Sentinel

HIGH-PERFORMANCE OUTDOOR SWEEPER

 Deliver excellent sweeping performance in the harshest, most

congested environments

 Achieve consistent cleaning results from all-weather sweeping capability

 Ensure a healthy and safe environment with improved air quality

from PM-10 certified dust control system

 Maximize operator comfort and safety with full-view,

cab-forward design

EQUIPMENT

CREATING A CLEANER, SAFER, HEALTHIER WORLD.

®

KEY SENTINEL

® SWEEPER FEATURES TO HELP MAXIMIZE

PRODUCTIVITY, REDUCE COSTS, AND INCREASE SAFETY



Main brush center-point suspension allows main broom to follow the

contours of uneven surfaces for optimum sweeping and dust control.



Hydraulic twin-vacuum dust control system meets the most stringent

PM-10 environmental air quality requirements.



Roomy, sealed pressurized cab interior keeps noise out and dust down for

increased operator safety.



Separate vacuum fan shuto allows operator to easily power o vacuum

fans when sweeping in wet conditions.



Pneumatic tires with leaf-spring suspension absorb many road shocks for

less vibration of components and operator comfort.



Optional Vario Sweeping Brush™ sweeps on both sides of the Sentinel with

a 56 in / 1,420 mm reach from machine side to outside tips of the brush.



Optional rear vision camera with in-cab monitor helps to provide 360°

visibility around the machine for safe maneuvering.



Optional multi-level dump hopper enables discharge into large roll os and

dump trucks preventing double handling of debris.



Optional front and rear warning lights provide high visibility for maximum

machine awareness.



Sentinel dust control congurations:

• Dry Side Brush Dust Control

• Wet Side Brush Dust Control

• Wet and Dry Side Brush Dust Control

THE SENTINEL® DELIVERS EXCEPTIONAL BENEFITS TO MEET

YOUR SWEEPING CHALLENGES

REDUCE COST TO CLEAN

Keep costs low with solid shaft design that increases conveyor life over previous models,

reducing cost of ownership.

HEALTH & SAFETY

Protect employees and facilities from potentially harmful dust with the unique, twin-vacuum

all-weather dry dust control system with PM-10 certication.

ENHANCE FACILITY IMAGE

Ensure your facilities are always looking great with a robust and proven design that enables

you to sweep in any season.

EASY OPERATION & MAINTENANCE

Deliver consistent sweeping results and easily maneuver through congested areas with

four-wheel power steering.

A HIGH-PERFORMANCE, ALL-WEATHER OUTDOOR

SWEEPER WITH EXCEPTIONAL DUST CONTROL FOR

CLEANING IN HARSH, CONGESTED ENVIRONMENTS.

INSIDE THE

Sentinel

Excellent dry dust control featuring

full skirting around side brushes

and main brush, using durable

high-density polyethylene skirts and

rubber coated nylon covers.

Wet dust control with adjustable spray

nozzles helps knock down dust with

ne water mist fed from a 94 gal /

355 liter on-board water tank.

Machine maintenance made

quick with easy access to

engine and conveyor.

(Photo shown with optional accessories.)

Long lasting synthetic lter made from

water-resistant, singed polyester helps

protect lter life

Solid shaft design with built-in

conveyor obstruction alert

maximizes conveyor life

99.9 hp / 74 kW CAT turbo diesel

powered engine increases machine

eectiveness in tough applications

TotalView™ glass doors

and cab-forward design

maximize sweeping safety

Left-hand side brush widens sweeping path to

87 in / 2,210 mm for increased productivity

Hydraulic-driven, spring-loaded side

brush retracts on impact for decreased

maintenance costs

Main brush center-point suspension

for sweeping uneven surface types Direct throw system and debris conveyor

collects virtually all forms of debris

Corrosion-resistant stainless

steel hopper captures

virtually all types of debris

Standard audio back-up

and hopper raise alarm

for operator and

employee protection

Hydraulic twin-vacuum

fans maximize dust control

®

KEY AVAILABLE FEATURES

4-Wheel power steering allows easy access to tight

spaces by delivering a 13 ft / 3,960 mm turning

radius with exceptional maneuverability.

One touch activation simplies operator training

with controls that enable sweeping systems to be

activated with a single button.

Optional 9.5 ft / 2,900 mm multi-level dump, with

hopper overload indicator, enables you to easily

empty debris in most places you need.

ENGINEERED FOR PRODUCTIVITY AND VERSATILITY

Optional high-pressure

spray hose delivers

powerful o-machine

cleaning.

KEY OPTIONS

TECHNOLOGY PROVIDES GREATER FLEXIBILITY

IN HARD TO REACH AREAS

Optional Vario Sweeping Brush™ allows the Sentinel to collect hard-to-reach debris

from corners while keeping the sweeper from riding up on curbs; giving the

operator the ability to sweep on top of curbs, around xed obstacles and in

congested areas for increased productivity and more eective sweeping.

Optional rear view

camera provides

additional visibility for

easy maneuvering.

Optional air ride

suspension seat

enhances operator

comfort and safety.

Optional vacuum wand

enables operators to

clean under and around

obstructions.

CONVEYOR SELF-TENSIONING

4-WHEEL STEERING

OPTIONAL VARIO SWEEPING BRUSH™

ONE-TOUCH ACTIVATION

OPTIONAL MULTI-LEVEL DUMP

SENTINEL® HIGH-PERFORMANCE OUTDOOR SWEEPER

SWEEPING SYSTEM

Cleaning path

Single side brush 69 in / 1,750 mm

Dual side brushes 87 in / 2,210 mm

With dual side brushes and Vario Sweeping Brush™ 126 in / 3,200 mm

BRUSH DRIVE SYSTEM

Main brush length (tubular) 51 in / 1,295 mm

Main brush lift Hydraulic

Main brush diameter 24 in / 610 mm

Side broom diameter (disk) 32 in / 810 mm

Vario Sweeping Brush™ Diameter 38 in / 965 mm

Hopper volume capacity 3.4 yd3 / 2.6 m3

Hopper weight capacity (stainless steel)

Low dump 7,000 lb / 3,175 kg

High dump 4,000 lb / 1,815 kg

Hopper dump height

Low dump 40 in / 1,015 mm

High dump 114 in / 2,895 mm

PROPELLING SYSTEM

Engine, turbo diesel, Caterpillar 99 hp / 74 kW

Propel speed forward (variable to) 25 mph / 40 km/h

Propel Type Hydrostatic

Gradeability

Full hopper 8 deg / 14%

Empty hopper 12 deg / 21%

DUST CONTROL SYSTEM

Filter system Dry-ltering

Filter type Mildew resistant, synthetic envelope style

Filter area 221 ft2 / 21 m2

Dust ltration (to) PM-10 certied, AQMD-Rule 1186 Certied

Vacuum fan motor (2) 15 hp each / 11 kW each

MACHINE SPECIFICATIONS

Length

Standard machine 175 in / 4,445 mm

With Vario Sweeping Brush 206 in / 5,230 mm

Width 70 in / 1,780 mm

Height 100 in / 2,540 mm

Weight-net base machine 12,500 lb / 5,670 kg

Turning radius 13 ft / 4 m

WARRANTY

See your local representative for warranty information.

Specications subject to change without notice.
