VF_VFD 528 PSI for Vodafone for FCC_EN_V0.1_20180821

Vodafone
Smart E9
© Vodafone Group 2018. Vodafone, Vodacom and the
Vodafone logos are trade marks of Vodafone Group.
Any product or company names mentioned herein
may be the trade marks of their respective owners.
Smart E9 / CQF2DJ101AAA
1 2
Do not rely on this device for emergency
communications
Switch off in explosive environments
Only use approved accessories
Do not use this device whilst walking across a
road or cycling
We recommend that you read this chapter carefully before
using your phone. The manufacturer disclaims any liability
for damage, which may result as a consequence of improper
use or use contrary to the instructions contained herein.
TRAFFIC SAFETY:
Given that studies show that using a phone while driving
a vehicle constitutes a real risk, even when the hands-
free kit is used (car kit, headset...), drivers are requested
to refrain from using their phone when the vehicle is not
parked. Check the laws and regulations on the use of
wireless phones and their accessories in the areas where
you drive. Always obey them. The use of these devices may
be prohibited or restricted in certain areas.
CONDITIONS OF USE:
• You are advised to switch off the phone from time to time
to optimize its performance;
• Remember to abide by local authority rules of mobile
phone use on aircrafts;
• If your phone is a unibody device, where the back cover
and battery are not removable, dissembling the phone
will void your warranty. Disassembling the phone can
cause bodily injury if the battery is punctured;
• Always handle your phone with care and keep it in a clean and
dust-free place;
• Do not allow your phone to be exposed to adverse
weather or environmental conditions, such as moisture,
humidity, rain, infiltration of liquids, dust, sea air, etc. The
manufacturer’s recommended operating temperature
range is -10°C (14°F) to +55°C (131°F). At over 55°C
(131°F), the legibility of the phone’s display may be
impaired, though this is temporary and not serious;
• Do not open, dismantle, or attempt to repair your phone
yourself;
Please read this safety information before you use the
device. Following the warnings will help prevent injury to
yourself or others and damage to your device.
Additional safety warnings may be given for the operation of
specific Apps on your device, you should also follow these
instructions.
Product safety information
Pictograms and graphic symbols
Read the Safety Information section of this user
guide [on page 2] before using this device. Failure
to comply with safety warnings can result in
serious injury.
Do not use while refuelling or near gas or
flammable liquids
Do not use while driving
This device may produce a bright or flashing light
For body-worn operation maintain a separation
of 5 mm
Do not dispose of this device or its battery in
a fire.
This device is not intended for use by young
children. If you allow a child to use it ensure the
child is strictly supervised. This device contains
small parts which are a choking hazard
Avoid contact with magnetic media
This device may produce a loud sound
Avoid extreme temperatures
Keep away from pacemakers and other personal
medical devices
Avoid contact with liquid, keep dry
Switch off when instructed in hospitals and
medical facilities
Do not try to disassemble
Switch off when instructed in aircraft and airports
3 4
BATTERY:
For a non-unibody device:
Observe the following precautions:
• Do not attempt to open the battery (due to the risk of
toxic fumes and burns);
• Do not puncture, disassemble, or cause a short circuit in
a battery;
• Do not burn or dispose of a used battery in household
rubbish or store it at temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally
applicable environmental regulations. Only use the battery
for the purpose for which it was designed. Never use
damaged batteries or those not recommended by TCL
Communication Ltd. and/or its affiliates.
For a non-unibody device with a non-removable battery:
Observe the following precautions:
• Do not attempt to eject, replace or open the battery;
• Do not puncture, disassemble, or cause a short circuit in
the battery;
• Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F).
Phone and battery must be disposed of in accordance with
locally applicable environmental regulations.
For a unibody device:
Observe the following precautions:
• Do not attempt to open the back cover;
• Do not attempt to eject, replace, or open battery;
• Do not puncture the back cover of your phone;
• Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F);
Phone and battery as a unibody device must be disposed
of in accordance with locally applicable environmental
regulations.
This symbol on your phone, the battery, and the
accessories means that these products must be
taken to collection points at the end of their life:
• Municipal waste disposal centers with specific bins
for these items of equipment;
• Collection bins at points of sale.
• Do not drop, throw, or bend your phone;
• Use only batteries, battery chargers, and accessories
which are recommended by TCL Communication Ltd. and
its affiliates and are compatible with your phone model.
TCL Communication Ltd. and its affiliates disclaim any
liability for damage caused by the use of other chargers
or batteries;
• Your phone should not be disposed of in a municipal
waste. Please check local regulations for disposal of
electronic products;
• Remember to make backup copies or keep a written
record of all important information stored on your phone;
• Some people may suffer epileptic seizures or blackouts
when exposed to flashing lights, or when playing video
games. These seizures or blackouts may occur even if a
person never had a previous seizure or blackout. If you have
experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult your doctor
before playing video games on your phone or enabling a
flashing-lights feature on your phone;
• Parents should monitor their children’s use of video
games or other features that incorporate flashing lights
on the phones. All persons should discontinue use and
consult a doctor if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness,
orientation, or movements.
PRIVACY:
Please note that you must respect the laws and regulations
in force in your jurisdiction or other jurisdiction(s) where
you will use your phone regarding taking photographs
and recording sounds with your phone. Pursuant to such
laws and regulations, it may be strictly forbidden to take
photographs and/or to record the voices of other people or
any of their personal attributes, and reproduce or distribute
them, as this may be considered to be an invasion of
privacy. It is the user's sole responsibility to ensure that
prior authorization has been obtained, if necessary, in order
to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller
or vendor of your phone (including the carrier) disclaim any
liability which may result from improper use of the phone.
5 6
Your phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for
exposure to radio-frequency (RF) energy. These limits are
part of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on standards that were developed by
independent scientific organizations through periodic and
thorough evaluation of scientific studies. These guidelines
include a substantial safety margin designed to ensure the
safety of all persons, regardless of age and health.
The exposure standard for phones employs a unit of
measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set by public authorities such as
the Federal Communications Commission of the US
Government (FCC), or by Innovation, Science and Economic
Development Canada (ISED), is 1.6 W/kg averaged over
1 gram of body tissue. Tests for SAR are conducted using
standard operating positions with the phone transmitting
at its highest certified power level in all tested frequency
bands.
This device is complied with SAR for general population/
uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and
had been tested in accordance with the measurement
methods and procedures specified in IEEE1528.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as
in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of www.fcc.
gov/oet/ea/fccid after searching on FCC ID: 2ACCJH095
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the phone.
Before a phone model is available for sale to the public,
compliance with national regulations and standards must
be shown.
The highest SAR value for this model phone when tested
is 1.21 W/Kg for use at the ear and 1.30 W/Kg for use close
to the body.
They will then be recycled, preventing substances being
disposed of in the environment, so that their components
can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these
collection points.
In non-European Union jurisdictions:
Items of equipment with this symbol are not to be thrown
into ordinary bins if your jurisdiction or your region has
suitable recycling and collection facilities; instead they are
to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s
Recycling Program at http://www.gowirelessgogreen.org/
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
WARNING: This product contains chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm.
CHARGERS:
Home A.C./Travel chargers will operate within the
temperature range of: 0°C (32°F) to 40°C (104°F).
The chargers designed for your phone meet the standard
for safety of information technology equipment and office
equipment use. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction
may not work in another jurisdiction. They should be used
for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5V, 550mA
Battery: Lithium 2000 mAh
RADIO WAVES:
THIS PHONE MEETS THE GOVERNMENT’S REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES.
7 8
For the receiver devices associated with the operation of
a licensed radio service (e.g. FM broadcast), they bear the
following statement:
This phone complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
• This device may not cause harmful interference;
• This device must accept any interference received,
including interference that may cause undesired
operation.
Your phone is equipped with a built-in antenna. For optimal
operation, you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can
be used in positions other than against your ear. In such
circumstances the device will be compliant with the
guidelines when used with a headset or USB data cable.
If you are using another accessory ensure that whatever
product is used is free of any metal and that it positions the
phone at least 10 mm away from the body.
Please note by using the device some of your personal
data may be shared with the main device. It is under
your own responsibility to protect your own personal data,
not to share with it with any unauthorized devices or
third party devices connected to yours. For products with
Wi-Fi features, only connect to trusted Wi-Fi networks. Also
when using your product as a hotspot (where available),
use network security. These precautions will help prevent
unauthorized access to your device. Your product can
store personal information in various locations including
a SIM card, memory card, and built-in memory. Be sure to
remove or clear all personal information before you recycle,
return, or give away your product. Choose your apps and
updates carefully, and install from trusted sources only.
Some apps can impact your product’s performance and/
or have access to private information including account
details, call data, location details and network resources.
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement for RF exposure.
For body-worn operation, the phone meets FCC RF exposure
guidelines provided that it is used with a non-metallic
accessory with the handset at least 10 mm from the body.
Use of other accessories may not ensure compliance with
FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.ctia.org/
The World Health Organization (WHO) considers that
present scientific information does not indicate the need
for any special precautions for use of phones. If individuals
are concerned, they might choose to limit their own or
their children’s RF exposure by limiting the length of calls,
or using “hands-free” devices to keep phones away from
the head and body. Additional WHO information about
electromagnetic fields and public health are available on
the following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and
receiver;
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected;
• Consult the dealer or an experienced radio/ TV technician
for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
9 10
Licences
microSD Logo is a trademark.
The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by TCL Communication
Ltd. and its affiliates is under license. Other
trademarks and trade names are those of their
respective owners.
Smart E9 Bluetooth
Declaration ID D038401
The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.
This equipment may be operated in all
European countries.
This device may be operated without
restrictions in any EU member state.
Google, the Google logo, Android, the Android
logo, Google Search TM, Google Maps TM, Gmail TM,
YouTube, Google Play Store and Duo TM are
trademarks of Google Inc.
The Android robot is reproduced or modified from work
created and shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution License
(the text will show when you touch and hold Google
legal in Settings > System > About phone > Legal
information) (1).
General information
You have purchased a product which uses the open source
(http://opensource.org/) programs mtd, msdosfs, netfilter/
iptables and initrd in object code and other open source
programs licensed under the GNU General Public License
and Apache License.
We will provide you with a complete copy of the
corresponding source codes upon request within a period
of three years from the distribution of the product from the
below mentioned address in chapter Notice.
You may download the source codes from https://
sourceforge.net/projects/alcatel/files/vodafone/SmartE9.
tar.xz/download. The provision of the source code is free of
charge from internet.
(1) This may not be available depending on your country
Note that any data shared with TCL Communication Ltd.
is stored in accordance with applicable data protection
legislation. For these purposes TCL Communication Ltd.
implements and maintains appropriate technical and
organizational measures to protect all personal data, for
example against unauthorized or unlawful processing
and accidental loss or destruction of or damage to such
personal data whereby the measures shall provide a level of
security that is appropriate having regard to
• The technical possibilities available;
• The costs for implementing the measures;
• The risks involved with the processing of the personal
data, and;
• The sensitivity of the personal data processed.
You can access, review and edit your personal information
at any time by logging into your user account, visiting your
user profile or by contacting us directly. Should you require
us to edit or delete your personal data, we may ask you to
provide us with evidence of your identity before we can act
on your request.
Innovation, Science and Economic Development
Canada (ISED) Notice
This device complies with Innovation, Science and Economic
Development Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
• This device may not cause interference, and;
• This device must accept any interference, including
interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-
003.
Innovation, Science and Economic Development
Canada (ISED) Radiation Exposure Statement
This EUT is compliance with SAR for general population/
uncontrolled exposure limits in ISED RSS-102 and had
been tested in accordance with the measurement methods
and procedures specified in IEEE 1528 and IEC 62209.
This equipment should be installed and operated with
minimum distance 10 mm between the radiator and your
body. This device and its antenna(s) must not be co-located
or operating in conjunction with any other antenna or
transmitter.
11 12
Warranty information
WARRANTY TERMS AND CONDITIONS
1. Vodafone undertakes the warranty of this mobile phone
for a period of two (2) years from the date of purchase by
the original owner (not transferable) under normal use.
2. The battery has a limited warranty for twelve (12)
months, and charger for twenty-four (24) months
against manufacturing defects. Other accessories have
a limited warranty for twenty-four (24) months against
manufacturing defects.
3. This warranty does not cover damage resulting from:
a) Normal wear & tear of the equipment;
b) Defects and damages due to the equipment being
used other than its normal and customary manner;
c) An unauthorised disassembly, repair, alteration or
modification being carried out;
d) Misuse, abuse, negligence or accident howsoever
caused;
e) Defects or damage arising from improper testing,
operation, maintenance, installation, or any alteration
or modification;
f) Defects or damage due to spillage of food or liquids,
corrosion, rust or the use of wrong voltage;
g) Scratches or damage to plastic surfaces and all
other externally exposed parts that are due to normal
customer use;
4. If this phone needs service or repair, it must be delivered
at the user's cost.
5. This warranty will be null and void in any of the following
events:
a) If the serial number or warranty seal on the equipment
has been defaced or removed.
b) If any term contained in this warranty has been altered
or modified in any way without prior written consent
of Vodafone.
6. This limited warranty extends only to customers who
purchase the product and is only valid in Vodafone’s
intended country (or area) of sale of the product.
Electronic labeling path: Touch Settings > Regulatory &
Safety or press *#07#, you can find more information about
labeling (1), such as FCC ID.
On our website, you will find our FAQ (Frequently Asked
Questions) section. You can also contact us by email to ask
any questions you may have.
Your phone is a transceiver that operates on GSM in
dual-band (1800/1900 MHz), UMTS in quad-band
(850/900/1900/2100 MHz), or LTE in B1/3/7/8/20.
GSM850/900: 33 dBm
FCC ID: 2ACCJH095
Notice
The information in this manual is subject to change without
notice.
Every effort has been made in the preparation of this manual
to ensure accuracy of the contents, but all statements,
information, and recommendations in this manual do not
constitute a warranty of any kind, expressed or implied. Read
the safety precautions and safety information carefully to
ensure that you use this wireless device in a correct and
safe manner.
Importer: TCT Mobile Europe SAS
Address: 55, avenue des Champs Pierreux 92000 Nanterre,
France
Manufacturer: Vodafone Procurement
Company S.a.r.l.
Registered trade mark:
Address: 15 rue Edward Steichen, L-2540 Luxembourg,
Grand-Duché de Luxembourg
(1) It depends on countries.
13
7. If the product is returned to Vodafone after the expiration
of the warranty period, Vodafone’s normal service
policies shall apply and the consumer will be charged
accordingly.
a) Vodafone neither assumes for it any other obligation
or liability beyond that which is expressly provided for
in this limited warranty.
b) All warranty information, product features and
specifications are subject to change without notice.
8. THIS WARRANTY IS IN LIEU OF ANY AND OTHER
WARRANTIES EXPRESSED OR IMPLIED, SPECIFICALLY
INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILlTY OR FITNESS FOR A PARTICULAR
PURPOSE. VODAFONE ASSUMES NO LIABILITY FOR THE
BREACH OF THE WARRANTY BEYOND CORRECTING
THE BREACH IN THE MANNER DESCRIBED ABOVE.
IN NO EVENT SHALL VODAFONE BE LIABLE FOR
CONSEQUENCES.

Navigation menu
