SAXM105A1 Wireless Optical Mouse User Manual
SAXM105A1 User’s Guide
1. Connecting with Computer:
The first time you take out this mouse and
receiver from the packing, Factory Preset ID
enables Plug and Play function.
Plug the Receiver into PC
USB Port . Under Win2000
or higher , wait for the OS to
detect the RF device. Under
Win98 or lower installation
of driver for the device is
necessary.
Insert the batteries into
the mouse and move it for a while , then it
starts working .
2. Inserting Batteries:
A. Push the battery cover
compartment backwards and
open it .
B. Insert 2 AAA batteries
Into compartment with
correct orientation .
C. Slide the battery cover
into the compartment and
close the cover .
3. ID Link:
When Factory ID has been changed or
wish to be changed , link ID as below :
A. Press the ID button on
the bottom of the mouse . The
led on it starts blinking .
B. Press the ID button on
the top of the receiver. The led
on it blinks fastly and link is
OK .
!ID linking should be completed within 10
seconds or connection would be failed
4. Low Battery Alert:
When batteries power
drops down to 2V, the alert
Led on the left side of the
mouse starts flashing.
Please replace new batteries .
Alert Led
6. Power Saving Mode:
A. Suspend Mode :
Keep mouse stationary for 10 minutes,
mouse will be automatically
set to Suspend Mode. Press
left button to wake up the
mouse again.
B. Power Off Mode :
When you wish to set the mouse to power
off mode, press mouse ID for 3 seconds .
The Optical Led will flash once and then
fade out showing mouse power is already
off. Press ID switch for waking up again .
7. Trouble Shooting:
A. When mouse doesn’t respond, check
the battery power status, and make sure
Battery Power is full.
B. Check the battery pole if the optical
Led is still off after inserting batteries.
C. If battery power is full and led is
normal yet mouse still won’t work , do
ID Linking to set up connection again.
D. Ask for maintenance solution from
your retailer and engineer if upper
trouble shooting would not work.
Personally taking apart after trouble
happened is prohibited.
FCC Note :
This equipment has been tested and comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection. This equipment
generates, uses and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation if
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter
FCC ID : HQXSAXM105A1
