Sysgration RSI06 TPMS User Manual RSI06 manual 20161229

Sysgration Ltd. TPMS RSI06 manual 20161229

Users Manual

SAFETYINSTRUCTIONS

Readallinstallation,safetyinstructionandreviewallillustrationsbeforeinstallingthesensor.Forreasonsofsafetyandfor

optimalfunction,Sysgraionrecommendsthatanymaintenanceandrepairworkiscarriedoutbytrainedexpertsonlyand

accordingtotheguidelinesofthevehiclemanufacturer.Thevalvesaresafety‐relevantpartswhichareintendedfor

professionalinstallationonly.FailuretofollowinstallationinstructionsmayresultinthefailureofthemotorvehicleTPMS

sensortooperateproperly.Sysgrationdoesnotassumeanyliabilityincaseoffaultyorincorrectinstallationoftheproduct.

CAUTION

 TheRSI06sensorassembliesarereplacementormaintenancepartsforvehiclesthathaveafactoryinstalledTPMS.

 MakesuretoprogramsensorbyRSI06programmingtoolforyourspecificvehiclemake,modelandyearbefore

installation.

 Inordertoguaranteeoptimalfunction,thesensormayonlybeinstalledwithvalvesandaccessoriesbySyagration.

 Uponcompletionofinstallation,testthevehiclesTPMSsystemusingproceduresdescribedintheoriginal

manufacturer’suserguidetoconfirmproperinstallation.



WARRANTY

SysgrationwarrantsthattheTPMSsensorcomplieswithRSI06Sensorproductspecificationsandshallbefreefromdefectsin

workmanshipandmaterialforaperiodoftwenty‐four(24)monthsor24,000milesofuse,whicheveroccurfirst.RSI06

Sensorwillatitsdiscretionreplaceanymerchandiseduringthewarrantyperiod.Thewarrantyshallbevoidifanyofthe

followingoccur:

1. Improperinstallationofproducts

2. Improperusage

3. Inductionofdefectbyotherproducts

4. Mishandlingofproduct

5. Incorrectapplication

6. Damageduetocollisionortirefailure

7. Racingorcompetition

Thisisthesoleandexclusivewarrantyandliabilitytocustomers.

Sysgrationexpresslydisclaimsandotherwarrantyincludingthewarrantiesofmerchantability.Fitnessforpurposeofother

impliedorexpresswarranties.UndernocircumstanceshallRSI06Sensorbeliabletocustomerforanyotheramounts

includinglaborchargesforinstallationorreinstallationofproductsnorshallRSI06Sensorliableunderanytheoryforany

otherdamagesincludingbutnotlimitedtodirect,indirect,special,consequentialandincidentaldamages.



EXPLOREVIEWOFSENSOR



EXPLOREVIEWOFSENSOR



Weightofsensorwithoutvalve:27.8g

Dimension:L61.7Xw33.3x20.4mm

Max.pressurerange:130psi



INSTALLATIONGUIDE

WARNING:FAILUFTETOFOLLOWINSTALLATIONINSTHUCTIONS0RTHEUSEOF

IMPROPERTPMSSENSORSMAYRESULTINTHEMOTORVEHICLETPMSSYSTEM

FAILURECAUSINGPROPERTYDAMAGE,PERSONALINJURYORDEATH

Eachtimeatireisservicedordismountedorifsensorisremoved,itisMANDATORYtoreplacethenut,andvaluetoensure

propersealing.TheTPMSsensornutmustbeproperlyinstalledandtightenedforProperinstallation.Carefullyfollow

instructionsanduseatorquewrenchtoensureproperinstallation.FailuretotorquetheTPMSsensornutproperlywillvoid

thewarrantyandtheTPMSmaynotfunctionproperly.



STEP1:Looseningthetire

Removethevalvecapandcoreanddeflatethetire.Usethe

beadloosenertounseatthetirebead.



STEP2:Dismountingthetire



STEP3:Dismountingtheoriginalsensor

Withascrewdriverremovethefasteningscrewandsensor

fromthevalvestem.Thenloosenthenutandremovethe

valve.



STEP4:MountingtheSensorandvalve

Slidethevalvestemthroughthevalveholeoftherim.

Tightenthecrewnutwith4.0Nmwiththehelpofthe

positioningpin.Assemblethesensorandthevalveagainst

therimandtightenthescrew.



STEP5Mountingthetire

Clamptherimontotheassemblymachinesothatthevalve

facestheassemblyheadatanangleof180°



WARNING:

Correctnuttorque:40inch‐pounds;4.6Newton‐meters.TPMSSENSORAND/ORVALUEBROKENBYOVERTORQUEARENOTCOVERED

UNDERWARRANTY.FAILURETOACHIEVETHENECESSARYTPMSSENSORNUTTORQUEMAYRESULTINANINADEQUATEAIRSEAL,

RESULTINGINTIREARILOSS.



WARRANTYINFORMATION

Professionalinstaller:WhenreplacinganentireTPMSsensorassembly,please

CompletethefollowingTPMSsensorwarrantyinformationgivingonecopytothe

Customerandsendtheduplicatecopytoindicatedaddress.



RSI06sensorcustomerInformationCard



PlaceofRepair:

Address:phone:

Vehicleowner:namesensorinstallationdate:(M)/(D)/(Y)

Address:

MotorVehicle:MakeModel:Year:

VINNumber:SensorID:



IMPORTANTWARRANTYINFORMATIONTOACTIVATEWARRANTY,

Pleasecompletethefollowingsectionandsendto:



RSI06Sensor.6F.,No.1,TidingBlvd.,NeihuDist.,TaipeiCity11494,Taiwan



Address:phone:

Vehicleowner:namesensorinstallationdate:(M)/(D)/(Y)

MotorVehicle:MakeModel:Year:

VINNumber:Mileage:

SensorID:

Partnumberofsensorbeingreplaced:FrontLeftFrontRight

RearLeftRearRightMemo

Manufactureofsensorbeingreplaced:



ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethat

maycauseundesiredoperation.



SYSGRATION.Ltd

6F.,No.1,TidingBlvd.,NeihuDist.,TaipeiCity11494,Taiwan

Tel:+88622790‐0088

Email:sales@max‐autoparts.com

Web:www.max‐autoparts.com
