A08_VF695_User manual
Safety and
warranty
information
VF695
Product safety information
Pictograms and graphic symbols
Read the Safety & warranty information
guide
Do not use while re-fuelling
Do not use hand-held while driving
This device may produce a bright or flashing
light
When using the phone, make sure it is kept
at least 10 mm away from your head or body
Do not dispose of in a fire
Small parts may cause a choking hazard
Avoid contact with magnetic media
This device may produce a loud sound
Avoid extreme temperatures
Keep away from pacemakers and other
personal medical devices
Avoid contact with liquid, keep dry
Switch off when instructed in hospitals and
medical facilities
Do not try to disassemble
Switch off when instructed in aircraft and
airports
Do not rely on this device for emergency
communications
Switch off in explosive environments
Only use approved accessories
Product safety information
RADIO WAVES:
THIS MOBILE PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio-frequency
(RF) energy. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based
on standards that were developed by independent
scientific organizations through periodic and thorough
evaluation of scientific studies. These guidelines
include a substantial safety margin designed to ensure
the safety of all persons, regardless of age and health.
The exposure standard for mobile phones employs a
unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by public authorities
such as the Federal Communications Commission of
the US Government (FCC), or by Industry Canada, is 1.6
W/kg averaged over 1 gram of body tissue. Tests for
SAR are conducted using standard operating positions
with the mobile phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the mobile phone
while operating can be well below the maximum
value. This is because the mobile phone is designed to
operate at multiple power levels so as to use only the
power required to reach the network. In general, the
closer you are to a wireless base station antenna, the
lower the power output of the mobile phone. Before a
mobile phone model is available for sale to the public,
compliance with national regulations and standards
must be shown.
The highest SAR value for this model mobile phone
when tested is 0.79 W/Kg for use at the ear and
0.76 W/Kg for use close to the body.
While there may be differences between the SAR levels
of various mobile phones and at various positions, they
all meet the government requirement for RF exposure.
For body-worn operation, the mobile phone meets FCC
RF exposure guidelines provided that it is used with a
non-metallic accessory with the handset at least 10
mm from the body. Use of other accessories may not
ensure compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the
Cellular Telecommunications & Internet Association
(CTIA) Web site: http://www.ctia.org/
The World Health Organization (WHO) considers
that present scientific information does not indicate
the need for any special precautions for use of
mobile phones. If individuals are concerned, they
might choose to limit their own or their children’s
RF exposure by limiting the length of calls, or using
“hands-free” devices to keep mobile phones away
from the head and body. (fact sheet n°193). Additional
WHO information about electromagnetic fields and
public health are available on the following website:
http://www.who.int/peh-emf.
Note: This equipment has been tested and found
to comply with the limits for a Class B digital device
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/ TV
technician for help.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
For the receiver devices associated with the operation
of a licensed radio service (e.g. FM broadcast), they
bear the following statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the condition that this device
does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Your mobile phone is equipped with a built-in antenna.
For optimal operation, you should avoid touching it or
degrading it.
As mobile devices offer a range of functions, they can
be used in positions other than against your ear. In
such circumstances the device will be compliant with
the guidelines when used with headset or usb data
cable. If you are using another accessory ensure that
whatever product is used is free of any metal and that
it positions the mobile phone at least 10 mm away
from the body.
FCC ID: 2ACCJH014
Distraction
Driving
Full attention must be given to driving at all times
in order to reduce the risk of an accident. Using a
phone while driving (even with a hands free kit) causes
distraction and can lead to an accident. You must
comply with local laws and regulations restricting the
use of wireless devices while driving.
Operating machinery
Full attention must be given to operating machinery in
order to reduce the risk of an accident.
Product handling
General statement on handling and use
You alone are responsible for how you use your phone
and any consequences of its use.
You must always switch off your phone wherever the
use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users
and their environment.
• Always treat your phone and its accessories with
care and keep it in a clean and dust-free place.
• Do not expose your phone or its accessories to open
flames or lit tobacco products.
• Do not expose your phone or its accessories to
liquid, moisture or high humidity.
• Do not drop, throw or try to bend your phone or its
accessories.
• Do not use harsh chemicals, cleaning solvents, or
aerosols to clean the device or its accessories.
• Do not paint your phone or its accessories.
• Do not attempt to disassemble your phone or its
accessories, only authorised personnel must do so.
• Do not expose your phone or its accessories to
extreme temperatures, minimum -10 and maximum
+50 degrees Celsius.
• Please check local regulations for disposal of
electronic products.
• Do not carry your phone in your back pocket as it
could break when you sit down.
Small children
Do not leave your phone and its accessories within the
reach of small children or allow them to play with it.
They could hurt themselves or others, or could
accidentally damage the phone.
Your phone contains small parts with sharp edges that
may cause an injury or which could become detached
and create a choking hazard.
Demagnetisation
To avoid the risk of demagnetisation, do not allow
electronic devices or magnetic media close to your
phone for a prolonged time.
Electrostatic discharge (ESD)
Do not touch the SIM card’s metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal use position
When placing or receiving a phone call, hold your
phone to your ear, with the bottom towards your
mouth or as you would a fixed line phone.
Air bags
Do not place a phone in the area over an air bag or in
the air bag deployment area.
Store the phone safely before driving your vehicle.
Seizures/Blackouts
This phone is capable of producing bright flashing
lights.
Repetitive motion injuries
To minimise the risk of RSI, when texting or playing
games with your phone:
• Do not grip the phone too tightly.
• Press the buttons lightly.
• Make use of the special features in the handset
which minimise the number of buttons which have
to be pressed, such as message templates and
predictive text.
• Take lots of breaks to stretch and relax.
Emergency calls
This phone, like any wireless phone, operates using
radio signals, which cannot guarantee connection in
all conditions. Therefore, you must never rely solely on
any wireless phone for emergency communications.
Loud noise
This phone is capable of producing loud noises which
may damage your hearing. Prolonged exposure
to music at full volume on the music player may
damage the listener’s hearing. Use the recommended
headphones only.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your device
near your ear while the loudspeaker is in use.
Bright light
This phone is capable of producing flash of light or use
as a torch, do not use it too close to the eyes.
Phone heating
Your phone may become warm during charging and
during normal use.
Electrical safety
Accessories
Use only approved accessories.
Do not connect with incompatible products or
accessories.
Take care not to touch or allow metal objects, such
as coins or key rings, to contact or short-circuit the
battery terminals.
Connection to a car
Seek professional advice when connecting a phone
interface to the vehicle’s electrical system.
Faulty and damaged products
Do not attempt to disassemble the phone or its
accessories.
Only qualified personnel must service or repair the
phone or its accessories.
If your phone or its accessories have been submerged
in water, punctured, or subjected to a severe fall, do
not use them until you have taken it to be checked at
an authorised service centre.
Battery handling & safety
Always switch the device off and disconnect the
charger before removing the battery.
Only use the battery and charger supplied, or
manufacturer approved replacements intended for use
with your phone. Using other batteries and chargers
could be dangerous.
Do not disassemble or short-circuit the battery.
Accidental short-circuiting can occur if a metallic
object such as a key, paper clip, or pen touches the
terminals of the battery.
Improper battery use may result in a fire, explosion,
or other hazard. If you believe the battery has been
damaged, do not use it, take it to a service centre for
testing.
Interference
General statement on interference
Care must be taken when using the phone in close
proximity to personal medical devices, such as
pacemakers and hearing aids.
Pacemakers
Pacemaker manufacturers recommend that a
minimum separation of 15 cm be maintained between
a mobile phone and a pacemaker to avoid potential
interference with the pacemaker. To achieve this use
the phone on the opposite ear to your pacemaker and
do not carry it in a breast pocket.
Hearing aids
People with hearing aids or other cochlear implants
may experience interference noises when using
wireless devices or when one is nearby. The level
of interference will depend on the type of hearing
device and the distance from the interference source,
increasing the separation between them may reduce
the interference. You may also consult your hearing aid
manufacturer to discuss alternatives.
Medical devices
Please consult your doctor and the device
manufacturer to determine if operation of your phone
may interfere with the operation of your medical
device.
Hospitals
Switch off your wireless device when requested to do
so in hospitals, clinics or health care facilities. These
requests are designed to prevent possible interference
with sensitive medical equipment.
Aircraft
Switch off your wireless device whenever you are
instructed to do so by airport or airline staff.
Consult the airline staff about the use of wireless
devices on board the aircraft, if your device offers a
‘flight mode’ this must be enabled prior to boarding
an aircraft.
Interference in cars
Please note that because of possible interference to
electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles unless
a handsfree kit with an external antenna is included in
the installation.
Explosive environments
Petrol stations and explosive atmospheres
In locations with potentially explosive atmospheres,
obey all posted signs to turn off wireless devices such
as your phone or other radio equipment.
Areas with potentially explosive atmospheres include
fuelling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air
contains chemicals or particles, such as grain, dust, or
metal powders.
Blasting caps and areas
Turn off your mobile phone or wireless device when
in a blasting area or in areas posted with notifications
requesting "two-way radios" or "electronic devices" are
turned off to avoid interfering with blasting operations.
Protection against theft (1)
Your telephone is identified by an IMEI (phone serial
number) shown on the packaging label and in the
product’s memory. We recommend that you note
the number the first time you use your telephone by
entering * # 0 6 # and keep it in a safe place. It may
be requested by the police or your operator if your
telephone is stolen. This number allows your mobile
telephone to be blocked preventing a third person
from using it, even with a different SIM card.
Battery
Please note your phone is a unibody device, the battery
is not removable. Observe the following precautions:
- Do not attempt to eject, replace and open battery,
- Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C.
Phone and battery as a unibody device must be
disposed of in accordance with locally applicable
environmental regulations.
This symbol on your telephone, the battery
and the accessories means that these
products must be taken to collection points
at the end of their life:
- Municipal waste disposal centres with
specific bins for these items of equipment.
- Collection bins at points of sale.
(1) Contact your network operator for service availability.
They will then be recycled, preventing substances
being disposed of in the environment, so that their
components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these
collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be
thrown into ordinary bins if your jurisdiction or your
region has suitable recycling and collection facilities;
instead they are to be taken to collection points for
them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
Licences
microSD Logo is a trademark.
The Bluetooth word mark and logos
are owned by the Bluetooth SIG, Inc.
and any use of such marks by TCL
Communication Ltd. and its affiliates
is under license. Other trademarks and
trade names are those of their respective
owners.
VF695 Bluetooth
Declaration
ID D023681
The Wi-Fi Logo is a certification mark of
the Wi-Fi Alliance.
Google, the Google logo, Android, the
Android logo, Google Search TM, Google
MapsTM, Gmail TM, YouTube, Google Play
Store, Google Latitude TM and Hangouts
TM are trademarks of Google Inc.
The Android robot is reproduced or modified from work
created and shared by Google and used according
to terms described in the Creative Commons 3.0
Attribution License (the text will show when you touch
and hold Google legal in Settings > About phone >
Legal information) (1).
(1) This may not be available depending on your country.
General information
You have purchased a product which uses the open
source (http://opensource.org/) programs mtd,
msdosfs, netfilter/iptables and initrd in object code
and other open source programs licensed under the
GNU General Public License and Apache License.
We will provide you with a complete copy of the
corresponding source codes upon request within a
period of three years from the distribution of the
product.
You may download the source codes from
http://www.vodafone.com/devices/Smartfirst. The
provision of the source code is free of charge from
the internet.
Your telephone is a transceiver that operates on GSM
in quad-band (850/900/1800/1900 MHz) or UMTS in
dual-band (900/2100 MHz).
This equipment is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC. The entire copy of the Declaration of
Conformity for your telephone can be obtained
through our website: http://www.vodafone.com/
devices/Smartfirst.
Notice
The information in this manual is subject to change
without notice.
Every effort has been made in the preparation of
this manual to ensure accuracy of the contents, but
all statements, information, and recommendations in
this manual do not constitute a warranty of any kind,
expressed or implied. Read the safety precautions and
safety information carefully to ensure that you use this
wireless device in a correct and safe manner.
TCL Communication Ltd.
Room 1910-12A, Tower 3, China HK City, 33 Canton
Road, Tsimshatsui, Kowloon, Hong Kong
Warranty information
WARRANTY TERMS AND CONDITIONS
1. Vodafone undertakes the warranty of this mobile
phone for a period of two (2) years from the date
of purchase by the original owner (not transferable)
under normal use.
2. The battery has a limited warranty for twelve (12)
months, and charger for twenty-four (24) months
against manufacturing defects. Other accessories
have a limited warranty for twenty-four (24) months
against manufacturing defects.
3. This warranty does not cover damage resulting
from:
a) Normal wear & tear of the equipment;
b) Defects and damages due to the equipment
being used other than its normal and customary
manner;
c) An unauthorised disassembly, repair, alteration or
modification being carried out;
d) Misuse, abuse, negligence or accident howsoever
caused;
e) Defects or damage arising from improper testing,
operation, maintenance, installation, or any
alteration or modification;
f) Defects or damage due to spillage of food
or liquids, corrosion, rust or the use of wrong
voltage;
g) Scratches or damage to plastic surfaces and all
other externally exposed parts that are due to
normal customer use;
4. If this phone needs service or repair, it must be
delivered at the user's cost.
5. This warranty will be null and void in any of the
following events:
a) If the serial number or warranty seal on the
equipment has been defaced or removed.
b) If any term contained in this warranty has been
altered or modified in any way without prior
written consent of Vodafone.
6. This limited warranty extends only to customers who
purchase the product and is only valid in Vodafone’s
intended country (or area) of sale of the product.
7. If the product is returned to Vodafone after the
expiration of the warranty period, Vodafone’s normal
service policies shall apply and the consumer will
be charged accordingly.
a) Vodafone neither assumes for it any other
obligation or liability beyond that which is
expressly provided for in this limited warranty.
b) All warranty information, product features and
specifications are subject to change without
notice.
8. THIS WARRANTY IS IN LIEU OF ANY AND
OTHER WARRANTIES EXPRESSED OR IMPLIED,
SPECIFICALLY INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILlTY OR FITNESS FOR A
PARTICULAR PURPOSE. VODAFONE ASSUMES NO
LIABILITY FOR THE BREACH OF THE WARRANTY
BEYOND CORRECTING THE BREACH IN THE
MANNER DESCRIBED ABOVE. IN NO EVENT SHALL
VODAFONE BE LIABLE FOR CONSEQUENCES.
© Vodafone Group 2015. Vodafone and the
Vodafone logos are trade marks of Vodafone Group.
Any product or company names mentioned herein
may be the trade marks of their respective owners.
CQA287AVDAAA
