Bringing Small Orbital
Cleaning to All Areas.
Why Look Anywhere Else?
www.tomcatequip.com
1(800) 450-9824
(+001) 262-681-6470
Scan This QR
Code With
Your Phone
For More
Information
HANDMADE IN THE USA
ERGONOMIC HANDLE
OPERATOR EASE
WHILE HANDLING
DUAL HANDLE MOUNTING
EASY SPRING LATCH RELEASE
EASY DISCONNECT
QUICKLY DISCONNECT
ELECTRICAL FOR TRANSPORT
ALUMINUM PLATE
WEAR AND CORROSION
RESISTANT
WEIGHTS FOR DEEP CLEANING
UNDERNEATH THE CASING ARE HD
WEIGHTS TO ALLOW HIGH PSI CLEANING
HEAVY DUTY CASING
THICK POLY CASES THE
MOTOR FOR PROTECTION
Clean Stairs and Bleachers with Ease!
BODY CONSTRUCTION / DIMENSIONS
Chassis Construction: 10 Gauge Steel (3 mm)
Scrub Head Size (L × W × H): 9.75'' × 4'' × 6.25'' (25 × 10 × 16 cm)
Handlebar Size (L × Diameter): 51.25'' × 1'' (130 × 3 cm)
Weight: 22 lbs (10 kg)
BRUSH / PAD SYSTEM
Dimensions: 10.5'' × 5.25'' (27 x 13 cm)
Motor Power: .33 hp (246 watts)
Motor Speed: 4,100 rpm
Current Draw: 1.2 amps (@120 VAC / 60 Hz)
POWER SYSTEM:
System Voltage: 120 VAC / 50-60 Hz (240 VAC / 50-60 Hz)
Cord Length: 30 ft / 18 Gauge (9 m / 1 mm)
GENERAL:
Cleaning Path: 10.5'' (27 cm)
Sound Level: Under 57 dBA
Vibration at Base: Avg. 6.5 mm/s2, MAX @ 6.8 mm/s2 (Avg. 5.8 mm/s2, MAX @ 6.0 mm/s2)
Vibration at Handle: 2.13 mm/s2 (Passed Requirements)
(11/16) TC-NANOEDGE-SALESSHEET
AUTHORIZED DISTRIBUTOR
www.tomcatequip.com
Phone: (800) 450-9824
International: (+001) 262-681-6470
© RPS Corporation 2016 All Rights Reserved As our policy is one of constant improvement, all
specifications are subject to change without notice.
Optional Baseboard Cart for:
• Cleaning of grout lines in baseboard
• Stripping residual baseboard finish
• Cleaning of stairs
Order as an option: NANO-5000
LIST Cost: $249.00
