Rugged Design for

Lasting Performance

Certain environments can exact a heavy toll on even the most

ruggedly designed cleaning equipment. Tornado’s® P Series of

Floor Machines have it all when it comes to heavy-duty applica-

tions and are built for years of trouble-free operation and long-

lasting performance.

Our patented, non-conductive one piece rotationally molded

body is designed to absorb the torque and vibration normally

felt when operating a floor machine. The one piece base and

motor housing ensures that wires and capacitors are complete-

ly enclosed, enhancing the machine’s durability, longevity and

safety. These units are so ruggedly built, they out weigh most

metal machines in the industry today.

Exceeding Performance Benchmarks

All P Series Rotary Floor Machines have a triple planetary gear

system for years of trouble-free use and a 1.5 HP motor to

handle the most demanding jobs. Available in both 17” and 20”

models, Tornado’s® P Series Floor Machines are establishing the

new benchmark for performance and quality in the commercial

cleaning industry.

Maximum Cleaning Efficiency

From daily polishing to heavy scrubbing or stripping, the P Se-

ries of Floor Machines from Tornado® have what it takes for the

cleaning and maintenance professional. These units will maxi-

mize cleaning efficiency, minimize equipment downtime and are

offered at a price that runs circles around the competition.

A better way to clean.

The P Series of Floor Machines

- P 17" 175 RPM

- P 20" 175 RPM

Value, high-performance

and smooth operation.

P 17” 175 RPM Floor Machine

P Series 17” and 20” 175 RPM Floor Machines - Value, high-performance and smooth operation.

Easy Pad Change

Tilt up position allows easy ac-

cess for changing pads.

Patented Design

Keeps motor running COOL,

and provides a longer life.

www.tornadovac.com • Toll free: 1-800-VACUUMS

Phone: (708) 867-5100 • Fax: (708) 867-6968

©2007 Tacony Inc. All rights reserved.

Form#: F2503. Printed in USA.

Easy Access

One-piece motor housing

features eassy access.

All Metal Handle

Sturdy metal handle has safety

lock-out features.

Optional Accessories

3 gallon solution tank attaches

for solution dispensing.

Rugged Design

Triple planetary all steel gears

for smooth power!

PRODUCT SPECIFICATIONS

MODEL P7562 P7564

CATALOG NUMBER 97562 97564

MACHINE DIMENSIONS

L X W X H 31" X 20.5" X 44.5" 31" X 20.5" X 44.5"

NET WEIGHT 103.5 lbs. 104.5 lbs.

MOTOR HEIGHT 19.5" 19.5"

DESIGN CHARACTERISTICS

HOUSING CONSTRUCTION High Density Polyethylene High Density Polyethylene

POWER SYSTEM 115V 115V

WHEEL TYPE / DIMENSIONS 5" Non-Marking-Self Lubricating 5" Non-Marking-Self Lubricating

HANDLE DESIGN / SAFETY All Metal, Positive Lock All Metal, Positive Lock

CLEANING SYSTEM

BRUSH DESIGN / TYPE Rotary Disc Rotary Disc

ROTARY DIAMETER 17" 20"

DISC RPM 175 175

SOLUTION TANK 3 gal. (Optional) 3 gal. (Optional)

CLEANING PATH 17" 20"

MOTORS

MACHINE MOTOR 1.5 HP 1.5 HP

WARRANTY

LABOR 1 year 1 year

PARTS 2 year 2 year

REPLACEMENT ITEMS AND ACCESSORIES

17" PAD HOLDER 717DP 717DP

20" PAD HOLDER 919DP 919DP

3 GALLON SOLUTION TANK F91P F91P

Key Features

• Comes standard with a quick-grip pad holder

• One piece rotationally molded housing that is more resilient than steel and delivers

precision balance, access to the motor and safety features

• Triple planetary gear transmission

• High output 1.5 HP motor with low amp draw for the ultimate in power

• All steel safety lock out on handle with easy access thumb action

• One piece all metal handle tube and switch housing for improved control, switch and

cord security

• Easily accepts an optional shampoo tank

• Can be fitted with pads and brushes for multiple tasks

• Provides 175 rpms of consistent scrubbing power

Flexibility

The Tornado® P Series of Floor Machines provides easy operation, versatility, innovative

features, and durable design for use in many different environments including:

• Hospitals and Healthcare Facilities

• Schools and Universities

• Hotels and Resorts

• Restaurants

• Commercial Office Buildings

• Retail Stores and Shopping Malls

• Industrial Facilities, large and small

P 20” 175 RPM Floor Machine
