TCL Communication H055 HSUPA/HSDPA/UMTS triple band /GSM quad band mobile phone User Manual

English - CJB28HBALAAA

Quick Start Guide

Thank you for choosing ALCATEL. This booklet helps you get started with your new. For more

information about how to use, please go to www.alcatelonetouch.us for complete user manual.

BC

A466BG

1

1 Your mobile ��

1�1 Keys and connectors

Headset connector

Touch screen

Home key

Back key

Recents key

Micro-USB Connector

Power key

Volume key

www.sar-tick.com

This product meets applicable national SAR limits of 1.6 W/kg. The specific

maximum SAR values can be found on page 32 of this user guide.

When carrying the product or using it while worn on your body, either

use an approved accessory such as a holster or otherwise maintain a

distance of 10 mm from the body to ensure compliance with RF exposure

requirements. Note that the product may be transmitting even if you are

not making a phone call.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume levels for

long periods. Exercise caution when holding your device near your ear while the

loudspeaker is in use.

Table of contents

1 Your mobile �� 1

2 Text input�� 12

3 Phone call�� 13

4 Contacts �� 15

5 Messaging �� 16

6 Email �� 17

7 Getting connected �� 18

8 Find my location using GPS satellites �� 20

9 Data backup �� 20

10 Factory data reset �� 21

11 Applications & Internal storage �� 21

12 Making the most of your phone �� 22

Safety and use �� 23

2 3

Camera

Back key

• Touch to go back to the previous screen, or to close a dialog box, options menu, the

notification panel, etc.

Home key

• While on any application or screen, touch to return to the Home screen.

Recents key

• Touch and hold to open a list of thumbnail images of apps you've worked with recently.

Power key

• Press: Lock the screen/Light up the screen.

• Press and hold: Generate a pop up menu providing more options: Restart, Power

off, Airplane mode�

• Press the Power key for more than 15 seconds to restart.

• Press the Power key to light up the screen when it dims during a call.

• Press the Power key and Volume up key to reset if the phone is off.

• Press the Power key and Volume down key to capture a screenshot while the

device is on.

Volume Keys

• In call mode, adjusts the earpiece or headset volume.

• In Music/Video/Streaming mode, adjusts the media volume.

• In general mode, adjusts the ringtone volume.

• Mutes the ringtone of an incoming call.

4 5

1�2 Getting started

1�2�1 Set-up

Removing and installing the back cover

Installing and removing the micro SD card

Insert the micro SD card with golden contact facing downwards into the slot. Slide it out to remove

the micro SD card.

To avoid data loss and SD card damage, before removing the SD card, please ensure that

the SD card is unmounted (Settings\Storage\Unmount SD card).

Installing and removing the battery

• To install, insert and click the battery into place, then close the phone cover.

• To remove the battery, first power the phone off. Then unclip the cover and remove the battery.

Charging the battery

Connect the battery charger to your phone and main socket respectively.

To reduce power consumption and energy waste, once the battery is fully charged,

disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-

running applications when not in use; reduce the backlight time, etc.

1�2�2 Power on your phone

Hold down the Power key until the phone powers on.

Set up your phone for the first time

The first time you power on the phone, you should set the following options: language, input method,

data connection, etc.

Even if no SIM card is installed, your phone will still power on and you will be able to connect to a

Wi-Fi network, sign into your Google account and use some of the phone's features.

1�2�3 Power off your phone

Hold down the Power key from the Home screen until the phone options appear, select Power off.

6 7

Slide/Swipe

Slide the screen to scroll up and down the applications, images, web pages… at your convenience.

The device also supports one finger zoom in (Message, Browser, Email and Gallery) by double tapping

the screen then slide with one finger to zoom in/out).

Flick

Similar to swiping, but flicking makes it move quicker.

Pinch/Spread

Place your fingers of one hand on the screen surface and draw them apart or together to scale an

element on the screen.

Rotate

Automatically change the screen orientation from portrait to landscape by turning the phone

sideways.

1�3�2 Status bar

From the status bar, you can view both phone status and notification information.

1�3 Home screen

You can bring all the items (applications, shortcuts, folders and widgets) you love or use most

frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen.

Status bar

• Status/Notification indicators

• Touch and drag down to open the notification

panel.

Touch an icon to open an application, folder, etc.

Application tab

• Touch to enter application list.

Favorite tray applications

• Touch to enter the application.

• Touch and hold to move applications.

Slide left or right to view other panels on the

Home screen.

The Home screen is provided in an extended format to allow more space for adding applications,

shortcuts etc. Slide the Home screen horizontally left and right to get a complete view.

1�3�1 Using the touchscreen

Touch

To access an application, touch it with your finger.

Touch and Hold

To enter the available options for an item, touch and hold the item. For example, select a contact in

Contacts, touch and hold this contact, an options list will then appear on screen.

Drag

Place your finger on the screen to drag an object to another location.

8 9

Status icons

GPRS connected Roaming

GPRS in use No signal

EDGE connected No SIM card installed

EDGE in use Vibrate mode

Signal strength Ringer is silenced

Wi-Fi is on Phone microphone is mute

Connected to a Wi-Fi network Battery is very low

Bluetooth is on Battery is low

Connected to a Bluetooth device Battery is partially drained

Airplane mode Battery is full

Alarm is set Battery is charging

Speakerphone is on Headset connected

Notification icons

New Gmail message Call forwarding is on

New Email message Song is playing

New text or multimedia message Connected to VPN

Problem with SMS or MMS delivery Disconnected from VPN

New Google Hangouts message Radio is on

New voicemail Uploading data

Upcoming event Downloading data

Screenshot error Download finished

Screenshot captured Select input method

Preparing SD card Phone is connected via USB cable

An open Wi-Fi network is available System update available

Carrier data use threshold approaching

or exceeded GPS is on

Missed call GPS is off

10 11

Touch and drag down the Status bar to open the Notification panel or Quick setting panel. Touch and

drag up to close it. When there are notifications, you can touch them to access notifications directly.

Notification panel

When there are notifications, touch and drag down the Status bar to open the Notification panel to

read the detailed information.

Touch to clear all event–based notifications

(other ongoing notifications will remain).

Touch to access the Quick settings bar

Touch to drag downwards twice to access

the Quick settings bar

Quick setting panel

Touch and then the Settings icon to access Settings. to open the Quick setting panel, where

you can enable or disable functions or change modes by touching the icons.

Quick settings bar

Touch icons to enable/disable functions or to

change models.

Touch to access Settings, where you can set

more items.

1�3�3 Search bar

The phone provides a Search function which can be used to locate information within applications,

the phone or the web.

1�3�4 Lock/Unlock your screen

To protect your phone and privacy, you can lock the phone screen by creating a variety of patterns,

PINs or passwords etc.

1�3�5 Personalize your Home screen

Add

You can touch and hold a folder, an application or a widget to activate the Move mode, and drag the

item to any Home screen as you prefer.

Reposition

Touch and hold the item to be repositioned to activate the Move mode, drag the item to the desired

position and then release. You can move items both on the Home screen and the Favorite tray. Hold

the icon on the left or right edge of the screen to drag the item to another Home screen.

Remove

Touch and hold the item to be removed to activate the Move mode, drag the item up to the top of the

Remove icon, and release after the item turns red.

Create folders

To improve the organization of items (shortcuts or applications) on the Home screen and the Favorite

tray, you can add them to a folder by stacking one item on top of another. To rename a folder, open

it and touch the folder’s title bar to input the new name.

Wallpaper customization

Touch the Menu key on the Home screen then touch Wallpaper to customize wallpaper.

1�3�6 Volume adjustment

You can set the ringer, media and phone ringtone volumes to your preference by pressing the Volume

up/down key, or touching Settings\Sound & notification to set the volume.

12 13

2 Text input ��

2�1 Using Onscreen Keyboard

Onscreen keyboard settings

Touch the Menu key from the Home screen, select Settings/Language & input/ Android Keyboard

and a series of settings will become available for your selection.

2�1�1 Android keyboard

Touch to switch to the

symbol and numeric

keyboard.

Touch to type text

or numbers.

Long press,

then select to

enter symbols/

emoticons

Touch to switch "abc/Abc"

mode; Touch & hold to switch

"abc/ABC" mode.

2�2 Text editing

You can edit the text you have entered.

• Touch and hold within the text you would like to edit.

• Drag the tabs to change the highlighted selection.

• The following options will show: CUT, COPY, SHARE.

• Touch the icon to discard.

3 Phone call ��

3�1 Placing a call

You can easily launch a call using Phone. Touch the Application tab from the Home screen and

select Call.

Touch and hold to

access voicemail.

Display the suggested

number(s).

Enter the desired number from the keyboard directly or select a contact from Contacts or Call log

then touch to place the call.

The number you entered can be saved to Contacts by touching Create new contact icon .

If you make a mistake, you can delete the incorrect digits by touching .

To hang up a call, touch .

14 15

3�2 Answering or rejecting a call

When you receive a call:

• Slide the icon to the right to answer;

• Slide the icon to the left to reject;

• Slide the icon upwards to reject the call by sending a preset message.

To mute the ringtone volume of an incoming call, press the Volume up/down key.

3�3 Consulting your call log

You can access your call log by touching from the Dial screen to view call history in categories

of Missed calls, Outgoing calls and Incoming calls.

4 Contacts ��

You can view and create contacts on your phone and synchronize these with your Gmail contacts or

other applications on the web or on your phone.

4�1 Adding a contact

Touch the Application tab on the Home screen, select Contacts, then touch the icon .

4�2 Importing, exporting and sharing contacts

From the Contacts screen, touch the Menu key to open the options menu, then touch Import/Export.

To import/export a contact to your SIM card, select the contact you want to import/export, then touch

OK to confirm or CANCEL to quit.

You can share a single contact or contacts with others by sending the contact's vCard to them via

Bluetooth, Gmail, etc.

Touch the contact you want to share, touch the Menu key and Share from the contact details screen,

then select the application to perform this action.

4�3 Synchronizing contacts in multiple accounts

Contacts, data or other information can be synchronized from multiple accounts, depending on the

applications installed on your phone.

16 17

5 Messaging ��

You can create, edit and receive SMS and MMS with this phone.

To access this feature, touch the Application tab from the Home screen, then select Messaging.

To consult messages stored in your SIM card, touch the Menu key from the Messaging

screen, then touch Settings\Text messages (SMS)\Multimedia message (MMS)�

5�1 Write message

On the message list screen, touch the new message icon to write text/multimedia messages.

• Touch to view the whole message thread.

• Touch & hold to activate delete mode.

Touch to create a new message

Touch to search in all messages.

Sending a text message

Enter the mobile phone number of the recipient in the Type name or number bar or touch to add

recipients; then touch the Type text message bar to type the text of the message. When finished,

touch to send the text message.

An SMS of more than 160 characters will be charged as several SMS. Specific letters

(accent) will also increase the size of the SMS, this may cause multiple SMS to be sent to

your recipient.

Sending a multimedia message

MMS enables you to send video clips, images, photos, animations, slides and sounds to other

compatible phones and e-mail addresses.

An SMS will be converted to MMS automatically when media files (image, video, audio, slides, etc.)

are attached or Subject or email addresses added.

6 Email��

Besides your Gmail account, you can also set up external POP3, IMAP or Exchange email accounts

in your phone.

To access this feature, touch the Application tab from the Home screen, then select Email.

An email wizard will guide you through the steps to set up an email account.

• Enter the email address and password of the account you want to set up.

• Touch Next. If the account you entered is not provided by your service provider in the phone,

you will be prompted to go to the email account settings screen to enter settings manually.

Alternatively, you can touch Manual setup to directly enter the incoming and outgoing settings

for the email account you are setting up.

• Finish Account settings of Email checking frequency, notification, synchronizing, etc.

• Enter the account name and display name in outgoing emails.

To add another email account, you can touch the Menu key and Settings. Touch ADD ACCOUNT on

the right of the title to create it.

To create and send emails

• Touch the icon and then Compose from the Inbox screen.

• Enter recipient(s) email address(es) in the To field.

• If necessary, touch the Menu key and touch Add Cc/Bcc to add a copy or a blind carbon copy

to the message.

• Enter the subject and the content of the message.

• Touch and Attach file to add an attachment.

• Finally, touch to send�

• If you do not want to send the mail right away, you can touch the Menu key and Save draft or

touch the Back key to save a copy.

18 19

7 Getting connected��

To connect to the Internet with this phone, you can use GPRS/EDGE/UMTS networks or Wi-Fi,

whichever is more convenient.

7�1 Connecting to the Internet

7�1�1 GPRS/EDGE/UMTS

The first time you turn on your phone with your SIM card inserted, it will automatically configure your

network service: GPRS/EDGE/UMTS.

To check the network connection you are using, touch the Menu key from the Home screen, then

touch Settings\More\Mobile networks, and touch Access Point Names or Network operators.

7�1�2 Wi-Fi

Using Wi-Fi, you can connect to the Internet when your phone is within the range of a wireless

network. Wi-Fi can be used on your phone even without a SIM card inserted.

To turn Wi-Fi on and connect to a wireless network

• Touch the Menu key from the Home screen, then touch Settings and select Wi-Fi.

• Touch the switch beside Wi-Fi to turn Wi-Fi on or off.

• Touch Wi-Fi. The detailed information of detected Wi-Fi networks is displayed in the Wi-Fi

networks section.

• Touch a Wi-Fi network to connect. If the network you selected is secured, you are required to enter

a password or other credentials (you can contact the service provider for details). When finished,

touch CONNECT.

7�2 Browser ��

Using the Browser, you can enjoy surfing the Web.

To access this feature, touch the Application tab from the Home screen, then select Browser.

To go to a web page

On the Browser screen, touch the URL box at the top, enter the address of the web page, then

confirm.

7�3 Connecting to a computer (1)

With the USB cable, you can transfer media files and other files between your micro SD card/internal

storage and the computer.

To connect/disconnect your phone to the computer:

To connect:

• Use the USB cable that came with your phone to connect the phone to a USB port on your

computer. You will receive a notification that the USB is connected.

• Open the Notification panel and touch USB connected.

• Touch Mount in the dialog that opens if you want to transfer files.

To disconnect (for mass storage):

• Open the Notification panel and touch USB connected.

• Touch Turn off in the dialog that opens to cancel USB mass storage.

Before using MTP, make sure that the driver (Windows Media Player 11 or higher version)

has been installed.

To locate data you have transferred or downloaded in your micro SD card:

• Touch to open the applications list.

• Touch File Manager.

All data you have downloaded is stored in the File Manager, where you can view media files (videos,

photos, music and others), rename files, install applications into your phone, etc.

(1) You can change your default connection mode via Settings\Storage & USB. Some

operations which are available under mass storage are not usable under MTP and PTP.

20 21

8 Find my location using GPS satellites

To activate your phone’s global positioning system (GPS) satellite receiver:

• Touch the Menu key from the Home screen.

• Touch Settings\Location.

• Touch the switch beside Location to turn on.

You can then open Maps to find your location:

Use your phone’s GPS satellite receiver to pinpoint your location within an accuracy as close as

several meters (“street level”). The process of accessing the GPS satellite and setting your phone's

precise location for the first time will require up to 5 minutes. You will need to stand in a place with

a clear view of the sky and avoid moving. After this, GPS will only need 20-40 seconds to identify

your precise location.

9 Data backup ��

This phone enables you to back up your phone’s settings and other application data to Google

Servers, with your Google account.

If you replace your phone, the settings and data you’ve backed up are restored onto the new phone

the first time you sign in with your Google account.

To activate this function:

• Touch the Menu key from the Home screen.

• Touch Settings\Backup & reset\Back up my data.

When this function is activated, a wide variety of settings and data is backed up, including your

Wi-Fi passwords, bookmarks, a list of the applications you’ve installed, the words you’ve added to

the dictionary used by the onscreen keyboard, and most of the settings that you configure with the

Settings application. If you deactivate this option, you stop backing up your settings, and any existing

backups are deleted from Google Servers.

10 Factory data reset ��

To activate factory data reset:

• Touch the Menu key from the Home screen.

• Touch Settings\Backup & reset\Factory data reset�

• Touch the RESET PHONE.

Resetting the phone will erase all of your personal data from internal phone storage, including

information about your Google account, any other accounts, your system and application settings,

and any downloaded applications. If you reset the phone in this way, you’re prompted to re-enter the

same kind of information as when you first started Android.

When you are unable to power on your cellphone, there is another way to perform a factory data

reset by pressing the Power key and the Volume up key at the same time until the screen lights up.

11 Applications & Internal storage ��

11�1 Applications

With this phone, some built-in Google applications and other third party applications are available

for your convenience.

With the built-in applications, you can

• Communicate with friends.

22 23

• Exchange messages or emails with friends.

• Track your location, view traffic situations, search for locations and get navigation information

to your destination.

• Download more applications from Google Play Store and more.

For more information about these applications, please check the online user manual at: www.

alcatelonetouch.us.

11�2 Internal storage

Touch Settings\Storage & USB to display the amount of internal phone storage used by the

operating system, its components, applications (including those you downloaded), permanent and

temporary data.

If a warning message comes up saying that phone memory is limited, you are required to

free up space by deleting some unwanted applications, downloaded files, etc.

12 Making the most of your phone ��

12�1 FOTA Upgrade

Using the FOTA Upgrade tool you can update your phone's software.

To access System update, please touch the Menu key from the Home screen, then Settings\

About phone\System updates. Touch Check for updates, and the phone will search for the latest

software. If you want to update the system, please touch the button Download, after it is done

please touch Install to complete the upgrade. Now your phone will have the latest software version.

You should turn on data connection or connect through Wi-Fi before searching for updates.

Safety and use ��

Please read before using your phone

THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE PHONE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE THE DEVICE.

Privacy restrictions

Some countries require full disclosure of recorded telephone conversations, and stipulate that

you must inform the person with whom you are speaking that the conversation is being recorded.

Always obey the relevant laws and regulations of your country when using the recording feature

of your phone.

Disclaimers

ANY WEATHER, STOCK, OR OTHER INFORMATION, DATA, OR DOCUMENTATION (“ACCESSED

INFORMATION”) ARE PROVIDED “AS IS” AND WITHOUT ANY WARRANTY OR ANY TECHNICAL SUPPORT.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, TCL MOBILE AND ITS AFFILIATES

expressly disclaim any and all representations and warranties, arising by law or otherwise, related

to the Accessed Information, including without limitation any express or implied representation or

warranty of merchantability, fitness for a particular purpose, non-infringement, quality, accuracy,

completeness, effectiveness, reliability, or usefulness. Without limiting the foregoing, it is further

understood that TCL Mobile and its Affiliates are not responsible for any use of the Accessed

Information or the results arising from such use, and that you use such information at your own risk.

Limitation of damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TCL MOBILE

OR ITS AFFILIATES BE LIABLE TO YOU, ANY USER, OR THIRD PARTY FOR ANY INDIRECT, SPECIAL,

CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, ARISING IN CONTRACT, TORT,

OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL,

LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS, REGARDLESS OF

THE FORESEEABILITY THEREOF OR WHETHER TCL MOBILE OR ITS AFFILIATES HAVE BEEN ADVISED

OF THE POSSIBILITY OF SUCH DAMAGES. AND IN NO EVENT SHALL THE TOTAL LIABILITY OF TCL

MOBILE OR ITS AFFILIATES EXCEED THE AMOUNT RECEIVED FROM YOU, REGARDLESS OF THE LEGAL

THEORY UNDER WHICH THE CAUSE OF ACTION IS BROUGHT. THE FOREGOING DOES NOT AFFECT ANY

STATUTORY RIGHTS WHICH MAY NOT BE DISCLAIMED.

24 25

Important health information and safety precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities

and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating

instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the

following precautions.

WARNING: This product contains chemicals known to the state of California to cause

cancer and birth defects or other reproductive harm.

Electrical safety

This product is intended for use when supplied with power from the designated battery or power

supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

Safety precautions for proper grounding installation

CAUTION: Connecting to improperly grounded equipment can result in an electric shock to your

device.

This product is equipped with a USB Cable for connecting with desktop or notebook computer. Be

sure your computer is properly grounded (earthed) before connecting this product to the computer.

The power supply cord of a desktop or notebook computer has an equipment-grounding conductor

and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed

and grounded in accordance with all local codes and ordinances.

Safety precautions for power supply unit

 Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings

label. If you are not sure of the type of power source required, consult your authorized service

provider or local power company. For a product that operates from battery power or other sources,

refer to the operating instructions that are included with the product. This product should be operated

only with the following designated power supply unit(s).

Travel charger: Input: 100-240 V, 50/60 Hz, 130/150 mA

Output: 5 V, 550mA

 Handle battery packs carefully

This product contains a Lithium-ion polymer or Lithium-ion battery. There is a risk of fire and burns

if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not

disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose

a battery pack to temperatures higher than 140˚F (60˚C) .

WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or

burns, do not disassemble, crush, puncture, short external contacts, expose to

temperature above 140˚F (60˚C), or dispose of in fire or water. Replace only with specified

batteries. Recycle or dispose of used batteries according to the local regulations or

reference guide supplied with your product.

NOTE: This product should be operated only with the following designated Battery Pack(s).

Battery: Lithium 1500mAh (TLi015M1/ CAB1500046C1)

 Take extra precautions

• Keep the battery or device dry and away from water or any liquid as it may cause a short circuit.

• Keep metal objects away so they don’t come in contact with the battery or its connectors as it may

lead to short circuit during operation.

• The phone should only be connected to products that bear the USB-IF logo or have completed the

USB-IF compliance program.

• Do not use a battery that appears damaged, deformed, or discolored, or the one that has any rust

on its casing, overheats, or emits a foul odor.

• Always keep the battery out of the reach of babies and small children, to avoid swallowing of the

battery. Consult the doctor immediately if the battery is swallowed.

• Only use the battery with a charging system that has been qualified with the system per this

standard, IEEE-Std-1725-2011. Use of an unqualified battery or charger may present a risk of fire,

explosion, leakage or other hazard.

• Replace the battery only with another battery that has been qualified with the system per this

standard, IEEE-Std-1725-2011. Use of an unqualified battery may present a risk of fire, explosion,

leakage or other hazard.

• Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard

surface, and the user suspects damage, take it to a service center for inspection.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin or clothing. If already in contact, flush

the affected area immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes. If already in contact, DO NOT rub;

rinse with clean water immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire as there is a danger of ignition

or explosion.

26 27

Safety precautions for direct sunlight

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product

or its battery inside a vehicle or in places where the temperature may exceed 140˚F (60˚C), such

as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong

ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or

pose a risk to the vehicle.

Prevention of hearing loss

CAUTION: Permanent hearing loss may occur if earphones or headphones are used at high volume

for prolonged periods of time.

Safety in aircraft

Due to the possible interference caused by this product to an aircraft’s navigation system and its

communications network, using this device’s phone function on board an airplane is against the law

in most countries. If you want to use this device when on board an aircraft, remember to turn off your

phone by switching to Airplane Mode.

Environment restrictions

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are

in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below

deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air

contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in

such areas could cause an explosion or fire resulting in bodily injury or even death.

Explosive atmospheres

When in any area with a potentially explosive atmosphere or where flammable materials exist, the

product should be turned off and the user should obey all signs and instructions. Sparks in such areas

could cause an explosion or fire resulting in bodily injury or even death.

Users are advised not to use the equipment at refueling points such as service or gas stations,

and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots,

chemical plants, or where blasting operations are in progress. Areas with a potentially explosive

atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on

boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or

particles, such as grain, dust, or metal powders.

Road safety

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a

phone while driving (even with a hands free kit) causes distraction and can lead to an accident. You

must comply with local laws and regulations restricting the use of wireless devices while driving.

Safety precautions for RF exposure

 Avoid using your phone near metal structures (for example, the steel frame of a building).

 Avoid using your phone near strong electromagnetic sources, such as microwave ovens, sound

speakers, TV and radio.

 Use only original manufacturer-approved accessories, or accessories that do not contain any metal.

 Use of non-original manufacturer-approved accessories may violate your local RF exposure

guidelines and should be avoided.

Interference with medical equipment functions

This product may cause medical equipment to malfunction. The use of this device is forbidden in

most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine

if they are adequately shielded from external RF energy. Your physician may be able to assist you

in obtaining this information.

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct

you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to

external RF energy.

Nonionizing radiation

Your device has an internal antenna. This product should be operated in its normal-use position

to ensure the radiative performance and safety of the interference. As with other mobile radio

transmitting equipment, users are advised that for satisfactory operation of the equipment and for

the safety of personnel, it is recommended that no part of the human body be allowed to come too

close to the antenna during operation of the equipment.

Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair

call quality and damage the phone, causing loss of performance and SAR levels exceeding the

recommended limits as well as result in non-compliance with local regulatory requirements in

your country.

To assure optimal phone performance and ensure human exposure to RF energy is within the

guidelines set forth in the relevant standards, always use your device only in its normal-use position.

Contact with the antenna area may impair call quality and cause your device to operate at a higher

power level than needed. Avoiding contact with the antenna area when the phone is IN USE optimizes

the antenna performance and the battery life.

Electrical safety

 Accessories

• Use only approved accessories.

• Do not connect with incompatible products or accessories.

• Take care not to touch or allow metal objects, such as coins or key rings, to contact or short-circuit

the battery terminals.

 Connection to a car

28 29

• Seek professional advice when connecting a phone interface to the vehicle electrical system.

 Faulty and damaged products

• Do not attempt to disassemble the phone or its accessory.

• Only qualified personnel must service or repair the phone or its accessory.

General precautions

You alone are responsible for how you use your phone and any consequences of its use. You must

always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject

to safety measures designed to protect users and their environment.

 Avoid applying excessive pressure to the device

Do not apply excessive pressure on the screen and the device to prevent damaging them and remove

the device from your pants’ pocket before sitting down. It is also recommended that you store the

device in a protective case and only use the device stylus or your finger when interacting with the

touch screen. Cracked display screens due to improper handling are not covered by the warranty.

 Device getting warm after prolonged use

When using your device for prolonged periods of time, such as when you’re talking on the phone,

charging the battery or browsing the Web, the device may become warm. In most cases, this

condition is normal and therefore should not be interpreted as a problem with the device.

 Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product

yourself. Service needed on components inside the device should be done by an authorized service

technician or provider.

 Protect your phone

• Always treat your phone and its accessories with care and keep them in a clean and dust-free place.

• Do not expose your phone or its accessories to open flames or lit tobacco products.

• Do not expose your phone or its accessories to liquid, moisture or high humidity.

• Do not drop, throw or try to bend your phone or its accessories.

• Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its accessories.

• Do not paint your phone or its accessories.

• Do not attempt to disassemble your phone or its accessories, only authorised personnel must do so.

• Do not expose your phone or its accessories to extreme temperatures, maximum 140°F (60°C).

• Please check local regulations for disposal of electronic products.

• Do not carry your phone in your back pocket as it could break when you sit down.

 Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician

or provider under the following conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the operating instructions.

 Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

 Avoid wet areas

Never use the product in a wet location.

 Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity

ranges, condensation may form on or within the device. To avoid damaging the device, allow

sufficient time for the moisture to evaporate before using the device.

NOTICE: When taking the device from low-temperature conditions into a warmer environment or

from high-temperature conditions into a cooler environment, allow the device to acclimate

to room temperature before turning on power.

 Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings

are provided for ventilation. These openings must not be blocked or covered.

 Air bags

Do not place a phone in the area over an air bag or in the air bag deployment area. Store the phone

safely before driving your vehicle.

 Mounting accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the

product should follow the manufacturer’s instructions, and should use a mounting accessory

recommended by the manufacturer.

 Avoid unstable mounting

Do not place the product with an unstable base.

 Use product with approved equipment

This product should be used only with personal computers and options identifified as suitable for

use with your equipment.

 Adjust the volume

Turn down the volume before using headphones or other audio devices.

 Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

30 31

 Small children

Do not leave your phone and its accessories within the reach of small children or allow them to play

with it. They could hurt themselves or others, or could accidentally damage the phone. Your phone

contains small parts with sharp edges that may cause an injury or which could become detached

and create a choking hazard.

 Repetitive motion injuries

To minimise the risk of RSI, when Texting or playing games with your phone:

• Do not grip the phone too tightly

• Press the buttons lightly

• Make use of the special features in the handset which minimize the number of buttons which have

to be pressed, such as message templates and predictive text.

• Take lots of breaks to stretch and relax.

 Operating machinery

Full attention must be given to operating the machinery in order to reduce the risk of an accident.

 Loud noise

This phone is capable of producing loud noises which may damage your hearing.

 Emergency calls

This phone, like any wireless phone, operates using radio signals, which cannot guarantee

connection in all conditions. Therefore, you must never rely solely on any wireless phone for

emergency communications.

Regulatory agency identifications

For regulatory identification purposes, your product is assigned a model number of A466BG. To

ensure continued reliable and safe operation of your device, use only the accessories listed below

with your A466BG device.

Operating temperature range: 32°F to 104°F (0°C to 40°C)

NOTE: This product is intended for use with a certified Class Limited Power Source, rated 4.35 Volts

DC, maximum 1 Amp power supply unit.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

 Consult the dealer or an experienced radio or television technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Important Note

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. End users must follow the specific operating instructions for satisfying RF exposure

compliance. To maintain compliance with FCC RF exposure compliance requirements, please follow

operation instruction as documented in this manual.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter, except the transmitters built-in with the device.

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT

Docket 01- 09 modified the exception of wireless phones under the Hearing Aid Compatibility Act

of 1988 (HAC Act) to require digital wireless phones be compatible with hearing-aids. The intent of

the HAC Act is to ensure reasonable access to telecommunications services for persons with hearing

disabilities. While some wireless phones are used near some hearing devices (hearing aids and

cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices

are more immune than others to this interference noise, and phones also vary in the amount of

interference they generate. The wireless telephone industry has

developed a rating system for wireless phones, to assist hearing

device users find phones that may be compatible with their hearing

devices. Not all phones have been rated. Phones that are rated have

the rating on their box or a label located on the box. The ratings

are not guarantees. Results will vary depending on the user’s

hearing device and hearing loss. If your hearing device happens to

be vulnerable to interference, you may not be able to use a rated

phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for

your personal needs.

32 33

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less

interference to hearing devices than phones that are not rated. M4 is the better/higher of the two

ratings. Your device is rated M3.

Please power off the Bluetooth® function while using hearing aid devices with your A466BG.

Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional

may help you find this rating. Higher ratings mean that the hearing device is relatively immune to

interference noise.

The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered

acceptable for normal use. A sum of 6 is considered for better use. A sum of 8 is considered for best

use. In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets

the M3 level rating, the sum of the two values equal M5. This should provide the hearing aid user with

“normal usage” while using their hearing aid with the particular wireless phone. “Normal usage” in

this context is defined as a signal quality that is acceptable for normal operation.

This methodology applies equally for T ratings. The M mark is intended to be synonymous with

the U mark. The T mark is intended to be synonymous with the UT mark. The M and T marks are

recommended by the Alliance for Telecommunications Industries Solutions (ATIS). The U and UT

marks are referenced in Section 20.19 of the FCC Rules. The HAC rating and measurement procedure

are described in the American National Standards Institute (ANSI) C63.19 standard.

Disclosure statement for HAC-rated handsets operating over the GSM air interface in the 1900 MHz

Band with a user-selectable mode of a special mode necessary to meet the hearing aid compatibility

standard for reducing the power under the provisions of Section 20.19

For information about hearing aids and digital wireless phones

FCC Hearing Aid Compatibility and Volume Control:

http://www.fcc.gov/cgb/dro/hearing.html

Gallaudet University, RERC:

https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm

SAR Information

1.04 W/kg @ 1g (HEAD)

1.18 W/kg @ 1g (BODY)

THIS MODEL DEVICE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines

when used with the TCL Mobile Limited. Accessories supplied or designated for this product. Use of

other accessories may not ensure compliance with the FCC RF exposure guidelines.

Your wireless mobile phone is a radio transmitter and receiver. It is designed and manufactured

not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the U.S. Government. These limits are part of comprehensive

guidelines and establish permitted levels of RF energy for the general population. The guidelines

are based on the safety standards previously set by both U.S. and international standards bodies:

 American National Standards Institute (ANSI) IEEE. C95.1-1999.

 National Council on Radiation Protection and Measurement (NCRP). Report 86. 1986.

 International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996.

 Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin

designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phone employs a unit of measurement known as the

Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg*.

The FCC has granted an Equipment Authorization for this model device with all reported SAR levels

evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model

device is on file with the FCC and can be found under the Display Grant section of https://fjallfoss.

fcc.gov/oetcf/eas/reports/GenericSearch.cfm after searching on FCC ID: 2ACCJH055 Additional

information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications &

Internet Association (CTIA) Web-site as http://http://www.ctia.org/.

* In the U.S. and Canada, the SAR limit for mobile phone used by the public is 1.6 Watts/kg (W/kg)

averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in usage.

Normal condition only to ensure the radiative performance and safety of the interference. As with

other mobile radio transmitting equipment, users are advised that for satisfactory operation of the

equipment and for the safety of personnel, it is recommended that no part of the human body be

allowed to come too close to the antenna during operation of the equipment.

Body-worn Operation

This device was tested for typical body-worn operations. To comply with RF exposure requirements,

a minimum separation distance of 1 cm must be maintained between the user’s body and the

handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this

device should not contain any metallic components. Body-worn accessories that do not meet these

requirements may not comply with RF exposure requirements and should be avoided.

Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments

could impair call quality, damage the phone, or result in violation of regulations. Do not use the phone

with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may

result. Please contact your local dealer for replacement antenna.

FCC RF Radiation Exposure Statement

 This Transmitter has been demonstrated co-location compliance requirements with Bluetooth®

and WLAN. This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment.

34

Telecommunications & Internet Association (TIA) safety

information

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of 15 cm

(6 inches) be maintained between a handheld wireless phone and a pacemaker to avoid potential

interference with the pacemaker. These recommendations are consistent with the independent

research by and recommendations of Wireless Technology Research.

Persons with pacemakers:

 Should ALWAYS keep the phone more than 15 cm (6 inches) from their pacemaker when the

phone is turned ON.

 Should not carry the phone in a breast pocket.

 Should use the ear opposite the pacemaker to minimize the potential for interference. If you

have any reason to suspect that interference is taking place, turn the phone OFF immediately.

Hearing aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference,

you may want to consult your service provider, or call the customer service line to discuss

alternatives.

Electronic Recycling (Within USA Only):

For more information on Electronic Recycling, please:

1. Visit ALCATEL ONETOUCH Electronic Recycling Program website at

http://www.alcatelonetouch.

us/electronic-recycling-program, or

2. Call ALCATEL ONETOUCH US Customer Support at 1-855-368-0829.

TCL Communication H055 HSUPA/HSDPA/UMTS triple band /GSM quad band mobile phone User Manual

TCL Communication Ltd. HSUPA/HSDPA/UMTS triple band /GSM quad band mobile phone

User Manual

Navigation menu

Namespaces

Views

Navigation
