DIAD IV Terminal
Licensing, Patent and Regulatory Information
© 2003 - 2004 SYMBOL TECHNOLOGIES, INC. All rights reserved.
Symbol and UPS' rights and obligations with relation to the DIAD IV product, including without limitation
product liability and license grants, will be in accordance with Purchase Agreements number: 2001 -
11204 - 01, 2001 - 11204 - 02 and 2001 - 11204 - 03, dated February 13, 2003.
Symbol reserves the right to make changes to any product to improve reliability, function, or design.
Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names
mentioned in this manual may be trademarks or registered trademarks of their respective companies and
are hereby acknowledged.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, N.Y. 11742-1300
http://www.symbol.com
Patents
For patent information, go to: www.symbol.com/patents.
72-63596-01
Revision C — June 2004
Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in the countries listed in
sections 4.5 of Exhibit 2 of the Agreement and will be labeled as required.
Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol
Technologies, could void the user's authority to operate the equipment.
Antenna's, use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could cause damage and may violate regulations.
Radio Modules
This device contains approved radio modules. These modules are identified below.
• Symbol Compact Flash RLAN (11Mbps DSSS) radio card, Type: LA-4137
• Motorola Triband GSM GPRS G18 module, or Motorola CDMA C18 module
• Symbol BluetoothTM Module, Type: 21-64381.
This device incorporates the International Roaming feature (IEEE802.11d) which will ensure the product
operates on the correct channels for the particular country of use.
This device contains a Bluetooth qualified module, Bluetooth ID: B01285 or B00813.
Country Approvals
Regulatory markings are applied to the device signifying the radio (s) are approved for use in the
following countries: United States, Canada, Australia, Japan & Europe 1.
Please refer to the Symbol Declaration of Conformity (DoC) for details of other country markings. This is
available at http://www2.symbol.com/doc/.
Note 1: For 2.4GHz Products: Europe includes, Austria, Belgium, Czech Republic, Croatia, Cyprus,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovak Republic,
Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
Operation of the device without regulatory approval is illegal.
Health and Safety Recommendations
Ergonomic Recommendations
Caution: Even the best-designed products can be a potential source of injury/illness if used incorrectly.
In order to avoid or minimize risk of ergonomic injury, follow the general recommendations below.
Consult with your local Health & Safety Manager to ensure that you are meeting your company’s safety
programs to prevent employee injury.
• Reduce or eliminate repetitive motion.
• Maintain a neutral posture and avoid awkward positions.
• Reduce or eliminate excessive force.
• Keep objects that are used frequently within easy reach.
• Perform tasks at correct heights.
• Reduce or eliminate vibration.
• Reduce or eliminate direct pressure.
• Provide adjustable workstations.
• Avoid static exertions.
• Provide adequate clearance.
• Provide a suitable working environment.
• Improve work procedures.
• Take periodic rest breaks.
For Vehicle installations and use
1. An air bag inflates with great force. DO NOT place objects, including either installed or portable
wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates, serious injury could result.
2. Position your device within easy reach. Be able to access your device without removing your eyes
from the road.
3. Do not take notes or use the device while driving to the point of distracting from driving. Reading
or Jotting down text takes attention away from your primary responsibility, driving safely.
Cell Phone/Terminal Warnings
Effect on Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles
(including safety systems). Check with the manufacturer or its representative regarding your vehicle. You
should also consult the manufacturer of any equipment that has been added to your vehicle.
Safety on Aircraft
You are required to switch OFF mobile phones when on board an aircraft as operation may be dangerous
and illegal.
Pacemakers
It is recommended by pacemaker manufacturers that a minimum of 15cm (6 inches) be maintained
between a handheld wireless phone and a pacemaker to avoid any possible interference with the
pacemaker. These recommendations are consistent with independent research and recommendations by
Wireless Technology Research.
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned
ON.
• Should not carry the device in a breast pocket.
• Should use the ear furthest from the pacemaker to minimise the potential for interference.
• If you have any reason to suspect that interference is taking place, turn OFF your device.
![](/img.php?id=491567&img=bg2.png)
Radio Frequency Interference Requirements
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Label Marking: The Term "IC:" before the radio certification only signifies that Industry Canada technical
specifications were met.
Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN's, for use through the EEA,
have the following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, equipment is restricted to 2.4465 -2.4835 GHz frequency range
• Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz frequency range
• Italy requires a user license for outside usage.
Bluetooth for use through the EEA have the following restrictions:
• Maximum radiated transmit power of 10mW EIRP in the frequency range 2.400 -2.4835 GHz
• Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz frequency range
• Italy requires a user license for outside usage.
In accordance with Clause 5, IEC 825 and EN60825, the following information is provided to the user:
ENGLISH HEBREW
CLASS 1 CLASS 1 LASER PRODUCT
CLASS 2 LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
DANISH / DANSK ITALIAN / ITALIANO
KLASSE 1 KLASSE 1 LASERPRODUKT CLASSE 1 PRODOTTO AL LASER DI CLASSE 1
KLASSE 2 LASERLYF CLASSE 2 LUCE LASER
SE IKKE IND I STRÅLEN NON FISSARE IL RAGGIOPRODOTTO
KLASSE 2 LASERPRODUKT AL LASER DI CLASSE 2
DUTCH / NEDERLANDS NORWEGIAN / NORSK
KLASSE 1 KLASSE-1 LASERPRODUKT KLASSE 1 LASERPRODUKT, KLASSE 1
KLASSE 2 LASERLICHT KLASSE 2 LASERLYS IKKE STIRR INN I LYSSTRÅLEN
NIET IN STRAAL STAREN LASERPRODUKT, KLASSE 2
KLASSE-2 LASERPRODUKT
FINNISH / SUOMI PORTUGUESE / PORTUGUÊS
LUOKKA 1 LUOKKA 1 LASERTUOTE CLASSE 1 PRODUTO LASER DA CLASSE 1
LUOKKA 2 LASERVALO CLASSE 2 LUZ DE LASER NÃO FIXAR O RAIO LUMINOSO
ÄLÄ TUIJOTA SÄDETTÄ PRODUTO LASER DA CLASSE 2
LUOKKA 2 LASERTUOTE
FRENCH / FRANÇAIS SPANISH / ESPAÑOL
CLASSE 1 PRODUIT LASER DE CLASSE 1 CLASE 1 PRODUCTO LASER DE LA CLASE 1
CLASSE 2 LUMIERE LASER CLASE 2 LUZ LASER
NE PAS REGARDER LE RAYON FIXEMENT NO MIRE FIJAMENTE EL HAZ
PRODUIT LASER DE CLASSE 2 PRODUCTO LASER DE LA CLASE 2
GERMAN / DEUTSCH SWEDISH / SVENSKA
KLASSE 1 LASERPRODUKT DER KLASSE 1 KLASS 1 LASERPRODUKT KLASS 1
KLASSE 2 LASERSTRAHLEN KLASS 2 LASERLJUS STIRRA INTE MOT STRÅLEN
NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN LASERPRODUKT KLASS 2
LASERPRODUKT DER KLASSE 2
Scanner Labeling
Statement of Compliance
Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential
requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC.
Declaration of Conformities may be obtained from http://www2.symbol.com/doc/.
Other Countries:
Mexico - Restrict Frequency Range to: 2.450 - 2.4835 GHz.
Israel - Restrict Frequency Range to: 2.418 - 2.457 GHz.
Sri Lanka - Restrict Frequency Range to: 2.400 - 2.430 GHz.
Hearing Aids
The device may interfere with some hearing aids. In the event of interference you may want to consult
your hearing aid supplier to discuss solutions.
Other Medical Devices
The device transmits radio frequency energy and has the potential to interfere with inadequately
protected medical devices. Consult your physician or the manufacturer of the device to see if the
particular device has sufficient protection.
It is good practice to turn OFF the device within a hospital or other medical facility where sensitive
medical equipment is in use. In some countries, this is a legal requirement applying to all mobile phones
and related equipment.
Warning Notices
Please observe all warning notices with regard to the usage of mobile phones and/or terminals.
Potentially Hazardous Atmospheres
You are advised not to use this device at a refuelling point. You are reminded of the need to observe
restrictions on the use of radio devices in fuel depots, chemical plants etc. and areas where the air
contains chemicals or particles (such as grain, dust, or metal powders) and any other area where you
would normally be advised to turn off your vehicle engine.
FCC RF Exposure Guidelines
Safety Information
The device complies with Internationally recognised standards covering Specific Absorption Rate (SAR)
related to human exposure to electromagnetic fields from radio devices.
Reducing RF Influence - Use Properly
It is advisable to use the device only in the normal operating position.
Handheld Devices:
This device was tested for typical body-worn operation. The use of third-party belt-clips, holsters, and
similar accessories should not contain metallic components in its assembly. The use of these
accessories that do not satisfy these requirements may not comply with FCC RF exposure compliance
requirements, and should be avoided.
Laser Devices
Symbol devices using lasers comply with US 21CFR1040.10, and IEC825-1:1993, EN60825-
1:1994+A11:1996. The laser classification is marked on one of the labels on the device.
Class 1 Laser devices are not considered to be hazardous when used for their intended purpose. The
following statement is required to comply with US and international regulations:
Caution: Use of controls, adjustments or performance of procedures other than those specified herein
may result in hazardous laser light exposure.
Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as
the sun, the user should avoid staring directly into the light beam. Momentary exposure to a Class 2
laser is not known to be harmful.
