Saber™ Glide
Rider Scrubber Series
Built to make the operator more productive.
We listened when you told us how to build the rider scrubber you need. The Saber
Glide Series was created to make the people who work with the machine more
productive. From the person cleaning floors every day to the person responsible
for maintenance, these riders deliver the performance features needed to get
the cleaning job done faster.
To help you choose the most productive rider for your facility, the Saber Glide
Series is available in three cleaning width choices—28" (71 cm), 32" (81 cm) and
variable width 28" to 36" (71 to 91 cm).
Filter can be removed and
cleaned without tools. Polyester
filter can be washed and reused.
Intuitively designed control panel
for simple operation.
Seat can be adjusted to suit the
operator.
Two side hoppers for easy
dumping.
Performance Features
Target Markets:
• Parking Lots
• Manufacturing Facilities
• Warehousing/Distributions
• Event Centers
• Hospitality
• Education
• Light Industrial
• Airports
Technical Specifications
Model: SG28 SG32 SG36
Cleaning Path: 28" (71 cm) 32" (81 cm) 28"–36" (71–91 cm)
Brushes: 2 x 14" (35.5 cm) 2 x 16" (41 cm) 3 x 12" (30.5 cm)
Brush Motor: 2 x .8 hp (600 watt) Same 3 x .8 hp (600 watt)
Brush Speed: 300 rpm Same Same
Brush Pressure: 0–225 lbs. (0–102 kg) Same 0–150 lbs. (0–68 kg)
Drive Motor: 1.3 hp (970 watt) Same Same
Maximum Transport
Speed:
4 mph (6.5 km/h) Same Same
Tires: 12" (30 cm) solid, (standard) Same Same
Solution Control: Gravity feed, fully variable
with automatic shut-off in
neutral
Same Same
Solution Tank: 30 gal. (114 liter) Same Same
Recovery Tank: 30 gal. (114 liter) Same
Vac Motor: .75 hp (552 watts), 3 stage Same Same
Electrical System: 36 V – Six 6V 250, 305 or
335 A/H batteries, Chargers
available
36 V – Six 6V 305 or 335 A/H
batteries, Chargers available
36 V – Six 6V 305 or 335 A/H
batteries, Chargers available
Weight:
(without batteries)
790 lbs. (369 kg) Same 825 lbs. (275 kg
Dimensions: (LxWxH) 64" x 33" x 54"
(163 cm x 84 cm x 137 cm)
64" x 38" x 54"
(163 cm x 96 cm x 137 cm)
64" x 33" x 54"
(163 cm x 84 cm x 137 cm)
Options: Backup alarm kit, Flashing
light kit, Headlight kit,
Accessory pump kit,
Second vacuum motor kit,
Solution recycling kit
Same Same
Specifications are subject to change without notice.
Windsor Innovations Protect:
WaterIndoor Air Quality People Environment
© 2010. All rights reserved.
A-411
Bold Innovation. Expert Results.
www.windsorind.com » 800-444-7654
1351 W. Stanford Ave. Englewood, CO 80110 USA
