1 HANDLE SUPPORT KIT

K4 11274A 1 HANDLE SWITCH LEVER KIT

K5 9098995000 1 HARDWARE HANDLE BAR KIT

02 D10II ADVANCE 9099868000(1).indd 11 24-Apr-13 11:21:34

PARTS LIST

12 SC351 - 9099868000 03/2013

MOTOR AND DECK SYSTEM

17

16

14

1

19

18

8

6

4

7

15

3

2

13

5

11

10

12

30

24

31

20

24

25

26

27

21 28

33

34

9

34

32

23

22

29

SEE

BRUSH DECK

SYSTEM

K1

02 D10II ADVANCE 9099868000(1).indd 12 24-Apr-13 11:21:35

PARTS LIST

03/2013 9099868000 - SC351 13

MOTOR AND DECK SYSTEM

KIT ITEM REF. NO. QTY DESCRIPTION

1 L08812203 2 KNOB

2 L08812306 1 HOUB.BRUSH R.GEARMOTOR RIGHT

3 L08812480 1 HUB, BRUSH

K2 4 1 SCREW, HEX THD TO HD M8x20 SS

K2 5 4 SCREW SOC. HD M6X50

K2 6 1 WASHER FLAT XL 9.0X32.0X2.5 SS

K2 7 3 SCREW SOC. HD M6x20 SS

8 9098557000 2 PIN, BRUSH PLATE FIXING

K1 9 1 SQUEEGEE

10 9099717000 1 FLANGE DECK

11 9099736000 1 SPACER LIMIT

12 9099181000 1 REDUCTION MOTOR GEAR 12V 260W (M1)

13 145 8024 000 1 KEY 5X 5X25

K2 14 2 WASHER, FLAT 5.3x10x1 SS

K2 15 3 WASHER NORD LOCK M6

K2 16 2 NUT, HEX NYL LOC THIN M5 SS

17 L08812426 2 CAP

K2 18 2 WASHER FLAT XL 10X30X2 - RUBBER

K2 19 4 WASHER FLAT 9,5X27X2.5

20 9099718000 1 SUPPORT DECK

21 L08601624 1 HOLDER RUBBER 1/4 D.10

22 L08812213 2 SHOCK ABSORBER

23 L08812779 2 PLATE, VIBRATION DAMPING

K2 24 2 ROND GREMB 8X24

K2 25 1 SCREW, HEX THD TO HD M8x12

K2 26 4 SCREW SOC. HD M6X25 SS

K2 27 4 NUT, HEX NYL LOC HVY M6

K2 28 4 NUT, HEX NYL LOC THIN M6

K2 29 4 SCREW, HEX THD TO HD M6x35 SS

K2 30 1 NUT, HEX NYL LOC THIN M8 SS

31 9097184000 1 SHOCK ABSORBER 40x30 M8 TYPE EI - 60 Sh

K1 32 9099707000 1 REAR STRAP ELASTIC

K1 33 9099708000 1 RUBBER BLADE RETAINER

K1 34 9100000077 1 BLADES SQUEEGEE KIT

K1 9100000085 1 SQUEEGEE KIT

[K2] 9100000086 1 HARDWARE MOTOR AND DECK KIT

02 D10II ADVANCE 9099868000(1).indd 13 24-Apr-13 11:21:36

PARTS LIST

14 SC351 - 9099868000 03/2013

BRUSH DECK SYSTEM

8 7 1 14

212

164

151115

7

1

8

13

9

10

13

15

17

5

3

12

6

02 D10II ADVANCE 9099868000(1).indd 14 24-Apr-13 11:21:36

PARTS LIST

03/2013 9099868000 - SC351 15

BRUSH DECK SYSTEM

KIT ITEM REF. NO. QTY DESCRIPTION

1 L08603665 2 WHEEL D51 SQUEEGEE

K2 2 2 SCREW FLAT SOCKET HEAD M8X20.0

K2 3 2 NUT, HEX THIN M6

K2 4 2 SCREW, CARRIAGE M6x25

K2 5 2 WASHER FLAT XL 6.6X24.0X2.0

K2 6 1 NUT, HEX NYL LOC THIN M10

K2 7 4 THREAD ROLLING SCR 5x16

K2 8 2 PIN D.8

9 9099163000 1 CASTOR WHEEL ø42

10 9099712000 1 COVER BRUSH DECK

11 9099713000 1 FLANGE CENTRAL

K1 12 2 CLUTCH SUPPORT

K1 13 2 CLUTCH

14 9100000040 1 COUNTERWEIGHT

15 9099720000 3 SPRING TRACTION

16 30048A 2 GUIDE, WHEEL

K2 17 2 WASHER 15

K1 9100000087 1 CLUTCH KIT

K2 9100000088 1 HARDWARE BRUSH DECK KIT

02 D10II ADVANCE 9099868000(1).indd 15 24-Apr-13 11:21:36

PARTS LIST

16 SC351 - 9099868000 03/2013

ACCESSORIES

1

2

3

4

6

5

02 D10II ADVANCE 9099868000(1).indd 16 24-Apr-13 11:21:37

PARTS LIST

03/2013 9099868000 - SC351 17

ACCESSORIES

KIT ITEM REF. NO. QTY DESCRIPTION

19099999000 1 BRUSH D.370MM 14” PROLENE PPL

1* 9100000001 1 BRUSH D.370MM 14” PROLITE PPL

1* 9100000000 1 BRUSH D.370MM 14” UNION MIX

1* 9100000002 1 BRUSH D.370MM 14” MID GRIT 240

1* 9100000003 1 BRUSH D.370MM 14” MIDLITE GRIT 180

2* 9099672000 1 PAD HOLDER GRIP 14”

3 L08603966 1 RING NYLON

4 L08837030 1 RETAINER PAD

5 L08603965 1 SEAL O-RING

6* 10001918 1 PAD 14 355MM BROWN 5 PCS

6* 10001920 1 PAD 14 355MM RED 5 PCS

6* 10001921 1 PAD 14 355MM WHITE 5 PCS

6* 10001919 1 PAD 14 355MM GREEN 5 PCS

02 D10II ADVANCE 9099868000(1).indd 17 24-Apr-13 11:21:37

PARTS LIST

18 SC351 - 9099868000 03/2013

WIRING DIAGRAM

02 D10II ADVANCE 9099868000(1).indd 18 24-Apr-13 11:21:37

PARTS LIST

03/2013 9099868000 - SC351 19

KEY COLOUR COLORE

BK BLACK NERO

BU LIGHT BLUE AZZURRO

BN BROWN MARRONE

GN GREEN VERDE

GY GREY GRIGIO

OG ORANGE ARANCIONE

KEY COLOUR COLORE

PK PINK ROSA

RD RED ROSSO

VT VIOLET VIOLA

WH WHITE BIANCO

YE YELLOW GIALLO

WIRING DIAGRAM

KEY REF. NO. DESCRIPTION

BAT 1464853000 BATTERY 12V 84AhC5 AGM

CH 9099794000 BATTERY CHARGER

D1 - DIODE

D2 - DIODE

EB1 146 3073 000 BATTERY LEVEL BOARD

EV 9098112000 DETERGENT SOLENOID VALVE

F1 9099802000 BRUSH MOTOR CIRCUIT BREAKER (35 A)

F2 145 8513 000 VACUUM MOTOR FUSE (30 A)

F3 145 9852 000 ROTATIVE SWITCH FUSE (5 A)

K1 146 3113 000 BRUSH MOTOR RELAY

K2 9098441000 VACUUM MOTOR RELAY

KT1 9098375000 SOLENOID VALVE TIMER

M1 9099181000 BRUSH MOTOR

M2 9098111000 VACUUM MOTOR

SW1 9099332000 ROTATIVE SWITCH

SW2 40263A SWITCH BRUSH MOTOR-SOLENOID VALVE

SW3 L08603153 DETERGENT SWITCH

KEY COLOUR

BK BLACK

BU LIGHT BLUE

BN BROWN

GN GREEN

GY GREY

OG ORANGE

KEY COLOUR

PK PINK

RD RED

VT VIOLET

WH WHITE

YE YELLOW

02 D10II ADVANCE 9099868000(1).indd 19 24-Apr-13 11:21:38

PARTS LIST

20 SC351 - 9099868000 03/2013

RECOMMENDED SPARE PARTS

REF. NO. QTY DESCRIPTION

NORMAL WEAR

9100000077 1 BLADES SQUEEGEE KIT

9099999000 1 BRUSH D.370MM 14” PROLENE PPL

ORDINARY MAINTENANCE

9099707000 1 REAR STRAP ELASTIC

9099708000 1 RUBBER BLADE RETAINER

9099127000 1 GASKET TANK COVER KIT

9098319000 2 GASKET

9098111000 1 MOTOR VACUUM 12V 200W (M2)

9098327000 1 GASKET VACUUM MOTOR

9098655000 1 FILTER VACUUM MOTOR

9099181000 1 REDUCTION MOTOR GEAR 12V 260W (M1)

L08812480 1 HUB.BRUSH

9099706000 1 VACUUM PIPE D.25

L08603665 2 WHEEL D51 SQUEEGEE

9099163000 1 CASTOR WHEEL ø42

9100000087 1 CLUTCH KIT

9100000085 1 SQUEEGEE KIT

EXTRA-ORDINARY MAINTENANCE

9099712000 1 COVER BRUSH DECK

30048A 2 GUIDE, WHEEL

9099732000 2 WHEEL Ø214

9099794000 1 CHARGER BATTERY 12V 12A (CH)

9098697000 1 VALVE WATER COMPLETE

9098992000 1 PIPES KIT

9098760000 2 CONNECTOR 50A GREY

9099802000 1 BREAKER CIRCUIT 35A (F1)

9098112000 1 SOLENOID VALVE 12V (EV)

146 3113 000 1 RELAY 12V (K1)

9098441000 1 RELAY 12V (K2)

9098375000 1 TIMER CYCLICAL (KT1)

145 8513 000 1 FUSE BLADE 30A UL (F2)

145 9852 000 1 FUSE 5A (F3)

9099332000 1 SWITCH ROTATIVE 4 POSITIONS (SW1)

40263A 1 SWITCH DPDT (SW2)

L08603153 1 SWITCH PUMP (SW3)

02 D10II ADVANCE 9099868000(1).indd 20 24-Apr-13 11:21:38

PARTS LIST

03/2013 9099868000 - SC351 21

OPTIONALS AND ACCESSORIES

REF. NO. QTY DESCRIPTION

9099011000 1 HOSE FILLING KIT

9100000001 1 BRUSH D.370MM 14” PROLITE PPL

9100000000 1 BRUSH D.370MM 14” UNION MIX

9100000002 1 BRUSH D.370MM 14” MID GRIT 240

9100000003 1 BRUSH D.370MM 14” MIDLITE GRIT 180

9099672000 1 PAD HOLDER GRIP 14”

10001918 1 PAD 14 355MM BROWN 5 PCS

10001920 1 PAD 14 355MM RED 5 PCS

10001921 1 PAD 14 355MM WHITE 5 PCS

10001919 1 PAD 14 355MM GREEN 5 PCS

02 D10II ADVANCE 9099868000(1).indd 21 24-Apr-13 11:21:38

14600 21st Avenue North

Plymouth, MN 55447-3408

www.advance-us.com

Phone: 800-989-2235

Fax: 800-989-6566

©2013 Nilfisk-Advance, Inc.

A Nilfisk-Advance Brand

02 D10II ADVANCE 9099868000(1).indd 22 24-Apr-13 11:21:38
