Sysgration RSI07 TPMS User Manual

Sysgration Ltd. TPMS Users Manual

Users Manual



SAFETYINSTRUCTIONS

Readallinstallation,andsafetyinstructionsandreviewallillustrationsbeforeinstallingthesensor.Forreasonsofsafetyand

foroptimalfunction,recommendsthatanymaintenanceandrepairworkiscarriedoutbytrainedexpertsonlyandaccording

totheguidelinesofthevehiclemanufacturer.Thevalvesaresafety‐relevantpartswhichareintendedforprofessional

installationonly.FailuretofollowinstallationinstructionsmayresultinthefailureofthevehicleTPMSsensortooperate

properly.Manufacturedoesnotassumeanyliabilityincaseofincorrect,faultyorincompleteinstallationoftheproduct.

CAUTION

 TheSensorassembliesarereplacementormaintenancepartsforvehiclesthathaveafactoryinstalledTPMS.

 MakesuretoprogramsensorbySensorprogrammingtoolforyourspecificvehiclemake,modelandyearbefore

installation.

 Uponcompletionofinstallation,testthevehiclesTPMSsystemusingproceduresdescribedintheoriginal

manufacturer’suserguidetoconfirmproperinstallation.



VIEWOFSENSOR



EXPLODEDVIEWOFSENSOR

INSTALLATIONGUIDE

WARNING:FAILURETOFOLLOWINSTALLATIONINSTRUCTIONS0RTHEUSEOF

IMPROPERTPMSSENSORSMAYRESULTINTHEMOTORVEHICLETPMSSYSTEM

FAILURECAUSINGPROPERTYDAMAGE,PERSONALINJURYORDEATH.

Eachtimeatireisservicedordismountedorifsensorisremoved,itisMANDATORYtoreplacethenut,andvalvetoensure

propersealing.TheTPMSsensornutmustbeproperlyinstalledandtightenedforproperinstallation.Carefullyfollow

instructionsanduseatorquewrenchtoensureproperinstallation.FailuretotorquetheTPMSsensornutproperlywillvoid

thewarrantyandtheTPMSmaynotfunctionproperly.



STEP1:Looseningthetire

Removethevalvecapandcoreanddeflatethetire.Usethe

beadloosenertounseatthetirebead.



STEP2:Dismountthetirefromthewheel



STEP3:Dismounttheoriginalsensor

Withascrewdriverremovethefasteningscrewandsensor

fromthevalvestem.Thenloosenthenutandremovethe

valve.



STEP5Mountingthetire

Clamptherimontotheassemblymachinesothatthevalve

facestheassemblyheadatanangleof180°



FCCNOTICE:

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.



ICNOTICE:

UnderIndustryCanadaregulations,thisradiotransmittermayonlyoperateusinganantennaofatype

andmaximum(orlesser)gainapprovedforthetransmitterbyIndustryCanada.Toreducepotential

radiointerferencetootheruser,theantennatypeanditsgainshouldbesochosenthattheequivalent

isotropicallyradiatedpower(e.i.r.p.)isnotmorethanthatnecessaryforsuccessfulcommunications.
