TAKSTAR ELECTRONIC ML70DWTX WIRELESS HEADPHONE TRANSMITTER User Manual ML 70DW
GUANGDONG TAKSTAR ELECTRONIC CO., LTD. WIRELESS HEADPHONE TRANSMITTER ML 70DW
User Manual
ML 70DW
1
2
1
2
4
36
5
7
8
9
Guangdong Takstar Electronic Co., Ltd.
Address: Longqiao Road Longxi Boluo Huizhou Guangdong China 516100
Tel:86 752 6383644 Fax: 86 752 6383952
Email: sales@ takstar.com Website: www.takstar.com
User Manual
Dynamic silver plated and glossy UV painted earcups design
Innovative HID controlling directive supports long distance controlling of
music playing software on computers; the volume, previous song, next
song, playing and pause function of the music playing software on
computers can be controlled via the button on headphones
2.4G frequency band guarantees accurate sound reproduction and full-
duplex for supporting wireless chatting
Wireless operating range is up to 10 meters/360 degree in open area
Dyn-Elec technology features automatic sleep function for reducing
power consumption
Built-in rechargeable lithium ion battery, the continuous playtime is
about 9 hours when the battery is fully charged
Features
Welcome to use TAKSTAR new wireless headphones, it is specially designed
for fashion. It features high quality wireless transmission, stable digital
wireless headphones system, integrated volume and program controlling
and convenient folding design for ease of carrying. Please read this manual
detailedly before using to make sure the correct operation and exert the
optimum function.
Operation
Power on/off button: press this button continuously for about 3 seconds
for turning on/off the headphones
Power indicator
When the headphone is turned on, the indicator will light green;
When there’s no signal, the indicator will flicker every 500ms;
When pressing the ID button , the indicator will flicker every 150ms;
When the frequency of transmitter and receiver is matched, the
indicator will light green continuously;
When the system is at sleep state, the indicator will flicker every 5s;
When the system is at low power, the indicator will flicker every 1s;
When the system is under recharging, the indicator will light red
continuously;
When the recharging is finished, the indicator will be off
5
4
3
5
6
DC socket: plug one side of the USB power cable into this socket, and the
other side of the USB power cable into USB socket of computer(or mains
supply by adding the power adaptor to the USB cable) for recharging
the battery
Audio input/output socket: when the headphone is working at wireless
status, the audio signal can be connected to other headphones or other
audio equipment for sharing the music with your friends by plugging an
audio cable into the audio output socket; when the wireless function is
turned off, plug in audio playing equipment such as IPOD, MP3 or
computer into this socket with an audio cable, the headphone will be
used as a common wired headphone
ID button: plug the transmitter into USB socket of computer, then press
the ID button on headphones, the LED indicator on the left earcup will
flicker every 150ms. Make sure that the distance between the
transmitter and the headphones are within 50cm. When the LED
indicator lights green continuously, it means the frequency matching is
finished, the headphones can be used normally (The headphones and
transmitter in the same package are already matched during production,
no need to operate the frequency matching unless the headphone is
used together with a new transmitter, or the transmitter is used
together will a new headphone)
Previous song, next song and pause control knob: turn the knob to for
previous song; turn the knob to for next song, press the knob vertically
for playing or pause
Volume control: press VOL+ for in increasing the volume, press VOL- for
decreasing the volume
Adjustable headband
2.4G wireless transmitter: plug the transmitter into USB socket of
computer, the transmitter is at working status
ML 70DW headphones 1pc
2.4G wireless transmitter 1pc
Y-type audio cable 1pc
Power adaptor 1pc
USB power cable 1pc
USB extension cable 1pc
Portable bag 1pc
User manual 1pc
7
9
8
2
Standard Configuration
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The de
vice can be used in portable exposure condition without restriction.
