Windsor Mini Pro Carpet Extractor Brochure Specifications
2017-01-03
: Sweepscrub Windsor-Mini-Pro-Carpet-Extractor-Brochure-Specifications windsor-mini-pro-carpet-extractor-brochure-specifications 1843 file product_file
Open the PDF directly: View PDF
.
Page Count: 2
Mini Pro™
Small Area Carpet Extractor
Faster, simpler, small area extractor.
» Productively clean and freshen up carpet surfaces with less effort.
» 4 gallon (15 liter) solution and recovery tank for home or commercial cleaning.
» Solution tank designed with no mess splash back protection and protective filter
screen to remove debris, designed for minimal service.
» Comfort grip adjustable handle with one button activation and ergonomically
positioned handle for balanced lifting.
» Fold-down handle for easy transporting in any vehicle.
» Optional hose and hand tool to clean upholstery, stairs, autos, motor homes,
boats and other small areas.
» Quiet, lightweight, easy to use.
Scan the QR code
to watch the Mini Pro
product demonstration
Simple operation.
Large 10" (254 mm) non-marking
wheels for easy transport and
maneuverability.
Vacuum Shoe with wrap around
soft sided bumper for surface
protection.
Floating brush with Perform
Alert™ wear indicators.
High performance vacuum motor
for faster drying time.
Performance Features
Target Markets:
• Hotel Rooms
• Offices
• Retail
Technical Specifications
MPRO
Model Number.: 1.008-039.0
Construction: Rotationally molded polyethylene tanks
and steel frame
Vacuum Shoe: 12.5" (314 mm) cast aluminum
Vacuum Motor: 3-stage, 1.5 hp (1300 watts)
Solution Tank: 4 gal (15 l) with splash back protection
Recovery Tank: 4.5 gal (17.1 l), lift-off design
Performance: 1,070 ft2/hr at 1.6 mph
Pumps: Two, 58 psi (3.9 bar), solenoid type, one for
accessory, one for main jet
Flow Rate: 0.38 gpm at jet
Cleaning Path: 10" (254 mm)
Brush: Floating 10.5" (267 mm) wide, Perform Alert™
wear indicators, US Patent #5,455,979
Brush Motor: 76 watts (1/10 hp), DC rectified
Wheels: Two, 10" (254 mm) non-marking wheels
Power Cable: 25' (7.6 m)
Handle: Adjustable handle, folds for storage and transport
Operating Dimensions (LxWxH): 36.25" (920 mm) x 14" (360 mm) x 30" (760 mm)
Storage Dimensions (LxWxH): 22.5" (570 mm) x 14" (360 mm) x 28" (710 mm)
Weight: 79 lbs (36 kg)
Optional Accessories: Double Dry Hand Tool Kit (8.600-001.0), Standard
Hand Tool (8.621-879.0)
Specifications are subject to change without notice.
Hose And Tool Attachment
For Detail Work
Recovery Tank Removes
Easily For Dumping
Wrap Around Soft-Sided
Bumper For Surface
Protection
Handle Folds Down For
Convenient Storage
Clear Dome To View
Recovery Of Solution
10" Non-Marking Wheels
Provide Easy Transport
Windsor Innovations Protect:
WaterIndoor Air Quality People Environment
© 2012. All rights reserved.
A-525
Bold Innovation. Expert Results.
www.windsorind.com » 800-444-7654
1351 W. Stanford Ave. Englewood, CO 80110 USA
