LEDs / Ports
© 2006 SYMBOL TECHNOLOGIES, INC. All rights reserved.
Symbol reserves the right to make changes to any product to improve reliability, function, or design.
Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit,
or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any patent right or patent, covering or
relating to any combination, system, apparatus, machine, material, method, or process in which Symbol products might be used.
An implied license exists only for equipment, circuits, and subsystems contained in Symbol products.
Symbol and the Symbol logo are registered trademarks of Symbol Technologies, Inc. Other product names mentioned in this
manual may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, N.Y. 11742-1300
http://www.symbol.com
Reference Documents
Supporting documents, including the latest version of this guide are available for viewing/download from the Symbol
documentation web site: http://www.symbol.com/manuals
Software updates, SDKs, development support and related documents are available from the Symbol Devzone web site:
http://devzone.symbol.com
Patents
This product is covered by one or more of the patents listed on the web site: http://www.symbol.com/patents
Warranty
For the complete Symbol hardware product warranty statement, go to: http://www.symbol.com/warranty
Service Information
Contact information is provided on the Symbol contact web site: http://www.symbol.com/contactsupport
LED / Ports Description
Battery LED Green - Battery charge is good Flash Red - Battery needs charging.
Amber Flash - Battery is charging Solid Amber - Battery is fully charged
Error LED Flash Red - Error, replace unit.
External Antenna Port RF1000-FL - Supports up to one external antenna.
USB Client Port USB client connection.
External Power Port See Power Supply for the Symbol approved power supply information.
USB Client Port
External Power Port
External Antenna Port
Mounting Holes (4)
Battery Door
Power Button
Error LED
Physical Connections
Battery LED
72-XXXXX-01
Revision A — July 2006
RF1000-FL
Quick Reference Quide
Microsoft® CE .NET 5.0
Introduction
This Quick Reference Guide (QRG) provides the required information for all product models in the RF1XXX Series of RFID readers.
The user documents use the RF1000-FL model number to generically reference all of the RFID readers in the series.
The QRG includes LED definitions, port descriptions, and mounting information. For details, refer to the RF1000-FL Integrator
Guide P/N 72E-XXXXX-XX, available at: http://www.symbol.com/manuals
Product Description
The RF1000-FL is an intelligent, multi-protocol UHF RFID reader with RFID read performance that provides real-time, seamless
EPC-compliant tags processing.
Features:
• UHF Generation 2 support
• EPC Class 0 and Class 1
• Intel XScale® processor with Windows® CE
• Support for custom or third-party applications
• Feature set for event and tag management.
Firmware Updates
The RF1000-FL is shipped with the current firmware version. To install the latest upgrade refer to the RF1000-FL Integrator Guide
P/N 72E-XXXXX-XX, available from: http://www.symbol.com/manuals
Installation/Mounting
For details on the required procedures and detailed installation instructions refer to the RF1000-FL Integrator Guide P/N 72E-
XXXXX-XX, available from: http://www.symbol.com/manuals
Prior to installation/mounting the following procedures must be performed:
• The mounting brackets (or mounting platform) must be secured.
• The LAN administrator must configure the RF1000-FL to communicate with the local LAN network and must set
up the application interface software for the local LAN environment.
• The battery must be fully charged.
Mounting
1. Insert the rubber shock mounts into the mounting holes.
2. Position the RF1000-FL on the mounting brackets (or mounting platform). Ensure the clearance on all sides.
3. Insert the mounting bolts through the rubber shock mounts and through the bracket holes.
4. Attach the nuts onto the mounting bolts and tighten to 2.8 ft.-lbs to secure the RF1000-FL to the mounting brackets.
Operation
Press power button to toggle power on/off. The battery LED lights green to indicate the battery is good. If the Error LED flashes
red, remove the unit and return to the network administrator.
Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as
required.
If local language translations are available, they are provided at: http://www.symbol.com/services/manuals.
Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void
the user's authority to operate the equipment.
Antennas: Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments
could cause damage and may violate regulations
Caution: Only use Symbol approved and UL Listed accessories, battery packs and battery chargers.
Do NOT attempt to charge damp/wet units or batteries. All components must be dry before connecting to an external
power source.
Products Equipped with Bluetooth® Wireless Technology
This device can contain the following Bluetooth® qualified subsystems:
• BTID: B01825
• BTID: B02413.
Country Approvals
Regulatory markings are applied to the device signifying country approvals, see notes 1 and 2
Please refer to the Symbol Declaration of Conformity (DoC) for details. This is available at http://www2.symbol.com/doc/.
Note 1: The use of 5GHz RLAN's have varying restrictions of use; please refer to the Symbol Declaration of Conformity (DoC) for
details.
Note 2: The use of RFID Devices have varying restrictions of use; please refer to the Symbol Declaration of Conformity (DoC) for
details.
Operation of the device without regulatory approval is illegal.
Health and Safety Recommendations
Warning for Use of Wireless Devices
Please observe all warning notices with regard to the usage of wireless devices.
Potentially Hazardous Atmospheres
You are reminded of the need to observe restrictions on the use of radio devices in fuel depots, chemical plants etc. and areas
where the air contains chemicals or particles (such as grain, dust, or metal powders) and any other area where you would
normally be advised to turn off your vehicle engine.
Hearing Aids
The wireless device may interfere with some hearing aids. In the event of interference you may want to consult your hearing aid
supplier to discuss solutions.
Other Medical Devices
Please consult your physician or the manufacturer of the medical device, to determine if the operation of your wireless product
may interfere with the medical device.
FCC / EU RF Exposure Guidelines
Safety Information
Reducing RF Exposure - Use Properly
It is advisable to use the device only in the normal operating position.
The device complies with Internationally recognized standards covering Specific Absorption Rate (SAR) related to human
exposure to electromagnetic fields from radio devices.
Remote and Standalone Antenna Configurations.
To satisfy FCC RF exposure requirements, a mobile transmitting device must operate with a minimum separation distance of
25cm or more from a person's body.
Power Supply
Use only a Symbol approved power supply output rated 12 Vdc and minimum 3.33 A. The power supply is certified to
EN60950-1
with SELV outputs. Use of alternative power supply will invalidate any approval given to this device and may be dangerous.
Batteries
Please follow the local regulations when disposing of re-chargeable batteries.
![](/img.php?id=682073&img=bg2.png)
Taiwan - Recycling
EPA (Environmental Protection Administration) requires dry battery producing or importing firms in accordance with Article 15 of
the Waste Disposal Act are required to indicate the recycling marks on the batteries used in sales, giveaway or promotion.
Contact a qualified Taiwanese recycler for proper battery disposal.
Wireless Devices - Countries
Country Roaming
This device incorporates the International Roaming feature (IEEE802.11d) which will ensure the product operates on the correct
channels for the particular country of use.
Ad-Hoc Operation (802.11a Only)
Ad-Hoc operation is limited to Channels 36-48 (5150-5250 MHz). Use of this band is restricted to Indoor Use Only, any other use
will make the operation of this device illegal.
Frequency of Operation - FCC and IC (US/Canada versions)
The use in the UNII (Unlicensed National Information Infrastructure) band 1 5150-5250 MHz band is restricted to Indoor Use Only;
any other use will make the operation of this device illegal.
The available channels for 802.11 b/g operation in the US are Channels 1 to 11. The range of channels is limited by firmware.
Radio Frequency Interference Requirements - FCC
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Radio Frequency Interference Requirements - Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Label Marking: The Term “IC:” before the radio certification only signifies that Industry Canada technical specifications were met.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (EIRP) is not more than that permitted for successful communication.
This device has been designed to operate with the antennas listed below, and having a maximum gain of (x) dBi. Antennas not
included in this list or having a gain greater than (x) dBi are strictly prohibited for use with this device. The required antenna
impedance is (y) ohms.
Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN's, for use through the EEA, have the following restrictions:
• Maximum radiated transmit power of 100 mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 2.4 - 2.454 GHz.
• Italy requires a user license for outside usage.
The use of 5GHz RLAN's has varying restrictions for use within the EEA; please refer to the Symbol Declaration of Conformity
(DoC) for details at http://www2.symbol.com/doc/
Bluetooth® Wireless Technology for use through the EEA has the following restrictions:
• Maximum radiated transmit power of 100mW EIRP in the frequency range 2.400 -2.4835 GHz
• France, outside usage is restricted to 10mW EIRP
• Italy requires a user license for outside usage.
RFID devices for use through the EEA have the following restrictions:
• "Maximum radiated transmit power of 2W ERP in the frequency range 865.6-867.6MHz
The use of RFID Devices has varying restrictions for use within the EEA; please refer to the Symbol
Declaration of Conformity (DoC) for details at http://www2.symbol.com/doc/
Statement of Compliance
Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant
provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC. Declaration of Conformities may be obtained from http://
www2.symbol.com/doc/.
Other Countries
Mexico - Restrict Frequency Range to: 2.450 - 2.4835 GHz.
Sri Lanka- Restrict Frequency Range to: 2.400 - 2.430 GHz.
Battery Information
Symbol rechargeable battery packs are designed and constructed to the highest standards within the industry.
However, there are limitations to how long a battery can operate or be stored before needing replacement. Many factors affect
the actual life cycle of a battery pack, such as heat, cold, harsh environmental conditions and severe drops.
When batteries are stored over six (6) months, some irreversible deterioration in overall battery quality may occur. Store batteries
discharged in a dry, cool place, removed from the equipment to prevent loss of capacity, rusting of metallic parts and electrolyte
leakage. When storing batteries for one year or longer, they should be charged and discharged at least once a year. If an
electrolyte leakage is observed, avoid any contact with affected area and properly dispose of the battery. Batteries must be
charged within the 32° to 104° F (0° to +40° C) ambient temperature range.
Replace the battery when a significant loss of run time is detected.
Standard warranty period for all Symbol batteries is 30 days, regardless if the battery was purchased separately or included as
part of the mobile computer or bar code scanner. For more information on Symbol batteries, please visit: http:/
mysymbolcare.symbol.com/battery/batbasics1.html
Waste Electrical and Electronic Equipment (WEEE)
English: For EU Customers: All products at the end of their life must be returned to Symbol for recycling. For information on how
to return product, please go to:
http://www.symbol.com/environmental_compliance.
Dansk: Til kunder i EU: Alle produkter skal returneres til Symbol til recirkulering, når de er udtjent. Læs oplysningerne om
returnering af produkter på: http://www.symbol.com/environmental_compliance.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen am Ende ihrer Lebensdauer zum Recycling an Symbol
zurückgesandt werden. Informationen zur Rücksendung von Produkten finden Sie unter http://www.symbol.com/
environmental_compliance.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes tagastada taaskasutamise eesmärgil Symbol'ile. Lisainformatsiooni
saamiseks toote tagastamise kohta külastage palun aadressi: http://www.symbol.com/environmental_compliance.
Español: Para clientes en la Unión Europea: todos los productos deberán entregarse a Symbol al final de su ciclo de vida para
que sean reciclados. Si desea más información sobre cómo devolver un producto, visite: http://www.symbol.com/
environmental_compliance.
Français : Clients de l'Union Européenne : Tous les produits en fin de cycle de vie doivent être retournés à Symbol pour
recyclage. Pour de plus amples informations sur le retour de produits, consultez : http://www.symbol.com/
environmental_compliance.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al termine del rispettivo ciclo di vita devono essere restituiti a Symbol
al fine di consentirne il riciclaggio. Per informazioni sulle modalità di restituzione, visitare il seguente sito Web: http://
www.symbol.com/environmental_compliance.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Symbol vállalathoz kell eljuttatni újrahasznosítás céljából. A
termék visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a http://www.symbol.com/
environmental_compliance weboldalra.
Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar Symbol te worden
teruggezonden voor recycling. Raadpleeg http://www.symbol.com/environmental_compliance voor meer informatie over het
terugzenden van producten.
Português: Para clientes da UE: todos os produtos no fim de vida devem ser devolvidos à Symbol para reciclagem. Para obter
informações sobre como devolver o produto, visite: http://www.symbol.com/environmental_compliance.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku življenjske dobe vrniti podjetju Symbol za reciklažo. Za informacije o
vraèilu izdelka obišèite: http://www.symbol.com/environmental_compliance.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet on palautettava kierrätettäväksi Symbol-yhtiöön, kun tuotetta ei
enää käytetä. Lisätietoja tuotteen palauttamisesta on osoitteessa http://www.symbol.com/environmental_compliance.
Svenska: För kunder inom EU: Alla produkter som uppnått sin livslängd måste returneras till Symbol för återvinning. Information
om hur du returnerar produkten finns på http://www.symbol.com/environmental_compliance.
