P 300STD/FZY/PRO Scanner
Product Reference Guide
2
72-39417-03
Revision A — October 2000
Symbol Technologies, Inc. One Symbol Plaza, Holtsville N.Y. 11742
P 300STD/FZY/PRO Scanner Product Reference Guide
P 300STD/FZY/PRO Scanner
Product Reference Guide
72-39417-03
Revision A
October 2000
ii
2000 by Symbol Technologies, Inc. All rights reserved.
No part of this publication may be reproduced or used in any form, or by any electrical or
mechanical means, without permission in writing from Symbol. This includes electronic or
mechanical means, such as photocopying, recording, or information storage and retrieval
systems. The material in this manual is subject to change without notice.
The software is provided strictly on an “as is” basis. All software, including firmware,
furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and
non-exclusive license to use each software or firmware program delivered hereunder (licensed
program). Except as noted below, such license may not be assigned, sublicensed, or otherwise
transferred by the user without prior written consent of Symbol. No right to copy a licensed
program in whole or in part is granted, except as permitted under copyright law. The user
shall not modify, merge, or incorporate any form or portion of a licensed program with other
program material, create a derivative work from a licensed program, or use a licensed
program in a network without written permission from Symbol. The user agrees to maintain
Symbol’s copyright notice on the licensed programs delivered hereunder, and to include the
same on any authorized copies it makes, in whole or in part. The user agrees not to
decompile, disassemble, decode, or reverse engineer any licensed program delivered to the
user or any portion thereof.
Symbol reserves the right to make changes to any software or product to improve reliability,
function, or design.
Symbol does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any
Symbol Technologies, Inc., intellectual property rights. An implied license only exists for
equipment, circuits, and subsystems contained in Symbol products.
Symbol, Spectrum One, and Spectrum24 are registered trademarks of Symbol Technologies,
Inc. Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, New York 11742-1300
http://www.symbol.com
iii
Contents
About This Guide
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Chapter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Notational Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Symbol Support Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
Warranty Coverage and Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Chapter 1. Getting Started
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Setting Up the P 300 Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Installing the Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Switching Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Connecting Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Connecting to a Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Programming the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
P 300PRO Scanning Mode Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Smart Raster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Slab Only Raster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Always Raster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Programmable Raster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
iv
P 300STD/FZY/PRO Scanner Product Reference Guide
Aiming Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Aiming Dot Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-10
Slab Raster Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Scanning 1D Bar Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Scanning PDF417 (2D) Bar Codes (P300 PRO only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Test Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Scan Stand Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Beeper Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Macro PDF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Chapter 2. Programming the Scanner
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Set Default Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Host Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
RS-232C Host Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Host Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
RS-232C Host Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Host Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
RS-232C Host Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Beeper Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Beeper Tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Laser On Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Trigger Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Beep After Good Decode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Transmit “No Read” Message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
Decode Buffering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
LRC Checksum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Linear Code Type Security Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
(Does not apply to Code 128). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Linear Security Level 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Linear Security Level 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Linear Security Level 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Linear Security Level 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Bi-directional Redundancy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Autodiscriminate Response Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-24
Scan Stand Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Time Delay to Low Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Timeout Between Decodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Enable/Disable UPC-E/UPC-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Enable/Disable UPC-E1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
Enable/Disable EAN-8/EAN-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-30
v
Contents
UPC Coupon Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Enable/Disable Bookland EAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Decode UPC/EAN Supplementals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Decode UPC/EAN Supplemental Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Transmit UPC-A/UPC-E Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
UPC-A Preamble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
UPC-E Preamble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
UPC-E1 Preamble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-38
Convert UPC-E to UPC-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Convert UPC-E1 to UPC-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Transmit UPC-E1 Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-41
UPC/EAN Security Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
UPC/EAN Security Level 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
UPC/EAN Security Level 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
UPC/EAN Security Level 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
UPC/EAN Security Level 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
EAN-8 Zero Extend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-44
Convert EAN-8 to EAN-13 Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
Enable/Disable Code 128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
Enable/Disable UCC/EAN-128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
Enable/Disable ISBT 128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-48
Lengths for Code 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-49
Enable/Disable Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-50
Enable/Disable Trioptic Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-51
Set Lengths for Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-52
Code 39 Check Digit Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-54
Transmit Code 39 Check Digit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-55
Enable/Disable Code 39 Full ASCII . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-56
Code 39 Buffering (Scan & Store) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
Buffer Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-58
Clear Transmission Buffer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-58
Transmit Buffer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-58
Overfilling Transmission Buffer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Attempt to Transmit an Empty Buffer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Convert Code 39 to Code 32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-60
Enable/Disable Code 32 Prefix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-61
Enable/Disable Code 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-62
Set Lengths for Code 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-63
Enable/Disable Interleaved 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-65
Set Lengths for Interleaved 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-66
I 2 of 5 Check Digit Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-68
Transmit I 2 of 5 Check Digit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-69
Convert I 2 of 5 to EAN-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-70
Enable/Disable Discrete 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-71
vi
P 300STD/FZY/PRO Scanner Product Reference Guide
Set Lengths for Discrete 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-72
Enable/Disable Codabar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-74
Set Lengths for Codabar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-75
CLSI Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-77
NOTIS Editing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-78
Enable/Disable MSI Plessey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-79
Set Lengths for MSI Plessey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-80
MSI Plessey Check Digits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-82
Transmit MSI Plessey Check Digit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-83
MSI Plessey Check Digit Algorithm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-84
Enable/Disable PDF417 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-85
Enable/Disable MicroPDF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-86
Code 128 Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-87
UCC/EAN-128 Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-88
Scanning Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-89
Programmable Raster Height And Raster Expansion Speed . . . . . . . . . . . . . . . . . . . . . . . . . . 2-90
Aiming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-92
Transmit Code ID Character . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-93
Transmit Code ID Character . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-94
Pause Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-95
Prefix/Suffix Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-96
Scan Data Transmission Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-97
RS-232C Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-99
Baud Rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-99
Parity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-100
Check Parity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-101
Hardware Handshaking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-102
Software Handshaking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-104
Host Serial Response Time-out. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-106
RTS Line State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-106
Stop Bit Select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-107
ASCII Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-108
Beep on <BEL>. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-108
Intercharacter Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-109
Wand Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-110
Wand Host Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-110
Wand Emulator Bar Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-111
Variable Leading Margin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-112
Variable Leading Margin (cont’d). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-113
Convert All to Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-114
Keyboard Wedge Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-115
Host Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-115
National Keyboard Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-116
Fast Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-118
vii
Contents
Intercharacter Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-119
Convert Control Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-119
Numeric Bar Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-120
Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-122
Macro PDF Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-123
Macro PDF Transmit / Decode Mode Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-124
Transmit Symbols in Codeword Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-126
Escape Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-128
Delete Character Set ECIs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-129
ECI Decoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-130
Transmit Unknown Codewords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-131
Transmit Macro PDF User-Selected Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-132
Transmit Macro PDF User-Selected Fields (Continued). . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-133
Flush Macro Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-135
Abort Macro PDF Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-135
Chapter 3. Advanced Data Formatting (ADF)
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Rules: Criteria Linked to Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Using ADF Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
ADF Bar Code Menu Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Alternate Rule Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Rules Hierarchy (in Bar Codes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Default Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Beeper Definitions for ADF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
ADF Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Special Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Begin New Rule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Save Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Quit Entering Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Disable Rule Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Criteria. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Code Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Code Lengths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Message Containing A Specific Data String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Rule Belongs To Set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Send Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Send Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-29
Setup Field(s). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-29
Send Preset Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
viii
P 300STD/FZY/PRO Scanner Product Reference Guide
Modify Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Beeps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-48
Send Keystroke (Control Characters and Keyboard Characters). . . . . . . . . . . . . . . . . . . . . . . 3-49
Turn On/Off Rule Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-83
Alphanumeric Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-84
Chapter 4. Maintenance and Troubleshooting
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Appendix A. Programming Reference
UCC/EAN-128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
AIM Code Identifiers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
Prefix / Suffix Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-6
Appendix B. Keyboard Maps
Appendix C. ASCII Character Set
Appendix D. Technical Specifications
P 300STD Decode Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3
P 300FZY Decode Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-4
P 300PRO 1-D Decode Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-5
P 300PRO 2-D Decode Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-6
Pin-outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-7
Index
Feedback
ix
About This Guide
Introduction
The P 300STD/FZY/PRO Scanner Product Reference Guide provides instructions for setting
up, programming, using, maintaining and troubleshooting the P 300STD, P 300FZY and P
300PRO scanner.
Chapter Descriptions
Chapter 1, Getting Started, provides a product overview and instructions on setting up your
scanner. Also included are detailed instruction on scanning 1- and 2-dimensional bar codes,
as well as definitions for each of the beeper indications.
Chapter 2, Programming the Scanner, contains all the bar codes necessary to program your
P 300 scanner.
Chapter 3, Advanced Data Formatting (ADF), explains how to customize scanned data
before transmission to your host.
Chapter 4, Maintenance and Troubleshooting, describes cleaning your scanner, and provides
a list of possible problems you may encounter with your scanner, and solutions to these
problems.
Appendix A, Programming Reference, provides information on AIM identifiers and prefix/
suffix values.
Appendix B, Keyboard Maps, illustrates the keyboard maps for use with the keyboard wedge
interface.
Appendix C, ASCII Character Set, provides a table of ASCII character conversions.
x
P 300STD/FZY/PRO Scanner Product Reference Guide
Appendix D, Technical Specifications, lists the technical specifications for the scanner, and
provides illustrations of the decode zones.
Audience
The intended audience for this manual is personnel performing installation/setup,
programming and troubleshooting of P 300 Series scanners.
Notational Conventions
The following conventions are used in this document:
!Italics are used to highlight specific items in the general text, and to identify chapters
and sections in this and related documents.
!Bullets (!) indicate:
"action items
"lists of alternatives
"lists of required steps that are not necessarily sequential
!Sequential lists (e.g., those that describe step-by-step procedures) appear as
numbered lists.
Related Publications
!P 300 (STD/FZY/PRO) Series Quick Reference Guide, p/n 72-39416-xx, provides
instructions on setting up and using the scanner. Default programming parameters
are listed as well.
!P 300IMG Imager Quick Reference Guide, p/n 72-40804-xx, provides instructions
on setting up and using the imager version of this product.
!P 300IMG Imager Product Reference Guide, p/n 72-40805-xx, provides the setup,
maintenance, troubleshooting, programming and operating instructions for the
imager version of this product.
Service Information
If you have a problem with your equipment, contact the Symbol Support Center for your
region. See page xi for contact information. Before calling, have the model number, serial
number, and several of your bar code symbols at hand.
xi
About This Guide
Call the Support Center from a phone near the scanning equipment so that the service person
can try to talk you through your problem. If the equipment is found to be working properly
and the problem is symbol readability, the Support Center will request samples of your bar
codes for analysis at our plant.
If your problem cannot be solved over the phone, you may need to return your equipment for
servicing. If that is necessary, you will be given specific directions.
Note: Symbol Technologies is not responsible for any damages incurred
during shipment if the approved shipping container is not used.
Shipping the units improperly can possibly void the warranty. If the
original shipping container was not kept, contact Symbol to have
another sent to you.
Symbol Support Centers
For service information, warranty information or technical assistance contact or call the
Symbol Support Center in:
United States
Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, New York 11742-1300
1-800-653-5350
Canada
Symbol Technologies Canada, Inc.
2540 Matheson Boulevard East
Mississauga, Ontario, Canada L4W 4Z2
905-629-7226
United Kingdom
Symbol Technologies
Symbol Place
Winnersh Triangle, Berkshire RG41 5TP
United Kingdom
0800 328 2424 (Inside UK)
+44 208 945 7529 (Outside UK)
Asia/Pacific
Symbol Technologies Asia, Inc.
230 Victoria Street #04-05
Bugis Junction Office Tower
Singapore 188024
337-6588 (Inside Singapore)
+65-337-6588 (Outside Singapore)
xii
P 300STD/FZY/PRO Scanner Product Reference Guide
Australia
Symbol Technologies Pty. Ltd.
432 St. Kilda Road
Melbourne, Victoria 3004
1-800-672-906 (Inside Australia)
+61-3-9866-6044 (Outside Australia)
Austria
Symbol Technologies Austria GmbH
Prinz-Eugen Strasse 70
Suite 3
2.Haus, 5.Stock
1040 Vienna, Austria
1-505-5794 (Inside Austria)
+43-1-505-5794 (Outside Austria)
Denmark
Symbol Technologies AS
Gydevang 2,
DK-3450 Allerod, Denmark
7020-1718 (Inside Denmark)
+45-7020-1718 (Outside Denmark)
Europe/Mid-East Distributor Operations
Contact your local distributor or call
+44 118 945 7360
Finland
Oy Symbol Technologies
Kaupintie 8 A 6
FIN-00440 Helsinki, Finland
9 5407 580 (Inside Finland)
+358 9 5407 580 (Outside Finland)
France
Symbol Technologies France
Centre d'Affaire d'Antony
3 Rue de la Renaissance
92184 Antony Cedex, France
01-40-96-52-21 (Inside France)
+33-1-40-96-52-50 (Outside France)
xiii
About This Guide
Germany
Symbol Technologies GmbH
Waldstrasse 68
D-63128 Dietzenbach, Germany
6074-49020 (Inside Germany)
+49-6074-49020 (Outside Germany)
Italy
Symbol Technologies Italia S.R.L.
Via Cristoforo Columbo, 49
20090 Trezzano S/N Navigilo
Milano, Italy
2-484441 (Inside Italy)
+39-02-484441 (Outside Italy)
Latin America Sales Support
7900 Glades Road
Suite 340
Boca Raton, Florida 33434 USA
1-800-347-0178 (Inside United States)
+1-561-483-1275 (Outside United States)
Mexico
Symbol Technologies Mexico Ltd.
Torre Picasso
Boulevard Manuel Avila Camacho No 88
Lomas de Chapultepec CP 11000
Mexico City, DF, Mexico
5-520-1835 (Inside Mexico)
+52-5-520-1835 (Outside Mexico)
Netherlands
Symbol Technologies
Kerkplein 2, 7051 CX
Postbus 24 7050 AA
Varsseveld, Netherlands
315-271700 (Inside Netherlands)
+31-315-271700 (Outside Netherlands)
Norway
Symbol Technologies
Trollasveien 36
Postboks 72
1414 Trollasen, Norway
66810600 (Inside Norway)
+47-66810600 (Outside Norway)
South Africa
Symbol Technologies Africa Inc.
Block B2
Rutherford Estate
1 Scott Street
Waverly 2090 Johannesburg
Republic of South Africa
11-4405668 (Inside South Africa)
+27-11-4405668 (Outside South Africa)
Spain
Symbol Technologies S.A.
Edificioi la Piovera Azul
C. Peonias, No. 2 - Sexta Planta
28042 Madrid, Spain
9-1-320-39-09 (Inside Spain)
+34-9-1-320-39-09 (Outside Spain)
xiv
P 300STD/FZY/PRO Scanner Product Reference Guide
If you purchased your Symbol product from a Symbol Business Partner, contact that Business
Partner for service.
Warranty
Symbol Technologies, Inc (“Symbol”) manufactures its hardware products in accordance with industry-
standard practices. Symbol warrants that for a period of twelve (12) months from date of shipment,
products will be free from defects in materials and workmanship.
This warranty is provided to the original owner only and is not transferable to any third party. It shall
not apply to any product (i) which has been repaired or altered unless done or approved by Symbol, (ii)
which has not been maintained in accordance with any operating or handling instructions supplied by
Symbol, (iii) which has been subjected to unusual physical or electrical stress, misuse, abuse, power
shortage, negligence or accident or (iv) which has been used other than in accordance with the product
operating and handling instructions. Preventive maintenance is the responsibility of customer and is not
covered under this warranty.
Wear items and accessories having a Symbol serial number, will carry a 90-day limited warranty. Non-
serialized items will carry a 30-day limited warranty.
Warranty Coverage and Procedure
During the warranty period, Symbol will repair or replace defective products returned to Symbol’s
manufacturing plant in the US. For warranty service in North America, call the Symbol Support Center
at 1-800-653-5350. International customers should contact the local Symbol office or support center.
If warranty service is required, Symbol will issue a Return Material Authorization Number. Products
must be shipped in the original or comparable packaging, shipping and insurance charges prepaid.
Symbol will ship the repaired or replacement product freight and insurance prepaid in North America.
Shipments from the US or other locations will be made F.O.B. Symbol’s manufacturing plant.
Symbol will use new or refurbished parts at its discretion and will own all parts removed from repaired
products. Customer will pay for the replacement product in case it does not return the replaced product
to Symbol within 3 days of receipt of the replacement product. The process for return and customer’s
charges will be in accordance with Symbol’s Exchange Policy in effect at the time of the exchange.
Customer accepts full responsibility for its software and data including the appropriate backup thereof.
Repair or replacement of a product during warranty will not extend the original warranty term.
Sweden
Symbol Technologies AB
Albygatan 109D
Solna
Sweden
84452900 (Inside Sweden)
+46 84452900 (Outside Sweden)
xv
About This Guide
Symbol’s Customer Service organization offers an array of service plans, such as on-site, depot, or phone
support, that can be implemented to meet customer’s special operational requirements and are available
at a substantial discount during warranty period.
General
Except for the warranties stated above, Symbol disclaims all warranties, express or implied, on products
furnished hereunder, including without limitation implied warranties of merchantability and fitness for
a particular purpose. The stated express warranties are in lieu of all obligations or liabilities on part of
Symbol for damages, including without limitation, special, indirect, or consequential damages arising
out of or in connection with the use or performance of the product.
Seller’s liability for damages to buyer or others resulting from the use of any product, shall in no way
exceed the purchase price of said product, except in instances of injury to persons or property.
Some states (or jurisdictions) do not allow the exclusion or limitation of incidental or consequential
damages, so the proceeding exclusion or limitation may not apply to you.
xvi
P 300STD/FZY/PRO Scanner Product Reference Guide
1-1
Chapter 1
Getting Started
Introduction
A combination of superb performance and ease of use, the rugged, versatile P 300 series of
industrial hand-held scanners offers a wide choice of scanners to meet the demands of your
data management tasks in extreme environments.
Here’s what each member of the P 300 family offers you:
!P 300STD: undecoded version of the scanner.
!P 300FZY: decodes damaged or poorly printed bar codes; uses multi-interfaces of
RS-232, Wand Emulation, Keyboard Wedge, and Synapse.
!P 300PRO: performs one and two-dimensional bar code scanning; uses multi-
interfaces of RS-232 and Synapse.
!P 300IMG: performs point-and-shoot image capture, outputs to digital formats of
TIFF, JPEG, and BMP. This version is covered in the P 300IMG Quick Reference
Guide, p/n 72-40804-xx and the P 300IMG Imager Product Reference Guide, p/n
72-40805-xx.
Unpacking
Remove the P 300 Series scanner from its packing and inspect it for damage. If the scanner
was damaged in transit, call the Symbol Support Center at one of the telephone numbers
listed on page xi. KEEP THE PACKING. It is the approved shipping container and should be
used if you ever need to return your equipment for servicing.
1-2
P 300STD/FZY/PRO Scanner Product Reference Guide
Accessories
Depending on your host system’s configuration, the following items may be included with
your scanner. These items are also available through your local Symbol representative or
business partner.
Cables
!Power Supply: p/n 50-14001-001
!DC Power Adapter: p/n 50-16002-009
!AC Line Cord: (part number is country-specific)
!Undecoded Cable: p/n 25-38697-01
!RS-232 Cable: p/n 25-38698-01
!Keyboard Wedge Cable: 25-38699-01
!Wand Emulation Cable: 25-39803-01
!Synapse Cable: 25-38700-01
User Documentation
The following user documentation is provided with your scanner:
!P 300 Scanner Quick Reference Guide, p/n 72-39416-xx
!P 300 Scanner Series Product Reference Guide, p/n 72-39417-xx.
Optional Accessories
Optional accessories include various stands, including an Intellistand, and holders, which are
supplied at extra cost. Additional units of standard accessories may also be purchased at
extra cost.
Setting Up the P 300 Scanner
Installing the Cable
Insert the cable into the receptacle on the bottom of the scanner, and twist to the right as
shown:
Note: Do not pull the trigger while installing a cable on the scanner.
1-3
Getting Started
Figure 1-1. Installing the Cable
Switching Cables
Different cables are required for different hosts. To change the scanner cable:
1. Turn the cable counter-clockwise to unlock.
2. Pull the cable out of the receptacle on the bottom of the scanner.
3. Insert a new cable in the receptacle. Press the cable into the receptacle and twist to
the right.
Note: Do not pull the trigger while installing a cable on the scanner.
Connecting Power
If your host does not provide power to the scanner, you will need to connect external power
to the scanner.
1. Connect the interface cable to the bottom of the scanner, as described in Installing
the Cable.
2. Connect the DC cable right-angle connector into the power port on the interface
cable. Plug the other end of the DC cable into the power supply.
3. Connect the AC line cord into the power supply. Plug the other end into a wall outlet.
1-4
P 300STD/FZY/PRO Scanner Product Reference Guide
Connecting to a Host
The P 300 series scanners support a variety of host interfaces. The P 300FZY uses RS-232,
Synapse, Keyboard Wedge and Wand emulation to interface to a host system. The P 300PRO
uses RS-232 and Synapse to interface to a host system. This section describes how to make
each of these connections.
RS-232 Connection
Both the P 300FZY and P300PRO scanner use RS-232 to interface to a host system. This
connection can be made either directly from the scanner to the host, or indirectly through a
Synapse adapter cable to the host.
RS-232 Direct Connection
1. Connect the interface cable to the bottom of the scanner, as described in Installing
the Cable on page 1-2.
2. Connect the other end of the cable to the serial port on the host.
Figure 1-2. RS-232 Direct Connection
3. Plug one end of the power supply into the power receptacle on the RS-232 cable.
Plug the other end into a wall outlet.
Wand Emulation Connection
To perform Wand emulation, the scanner can be connected to a portable data terminal, or a
controller which collects the data as wand data, and interprets it for the host.
1-5
Getting Started
1. Connect the wand emulation interface cable (p/n 25-39803-01) to the bottom of the
scanner, as described in Installing the Cable on page 1-2.
2. Connect the other end of the interface cable into the COM port on the PDT or
Controller.
Figure 1-3. Wand Emulation Connection
3. Plug one end of the power cable into the power receptacle on the interface cable, and
plug the other end into a wall outlet.
Keyboard Wedge Connection
When configured for keyboard wedge input, the host accepts input from the scanner as
keystrokes. The P 300 can perform keyboard wedge input using a keyboard wedge cable, or
via the Synapse cable.
To connect the keyboard wedge cable:
1. Connect the keyboard wedge interface cable (p/n 25-38699-01) to the bottom of the
scanner, as described in Installing the Cable on page 1-2.
1-6
P 300STD/FZY/PRO Scanner Product Reference Guide
2. Connect the male end of the keyboard cable into the female end of the interface
cable. Connect the male end of the interface cable into the keyboard port on the host.
Figure 1-4. Keyboard Wedge Connection
3. Plug one end of the power cable into the power receptacle on the interface cable, and
plug the other end into a wall outlet.
Synapse Cable Connection
Symbol’s Synapse Smart Cables enable interfacing to a variety of hosts. The Synapse cable has
the built-in intelligence to detect the host to which it is connected.
1. Connect the Synapse adapter cable into the bottom of the scanner, as described in
Installing the Cable on page 1-2.
2. Plug the other end of the Synapse adapter cable into the Synapse Smart Cable.
Figure 1-5. Synapse Cable Connection
3. Connect the other end of the Synapse smart cable into the host.
1-7
Getting Started
RS-232 Connection using Synapse
1. Connect the interface cable to the bottom of the scanner, as described in Installing
the Cable on page 1-2.
2. Plug the other end of the interface cable into the Synapse Smart Cable.
3. Connect the other end of the Synapse Smart Cable to the host.
Figure 1-6. RS-232 Connection using Synapse
4. If needed, plug one end of the power supply into the power receptacle on the RS-232
cable. Plug the other end into a wall outlet.
5. If needed, plug one end of the power supply into the power receptacle on the RS-232
cable. Plug the other end into a wall outlet.
Keyboard Wedge Connection using Synapse
To connect the Synapse cable with Keyboard Wedge:
1. Connect the interface cable to the bottom of the scanner, as described in Installing
the Cable on page 1-2.
2. Connect the other end of the interface cable into the Synapse cable.
1-8
P 300STD/FZY/PRO Scanner Product Reference Guide
3. The other end of the Synapse cable has 2 “flying leads”. Connect the male end of the
lead into the female end of the keyboard cable. Connect the male end of the lead into
the keyboard port on the host.
Figure 1-7. Keyboard Wedge via Synapse Connection
Programming the Scanner
Once the connections are made to the host, the scanner must be programmed to work with
that host. Refer to Chapter 2, Programming the Scanner for the specific bar code
programming information.
P 300PRO Scanning Mode Options
The P 300PRO supports several scanning options:
Smart Raster
The P 300PRO programmable “Smart Raster” capability causes the scanner to emit a raster
pattern dynamically adjusted to the particular PDF417 bar code’s height. To increase
scanning efficiency and decrease decode time, the scanner determines the height of the bar
code, opening at a size optimal for decoding that bar code.
In normal “Smart Raster” operation, a trigger pull causes a slab raster pattern to appear. If
the target is a 1-D bar code, the scanner decodes the symbol. If the target bar code is PDF417,
1-9
Getting Started
the scanning patterns open up to a full, optimized raster pattern as soon as the scanner is
properly aligned over the bar code.
Figure 1-8. P 300PRO Aiming and Scanning Patterns
For best operation in Smart Raster mode, keep the scan pattern as parallel to the symbol’s
rows as possible, keep the scanner as still as possible, and hold the scanner at an angle which
does not give specular reflection. Likewise, the symbol should be in good condition.
Unless otherwise programmed, the P 300PRO operates with Smart Raster performance.
Slab Only Raster
Scanner activation creates a slab raster pattern which does not open vertically, regardless of
bar code type. This may provide optimal performance on small PDF417 and 1D bar codes.
Always Raster
When programmed to this option, the scanner directly opens the raster pattern to the
programmed height and at the programmed expansion speed when the trigger is pulled.
Programmable Raster
The user programs the height of the raster pattern and the rate at which it expands. Scanner
activation creates the slab raster pattern which only opens for PDF417 or MicroPDF417 bar
“Slab” Raster Pattern
Open Raster Pattern
Y- A x i s
Y- A x i s
Horizontal Displacement (X - Axis)
Aiming “Dot” Pattern
1-10
P 300STD/FZY/PRO Scanner Product Reference Guide
codes, useful when decoding low-profile 1D and 2D bar codes where over-scanning is not
desired. Note that the height and expansion rate are directly, but not linearly, proportional to
their respective parameter values.
Aiming Modes
There are two aiming modes: aiming with a dot pattern, or with a slab raster pattern. Note
that aiming modes do not work with the Always Raster scanning option.
Aiming Dot Option
A trigger pull creates the single dot aiming pattern, which lasts for a fixed interval. This dot
can easily be seen in outdoor or high ambient light environments. A slab raster pattern or an
open raster pattern appears next, depending on the programmed scanning option. There are
two programmable timeout periods for this option — normal and extended.
Slab Raster Option
A trigger pull creates the slab raster pattern. If the target is a 1-D bar code, the pattern never
gets beyond a slab raster. If the target bar code is PDF417, the pattern opens up to an
optimized raster pattern as soon as the scanner is properly aligned over the bar code.
Scanning 1D Bar Codes
To scan a 1D bar code:
1. Make sure all connections are secure, and the symbol you want to scan is within the
scanning range (refer to Appendix D, Technical Specifications).
2. Aim the scanner at the symbol and press the trigger. The scanning beam remains on
for approximately 3.0 seconds (default) or until a successful decode.
The scanner has read the symbol when:
!You hear a short, high tone beep (if the beeper is enabled).
!The green LED on the scanner lights.
The green LED stays lit for one second or until the next trigger pull.
1-11
Getting Started
Aiming
Scan the Entire Symbol
!Cross every bar and space of the symbol with the scan beam.
!Hold the scanner further away for larger bar codes.
!Hold the scanner closer for symbols with bars that are close together.
Right Wrong
Hold at an Angle
Do not hold the scanner directly over the bar code. Laser light reflecting directly back into
the scanner from the bar code is known as specular reflection. This strong light can
temporarily “blind” the scanner and make decoding difficult. The area where specular
reflection occurs is known as a “dead zone.”
You can tilt the scanner up to 65° forward or back and still achieve a successful decode Simple
practice quickly shows what tolerances to work within.
Scanning PDF417 (2D) Bar Codes (P300 PRO only)
PDF417 scanning is enabled by default in the P 300PRO scanner, and can be disabled or
enabled by scanning the corresponding parameter bar code in Enable/Disable PDF417 on
page 2-85.
To scan a PDF417 bar code:
1. Aim the scanner at the PDF bar code and press the trigger.
2. Hold the trigger down and keep the scan line parallel to the rows of the symbol
overlapping the outside edges of the bar code by about 1/2” on each side.
The beam expands vertically to completely cover the bar code.
!Check that PDF417 scanning is enabled.
!Make sure the scan line extends at least 1/2” past the left and right edges of the bar
code.
1-12
P 300STD/FZY/PRO Scanner Product Reference Guide
!Hold the scanner closer for denser symbols, farther away for larger symbols.
!Make sure you scan to the top and bottom rows of the symbol.
!Be patient - it may take a few passes to decode the symbol.
The bar code has been completely decoded when you hear a tone, followed by a short, high
tone beep. The greed LED on the scanner lights. The green LED stays lit for two seconds or
until the next trigger pull.
Test Symbols
To ensure your scanner is working properly, try scanning the following bar codes. If you have
trouble, refer to Troubleshooting on page 4-2.
CODE 128
UPC
1/2” 1/2”
1-13
Getting Started
PDF417
PDF417
Symbol Technologies, Inc.
“The Gettysburg Address”
1-14
P 300STD/FZY/PRO Scanner Product Reference Guide
Scan Stand Operation
Scan Stand operation allows hands-free scanning on the P 300FZY and P 300PRO. When the
scanner is placed in the stand, the scan pattern begins to blink on the surface below. The red
LED lights to indicate scanning activity.
To scan, present the symbol in the path of the scan pattern, but no more than 7” away. Make
sure the scan pattern extends at 3/4 inch beyond the symbol’s edges. When the symbol is
properly oriented, the scan pattern expands vertically to cover the symbol. The LED lights
green and a short, high-toned beep sounds to indicate successful decode.
After a successful decode, remove the symbol from the scan path. If the symbol does not
decode, or if the pattern does not expand, remove the symbol from the scan path and try
again. Make sure the bar code is on a clean, white, non-reflective surface.
1-15
Getting Started
Beeper Indications
Table 1-1. Beeper Indicatio ns
Beeper Sequence Indication
Standard Use
Short high tone A bar code symbol was decoded (if decode beeper is
enabled).
Low tone, followed by short high tone A PDF417 bar code symbol was decoded (if decode
beeper is enabled).
4 Beeps - long low tone A transmission error has been detected in a scanned
symbol. The data is ignored. This occurs if a unit is not
properly configured. Check option settings.
5 Beeps - low tone Convert or format error.
Low/high/low tone ADF transmit error.
High/high/high/low tone RS-232 receive error.
Parameter Menu Scanning
Short high tone Correct entry scanned or correct menu sequence
performed.
Low/high tone Input error, incorrect bar code or “Cancel” scanned,
wrong entry, incorrect bar code programming sequence;
remain in program mode.
High/low tone Keyboard parameter selected. Enter value using bar code
keypad.
High/low/high/low tone Successful program exit with change in the parameter
setting.
1-16
P 300STD/FZY/PRO Scanner Product Reference Guide
Macro PDF
Table 1-2 provides beeper definitions for Macro PDF mode.
Beeper Sequence Indication
Code 39 Buffering
High/low tone New Code 39 data was entered into the buffer.
3 Beeps - long high tone Code 39 buffer is full.
Low/high/low tone The buffer was erased, or there was an attempt to
transmit an empty buffer. When the Code 39 buffer was
empty, the scanner read a command to clear or to
transmit a Code 39 buffer.
4 Beeps - long low tone Error in data transmission.
Low/high tone A successful transmission of buffered data.
Table 1-2. Macro PDF Beeper Indications
Beeper Sequence Indication
Error
1 Low Long Hi-level decode error caused by incorrect
symbol.
2 Low Long File ID error. A bar code not in the current
MPDF sequence was scanned.
3 Low Long Out of memory. There is not enough buffer
space to store the current MPDF symbol.
4 Low Long Bad symbology. You scanned a 1-D or 2-D
bar code in an MPDF sequence, a duplicate
MPDF label, an incorrect sequence, or are
trying to transmit an empty or illegal
MPDF field.
5 Low Long Flushing buffer.
Fast Warble Successful parameter scanned.
Decode Beep Sequence
Table 1-1. Beeper Indications (Continued)
1-17
Getting Started
Single short Standard decode and transmit beep for all
symbols.
Double short MPDF symbol is buffered. A single beep
indicates transmission of the buffered data.
Table 1-2. Macro PDF Beeper Indications
Beeper Sequence Indication
1-18
P 300STD/FZY/PRO Scanner Product Reference Guide
2-1
Chapter 2
Programming the Scanner
Introduction
The P 300 Series scanner can be programmed to perform various functions, or activate
different features. This chapter describes each feature and provides the programming bar
codes necessary for selecting these features for your scanner. Before programming, follow the
setup instructions in Chapter 1, Getting Started.
The P 300 Series scanner is shipped with the default settings shown in Table 2-1. You can
change these default values by scanning the appropriate bar codes included in this chapter.
These new values replace the standard default values in memory and are preserved even when
the scanner is powered down. The default parameter values can be recalled by scanning the
Set All Defaults bar code on page 2-9.
Even if the default parameters suit your needs, you must still select a terminal type. The
scanner automatically identifies the host type on power-up. It makes this determination
provided the host is powered-up before the scanner is attached to it. You must then select the
appropriate terminal type for that host.
The following table lists the defaults for all parameters. If you wish to change any option,
scan the appropriate bar code(s). Several of the bar code parameters apply only to the
P300FZY, and others apply only to the P300PRO. This is noted in the parameter menus.
2-2
P 300STD/FZY/PRO Scanner Product Reference Guide
Table 2-1. Default Table
Parameter P300FZY Default P 300PRO Default Page #
Set Default Parameter All Defaults All Defaults 2-9
Host Type RS-232 RS-232 2-12
Beeper Volume High N/A 2-13
Beeper Tone Medium High 2-14
Laser On Time 3.0 seconds 5.0 seconds 2-15
Power Mode Continuous Continuous 2-16
Trigger Mode N/A Level 2-17
Beep After Good Decode Enable Enable 2-18
Transmit “No Read” Message Disable Disable 2-19
Decode Buffering N/A Enable 2-19
LRC Checksum Disable Disable 2-20
Linear Code Type Security Levels 1 2 2-21
Bi-directional Redundancy Disable Disable 2-23
Autodiscriminate Response Time 1.0 second N/A 2-24
SCAN STAND OPTIONS
Time Delay to Low Power Mode N/A 30 seconds 2-25
Time Out Between Same Symbols N/A 0.6 seconds 2-26
Time Out Between Different Symbols N/A 0.0 seconds 2-26
UPC/EAN
UPC-A Enable Enable 2-28
2-3
Programming the Scanner
UPC-E Enable Enable 2-28
UPC-E1 Disable Disable 2-29
EAN-8 Enable Enable 2-30
EAN-13 Enable Enable 2-30
UPC Coupon Code Disable N/A 2-31
Bookland EAN Disable Disable 2-32
Decode UPC/EAN Supplementals Ignore Ignore 2-33
Decode UPC/EAN Supplemental
Redundancy
77
2-34
Transmit UPC-A Check Digit Enable Enable 2-35
Transmit UPC-E Check Digit Enable Enable 2-35
UPC-A Preamble System Character System Character 2-36
UPC-E Preamble System Character System Character 2-37
UPC-E1 Preamble System Character System Character 2-38
Convert UPC-E to A Disable Disable 2-39
Convert UPC-E1 to UPC-A Disable Disable 2-40
Transmit UPC-E1 Check Digit Enabled Enable 2-41
UPC/EAN Security Levels 0 0 2-42
EAN-8 Zero Extend Disable Disable 2-44
Convert EAN-8 to EAN-13 Type Disable Disable 2-45
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-4
P 300STD/FZY/PRO Scanner Product Reference Guide
Code 128
Code 128 Enable Enable 2-46
UCC/EAN-128 Enable Enable 2-47
ISBT-128 Enable Enable 2-48
Code 39
Code 39 Enable Enable 2-50
Trioptic Code 39 Disable Disable 2-51
Set Length(s) for Code 39 2 to 55 1-55 2-53
Code 39 Check Digit Verification Disable Disable 2-54
Transmit Code 39 Check Digit Disable Disable 2-55
Code 39 Full ASCII Conversion Disable Disable 2-56
Buffer Code 39 Disable N/A 2-57
Convert Code 39 to Code 32 Disable Disable 2-60
Code 32 Prefix Disable Enabled 2-61
Code 93
Code 93 Disable Disable 2-62
Set Length(s) for Code 93 4-55 4-55 2-63
Interleaved 2 of 5
Interleaved 2 of 5 Enable Disable 2-65
Set Length(s) for I 2 of 5 14 14 2-66
I 2 of 5 Check Digit Verification Disable Disable 2-68
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-5
Programming the Scanner
Transmit I 2 of 5 Check Digit Disable Disable 2-69
Convert I 2 of 5 to EAN 13 Disable Disable 2-70
Discrete 2 of 5
Discrete 2 of 5 Disable Disable 2-71
Set Length(s) for D 2 of 5 12 12 2-72
Codabar
Codabar Disable Disable 2-74
Set Lengths for Codabar 5-55 5-55 2-75
CLSI Editing Disable Disable 2-77
NOTIS Editing Disable Disable 2-78
MSI Plessey
MSI Plessey Disable Disable 2-79
Set Length(s) for MSI Plessey Any Length Any Length 2-81
MSI Plessey Check Digits One One 2-82
Transmit MSI Plessey Check Digit Disable Disable 2-83
MSI Plessey Check Digit Algorithm Mod 10/Mod 10 Mod10/Mod10 2-84
PDF
Enable/Disable PDF417 N/A Enable 2-85
Scanning Mode N/A Smart Raster 2-89
Raster Height N/A 15 2-90
Raster Expansion N/A 11 2-90
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-6
P 300STD/FZY/PRO Scanner Product Reference Guide
Aiming Mode N/A Slab Raster 2-92
Micro PDF
Enable/Disable Micro PDF N/A Disable 2-86
Code 128 Emulation N/A Enable 2-87
UCC/EAN-128 Emulation N/A Ignore 2-88
Data Options
Transmit Code ID Character None None 2-94
Pause Duration 0 0 2-95
Prefix/Suffix Values 7013
(<CR/LF> for
serial)
Enter 2-96
Scan Data Transmission Format Data as is Data As Is 2-97
RS-232C
RS-232 Host Type Standard Standard 2-12
Baud Rate 9600 9600 2-100
Parity None None 2-101
Check Parity Do Not Check Check 2-102
Hardware Handshaking None None 2-103
Software Handshaking None None 2-104
Host Serial Response Time-out 2.0 Sec. 2.0 Sec. 2-106
RTS Line State Low Low 2-107
Stop Bit Select 1 1 2-107
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-7
Programming the Scanner
ASCII Format 8-Bit 8-Bit 2-108
Beep on <BEL> Disable Disable 2-108
Intercharacter Delay 0 0 2-109
Wand Parameters
Wand Host Interface Symbollink N/A 2-110
Wand Emulator Bar Output Bar High N/A 2-111
Variable Leading Margin 80 ms. N/A 2-112
Convert All to Code 39 Disable N/A 2-114
Keyboard Wedge Parameters
Host Type IBM PC/AT N/A 2-115
National Keyboard Type North American N/A 2-116
Fast Transmit Enabled N/A 2-118
Intercharacter Delay 0 N/A 2-119
Convert Control Characters Disable N/A 2-119
MacroPDF Parameters
MacroPDF Transmit/Decode Mode
Symbols
N/A Buffer all Symbols;
Transmit Macro PDF
when complete
2-124
Transmit Symbols in Codeword
Format
N/A Disable 2-126
Escape Characters N/A None 2-128
Delete Character Set ECIs N/A Enable 2-129
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-8
P 300STD/FZY/PRO Scanner Product Reference Guide
ECI Decoder N/A Enable 2-130
Transmit Unknown Codewords N/A Disable 2-131
Transmit MacroPDF User-Selectable
Fields
N/A Disable 2-132
Flush Macro Buffer N/A Disable 2-135
Abort MacroPDF Entry N/A Disable 2-135
Transmit Macro PDF User-Selected Field:
Transmit File Name N/A Disable 2-133
Transmit Block Count N/A Disable 2-133
Transmit Time Stamp N/A Disable 2-133
Transmit Sender N/A Disable 2-133
Transmit Addresses N/A Disable 2-134
Transmit File Size N/A Disable 2-134
Transmit Checksum N/A Disable 2-134
Transmit Macro PDF Control Header N/A Disable 2-134
Last Block Marker N/A Disable 2-134
Table 2-1. Default Table (continued)
Parameter P300FZY Default P 300PRO Default Page #
2-9
Programming the Scanner
Set Default Parameter
Scanning this bar code returns all parameters to the default values listed in Table 2-1 on page
2-2.
Set All Defaults
2-10
P 300STD/FZY/PRO Scanner Product Reference Guide
Host Type
RS-232C Host Types
Three RS-232C hosts are set up with their own parameter default settings (Table 2-2.)
Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal sets the defaults listed below. These
defaults take precedence over standard defaults. So if you select Fujitsu RS-232C, then select
the standard defaults, the Fujitsu defaults still take precedence.
Table 2-2. Terminal-Specific RS-232C
Parameter Standard ICL FUJITSU NIXDORF
Mode A/
Mode B
Transmit Code ID No Yes Yes Yes
Data Transmission Format Data as is Data/Suffix Data/Suffix Data/Suffix
Suffix CR/LF (7013) CR (1013) CR (1013) CR (1013)
Baud Rate 9600 9600 9600 9600
Parity None Even None Odd
Hardware Handshaking None RTS/CTS
Option 3
None RTS/CTS
Option 3
Software Handshaking None None None None
Serial Response Time-out 2 Sec. 9.9 Sec. 2 Sec. indefinite
Stop Bit Select One One One One
ASCII Format 8-Bit 8-Bit 8-Bit 8-Bit
Beep On <BEL> Disabled Disabled Disabled Disabled
RTS Line State Low High Low *Low = No
data to send
*In the Nixdorf Mode B, if CTS is Low, scanning is disabled. When CTS is High, the user can scan
bar codes.
2-11
Programming the Scanner
Host Type
RS-232C Host Types
Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal enables the transmission of the code
ID characters listed in Table 2-3. These code ID characters are not programmable; do not
enable the Transmit Code ID feature.
Table 2-3. Terminal Specific Code ID Characters
ICL FUJITSU NIXDORF
UPC-A A A A
UPC-E E E C0
EAN-8 FF FF B
EAN-13 F F A
Code 39 C <len> None M
Codabar N <len> None N
Code 128 L <len> None K
I 2 of 5 I <len> None I
Code 93 None None L
D 2 of 5 H <len> None H
UCC/EAN 128 L <len> None P
MSI/Plessey None None O
Bookland EAN F F A
Trioptic None None None
2-12
P 300STD/FZY/PRO Scanner Product Reference Guide
Host Type
RS-232C Host Types
To select an RS-232C host interface, scan one of the following bar codes.
Standard RS-232C
ICL RS-232C
Nixdorf RS-232C Mode A
Nixdorf RS-232C Mode B
Fujitsu RS-232C
2-13
Programming the Scanner
Beeper Volume
To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume bar code.
Low Volume
Medium Volume
High Volume
2-14
P 300STD/FZY/PRO Scanner Product Reference Guide
Beeper Tone
This parameter sets the decode beep frequency or tone — low, medium, or high.
Note: This parameter is used by the P300 FZY and PRO only
Low Frequency
Medium Frequency
High Frequency
2-15
Programming the Scanner
Laser On Time
This parameter sets the maximum time decode processing continues during a scan attempt.
It is programmable in 0.1 second increments from 0.5 to 9.9 seconds.
To set a Laser On Time, scan the bar code below. Next scan two numeric bar codes beginning
on page 2-120 that correspond to the desired time on. Single digit numbers must have a
leading zero. For example, to set a Time On of .5 seconds, scan the bar code below, then scan
the “0” and “5” bar codes. If you make an error, or wish to change your selection, scan
CANCEL on page 2-122.
Laser On Time
2-16
P 300STD/FZY/PRO Scanner Product Reference Guide
Power Mode
This parameter determines whether or not power remains on after a decode attempt. When
in low power mode, the scanner enters low power consumption mode to preserve battery
life after each decode attempt. When in continuous power mode, power remains on after
each decode attempt.
Continuous On
Low Power
2-17
Programming the Scanner
Trigger Mode
This parameter controls scanner triggering. “Trigger” refers to an external hardware trigger
or a scanner trigger.
Note: This parameter is available on the P 300PRO only.
!If Level is selected, a trigger pull activates the laser and decode processing. The laser
remains on and decode processing continues until a successful decode, the trigger is
released, or the Decode Attempt Duration is reached.
!If Pulse is selected, a trigger pull activates the laser and decode processing. The laser
remains on and decode processing continues until a successful decode or the Decode
Attempt Duration is reached.
Select either Level or Pulse trigger mode.
Level
Pulse
2-18
P 300STD/FZY/PRO Scanner Product Reference Guide
Beep After Good Decode
Scan this symbol if you want the scanner to beep after a good decode.
Beep After Good Decode
Scan this symbol if you do not want the scanner to beep after a good decode. The beeper still
operates during parameter menu scanning and indicates error conditions.
Do Not Beep After Good Decode
2-19
Programming the Scanner
Transmit “No Read” Message
When enabled, the scanner transmits “NR” if it does not decode a symbol. Any enabled
prefixes or suffixes are appended around this message. When disabled, if a symbol does not
read, nothing is sent to the host.
Enable No Read
Disable No Read
Decode Buffering
This option permits the scanner to store decode data until the host device is ready to receive
them. If the scanner reaches its capacity to store decoded symbols before the host is ready,
subsequent trigger pulls have no effect until a buffer is available.
Enable Decode Buffering Disable Decode Buffering
2-20
P 300STD/FZY/PRO Scanner Product Reference Guide
LRC Checksum
Enabling this option allows for appending an LRC checksum character at the end of a decode
transmission.
When an LRC checksum is enabled, the format of output data is as follows: <STX>
<DATA...> <ETX> <LRC>. If <DATA...> contains the special characters STX, ETX, and
DLE, a DLE character is used as an escape character and is added before each of those
characters so that the receiving side knows not to interpret the special characters in the data
as control characters. The LRC character is the exclusive OR of all characters except for the
LRC character itself.
Enable LRC Checksum
Disable LRC Checksum
2-21
Programming the Scanner
Linear Code Type Security Level
(Does not apply to Code 128)
The P 300 Series scanner offers four levels of decode security for linear code types (e.g. Code
39, Interleaved 2 of 5). Select a higher security level for low quality bar codes. As security
levels increase, the scanner’s aggressiveness decreases.
Select the security level appropriate for your bar code quality.
Linear Security Level 1
The following code types must be successfully read twice before being transmitted.
Linear Security Level 1
Linear Security Level 2
All code types must be successfully read twice before being transmitted.
Linear Security Level 2
Code Type Length
Codabar All
MSI Plessey 4 or less
D 2 of 5 8 or less
I 2 of 5 8 or less
2-22
P 300STD/FZY/PRO Scanner Product Reference Guide
Linear Security Level 3
Code types other than the following must be successfully read twice before being transmitted.
The following codes must be read three times:
Linear Security Level 3
Linear Security Level 4
All code types must be successfully read three times before being transmitted
Linear Security Level 4
Code Type Length
MSI Plessey 4 or less
D 2 of 5 8 or less
I 2 of 5 8 or less
Codabar 8 or less
2-23
Programming the Scanner
Bi-directional Redundancy
This parameter is only valid when a Linear Code Type Security Level (see page 2-21) is
enabled. When this parameter is enabled, a bar code must be successfully scanned in both
directions (forward and reverse) before being decoded.
Enable Bi-directional Redundancy
Disable Bi-directional Redundancy
2-24
P 300STD/FZY/PRO Scanner Product Reference Guide
Autodiscriminate Response Time
This parameter extends the length of time during which the scanner tries to detect which host
it is connected to on power up.
Note: When connected to an LS 5700/5800 scanner, the 5 second option
must be used.
1 second
5 seconds
2-25
Programming the Scanner
Scan Stand Options
Time Delay to Low Power Mode
Note: This parameter is available on the P 300PRO only.
For extending laser life in scan stand mode, select the time the scanner remains active
following a successful decode. Selectable options include 30 seconds, 1 minute, 2 minutes, 3
minutes. To awaken the scanner in low power mode, present a symbol to the scan path. A
successful decode restores it to normal blinking.
30 Second Delay 1 Minute Delay
2 Minute Delay 3 Minute Delay
2-26
P 300STD/FZY/PRO Scanner Product Reference Guide
Timeout Between Decodes
Note: This parameter is available on the P 300PRO only.
Timeout Between Decodes, Same Symbol is used in scan stand mode to prevent the beeper
from continuously beeping when a symbol is left in the scanner’s field of view. It is
programmable in 0.1 second increments from 0.0 to 9.9 seconds. The recommended interval
is 0.6 seconds.
Timeout Between Decodes, Different Symbols is used in scan stand mode to prevent the
beeper from beeping when a different symbol appears in the scanner’s field of view before the
timeout period between decodes has expired. This is programmable in 0.1 second increments
from 0.0 to 9.9 seconds. The recommended value is 0.0 seconds.
Select the timeouts between decodes for the same or different symbols.
1. Scan the option bar code you wish to set.
2. Scan two bar codes on the next page which correspond to the desired interval, in 0.1
second increments.
3. If you make an error, or wish to change your selection, scan CANCEL.
Timeout Between Decodes -
The Same Symbol
Timeout Between Decodes -
Different Symbols
2-27
Programming the Scanner
Timeout Between Decodes (Continued)
1
23
45
67
89
0
Cancel
2-28
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable UPC-E/UPC-A
To enable or disable UPC-E or UPC-A, scan the appropriate bar code below.
Enable UPC-E
Disable UPC-E
Enable UPC-A
Disable UPC-A
2-29
Programming the Scanner
Enable/Disable UPC-E1
To enable or disable UPC-E1, scan the appropriate bar code below.
Enable UPC-E1
Disable UPC-E1
2-30
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable EAN-8/EAN-13
To enable or disable EAN-8 or EAN-13, scan the appropriate bar code below.
Enable EAN-8
Disable EAN-8
Enable EAN-13
Disable EAN-13
2-31
Programming the Scanner
UPC Coupon Code
To enable or disable UPC Coupon Code, scan one of the following bar codes:
Enable UPC/EAN Coupon Code Disable UPC/EAN Coupon Code
2-32
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Bookland EAN
To enable or disable EAN Bookland, scan the appropriate bar code below.
Enable Bookland EAN
Disable Bookland EAN
2-33
Programming the Scanner
Decode UPC/EAN Supplementals
Supplementals are additionally appended characters (2 or 5) according to specific code
format conventions (e.g., UPC A+2, UPC E+2, EAN 8+2). Three options are available.
!If UPC/EAN with supplemental characters is selected, UPC/EAN symbols without
supplemental characters are not decoded.
!If UPC/EAN without supplemental characters is selected, and the P 300 Series
scanner is presented with a UPC/EAN plus supplemental symbol, the UPC/EAN
is decoded and the supplemental characters ignored.
!An autodiscriminate option is also available. If this option is selected, choose an
appropriate Decode UPC/EAN Supplemental Redundancy value from the next page.
A value of 5 or more is recommended.
Note: To minimize the risk of invalid data transmission, select whether to
read or ignore supplemental characters.
Decode UPC/EAN with Supplementals
Ignore UPC/EAN with Supplementals
Autodiscriminate UPC/EAN Supplemental
2-34
P 300STD/FZY/PRO Scanner Product Reference Guide
Decode UPC/EAN Supplemental Redundancy
With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of
times a symbol without supplementals is decoded before transmission. The range is from two
to twenty times. Five or above is recommended when decoding a mix of UPC/EAN symbols
with and without supplementals, and the autodiscriminate option is selected.
Scan the bar code below to select a decode redundancy value. Next scan two numeric bar
codes beginning on page 2-120. Single digit numbers must have a leading zero. If you make
an error, or wish to change your selection, scan CANCEL on page 2-122.
Decode UPC/EAN
Supplemental Redundancy
2-35
Programming the Scanner
Transmit UPC-A/UPC-E Check Digit
Scan the appropriate bar code below to transmit the symbol with or without the UPC-A or
UPC-E check digit.
Transmit UPC-A Check Digit
Do Not Transmit UPC-A Check Digit
Transmit UPC-E Check Digit
Do Not Transmit UPC-E Check Digit
2-36
P 300STD/FZY/PRO Scanner Product Reference Guide
UPC-A Preamble
Three options are given for lead-in characters for UPC-A symbols transmitted to the host
device: transmit system character only, transmit system character and country code (“0” for
USA), and no preamble transmitted. The lead-in characters are considered part of the symbol.
No Preamble
(<DATA>)
System Character
(<SYSTEM CHARACTER> <DATA>)
System Character & Country Code
(< COUNTRY CODE> <SYSTEM CHARACTER> <DATA>)
2-37
Programming the Scanner
UPC-E Preamble
Three options are given for lead-in characters for UPC-E symbols transmitted to the host
device: transmit system character only, transmit system character and country code (“0” for
USA), and no preamble transmitted. The lead-in characters are considered part of the symbol.
No Preamble
(<DATA>)
System Character
(<SYSTEM CHARACTER> <DATA>)
System Character & Country Code
(< COUNTRY CODE> <SYSTEM CHARACTER> <DATA>)
2-38
P 300STD/FZY/PRO Scanner Product Reference Guide
UPC-E1 Preamble
Three options are given for lead-in characters for UPC-E1 symbols transmitted to the host
device: transmit system character only, transmit system character and country code (“0” for
USA), and no preamble transmitted. The lead-in characters are considered part of the symbol.
No Preamble
System Character
System Character and Country Code
2-39
Programming the Scanner
Convert UPC-E to UPC-A
This parameter converts UPC-E (zero suppressed) decoded data to UPC-A format before
transmission. After conversion, data follows UPC-A format and is affected by UPC-A
programming selections (e.g., Preamble, Check Digit).
Scanning DO NOT CONVERT UPC-E TO UPC-A allows you to transmit
UPC-E (zero suppressed) decoded data.
Convert UPC-E to UPC-A
(Enable)
Do Not Convert UPC-E to UPC-A
(Disable)
2-40
P 300STD/FZY/PRO Scanner Product Reference Guide
Convert UPC-E1 to UPC-A
This parameter converts UPC-E1 decoded data to UPC-A format before transmission. After
conversion, data follows UPC-A format and is affected by UPC-A programming selections
(e.g., Preamble, Check Digit).
Scanning DO NOT CONVERT UPC-E1 TO UPC-A allows you to transmit UPC-E1
decoded data.
Convert UPC-E1 to UPC-A
Do Not Convert UPC-E1 to UPC-A
2-41
Programming the Scanner
Transmit UPC-E1 Check Digit
Scan the appropriate bar code below to transmit the symbol with or without the UPC-E1
check digit
Transmit UPC-E1 Check Digit
Do Not Transmit UPC-E1 Check Digit
2-42
P 300STD/FZY/PRO Scanner Product Reference Guide
UPC/EAN Security Level
The P 300 Series scanner offers four levels of decode security for UPC/EAN bar codes. Select
a higher level of security for poor quality bar codes. There is an inverse relationship between
security and scanner aggressiveness, so be sure to choose only that level of security necessary
for your application.
UPC/EAN Security Level 0
This default setting allows the scanner to operate in its most aggressive state, while providing
sufficient security in decoding “in-spec” UPC/EAN bar codes.
UPC/EAN Security Level 0
UPC/EAN Security Level 1
As bar code quality levels diminish, certain characters become prone to misdecodes before
others (i.e., 1, 2, 7, 8). If you are experiencing misdecodes of poorly printed bar codes, and
the mis-decodes are limited to these characters, select this security level.
UPC/EAN Security Level 1
2-43
Programming the Scanner
UPC/EAN Security Level 2
If you are experiencing misdecodes of poorly printed bar codes, and the misdecodes are not
limited to characters 1, 2, 7, and 8, select this security level.
UPC/EAN Security Level 2
UPC/EAN Security Level 3
If you have tried Security Level 2, and are still experiencing misdecodes, select this security
level. Be advised, selecting this option is an extreme measure against misdecoding severely out
of spec bar codes, and security significantly impairs the decoding ability of the scanner. If this
level of security is necessary, try to improve the quality of your bar codes.
UPC/EAN Security Level 3
2-44
P 300STD/FZY/PRO Scanner Product Reference Guide
EAN-8 Zero Extend
This parameter adds five leading zeros to decoded EAN-8 symbols to make them compatible
in format to EAN-13 symbols.
Enable EAN-8 Zero
Extend
Disable EAN-8 Zero
Extend
2-45
Programming the Scanner
Convert EAN-8 to EAN-13 Type
When EAN Zero Extend is enabled, this parameter gives you the option of labeling the
extended symbol as either an EAN-13 bar code, or an EAN-8 bar code. This affects Transmit
Code ID Character and DECODE_DATA message.
When EAN Zero Extend is disabled, this parameter has no effect on bar code data.
Ty pe Is EA N - 8
Typ e I s EA N -1 3
2-46
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Code 128
To enable or disable Code 128, scan the appropriate bar code below.
Enable Code 128
Disable Code 128
2-47
Programming the Scanner
Enable/Disable UCC/EAN-128
To enable or disable UCC/EAN-128, scan the appropriate bar code below. (See Appendix A,
Programming Reference for details on UCC/EAN128.)
Enable UCC/EAN-128
Disable UCC/EAN-128
2-48
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable ISBT 128
To enable or disable ISBT 128, scan the appropriate bar code below.
Enable ISBT 128
Disable ISBT 128
2-49
Programming the Scanner
Lengths for Code 128
No length setting is required for Code 128. The default setting is Any Length.
2-50
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Code 39
To enable or disable Code 39, scan the appropriate bar code below.
Enable Code 39
Disable Code 39
2-51
Programming the Scanner
Enable/Disable Trioptic Code 39
Trioptic Code 39 symbols always contain six characters. To enable or disable Trioptic Code
39, scan the appropriate bar code below.
Enable Trioptic Code 39
Disable Trioptic Code 39
Note: Trioptic Code 39 and Code 39 Full ASCII cannot be enabled
simultaneously. If you get an error beep when enabling Trioptic Code
39, disable Code 39 Full ASCII and try again.
2-52
P 300STD/FZY/PRO Scanner Product Reference Guide
Set Lengths for Code 39
Lengths for Code 39 may be set for any length, one or two discrete lengths, or lengths within
a specific range. The length of a code refers to the number of characters (i.e., human readable
characters), the code contains, including check digit(s) . If Code 39 Full ASCII is enabled,
Length Within a Range or Any Length are the preferred options.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select Code 39 One Discrete Length, then scan 1, 4, only
Code 39 symbols containing 14 characters are decoded. Numeric bar codes begin on page
2-120. If you make an error or wish to change your selection, scan CANCEL on page 2-
122.
Code 39 - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing two
selected lengths. For example, if you select Code 39 Two Discrete Lengths, then scan 0,
2, 1, 4, only Code 39 symbols containing 2 or 14 characters are decoded. Numeric bar
codes begin on page 2-120. If you make an error or wish to change your selection, scan
CANCEL on page 2-122.
Code 39 - Two Discrete Lengths
2-53
Programming the Scanner
Length Within Range - This option allows you to decode a code type within a specified
range. For example, to decode Code 39 symbols containing between 4 and 12 characters,
first scan Code 39 Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must
always be preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make
an error or wish to change your selection, scan CANCEL on page 2-122.
Code 39 - Length within Range
Any Length - Scanning this option allows you to decode Code 39 symbols containing any
number of characters.
Code 39 - Any Length
2-54
P 300STD/FZY/PRO Scanner Product Reference Guide
Code 39 Check Digit Verification
When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies
with specified algorithms.
Only those Code 39 symbols which include a modulo 43 check digit are decoded when this
parameter is enabled.
Enable Code 39 Check Digit
Disable Code 39 Check Digit
2-55
Programming the Scanner
Transmit Code 39 Check Digit
Scan this symbol if you want to transmit the check digit with the data.
Transmit Code 39 Check Digit
(Enable)
Do Not Transmit Code 39 Check Digit
(Disable)
2-56
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Code 39 Full ASCII
To enable or disable Code 39 Full ASCII, scan the appropriate bar code below.
When enabled, the ASCII character set assigns a code to letters, punctuation marks,
numerals, and most control keystrokes on the keyboard.
The first 32 codes are non-printable and are assigned to keyboard control characters such as
BACKSPACE and RETURN. The other 96 are called printable codes because all but SPACE
and DELETE produce visible characters.
Code 39 Full ASCII interprets the bar code special character ($ + % /) preceding a Code 39
character and assigns an ASCII character value to the pair. For example, when Code 39 Full
ASCII is enabled and a +B is scanned, it is interpreted as b, %J as ?, and $H emulates the
keystroke BACKSPACE. Scanning ABC$M outputs the keystroke equivalent of ABC
ENTER. Refer to Table C-1 on page C-1.
The scanner does not autodiscriminate between Code 39 and Code 39 Full ASCII.
Enable Code 39 Full ASCII
Disable Code 39 Full ASCII
Note: Trioptic Code 39 and Code 39 Full ASCII cannot be enabled
simultaneously. If you get an error beep when enabling Trioptic Code
39, disable Code 39 Full ASCII and try again.
2-57
Programming the Scanner
Code 39 Buffering (Scan & Store)
When you select the Buffer Code 39 option, all Code 39 symbols having a leading space as a
first character are temporarily buffered in the unit to be transmitted later. The leading space
is not buffered.
Decode of a valid Code 39 symbol with no leading space causes transmission in sequence of
all buffered data in a first-in first-out format, plus transmission of the “triggering” symbol.
See the following pages for further details.
When the Do Not Buffer Code 39 option is selected, decoded Code 39 symbols without
leading spaces are transmitted immediately.
Scan and Store affects Code 39 decodes only. If you select scan and store, we recommend that
you configure the scanner to decode Code 39 symbology only.
Buffer Code 39
(Enable)
Do Not Buffer Code 39
(Disable)
While there is data in the transmission buffer, disabling Code 39 buffering via the
parameter menu is not allowed. The buffer holds 200 bytes of information.
To allow disabling of Code 39 buffering, first force the buffer transmission (see Transmit
Buffer) or clear the buffer. Both the CLEAR BUFFER and TRANSMIT BUFFER bar codes
are length 1. Be sure Code 39 length is set to include length 1.
2-58
P 300STD/FZY/PRO Scanner Product Reference Guide
Buffer Data
To buffer data, Code 39 buffering must be enabled, and a symbol must be read with a space
immediately following the start pattern.
!Unless symbol overflows the transmission buffer, the scanner gives a low/high beep
to indicate successful decode and buffering. See Overfilling Transmission Buffer.
!The scanner adds the message, excluding the leading space, to the transmission
buffer.
!No transmission occurs.
Clear Transmission Buffer
To clear the transmission buffer, read a symbol which contains only a start character, a dash
(minus), and a stop character.
!The scanner issues a short high/low/high beep to signal that the transmission buffer
has been erased, and no transmission has occurred.
!The scanner erases the transmission buffer.
!No transmission occurs.
Clear Buffer
Transmit Buffer
To transmit the buffer, read a symbol containing either the first or second condition:
1. Only a start character, a plus (+), and a stop character.
!The scanner signals that the transmission buffer has been sent (a low/high beep).
!The scanner sends the buffer.
!The scanner clears the buffer.
Trans m it Buf fer
2-59
Programming the Scanner
2. A Code 39 bar code with a leading character other than a space.
!The scanner signals a good decode and buffering of that decode has occurred by
giving a high/low beep.
!The scanner transmits the buffer.
!The scanner signals that the buffer has been transmitted with a low/high beep.
Overfilling Transmission Buffer
If a decoded symbol results in an overflow of the transmission buffer:
!The scanner indicates that the symbol has been rejected by issuing three long,
high beeps.
!No transmission occurs. Data in the buffer is not affected.
Attempt to Transmit an Empty Buffer
If a decoded symbol was the transmit buffer symbol and the Code 39 buffer is empty:
!A short low/high/low beep signals that the buffer is empty.
!No transmission occurs.
!The buffer remains empty.
2-60
P 300STD/FZY/PRO Scanner Product Reference Guide
Convert Code 39 to Code 32
Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32.
Note: Code 39 must be enabled in order for this parameter to function.
Convert Code 39 to Code 32
Do Not Convert Code 39 to Code 32
2-61
Programming the Scanner
Enable/Disable Code 32 Prefix
Scan the appropriate bar code below to enable or disable adding the prefix character “A” to
all Code 32 bar codes.
Note: Convert Code 39 to Code 32 must be enabled for this parameter to
function.
Code 32 Prefix Enable
Code 32 Prefix Disable
2-62
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Code 93
To enable or disable Code 93, scan the appropriate bar code below.
Enable Code 93
Disable Code 93
2-63
Programming the Scanner
Set Lengths for Code 93
Lengths for Code 93 may be set for any length, one or two discrete lengths, or lengths within
a specific range. The length of a code refers to the number of characters (i.e., human readable
characters), including check digit(s) the code contains.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select Code 93 One Discrete Length, then scan 1, 4, only
Code 93 symbols containing 14 characters are decoded. Numeric bar codes begin on page
2-120. If you make an error or wish to change your selection, scan CANCEL on page 2-
122.
Code 93 - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing
two selected lengths. For example, if you select Code 93 Two Discrete Lengths, then
scan 0, 2, 1, 4, only Code 93 symbols containing 2 or 14 characters are decoded.
Numeric bar codes begin on page 2-120. If you make an error or wish to change your
selection, scan CANCEL on page 2-122.
Code 93 - Two Discrete Lengths
2-64
P 300STD/FZY/PRO Scanner Product Reference Guide
Length Within Range - This option allows you to decode a code type within a specified
range. For example, to decode Code 93 symbols containing between 4 and 12 characters,
first scan Code 93 Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must
always be preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make
an error or wish to change your selection, scan CANCEL on page 2-122.
Code 93 - Length within Range
Any Length - Scanning this option allows you to decode Code 93 symbols containing any
number of characters.
Code 93 - Any Length
2-65
Programming the Scanner
Enable/Disable Interleaved 2 of 5
To enable or disable Interleaved 2 of 5, scan the appropriate bar code below.
Enable Interleaved 2 of 5
Disable Interleaved 2 of 5
2-66
P 300STD/FZY/PRO Scanner Product Reference Guide
Set Lengths for Interleaved 2 of 5
Lengths for I 2 of 5 may be set for any length, one or two discrete lengths, or lengths within
a specific range. The length of a code refers to the number of characters (i.e., human readable
characters) the code contains, and includes check digits.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select I 2 of 5 One Discrete Length, then scan 1, 4, the
only I 2 of 5 symbols decoded are those containing 14 characters. Numeric bar codes begin
on page 2-120. If you make an error or wish to change your selection, scan CANCEL on
page 2-122.
I 2 of 5 - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing two
selected lengths. For example, if you select I 2 of 5 Two Discrete Lengths, then scan 0, 2, 1,
4, the only I 2 of 5 symbols decoded are those containing 2 or 14 characters. Numeric bar
codes begin on page 2-120. If you make an error or wish to change your selection, scan
CANCEL on page 2-122.
I 2 of 5 - Two Discrete Lengths
2-67
Programming the Scanner
Length Within Range - This option allows you to decode a code type within a specified range.
For example, to decode I 2 of 5 symbols containing between 4 and 12 characters, first scan I
2 of 5 Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must always be
preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make an error
or wish to change your selection, scan CANCEL on page 2-122.
I 2 of 5 - Length within Range
Any Length - Scanning this option allows you to decode I 2 of 5 symbols containing any
number of characters.
Note: Selecting this option may lead to misdecodes for I 2 of 5 codes.
I 2 of 5 - Any Length
2-68
P 300STD/FZY/PRO Scanner Product Reference Guide
I 2 of 5 Check Digit Verification
When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies
a specified algorithm, either Uniform Symbology Specification (USS ), or Optical Product
Code Council (OPCC).
Disable
USS Check Digit
OPCC Check Digit
2-69
Programming the Scanner
Transmit I 2 of 5 Check Digit
Scan a symbol below to transmit the data with or without the check digit.
Transmit I 2 of 5 Check Digit
(Enable)
Do Not Transmit I 2 of 5 Check Digit
(Disable)
2-70
P 300STD/FZY/PRO Scanner Product Reference Guide
Convert I 2 of 5 to EAN-13
This parameter converts a 14 character I 2 of 5 code into EAN-13, and transmits to the host
as EAN-13. In order to accomplish this, the I 2 of 5 code must be enabled, one length must
be set to 14, and the code must have a leading zero and a valid EAN-13 check digit.
Convert I 2 of 5 to EAN-13
(Enable)
Do Not Convert I 2 of 5 to EAN-13
(Disable)
2-71
Programming the Scanner
Enable/Disable Discrete 2 of 5
To enable or disable Discrete 2 of 5, scan the appropriate bar code below.
Enable Discrete 2 of 5
Disable Discrete 2 of 5
2-72
P 300STD/FZY/PRO Scanner Product Reference Guide
Set Lengths for Discrete 2 of 5
Lengths for D 2 of 5 may be set for any length, one or two discrete lengths, or lengths within
a specific range. The length of a code refers to the number of characters (i.e., human readable
characters) the code contains, and includes check digits.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select D 2 of 5 One Discrete Length, then scan 1, 4, the
only D 2 of 5 symbols decoded are those containing 14 characters. Numeric bar codes begin
on page 2-120. If you make an error or wish to change your selection, scan CANCEL on
page 2-122.
D 2 of 5 - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing two
selected lengths. For example, if you select D 2 of 5 Two Discrete Lengths, then scan 0, 2, 1,
4, the only D 2 of 5 symbols decoded are those containing 2 or 14 characters. Numeric bar
codes begin on page 2-120. If you make an error or wish to change your selection, scan
CANCEL on page 2-122.
D 2 of 5 - Two Discrete Lengths
2-73
Programming the Scanner
Length Within Range - This option allows you to decode a code type within a specified
range. For example, to decode D 2 of 5 symbols containing between 4 and 12 characters, first
scan D 2 of 5 Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must
always be preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make
an error or wish to change your selection, scan CANCEL on page 2-122.
D 2 of 5 - Length within Range
Any Length - Scanning this option allows you to decode D 2 of 5 symbols containing any
number of characters.
Note: Selecting this option may lead to misdecodes for D 2 of 5 codes.
D 2 of 5 - Any Length
2-74
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable Codabar
To enable or disable Codabar, scan the appropriate bar code below.
Enable Codabar
Disable Codabar
2-75
Programming the Scanner
Set Lengths for Codabar
Lengths for Codabar may be set for any length, one or two discrete lengths, or lengths within
a specific range. The length of a code refers to the number of characters (i.e., human readable
characters) the code contains. It also includes any start or stop characters.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select Codabar One Discrete Length, then scan 1, 4, the
only Codabar symbols decoded are those containing 14 characters. Numeric bar codes begin
on page 2-120. If you make an error or wish to change your selection, scan CANCEL on
page 2-122.
Codabar - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing two
selected lengths. For example, if you select Codabar Two Discrete Lengths, then scan 0, 2, 1,
4, the only Codabar symbols decoded are those containing 2 or 14 characters. Numeric bar
codes begin on page 2-120. If you make an error or wish to change your selection, scan
CANCEL on page 2-122.
Codabar - Two Discrete Lengths
Length Within Range - This option allows you to decode a code type within a specified
range. For example, to decode Codabar symbols containing between 4 and 12 characters,
first scan Codabar Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must
always be preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make
an error or wish to change your selection, scan CANCEL on page 2-122.
Codabar - Length within Range
2-76
P 300STD/FZY/PRO Scanner Product Reference Guide
Any Length - Scanning this option allows you to decode Codabar symbols containing any
number of characters.
Codabar - Any Length
2-77
Programming the Scanner
CLSI Editing
When enabled, this parameter strips the start and stop characters and inserts a space after the
first, fifth, and tenth characters of a 14-character Codabar symbol.
Note: Symbol length does not include start and stop characters.
Enable CLSI Editing
Disable CLSI Editing
2-78
P 300STD/FZY/PRO Scanner Product Reference Guide
NOTIS Editing
When enabled, this parameter strips the start and stop characters from decoded Codabar
symbol.
Enable NOTIS Editing
Disable NOTIS Editing
2-79
Programming the Scanner
Enable/Disable MSI Plessey
To enable or disable MSI Plessey, scan the appropriate bar code below.
Enable MSI Plessey
Disable MSI Plessey
2-80
P 300STD/FZY/PRO Scanner Product Reference Guide
Set Lengths for MSI Plessey
Lengths for MSI Plessey may be set for any length, one or two discrete lengths, or lengths
within a specific range. The length of a code refers to the number of characters (i.e., human
readable characters) the code contains, and includes check digits.
One Discrete Length - This option allows you to decode only those codes containing a
selected length. For example, if you select MSI Plessey One Discrete Length, then scan 1, 4,
the only MSI Plessey symbols decoded are those containing 14 characters. Numeric bar codes
begin on page 2-120. If you make an error or wish to change your selection, scan CANCEL
on page 2-122.
MSI Plessey - One Discrete Length
Two Discrete Lengths - This option allows you to decode only those codes containing two
selected lengths. For example, if you select MSI Plessey Two Discrete Lengths, then scan 0, 2,
1, 4, the only MSI Plessey symbols decoded are those containing 2 or 14 characters.
Numeric bar codes begin on page 2-120. If you make an error or wish to change your
selection, scan CANCEL on page 2-122.
MSI Plessey - Two Discrete Lengths
2-81
Programming the Scanner
Length Within Range - This option allows you to decode a code type within a specified range.
For example, to decode MSI Plessey symbols containing between 4 and 12 characters, first
scan MSI Plessey Length Within Range. Then scan 0, 4, 1, and 2 (single digit numbers must
always be preceded by a leading zero). Numeric bar codes begin on page 2-120. If you make
an error or wish to change your selection, scan CANCEL on page 2-122.
MSI Plessey - Length WIthin Range
Any Length - Scanning this option allows you to decode MSI Plessey symbols containing any
number of characters.
Note: Selecting this option may lead to misdecodes for MSI Plessey codes.
MSI Plessey - Any Length
2-82
P 300STD/FZY/PRO Scanner Product Reference Guide
MSI Plessey Check Digits
These check digits at the end of the bar code verify the integrity of the data. At least one check
digit is always required. Check digits are not automatically transmitted with the data.
One MSI Plessey Check Digit
Two MSI Plessey Check Digits
2-83
Programming the Scanner
Transmit MSI Plessey Check Digit
Scan a symbol below to transmit the data with or without the check digit.
Transmit MSI Plessey Check Digit
(Enable)
Scan this symbol if you want to transmit the data without the check digit.
Do Not Transmit MSI Plessey Check Digit
(Disable)
2-84
P 300STD/FZY/PRO Scanner Product Reference Guide
MSI Plessey Check Digit Algorithm
When two MSI Plessey check digits option is selected, an additional verification is required
to ensure integrity. Either of the two following algorithms may be selected.
Mod 11/Mod 10
Mod 10/Mod 10
2-85
Programming the Scanner
Enable/Disable PDF417
Scan a bar code below to enable or disable PDF417 scanning.
Note: This parameter is available only on the P 300PRO.
Enable PDF417
Disable PDF417
2-86
P 300STD/FZY/PRO Scanner Product Reference Guide
Enable/Disable MicroPDF
Scan a bar code below to enable or disable MicroPDF417 scanning.
Note: This parameter is available only on the P 300PRO.
Enable MICROPDF417 Disable MICROPDF417
2-87
Programming the Scanner
Code 128 Emulation
When this parameter is enabled, the scanner transmits data from certain MicroPDF417
symbols as if it was encoded in Code 128 symbols. Transmit AIM Symbology Identifiers must
be enabled for this parameter to work.
If Code 128 Emulation is enabled, these MicroPDF417 symbols are transmitted with the one
of the following prefixes:
]C1 if the first codeword is 903-907, 912, 914, 915
]C2 if the first codeword is 908 or 909
]C0 if the first codeword is 910 or 911
If disabled, they are transmitted with one of the following prefixes:
]L3 if the first codeword is 903-907, 912, 914, 915
]L4 if the first codeword is 908 or 909
]L5 if the first codeword is 910 or 911
Scan a bar code below to enable or disable Code 128 Emulation.
Enable Code 128 Emulation
Disable Code 128 Emulation
2-88
P 300STD/FZY/PRO Scanner Product Reference Guide
UCC/EAN-128 Emulation
Certain MicroPDF417 symbols can be “linked” with a linear symbol during transmission as
if they were one symbol. The MicroPDF417 symbol provides supplemental data to the linear
symbol. Three scanning options are offered for these symbols:
!If Decode Linked Symbol is selected, Code 128, ITF-14 and UPC/EAN symbols are
not decoded unless a MicroPDF417 symbol beginning with codeword 906, 907,
912, 914, or 915 is present.
!If Ignore Linked Symbol is selected, MicroPDF417 symbols beginning with
codeword 906, 907, 912, 914, or 915 are ignored.
!If Autodiscriminate Linked Symbol is selected, the scanner looks for a MicroPDF417
symbol when scanning a 1-D symbol. If a MicroPDF417 symbol is not detected
within the timeout period, the 1-D symbol data is transmitted.
The Timeout Between Decodes, Different Symbols parameter must be set to 0 before Ignore
Linked Symbol or Autodiscriminate Linked Symbol can be selected.
Select one option for UCC/EAN 128 Emulation by scanning the appropriate bar code.
Decode Linked Symbol
Ignore Linked Symbol
Autodiscriminate Linked Symbol
2-89
Programming the Scanner
Scanning Mode
This parameter allows you to select one of the following scanning mode options (see P
300PRO Scanning Mode Options on page 1-8 for descriptions):
!Smart Raster • Always Raster
!Slab Only Raster • Programmable Raster
Select a scanning mode.
Note: This parameter is available only on the P 300PRO.
Smart Raster
Always Raster
Slab Only Raster
Programmable Raster
2-90
P 300STD/FZY/PRO Scanner Product Reference Guide
Programmable Raster Height And Raster Expansion Speed
Note: This parameter is available only on the P 300PRO.
This parameter allows you to select the laser pattern’s height and rate of expansion, and is
only used when Programmable Raster or Always Raster is enabled. This parameter is
intended for very specific applications, and is usually not necessary.
Select the laser pattern’s height and/or rate of expansion.
1. Scan the bar code for either RASTER HEIGHT or RASTER EXPANSION
SPEED below.
2. To represent a two-digit value, scan two bar codes from the next page. Valid values
are between 01 and 15.
3. If you make an error, or wish to change your selection, scan CANCEL.
Raster Height (Default 15)
Raster Expansion Speed (Default 11)
2-91
Programming the Scanner
Programmable Raster Height And Raster Expansion Speed
(Continued)
1
23
45
67
89
0
Cancel
2-92
P 300STD/FZY/PRO Scanner Product Reference Guide
Aiming Mode
Note: This parameter is available only on the P 300PRO.
This parameter allows you to select either an aiming dot or slab raster for aiming. See Aiming
Modes on page 1-10 for descriptions.
Select the aiming mode.
Note: Aiming modes can not be used with the Always Raster scanning
option.
Slab Raster
Aiming Dot
(Normal Timeout)
Aiming Dot
(Extended Timeout)
2-93
Programming the Scanner
Transmit Code ID Character
A code ID character identifies the code type of a scanned bar code. This may be useful when
the scanner is decoding more than one code type. In addition to any single character prefix
already selected, the code ID character is inserted between the prefix and the decoded symbol.
The user may select no code ID character, a Symbol Code ID character, or an AIM Code ID
character. The Symbol Code ID characters are listed below; see AIM Code Identifiers in
Appendix A, Programming Reference.
A = UPC-A, UPC-E, EAN-8, EAN-13
B = Code 39
C = Codabar
D = Code 128
E = Code 93
F = Interleaved 2 of 5
G = Discrete 2 of 5, or Discrete 2 of 5 IATA
J = MSI Plessey
K = UCC/EAN-128
L = Bookland EAN
M = Trioptic Code 39
X = PDF 417
2-94
P 300STD/FZY/PRO Scanner Product Reference Guide
Transmit Code ID Character
Symbol Code ID Character
AIM Code ID Character
None
2-95
Programming the Scanner
Pause Duration
This parameter inserts a pause at any point in the data transmission. Pauses are set by
scanning a two-digit number (i.e. two bar codes), and are measured in 0.1 second intervals.
For example, scanning bar codes “0” and “1” inserts a 0.1 second pause; “0” and “5” gives
you a 0.5 second delay. Numeric bar codes begin on page 2-120. If you make an error or
wish to change your selection, scan DATA FORMAT CANCEL on page 2-96.
Pause Duration
2-96
P 300STD/FZY/PRO Scanner Product Reference Guide
Prefix/Suffix Values
A prefix/suffix may be appended to scan data for use in data editing. These values are set by
scanning a four-digit number (i.e., four bar codes) that corresponds to key codes for various
terminals. See Table A-2., AIM Code Identifiers in Appendix A, Programming Reference for
conversion information. Numeric bar codes begin on page 2-120. If you make an error or
wish to change your selection, scan CANCEL on page 2-122.
Scan Prefix
Scan Suffix
Data Format Cancel
2-97
Programming the Scanner
Scan Data Transmission Format
To change the Scan Data Transmission Format, scan the SCAN OPTIONS bar code below.
Then select one of four options. When you have made your selection, scan the ENTER bar
code on the next page. If you make a mistake, scan the DATA FORMAT CANCEL bar code
on the next page.
Scan Options
Data As Is
<Data> <Suffix>
<Prefix> <Data>
2-98
P 300STD/FZY/PRO Scanner Product Reference Guide
<Prefix> <Data> <Suffix>
Enter
Data Format Cancel
2-99
Programming the Scanner
RS-232C Parameters
Baud Rate
Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting
should match the data rate setting of the host device. If not, data may not reach the host
device or may reach it in distorted form.
Baud Rate 600
Baud Rate 1200
Baud Rate 2400
Baud Rate 4800
2-100
P 300STD/FZY/PRO Scanner Product Reference Guide
Baud Rate 9600
Baud Rate 19,200
Baud Rate 38,400
Parity
A parity check bit is the most significant bit of each ASCII coded character. Select the parity
type according to host device requirements.
!If you select ODD parity, the parity bit has a value 0 or 1, based on data, to ensure
than an odd number of 1 bits are contained in the coded character.
Odd
!If you select EVEN parity, the parity bit has a value 0 or 1, based on data, to ensure
than an even number of 1 bits are contained in the coded character.
2-101
Programming the Scanner
Even
!Select MARK parity and the parity bit is always 1.
Mark
!Select SPACE parity and the parity bit is always 0.
Space
!If no parity is required, select NONE.
None
Check Parity
Select whether or not the parity, framing, and overrun of received characters are checked. The
type of parity used is selectable through the PARITY parameter.
2-102
P 300STD/FZY/PRO Scanner Product Reference Guide
Check for Received Errors
Do Not Check for Received Errors
Hardware Handshaking
The data interface consists of an RS-232C port, designed to operate either with or without
the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS).
If Standard RTS/CTS handshaking is selected, scan data is transmitted according to the
following sequence:
!The controller reads the CTS line for activity. If CTS is asserted, the controller waits
up to 2 seconds for the host to negate the CTS line. If, after 2 seconds (default), the
CTS line is still asserted, the scanner sounds a transmit error and any scanned data
is lost.
!When the CTS line is negated, the controller asserts the RTS line and waits up to 2
seconds for the host to assert CTS. When the host asserts CTS, data is transmitted.
If, after 2 seconds (default), the CTS line is not asserted, the scanner sounds a
transmit error and discards the data.
!When data transmission is complete, the controller negates RTS 10 msec after
sending the last character.
!The host responds by negating CTS. The controller checks for a negated CTS upon
the next transmission of data.
During the transmission of data, the CTS line should be asserted. If CTS is deasserted for
more than 50 ms between characters, the transmission is aborted, the scanner sounds a
transmission error, and the data is discarded.
If the above communications sequence fails, the scanner issues an error indication. In this
case, the data is lost and must be rescanned.
2-103
Programming the Scanner
If Hardware Handshaking and Software Handshaking are both enabled, Hardware
Handshaking takes precedence.
Note: The DTR signal is jumpered active.
Scan the bar code below if no Hardware Handshaking is desired.
None
Scan the bar code below to select Standard RTS/CTS Hardware Handshaking.
Standard RTS/CTS
When RTS/CTS Option 1 is selected, the scanner asserts RTS before transmitting and ignores
the state of CTS. The scanner deasserts RTS when the transmission is complete.
RTS/CTS Option 1
When Option 2 is selected, RTS is always high or low (user-programmed logic level).
However, the scanner waits for CTS to be asserted before transmitting data. If CTS is not
asserted within 2 seconds (default), the scanner issues an error beep and discards the data.
2-104
P 300STD/FZY/PRO Scanner Product Reference Guide
RTS/CTS Option 2
When Option 3 is selected, the scanner asserts RTS prior to any data transmission, regardless
of the state of CTS. The scanner waits up to 2 seconds (default) for CTS to be asserted. If CTS
is not asserted during this time, the scanner issues an error beep and discards the data. The
scanner deasserts RTS when transmission is complete.
RTS/CTS Option 3
Software Handshaking
This parameter offers control of the data transmission process in addition to, or instead of,
that offered by hardware handshaking. There are five options.
If Software Handshaking and Hardware Handshaking are both enabled, Hardware
Handshaking takes precedence.
!None
When this option is selected, data is transmitted immediately.
None
!ACK/NAK
When this option is selected, after transmitting data, the scanner expects either an
ACK or NAK response from the host. Whenever a NAK is received, the scanner
2-105
Programming the Scanner
transmits the same data again and waits for either an ACK or NAK. After three
unsuccessful attempts to send data when NAKs are received, the scanner issues an
error beep and discards the data.
The scanner waits up to the programmable Host Serial Response Time-out to receive
an ACK or NAK. If the scanner does not get a response in this time, it issues an error
beep and discards the data. There are no retries when a time-out occurs.
ACK/NAK
!ENQ
When this option is selected, the scanner waits for an ENQ character from the host
before transmitting data. If an ENQ is not received within 2 seconds, the scanner
issues an error indication and discards the data. The host must transmit an ENQ
character at least every 2 seconds to prevent transmission errors.
ENQ
!ACK/NAK with ENQ
This combines the two previous options.
ACK/NAK with ENQ
!XON/XOFF
An XOFF character turns the scanner transmission off until the scanner receives an
XON character. There are two situations for XON/XOFF:
2-106
P 300STD/FZY/PRO Scanner Product Reference Guide
!XOFF is received before the scanner has data to send. When the scanner has
data to send, it then waits for an XON character before transmission. The
scanner waits up to 2 seconds to receive the XON. If the XON is not
received within this time, the scanner issues an error beep and discards the
data.
!XOFF is received during a transmission. Data transmission then stops after
sending the current byte. When the scanner receives an XON character, it
sends the rest of the data message. The scanner waits indefinitely for the
XON.
XON/XOFF
Host Serial Response Time-out
This parameter specifies how long the scanner waits for an ACK, NAK, or CTS before
determining that a transmission error has occurred. This only applies when in one of the
ACK/NAK Software Handshaking modes, or RTS/CTS Hardware Handshaking option.
The delay period can range from 0.0 to 9.9 seconds in .1-second increments. After scanning
the bar code below, scan two numeric bar codes beginning on page 2-120. If you make an
error or wish to change your selection, scan CANCEL on page 2-122.
Host Serial Response Time-out
RTS Line State
This parameter sets the idle state of the Serial Host RTS line. Select Low or High RTS line
state.
2-107
Programming the Scanner
Host: Low RTS
Host: High RTS
Stop Bit Select
The stop bit(s) at the end of each transmitted character marks the end of transmission of one
character and prepares the receiving device for the next character in the serial data stream.
The number of stop bits selected (one or two) depends on the number the receiving terminal
is programmed to accommodate. Set the number of stop bits to match host device
requirements.
1 Stop Bit
2 Stop Bits
2-108
P 300STD/FZY/PRO Scanner Product Reference Guide
ASCII Format
This parameter allows the scanner to interface with devices requiring a 7-bit or 8-bit ASCII
protocol.
7-Bit
8-Bit
Beep on <BEL>
When this parameter is enabled, the scanner issues a beep when a <BEL> character is detected
on the RS-232C serial line. <BEL> alerts the user that an illegal entry or other important event
has occurred.
Beep On <BEL> Character
(Enable)
Do Not Beep on <BEL> Character
(Disable)
2-109
Programming the Scanner
Intercharacter Delay
Select the intercharacter delay option matching host requirements. The intercharacter delay
gives the host system time to service its receiver and perform other tasks between characters.
The delay period can range from no delay to 99 msec in 1-msec increments. After scanning
the bar code below, scan two bar codes beginning on page 2-120 to set the desired time-out.
If you make an error or wish to change your selection, scan CANCEL on page 2-122.
Intercharacter Delay
2-110
P 300STD/FZY/PRO Scanner Product Reference Guide
Wand Parameters
Wand Host Interface
Note: This parameter is available only on the P 300FZY.
Select the appropriate host by scanning one of the bar codes below.
Symbollink Controller
Symbol Portable Terminal
Norand Terminal
2-111
Programming the Scanner
Wand Emulator Bar Output
Note: This parameter is available only on the P 300FZY.
Select the option that matches your host system.
Bar High
Bar Low
2-112
P 300STD/FZY/PRO Scanner Product Reference Guide
Variable Leading Margin
Note: This parameter is available only on the P 300FZY.
Select a variable leading margin.
80 msec
90 msec
100 msec
110 msec
120 msec
130 msec
2-113
Programming the Scanner
Variable Leading Margin (cont’d)
150 msec
160 msec
170 msec
180 msec
190 msec
200 msec
140 msec
2-114
P 300STD/FZY/PRO Scanner Product Reference Guide
Convert All to Code 39
Note: This parameter is available only on the P 300FZY.
Select whether or not to convert the decoded output to Code 39.
Convert All to Code 39
Do Not Convert All to Code 39
2-115
Programming the Scanner
Keyboard Wedge Parameters
Host Interfaces
Note: This parameter is available only on the P 300FZY.
Use these bar codes to select your host interface.
IBM PC/AT IBM PS/2-50, 55SX, 60, 70, 80 (Default)
IBM PS/2-30
IBM PC/XT
NCR 7052
2-116
P 300STD/FZY/PRO Scanner Product Reference Guide
National Keyboard Types
Note: This parameter is available only on the P 300FZY.
Use these bar codes to select the appropriate national keyboard type.
North American
French
German
French International
Spanish
2-117
Programming the Scanner
Italian
Swedish
British
2-118
P 300STD/FZY/PRO Scanner Product Reference Guide
Fast Transmit
Note: This parameter is available only on the P 300FZY.
Older systems may require a slower transmission method. If your system still needs additional
time to process keyboard data after setting an Intercharacter Delay, scan the DISABLE FAST
TRANSMIT bar code.
Enable Fast Transmit
Disable Fast Transmit
2-119
Programming the Scanner
Intercharacter Delay
Note: This parameter is available only on the P 300FZY.
Select the intercharacter delay option matching host requirements. The intercharacter delay
gives the host system time to service its receiver and perform other tasks between characters.
The delay period can range from no delay to 99 msec in 1-msec increments. After scanning
the bar code below, scan two bar codes beginning on page 2-120 to set the desired time-out.
If you make an error or wish to change your selection, scan CANCEL on page 2-122.
Intercharacter Delay
Convert Control Characters
When enabled, this parameter converts special control character sequences to their
corresponding keycodes. It converts the <CTRL> M, <CTRL> I, and <CTRL> [ sequences to
<Enter>, <Tab>, <Backspace>, and <Esc> respectively.
Note: This parameter is available on the P 300FZY only.
Disable Convert Control Character
Enable Convert Control Character
2-120
P 300STD/FZY/PRO Scanner Product Reference Guide
Numeric Bar Codes
For parameters requiring specific numeric values, scan the appropriately numbered bar
code(s).
0
1
2
3
4
2-121
Programming the Scanner
5
6
7
8
9
2-122
P 300STD/FZY/PRO Scanner Product Reference Guide
Cancel
If you make an error or wish to change your selection, scan the bar code below.
Cancel
2-123
Programming the Scanner
Macro PDF Features
This section discusses programmable Macro PDF features fully supported by the P 300PRO
scanner. Macro PDF is a special feature for concatenating multiple PDF symbols into one file.
The P 300PRO can decode symbols that are encoded with this feature.
Caution
When printing, keep each Macro PDF sequence separate, for each sequence
has unique identifiers. Do not mix bar codes from several Macro PDF se-
quences, even if they encode the same data. When scanning Macro PDF se-
quences, scan the entire Macro PDF sequence without interruption. If you
scan a mixed sequence, you get two long low beeps (Lo Lo) for inconsistent
file ID or inconsistent symbology error.
Before programming these special features, follow the physical setup instructions in Chapter
1, Getting Started. Then program the required generic decode and data transmission
parameters using the bar codes on the following pages. Use the same programming method
for setting Macro PDF features as used for standard features.
Note that all parameter settings are stored in non-volatile memory and so are retained after
powerdown.
2-124
P 300STD/FZY/PRO Scanner Product Reference Guide
Macro PDF Transmit / Decode Mode Symbols
Select only one of the four options below for handling the decoding of Macro PDF.
!Buffer All Symbols / Transmit Macro PDF When Complete: This activates
transmission of all decode data from an entire Macro PDF sequence. Transmission
does not occur until the entire Macro PDF sequence is scanned and decoded. This is
the default option.
If the decode data exceeds the limit of the space available in RAM, there is no
transmission because the entire sequence has not been scanned, and an error occurs.
Use the parameter Flush Macro PDF Buffer to purge the buffer.
!Transmit Any Symbol in Set / No Particular Order: This causes transmission of data
from each Macro PDF417 symbol as decoded, whether it is in sequential order or
not. Up to 1024 Macro PDF bar codes may be transmitted.
!Scan in Sequence Only / Transmit in Sequence Without Buffering: This causes
transmission of data from each symbol within the Macro PDF sequence as decoded,
provided the Macro PDF symbols are scanned in order. If you do not scan the
symbols in order, an error occurs. Up to 1024 Macro PDF bar codes may be
transmitted.
!Buffer Scans Out of Order / Transmit Scans in Order: When enabled, decode data
from each symbol within the Macro PDF sequence is transmitted when decoded,
provided that the Macro PDF symbols are scanned in order. Decode data from
symbols out of order in the Macro PDF sequence is buffered. If the decode data
exceeds the limit of the space available in RAM, there is no transmission because the
entire sequence has not been scanned, and an error occurs. Use the parameter Flush
Macro PDF Buffer to purge the buffer.
2-125
Programming the Scanner
Macro PDF Transmit / Decode Mode Symbols (Continued)
Buffer All Symbols /
Transmit When Complete - Default
Buffer Scans Out Of Order/
Transmit Scans In Order
Transmit Any Symbol In Set /
No Particular Order
Scan In Sequence Only /
Transmit In Sequence Without Buffering
2-126
P 300STD/FZY/PRO Scanner Product Reference Guide
Transmit Symbols in Codeword Format
Enabling this activates transmission of each PDF symbol as directly decoded data codewords,
whether that symbol is part of a macro PDF sequence or not. Note that data is output as
codeword values — not as interpreted data.
“Codeword values” is an ASCII representation of a number from 000 to 928 for each
codeword, preceded by an escape character. This escape character is a backslash by default,
but the user may change this value. For example, the codeword value 005 is sent to the host
in the form of \005 for GLIs, and \C005C for ECIs. This output format is based on the AIM
USA Uniform Symbology Specification for PDF417 (1994).
All output codewords take up exactly 4 characters for GLIs and 6 characters for ECIs.
However, there may be non-decodable characters in the PDF symbol, such as a GLI sequence.
This special codeword sequence activates a certain kind of interpretation to the encoded data.
Non-decodable codewords like GLIs are embedded in the output stream just like any other
codeword, e.g., \927\001.
Because GLIs are indistinguishable from other codewords in the output data stream, the host
must intelligently recognize them as GLIs and process their interpretations.
Note that when a macro PDF sequence is transmitted, the last character in the last block of
data transmitted is always\922 (if selected). This indicates the end of that macro PDF
transmission.
2-127
Programming the Scanner
Transmit Symbols in Codeword Format (Continued)
Enable or disable by scanning the appropriate bar code.
Enable Transmit In Codeword Format
Disable Transmit In Codeword Format
2-128
P 300STD/FZY/PRO Scanner Product Reference Guide
Escape Characters
This enables the backslash (\) character as an Escape character for systems that can process
transmissions containing special data sequences. Scan a bar code below to either format
special data (e.g., GLI escapes, MacroPDF417 Control Block optional fields) according to the
GLI (Global Label Identifier) protocol or the ECI (Extended Channel Interpretation)
protocol, or to disable this parameter.
ECI Protocol
GLI Protocol
None
2-129
Programming the Scanner
Delete Character Set ECIs
This parameter enables the scanner to delete any escape sequences representing Character Set
ECIs (also known as GLIs) from its buffer before transmission. In many receiving systems,
Character Set ECIs can be removed without affecting the way data is displayed or processed.
When deletion is selected, the scanner transmits data from PDF417 and MicroPDF417 bar
codes containing Character Set ECIs, even when the ECI Protocol is disabled.
Scan a bar code to delete or transmit character set ECIs.
Delete Character Set ECIs
Transmit Character Set ECIs
2-130
P 300STD/FZY/PRO Scanner Product Reference Guide
ECI Decoder
This parameter enables the scanner to interpret any Extended Channel Interpretations (ECIs)
that are supported by the scanner firmware. This parameter has no effect on symbols that
were not encoded using ECIs. This version of the product supports ECIs 000900 through
000913, used for efficient encoding of Common Data Syntax Format 00-99. If this parameter
is disabled, and a symbol is scanned that was encoded using an ECI escape, the scanner
transmits the ECI escape followed by the uninterpreted data.
Scan a bar code to enable or disable this option.
Enable ECI Decoder
Disable ECI Decoder
2-131
Programming the Scanner
Transmit Unknown Codewords
This enables using the output codeword format for transmitting any non-GLI or non-macro
PDF codeword. If this is not enabled and an unknown codeword is found, a decode error
beep sounds.
Enable or disable by scanning the appropriate bar code.
Transmit Unknown Codewords
Do Not Transmit Unknown Codewords
2-132
P 300STD/FZY/PRO Scanner Product Reference Guide
Transmit Macro PDF User-Selected Fields
When enabled, the following parameters cause transmission of the specified field in
subsequently scanned Macro PDF417 symbols. Unless transmission of a specific field is
enabled, it is not transmitted. The options cannot be changed in the middle of a Macro PDF
set entry. All user-selected fields are prefixed by \923 for GLIs, and \C923C for ECIs. Tags
and examples in the following parameters demonstrate GLI protocol, but the ECI tag
(\C923C) can be used instead if ECI protocol is enabled.
!Transmit File Name: Activates transmission of the file name field. The field character
tag is \923\000. For example, the filename MANHOURS.WK1 is sent as:
\923\000MANHOURS.WK1.
!Transmit Block Count: This activates transmission of the block count field. The field
character tag is \923\001. For example, the field may be: \923\0011856.
!Transmit Time Stamp: This activates transmission of the time stamp field. The field
character tag is \923\002. For example, the field may be: \923\0022123443243234.
!Transmit Sender: Activates transmission of the sender field. The field character tag
is \923\003. For example, the field may be: \923\003Symbol TechnologiesHoltsville,
NY.
!Transmit Addressee: Activates transmission of the addressee field. The field
character tag is \923\004. For example, the field may be: \923\004AIM USA.
!Transmit File Size: Activates transmission of the file size field. The field character tag
is \923\005. For example, the field may be: \923\005179234.
!Transmit Checksum: Activates transmission of the checksum field. The field
character tag is \923\006. For example, the field may be: \923\00663823.
!Transmit Macro PDF Control Header: Activates transmission of the control header,
which contains the segment index and the file ID. For example, the field may be:
\92800000\725\120\343. The five digits after the \928 are the segment index (or
block index), and \725\120\343 is the file ID.
!Enable / Disable Last Block Marker: This enables marking the last block in the set
by the codeword \922.
2-133
Programming the Scanner
Transmit Macro PDF User-Selected Fields (Continued)
Enable or disable by scanning the appropriate bar code.
Enable File Name Transmit Disable File Name Transmit
Enable Block Count Transmit Disable Block Count Transmit
Enable Time Stamp Transmit Disable Time Stamp Transmit
Enable Sender Transmit Disable Sender Transmit
2-134
P 300STD/FZY/PRO Scanner Product Reference Guide
Transmit Macro PDF User-Selected Fields (Continued)
Disable File Size TransmitEnable File Size Transmit
Enable Checksum Transmit Disable Checksum Transmit
Enable Macro PDF Control
Header Transmit
Disable Macro PDF Control
Header Transmit
Enable Last Block Marker Disable Last Block Marker
Enable Addressee Transmit Disable Addressee Transmit
2-135
Programming the Scanner
Flush Macro Buffer
This flushes the buffer of all decoded Macro PDF data stored to that point, transmits it to the
host device, and aborts from Macro PDF mode.
Abort Macro PDF Entry
This clears all currently-stored Macro PDF data in the buffer without transmission and aborts
from Macro PDF mode.
Flush Macro PDF Buffer
Abort Macro PDF Entry
2-136
P 300STD/FZY/PRO Scanner Product Reference Guide
3-1
Chapter 3
Advanced Data Formatting (ADF)
Introduction
Advanced Data Formatting (ADF) is a means of customizing, or editing, the data scanned by
the scanner before transmitting the data to your host device. Scanned data can be edited to
suit your particular requirements.
ADF is implemented by scanning a related series of bar codes to create rules to apply to the
scanned data. These bar codes appear later in this chapter.
Rules: Criteria Linked to Actions
In ADF, data is customized through rules. These rules perform specific actions when the data
meets certain criteria. One rule may consist of single or multiple actions applied to single or
multiple criteria.
For instance, a data formatting rule could be the following:
Criteria: When scan data is Code 39, length 12,
and data at the start position is the string “129”,
Actions: pad all sends with zeros to length 8,
send all data up to X,
send a space.
In this example, if a Code 39 bar code of 1299X1559828 is scanned, the following is
transmitted: 00001299<space>. If a Code 39 bar code of 1299X15598 is scanned, this rule
is ignored because the length (10 characters) does not pass the criteria.
The rule specifies the editing conditions and requirements before data transmission occurs.
3-2
P 300 STD/FZY/PRO Scanner Product Reference Guide
Using ADF Bar Codes
When you program a rule, make sure the rule is logically correct. Plan ahead before you start
scanning.
To program each data formatting rule:
1. Start the Rule. Scan the Begin New Rule bar code on page 3-11.
2. Criteria. Scan the bar codes for all pertinent criteria. Criteria can include code type
(e.g., Code 128), code length, or data that contains a specific character string (e.g.,
the digits “129”). These options are described in Criteria on page 3-14.
3. Actions. Scan all actions related to, or affecting, these criteria. The actions of a rule
specify how to format the data for transmission. These options are described in
Actions on page 3-25.
4. Save the Rule. Scan the Save Rule bar code on page 3-11. This places the rule in the
“top” position in the rule buffer.
If you make errors during this process, some special-purpose bar codes may be useful: Erase
Criteria and Start Again, Erase Actions and Start Again, Erase Previously Saved Rule, and
Erase All Rules. See Erase on page 3-12.
Beeper Definitions for ADF on page 3-8 help guide you through the programming steps.
3-3
Advanced Data Formatting (ADF)
ADF Bar Code Menu Example
This section provides an example of how to enter an ADF rule to apply to scanned data.
An auto parts distribution center wants to encode manufacturer ID, part number, and
destination code into their own Code 128 bar codes. The distribution center also has
products that carry UPC bar codes, placed there by the manufacturer. The Code 128 bar
codes have the following format:
MMMMMPPPPPDD
Where: M = Manufacturer ID
P = Part Number
D = Destination Code
The distribution center uses a PC with dedicated control characters for manufacturer ID
<CTRL M>, part number <CTRL P>, and destination code <CTRL D>. At this center the
UPC data is treated as manufacturer ID code.
The following rules need to be entered:
When scanning data of code type Code 128, send the next 5 characters, send the
manufacturer ID key <CTRL M>, send the next 5 characters, send the part number
key <CTRL P>, send the next 2 characters, send the destination code key <CTRL D>.
When scanning data of code type UPC/EAN, send all data, send the manufacturer ID
key <CTRL M>.
To enter these rules, follow these steps:
3-4
P 300 STD/FZY/PRO Scanner Product Reference Guide
Rule 1: The Code 128 Scanning Rule
Rule 2: The UPC Scanning Rule
If you made any mistakes while entering this rule, scan the Quit Entering Rules bar code on
page 3-12. If you already saved the rule, scan the Erase Previously Saved Rule bar code on
page 3-12.
Table 3-1. Code 128 Scanning Rule
Step Bar Code On Page Beep Indication
1 Begin New Rule 3-11 High High
2 Code 128 3-14 High High
3 Send next 5 characters 3-26 High High
4 Send <CTRL M> 3-51 High High
5 Send next 5 characters 3-26 High High
6 Send <CTRL P> 3-51 High High
7 Send next 2 characters 3-25 High High
8 Send <CTRL D> 3-49 High High
9Save Rule 3-11 High Low High Low
Table 3-2. UPC Scanning Rule
Step Bar Code On Page Beep Indication
1 Begin New Rule 3-11 High High
2UPC/EAN 3-15 High High
3Send all remaining data 3-25 High High
4Send <CTRL M> 3-51 High High
5Save Rule 3-11 High Low High Low
3-5
Advanced Data Formatting (ADF)
Alternate Rule Sets
ADF rules may be grouped into one of five alternate sets that can be turned on and off when
needed. This is useful when you want to format the same message in different ways. For
example, a Code 128 bar code contains the following information:
Class (2 digits), Stock Number (8) digits, Price (5 digits)
This bar code might look like this:
245671243701500
where:
Class = 24
Stock Number = 56712437
Price = 01500
Ordinarily you would send this data as follows:
24 (class key)
56712437 (stock key)
01500 (enter key)
But, when there is a sale, you may want to send only the following:
24 (class key)
56712437 (stock key)
and the cashier keys the price manually.
To implement this, first enter an ADF rule that applies in the normal situation. This rule may
look like this:
When scanning a bar code of length 15, send the next 2 characters, send the class key,
send the next 8 characters, send the stock key, send the data that remains, send the Enter
key.
The “sale” rule may look like this:
When scanning a bar code of length 15, send the next 2 characters, send the class key,
send the next 8 characters, send the stock key.
To switch between the two sets of rules, a “switching rule” must be programmed. This rule
specifies what type of bar code must be scanned to switch between the rule sets. For example,
3-6
P 300 STD/FZY/PRO Scanner Product Reference Guide
in the case of the “sale” rule above, the rule programmer wants the cashier to scan the bar
code “M” before a sale. To do this, a rule can be entered as follows:
When scanning a bar code of length 1 that begins with “M”, select rule set number 1.
Another rule could be programmed to switch back.
When scanning a bar code of length 1 that begins with “N”, turn off rule set number 1.
The switching back to normal rules can also be done in the “sale” rule. For example, the rule
may look like this:
When scanning a bar code of length 15, send the next 2 characters, send the class key,
send the next 8 characters, send the stock key, turn off rule set 1.
It is recommended that you scan the Disable All Rule Sets bar code after programming a rule
belonging to an alternate rule set.
In addition to enabling and disabling rule sets within the rules, you can disable them by
scanning the appropriate bar codes in Disable Rule Set on page 3-13.
Rules Hierarchy (in Bar Codes)
The order of programming individual rules is important. The most general rule should be
programmed first.
All programmed rules are stored in a buffer. As they are programmed, they are stored at the
“top” of a rules list. If three rules have been created, the list would be configured as follows:
Third Rule
Second Rule
First Rule
When data is scanned, the rules list is checked from top to bottom to determine if the criteria
matches (and therefore, if the actions should occur). Input is modified into the data format
specified by the first matching set of criteria it finds. Be sure that your most general rule is the
first one programmed.
For example, if the THIRD rule states:
When scanning a bar code of any length, send all data, then send the ENTER key.
And the SECOND rule states:
When scanning a Code 128 bar code of length 12, send the first four characters, then
send the ENTER key, then send all remaining data.
3-7
Advanced Data Formatting (ADF)
If a Code 128 bar code of length 12 were scanned, the THIRD rule would be in effect. The
SECOND rule would appear to not function.
Note also that ADF rules are actually created when you use the standard data editing
functions. Scan options are entered as ADF rules, and the hierarchy mentioned above also
applies to them. For the P 300, this applies to prefix/suffix programming in the parameter
Scan Data Transmission Format.
These rules reside in the same “rule list” as ADF Rules, so the order of their creation is also
important.
Default Rules
Every unit has a default rule to send all scan data. Units with custom software may have one
or more default rules burned in. The rules hierarchy checks user programmable rules first,
then the default rules. Default rules can be disabled by entering the following general rule in
the user programmable buffer:
When receiving scan data, send all data.
Since this rule always applies, ADF will never go into the default rules.
3-8
P 300 STD/FZY/PRO Scanner Product Reference Guide
Beeper Definitions for ADF
The following table defines beep sequences that occur during rule entry.
Table 3-3. Beeper Definitions
Beeper Sequence Indication
Normal Data Entry. Duration of tones are short.
High-Low Entry of a number is expected. Enter another digit. Add leading zeros
to the front if necessary.
Low-Low Entry of an alphabetic character is expected. Enter another character
or scan the End of Message bar code.
High-High Entry of Criterion/Action is expected. Enter another criterion or
action, or scan the Save Rule bar code.
High-Low-High-Low Rule saved. Rule entry mode exited.
High-Low-Low All criteria or actions were cleared for rule currently being entered;
continue entry of rule.
Low Last saved rule was successfully deleted. The rule presently being
entered is left intact.
Low-High-High All rules are now deleted. The rule presently being entered is left
intact. (This beep sequence has a different meaning outside of ADF.)
Error Indications. Duration of tones are very long.
Low-High-Low-High Out of rule memory. Erase some existing rules, then try to save rule
again. (The current rule need not be re-entered.)
Low-High-Low Cancel rule entry. Rule entry mode exited because of an error or the
user asked to exit rule entry.
Low-High Entry error, wrong bar code scanned. Re-enter criterion or action. All
previously entered criteria and actions are retained. Criteria or action
list is too long for a rule.
3-9
Advanced Data Formatting (ADF)
ADF Bar Codes
The following table helps you locate the bar codes you need to create an ADF rule.
Table 3-4. ADF Bar Codes
Bar Code Description Page
Special Commands
Begin New Rule Starts data formatting rule. 3-11
Save Rule Completes and saves rule. 3-11
Erase Erases criteria, actions, or rules. 3-12
Quit Entering Rules Quits entering rules. 3-12
Disable Rule Set Disables rule sets. 3-13
Criteria
Code Types Selects code types to be affected by rule. 3-14
Code Lengths Defines the number of characters each code type must contain. 3-17
Message Containing A
Specific Data String
Select whether formatting affects data that begins with or
contains a specific character or data string.
3-22
Numeric Keypad Used for specifying a data string. 3-23
Rule Belongs To Set Selects which set a rule belongs to. 3-24
Actions
Send Data Sends all data that remains, sends all data up to a specific
character, or sends N characters.
3-25
Send Pause Inserts a pause. 3-29
Setup Field(s) Moves the cursor in relation to a specified character. 3-29
Send Preset Value Sends prefix and suffix values. 3-36
3-10
P 300 STD/FZY/PRO Scanner Product Reference Guide
Modify Data
!Remove All Spaces
!Crunch All Spaces
!Stop Space Removal
!Remove Leading Zeros
!Stop Zero Removal
!Pad Data With Spaces
!Pad Data With Zeros
Modifies data as follows:
!Removes all spaces in the send commands.
!Leaves one space between words.
!Stops space removal.
!Removes all leading zeros.
!Stops removal of zeros.
!Pads data to the left with spaces.
!Pads data to the left with zeros.
3-36
3-36
3-36
3-37
3-37
3-37
3-38
3-43
Beeps Selects beep sequence for each rule. 3-48
Send Keystroke
!Control Characters
!Keyboard Characters
!Send ALT Characters
!Send Command
Characters
!Send Special Characters
!Send Keypad Characters
!Send Function Keys
Specifies control and keyboard characters to send.
!Sends control characters.
!Sends keyboard characters.
!Sends ALT characters.
!Sends command characters.
!Sends special characters.
!Sends keypad characters.
!Sends function keys.
3-49
3-49
3-54
3-66
3-70
3-72
3-73
3-77
Turn On/Off Rule Sets Turns rule sets on and off. 3-83
Alphanumeric Keyboard Used to specify characters and strings when creating a rule. 3-84
Table 3-4. ADF Bar Codes
Bar Code Description Page
3-11
Advanced Data Formatting (ADF)
Special Commands
Bar codes and explanations of the following special commands are provided on the next few
pages.
!Begin New Rule
!Save Rule
!Erase
!Quit Entering Rules
!Disable Rule Set
Begin New Rule
Scan this bar code to start entering a new data formatting rule.
Save Rule
Scan this bar code to complete and save the rule you entered.
<FN3>7B1211
Begin New Rule
<FN3>4
Save Rule
3-12
P 300 STD/FZY/PRO Scanner Product Reference Guide
Erase
Use these bar codes to erase criteria, actions, or rules.
Quit Entering Rules
Scan this bar code to quit entering rules.
<FN3>6C-
Erase Criteria And
Start Again
<FN3>6A-
Erase Actions And
Start Again
<FN3>81
Erase Previously
Saved Rule
<FN3>80
Erase All Rules
<FN3>6Q
Quit Entering Rules
3-13
Advanced Data Formatting (ADF)
Disable Rule Set
Use these bar codes to disable rule sets.
<FN3>01
Disable Rule Set 1
<FN3>02
Disable Rule Set 2
<FN3>04
Disable Rule Set 4
<FN3>03
Disable Rule Set 3
<FN3>00
Disable All Rule Sets
3-14
P 300 STD/FZY/PRO Scanner Product Reference Guide
Criteria
Code Types
Select any number of code types to be affected. All selected codes must be scanned in
succession, prior to selecting other criteria. If you don't select a code type, all code types are
affected.
<FN3>6C13D01
Code 39
<FN3>6C13D02
Codabar
<FN3>6C13D03
Code 128
<FN3>6C13D06
I 2 Of 5
<FN3>6C13D04
D 2 Of 5
<FN3>6C13D07
Code 93
3-15
Advanced Data Formatting (ADF)
Code Types (continued)
<FN3>6C13D08
UPC-A
<FN3>6C13D09
UPC-E
<FN3>6C13D0A
EAN-8
<FN3>6C13D0B
EAN-13
<FN3>6C13D10
UPC-E1
<FN3>6C13D0F
EAN 128
3-16
P 300 STD/FZY/PRO Scanner Product Reference Guide
Code Types (continued)
<FN3>6C13D00
PDF417
<FN3>6C13D1A
ADF for Macro PDF417
(Applies rule to each block in MPDF set.)
<FN3>6C13D05
IATA 2 Of 5
<FN3>6C13D0E
MSI Plessey
<FN3>6C13D11
Bookland EAN
<FN3>6C13D12
Trioptic Code 39
3-17
Advanced Data Formatting (ADF)
Code Lengths
Define the number of characters the selected code type must contain. Select one length per
rule only. If you don't select a code length, selected code types of any length are affected.
Note: These codes are used to set the code length only; this is not a keypad.
<FN3>6C13701
1
<FN3>6C13702
2
<FN3>6C13704
4
<FN3>6C13703
3
<FN3>6C13705
5
<FN3>6C13706
6
3-18
P 300 STD/FZY/PRO Scanner Product Reference Guide
Code Lengths (continued)
<FN3>6C13709
9
<FN3>6C1370A
10
<FN3>6C1370C
12
<FN3>6C1370B
11
<FN3>6C13707
7
<FN3>6C13708
8
3-19
Advanced Data Formatting (ADF)
Code Lengths (continued)
<FN3>6C1370D
13
<FN3>6C1370F
15
<FN3>6C13710
16
<FN3>6C1370E
14
<FN3>6C13711
17
<FN3>6C13712
18
3-20
P 300 STD/FZY/PRO Scanner Product Reference Guide
Code Lengths (continued)
<FN3>6C13714
20
<FN3>6C13713
19
<FN3>6C13715
21
<FN3>6C13717
23
<FN3>6C13718
24
<FN3>6C13716
22
3-21
Advanced Data Formatting (ADF)
Code Lengths (continued)
<FN3>6C13719
25
<FN3>6C1371A
26
<FN3>6C1371C
28
<FN3>6C1371B
27
<FN3>6C1371D
29
<FN3>6C1371E
30
3-22
P 300 STD/FZY/PRO Scanner Product Reference Guide
Message Containing A Specific Data String
Select whether the formatting affects data that begins with a specific character or data string,
or contains a specific character or data string.
Specific String at Start
To apply formatting to data that begins with a specific character or data string:
1. Scan the bar code below.
2. Enter a string representing the desired character or characters (up to a total of 8)
using the Alphanumeric Keyboard beginning on page 3-84.
3. Scan End Of Message on page 3-93.
Specific String, Any Location
To apply formatting to data that contains a specific character or data string:
1. Scan the bar code below.
2. Scan a two-digit number representing the position (include a leading “zero” if
necessary) using the Numeric Keypad on page 3-23.
3. Enter the desired character or characters (up to a total of 8) using the Alphanumeric
Keyboard beginning on page 3-84.
4. Scan End Of Message on page 3-93.
Any Message OK
By not scanning any bar code, all selected code types are formatted, regardless of information
contained.
<FN3>6C201
Specific String At Start
<FN3>6C200
Specific String Any Location
3-23
Advanced Data Formatting (ADF)
Numeric Keypad
Bar codes on this page should not be confused with those on the alphanumeric keyboard.
<FN3>A0
0<FN3>A1
1
<FN3>A3
3
<FN3>A2
2
<FN3>A4
4<FN3>A5
5
<FN3>A7
7
<FN3>A9
9
<FN3>A6
6
<FN3>A8
8
<FN3>A-
Cancel
3-24
P 300 STD/FZY/PRO Scanner Product Reference Guide
Rule Belongs To Set
Scan a bar code below to select which set a rule belongs to.
<FN3>6C12A3
Rule Belongs To Set 3
<FN3>6C12A1
Rule Belongs To Set 1
<FN3>6C12A2
Rule Belongs To Set 2
<FN3>6C12A4
Rule Belongs To Set 4
3-25
Advanced Data Formatting (ADF)
Actions
Select how to format the data meeting the defined criteria before transmission.
Send Data
Use the following bar codes to send all data that remains, send all data up to a specific
character selected from the Alphanumeric Keyboard on page 3-84, or send the next N
characters. N = any number from 1 to 254, selected from the Alphanumeric Keyboard on
page 3-84.
<FN3>6A110
Send All Data
That Remains
<FN3>6A141001
Send Next Character
<FN3>6A141003
Send Next 3 Characters
<FN3>6A141002
Send Next 2 Characters
<FN3>6A5211
Send Data Up To
Character
3-26
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Data (continued)
<FN3>6A141007
Send Next 7 Characters
<FN3>6A141006
Send Next 6 Characters
<FN3>6A141008
Send Next 8 Characters
<FN3>6A141009
Send Next 9 Characters
<FN3>6A14100B
Send Next 11 Characters
<FN3>6A14100A
Send Next 10 Characters
<FN3>6A141004
Send Next 4 Characters
<FN3>6A141005
Send Next 5 Characters
3-27
Advanced Data Formatting (ADF)
Send Data (continued)
<FN3>6A14100C
Send Next 12 Characters
<FN3>6A14100D
Send Next 13 Characters
<FN3>6A14100F
Send Next 15 Characters
<FN3>6A14100E
Send Next 14 Characters
<FN3>6A141010
Send Next 16 Characters
<FN3>6A141011
Send Next 17 Characters
3-28
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Data (continued)
<FN3>6A141013
Send Next 19
Characters
<FN3>6A141012
Send Next 18
Characters
<FN3>6A141014
Send Next 20
Characters
<FN3>6A141032
Send Next 50
Characters
<FN3>6A141064
Send Next 100
Characters
<FN3>6A141096
Send Next 150
Characters
<FN3>6A1410C8
Send Next 200
Characters
<FN3>6A1410FA
Send Next 250
Characters
3-29
Advanced Data Formatting (ADF)
Send Pause
Send Pause
Setup Field(s)
Use the following bar codes to move the cursor in relation to a specified character.
Note: If there is no match when the rule is interpreted and the rule fails, the
next rule is checked.
Move Cursor To a Character
Scan the Move Cursor To Character bar code, then any printable ASCII character from the
Alphanumeric Keyboard on page 3-84. This moves the cursor to the position after the
matching character. If the character is not there, the rule fails and ADF tries the next rule.
Move Cursor to Start of Data
Scan this bar code to move cursor to the beginning of the data.
<FN3>6A5230
Move Cursor To
Character
<FN3>6A1231
Move Cursor To Start
3-30
P 300 STD/FZY/PRO Scanner Product Reference Guide
Move Cursor Past a Character
This parameter moves the cursor past all sequential occurrences of a selected character. Scan
the Move Cursor Past Character bar code on page 3-30, then select a character from the
Alphanumeric Keyboard on page 3-84. If the character is not there, the cursor does not move
(i.e., has no effect).
Skip Ahead “N” Characters
Scan one of these bar codes to select the number of positions ahead you wish to move the
cursor.
<FN3>6A5235
Move Cursor Past
Character
<FN3>6A143302
Skip Ahead 2
Characters
<FN3>6A143304
Skip Ahead 4
Characters
<FN3>6A143301
Skip Ahead 1
Character
<FN3>6A143303
Skip Ahead 3
Characters
3-31
Advanced Data Formatting (ADF)
Skip Ahead (continued)
<FN3>6A143305
Skip Ahead 5
Characters
<FN3>6A143306
Skip Ahead 6
Characters
<FN3>6A143308
Skip Ahead 8
Characters
<FN3>6A143307
Skip Ahead 7
Characters
<FN3>6A143309
Skip Ahead 9
Characters
<FN3>6A14330A
Skip Ahead 10
Characters
3-32
P 300 STD/FZY/PRO Scanner Product Reference Guide
Skip Ahead (continued)
<FN3>6A143332
Skip Ahead 50
Characters
<FN3>6A143396
Skip Ahead 150
Characters
<FN3>6A143364
Skip Ahead 100
Characters
<FN3>6A1433C8
Skip Ahead 200
Characters
<FN3>6A1433FA
Skip Ahead 250
Characters
3-33
Advanced Data Formatting (ADF)
Skip Back “N” Characters
Scan one of these bar codes to select the number of positions back you wish to move the
cursor.
<FN3>6A143401
Skip Back 1
Characters
<FN3>6A143403
Skip Back 3
Characters
<FN3>6A143402
Skip Back 2
Characters
<FN3>6A143404
Skip Back 4
Characters
3-34
P 300 STD/FZY/PRO Scanner Product Reference Guide
Skip Back (continued)
<FN3>6A143406
Skip Back 6
Characters
<FN3>6A143405
Skip Back 5
Characters
<FN3>6A143407
Skip Back 7
Character
<FN3>6A143408
Skip Back 8
Characters
<FN3>6A143409
Skip Back 9
Characters
<FN3>6A14340A
Skip Back 10
Characters
3-35
Advanced Data Formatting (ADF)
Skip Back (continued)
<FN3>6A143432
Skip Back 50
Characters
<FN3>6A143496
Skip Back 150
Characters
<FN3>6A143464
Skip Back 100
Characters
<FN3>6A1434C8
Skip Back 200
Characters
<FN3>6A1434FA
Skip Back 250
Characters
3-36
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Preset Value
Use these bar codes to send preset values.
Modify Data
Modify data in the ways listed. The following actions work for all send commands that
follow it within a rule. If you program pad zeros to length 6, send next 3 characters, stop
padding, send next 5 characters, three zeros are added to the first send, and the next send is
unaffected by the padding. These options do not apply to the Send Keystroke or Send Preset
Value options.
Remove All Spaces
To remove all spaces in the send commands that follow, scan this bar code.
Crunch All Spaces
To leave one space between words, scan this bar code. This also removes all leading and
trailing spaces.
<FN3>6A1272
Send Value 2
<FN3>6A1271
Send Value 1
<FN3>6A1260
Remove All Spaces
<FN3>6A1261
Crunch All Spaces
3-37
Advanced Data Formatting (ADF)
Stop Space Removal
Scan this bar code to disable space removal.
Remove Leading Zeros
Scan this bar code to remove all leading zeros.
Stop Zero Removal
Scan this bar code to disable the removal of zeros.
<FN3>6A1262
Stop Space Removal
<FN3>6A1264
Remove Leading
Zeros
<FN3>6A1265
Stop Zero Removal
3-38
P 300 STD/FZY/PRO Scanner Product Reference Guide
Pad Data With Spaces
To pad data to the left, scan the bar code containing the desired number of spaces. This
parameter is activated by Send commands.
<FN3>6A146301
Pad Spaces To
Length 1
<FN3>6A146302
Pad Spaces To
Length 2
<FN3>6A146304
Pad Spaces To
Length 4
<FN3>6A146303
Pad Spaces To
Length 3
<FN3>6A146305
Pad Spaces To
Length 5
<FN3>6A146306
Pad Spaces To
Length 6
3-39
Advanced Data Formatting (ADF)
Pad Data with Spaces (continued)
<FN3>6A146308
Pad Spaces To
Length 8
<FN3>6A146307
Pad Spaces To
Length 7
<FN3>6A146309
Pad Spaces To
Length 9
<FN3>6A14630A
Pad Spaces To
Length 10
<FN3>6A14630C
Pad Spaces To
Length 12
<FN3>6A14630B
Pad Spaces To
Length 11
3-40
P 300 STD/FZY/PRO Scanner Product Reference Guide
Pad Data with Spaces (continued)
<FN3>6A14630D
Pad Spaces To
Length 13
<FN3>6A14630E
Pad Spaces To
Length 14
<FN3>6A146310
Pad Spaces To
Length 16
<FN3>6A14630F
Pad Spaces To
Length 15
<FN3>6A146311
Pad Spaces To
Length 17
<FN3>6A146312
Pad Spaces To
Length 18
3-41
Advanced Data Formatting (ADF)
Pad Data with Spaces (continued)
<FN3>6A146314
Pad Spaces To
Length 20
<FN3>6A146313
Pad Spaces To
Length 19
<FN3>6A146315
Pad Spaces To
Length 21
<FN3>6A146316
Pad Spaces To
Length 22
<FN3>6A146318
Pad Spaces To
Length 24
<FN3>6A146317
Pad Spaces To
Length 23
3-42
P 300 STD/FZY/PRO Scanner Product Reference Guide
Pad Data with Spaces (continued)
<FN3>6A146319
Pad Spaces To
Length 25
<FN3>6A14631A
Pad Spaces To
Length 26
<FN3>6A14631C
Pad Spaces To
Length 28
<FN3>6A14631B
Pad Spaces To
Length 27
<FN3>6A14631D
Pad Spaces To
Length 29
<FN3>6A14631E
Pad Spaces To
Length 30
<FN3>6A146300
Stop Pad Spaces
3-43
Advanced Data Formatting (ADF)
Pad Data With Zeros
To pad data to the left, scan the bar code containing the desired number of zeros. This
parameter is activated by Send commands. Use these bar codes to pad data with zeros.
<FN3>6A146601
Pad Zeros To
Length 1
<FN3>6A146602
Pad Zeros To
Length 2
<FN3>6A146604
Pad Zeros To
Length 4
<FN3>6A146603
Pad Zeros To
Length 3
<FN3>6A146605
Pad Zeros To
Length 5
<FN3>6A146606
Pad Zeros To
Length 6
3-44
P 300 STD/FZY/PRO Scanner Product Reference Guide
Pad Data With Zeros (continued)
<FN3>6A146609
Pad Zeros To
Length 9
<FN3>6A14660A
Pad Zeros To
Length 10
<FN3>6A14660C
Pad Zeros To
Length 12
<FN3>6A14660B
Pad Zeros To
Length 11
<FN3>6A146608
Pad Zeros To
Length 8
<FN3>6A146607
Pad Zeros To
Length 7
3-45
Advanced Data Formatting (ADF)
Pad Data With Zeros (continued)
<FN3>6A14660D
Pad Zeros To
Length 13
<FN3>6A14660E
Pad Zeros To
Length 14
<FN3>6A14660F
Pad Zeros To
Length 15
<FN3>6A146610
Pad Zeros To
Length 16
<FN3>6A146611
Pad Zeros To
Length 17
<FN3>6A146612
Pad Zeros To
Length 18
3-46
P 300 STD/FZY/PRO Scanner Product Reference Guide
Pad Data With Zeros (continued)
<FN3>6A146613
Pad Zeros To
Length 19
<FN3>6A146614
Pad Zeros To
Length 20
<FN3>6A146615
Pad Zeros To
Length 21
<FN3>6A146617
Pad Zeros To
Length 23
<FN3>6A146616
Pad Zeros To
Length 22
<FN3>6A146618
Pad Zeros To
Length 24
3-47
Advanced Data Formatting (ADF)
Pad Data With Zeros (continued)
<FN3>6A146619
Pad Zeros To
Length 25
<FN3>6A14661B
Pad Zeros To
Length 27
<FN3>6A14661A
Pad Zeros To
Length 26
<FN3>6A14661C
Pad Zeros To
Length 28
<FN3>6A14661D
Pad Zeros To
Length 29
<FN3>6A146600
Stop Pad Zeros
<FN3>6A14661E
Pad Zeros To
Length 30
3-48
P 300 STD/FZY/PRO Scanner Product Reference Guide
Beeps
Select a beep sequence for each ADF rule.
<FN3>6A13A01
Beep Once
<FN3>6A13A02
Beep Twice
<FN3>6A13A03
Beep Three Times
3-49
Advanced Data Formatting (ADF)
Send Keystroke (Control Characters and Keyboard Characters)
Scan the “Send __” bar code for the keystroke you wish to send.
Control Characters
Scan these bar codes to send control characters.
<FN3>6A144100
Send Control 2
<FN3>6A144101
Send Control A
<FN3>6A144103
Send Control C
<FN3>6A144102
Send Control B
<FN3>6A144104
Send Control D
<FN3>6A144105
Send Control E
3-50
P 300 STD/FZY/PRO Scanner Product Reference Guide
Control Characters (continued)
<FN3>6A144108
Send Control H
<FN3>6A144109
Send Control I
<FN3>6A14410B
Send Control K
<FN3>6A14410A
Send Control J
<FN3>6A144107
Send Control G
<FN3>6A144106
Send Control F
3-51
Advanced Data Formatting (ADF)
Control Characters (continued)
<FN3>6A14410C
Send Control L
<FN3>6A14410D
Send Control M
<FN3>6A14410F
Send Control O
<FN3>6A14410E
Send Control N
<FN3>6A144110
Send Control P
<FN3>6A144111
Send Control Q
3-52
P 300 STD/FZY/PRO Scanner Product Reference Guide
Control Characters (continued)
<FN3>6A144113
Send Control S
<FN3>6A144112
Send Control R
<FN3>6A144114
Send Control T
<FN3>6A144115
Send Control U
<FN3>6A144117
Send Control W
<FN3>6A144116
Send Control V
<FN3>6A144118
Send Control X
3-53
Advanced Data Formatting (ADF)
Control Characters (continued)
<FN3>6A144119
Send Control Y
<FN3>6A14411B
Send Control [
<FN3>6A14411A
Send Control Z
<FN3>6A14411C
Send Control \
<FN3>6A14411D
Send Control ]
<FN3>6A14411F
Send Control -
<FN3>6A14411E
Send Control 6
3-54
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters
Use these bar codes to send keyboard characters.
<FN3>6A144120
Send Space
<FN3>6A144121
Send !
<FN3>6A144123
Send #
<FN3>6A144122
Send “
<FN3>6A144124
Send $
<FN3>6A144125
Send %
<FN3>6A144127
Send ‘
<FN3>6A144126
Send &
3-55
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144128
Send (
<FN3>6A144129
Send )
<FN3>6A14412B
Send +
<FN3>6A14412A
Send *
<FN3>6A14412C
Send ,
<FN3>6A14412D
Send -
<FN3>6A14412F
Send /
<FN3>6A14412E
Send .
3-56
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters (continued)
<FN3>6A144130
Send 0
<FN3>6A144131
Send 1
<FN3>6A144133
Send 3
<FN3>6A144132
Send 2
<FN3>6A144134
Send 4
<FN3>6A144135
Send 5
<FN3>6A144137
Send 7
<FN3>6A144136
Send 6
3-57
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144138
Send 8
<FN3>6A144139
Send 9
<FN3>6A14413B
Send ;
<FN3>6A14413A
Send :
<FN3>6A14413C
Send <
<FN3>6A14413D
Send =
<FN3>6A14413F
Send ?
<FN3>6A14413E
Send >
3-58
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters (continued)
<FN3>6A144140
Send @
<FN3>6A144141
Send A
<FN3>6A144143
Send C
<FN3>6A144142
Send B
<FN3>6A144144
Send D
<FN3>6A144145
Send E
<FN3>6A144147
Send G
<FN3>6A144146
Send F
3-59
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144148
Send H
<FN3>6A144149
Send I
<FN3>6A14414B
Send K
<FN3>6A14414A
Send J
<FN3>6A14414C
Send L
<FN3>6A14414D
Send M
<FN3>6A14414F
Send O
<FN3>6A14414E
Send N
3-60
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters (continued)
<FN3>6A144150
Send P
<FN3>6A144151
Send Q
<FN3>6A144153
Send S
<FN3>6A144152
Send R
<FN3>6A144154
Send T
<FN3>6A144155
Send U
<FN3>6A144157
Send W
<FN3>6A144156
Send V
3-61
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144158
Send X
<FN3>6A144159
Send Y
<FN3>6A14415B
Send [
<FN3>6A14415A
Send Z
<FN3>6A14415C
Send \
<FN3>6A14415D
Send ]
<FN3>6A14415F
Send _
<FN3>6A14415E
Send ^
3-62
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters (continued)
<FN3>6A144160
Send ‘
<FN3>6A144161
Send a
<FN3>6A144163
Send c
<FN3>6A144162
Send b
<FN3>6A144164
Send d
<FN3>6A144165
Send e
<FN3>6A144167
Send g
<FN3>6A144166
Send f
3-63
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144168
Send h
<FN3>6A144169
Send i
<FN3>6A14416B
Send k
<FN3>6A14416A
Send j
<FN3>6A14416C
Send l
<FN3>6A14416D
Send m
<FN3>6A14416F
Send o
<FN3>6A14416E
Send n
3-64
P 300 STD/FZY/PRO Scanner Product Reference Guide
Keyboard Characters (continued)
<FN3>6A144170
Send p
<FN3>6A144171
Send q
<FN3>6A144173
Send s
<FN3>6A144172
Send r
<FN3>6A144174
Send t
<FN3>6A144175
Send u
<FN3>6A144177
Send w
<FN3>6A144176
Send v
3-65
Advanced Data Formatting (ADF)
Keyboard Characters (continued)
<FN3>6A144178
Send x
<FN3>6A144179
Send y
<FN3>6A14417B
Send {
<FN3>6A14417A
Send z
<FN3>6A14417C
Send |
<FN3>6A14417D
Send }
<FN3>6A14417E
Send ~
3-66
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send ALT Characters
Use these bar codes to send ALT characters
<FN3>6A144240
Send ALT 2
<FN3>6A144241
Send ALT A
<FN3>6A144243
Send ALT C
<FN3>6A144242
Send ALT B
<FN3>6A144244
Send ALT D
<FN3>6A144245
Send ALT E
<FN3>6A144247
Send ALT G
<FN3>6A144246
Send ALT F
3-67
Advanced Data Formatting (ADF)
Send ALT Characters (continued)
<FN3>6A144248
Send ALT H
<FN3>6A144249
Send ALT I
<FN3>6A14424B
Send ALT K
<FN3>6A14424A
Send ALT J
<FN3>6A14424C
Send ALT L
<FN3>6A14424D
Send ALT M
<FN3>6A14424F
Send ALT O
<FN3>6A14424E
Send ALT N
3-68
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send ALT Characters (continued)
<FN3>6A144250
Send ALT P
<FN3>6A144251
Send ALT Q
<FN3>6A144253
Send ALT S
<FN3>6A144252
Send ALT R
<FN3>6A144254
Send ALT T
<FN3>6A144255
Send ALT U
S<FN3>6A144257
end ALT W
<FN3>6A144256
Send ALT V
3-69
Advanced Data Formatting (ADF)
Send ALT Characters (continued)
<FN3>6A144258
Send ALT X
<FN3>6A144259
Send ALT Y
<FN3>6A14425B
Send ALT [
<FN3>6A14425A
Send ALT Z
<FN3>6A14425C
Send ALT \
<FN3>6A14425D
Send ALT ]
<FN3>6A14425F
Send ALT -
<FN3>6A14425E
Send ALT 6
3-70
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Command Characters
<FN3>6A144301
Send PA 1
<FN3>6A144302
Send PA 2
<FN3>6A144304
Send CMD 2
<FN3>6A144303
Send CMD 1
<FN3>6A144305
Send CMD 3
<FN3>6A144306
Send CMD 4
3-71
Advanced Data Formatting (ADF)
Send Command Characters (continued)
<FN3>6A144309
Send CMD 7
<FN3>6A14430A
Send CMD 8
<FN3>6A14430C
Send CMD 10
<FN3>6A14430B
Send CMD 9
<FN3>6A144307
Send CMD 5
<FN3>6A144308
Send CMD 6
3-72
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Special Characters
<FN3>6A144311
Send Bullet Character
<FN3>6A144312
Send 1/2 Character
<FN3>6A144314
Send Section Character
<FN3>6A144313
Send Paragraph Character
<FN3>6A144315
Send Vertical Character
<FN3>6A14430F
Send Bomb Character
<FN3>6A144310
Send Hook Character
<FN3>6A14430D
Send Yen Character
<FN3>6A14430E
Send Pound Sterling Character
3-73
Advanced Data Formatting (ADF)
Send Keypad Characters
<FN3>6A14462A
Send Keypad *
<FN3>6A14462B
Send Keypad +
<FN3>6A14462E
Send Keypad .
<FN3>6A14462D
Send Keypad -
<FN3>6A14462F
Send Keypad /
<FN3>6A144630
Send Keypad 0
<FN3>6A144632
Send Keypad 2
<FN3>6A144631
Send Keypad 1
<FN3>6A144634
Send Keypad 4
<FN3>6A144633
Send Keypad 3
3-74
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Keypad Characters (continued)
<FN3>6A144635
Send Keypad 5
<FN3>6A144636
Send Keypad 6
<FN3>6A144638
Send Keypad 8
<FN3>6A144637
Send Keypad 7
<FN3>6A144639
Send Keypad 9
<FN3>6A14463A
Send Keypad ENTER
<FN3>6A14463B
Send Keypad
NUM LOCK
3-75
Advanced Data Formatting (ADF)
Send Keypad Characters (continued)
<FN3>6A144701
Send Break Key
<FN3>6A144702
Send Delete Key
<FN3>6A144704
Send End Key
<FN3>6A144703
Send Page Up Key
<FN3>6A144705
Send Page Down Key
<FN3>6A144706
Send Pause Key
<FN3>6A144708
Send Backspace Key
<FN3>6A144707
Send Scroll Lock Key
<FN3>6A14470A
Send Print Screen Key
<FN3>6A144709
Send Tab Key
3-76
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Keypad Characters (continued)
<FN3>6A14470B
Send Insert Key
<FN3>6A14470D
Send Enter Key
<FN3>6A14470F
Send Up Arrow Key
<FN3>6A144711
Send Left Arrow Key
<FN3>6A144713
Send Back Tab Character
<FN3>6A14470C
Send Home Key
<FN3>6A14470E
Send Escape Key
<FN3>6A144710
Send Down Arrow Key
<FN3>6A144712
Send Right Arrow Key
3-77
Advanced Data Formatting (ADF)
Send Function Keys
<FN3>6A144501
Send F1 Key
<FN3>6A144502
Send F2 Key
<FN3>6A144504
Send F4 Key
<FN3>6A144503
Send F3 Key
<FN3>6A144505
Send F5 Key
<FN3>6A144506
Send F6 Key
<FN3>6A144508
Send F8 Key
<FN3>6A144507
Send F7 Key
<FN3>6A14450A
Send F10 Key
<FN3>6A144509
Send F9 Key
3-78
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Function Keys (continued)
<FN3>6A14450B
Send F11 Key
<FN3>6A14450C
Send F12 Key
<FN3>6A14450E
Send F14 Key
<FN3>6A14450D
Send F13 Key
<FN3>6A14450F
Send F15 Key
<FN3>6A144510
Send F16 Key
<FN3>6A144512
Send F18 Key
<FN3>6A144511
Send F17 Key
<FN3>6A144514
Send F20 Key
<FN3>6A144513
Send F19 Key
3-79
Advanced Data Formatting (ADF)
Send Function Keys (continued)
<FN3>6A144515
Send F21 Key
<FN3>6A144516
Send F22 Key
<FN3>6A144518
Send F24 Key
<FN3>6A144517
Send F23 Key
<FN3>6A144519
Send F25 Key
<FN3>6A14451A
Send F26 Key
<FN3>6A14451C
Send F28 Key
<FN3>6A14451B
Send F27 Key
<FN3>6A14451E
Send F30 Key
<FN3>6A14451D
Send F29 Key
3-80
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Function Keys (continued)
<FN3>6A144401
Send PF1 Key
<FN3>6A144402
Send PF2 Key
<FN3>6A144404
Send PF4 Key
<FN3>6A144403
Send PF3 Key
<FN3>6A144405
Send PF5 Key
<FN3>6A144406
Send PF6 Key
<FN3>6A144408
Send PF8 Key
<FN3>6A144407
Send PF7 Key
<FN3>6A14440A
Send PF10 Key
<FN3>6A144409
Send PF9 Key
3-81
Advanced Data Formatting (ADF)
Send Function Keys (continued)
<FN3>6A14440B
Send PF11 Key
<FN3>6A14440C
Send PF12 Key
<FN3>6A14440E
Send PF14 Key
<FN3>6A14440D
Send PF13 Key
<FN3>6A14440F
Send PF15 Key
<FN3>6A144410
Send PF16 Key
<FN3>6A144412
Send PF18 Key
<FN3>6A144411
Send PF17 Key
<FN3>6A144414
Send PF20 Key
<FN3>6A144413
Send PF19 Key
3-82
P 300 STD/FZY/PRO Scanner Product Reference Guide
Send Function Keys (continued)
<FN3>6A144415
Send PF21 Key
<FN3>6A144416
Send PF22 Key
<FN3>6A144418
Send PF24 Key
<FN3>6A144417
Send PF23 Key
<FN3>6A144419
Send PF25 Key
<FN3>6A14441A
Send PF26 Key
<FN3>6A14441C
Send PF28 Key
<FN3>6A14441B
Send PF27 Key
<FN3>6A14441E
Send PF30 Key
<FN3>6A14441D
Send PF29 Key
3-83
Advanced Data Formatting (ADF)
Turn On/Off Rule Sets
Use these bar codes to turn rule sets on and off within a rule.
<FN3>6A13911
Tu r n O n R ul e S e t 1
<FN3>6A13921
Tu r n On Rul e Se t 2
<FN3>6A13941
Tu r n On Rul e Se t 4
<FN3>6A13931
Tu r n O n R ul e S e t 3
<FN3>6A13910
Tur n O f f Rul e Set 1
<FN3>6A13920
Tur n Off Rul e Set 2
<FN3>6A13940
Tu r n O ff Ru l e S e t 4
<FN3>6A13930
Tur n Off Rul e Set 3
3-84
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard
<FN3>B20
Space
<FN3>B23
#
<FN3>B25
%
<FN3>B24
$
<FN3>B2A
*
<FN3>B2B
+
<FN3>B2E
.
<FN3>B2D
-
3-85
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B22
“
<FN3>B26
&
<FN3>B28
(
<FN3>B27
‘
<FN3>B29
)
<FN3>B3A
:
<FN3>B21
!
<FN3>B2F
/
3-86
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
<FN3>B3C
<
<FN3>B3B
;
<FN3>B3E
>
<FN3>B3D
=
<FN3>B3F
?
<FN3>B40
@
3-87
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B5C
\
<FN3>B5B
[
<FN3>B5D
]
<FN3>B5E
^
<FN3>B60
`
<FN3>B5F
_
3-88
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
Bar codes on this page should not be confused with those on the numeric keypad.
<FN3>B30
0
<FN3>B31
1
<FN3>B33
3
<FN3>B32
2
<FN3>B34
4
<FN3>B35
5
3-89
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
Bar codes on this page should not be confused with those on the numeric keypad.
<FN3>B37
7
<FN3>B36
6
<FN3>B39
9
<FN3>B38
8
3-90
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
<FN3>B41
A
<FN3>B42
B
<FN3>B44
D
<FN3>B43
C
<FN3>B45
E
<FN3>B46
F
<FN3>B48
H
<FN3>B47
G
3-91
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B4B
K
<FN3>B4C
L
<FN3>B4E
N
<FN3>B4D
M
<FN3>B4A
J
<FN3>B49
I
<FN3>B4F
O
<FN3>B50
P
3-92
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
<FN3>B52
R
<FN3>B51
Q
<FN3>B54
T
<FN3>B53
S
<FN3>B55
U
<FN3>B56
V
3-93
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B59
Y
<FN3>B5A
Z
<FN3>B+
End Of Message
<FN3>B-
Cancel
<FN3>B58
X
<FN3>B57
W
3-94
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
<FN3>B61
a
<FN3>B62
b
<FN3>B64
d
<FN3>B63
c
<FN3>B65
e
<FN3>B66
f
<FN3>B68
h
<FN3>B67
g
3-95
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B6B
k
<FN3>B6C
l
<FN3>B6E
n
<FN3>B6D
m
<FN3>B6F
o
<FN3>B70
p
<FN3>B6A
j
<FN3>B69
i
3-96
P 300 STD/FZY/PRO Scanner Product Reference Guide
Alphanumeric Keyboard (continued)
<FN3>B72
r
<FN3>B71
q
<FN3>B74
t
<FN3>B73
s
<FN3>B75
u
<FN3>B76
v
<FN3>B78
x
<FN3>B77
w
3-97
Advanced Data Formatting (ADF)
Alphanumeric Keyboard (continued)
<FN3>B79
y
<FN3>B7A
z
<FN3>B7C
|
<FN3>B7B
{
<FN3>B7E
~
<FN3>B7D
}
3-98
P 300 STD/FZY/PRO Scanner Product Reference Guide
4-1
Chapter 4
Maintenance and Troubleshooting
Maintenance
Cleaning the scanner exit window is the only maintenance required.
!Do not allow any abrasive material to touch the window.
!Remove any dirt particles with a damp cloth.
!Wipe the window using a damp cloth, and if necessary, a non-ammonia based
detergent.
4-2
P 300STD/FZY/PRO Scanner Product Reference Guide
Troubleshooting
Note: If, after performing these checks, the problem is not corrected, contact
your distributor or call the Symbol Support Centers. See Service
Information on page x for contact information.
Table 4-1. Troubleshooting
Problem Possible Cause Possible Solutions
Nothing happens when
you follow the operating
instructions.
No power to the scanner.
Scanner is not programmed for
the correct host.
Scanner is not programmed for
the correct bar code type.
Interface/power cables are
loose.
Bar code symbol is unreadable.
Check the system power. Ensure the
power supply is connected if your
configuration requires a power supply.
Be sure the scanner is programmed for the
terminal in use.
Be sure the scanner is programmed to read
the type of bar code you are scanning.
Check for loose cable connections.
Check the symbol to make sure it is not
defaced. Try scanning test symbols of the
same bar code type.
Symbol is decoded, but
not transmitted to the
host terminal.
Scanner is not programmed for
the correct host type.
Be sure the proper host type is selected.
(See Chapter 2, Programming the
Scanner.)
Scanned data is
incorrectly displayed on
the terminal.
Scanner is programmed to
work with the wrong keyboard
type.
RS-232 host setup is wrong.
Scanner is programmed to
work with the wrong host
type.
Scanner is programmed with
the wrong editing options.
For a keyboard wedge configuration,
ensure the system is programmed for the
correct keyboard type, and the CAPS
LOCK key is off.
Ensure the scanner’s communication
paraneters match the host terminal’s
settings.
Be sure the proper host is selected.
Be sure editing options (e.g., UPC-E to
UPC-A Conversion) are properly
programmed.
A-1
Appendix A
Programming Reference
UCC/EAN-128
UCC/EAN-128 is a convention for printing data fields with standard Code 128 bar code
symbols. UCC/EAN-128 symbols are distinguished by a leading FNC 1 character as the first
or second character in the symbol. Other FNC 1 characters are used to delineate fields.
When EAN-128 symbols are read, they are transmitted after special formatting strips off the
leading FNC 1 character and replaces other FNC 1 characters with the ASCII 29 GS control
character.
When AIM symbology identifiers are transmitted, the modifier character indicates the
position of the leading FNC 1 character according to AIM guidelines. For example, ]c1
indicates a UCC/EAN-128 symbol with a leading FNC1 character.
Standard Code 128 bar codes which do not have a leading FNC 1 may still be used but are
not encoded according to the EAN-128 convention. Standard Code 128 and UCC/EAN-128
may be mixed in an application. The P 300FZY and P 300PRO scanner autodiscriminates
between these symbols, and can enable or disable one or both code types via bar code
menus. Table A-1 indicates the behavior of the P 300FZY and P 300PRO in each of the
possible parameter settings.
A-2
P 300STD/FZY/PRO Scanner Product Reference Guide
Table A-1. Reading Standard Code128 & UCC/EAN 128
Standard Code
128
UCC/EAN-
128
Effect and Example
Disable Disable No Code 128 symbols can be read.
Disable Enable Read only symbols with leading FNC 1.
Examples:
FNC1ABCDFNC1E are read as ABCD29E
AFNC1BCDFNC1E are read as ABCD29E
FNC1FNC1ABCDFNC1E are read as ABCD29E
ABCDFNC1E cannot be read
ABCDE cannot be read
Enable Disable Read only symbols without leading FNC 1.
Examples:
FNC1ABCDFNC1E cannot be read
AFNC1BCDFNC1E cannot be read
FNC1FNC1ABCDFNC1E cannot be read
ABCDFNC1E is read as ABCD29E
ABCDE is read as ABCDE
Enable Enable Read both types of symbols.
Examples:
FNC1ABCDFNC1E are read as ABCD29E
AFNC1BCDFNC1E are read as ABCD29E
FNC1FNC1ABCDFNC1E are read as ABCD29E
ABCDFNC1E is read as ABCD29E
ABCDE is read as ABCDE
A-3
Programming Reference
AIM Code Identifiers
Each AIM Code Identifier contains the three-character string ]cm where:
] = Flag Character (ASCII 93)
c = Code Character (see Table A-2)
m = Modifier Character (see Table A-3)
Table A-2. AIM Code Identifiers
Code Identifiers Code Type
ACode 39
CCode 128
EUPC/EAN
F Codabar
GCode 93
HCode 11
I Interleaved 2 of 5
L PDF417
MMSI Plessey
S D2 of 5, IATA 2 of 5
X Code 39 Trioptic
X Bookland EAN
X Coupon Code
A-4
P 300STD/FZY/PRO Scanner Product Reference Guide
The modifier character is the sum of the applicable option values based on Table A-3.
Table A-3. Modifier Characters
Code Type Option Value Option
Code 39 0 No check character or Full ASCII processing.
1 Reader has checked one check character.
3 Reader has checked and stripped check character.
4 Reader has performed Full ASCII character conversion.
5 Reader has performed Full ASCII character conversion
and checked one check character.
7 Reader has performed Full ASCII character conversion
and checked and stripped check character.
Example: A Full ASCII bar code with check character W, A+I+MI+DW, is
transmitted as ]A7AimId where 7 = (3+4).
Trioptic Code 39 0 No option specified at this time. Always transmit 0.
Example: A Trioptic bar code 412356 is transmitted as ]X0412356
Code 128 0 Standard data packet, no Function code 1 in first symbol
position.
1 Function code 1 in first symbol character position.
2 Function code 1 in second symbol character position.
Example: A Code (EAN) 128 bar code with Function 1 character in the first
position, FNC1 Aim Id is transmitted as ]C1AimId
I 2 of 5 0 No check digit processing.
1 Reader has validated check digit.
3 Reader has validated and stripped check digit.
Example: An I 2 of 5 bar code without check digit, 4123, is transmitted as
]I04123
Codabar 0 No check digit processing.
1 Reader has checked check digit.
3 Reader has stripped check digit before transmission.
Example: A Codabar bar code without check digit, 4123, is transmitted as
]F04123
A-5
Programming Reference
Code 93
0 No options specified at this time. Always transmit 0.
Example: A Code 93 bar code 012345678905 is transmitted as
]G0012345678905
MSI Plessey 0 Single check digit checked.
1 Two check digits checked.
2 Single check digit verified and stripped before
transmission.
3 Two check digits verified and stripped before
transmission.
Example: An MSI Plessey bar code 4123, with a single check digit checked,
is transmitted as ]M04123
D 2 of 5 0 No options specified at this time. Always transmit 0.
Example: A D 2 of 5 bar code 4123, is transmitted as ]S04123
UPC/EAN 0 Standard packet in full EAN country code format, which
is 13 digits for UPC-A and UPC-E (not including
supplemental data).
1 Two-digit supplement data only.
2 Five-digit supplement data only.
4 EAN-8 data packet.
Example: A UPC-A bar code 012345678905 is transmitted as
]E00012345678905
Bookland EAN 0 No options specified at this time. Always transmit 0.
Example: A Bookland EAN bar code 123456789X is transmitted as
]X0123456789X
Table A-3. Modifier Characters (Continued)
Code Type Option Value Option
A-6
P 300STD/FZY/PRO Scanner Product Reference Guide
Prefix / Suffix Values
The following values can be assigned as prefixes or suffixes for ASCII character data
transmission. If you’re using a keyboard interface, refer to the Synapse “Smart Cable”
Interface Guide for keystroke prefix/suffix values.
Table A-4. Prefix/Suffix Values
Prefix/Suf- Full ASCII Code ASCII
fix Value 39 Encode Char. Character
1000 %U NUL
1001 $A SOH
1002 $B STX
1003 $C ETX
1004 $D EOT
1005 $E ENQ
1006 $F ACK
1007 $G BELL
1008 $H BCKSPC
1009 $I HORIZ TAB
1010 $J LF/NW LN
1011 $K VT
1012 $L FF
1013 $M CR/ENTER
1014 $N SO
1015 $O SI
1016 $P DLE
1017 $Q DC1
1018 $R DC2
1019 $S DC3
1020 $T DC4
1021 $U NAK
1022 $V SYN
1023 $W ETB
1024 $X CAN
1025 $Y EM
1026 $Z SUB
1027 %A ESC
1028 %B FS
1029 %C GS
Prefix/Suf- Full ASCII Code ASCII
fix Value 39 Encode Char. Character
1030 %D RS
1031 %E US
1032 Space Space
1033 /A !
1034 /B "
1035 /C #
1036 /D $
1037 /E %
1038 /F &
1039 /G ‘
1040 /H (
1041 /I )
1042 /J *
1043 /K +
1044 /L ,
1045 - -
1046 . .
1047 / /
1048 0 0
1049 1 1
1050 2 2
1051 3 3
1052 4 4
1053 5 5
1054 6 6
1057 7 7
1056 8 8
1057 9 9
1058 /Z :
1059 %F ;
A-7
Programming Reference
Table A-3. Prefix/Suffix Values (continued)
Prefix/Suf- Full ASCII Code ASCII
fix Value 39 Encode Char. Character
1060 %G <
1061 %H =
1062 %I >
1063 %J ?
1064 %V @
1065 A A
1066 B B
1067 C C
1068 D D
1069 E E
1070 F F
1071 G G
1072 H H
1073 I I
1074 J J
1075 K K
1076 L L
1077 M M
1078 N N
1079 O O
1080 P P
1081 Q Q
1082 R R
1083 S S
1084 T T
1085 U U
1086 V V
1087 W W
1088 X X
1089 Y Y
1090 Z Z
1091 %K [
1092 %L \
1093 %M ]
1094 %N ^
Prefix/Suf- Full ASCII Code ASCII
fix Value 39 Encode Char. Character
1095 %O _
1096 %W `
1097 +A a
1098 +B b
1099 +C c
1100 +D d
1101 +E e
1102 +F f
1103 +G g
1104 +H h
1105 +I i
1106 +J j
1107 +K k
1108 +L l
1109 +M m
1110 +N n
1111 +O o
1112 +P p
1113 +Q q
1114 +R r
1115 +S s
1116 +T t
1117 +U u
1118 +V v
1119 +W w
1120 +X x
1121 +Y y
1122 +Z z
1123 %P {
1124 %Q |
1125 %R }
1126 %S ~
1127 Undefined
7013 ENTER
A-8
P 300STD/FZY/PRO Scanner Product Reference Guide
B-1
Appendix B
Keyboard Maps
The keyboard maps on the following pages are provided for prefix/suffix keystroke
parameters, and are used only with scanners that support data formatting. To program the
prefix/suffix values, see the bar codes on page 2-96.
Figure B-1. IBM PC/XT Keyboard
5001 5002
5003 5004
5005 5006
5007 5008
5009 5010
7009
7014 7008
7013
7012
7004
7011 7002
7003
7006
B-2
P 300STD/FZY/PRO Scanner Product Reference Guide
Figure B-2. IBM PC/AT Keyboard
Figure B-3. IBM PS2 Keyboard
5001 5002
5003 5004
5005 5006
5007 5008
5009 5010
7009
7008
7013
7012
7004
7011
7003
7002
7014
7019
7009
7013
7017
7004
7016
7002
7008
7014
7018
7015
7005
7011 7012 7003 6042
6047
6058
6045
5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 5011 5012 7006
7001
7010
3023
Normal
CNTRL
6043
7013
B-3
Keyboard Maps
Figure B-4. NCR 7052 32-Key Keyboard
Figure B-5. NCR 7052 58-Key Keyboard
5007 5008
5010
5002
5003 5004
5005 5006
1046
1045
5014
1043
5013
5015
5016
5018
5019
5001
5017
7013
5011
(7013 if double key)
(1048 if double key)
1048 5012
5009
5007 5008
5010
5002
5003 5004
5005 5006
1046
1045
5014
1043
5013
5015
5016
5018
5019
1086
1087
1088
1089
1090
5001
1066
1072 1073
1079 1080
1065 1070
1076 1077
1083 1084
1071
1078
1085
1069
5017
7013
5011
1082
1075
1068
1067
(1043 if double key)
(1048 if double key)
1048 5012
5009
1074
1081
B-4
P 300STD/FZY/PRO Scanner Product Reference Guide
C-1
Appendix C
ASCII Character Set
Table C-1. ASCII Character Set
ASCII Value Full ASCII
Code 39
Encode Char.
Keystroke
1000 %U CTRL 2
1001 $A CTRL A
1002 $B CTRL B
1003 $C CTRL C
1004 $D CTRL D
1005 $E CTRL E
1006 $F CTRL F
1007 $G CTRL G
1008 $H CTRL H
1009 $I CTRL I
1010 $J CTRL J
1011 $K CTRL K
1012 $L CTRL L
1013 $M CTRL M
C-2
P 300STD/FZY/PRO Scanner Product Reference Guide
1014 $N CTRL N
1015 $O CTRL O
1016 $P CTRL P
1017 $Q CTRL Q
1018 $R CTRL R
1019 $S CTRL S
1020 $T CTRL T
1021 $U CTRL U
1022 $V CTRL V
1023 $W CTRL W
1024 $X CTRL X
1025 $Y CTRL Y
1026 $Z CTRL Z
1027 %A CTRL [
1028 %B CTRL \
1029 %C CTRL ]
1030 %D CTRL 6
1031 %E CTRL -
1032 Space Space
1033 /A !
1034 /B ‘
1035 /C #
1036 /D E
1037 /E %
1038 /F &
1039 /G ‘
1040 /H (
Table C-1. ASCII Character Set (Continued)
C-3
ASCII Character Set
1041 /I )
1042 /J *
1043 /K +
1044 /L ,
1045 - -
1046 . .
1047 / /
1048 0 0
1047 1 1
1050 2 2
1051 3 3
1052 4 4
1053 5 5
1054 6 6
1055 7 7
1056 8 8
1057 9 9
1058 /Z :
1059 %F ;
1060 %G <
1061 %H =
1062 %I >
1063 %J ?
1064 %V @
1065 A A
1066 B B
1067 C C
Table C-1. ASCII Character Set (Continued)
C-4
P 300STD/FZY/PRO Scanner Product Reference Guide
1068 D D
1069 E E
1070 F F
1071 G G
1072 H H
1073 I I
1074 J J
1075 K K
1076 L L
1077 M M
1078 N N
1079 O O
1080 P P
1081 Q Q
1082 R R
1083 S S
1084 T T
1085 U U
1086 V V
1087 W W
1088 X X
1089 Y Y
1090 Z Z
1091 %K [
1092 %L \
1093 %M ]
1094 %N ^
Table C-1. ASCII Character Set (Continued)
C-5
ASCII Character Set
1095 %O _
1096 %W ‘
1097 +A a
1098 +B b
1099 +C c
1100 +D d
1101 +E e
1102 +F f
1103 +G g
1104 +H h
1105 +I i
1106 +J j
1107 +K k
1108 +L l
1109 +M m
1110 +N n
1111 +O o
1112 +P p
1113 +Q q
1114 +R r
1115 +S s
1116 +T t
1117 +U u
1118 +V v
1119 +W w
1120 +X x
1121 +Y y
Table C-1. ASCII Character Set (Continued)
C-6
P 300STD/FZY/PRO Scanner Product Reference Guide
1122 +Z z
1123 %P {
1124 %Q |
1125 %R }
1126 %S ~
1127 Undefined
1128
ALT Keys Keystroke
2064 ALT 2
2065 ALT A
2066 ALT B
2067 ALT C
2068 ALT D
2069 ALT E
2070 ALT F
2071 ALT G
2072 ALT H
2073 ALT I
2074 ALT J
2075 ALT K
2076 ALT L
2077 ALT M
2078 ALT N
2079 ALT O
2080 ALT P
2081 ALT Q
2082 ALT R
Table C-1. ASCII Character Set (Continued)
C-7
ASCII Character Set
2083 ALT S
2084 ALT T
2085 ALT U
2086 ALT V
2087 ALT W
2088 ALT X
2089 ALT Y
2090 ALT Z
2091 ALT [
2092 ALT \
2093 ALT ]
2094 ALT 6
2095 ALT -
Misc. Key Keystroke
3001 PA 1
3002 PA 2
3003 CMD 1
3004 CMD 2
3005 CMD 3
3006 CMD 4
3007 CMD 5
3008 CMD 6
3009 CMD 7
3010 CMD 8
3011 CMD 9
3012 CMD 10
3013 ¥
Table C-1. ASCII Character Set (Continued)
C-8
P 300STD/FZY/PRO Scanner Product Reference Guide
3014 £
3015 ¤
3016 ¬
3017 °
3018 1/2
3019 ¶
3020 §
3021 |
3022 0/00
PF Keys Keystrokes
4001 PF 1
4002 PF 2
4003 PF 3
4004 PF 4
4005 PF 5
4006 PF 6
4007 PF 7
4008 PF 8
4009 PF 9
4010 PF 10
4011 PF 11
4012 PF 12
4013 PF 13
4014 PF 14
4015 PF 15
4016 PF 16
4017 PF 17
Table C-1. ASCII Character Set (Continued)
C-9
ASCII Character Set
4018 PF 18
4019 PF 19
4020 PF 20
4021 PF 21
4022 PF 22
4023 PF 23
4024 PF 24
F Keys Keystroke
5001 F1
5002 F2
5003 F3
5004 F4
5005 F5
5006 F6
5007 F7
5008 F8
5009 F9
5010 F10
5011 F11
5012 F12
5013 F13
5014 F14
5015 F15
5016 F16
5017 F17
5018 F18
5019 F19
Table C-1. ASCII Character Set (Continued)
C-10
P 300STD/FZY/PRO Scanner Product Reference Guide
5020 F20
5021 F21
5022 F22
5023 F23
5024 F24
5025 F25
5026 F26
5027 F27
5028 F28
5029 F29
5030 F30
5031 F31
5032 F32
5033 F33
5034 F34
5035 F35
5036 F36
5037 F37
5038 F38
5039 F39
5040 F40
Numeric
Keypad
Keystroke
6042 *
6043 +
6044 undefined
6045 -
Table C-1. ASCII Character Set (Continued)
C-11
ASCII Character Set
6046 .
6047 /
6048 0
6049 1
6050 2
6051 3
6052 4
6053 5
6054 6
6055 7
6056 8
6057 9
6058 Enter
6059 Num Lock
6060 00
Extended
Keypad
Keystroke
7001 Break
7002 Delete
7003 Pg Up
7004 End
7005 Pg Dn
7006 Pause
7007 Scroll Lock
7008 Backspace
7009 Tab
7010 Print Screen
7011 Insert
Table C-1. ASCII Character Set (Continued)
C-12
P 300STD/FZY/PRO Scanner Product Reference Guide
7012 Home
7013 Enter
7014 Escape
7015 Up Arrow
7016 Dn Arrow
7017 Left Arrow
7018 Right Arrow
7019 Back Tab
Table C-1. ASCII Character Set (Continued)
D-1
Appendix D
Technical Specifications
Table D-1. Technical Specifications
Item Description
Power Requirements*
PC Wedge/Synapse
RS-232C/Synapse
Low Power
4.5 to 5.5 VDC (max) 200 mA @ 5V typical
4.5 to 5.5 VDC (max) 190 mA @ 5V typical
4.5 to 5.5 VDC (max) 400 mA @ 5V typical
Decode Capability The P 300FZY and P 300PRO can be programmed to
decode the following code types: UPC/EAN, Bookland
EAN, Code 39, Code 39 Full ASCII, Trioptic Code 39,
Code 93, Codabar, Interleaved 2 of 5, Code 128, EAN
128, Discrete 2 of 5, MSI Plessey, and PDF417. Set code
length(s) for any linear code type. The P 300FZY and 300PRO
can auto-discriminate between all of the above code types
except for Code 39 and Code 39 Full ASCII. Transmission of
decoded information depends on the capabilities of the
attached terminal.
Beeper Operation User-selectable: Enabled, Disabled
Scan Repetition Rate 36 scans/sec
Scan Angle ±37°
Roll (Skew) Tolerance ±45° from normal
Pitch ±60° from normal
Yaw ±30° from normal
1-D Decode Depth of Field See P 300STD Decode Zone on page D-3
D-2
P 300STD/FZY/PRO Scanner Product Reference Guide
2-D Decode Depth of Field See P 300FZY Decode Zone on page D-4
Print Contrast Minimum MRD 25% absolute dark/light differential, measured at 650
nm.
*For direct host power connection, make sure the host terminal supplies sufficient power for the
specified operation. Symbol is not responsible for damage to host equipment or system mis-
operation due to an insufficient power condition.
Ambient Light Immunity
Artificial Lighting
Sunlight
450 ft. candles 4844 lux
9000 ft. candles 96876 lux
(@8 in. (20 cm) on low density bar codes)
Operating Temperature -30° to 50°C (STD/FZY -20° to 50°C (PRO)
Storage Temperature -40° to 140°F -40° to 60°C
Humidity 5% to95% (non-condensing)
Durability 6-ft. drop to concrete 1.8 m
Dimensions
Height
Length
Width
7.0 in. 17.80 cm
9.2in. 13.50 cm
3.5 in. 9.80 cm
Laser Classifications CDRH Class II
IEC 825 Class 2
Laser Power 0.81 mW ±0.07mW
Table D-1. Technical Specifications (Continued)
Item Description
D-3
Technical Specifications
P 300STD Decode Zone
Figure D-1. P 300STD Decode Zone
2.0"
4.0" 7.0"
11.0"
22.0"
30.0"
60.0"
80.0"
Distance from Front of Scanner
2.0"
3.0"
5.0"
7.5 Mil
Width of Field
3.0"
80% MRD
31% MRD
10
25.4 20
50.8 30
76.2 40
101.6 50
127 60
152.4 70
177.8 80
203.2
0
0in.
cm
3.5"
28.0"
26 in
66.0 cm
26 in
66.0 cm
13 in
33.0 cm
13 in
33.0 cm
0 in
0.0 cm
D-4
P 300STD/FZY/PRO Scanner Product Reference Guide
P 300FZY Decode Zone
Figure D-2. P 300FZY Decode Zone
Note: The measurements above are for 6.6 mil, 100 character PDF bar code
and 15 mil, 64 character PDF bar code.
1.5"
4.0" 7.0"
12.0"
23.0"
34.0"
65.0"
84.0"
Distance from Front of Scanner
1.5"
3.0"
5.0"
7.5 Mil
Width of Field
2.0"
80% MRD
31% MRD
10
25.4 20
50.8 30
76.2 40
101.6 50
127 60
152.4 70
177.8 80
203.2
0
0in.
cm
3.0"
30.0"
90
228.6
27 in
68.6 cm
13 in
34.3 cm
0 in
0.0 cm
13 in
34.3 cm
27 in
68.6 cm
D-5
Technical Specifications
P 300PRO 1-D Decode Zone
Figure D-3. P 300PRO 1-D Decode Zone
In.
cm 0
UPC 15.0
20 mil 20.5
0
In. cm
W
i
d
t
h
o
f
F
i
e
l
d
Depth of Field
2.0
0
Note: Typical performance at 68˚F (20˚C)
on high quality symbols.
1.5
3
6
9
3
6
9
7.6
15.2
22.8
7.6
15.2
22.8
3 6 9 121518 2124
0 7.6 15.2 22.8 30.4 38.1 45.7 53.3
Top of
scanner
32.0
4.0 55 mil
7.5 mil 7.0
1.0
6 mil 5.0
1.25
27 30 33
60.9 68.5 76.2 83.8
12
15
12
15
38.1
30.4
30.4
38.1
D-6
P 300STD/FZY/PRO Scanner Product Reference Guide
P 300PRO 2-D Decode Zone
Figure D-4. P 300PRO 2-D Decode Zone
In.
cm 0
6.6 mil 6.0
10 mil 9.5
0
In. cm W
i
d
t
h
o
f
F
i
e
l
d
Depth of Field
3.0
0
Note: Typical performance at 68˚F (20˚C)
on high quality symbols.
1.25
2
4
6
2
4
6
5.0
10.1
15.2
5.0
10.1
15.2
2 4 6 8 10 12 14 16
0 5.0 10.1 15.2 20.3 25.4 30.5 35.6 40.6
Top of
scanner
15.0
5.0 15 mil
D-7
Technical Specifications
Pin-outs
Table D-2. Pin-outs
Pin P 300
1Reserved
2Power
3 Ground
4 Synapse Data
5 Synapse Clock
6RxD
7TxD
8DTR
9CTS
10 RTS
D-8
P 300STD/FZY/PRO Scanner Product Reference Guide
Glossary-1
Glossary
APERTURE The opening in an optical system defined by a lens or baffle
that establishes the field of view.
ASCII American Standard Code for Information Interchange. A 7
bit-plus-parity code representing 128 letters, numerals,
punctuation marks, and control characters. It is a standard
data transmission code in the U.S.
ASYMMETRIC WIDTH
GROWTH
Non-uniform growth of elements in a printed symbol.
AUTODISCRIMINATION The ability of an interface controller to determine the code
type of a scanned bar code. After this determination is made,
the information content can be decoded.
AVERAGE BAR WIDTH
GROWTH
Average deviation of bars from nominal widths over the
entire symbol.
BAD CHECK DIGIT Error message resulting from failure of the check digit to
calculate properly.
BAD DATA CHARACTER Error message caused by failure of one or more data
characters to decode properly.
BAD PRINT CONTRAST Error message due to lack of contrast between the
background and the bars of the symbol.
BAR The dark element in a printed bar code symbol.
Glossary-2
P 300 STD/FZY/PRO Scanner Product Reference Guide
BAR CODE DENSITY The number of characters represented per unit of
measurement (e.g., characters per inch in one-dimensional
symbologies, characters per square inch in PDF417).
BAR HEIGHT The dimension of a bar measured perpendicular to the bar
width.
BAR WIDTH Thickness of a bar measured from the edge closest to the
symbol start character to the trailing edge of the same bar.
BAR WIDTH DEVIATION Increase or decrease in bar width as compared with nominal
bar width.
BAUD RATE A measure of the data flow or number of signaling events
occurring per second. When one bit is the standard "event,"
this is a measure of bits per second (bps). For example, a
baud rate of 50 means transmission of 50 bits of data per
second.
BIDIRECTIONAL READING
CAPABILITY
The ability to decode a symbol successfully by reading in
complementary (opposite) directions across bars and spaces.
BIT Binary digit. One bit is the basic unit of binary information.
Generally, eight consecutive bits compose one byte of data.
The pattern of 0 and 1 values within the byte determines its
"meaning."
BUFFER An area of memory allocated for data storage. In this
context, a buffer's data storage capacity is needed when data
can flow into the device more quickly than the device can
process that data. Buffering the data preserves it until it can
be processed.
BYTE On an addressable boundary, eight adjacent binary digits (0
and 1) combined in a pattern to represent a specific character
or numeric value. Bits are numbered from the right, 0
through 7, with bit 0 the low-order bit. One byte in memory
can be used to store one ASCII character.
CHARACTER A pattern of bars and spaces which either directly represents
data or indicates a control function, such as a number, letter,
punctuation mark, or communications control contained in
a message.
Glossary-3
Glossary
CHARACTER SET Those characters available for encodation in a particular bar
code symbology.
CHECK DIGIT A digit used to verify a correct symbol decode. The scanner
inserts the decoded data into an arithmetic formula and
checks that the resulting number matches the encoded check
digit. Check digits are required for UPC and Code 128 but
are optional for other symbologies. Using check digits
decreases the chance of substitution errors when a symbol is
decoded.
CLUSTER One of three subsets of mututally exclusive codeword
definitions within PDF417.
CODABAR A discrete self-checking code with a character set consisting
of start/stop characters (A B C D or * T N E), digits 0 to 9,
and these additional characters: ( - $ : / , +).
CODE Set of unambiguous rules specifying the way in which data
may be represented.
CODEWORD In PDF417, a single group of bars and spaces (4 bars and 4
spaces, for a total of 17 module widths) which represents one
or more numbers, letters, or other symbols.
CODEWORD PD
(CODEWORD PERCENT
DECODE)
Within a PDF417 symbol, the percentage of codewords
which decoded successfully; the number of good codewords
divided by the total number of codewords (data codewords
plus error correction codewords).
CODE LENGTH Number of data characters in a bar code between the start
and stop characters, not including those characters.
CODE 128 A high density symbology which allows the interface
controller to encode all 128 ASCII characters without adding
extra symbol elements.
CODE 3 OF 9 (CODE 39) A versatile and widely used alphanumeric bar code
symbology with a set of 43 character types, including all
uppercase letters, numerals from 0 to 9, and 7 special
characters (- . / + % $ and space). The code name is derived
from the fact that 3 of 9 elements representing a character are
wide, while the remaining 6 are narrow.
Glossary-4
P 300 STD/FZY/PRO Scanner Product Reference Guide
CONTINUOUS CODE A bar code or symbol in which all spaces within the symbol
are parts of characters. There are no intercharacter gaps in
a continuous code. The absence of gaps allows for greater
information density.
COUNTRY FLAG In EAN-8 and EAN-13 codes, two or three digits which
appear immediately following the left guard bar pattern.
DEAD ZONE An area within a scanner's field of view, in which specular
reflection may prevent a successful decode.
DECODE To recognize a bar code symbology (e.g., UPC/EAN) and
then analyze the content of the specific bar code scanned. To
translate the bar/space pattern into defined characters within
a defined symbology.
DECODE ALGORITHM A decoding scheme that converts pulse widths into data
representation of the letters or numbers encoded within a bar
code symbol.
DEPTH OF FIELD The range between minimum and maximum distances at
which a scanner can read a symbol with a certain minimum
element width.
DISCRETE CODE A bar code or symbol in which the spaces between characters
(intercharacter gaps) are not part of the code (e.g., Code 39).
DISCRETE 2 OF 5 A binary bar code symbology representing each character by
a group of five bars, two of which are wide. The location of
wide bars in the group determines which character is
encoded; spaces are insignificant. Only numeric characters
(0 to 9) and START/STOP characters may be encoded.
EAN European Article Number. This European/International
version of the UPC provides its own coding format and
symbology standards. Element dimensions are specified
metrically. EAN is used primarily in retail. Main variants are
EAN-8 and EAN-13.
EDGE ROUGHNESS Edge irregularities as compared with a nominal bar edge.
ELEMENT Generic term for a bar or space.
Glossary-5
Glossary
ENCODED AREA Total linear dimension occupied by all characters of a code
pattern, including start/stop characters and data.
ERROR CORRECTION In addition to error detection, the recovery capability of
PDF417 over missing, destroyed, or misdecoded codewords.
Error correction capability is based on the level of security (0
- 8) selected when the PDF417 label is printed.
EXTRANEOUS INK Ink in a scan area not intended to be there (i.e., tracking and
splatter).
FIRST READ RATE Percentage of correct readings obtainable by one pass of a
scanning device over a bar code.
FLASH Derived from EEPROM, this is a type of memory that holds
its content without power but must be erased in bulk — or
in a “flash.” Typically, these memory chips are less expensive
and provide higher bit densities.
GUARD BARS The start, stop, and center delimiting bars of UPC and EAN
symbols.
HOST COMPUTER A computer that serves other terminals in a network,
providing such services as computation, database access,
supervisory programs, and network control.
INTERCHARACTER GAP The space between two adjacent bar code characters in a
discrete code.
INTERLEAVED BAR CODE A bar code in which characters are paired together, using
bars to represents the first character and the intervening
spaces to represent the second.
INTERLEAVED 2 OF 5 A binary bar code symbology representing character pairs in
groups of five bars and five interleaved spaces. Interleaving
provides for greater information density. The location of
wide elements (bar/spaces) within each group determines
which characters are encoded. This continuous code type
uses no intercharacter spaces. Only numeric (0 to 9) and
START/STOP characters may be encoded.
Glossary-6
P 300 STD/FZY/PRO Scanner Product Reference Guide
LASER An acronym for Light Amplification by Stimulated Emission
of Radiation. The laser is an intense light source. Light from
a laser is all the same frequency, unlike the output of an
incandescent bulb. Laser light is typically coherent and has
a high energy density.
LASER SPOT SIZE The diameter of the spot of laser light scanning the bar code,
as measured at a given distance from the bar code. Smaller
spot sizes yield higher resolution but poorer depth of focus.
LED INDICATOR A semiconductor diode (LED - Light Emitting Diode) used as
an indicator, often in digital displays. The semiconductor
uses applied voltage to produce light of a certain frequency
determined by the semiconductor's particular chemical
composition.
MIL 1 mil = 1 thousandth of an inch.
MINIMUM REFLECTANCE
DIFFERENCE (MRD)
The difference in percentage between light reflected from
spaces (RS) and light reflected from bars (RB). MRD = %RS
- %RB.
MISREAD (Misdecode) A condition which occurs when the data output of a reader
or interface controller does not agree with the data encoded
within a bar code symbol.
MODULE The narrowest bar or space (unit of measure) in a code. The
term is used by the Uniform Code Council in its description
of UPC/EAN code; it is also used in the description of Code
128. Contiguous modules are used to form bars or spaces
which are wider than one unit.
MODULE ASPECT RATIO The ratio of height to width of the narrowest bar or space, or
unit of measure, in a bar code.
NANOMETRE A unit of measure used to define the wavelength of light.
Equal to 10-9 metre.
NOMINAL The exact (or ideal) intended value for a specified parameter.
Tolerances are specified as positive and negative deviations
from this value.
Glossary-7
Glossary
NOMINAL SIZE Standard size for a bar code symbol. Most UPC/EAN codes
can be used over a range of magnifications (e.g., from 0.80
to 2.00 of nominal).
NUMBER SYSTEM
CHARACTER
In the UPC/EAN code used in a retail application, the
mandatory, first encoded character, after the left guard bars.
The corresponding human readable character identifies the
coded character and appears at the bottom left-hand margin
of the symbol. The assigned system number corresponds to
a usage category for the bar coded item.
ONE-DIMENSIONAL
SYMBOLOGY
Symbologies which encode data only in a linear or horizontal
dimension (X-dimension); the symbol’s vertical height (Y-
dimension) is redundant (e.g., UPC/EAN, Code 39).
OPACITY The capacity for material to interfere with transmission of
light.
OVERHEAD The number of characters required for start, stop, and
checking for a given symbol (in PDF417, also left and right
row indicators and error correction codewords). For
example, a one-dimensional symbol requiring start/stop and
two check characters contains four characters of overhead.
Thus, to encode three data characters, seven characters are
required.
PARAMETER A variable that can have different values assigned to it.
PARITY TYPE A parity check bit is the most significant bit of each ASCII
coded character. The parity should be set to help detect
transmission errors. The parity should be set to match that
of the receiving device. If even parity is selected, the parity
bit has a value (0 or 1) to ensure that an even number of 1
bits are contained in the coded character. If odd parity is
selected, the parity bit will have a value (0 or 1) to ensure that
an odd number of 1 bits are contained in the coded character.
If 0 parity is selected, the parity bit always will be set to 0. If
1 parity is selected, the parity bit always will be set to 1.
Glossary-8
P 300 STD/FZY/PRO Scanner Product Reference Guide
PDF417 A two-dimensional, or stacked, bar code symbology which
can encode over one kilobyte of data per label and which
represents data in the form of codewords (values 0 - 928).
Each codeword consists of four bars and four spaces, for a
total of 17 module widths; modules vary in width from one
to six element widths. The symbology permits encoding up
to 30 data columns and from 3 to 90 data rows. For ease of
reading while still maintaining high data density, codewords
are encoded in three mutually-exclusive encodation sets, or
clusters, with the same cluster repeating sequentially each
third row.
PERCENT DECODE The average probability that a single scan of a bar code
would result in a successful decode. In a well-designed bar
code scanning system, that probability should approach near
100%.
PRINT CONTRAST SIGNAL
(PCS)
Measurement of the contrast (brightness difference) between
the bars and spaces of a symbol. A minimum PCS value is
needed for a bar code symbol to be scannable. PCS = (RL -
RD) / RL, where RL is the reflectance factor of the
background and RD the reflectance factor of the dark bars.
PROM Acronym for Programmable Read Only Memory. An
integrated circuit which can be programmed through special
processes and accessed at random during normal operation.
Reprogramming is possible, but only through processes such
as ultraviolet light erasing and electrical rewriting of data.
PROTOCOL For a specific signaling type, a set of recognized rules
governing the format and timing of message exchange.
Between data communications devices, this includes an
exchange of predetermined signals arranged for both
establishing connection and for disconnecting.
QUIET ZONE A clear space, containing no dark marks, which precedes the
start character of a bar code symbol and follows the stop
character.
REFLECTANCE Amount of light returned from an illuminated surface.
Glossary-9
Glossary
RESOLUTION The narrowest element dimension which can be
distinguished by a particular reading device or printed with
a particular device or method.
ROW INDICATORS To help synchronize a PDF417 symbol’s structure,
codewords which collectively indicate which row a
particular one is, which is the left and right side of that row,
how many rows are in the symbol, what security level is
encoded in the symbol, and how many data columns are in
the rows. Left Row Indicators occur in each row immediately
after the Start pattern; Right Row Indicators occur in each
row immediately before the Stop pattern.
SCAN Search for a symbol to be optically recognized.
SCAN AREA Area intended to contain a symbol.
SCANNER An electronic device used to scan bar code symbols and
produce a digitized pattern that corresponds to the bars and
spaces of the symbol. Its three main components are:
1. Light source (laser or photoelectric cell) - illuminates a bar
code.
2. Photodetector - registers the difference in reflected light
(more light reflected from spaces).
3. Signal conditioning circuit - transforms optical detector
output into a digitized bar pattern.
SELF-CHECKING CODE A symbology that uses a checking algorithm to detect
encoding errors within the characters of a bar code symbol.
SHOW-THROUGH The generally undesirable property of a substrate that
permits underlying markings to be seen.
SPACE The lighter element of a bar code formed by the background
between bars.
SPECULAR REFLECTION The mirror-like reflection of light from a surface, which can
“blind” a scanner.
SPOT SIZE Size of the scanning aperture.
SPOTS The presence of ink in a bar code's spaces or clear areas.
These generally reduce the percent decode.
Glossary-10
P 300 STD/FZY/PRO Scanner Product Reference Guide
START/STOP CHARACTER A pattern of bars and spaces that provides the scanner with
start and stop reading instructions and scanning direction.
The start and stop characters are the first and last encoded
characters of a bar code.
SUBSTRATE A foundation material on which a substance or image is
placed.
SUBSTRATE SCATTERING Optical phenomenon which causes bars to appear larger and
spaces narrower than they are actually printed. It is caused
by the scattering of incident light rays within the medium.
SYMBOL A scannable unit that encodes data within the conventions of
a certain symbology, usually including start/stop characters,
quiet zones, data characters, and check characters.
SYMBOL ASPECT RATIO The ratio of symbol height to symbol width.
SYMBOL HEIGHT The distance between the outside edges of the quiet zones of
the first row and the last row.
SYMBOL LENGTH Length of symbol measured from the beginning of the quiet
zone (margin) adjacent to the start character to the end of
the quiet zone (margin) adjacent to a stop character.
SYMBOLOGY The structural rules and conventions for representing data
within a particular bar code type (e.g. UPC/EAN, Code 39).
SYMMETRIC BAR WIDTH
GROWTH
Uniform growth of bars evenly distributed.
TOLERANCE Allowable deviation from the nominal bar or space width.
TWO-DIMENSIONAL
SYMBOLOGY
Designed for high information density and higher encoding
capability than one-dimensional bar codes, a symbology
which encodes data in both the horizontal (X-dimension)
and vertical dimensions, usually in a “stacked” or multi-row
arrangement.
UPC Universal Product Code. A relatively complex numeric
symbology. Each character consists of two bars and two
spaces, each of which can be any of four widths. The
standard symbology for retail food packages in the United
States.
Glossary-11
Glossary
VISIBLE LASER DIODE (VLD) A solid state device which produces visible laser light. Laser
light emitted from the diode has a wavelength of 670 to 680
nanometers.
VOID Absence of ink within printed bars.
X-DIMENSION Width of the narrowest element (bar of space) in a bar code
symbol.
Y-DIMENSION Element height, as applied to a two-dimensional symbology,
which must equal or exceed a required minimum.
ZERO-SUPPRESSED CODE A version of UPC/EAN which reduces the number of
characters in the code. The resulting code combines the
manufacturer's code and the product's code of Version A in
a retail application.
Glossary-12
P 300 STD/FZY/PRO Scanner Product Reference Guide
Index-1
Index
Numerics
1D bar code
scanning . . . . . . . . . . . . . . . . . . . . . . . 1-10
1-D bar codes . . . . . . . . . . . . . . . . . . . . . . . 1-8
A
Abort MacroPDF Entry . . . . . . . . . . . . . . . . 2-8
AC Line Cord . . . . . . . . . . . . . . . . . . . . . . . 1-2
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Cables . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
AC Line Cord . . . . . . . . . . . . . . . . 1-2
DC Power Adapter . . . . . . . . . . . . 1-2
Keyboard Wedge Cable . . . . . . . . . 1-2
Power Supply . . . . . . . . . . . . . . . . 1-2
RS-232 Cable . . . . . . . . . . . . . . . . 1-2
Synapse Cable . . . . . . . . . . . . . . . . 1-2
Undecoded Cable . . . . . . . . . . . . . 1-2
Wand Emulation Cable . . . . . . . . . 1-2
Optional . . . . . . . . . . . . . . . . . . . . . . . . 1-2
User Documentation . . . . . . . . . . . . . . . 1-2
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
ADF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
actions . . . . . . . . . . . . . . . . . . . . 3-1, 3-25
alphanumeric keyboard . . . . . . . . . . . 3-84
alternate rule sets . . . . . . . . . . . . . . . . . 3-5
bar code menu example . . . . . . . . . . . . 3-3
beeper definitions . . . . . . . . . . . . . . . . . 3-8
code length . . . . . . . . . . . . . . . . . . . . . 3-17
code types . . . . . . . . . . . . . . . . . . . . . 3-14
criteria . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
default rules . . . . . . . . . . . . . . . . . . . . . 3-7
numeric keypad . . . . . . . . . . . . . . . . . 3-23
rule belongs to set . . . . . . . . . . . . . . . 3-24
rules . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
rules heirarchy . . . . . . . . . . . . . . . . . . . 3-6
send ALT characters . . . . . . . . . . . . . 3-66
send command characters . . . . . . . . . 3-70
send control characters . . . . . . . . . . . 3-49
send function keys . . . . . . . . . . . . . . . 3-77
send keypad characters . . . . . . . . . . . 3-73
send special characters . . . . . . . . . . . . 3-72
advanced data formatting . . . . . . . . . . . . . . 3-1
actions . . . . . . . . . . . . . . . . . . . . . 3-1, 3-25
alphanumeric keyboard . . . . . . . . . . . 3-84
alternate rule sets . . . . . . . . . . . . . . . . . 3-5
bar code menu example . . . . . . . . . . . . 3-3
beeper definitions . . . . . . . . . . . . . . . . 3-8
code length . . . . . . . . . . . . . . . . . . . . 3-17
code types . . . . . . . . . . . . . . . . . . . . . 3-14
criteria . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
default rules . . . . . . . . . . . . . . . . . . . . . 3-7
numeric keypad . . . . . . . . . . . . . . . . . 3-23
rule belongs to set . . . . . . . . . . . . . . . 3-24
rules . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
rules heirarchy . . . . . . . . . . . . . . . . . . . 3-6
send control characters . . . . . . . . . . . 3-49
aiming . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
hold at an angle . . . . . . . . . . . . . . . . . 1-11
scan the entire symbol . . . . . . . . . . . . 1-11
aiming dot . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Aiming Mode . . . . . . . . . . . . . . . . . . . . . . . 2-6
aiming modes . . . . . . . . . . . . . . . . . . 1-10, 2-92
aiming dot . . . . . . . . . . . . . . . . . . . . . 1-10
slab raster . . . . . . . . . . . . . . . . . . . . . 1-10
always raster mode . . . . . . . . . . . . . . . . . . . 1-9
ASCII Character Set . . . . . . . . . . . . . . . . . . C-1
Index-2
P 300STD/FZY/PRO Scanner Product Reference Guide
ASCII Format . . . . . . . . . . . . . . . . . . 2-7, 2-108
Autodiscriminate Response Tim . . . . . . . . 2-24
Autodiscriminate Response Time . . . . . . . . 2-2
B
bar codes
Beep After Good Decode . . . . . . . . . . 2-18
beep after good decode . . . . . . . . . . . 2-18
beeper tone . . . . . . . . . . . . . . . . . . . . 2-13
bi-directional redundancy . . . . . . . . . 2-23
codabar . . . . . . . . . . . . . . . . . . . 2-74–2-76
CLSI editing . . . . . . . . . . . . . . . . 2-77
lengths . . . . . . . . . . . . . . . . . . . . 2-75
NOTIS editing . . . . . . . . . . . . . . 2-78
code 128
UCC/EAN-128 . . . . . . . . . . . . . . 2-47
code 39 . . . . . . . . . . . . . . . . . . . 2-50–2-58
buffering . . . . . . . . . . . . . . . . . . 2-57
check digit verification . . . . . . . . 2-54
full ASCII . . . . . . . . . . . . . . . . . . 2-56
lengths . . . . . . . . . . . . . . . . . . . . 2-52
transmit check digit . . . . . . . . . . 2-55
code 93 . . . . . . . . . . . . . . . . . . . . . . . 2-62
lengths . . . . . . . . . . . . . . . . . . . . 2-63
data options . . . . . . . . . . . . . . . . . . . 2-93
pause duration . . . . . . . . . . . . . . 2-95
prefix/suffix values . . . . . . . . . . . 2-96
scan data xmission format . . . . . 2-97
transmit code ID character . . . . . 2-93
discrete 2 of 5 . . . . . . . . . . . . . . . . . . 2-71
lengths . . . . . . . . . . . . . . . . . . . . 2-72
host types . . . . . . . . . . . . . . . . . . . . . 2-10
interleaved 2 of 5 . . . . . . . . . . . . 2-65–2-70
check digit verification . . . . . . . . 2-68
convert to EAN-13 . . . . . . . . . . . 2-70
lengths . . . . . . . . . . . . . . . . . . . . 2-66
transmit check digit . . . . . . . . . . 2-69
laser on time . . . . . . . . . . . . . . . . . . . 2-15
linear code type security level . . . . . . 2-21
MSI Plessey . . . . . . . . . . . . . . . . . . . . 2-79
MSI plessey
check digits . . . . . . . . . . . . . . . . 2-82
lengths . . . . . . . . . . . . . . . . . . . . 2-80
transmit check digit . . . . . . . . . . . 2-83
NOTIS Editing . . . . . . . . . . . . . . . . . . 2-78
numeric bar codes . . . . . . . . . . . . . . . 2-120
PDF417
enable . . . . . . . . . . . . . . . . . . . . . 2-85
power mode . . . . . . . . . . . . . . . . . . . . 2-16
RS-232C parameters . . . . . . . . 2-99–2-119
ASCII format . . . . . . . . . . . . . . . 2-108
baud rate . . . . . . . . . . . . . . . . . . . 2-99
beep on bel . . . . . . . . . . . . . . . . 2-108
check receive errors . . . . . . . . . . 2-101
hardware handshaking . . . . . . . 2-102
host serial response time-out . . . 2-106
intercharacter delay . . . . 2-109, 2-119
parity . . . . . . . . . . . . . . . . . . . . . 2-100
RTS line state . . . . . . . . . . . . . . 2-106
software handshaking . . . . . . . . 2-104
stop bit select . . . . . . . . . . . . . . . 2-107
set defaults . . . . . . . . . . . . . . . . . . . . . . 2-9
transmit no read message . . . . . . . . . . 2-19
UPC/EAN
bookland EAN . . . . . . . . . . . . . . 2-32
convert UPC-E to UPC-A . . . . . . 2-39
Convert UPC-E1 to UPC-A . . . . . 2-40
EAN-8/EAN-13 . . . . . . . . . . . . . . 2-30
UPC-A preamble . . . . . . . . . . . . . 2-36
UPC-E preamble . . . . . . . . . . . . . 2-37
UPC-E/UPC-A . . . . . . . . . . . . . . . 2-28
check digit . . . . . . . . . . . . . . 2-35
supp redundancy . . . . . . . . . 2-34
supplementals . . . . . . . . . . . . 2-33
Baud Rate . . . . . . . . . . . . . . . . . . . . . 2-6, 2-99
Beep After Good Decode . . . . . . . . . . 2-2, 2-18
Beep on . . . . . . . . . . . . . . . . . . . . . . 2-7, 2-108
beeper
ADF definitions . . . . . . . . . . . . . . . . . . 3-8
macro PDF definitions . . . . . . . . . . . . 1-16
tone . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Beeper Indications . . . . . . . . . . . . . . . . . . . 1-15
beeper indications . . . . . . . . . . . . . . . . . . . 1-15
Beeper Volume . . . . . . . . . . . . . . . . . . 2-2, 2-13
beeper volume . . . . . . . . . . . . . . . . . . . . . . 2-13
Bi-directional Redundancy . . . . . . . . . 2-2, 2-23
Bookland EAN . . . . . . . . . . . . . . . . . . . . . . 2-3
Index-3
Index
Buffer Code 39 . . . . . . . . . . . . . . . . . . . . . . 2-4
bullets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x
C
Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-122
Check Receive Errors . . . . . . . . . . . . 2-6, 2-101
CLSI Editing . . . . . . . . . . . . . . . . . . . 2-5, 2-77
Codabar . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Code 128 . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Code 32 Prefix . . . . . . . . . . . . . . . . . . . . . . 2-4
Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Code 39 Check Digit Verification . . . 2-4, 2-54
Code 39 Full ASCII Conversion . . . . . . . . . . 2-4
Code 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
codewords . . . . . . . . . . . . . . . . . . . . . . . . 2-126
transmit unknown . . . . . . . . . . . . . . 2-131
Connecting Power . . . . . . . . . . . . . . . . . . . . 1-3
Connecting to a Host . . . . . . . . . . . . . . . . . . 1-4
RS-232 . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
conventions
notational . . . . . . . . . . . . . . . . . . . . . . . . .x
Convert All to Code 39 . . . . . . . . . . . . . . . . 2-7
Convert Code 39 to Code 32 . . . . . . . . . . . . 2-4
Convert I 2 of 5 to EAN 13 . . . . . . . . . . . . . 2-5
Convert I 2 of 5 to EAN-13 . . . . . . . . . . . . 2-70
Convert UPC-E to A . . . . . . . . . . . . . . . . . . 2-3
Convert UPC-E1 to UPC-A . . . . . . . . . . . . . 2-3
criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
D
DC Power Adapter . . . . . . . . . . . . . . . . . . . 1-2
dead zone . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Decode UPC/EAN Supplemental
Redundancy . . . . . . . . . . . . . . . . . 2-3
Decode UPC/EAN Supplementals . . . . . . . . 2-3
default table . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Delete Character Set ECIs . . . . . . . . . . . . . . 2-7
Discrete 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . 2-5
E
EAN-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
EAN-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
ECI
decoder . . . . . . . . . . . . . . . . . . . . . . 2-130
delete character set ECIs . . . . . . . . . 2-129
ECI Decoder . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Enable/Disable Codabar . . . . . . . . . . . . . . 2-74
Enable/Disable Code 128 . . . . . . . . . . . . . 2-46
Enable/Disable Code 39 Full ASCII . . . . . 2-56
Enable/Disable Interleaved 2 of 5 . . . . . . . 2-65
Enable/Disable Micro PDF . . . . . . . . . . . . . 2-6
Enable/Disable PDF417 . . . . . . . . . . . . . . . 2-5
Enable/Disable Trioptic Code 39 . . . . . . . 2-51
Enable/Disable UCC/EAN-128 . . . . . . . . . 2-47
Enable/Disable UPC-E/ UPC-A . . . . . . . . . 2-28
Escape Characters . . . . . . . . . . . . . . . . . . . . 2-7
escape characters . . . . . . . . . . . . . . . . . . 2-128
F
Fast Transmit . . . . . . . . . . . . . . . . . . . . . . . 2-7
Flush Macro Buffer . . . . . . . . . . . . . . . . . . . 2-8
FUJITSU . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
H
hands-free scanning . . . . . . . . . . . . . . . . . 1-14
Hardware Handshaking . . . . . . . . . . 2-6, 2-102
Host Connection
Keyboard Wedge . . . . . . . . . . . . . . . . . 1-5
Keyboard Wedge via Synapse . . . . . . . 1-7
Synapse . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Wand Emulation . . . . . . . . . . . . . . . . . 1-4
Host Serial Response Time-out . . . . . 2-6, 2-106
Host Type . . . . . . . . . . . . . . . . . . . . . . . 2-2, 2-7
I
I 2 of 5 Check Digit Verification . . . . . . . . . 2-4
ICL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
indications, beeper . . . . . . . . . . . . . . . . . . 1-15
information, service . . . . . . . . . . . . . . . . . . . . x
Installing the Cable . . . . . . . . . . . . . . . . . . . 1-2
Intellistand . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Intellistand Options . . . . . . . . . . . . . . . . . 2-25
Time Delay to Low Power Mode . . . . 2-25
Timeout Between Decodes . . . . . . . . . 2-26
Index-4
P 300STD/FZY/PRO Scanner Product Reference Guide
Intercharacter Delay . . . . . . . . . . . . . 2-7, 2-109
Interleaved 2 of 5 . . . . . . . . . . . . . . . . . . . . 2-4
K
Keyboard Wedge Cable . . . . . . . . . . . . . . . 1-2
Keyboard Wedge Connection . . . . . . . . . . . 1-5
Keyboard Wedge via Synapse . . . . . . . . . . . 1-7
L
Laser On Time . . . . . . . . . . . . . . . . . . 2-2, 2-15
Lengths for Code 128 . . . . . . . . . . . . . . . . 2-49
linear bar codes
scanning . . . . . . . . . . . . . . . . . . . . . . 1-10
Linear Code Type Security Level . . . . . . . . 2-21
Linear Code Type Security Levels . . . . . . . . 2-2
LS 100x
Installing the Cable . . . . . . . . . . . . . . . 1-2
Switching Cables . . . . . . . . . . . . . . . . . 1-3
M
Macro PDF
ECI decoder . . . . . . . . . . . . . . . . . . . 2-130
transmit user-selected fields . . . . . . . 2-132
macro PDF
beeper definitions . . . . . . . . . . . . . . . 1-16
buffer all symbols . . . . . . . . . . . . . . 2-124
buffer/transmit scans . . . . . . . . . . . . 2-124
delete character set ECIs . . . . . . . . . 2-129
escape characters . . . . . . . . . . . . . . . 2-128
flush buffer/abort PDF entry . . . . . . 2-135
scan in sequence . . . . . . . . . . . . . . . 2-124
transmit any symbol in set . . . . . . . . 2-124
transmit symbols in codeword format . . 2-
126
transmit unknown codewords . . . . . 2-131
transmit/decode mode symbols . . . . 2-124
Macro PDF Features . . . . . . . . . . . . . . . . 2-123
MacroPDF Parameters . . . . . . . . . . . . . . . . 2-7
MacroPDF Transmit/Decode Mode Symbols 2-7
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 4-1
MSI Plessey . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
MSI Plessey Check Digit Algorithm . . 2-5, 2-84
MSI Plessey Check Digits . . . . . . . . . . 2-5, 2-82
N
National Keyboard Type . . . . . . . . . . . . . . . 2-7
NIXDORF Mode A/Mode B . . . . . . . . . . . 2-10
notational conventions . . . . . . . . . . . . . . . . . . x
NOTIS Editing . . . . . . . . . . . . . . . . . . . . . . . 2-5
Numeric Bar Codes . . . . . . . . . . . . . . . . . 2-120
P
P 300STD . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
P 302FZY . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
P 304IMG . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
P 304PRO . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
P 304PRO Scanning Mode Options
Always Raster . . . . . . . . . . . . . . . . . . . . 1-9
Programmable Raster . . . . . . . . . . . . . .1-9
Slab Only Raster . . . . . . . . . . . . . . . . . . 1-9
Parameters
aiming mode . . . . . . . . . . . . . . . . . . . . 2-92
ASCII format . . . . . . . . . . . . . . . . . . 2-108
Autodiscriminate Response Time . . . . 2-24
Baud Rate . . . . . . . . . . . . . . . . . . . . . . 2-99
Beep After Good Decode . . . . . . . . . . 2-18
Beep on . . . . . . . . . . . . . . . . . . . . . . .2-108
Beeper Volume . . . . . . . . . . . . . . . . . . 2-13
Cancel . . . . . . . . . . . . . . . . . . . . . . .2-122
CLSI Editing . . . . . . . . . . . . . . . . . . . . 2-77
Codabar . . . . . . . . . . . . . . . . . . . . . . . 2-74
Code 39 Buffering . . . . . . . . . . . . . . . 2-57
Code 39 Check Digit Verification . . . . 2-54
Convert EAN-8 to EAN-13 . . . . . . . . 2-44
Convert I 2 of 5 to EAN-13 . . . . . . . . 2-70
Convert UPC-E1 to UPC-A . . . . . . . . . 2-40
Decode UPC/EAN Supplementals . . . . 2-33
Enable/Disable Code 128 . . . . . . . . . . 2-46
Enable/Disable Code 39 . . . . . . . . . . . 2-50
Enable/Disable Code 39 Full ASCII . . 2-56
Enable/Disable Code 93 . . . . . . . . . . . 2-62
Enable/Disable Discrete 2 of 5 . . . . . . 2-71
Enable/Disable Interleaved 2 of 5 . . . . 2-65
Enable/Disable MSI Plessey . . . . . . . . 2-79
Enable/Disable Trioptic Code 39 . . . . 2-51
Index-5
Index
Enable/Disable UCC/EAN-128 . . . . . . 2-47
Enable/Disable UPC-E/UPC-A . . . . . . 2-28
Hardware Handshaking . . . . . . . . . . 2-102
Host Serial Response Time-Out . . . . 2-106
I 2 of 5 Check Digit Verification . . . . 2-68
Keyboard Wedge
Fast Transmit . . . . . . . . . . . . . . 2-118
Host Interfaces . . . . . . . . . . . . . 2-115
Intercharacter Delay . . . . . . . . . 2-119
National Keyboard Types . . . . . 2-116
Laser On Time . . . . . . . . . . . . . . . . . . 2-15
Linear Code Type Security Level . . . . 2-21
MSI Plessey Check Digit Algorithm . . 2-84
MSI Plessey Check Digits . . . . . . . . . . 2-82
MSI Plessey Lengths . . . . . . . . . . . . . . 2-80
NOTIS Editing . . . . . . . . . . . . . . . . . . 2-78
Numerics . . . . . . . . . . . . . . . . . . . . . 2-120
Parity . . . . . . . . . . . . . . . . . . . . . . . . 2-100
Pause Duration . . . . . . . . . . . . . . . . . . 2-95
Power Mode . . . . . . . . . . . . . . . . . . . . 2-16
Prefix/Suffix Values . . . . . . . . . . . . . . 2-96
programmable raster size/expansion . . 2-90
RTS Line State . . . . . . . . . . . . . . . . . 2-106
Set Lengths for Codabar . . . . . . . . . . . 2-75
Set Lengths for Code 39 . . . . . . . . . . . 2-52
Set Lengths for Code 93 . . . . . . . . . . . 2-63
Set Lengths for Discrete 2 of 5 . . . . . . 2-72
Set Lengths for Interleaved 2 of 5 . . . . 2-66
Software Handshaking . . . . . . . . . . . 2-104
Transmit Code 39 Check Digit . . . . . . 2-55
Transmit Code ID Character . . . . . . . 2-93
Transmit I 2 of 5 Check Digit . . . . . . . 2-69
Transmit MSI Plessey Check Digit . . . 2-83
Transmit UPC-A/UPC-E Check Digit . 2-35
Transmit UPC-E1 Check Digit . . . . . . 2-41
Transmit "No Read" Message . . . . . . 2-19
Trigger Mode . . . . . . . . . . . . . . . . . . . 2-17
UPC-A Preamble . . . . . . . . . . . . . . . . 2-36
UPC-E Preamble . . . . . . . . . . . . . . . . . 2-37
UPC/EAN Security Level . . . . . . . . . . 2-42
Wand
Convert all to Code 39 . . . . . . . 2-114
Host Interface . . . . . . . . . . . . . . 2-110
Variable Leading Margin . . . . . 2-112
Wand Emulator Bar Output . . . 2-111
Parametes
Intercharacter Delay . . . . . . . . . . . . 2-109
Parity . . . . . . . . . . . . . . . . . . . . . . . . 2-6, 2-100
Pause Duration . . . . . . . . . . . . . . . . . . 2-6, 2-95
PDF417 . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
pin outs . . . . . . . . . . . . . . . . . . . . . . . . . . . D-6
Power Mode . . . . . . . . . . . . . . . . . . . . 2-2, 2-16
Power Supply . . . . . . . . . . . . . . . . . . . . . . . 1-2
prefix values . . . . . . . . . . . . . . . . . . . . . . . . A-6
Prefix/Suffix Values . . . . . . . . . . . . . . 2-6, 2-96
prefix/suffix values . . . . . . . . . . . . . . . . . . . A-6
Product Descriptions
P 300STD . . . . . . . . . . . . . . . . . . . . . . 1-1
P 302FZY . . . . . . . . . . . . . . . . . . . . . . 1-1
P 304IMG . . . . . . . . . . . . . . . . . . . . . . 1-1
P 304PRO . . . . . . . . . . . . . . . . . . . . . . 1-1
Programmable Raster . . . . . . . . . . . . . . . . . 1-9
programmable raster . . . . . . . . . . . . . . . . . 1-9
programming . . . . . . . . . . . . . . . . . . . . . . . 2-1
programming parameters
beeper tone . . . . . . . . . . . . . . . . . . . . 2-14
Code 128 emulation . . . . . . . . . . . . . 2-87
delete character set ECIs . . . . . . . . . 2-129
ECI decoder . . . . . . . . . . . . . . . . . . . 2-130
escape characters . . . . . . . . . . . . . . . 2-128
flush macro buffer/abort macro PDF
entry . . . . . . . . . . . . . . . . . . . . . 2-135
macro PDF transmit/decode mode
symbols . . . . . . . . . . . . . . . . . . 2-124
time delay to low power . . . . . . . . . . 2-25
timeout between decodes . . . . . . . . . . 2-26
transmit Macro PDF user-selected
fields . . . . . . . . . . . . . . . . . . . . 2-132
transmit symbols in codeword
format . . . . . . . . . . . . . . . . . . . 2-126
transmit unknown codewords . . . . . 2-131
UCC/EAN-128 emulation . . . . . . . . . 2-88
Programming the scanner . . . . . . . . . . . . . . 1-8
Publications
Related . . . . . . . . . . . . . . . . . . . . . . . . . . x
Index-6
P 300STD/FZY/PRO Scanner Product Reference Guide
R
Raster Expansion . . . . . . . . . . . . . . . . . . . . 2-5
Raster Height . . . . . . . . . . . . . . . . . . . . . . . 2-5
raster pattern . . . . . . . . . . . . . . . . . . . . 1-8, 1-9
slab . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Related Publications . . . . . . . . . . . . . . . . . . . . x
RS-232 Cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
RS-232 Host Type . . . . . . . . . . . . . . . . . . . 2-6
RS-232C Host Types . . . . . . . . . . . .2-10, 2-12
RTS Line State . . . . . . . . . . . . . . . . . 2-6, 2-106
S
Scan Data Transmission Format . . . . . 2-6, 2-97
Scan Stand Operation . . . . . . . . . . . . . . . . 1-14
Scan Stand Options . . . . . . . . . . . . . . . . . . 2-27
Time Delay to Low Power Mode . . . . 2-25
Timeout Between Decodes . . . . . . . . . 2-26
scan the entire symbol . . . . . . . . . . . . . . . . 1-11
scanning
1D bar codes . . . . . . . . . . . . . . . . . . . 1-10
Scanning 1D Bar Codes . . . . . . . . . . . . . . 1-10
Scanning Mode . . . . . . . . . . . . . . . . . . . . . . 2-5
scanning modes
always raster . . . . . . . . . . . . . . . . . . . . 1-9
programmable raster . . . . . . . . . . . . . . 1-9
slab only raster . . . . . . . . . . . . . . . . . . 1-9
smart raster . . . . . . . . . . . . . . . . . . 1-8, 1-9
Scanning PDF417 (2D) Bar Codes . . . . . . 1-11
Service Information . . . . . . . . . . . . . . . . . . . . . x
service information . . . . . . . . . . . . . . . . . . . . . x
Set Default Parameter . . . . . . . . . . . . . .2-2, 2-9
Set Lengths for Codabar . . . . . . . . . . . 2-5, 2-75
Set Lengths for Code 39 . . . . . . . . . . . . . . 2-52
Set Lengths for Discrete 2 of 5 . . . . . . . . . 2-72
Set Length(s) for Code 39 . . . . . . . . . . . . . . 2-4
Set Length(s) for Code 93 . . . . . . . . . . . . . . 2-4
Set Length(s) for D 2 of 5 . . . . . . . . . . . . . . 2-5
Set Length(s) for I 2 of 5 . . . . . . . . . . . . . . . 2-4
Set Length(s) for MSI Plessey . . . . . . . . . . . 2-5
Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Connecting Power . . . . . . . . . . . . . . . . 1-3
Connecting to Host . . . . . . . . . . . . . . . 1-4
Installing the Cable . . . . . . . . . . . . . . . 1-2
Switching Cables . . . . . . . . . . . . . . . . . 1-3
slab raster . . . . . . . . . . . . . . . . . .1-8, 1-9, 1-10
smart raster . . . . . . . . . . . . . . . . . . . . . 1-8, 1-9
Software Handshaking . . . . . . . . . . . 2-6, 2-104
specular reflection . . . . . . . . . . . . . . . . . . . 1-11
Stop Bit Select . . . . . . . . . . . . . . . . . 2-6, 2-107
suffix values . . . . . . . . . . . . . . . . . . . . . . . . .A-6
Switching the Cable . . . . . . . . . . . . . . . . . . . 1-3
symbol support center . . . . . . . . . . . . . . . . . . xi
Synapse Cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
Synapse Cable Connection . . . . . . . . . . . . . .1-6
T
technical specifications
ambient light immunity . . . . . . . . . . . D-2
beeper operation . . . . . . . . . . . . . . . . . D-1
decode capability . . . . . . . . . . . . . . . . D-1
decode depth of field . . . . . . . . . D-1, D-2
dimensions . . . . . . . . . . . . . . . . . . . . . D-2
durability . . . . . . . . . . . . . . . . . . . . . . D-2
humidity . . . . . . . . . . . . . . . . . . . . . . . D-2
laser classification . . . . . . . . . . . . . . . . D-2
pitch . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
power requirements . . . . . . . . . . . . . . D-1
print contrast minimum . . . . . . . . . . . D-2
roll tolerance . . . . . . . . . . . . . . . . . . . D-1
scan repetition rate . . . . . . . . . . . . . . . D-1
temperature
operating . . . . . . . . . . . . . . . . . . . D-2
storage . . . . . . . . . . . . . . . . . . . . . D-2
yaw . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Test Symbols . . . . . . . . . . . . . . . . . . . . . . . 1-12
Time Delay to Low Power Mode . . . . . . . . 2-25
Transmit Code 39 Check Digit . . . . . 2-4, 2-55
Transmit Code ID Character . . . . . . . . . . . . 2-6
Transmit I 2 of 5 Check Digit . . . . . . 2-5, 2-69
Transmit MacroPDF User-Selectable Fields .2-8
Transmit MSI Plessey Check Digit . . . 2-5, 2-83
Transmit Symbols in Codeword Format . . . 2-7
Transmit Unknown Codewords . . . . . . . . . . 2-8
Transmit UPC-A Check Digit . . . . . . . . . . .2-3
Transmit UPC-E Check Digit . . . . . . . . . . . . 2-3
Transmit UPC-E1 Check Digit . . . . . . 2-3, 2-41
Index-7
Index
Transmit “No Read” Message . . . . . . 2-2, 2-19
Trigger Mode . . . . . . . . . . . . . . . . . . . . . . 2-17
Trioptic Code 39 . . . . . . . . . . . . . . . . . . . . . 2-4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . 4-2
U
UCC/EAN-128 . . . . . . . . . . . . . . . . . . . . . . 2-4
Undecoded Cable
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
UPC-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
UPC-A Preamble . . . . . . . . . . . . . . . . 2-3, 2-36
UPC-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
UPC-E Preamble . . . . . . . . . . . . . . . . 2-3, 2-37
UPC-E1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
UPC-E1 Preamble . . . . . . . . . . . . . . . . . . . . 2-3
UPC/EAN Security Level . . . . . . . . . . . . . 2-42
UPC/EAN Security Levels . . . . . . . . . . . . . . 2-3
User Documentation . . . . . . . . . . . . . . . . . . 1-2
V
Variable Leading Margin . . . . . . . . . . . . . . 2-7
W
Wand Emulation Cable . . . . . . . . . . . . . . . 1-2
Wand Emulation Connection . . . . . . . . . . . 1-4
Wand Emulator Bar Output . . . . . . . . . . . . 2-7
Wand Host Interface . . . . . . . . . . . .2-7, 2-110
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
Index-8
P 300STD/FZY/PRO Scanner Product Reference Guide
Thank you for your input—We value your comments.
Tell Us What You Think...
We’d like to know what you think about this Manual. Please take a moment
to fill out this questionnaire and fax this form to: (631) 738-3318, or mail
to:
Symbol Technologies, Inc.
One Symbol Plaza M/S B-4
Holtsville, NY 11742-1300
Attn: Technical Publications Manager
IMPORTANT: If you need product support, please call the appropriate cus-
tomer support number provided. Unfortunately, we cannot provide customer
support at the fax number above.
User’s Manual Title: _______________________________________________
(please include revision level)
How familiar were you with this product before using this manual?
Did this manual meet your needs? If not, please explain. ________________
________________________________________________________________
What topics need to be added to the index, if applicable? _______________
________________________________________________________________
What topics do you feel need to be better discussed? Please be specific.
_________________________________________________________________
What can we do to further improve our manuals?_______________________
_________________________________________________________________
_________________________________________________________________
Very familiar Slightly familiar Not at all familiar

Navigation menu
