Sysgration AXM-605A WIRELESS OPTICAL MOUSE User Manual USERS MANUAL

Sysgration Ltd. WIRELESS OPTICAL MOUSE USERS MANUAL

USERS MANUAL

AXM-605A Wireless Optical Mouse User Manual
AXM-209C User Manual
1. Connecting with Computer:
The first time you take out this mouse and
receiver from the packing, Factory Preset ID
enables Plug and Play function.
Plug the Receiver into PC
USB Port . Under Win2000
or higher , wait for the OS to
detect the RF device.
Under Win98 or lower,
installation of driver for the
device is necessary.
Insert the batteries into
the mouse and move it for a while , then it
starts working .
2. Inserting Batteries:
A. Push the battery cover
compartment backward
and open it .
B. Insert 2 AAA batteries
into the compartment with
correct orientation .
B. Slide the battery cover
into the compartment and
close the cover .
3. ID Link:
When Factory ID has been changed or
wish to be changed , link ID as below :
A. Press the ID button on
the bottom of the mouse .
B. Press the ID button on
the top of the receiver. If
the led on it starts blinking
rapidly , ID Link is OK .
! ID linking should be completed within
10 seconds or connection would be failed
4. Power Saving Mode:
A. Suspend Mode :
Keep mouse stationary for 10 minutes,
mouse will be automatically
set to Suspend Mode. Press
left button to wake up the
mouse again.
B. Power Off Mode :
When you wish to set the mouse to
power off mode, press mouse ID for 3
seconds . The Optical Led will flash once
and then fade out, showing mouse power
is already off. Press ID switch for waking
up again .
5. Trouble Shooting:
A. When mouse doesn’t respond, check
the battery power status, and link ID again.
B. Be sure the Receiver is connected
properly to the USB port of the PC.
C. Ask for maintenance solution from
your retailer and engineer . Personally
taking apart is prohibited after trouble
happened.
FCC Note :
This equipment has been tested and comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection. This equipment
generates, uses and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation if
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter
FCC ID: HQXAXM-605A
FCC Compliance and Advisory Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
according to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try correct the interference by one or more
of the following measures:
1.Reorient the receiving antenna.
2.Increase the separation between the equipment and receiver.
3.Connect the equipment into and outlet on a circuit different from that to which the receiver is
connected.
4.Consult the dealer or an experienced radio/TV technician for help.
Any special accessories needed for compliance must be specified in the instruction manual.
Warning: A shielded-type power cord is required in order to meet FCC emission limits and
also to prevent interference to the nearby radio and television reception. It is essential that
only the supplied power cord be used. Use only shielded cables to connect I/O devices to this
equipment.
CAUSION: Any changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
