TAIYO YUDEN EYSHSN Bluetooth Smart / ANT Module User Manual Bluetooth 4
TAIYO YUDEN CO., LTD. Bluetooth Smart / ANT Module Bluetooth 4
05 (Short-Term Confidential) User Manual
30-Jun.2017 Ver.0.9
TAIYO YUDEN CO., LTD.
TAIYO YUDEN CO., LTD. 1/3
EYSHSN
User manual
(for EYSHSN)
FCC ID: RYYEYSHSN
IC Number: 4389B-EYSHSN
30-Jun.2017 Ver.0.9
TAIYO YUDEN CO., LTD.
TAIYO YUDEN CO., LTD. 2/3
EYSHSN
Since this module is not sold to general end users directly, there is no user manual of module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification
(installation procedure).
The following information must be indicated on the host device of this module;
1) Japan Regulatory Information
a) This Product is a radio system and obtained certification of construction type combined
with the specific antenna.
b) Please ensure that your product has a label with the following certification mark at easily
viewable location. If your product is too small to have the label, please place it in the
instruction manual and package of your product. The mark diameter shall be equal or
greater than 3mm. In case your product does not have the label with the following
certification mark, you or your customer who uses your product may be against the Radio
Law and subjected to criminal punishment. TAIYO YUDEN shall not be liable for any
loss or damage incurred by you or your customer arising from use of your product which
does not have following certification mark.
This product has a radio system which was approved as a radio station in a low
power data communication system based on the Radio Law.
EYSHSN : 001-A＊＊＊＊＊
2) Canada Regulatory Information
a) This device complies with Industry Canada’s applicable licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
b) This product is certified as type of the portable device with Industry Canada Rules. To
maintain compliance with RF Exposure requirement,please use within specification of
this product.
Ce produit est certifié comme type de l'appareil portable avec Industrie Règles de
Canada. Pour maintenir l'acquiescement avec exigence Exposition de RF, veuillez
utiliser dans spécification de ce produit.
- IC: 4389B-EYSHSN
30-Jun.2017 Ver.0.9
TAIYO YUDEN CO., LTD.
TAIYO YUDEN CO., LTD. 3/3
EYSHSN
c) Please notify certified ID by either one of the following method on your product.
-Contains IC : 4389B-EYSHSN
Specifiez ID certifiée dans votre produit par une de méthode suivante.
-Contains IC : 4389B-EYSHSN
3) FCC Regulatory Information
a) This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
b) Please notify certified ID by either one of the following method on your product.
-Contains Transmitter Module FCC ID: RYYEYSHSN
-Contains FCC ID: RYYEYSHSN
c) CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the use’s authority to operate the equipment.
d) This product is certified as type of the portable device with FCC Rules. To maintain
compliance with RF Exposure requirement, please use within specification of this
product.
e) The antenna used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
f) This module can change the output power depending on the circumstances by the
application software which is developed by module installer. Any end user cannot
change the output power.
4) CE Regulatory Information
a) When your end product installs this module, it is required to proceed additional
certification processes before placing on the market in EU member states to make your
products fully comply with relative EU standards.
b) TAIYO YUDEN can provide you the test reports of conducted measurement portion for
the radio module. You can utilize the test reports for the certification processes of your
end product as it requires radio testing.
