TCL Communication N007 HSUPA/HSDPA/UMTS Tri Band/GSM Quad Band/LTE 7 band mobile phone User Manual
TCL Communication Ltd. HSUPA/HSDPA/UMTS Tri Band/GSM Quad Band/LTE 7 band mobile phone
User manual
CJA61KAVDAAA
1 2
Table of Contents
1 Your phone ................................................................ 4
1.1 Keys and connectors ..................................................... 4
1.2 Getting started ................................................................. 7
1.3 Home screen ...................................................................10
2 Text input .................................................................19
2.1 Using the onscreen keyboard ..................................19
2.2 Text editing ......................................................................20
3 Phone call, Call log & Contacts ........................21
3.1 Phone call ........................................................................21
3.2 Recents .............................................................................. 28
3.3 Contacts ............................................................................28
4 Messaging & Email ...............................................35
4.1 Messaging ........................................................................35
4.2 Gmail/Email ....................................................................40
5 Calendar , Alarm clock & Calculator ..............43
5.1 Calendar ............................................................................43
5.2 Clock ...................................................................................45
5.3 Calculator .........................................................................46
6 Getting connected ................................................47
6.1 Connecting to the Internet .......................................47
6.2 Chrome ..............................................................................49
6.3 Connecting to Bluetooth devices .........................49
6.4 Connecting to a computer via USB .......................50
6.5 To safely remove the microSD card from your
phone ................................................................................. 51
6.6 Sharing your phone’s mobile data connection 52
6.7 Connecting to virtual private networks ...............53
7 Google Play Store ................................................54
8 Multimedia applications ....................................55
8.1 Camera...............................................................................55
8.2 Gallery ................................................................................ 57
8.3 Play music ........................................................................59
8.4 Video player .....................................................................61
9 Google Maps ............................................................. 62
9.1 Get My Location .............................................................62
9.2 Search for a location ....................................................63
9.3 Save a location ...............................................................63
9.4 Open Street View for a location ..............................63
9.5 Get driving, public transportation or walking
directions ..........................................................................64
10 Others .......................................................................65
10.1 File Manager ....................................................................65
10.2 Sound Recorder .............................................................65
10.3 Radio ................................................................................... 65
11 Settings ....................................................................67
11.1 Wireless & networks .....................................................67
3 4
11.2 Device .................................................................................71
11.3 Personal.............................................................................74
11.4 System ...............................................................................79
12 Update your phone’s software .........................82
13 Product safety information ...............................83
14 Telephone warranty .............................................95
15 Accessories ............................................................ 97
16 Specifications ......................................................... 98
1 Your phone
1.1 Keys and connectors
Micro-USB connector
Back key
Proximity
and light
sensor
Home key
Recents key
Touch screen
Front camera
Headset connector
LED light
Flash
5 6
Volume
up
Volume
down
Power
key
Camera
Camera flash/ Flashlight
Fingerprint sensor
SIM/SD
card slot
Camera
key
Recents key
• Touch: this shows you images of your recently-used
apps. Touch an image to open the associated app, or
swipe it left or right to remove it from the list.
Home key
• While on any app or screen, touch the Home key to
return to the main Home screen.
• Touch & hold this key to access Google Now & Voice
Search.
Back key
• Touch to go back to the previous screen, or to close
a dialogue box, options menu, the Notification panel,
etc.
These keys are always visible when you light on the screen.
Power key
• Press: activate the lock screen/wake up the screen.
• Press and hold: show the pop-up menu to select from
Shut down, Restart, Flight mode.
Press and hold: power on.
• Press and hold the Power key and the Volume down
key to capture a screenshot.
Volume keys
• During a call, they adjust the earpiece or headset
volume.
• In Music/Video/Streaming mode, they adjust the
media volume.
• In general mode, they adjust the ringtone volume.
• Mute the ringtone of an incoming call.
Camera keys (1)
• In Camera Auto or Manual mode, press to capture
a picture.
• In Camera Auto mode, press and hold to do
simultaneous capture.
• In Camera Panorama mode, press to start taking
picture and press again to save.
• In Camera Slow motion mode, press to start recoding
and press again to save.
• Double press to open Camera from sleep mode, lock
screen or any screen.
It(1)
(1) Camera key function is enabled by default. You can also change in
Settings > Buttons > Camera key.
7 8
1.2 Getting started
1.2.1 Set-up
Inserting or removing the SIM/microSD card
You must insert your SIM card to make phone calls.
Before you install or remove the SIM card or microSD card, use a
pin to press the small cavity until the SIM/microSD slot pops out.
Place the SIM card with the chip facing downwards and slide it
into its housing. Make sure that it is correctly inserted.
Your phone only supports nano-SIM card. Do not attempt
to insert other SIM types like mini and micro cards,
otherwise you may damage your phone.
Charging the battery
To charge the battery, connect the charger to your phone and
mains socket. You can also charge your phone via a USB cable.
Your phone is battery embedded design with not
removable battery or back cover. Unauthorized personnel
are strictly prohibited from disassembling the phone. To
reduce energy wastage, disconnect your charger from the
plug when the battery is fully charged.
To reduce your phone’s power consumption, switch off
Wi-Fi, GPS, Bluetooth or apps running in the background
when not needed. In Settings you can also lower the
brightness of the screen, and shorten the length of time
before the screen goes to sleep.
9 10
1.2.2 Power on your phone
Hold down the Power key until the phone powers on. It will take
a few seconds before the screen lights up. Unlock your phone
(Swipe, PIN, password or pattern) if necessary and confirm. The
Home screen will display.
If you do not know your PIN code or if you have forgotten it,
contact your network operator. Do not leave your PIN code with
your phone. Store this information in a safe place when not in use.
Set up your phone for the first time
The first time you power on the phone you will be asked to set
the following options: language, mobile data, Google account,
date & time, etc.
1. Select the phone’s language, then touch .
2. Select Wi-Fi, then touch SKIP.
3. Select Name, then touch NEXT.
4 Select Set up email, then touch NEXT.
5. Select Protect your phone, then touch SKIP.
6. Select Google services, then touch NEXT.
7.Select App permissions, then touch NEXT.
8. Select Experience improvement, then touch NEXT.
9. Select Help tips, then touch NEXT.
Then your phone is setup and ready to use.
If you power on your phone with no SIM card inserted, you will
still be able to connect to a Wi-Fi network to sign into your Google
account and to use some features.
1.2.3 Power off your phone
Hold down the Power key from the Home screen until the Phone
options appear, then select Shut down.
1.3 Home screen
You can bring all your favourite items (apps, shortcuts, folders and
widgets) to your Home screen for quick access. Touch the Home
key to switch to the Home screen.
Status bar
• Status/Notification indicators
• Touch and drag down to open the
Notification panel
Application tab
• Touch to open all apps
Slide left or right to view other panels
on the Home screen
Google Search bar
• Touch a to enter text search screen
• Touch b to enter voice search screen
Favourite tray apps
• Touch to enter the app
• Touch and hold to move or change apps
ab
The Home screen extends on either side of the screen to allow
more space for adding apps, shortcuts, etc. Slide the Home
screen horizontally left and right to get a complete view of the
Home screen. The white spot in the lower part of the screen
indicates which screen you are viewing.
11 12
1.3.1 Using the touchscreen
Touch
To access an app, touch it with your finger.
Touch and hold
Touch and hold the Home screen to access the available options
for setting the wallpaper.
Drag
Touch and hold an item to be able to drag it to another location.
Slide/Swipe
Slide the screen to scroll up and down lists, screens of apps,
images, web pages, etc.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw
them apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways.
1.3.2 Status bar
From status bar, you can view both phone status (on the right
side) and notification information (on the left side).
Status icons
GPRS connected No SIM card inserted
EDGE connected Vibrate mode
3G connected Do not disturb mode
is on
HSDPA (3G) connected Phone microphone
is mute
HSPA (3G) connected Battery is very low
4G connected Battery is low
4G+ connected via CA Battery is partially
drained
Bluetooth is on Battery is full
Connected to a
Bluetooth device Battery is charging
Flight mode Headset connected
Alarm is set Roaming
GPS is on Signal strength
Connected to a Wi-Fi
network
13 14
Notification icons
New GmailTM message Call in progress
New text or multimedia
message Missed call
Problem with SMS or
MMS delivery Call on hold
New Hangouts
message Call forwarding is on
New voicemail Uploading data
Upcoming event Download finished
Data is synchronising
Carrier data use
threshold approaching
or exceeded
No SIM card installed An open Wi-Fi network
is available
Song is playing Radio is on
Screenshot error System update
available
USB tethering is on Connected to VPN
Portable Wi-Fi hotspot
is on
International Roaming
is enabled
Screenshot captured International Roaming
is disabled
More notifications are
hidden
Notification panel
Touch and drag down the Status bar to open the Quick setting
panel and drag down again to open the Quick setting panel. Touch
and drag up to close it. From the Notification panel, you can open
items and other reminders indicated by notification icons or view
wireless service information.
Touch to access Quick setting bar
Touch and drag twice downward to
access Quick setting bar
Touch a notification and slide it sideways to delete it.
Touch the icon to clear all event–based notifications (other
ongoing notifications will remain).
In Quick setting screen, touch the Settings icon to access
Settings.
Quick setting bar
•Touchiconstoenable/disable
functions or to change modes
•Touch to show the settings
The customised picture will show if you set up
your profile in Contacts application (1)
(1) Please refer to "3.3.1 View your contacts"
15 16
1.3.3 Search bar
The phone provides a Search function which can be used to
locate information within applications, the phone or the web.
ab
a Search by text
• Touch Search bar from the Home screen.
• Enter the text/phrase you want to search for.
• Touch on the keyboard if you want to search on the web.
b Search by voice
• Touch from Search bar to display a dialog screen.
• Speak the word/phrase you want to search for. A list of search
results will display for you to select from.
1.3.4 Lock/Unlock your screen
To protect your phone and privacy, you can lock your phone
screen with a variety of patterns, PIN or password, etc. through
Settings > Security > Screen lock.
To create a screen unlock pattern (Follow onscreen
instructions)
• Touch Settings > Security > Screen lock > Pattern.
• Draw your own pattern.
Draw your unlock pattern
Touch to confirm by
drawing pattern again
To create a screen unlock PIN/Password
• Touch Settings > Security > Screen lock > PIN or Password.
• Set your PIN or password.
To lock phone screen
Press the Power key once to lock the screen.
17 18
To unlock phone screen
Press the Power key once to light up the screen, draw the unlock
pattern you have created or enter PIN or password to unlock
the screen.
If you have chosen Swipe as the screen lock, slide upward to
unlock the screen.
Swipe from the icon to open the app
1.3.5 Personalise your Home screen
Add an app or widget
Touch the Application tab , then touch and hold the app to
activate the Move mode, and drag the item to any Home screen.
Touch and hold the blank space on any Home screen, choose
WIDGETS and drage widget to the Home screen.
Reposition an app or widget
Touch and hold the item to be repositioned to activate the Move
mode, drag the item to the desired position and then release. You
can move items both on the Home screen and the Favourites tray.
Hold the icon on the left or right edge of the screen to drag the
item to another Home screen.
Remove
Touch and hold the item to be removed to activate the Move
mode, drag the item up to the top of Remove icon, and release
after the item turns grey.
Create folders
To make it easier to organise apps and shortcuts on the Home
screen and the Favourite tray, you can add them to a folder by
stacking one item on top of another. To rename a folder, open it
and touch the folder’s title bar to input the new name.
Wallpaper customisation
Touch and hold an empty area on the Home screen or go to
Settings > Display > Wallpaper to customise your wallpaper.
1.3.6 Volume adjustment
Using volume key
Press Volume key to adjust the volume. To activate the vibrate
mode, press the Volume down key until the phone vibrates.
Press the Volume down key once more to activate the silent
mode.
Using Settings menu
Drag down twice from the notification panel and touch the
settings icon to enter Settings, then touch Sound &
notification, you can set the volume of calls, notification, system
and etc. to your preference.
19 20
2 Text input
2.1 Using the onscreen keyboard
Onscreen keyboard settings
Touch the Application tab from the Home screen, select
Settings > Language & input.
Adjust the onscreen keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen
Keyboard orientation. You can also adjust it by changing the
settings (go to Settings > Display > When device is rotated >
Rotate the contents of the screen).
2.1.1 Android keyboard
Touch to switch between
letter keyboard and symbol/
numeric keyboard
Touch & hold, then
select to enter
symbols
Touch to enter text
or numbers
Touch to switch
between "abc/
Abc" mode;
Touch & hold to
switch between
"abc/ABC" mode
2.2 Text editing
You can edit the text you have entered.
• Touch and hold or double-tap on the text you would like to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: CUT, COPY, PASTE(1), SHARE,
SELECT ALL and REPLACE.
You can also insert new text
• Touch where you want to type, or touch and hold a blank space,
the cursor will blink and the tab will show. Drag the tab to move
the cursor.
• If you have selected any text, touch the tab to show PASTE icon
which allows you to paste any text you have previously copied.
(1) It won't appear until you choose copy.
21 22
3 Call+, Call log & Contacts
3.1 Call+
Call+ allows users to share content using data while being in a
call. It also enriches the calling experience by adding features
that let users inform their contacts on why they are calling or
why they called.
3.1.1 Placing a call
You can easily make a call using Call+. Touch the Application tab
from the Home screen and select Call+
Touch to show the dial pad
Contacts
Call log
Touch and hold to access voicemail
Enter the number you want from the dial pad directly or touch a
contact from CONTACTS or FAVOURITES tab to place the call.
Enter the number from the dial pad, and touch key, the following
options are available:
Add to contacts Save the number to Contacts.
Speed dial Touch to enter speed dial setting.
Add 2 sec pause Touch to add "," of 2 sec pause.
Add wait Touch to add ";" of waiting.
If you make a mistake, you can delete the incorrect digits by
touching .
To hang up a call, touch .
International call
To dial an international call, touch and hold to enter "+", then
enter the international country prefix followed by the full phone
number and finally touch .
Emergency call
If your phone has network coverage, dial emergency number and
touch to make an emergency call. This works even without a
SIM card and without typing the PIN code.
23 24
3.1.2 Answering or rejecting a call
When you receive a call, touch
• Slide the icon right to answer the call;
• Slide the icon left to reject the call;
• Slide the icon down to reject the call by sending a preset
message.
To mute incoming calls, press the Volume up/down key directly
3.1.3 Calling your voicemail
Your voicemail is provided by your network to avoid missing
calls. It works like an answering machine that you can consult
at any time.
To access your voicemail, touch and hold on dial pad.
To set your voicemail number, touch key and touch Settings >
Call settings > Voicemail.
If you receive a voicemail, a voicemail icon appears on the
Status bar. Open the Notification panel, touch New voicemail.
3.1.4 During a call
To adjust the volume during a call, press the Volume up/down
key.
Touch to hold the current call. Touch this icon again to
retrieve the call.
Touch to display Dial pad.
Touch to end the current call.
Touch to mute the current call. Touch this icon again
to unmute the call.
Touch to activate the speaker during the current call.
Touch this icon again to deactivate the speaker.
Touch to add the number to new contact.
To avoid misoperation on touchscreen during a call,
screen will be locked automatically when you put the
cellphone close to your ear; and it will be unlocked
when the cellphone is taken away from your ear.
25 26
3.1.5 Managing multiple calls
With this phone you can handle multiple calls at the same time.
Conference calls (1)
You can set up a conference call.
• Place a call to the first participant of the conference call.
• Touch .
• Enter the phone number of the person you want to add to
conference and touch . You can also add participants from
Contacts or Recents.
• Touch icon to start a conference call.
• During a conference call, touch to drop a participant or to
talk privately to one of the participants. Touch to drop the
participant from the conference, touch to talk privately to
the participant and hold on other participants.
• Touch to end the conference call and disconnect all callers.
(1) Depending on your network operator.
3.1.6 Call settings
Touch key from Call+ screen, the following options are available:
Clear call history
Touch to clear the entire call memory, touch OK to confirm.
Filter call logs by...
Touch to filter call logs by Missed calls, Outgoing calls,
Received calls or Show all.
New contact
Touch to add a new contact.
Call+ settings
Servie options Mark the checkbox to enable Call+ and
Message+service.
Add video to the
call
Touch to add video to the call.
Automatic
download
Touch to set automatic download.
Help Touch to learn more about Call+.
Settings
• Call settings\Voicemail
Service Opens a dialog box where you can select
your carrier’s voicemail service or another
service.
Setup If you are using your carrier’s voicemail
service, this opens a dialog box where you
can enter the phone number to use for
listening to and managing your voicemail.
Sound Touch to select the notification sound.
Vibrate Mark the check box to enable vibration
when voicemail notification.
27 28
• Call settings\Fixed Dialling Numbers
Fixed Dialling Number (FDN) is a service mode of SIM, where
outgoing calls are restricted to a set of phone numbers. These
numbers are added to the FDN list. The most common practical
application of FDN is for parents to restrict the phone numbers
which their children can dial.
For security reasons, you’ll be prompted to enable FDN by
entering SIM PIN2 which is usually acquired from your service
provider or SIM maker.
• Call settings\Vibrate reminder
You can set vibrate reminder when outgoing calls connect
successfully.
• Call settings\Service Dialling Numbers
You can place a call from the SDN list.
• Call settings\GSM call settings
Touch to set additional GSM only call settings.
• Sounds and vibrations
Touch to set phone ringtone and volume, etc
• Quick responses
Touch to edit quick responses which will be used when you reject
a call with messages.
• Accessibility
TTY mode TTY mode can be used by people who
are deaf, have poor hearing or speech
impairments. Touch to set TTY mode.
3.2 Recents
You can view your call history in CALL tab
from the Call+ screen.
Touch a contact's photo to open the Quick Contact panel.
In Quick Contact panel, you can view detailed information of a
call, launch a new call or send messages to a contact or number,
or add numbers to Contatcs (only available for unsaved phone
numbers), etc.
To clear the entire call memory, touch key from the Call+ screen
and touch Clear call history, then touch OK.
3.3 Contacts
You can view and create contacts on your phone and synchronise
these with your Gmail contacts or other apps on the web or on
your phone.
When using Contatcs for the first time you are asked
whether to import contacts from your SIM card.
29 30
3.3.1 View your contacts
To access Contacts app, touch the Application tab on the Home
screen, then select Contacts.
Touch icon to open Quick
Contact panel and view the
contact’s detailed information
Touch to view your favourite contacts
Touch to view all your contacts
Contact list
Touch to add a new contact
Touch to search in Contacts
Touch to set up your profile and your
picture will show
After set up your profile, your picture
will show and the icon in quick setting
screen will vary together
Touch key to display contacts list option menu.
Following actions are enabled:
• Contacts to
display
Choose contacts to display.
• Import/Export Import or export contacts between phone,
SIM card, and microSD card, or share
contacts.
• Manage SIM
contacts
Access to SIM contacts settings.
• Accounts Manage the synchronisation settings for
different accounts.
• Settings Access to contact display settings.
3.3.2 Adding a contact
Touch the Application tab on the Home screen, select the
Contacts, then touch the icon in the contact list to create
a new contact.
Touch to take a photo or select a
picture for the contact
Touch to save
Touch to expand the Name label
If you want to add more information, touch More fields to add
a new category.
When finished, touch to save.
To exit without saving, you can touch Back key and then OK.
31 32
Add to/remove from Favourites
To add a contact to favourites, you can touch a contact to view
details then touch to add the contact to favourites.
To remove a contact from favourites, touch on contact details
screen.
Only phone and account contacts can be added to
favourites.
3.3.3 Editing your contacts
To edit contact information, touch key in the contact details
screen. When finished, touch .
Change a contact’s default phone number
The default phone number (the number which has priority when
making a call or sending a message) will always be displayed
under the contact name.
To change the default phone number, touch and hold the
number you want to set as the default number from the contact’s
details screen, then select Set default. A appears before the
number.
This choice is only available when the contact has more than
one number.
Delete a contact
To delete a contact, touch key from the Contatcs detail screen
and touch Delete.
The contact you have deleted will also be removed from
other applications on the phone or web the next time
you synchronise your phone.
3.3.4 Communicating with your contacts
From contact details screen, you can communicate with your
contacts by making a call or exchanging messages.
To launch a call, touch the phone number.
To send a message, touch the icon on the right side of the
number.
Use Quick Contact for Android
Touch a contact’s picture to open Quick Contact for Android,
then you can touch the number or the icon for the way you
want to connect.
The icons available on Quick Contact panel depend on the
information you have for the contact and the applications/
accounts on your phone.
33 34
3.3.5 Importing, exporting and sharing contacts
From the Contacts screen, touch key to open the options menu,
touch Import/Export, then select to import/export contacts
from/to your SIM card, Phone storage, Accounts, etc.
You can share a single contact or contacts with others by sending
the contact’s vCard to them via Bluetooth, Gmail, etc.
To do this, touch a contact you want to share, touch key and
Share from contact details screen, then select the app to perform
this action.
3.3.6 Displaying contacts
You can configure which group of contacts, for each account,
you want to display in the Contacts list. Touch key and then
Contacts to display from contacts list screen, then you can
choose contacts to display.
Touch key and then Settings, you can Sort by First name or
Last name, as well as Name format as First name first or Last
name first.
3.3.7 Joining/Discarding contacts
To avoid duplication, you can add any new contact information to
existing contacts in a single action.
Touch the contact which you want to add information to, touch
key, then touch key in edit screen and touch Merge.
At this time, you are required to select the contact whose
information you want to merge with the first contact. The
information from the second contact is added to the first one,
and the second contact will no longer be displayed in the
contacts list.
To separate contact information, touch the contact whose
information you want to separate, touch key, then touch key
in edit screen and touch Separate, touch to confirm.
3.3.8 Synchronising contacts in multiple accounts
Contacts, data or other information can be synchronised from
multiple accounts, depending on the apps installed on your
phone.
To add an account, touch on Quick setting bar to get to
Settings, then touch Accounts > Add account.
You are required to select the kind of account you are adding, like
Google, Corporate, etc.
As with other account set-ups, you need to enter detailed
information, like username, password, etc.
You can remove an account and all associated information from
the phone. Open the Settings > Accounts screen, touch the
account you want to delete, touch key and then select Remove
account, then confirm.
Sync
You can synchronise an account on Accounts screen, touch an
account in the list, then touch key and select Sync now.
35 36
4 Message+ & Email
4.1 Message+
Message+ is a new messaging service that lets Vodafone
customers send and receive messages, photos, videos and sounds
with any contacts. Message+ provides a user an integrated inbox
across SMS/MMS and Chat messages. Based on the contact
availability, a message will be sent out as SMS/MMS or Chat.
Touch the Application tab from the Home screen, then select
Message+.
4.1.1 Create a new message
On the Message+ list screen, touch the new message icon and
touch to write new text/multimedia messages, touch to
start a new group chat or touch to go back to list screen.
Touch to create a new message or start a
new group chat
• Touch to view the whole message thread
• Touch & hold message threads to open
messages options
Sending a text message
Enter the mobile phone number of the recipient on the To: bar or
touch to choose a contact from MOST CONTACTED or ALL
CONTATCS and touch to add recipients, then touch the
SMS bar to enter the text of the message. When you’ve finished,
touch to send the text message.
An SMS of more than 160 characters will be charged as
several SMS. Specific letters (like accents, for example)
will also increase the size of the SMS, so this may cause
multiple SMS to be sent to your recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations,
and audio to other compatible phones and e-mail addresses.
An SMS will be converted to MMS automatically when media
files (image, video, audio, etc.) are attached or Subject or email
addresses are added.
To send a multimedia message, enter the recipient’s phone
number in the To: bar, touch SMS bar to enter the text of the
message. touch to attach photo, video, audio, etc.
When finished, touch to send the multimedia message.
Attach options:
Access Contacts to select a contact.
Access Message+ to take a picture.
Touch to add audio files.
Access Message+ to record videos.
Touch to download Pinnatta to have further
operations.
Touch to download Follow Me to have further
operations.
37 38
4.1.2 Manage messages
When a new message comes, an icon will appear on status bar
as notification. Drag down the status bar to open the Notification
panel, touch the new message to open it. You can also access
Message+ and touch the new message to open it.
Messages are displayed in conversational order.
To reply to a message, touch the current message to enter
message-composing screen, enter the text, then touch .
Touch and hold a message in message details screen, the
following options will be available:
Copy message text This option available for SMS and MMS
with text. Touch to copy current message
content and past it to SMS bar of the new
message you are going to compose.
Forward Touch to forward the message to another
recipient.
Delete message Delete the current message.
4.1.3 Adjust message settings
In message list screen, touch key and select Settings.
Look & Feel
• Font size Touch to change application font size.
• Background Touch to set background image.
• Sort contacts
by...
Touch to set how to sort contacts.
• Display contact
names by...
Touch to set how to display contacts.
• Show call logs
in conversation
Phone logs, messages and media shared
during a call will be highlighted.
Chat
• Service options Touch to enable Call+ and Message+
service.
• Show last active
info
Mark to show last active info.
• Read
notifications
(chat only)
Mark to send notification when a chat
message was read.
• Chat profile
name
Touch to set chat name on profile.
• Automatic
download
Touch to enable automatic download in
different network environment.
39 40
SMS & MMS
• Allow conversion
of long SMS to
MMS
Mark to allow conversion of long SMS to
MMS.
• SMS delivery
reports
Mark to allow request of SMS delivery
reports.
• MMS delivery
reports
Mark to allow request of MMS delivery
reports.
• MMS while
roaming
Mark to enable automatically retrieve
incoming MMS while roaming.
• MMS auto-
retrieve
Mark to enable automatically retrieve
incoming MMS.
• Advanced Touch to set advanced settings.
Notifications
• Notification
sounds
Touch to set notification sound.
• Notification light Touch to set notification light.
• Vibration Mark to enable vibration with incoming
messages.
• Group chat
notifications
Mark to enable notify for new group chat
messages.
• Privacy mode Mark to enable privacy mode.
Help
Touch to lean more about Message+ and Call+.
4.2 Gmail/Email
The first time you set up your phone, you can select to use an
existing Gmail account or to create a new Email account.
4.2.1 Gmail
As Google’s web-based email service, Gmail is configured when
you first set up your phone. Gmail on your phone can be
automatically synchronised with your Gmail account on the web.
Unlike other kinds of email account, each message and its replies
in Gmail are grouped in your inbox as a single conversation; all
emails are organised by labels instead of folders.
To access Gmail
From the Home screen, touch the Application tab to enter the
applications list, then touch Gmail.
Gmail displays messages and conversations from one single Gmail
account at a time, if you own more than one account, you can add
an account by touching icon and select Settings from Inbox
screen, then touch ADD ACCOUNT. When finished, you can switch
to another by touching the account name from Inbox screen, then
select the account you want to view.
To create and send emails
1 Touch from Inbox screen.
2 Enter recipient(s)’s email address in To field.
3 If necessary, touch the popup menu icon Add Cc/Bcc to add
a copy or a blind copy to the message.
4 Enter the subject and the content of the message.
5 Touch icon and select Attach file to add an attachment.
6 Finally, touch the icon to send.
41 42
7 If you do not want to send the mail out right away, you can
touch icon and then Save draft or touch the Back key to save
a copy. To view the draft, touch your account name to display
all labels, then select Drafts.
If you do not want to send or save the mail, you can touch icon
and then touch Discard.
To add a signature to emails, touch icon and then touch
Settings from inbox screen, choose an account, then touch
Signature.
To receive and read your emails
When a new email arrives, you will be notified by a ringtone or
vibration, and an icon will appear on Status bar.
Touch and drag down the Status bar to display the Notification
panel, touch the new email to view it. Or you can also access the
Gmail Inbox label and touch the new mail to read it.
You can search for an email by sender, recipient, subject, etc.
• Touch the icon from Inbox screen.
• Enter the keyword you want to search for in the searching box
and touch on the software keyboard.
To reply or forward emails
• Reply When viewing an email, touch to reply
this mail.
• Reply all Touch and select Reply all to send
message to all people in a mail loop.
• Forward Touch and select Forward to forward the
received mail to other people.
4.2.2 Email
Besides your Gmail account, you can also set-up external email
accounts on your phone.
Touch the Application tab from the Home screen, then select
Email.
An email wizard will guide you through the steps to set up an
email account.
1 Enter the email address and password of the account you want
to set up.
2 Touch Next. If the account you entered is not provided by your
service provider in the phone, you will be prompted to go to
the email account settings screen to enter settings manually.
Or you can touch Manual setup to directly enter the incoming
and outgoing settings for the email account you are setting up.
3 Enter the account name and display name in outgoing emails.
4 To add another email account, you can touch key and
Settings. Touch Add account to create a new account.
To create and send emails
1 Touch the icon on Inbox screen.
2 Enter recipient(s) email address(es) in the To field.
3 If necessary, touch key to add a copy CC or a blind copy BCC
to other recipients.
4 Enter the subject and the content of the message.
5 Touch to add an attachment.
6 Finally, touch to send.
7 If you do not want to send the mail right away, you can touch key
and Save draft or touch the Back key to save a copy.
43 44
5 Calendar , Alarm clock &
Calculator
5.1 Calendar
Use Calendar to keep track of important meetings, appointments,
etc.
To access this function, touch the Application tab from the Home
screen, then touch Calendar.
5.1.1 Multimode view
You can display the Calendar in daily, weekly, monthly, or agenda
view.
To change your Calendar view, touch key to open list menu
for your options. Touch the icon to return to Today’s view.
In Agenda, Day or Week view touch
an event to view its details.
Touch a day in Month view to
open that day’s events.
Schedule view
Day view
3-day view
Week view
Month view
5.1.2 To create new events
You can add new events from any Calendar view.
• Touch in calendar view.
• Fill in all required information for this new event. If it is a whole-
day event, you can enable All-day option.
When finished, touch SAVE from the top of the screen.
Before you can add an event, you must add at least one
Calendar account and make a calendar visible.
To delete or edit an event
To share, delete or edit an event, touch the event to enter details
screen, touch the icon to edit the event, and touch DELETE
from the bottom of the screen to delete.
5.1.3 Event reminder
If a reminder is set for an event, the upcoming event icon
will appear on Status bar as a notification when the reminder
time arrives.
Touch and drag down the status bar to open the Notification
panel, touch event name to view Calendar notification list.
Touch Snooze to turn off all event reminders for 5 minutes.
Touch Back key to keep the reminders pending in the status bar
and the Notification panel.
Touch icon from Calendar main screen to refrensh the calendar:
Touch icon to enter Calendar Settings to set a series of
Calendar settings.
45 46
5.2 Clock
Your mobile phone has a built-in clock.
To access this function, touch the Application tab from the Home
screen, then touch Clock.
Touch to add or set an alarm.
5.2.1 To set an alarm
From Clock screen, touch to enter Alarms screen, touch
to add a new alarm. Following options will show:
• Time Touch numbers to set the time for your
alarm.
• Label Touch to set a name for the alarm.
• Repeat Touch to select days you want alarm to
work.
• Ringtone Touch to select an alarm ringtone.
• Vibrate Select to activate vibration.
Touch an already existing alarm and touch to delete the
selected alarm.
5.2.2 To adjust alarm settings
Touch key from Alarms screen. The following options will be
available under Settings:
Clock
• Style Touch to set Analog or Digital style.
• Auto home clock Touch to set home clock while travelling
outside.
• Home time zone Touch to set home time zone.
Alarms
• Silence after Touch to set time silence.
• Snooze length Touch to choose length of snooze.
• Alarm volume Touch to set alarm volume.
• Volume buttons Touch to choose Snooze, Dismiss or Do
nothing as volume buttons.
• Start week on Touch to choose from which day to start
one week.
5.3 Calculator
With Calculator, you can solve many mathematical problems.
To access this function, touch the Application tab from the Home
screen, then touch Calculator.
There are two panels available: Basic panel and Advanced panel.
To switch between panels, select one of the following two ways:
• Touch and drag the basic screen to the left to open the
Advanced panel.
• Or turn the device to the landscape mode from the basic panel
to open the Advanced panel(1).
(1) If "Settings\Display\When device is rotated\Stay in current
orientation” is on, this item will not display.
47 48
6 Getting connected
Your phone can connect to the Internet using either GPRS/
EDGE/3G/4G/4G+ or Wi-Fi.
6.1 Connecting to the Internet
6.1.1 GPRS/EDGE/3G/4G/4G+
The first time you turn on your phone with the SIM card inserted,
it will automatically configure a mobile network service: GPRS,
EDGE, 3G, 4G or 4G+.
To check the network connection you are using, touch the
Application tab on the Home screen, then touch Settings >
More > Mobile networks > Access Point Names or Network
operators.
To create a new access point
A new mobile network connection can be added to your phone
with the following steps:
1 Touch on Quick setting bar to get to Settings.
2 Touch More > Mobile networks > Access Point Names.
3 Then touch key to add new APN.
4 Enter the required APN information.
5 When finished, touch key and Save.
To activate/deactivate Data roaming
When roaming, you can decide to connect/disconnect to a data
service.
1 Touch on Quick setting bar to get to Settings.
2 Touch More > Mobile networks.
3 Touch the switch to activate or deactivate data roaming.
4 When Data roaming is deactivated, you can still perform data
exchange with a Wi-Fi connection (refer to "6.1.2 Wi-Fi").
6.1.2 Wi-Fi
You can connect to the Internet when your phone is within range
of a wireless network. Wi-Fi can be used on your phone even
without a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
1 Touch on Quick setting bar to get to Settings.
2 Touch the switch in Wi-Fi to turn on/off Wi-Fi.
3 Touch Wi-Fi: detailed information of all detected Wi-Fi networks
is displayed in the Wi-Fi networks section.
4 Touch a Wi-Fi network to connect to it. If the network you
selected is secured, you are required to enter a password or other
credentials (contact network operator for details). When you’re
finished, touch Connect.
To activate notification when a new network is detected
When Wi-Fi is on and the network notification is activated, the
Wi-Fi icon will appear on the status bar whenever the phone
detects an available wireless network within range. The following
steps activate the notification function when Wi-Fi is on:
1 Touch on Quick setting bar to get to Settings.
2 Touch Wi-Fi, then key and select Advanced.
3 Touch the switch to activate/deactivate this function.
To add a Wi-Fi network
When Wi-Fi is on, you may add new Wi-Fi networks according to
your preference.
1 Touch on Quick setting bar to get to Settings.
2 Touch Wi-Fi, and then touch and select Add network.
3 Enter the name of the network and any required network
information.
4 Touch CONNECT.
When successfully connected, your phone will be connected
automatically the next time you are within range of this network.
49 50
To forget a Wi-Fi network
The following steps prevent automatic connections to networks
which you no longer wish to use.
1 Turn on Wi-Fi, if it’s not already on.
2 In the Wi-Fi screen, touch the name of the saved network.
3 Touch FORGET in the dialogue that opens.
6.2 Chrome
Using the Browser you can enjoy surfing the Web.
To get onto the Web, touch the Application tab from the Home
screen, then touch Chrome.
To go to a web page
On Browser screen, touch the URL box at the top, enter the
address of the web page, then touch to confirm.
Touch to delete all contents
Touch to search and go to this address
6.3 Connecting to Bluetooth devices
Bluetooth is a short-range wireless communication technology
that you can use to exchange data, or connect to other Bluetooth
devices for various uses.
To access this function, touch on Quick setting bar to get to
Settings, then touch Bluetooth, your device and other available
ones will show on the screen.
To turn on Bluetooth
1 Touch on Quick setting bar to get to Settings.
2 Touch to activate/deactivate this function.
To make your phone more recognizable, you can change your
phone name which is visible to others.
1 Touch on Quick setting bar to get to Settings.
2 Touch Bluetooth.
3 Touch key and select Rename this device.
4 Enter a name, and touch RENAME to confirm.
To pair/connect your phone with a Bluetooth device
To exchange data with another device, you need to turn Bluetooth
on and pair your phone with the Bluetooth device with which you
want to exchange data.
1 Touch on Quick setting bar to get to Settings.
2 Touch Bluetooth.
3 Touch a Bluetooth device you want to be paired with in the list.
4 A dialog will popup, touch PAIR to confirm.
5 If the pairing is successful, your phone connects to the device.
To disconnect/unpair from a Bluetooth device
1 Touch after the device name you want to unpair.
2 Touch FORGET.
6.4 Connecting to a computer via USB
With the USB cable, you can transfer media files and other files
between your phone and computer.
To connect:
51 52
• Use the USB cable that came with your phone to connect
the phone to a USB port on your computer. You will receive a
notification that the USB is connected.
• Open the Notification panel and touch USB for file transfer,
then, in the next dialog, choose the way in which you want to
transfer files.
Before using MTP, make sure that the driver (Windows
Media Player 11 or higher version) has been installed.
To locate data you have transferred or downloaded in the
internal storage:
1 Touch the Application tab from the Home screen to open the
apps list.
2 Touch File Manager.
All data you have downloaded is stored in File Manager, where
you can view media files (videos, photos, music and others),
rename files, install apps onto your phone, etc.
6.5 To safely remove the microSD card from
your phone
The microSD card can be removed from your phone any time
the phone is powered off. To remove the microSD card while the
phone is on, you must unmount the storage card from the phone
first, to prevent corrupting or damaging the storage card.
To format a microSD card
1 Touch on Quick setting bar to get to Settings.
2 Touch Storage.
3 Touch Unmount SD card.
You can now safely remove the microSD card from the phone.
To format a microSD card
1 Touch on Quick setting bar to get to Settings.
2 Touch Storage & USB.
3 Touch to erase microSD card.
6.6 Sharing your phone’s mobile data
connection
You can share your phone’s mobile data connection with a single
computer via a USB cable (USB tethering) or with up to eight
devices at once by turning your phone into a portable Wi-Fi
hotspot or via Bluetooth.
Sharing data may incur additional charges from your
network operator. Extra fees may also be charged in
roaming areas.
To share your phone’s data connection via USB
Use the USB cable that along with your phone to connect the
phone to a USB port on your computer.
1 Touch on Quick setting bar to go to Settings.
2 Touch More > Tethering & portable hotspot.
3 Touch the switch beside USB tethering to activate/
deactivate this function.
To share your phone’s data connection as a portable Wi-Fi
hotspot
1 Touch on Quick setting bar to go to Settings.
2 Touch More > Tethering & portable hotspot.
3 Touch the switch beside Portable Wi-Fi hotspot to
activate/deactivate this function.
To share your phone’s data connection via Bluetooth
1 Touch on Quick setting bar to go to Settings.
2 Touch More > Tethering & portable hotspot.
3 Touch the switch beside Bluetooth tethering to activate/
deactivate this function.
To rename or secure your portable hotspot
When Portable Wi-Fi hotspot is activated, you could change the
name of your phone’s Wi-Fi network (SSID) and secure its Wi-Fi
network.
53 54
1 Touch on Quick setting bar to go to Settings.
2 Touch More > Tethering & portable hotspot.
3 Touch Set up Wi-Fi hotspot to change the network SSID or set
your network security.
4 Touch SAVE.
6.7 Connecting to virtual private networks
Virtual private networks (VPNs) allow you to connect to the
resources inside a secured local network from outside that
network. VPNs are commonly deployed by corporations, schools,
and other institutions so that their users can access local network
resources when not inside that network, or when connected to a
wireless network.
To add a VPN
1 Touch on Quick setting bar to get to Settings.
2 Touch More > VPN and then touch .
3 In the screen that opens, follow the instructions from your
network administrator to configure each component of the
VPN settings.
4 Touch SAVE.
The VPN is added to the list on the VPN settings screen.
Before adding a VPN, you should set a lock screen
pattern, PIN code or password for your phone.
To connect/disconnect to a VPN
To connect to a VPN:
1 Touch on Quick setting bar to get to Settings.
2 Touch More > VPN.
3 VPNs you have added are listed; touch the VPN you want to
connect with.
4 In the dialog that opens, enter any requested credentials and
touch CONNECT.
To disconnect:
• Open the Notification panel and touch the resulting notification
for VPN disconnection.
To edit/delete a VPN
To edit a VPN:
1 Touch on Quick setting bar to get to Settings.
2 Touch More > VPN.
3 VPNs you have added are listed; touch besides the VPN you
want to edit.
4 After finished, touch SAVE.
To delete:
• Touch besides the VPN you want to delete, in the dialog
that opens, touch FORGET.
7 Google Play Store (1)
Google Play Store is an online software store, where you can
download and install applications and games to your Android
Powered Phone.
To open Google Play Store:
• Touch the Application tab from the Home screen, then touch
Google Play Store.
• For the first time you access Google Play Store, a screen with
terms of service pops up for your attention, touch Accept to
continue.
Touch key and then select Help to enter Google Play Store help
page for more information on this function.
(1) Depending on your country and operator.
55 56
8 Multimedia applications
8.1 Camera
Your mobile phone is fitted with a Camera for taking photos and
shooting videos.
Before using the Camera, please be sure to open the protective
lens cover before use to avoid it affecting your picture quality.
To access this function, touch the Application tab from the Home
screen and then touch Camera.
Slide to switch to video recorder
Touch to open settings
Touch to view pictures or
videos you have taken
Tap to focus, Pinch/Spread to
zoom in/out
Touch to switch between front/
back camera
Touch to select flash modes
Touch to take a picture
Slide to choose picture mode,
MANUAL, PANO, AUTO or
SLO-MO
Touch to select HDR function
Touch to open taking pictures delay
Touch to select night mode
To take a picture
The screen acts as the viewfinder. First position the object or
landscape in the viewfinder, touch icon to take the picture
which will be automatically saved.
To shoot a video
First position the object or landscape in the viewfinder, and touch
icon to start recording. Touch to stop recording. The
video will be automatically saved.
Further operations when viewing a picture/video you have
taken
• Touch to quick view the picture you taken.
• Touch the icon then Gmail, Bluetooth, MMS, etc to share
the photo or video you have taken.
• Touch the Back key to return to the Camera or Camcorder.
8.1.1 Settings in framing mode
Before taking a photo/shooting a video, touch the icon to
adjust a number of settings in framing mode.
Back camera shooting mode
Touch the icon to access camera settings and below options
will display for you to choose from:
• Size Touch to set the picture size.
• Gird Touch to turn on/off grid.
• Video
quality(rear)
Touch to set video quality.
• Image stabilizer Slide to enable image stabilizer.
• Storage Touch to choose storage place
• GPS tagging Touch to turn on/off the GPS tagging.
• Shutter sound Touch to turn on/off the shutter sound.
• Reset to factory
settings
Touch to reset to factory settings.
Front camera shooting mode
Switch to front camera, touch the icon to read the tip of taking
picture. To take a picture, show the palm of your hand in front of
the camera.
57 58
8.2 Gallery
Gallery acts as a media player for you to view photos and
playback videos. In addition, a set of further operations to
pictures and videos are available for your choice.
To access this function, touch the Application tab from the Home
screen, then touch Gallery.
Touch to select pictures to display
Touch to select categories:
MOMENTS, ALBUMS
Touch the picture to spread it apart
Slide up and down to view
more albums
Touch to open gallery options
To view a picture/play a video
Pictures and videos are displayed by albums in Gallery.
Slide up and down to view more pictures
• Touch an album and all pictures or videos will spread the
screen.
• Touch the picture/video directly to view or play it.
• Slide up/down to view previous or next pictures/videos.
Working with pictures
You can work with pictures by rotating or cropping them, sharing
them with friends, setting them as contact photo or wallpaper,
etc.
Locate the picture you want to work on, touch the picture
from full-screen picture view. Slide the icon bar below left and
right to select one, touch icon to share the picture, edit
icon to edit the picture and touch to delete the picture.
Touch to edit the picture: Enhance,
Effect, Frame, Mosaics, etc.
Touch to view details of the picture
or directly print it
Touch from full-screen picture view to edit a picture.
59 60
Touch to save
Effect Touch to set effect of Punch, Vintage, B/W, Art,etc.
Frame Touch to add frame.
Edit Touch to Crop, Straight or Rotate the picture.
Enhance Touch to set Autocolor, Exposure, Vignette, etc..
After activating the crop mode, the cropping square
appears in the middle of the picture. Select the portion to
crop, touch to confirm and Save, touch icon to exit
without saving.
8.3 Play music
Using this menu, you can play music files stored on the microSD
card in your phone. Music files can be downloaded from computer
to microSD card using a USB cable.
To access this function, touch the Application tab from the Home
screen, then touch Play Music.
Touch key and choose My Library, you will find five
categories in which all songs are classified: PLAYLISTS, GENRES,
ARTISTS, ALBUMS and SONGS. Slide left and right to view all.
Touch SHUFFLE ALL to shuffle all songs in SONGS category.
8.3.1 Playing music
Touch a song to play the song.
Touch to select Listen now, My
Library or Shop
Touch to search music
Touch to pause/resume playback
Touch key to get to Settings
GENERAL
Google Account Touch to choose account.
Your device Touch to access your music from up to 10
devices.
Equaliser Touch to get to audio settings.
DEVELOPER
Open-source
licences
Touch to read licences.
Music version Check version of Music.
While playing songs with Music, the operation of pause,
play or skip is still available even if the screen is locked.
61 62
Touch from songs to get available options:
Add to queue Touch to add the song into playing queue.
Add to playlist Touch to add to playlist.
Go to artist Touch to go to artist.
Go to album Touch to go to album.
Clear queue Touch to clear the song in current queue.
Save queue Touch to save queue.
8.4 Video player
To access this function, touch the Application tab from the Home
screen, then touch Video player
Video player is a small built-in video player that lists all your
videos.
Touch an item from the list to play. While playing, touch a point
on the timeline to jump to and play from.
9 Google Maps
9.1 Get My Location
9.1.1 Turn on GPS
To turn on your phone’s global positioning system (GPS) satellite
receiver:
1 Touch on Quick setting bar to go to Settings.
2 Touch Location.
3 Slide the switch to enable location and choose location
mode you preferred.
9.1.2 Open Google Maps and view My Location
Touch the Application tab from the Home screen, then touch
Maps.
Touch icon on the map to view My Location.
The map will then center on a blue dot. Your actual position will be
at the blue dot.
To move the map, drag the map with your finger.
To zoom in and out of a map, pinch or spread your fingers, or you
can also zoom in by double-tapping a location on screen.
63 64
9.2 Search for a location
While viewing a map, touch the search icon to activate search
function.
In the search box, enter an address, a city or a local business.
Touch the search icon to search, and in a while your search
results will appear on the map as red dots. You can touch one
to show a label.
Slide left or right to view
more search results
Touch to show more information
9.3 Save a location
Just like bookmarking a web address on the Internet, you can star
any position on the map for later use.
9.4 Open Street View for a location
1 Touch and hold a location to display its address at the bottom
of the maps screen.
2 Drag up the details screen to sign in to save offline.
3 Touch icon to display a Street View thumbnail.
9.5 Get driving, public transportation or
walking directions
9.5.1 Get suggested routes for your trip
Touch icon from Maps screen.
1 Touch enter bar to edit your start point by entering an address
or selecting a saved item.
2 Do likewise for your end point.
3 To reverse directions, touch .
4 Then select a transport mode: driving by car, using public
transportation, or walking directions.
5 Touch Route options to select Avoid motorways, Avoid tolls
or Avoid ferries.
6 A couple of suggested routes will appear in a list. Touch any
route to view its respective detailed direction.
65 66
10 Others
10.1 File Manager
To access this function, touch the Application tab from the Home
screen, then touch File Manager.
File Manager works with both microSD card and phone storage.
File Manager displays all data stored on both microSD card
and phone storage, including applications, media files; videos,
pictures or audios you have captured; other data transferred via
Bluetooth, USB cable, etc.
When you download an application from PC to microSD card, you
can locate the application on File Manager, then touch it to install
it in your phone.
File Manager allows you to perform and be really efficient with
the following common operations: create (sub) folder, open
folder/file, view, rename, move, copy, delete, play, share, etc.
10.2 Sound Recorder
To access this function, touch the Application tab from the Home
screen, then touch Sound Recorder.
Sound Recorder allows you to record voice/sound for seconds/
hours.
10.3 Radio
Your phone is equipped with a radio (1). You can use the application
as a traditional radio with saved channels or with parallel visual
information related to the radio program on the display if you
turn to stations that offer Visual Radio service.
To access this function, touch the Application tab from the Home
screen, then touch Radio.
(1) The quality of the radio depends on the coverage of the radio station in
that particular area.
Please insert a headset to improve the FM Radio reception
quality.
Touch to play/stop
Touch to increase 0.1MHz
Touch to go to next saved channel
Touch to add the current station
to favourites
Touch to go to previous saved channel
Touch to decrease 0.1MHz
Touch and hold to search and go to the
nearest lower frequency channel
Touch to open and view the saved
channels list
Available options:
• Save channel Save the current tuned station to the
channels list.
• Scan channels Touch to scan channels.
• Delete Delete the channel.
• Enter frequency Enter the frequency manually.
• Station info Mark the checkbox to view the station info.
• Exit Turn off the radio.
67 68
11 Settings
Drag down twice from the Notification panel and touch the
Settings icon to access Settings.
11.1 Wireless & networks
11.1.1 Wi-Fi
Using Wi-Fi you can now surf the Internet without using your SIM
card whenever you are in range of a wireless network. The only
thing you have to do is to enter the Wi-Fi screen and configure
an access point to connect your phone to the wireless network.
For detailed instructions on using Wi-Fi, please refer to "6.1.2
Wi-Fi".
11.1.2 Bluetooth
Bluetooth allows your phone to exchange data (videos, images,
music, etc.) in a small range with another Bluetooth supported
device (phone, computer, printer, headset, car kit, etc.).
For more information on Bluetooth, please refer to "6.3
Connecting to Bluetooth devices".
11.1.3 Data usage
To enable/disable mobile data by touching the switch .
Touch the switch of Set mobile data limit, then you can drag
the limit line and the warning line according to your limitation.
Your mobile data connection will be disabled when the specified
limit is reached. You can also choose a data usage cycle to view
the statistics and related applications of used data by your phone.
Touch icon, and you can view more settings related to your
data usage.
Data usage is measured by your phone, and your carrier
may count differently. Please consider using a
conservative limit.
11.1.4 More\Flight mode
Through More > Flight mode to simultaneously disable all
wireless connections including Wi-Fi, Bluetooth and more.
You can also open Flight mode in phone options when pressing
Power key.
11.1.5 More\NFC
Touch the switch . to allow data exchange when the device
touches another device.
11.1.6 More\Android Beam
When NFC is enabled, it can transmit app content to another
device.
11.1.7 More\Tethering & portable hotspot
This function allows you to share your phone’s mobile data
connection via USB or as a portable Wi-Fi access point (Please
refer to "6.6 Sharing your phone’s mobile data connection"
11.1.8 More\VPN
A mobile virtual private network (mobile VPN or mVPN) provides
mobile devices with access to network resources and software
applications on their home network, when they connect via
other wireless or wired networks. Mobile VPNs are used in
environments where workers need to keep application sessions
open at all times, throughout the working day, as the user
connects via various wireless networks, encounters gaps in
coverage, or suspend-and-resumes their devices to preserve
battery life. A conventional VPN cannot survive such events
because the network tunnel is disrupted, causing applications
to disconnect, time out, fail, or even the computing device itself
to crash.
For more information on VPN, please refer to "6.7 Connecting to
virtual private networks"
69 70
11.1.9 More\Mobile networks
• Data roaming
Touch the switch to connect to data services when roaming.
• Preferred network type
Touch to select preferred network mode.
• Access Point Names
You can select your preferred network with this menu.
• Network operators
You can select a network operator.
11.1.10 More\Emergency broadcasts
Emergency Alert Settings
• Presidential
Presidential alerts are always displayed.
• Show extreme threats
Mark the checkbox to display alerts for extreme threats to life
and property.
• Show severe threats
Mark the checkbox to display alerts for severe threats to life and
property.
• Show AMBER threats
Mark the checkbox to display child abduction emergency
bulletins.
• Turn on notifications
Mark the checkbox to display emergency alert broadcasts.
• Alert sound duration
Touch to sent Alert sound duration.
• Alert reminder
Touch to set the alert reminder
• Vibrate
Mark the checkbox to activate vibration when alert incoming.
• Speak alert message
Mark the checkbox to use text-to-speech to speak emergency
alert message.
ETWS settings
• Show ETWS test broadcasts
Mark the checkbox to display test broadcasts for Earthquake
Tsunami Warning System.
Settings for Brazil
• Show channel 50 broadcasts
Mark the checkbox to display Channel 50 which is used for Brazil
for area update information.
Settings for India
• Show channel 60 broadcasts
Mark the checkbox to display Channel 60 which is used for India
for operator specific information.
Developer options
• Show CMAS test broadcasts
Mark the checkbox to display test broadcasts for Commercial
Mobile Alert System.
• Show opt-out dialog
Mark the checkbox to show an opt-out dialog after displaying the
first CMAS alert.
71 72
11.2 Device
11.2.1 Buttons
• Camera key
Touch to enable camera key to launch the camera app and take
photos.
• Navigation buttons
Touch to see navigation buttons tip.
11.2.2 Display
• Home screen Touch to switch to activate the function of
launching favourite app by swiping right.
• Favourite Home
screen app
Touch to set your favourite your application .
• Lock screen
shortcuts
Touch to set app shortcuts on lock screen.
• Brightness level Touch to adjust the brightness of the screen.
• Adaptive
brightness
Touch to optimise brightness level for
available light.
• Wallpaper Touch to set the wallpaper.
• Screen mode Touch to set screen mode.
• Sleep Touch to set screen timeout.
• Daydream Touch to set the daydream.
• Ambient display Touch to set wake screen when you pick up
device or receive notifications.
• Pulse notification
light
Touch to turn on pulse notification light.
• Font size Touch to set the font size.
• When device is
rotated
Touch to set whether rotate the contents of
the screen or stay in portrait view.
• Cast Touch to activate cast.
11.2.3 Sound & notification
Use the Sound settings to configure ringtones for different events
and environments.
Sound
• Also vibrate for
calls
Touch to vibrate phone for incoming calls.
• Do not disturb Touch to set whether interrupt and priority
interruptions.
• Phone ringtone Touch to set your default incoming call
ringtone.
• Default
notification
ringtone
Touch to set your default notification
ringtone.
• Other sounds Touch to set dial pad tones, Screen locking
sounds, Touch sounds and Vibrate on touch.
• Audio
enhancement
Notification
• When device is
locked
Touch to select whether show all notication
content or don't show notification at all
when device is locked.
• App notificationsTouch to set app notifications.
• Notification
access
Touch to view the notification listerners.
• Do Not Disturb
access
Touch to view installed apps requested Do
Not Disturb access.
73 74
11.2.4 Apps
Use the Manage applications settings to view details about
the applications installed on your phone, to manage their data
and force them to stop, and to set whether you want to permit
installation of applications that you obtain from websites and
emails.
11.2.5 Storage & USB
Use these settings to monitor the total and available space on
your phone and on your microSD card; to manage your microSD
card; and if necessary, to reset the phone, erasing all of your
personal information.
Device storage
This menu displays the amount of internal phone storage in
different colours. The available space will be shown in grey,
which shows the amount of internal phone storage used by the
operating system, its components, applications (including those
you downloaded), permanent and temporary data.
Portable storage
Lists the amount of space on any microSD card installed in your
phone and the amount you can use to store photos, videos,
music, and other files. You can touch SD card to access the
function and learn more details.
11.2.6 Battery
In battery screen you can view the battery usage data since you
last connected the phone to a power source. The screen also
shows your battery status and how long it has been used since
last charging. Touch one category, then you can learn its specific
power consumption.
You can adjust power use via the screen brightness or screen
timeout in Display screen.
11.2.7 Memory
You use the Memory to view details about the applications used
memory in the past.
11.2.8 Users
Touch to set owner and guest account for the device.
11.2.9 Tap & pay
The device allows you to pay with just a tap without worry no
cash at hand.
11.3 Personal
11.3.1 Location
Mode
Choose mode for location access.
• High accuracy Use GPS, Wi-Fi and mobile networks to
determine location.
• Battery saving Use Wi-Fi and mobile networks to determine
location.
• Device only Mark the check box to use GPS to determine
your location.
11.3.2 Security
Screen lock
• None Touch to disable screen unlock security.
• Swipe Touch to enable slide unlock mode.
• Pattern Touch to draw pattern to unlock screen.
• PIN Touch to enter a numeric PIN to unlock screen.
• Password Touch to enter a password to unlock screen.
Make passwords visible
Mark the checkbox to show passwords as you type.
75 76
Automatically lock
Touch to set automatically lock after sleep.
Power button instantly lock
Mark the checkbox to enable Power button instantly lock the
device.
Lock screen message
Touch to set lock screen message.
Fingerprint
Touch to enable unlock with fingerprint.
Smart lock
You must set a screen lock first when you enable this function,
Encrypt phone
You can encrypt your accounts, settings, download apps and their
data, media and other files by touching Encrypt phone.
Set up SIM card lock
Choose a SIM card you want to configure.
Mark the checkbox of Lock SIM card to lock the SIM card with
PIN code.
Touch Change SIM PIN to change the PIN code.
Make passwords visible
Mark the checkbox to show passwords as you type.
Device administrators
Touch to view or deactivate device administrators.
Unknown sources
Mark the checkbox to permit installation of applications that
you obtain from web sites, emails, or other locations other than
Android Market.
To protect your phone and personal data, download applications
only from trusted sources, such as Android Market.
Storage type
Touch to choose storage type for credentials.
Trusted credentials
Touch to display trusted CA certificates.
Install from SD card
Touch to install encrypted certificates from the microSD card.
Clear credentials
Touch to remove all credentials.
Trusted agents
Touch to view or deactivate trusted agents.
Screen pinning
Touch to set screen pinning.
Apps with usage access
Touch to set the app access.
11.3.3 Accounts
Use the settings to add, remove, and manage your Email and
other supported accounts. You can also use these settings to
control how and whether all applications send, receive, and
synchronise data on their own schedules, and whether all
applications can synchronise user data automatically.
Add account
Touch to add an account for selected app.
11.3.4 Language & input
Use the Language & input settings to select the language for the
text on your phone and for configuring the onscreen keyboard.
You can also configure voice input settings and the pointer speed.
Language
Touch to select the language and the region you want.
77 78
Spell checker
Mark the checkbox to enable the system to show suggested words.
Personal dictionary
Touch to open a list of the words you’ve added to the dictionary.
Touch a word to edit or delete it. Touch the add button (+) to
add a word.
Current keyboard
Touch to select a default input method.
Google voice typing
Touch to view settings about Google voice input.
Text-to-speech output
• Prefered engine
Touch to choose a preferred text-to-speech engine, touch the
Settings icon to show more choices for each engine.
• Speech rate
Touch to open a dialog where you can select how quickly you
want the synthesiser to speak.
• Listen to an example
Touch to play a brief sample of the speech synthesiser, using your
current settings.
Default language status
Touch to show status of default language.
Pointer speed
Touch to open a dialog where you can change the pointer speed,
touch OK to confirm.
11.3.5 Backup and reset
Back up my data
Mark the checkbox to back up your phone’s settings and other
application data to Google Servers, with your Google Account.
If you replace your phone, the settings and data you’ve backed
up are restored onto the new phone for the first time you sign
in with your Google Account. If you mark this option, a wide
variety of settings and data are backed up, including your Wi-Fi
passwords, bookmarks, a list of the applications you’ve installed,
the words you’ve added to the dictionary used by the onscreen
keyboard, and most of the settings that you configure with the
Settings application. If you unmark this option, you stop backing
up your settings, and any existing backups are deleted from
Google Servers.
Backup account
Touch to back up your account.
Auto-restore
Mark the checkbox to restore your backed up settings or other
data when you reinstall an application.
Network setting reset
Touch to reset all network settings, including Wi-Fi, Mobile data
and Bluetooth.
Factory data reset
Erase all of your personal data from internal phone storage,
including information about your Google Account, any other
accounts, your system and application settings, and any
downloaded applications. Resetting the phone does not erase
any system software updates you’ve downloaded or any files
on your microSD card, such as music or photos. If you reset the
phone in this way, you’re prompted to re-enter the same kind of
information as when you first started Android.
79 80
When you are unable to power on your phone, there is another
way to perform a factory data reset by using hardware keys. Press
the Volume up key and the Power key at same time until the
screen lights up.
11.4 System
11.4.1 Date & time
Use Date & Time settings to customise your preferences for how
date and time are displayed.
Auto date & time
Touch to select Use network/GPS provided time or Off.
Mark the checkbox to use network provided time or use GPS
provided time.
Auto-time zone
Mark the checkbox to use network-provided time zone. Or
unmark to set all values manually.
Set date
Touch to open a dialog where you can manually set the phone’s
date.
Set time
Touch to open a dialog where you can manually set the phone’s
time.
Select time zone
Touch to open a dialog where you can set the phone’s time zone.
Use 24-hour format
Mark the checkbox to display the time using 24-hour clock
format.
Choose date format
Touch to open a dialog where you can select the format for
displaying dates.
11.4.2 Accessibility
You use the Accessibility settings to configure any accessibility
plug-ins you have installed on your phone.
TalkBack
Touch to turn on/off TalkBack.
Switch Access
Touch to turn on/off switch access.
Captions
Touch to activate/deactivate captions for phone screen.
Magnification gestures
Touch to turn on/off to activate/deactivate zoom in/out function
by triple-tapping the screen.
Large text
Mark the checkbox to enlarge the screen text.
High contrast text
Mark the checkbox to activate high contrast text.
Power button ends call
Mark the check box to enable Power button ends call.
Auto-rotate screen
Mark the checkbox to activate auto-rotate screen.
Speak passwords
Mark the checkbox to speak passwords while typing.
Help Tips
Mark the checkbox to enable help tips.
Accessibility shortcut
Touch to turn on/off to enable/disable accessibility features.
Text-to-speech output
Refer to "Preferred engine/Speech rate/Listen to an example"
setting before.
81 82
Long press delay
Touch to adjust the duration of long press delay. This function
enables your phone to differ touch and long press, which may
avoid incorrect operations.
Colour inversion
Touch the switch to turn on/off colour inversion.
Colour correction
Touch to turn on/off colour correction.
11.4.3 Printing
The device provides the printing service which support the file
and pictures to print directly after connecting with printer.
11.4.4 Regulatory & Safety
Touch to view Regulatory & Safety information, including Product
model, Manufacturer name, etc.
11.4.5 About phone
This contains information about things ranging from Legal
information, Model number, Firmware version, Baseband version,
Kernel version, Build number to those listed below:
Software updates
Touch to check for system updates.
Experience improvement
Touch to enable experience improvement.
Status
This contains the status of the Battery status, Battery level, My
phone number, Network, Signal strength, etc.
Legal information
Touch to view legal information.
12 Update your phone’s
software
Using the FOTA (Firmware Over The Air) Upgrade tool you can
update your phone’s software.
To access Software Updates, touch Settings > About phone >
Software updates. Touch Check for updates, and the phone will
search for the latest software. If you want to update the system,
please touch Download, and when that’s finished, touch Install to
complete the upgrade. Now your phone will have the latest version
of the software.
You should turn on data connection before searching for updates.
Settings for auto-check intervals and Wi-Fi only about upgrades
are also available once you restart the phone.
If you have chosen auto-check, when the system discovers the
new version, the icon will appear in the status bar. Touch the
notification to access the Software Updates directly.
During FOTA downloading or updating, to avoid errors in
locating the correct update packages, do not change
your default storage location.
83 84
13 Safety and use
We recommend that you read this chapter carefully before using
your mobile phone. The manufacturer disclaims any liability for
damage, which may result as a consequence of improper use or
use contrary to the instructions contained herein.
• TRAFFIC SAFETY
Given that studies show that using a mobile phone while driving
a vehicle constitutes a real risk, even when the hands-free kit
is used (car kit, headset...), drivers are requested to refrain from
using their mobile phone when the vehicle is not parked. Check
the laws and regulations on the use of wireless mobile phones
and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted
in certain areas.
When driving, do not use your mobile phone and headphone
to listen to music or to the radio. Using a headphone can be
dangerous and forbidden in some areas.
When switched on, your mobile phone emits electromagnetic
waves that can interfere with the vehicle’s electronic systems
such as ABS anti-lock brakes or airbags. To ensure that there is
no problem:
-do not place your mobile phone on top of the dashboard or
within an airbag deployment area,
-check with your car dealer or the car manufacturer to make sure
that the car’s electronic devices are shielded from mobile phone
RF energy.
• CONDITIONS OF USE
You are advised to switch off the mobile phone from time to time
to optimize its performance.
Remember to abide by local authority rules of mobile phone use
on aircrafts.
Operational Warnings: Obey all posted signs when using mobile
devices in public areas.
Follow Instructions to Avoid Interference Problems: Turn off your
mobile device in any location where posted notices instruct you
to do so. In an aircraft, turn off your mobile device whenever
instructed to do so by airline staff. If your mobile device offers
an airplane mode or similar feature, consult airline staff about
using it in flight.
Switch the mobile phone off when you are in health care
facilities, except in designated areas. As with many other types
of equipment now in regular use, mobile phones can interfere
with other electrical or electronic devices, or equipment using
radio frequency.
Switch the mobile phone off when you are near gas or flammable
liquids. Strictly obey all signs and instructions posted in a fuel
depot, gas station, or chemical plant, or in any potentially
explosive atmosphere.
When the mobile phone is switched on, it should be kept at
least 15 cm from any medical device such as a pacemaker, a
hearing aid or insulin pump. In particular when using the mobile
phone you should hold it against the ear on the opposite side
to the device, if any. Read and follow the directions from the
manufacturer of your implantable medical device. If you have any
questions about using your mobile device with your implantable
medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding your
mobile phone to your ear. Also move the handset away from your
ear while using the “hands-free” option because the amplified
volume might cause hearing damage.
It is recommended to have proper supervision while small
children use your mobile phone.
Always handle your mobile phone with care and keep it in a clean
and dust-free place.
85 86
Do not allow your mobile phone to be exposed to adverse
weather or environmental conditions (moisture, humidity, rain,
infiltration of liquids, dust, sea air, etc.). The manufacturer’s
recommended operating temperature range is -10°C (14°F) to
+40°C (104°F) (the max value depends on device, materials and
housing paint/texture).
Over 50°C (122°F) the legibility of the mobile phone’s display
may be impaired, though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is
damaged, cracked or broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are
recommended by TCL Communication Ltd. and its affiliates
and are compatible with your mobile phone model.TCL
Communication Ltd. and its affiliates disclaim any liability for
damage caused by the use of other chargers or batteries.
Your mobile phone should not be disposed of in a municipal
waste. Please check local regulations for disposal of electronic
products.
Remember to make back-up copies or keep a written record of all
important information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts when
exposed to flashing lights, or when playing video games. These
seizures or blackouts may occur even if a person never had a
previous seizure or blackout. If you have experienced seizures
or blackouts, or if you have a family history of such occurrences,
please consult your doctor before playing video games on your
mobile phone or enabling a flashing-lights feature on your
mobile phone. Parents should monitor their children’s use of
video games or other features that incorporate flashing lights on
the mobile phones.
All persons should discontinue use and consult a doctor if any
of the following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary movements, or
disorientation. To limit the likelihood of such symptoms, please
take the following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may experience
occasional discomfort in your hands, arms, shoulders, neck,
or other parts of your body. Follow these instructions to avoid
problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders:
-Take a minimum of a 15-minute break every hour of game
playing.
-If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.-
-If you continue to have sore hands, wrists, or arms during or after
playing, stop the game and see a doctor.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at
high volume levels for long periods. Exercise caution
when holding your device near your ear while the
loudspeaker is in use.
•CHARGERS
Home A.C./ Travel chargers will operate within the temperature
range of: 0°C (32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the
standard for safety of information technology equipment and
office equipment use. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction may
not work in another jurisdiction. They should be used for this
purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: XXX
Output: XXX
87 88
Battery: 3000 mAh
• RADIO WAVES
THIS MOBILE PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits
for exposure to radio-frequency (RF) energy. These limits are part
of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. These guidelines include a substantial safety
margin designed to ensure the safety of all persons, regardless
of age and health.
The exposure standard for mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by public authorities such as the Federal
Communications Commission of the US Government (FCC), or by
Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue.
Tests for SAR are conducted using standard operating positions
with the mobile phone transmitting at its highest certified power
level in all tested frequency bands.
Although the SAR is determined at the highest certified power
level, the actual SAR level of the mobile phone while operating
can be well below the maximum value. This is because the mobile
phone is designed to operate at multiple power levels so as to
use only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the lower
the power output of the mobile phone. Before a mobile phone
model is available for sale to the public, compliance with national
regulations and standards must be shown.
The highest SAR value for this model mobile phone when tested
is 1.13 W/Kg for use at the ear and 1.16 W/Kg for use close to
the body.
While there may be differences between the SAR levels of
various mobile phones and at various positions, they all meet
the government requirement for RF exposure. For body-worn
operation, the mobile phone meets FCC RF exposure guidelines
provided that it is used with a non-metallic accessory with the
handset at least 10 mm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.ctia.org/
The World Health Organization (WHO) considers that present
scientific information does not indicate the need for any
special precautions for use of mobile phones. If individuals
are concerned, they might choose to limit their own or their
children’s RF exposure by limiting the length of calls, or using
“hands-free” devices to keep mobile phones away from the head
and body. Additional WHO information about electromagnetic
fields and public health are available on the following website:
http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
89 90
-Consult the dealer or an experienced radio/ TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
For the receiver devices associated with the operation of a
licensed radio service (e.g. FM broadcast), they bear the following
statement:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.
For other devices, they bear the following statement: This device
complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For
optimal operation, you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used
in positions other than against your ear. In such circumstances
the device will be compliant with the guidelines when used with
headset or usb data cable. If you are using another accessory
ensure that whatever product is used is free of any metal and that
it positions the mobile phone at least 10 mm away from the body.
Licences
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by TCL Communication Ltd. and its
affiliates is under license. Other trademarks
and trade names are those of their respective
owners.
VFD 900
Bluetooth Declaration ID D029817
The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.
Google, the Google logFo, Android, the
Android logo, Google SearchTM, Google MapsTM,
GmailTM, YouTube, Google Play Store, Google
LatitudeTM and HangoutsTM are trademarks of
Google Inc.
The Android robot is reproduced or modified from work created
and shared by Google and used according to terms described in
the Creative Commons 3.0 Attribution License (the text will show
when you touch and hold Google legal in Settings > About
phone > Legal information) (1).
You have purchased a product which uses the open source
(http://opensource.org/) programs mtd, msdosfs, netfilter/
iptables and initrd in object code and other open source
programs licensed under the GNU General Public License and
Apache License.
We will provide you with a complete copy of the corresponding
source codes upon request within a period of three years from the
distribution of the product by TCT.
(1) This may not be available depending on your country.
91 92
You may download the source codes from http://sourceforge.
net/projects/alcatel/files/. The provision of the source code is
free of charge from internet.
FCC ID: 2ACCJN007
14 General information
•Website:www.alcatelonetouch.com
•Facebook:http://www.facebook.com/alcatelonetouchusa
•Twitter:http://www.twitter.com/alcatel1touch
•HotLineNumber:IntheUnitedStates,call877-702-3444for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked
Questions) section. You can also contact us by e-mail to ask any
questions you may have.
An electronic version of this user guide is available in English and
other languages according to availability on our server:
www.alcatelonetouch.com
Your telephone is a transceiver that operates on GSM in quad-
band with 850/900/1800/1900 MHz, WCDMA in Tri-band with
B1/B5/B8 or LTE in Six-band with B1/B3/B5/B7/B8/B20 and
TDD with B38.
• Protection against theft(1)
Your mobile phone is identified by an IMEI (mobile phone serial
number) shown on the packaging label and in the product’s
memory. We recommend that you note the number the first time
you use your mobile phone by entering *#06# and keep it in a
safe place. It may be requested by the police or your operator if
your mobile phone is stolen.
(1) Contact your network operator to check service availability.
• Disclaimer
There may be certain differences between the user manual
description and the mobile phone’s operation, depending on
the software release of your mobile phone or specific operator
services.
TCL Communication Ltd. shall not be held legally responsible
for such differences, if any, nor for their potential consequences,
which responsibility shall be borne by the operator exclusively.
14 TCL Communication Ltd. (US), Inc Warranty
TCL Communication Ltd. (US), Inc. warrants to the original retail
purchaser of this wireless device that should this product or
part thereof during normal consumer usage and condition be
proven to be defective in material or workmanship that results
in product failure within the first twelve (12) months from the
date of purchase as shown on your original sales receipt from an
authorized sales agent. Such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the company’s option without
charge for parts or labor directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box
items are also warranted against defects and workmanship that
results in product failure within the first six (6) months period
from the date of purchase as shown on your original sales receipt.
Such defect(s) will be repaired or replaced (with new or rebuilt
parts) at the company’s option without charge for parts or labor
directly related to the defect(s).
The limited warranty for your wireless device will be voided if any
of the following conditions occur:
•Non-compliancewiththeinstructionsforuseorinstallation,or
with technical and safety standards applicable in the geographical
area where your phone is used;
•Connectiontoanyequipmentnotsuppliedornotrecommended
by TCL Communication Ltd. (US), Inc.;
•Modificationorrepairperformedbyindividualsnotauthorized
by TCL Communication Ltd. (US), Inc. or its affiliates;
93 94
• Changes to the device operating system by the user or third
party applications;
•Actsofgodsuchasinclementweather,lightning,powersurges,
fire, humidity, infiltration of liquids or foods, chemical products,
download of files, crash, high voltage, corrosion, oxidation;
•Removaloralteringofthewirelessdevice’seventlabelsorserial
numbers (IMEI);
• Damage from exposure to water or other liquids,
moisture,humidity, excessive temperatures or
extreme,environmental conditions, sand, excess dust and any
condition outside the operating guidelines;
•Defectsinappearance,cosmetic,decorativeorstructuralitems
such as framing and non-operative parts;
•Damageasresultofphysicalabuseregardlessofcause.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory
warranty provided by your jurisdiction. In no event shall TCL
Communication Ltd. (US), Inc. or any of its affiliates be liable for
incidental or consequential damages of any nature whatsoever,
including but not limited to commercial loss, to the full extent
those damages can be disclaimed by law. Some states do not
allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so
the preceding limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer care center by
calling (877-702-3444) or going to (http://www.alcatelonetouch.
com/usa/). We have placed many self-help tools that may help
you to isolate the problem and eliminate the need to send
your wireless device in for service. In the case that your wireless
device is no longer covered by this limited warranty due to time
or condition, you may utilize our out of warranty repair options.
How to obtain Hardware Service within the terms of this warranty:
Create a user profile (alcatel.finetw.com) and then create an
RMA for the defective device. Ship the device with a copy of the
original proof of purchase (e.g. original copy of the dated bill
of sale, invoice) with the owner’s return address (No PO Boxes
accepted), wireless carrier’s name, alternate daytime phone
number, and email address with a complete problem description.
Only ship the device. Do not ship the SIM card, memory cards,
or any other accessories such as the power adapter. You must
properly package and ship the wireless device to the repair
center. TCL Communication Ltd. (US), Inc. is not responsible for
devices that do not arrive at the service center or are damaged
in transit.Insurance is recommended with proof of delivery. Upon
receipt, the service center will verify the warranty conditions,
repair, and return your device to the address provided in the RMA.
Check the warranty repair status by going online with the RMA
number on web portal.
95 96
15 Accessories
The latest Vodafone Smartphones offers a built-in handsfree
feature that allows you to use the telephone from a distance,
placed on a table for example. For those who prefer to keep their
conversations confidential, an earpiece is also available known
as the headset.
1. SmartPlatunum 7
2. Charger
3. USB cable
4. Headset
5. Quick Start Guide
6. SIM tooling pin
7. Safety and warranty
8. Leaflet
Only use your telephone with the chargers and
accessories in your box.
16 Specifications
Processor Qualcomm MSM8976+1.8GHz Quad Core
Platform Android™ M
Memory 32GB + 3GB RAM
Dimensions
(LxWxT) 154*75.65*6.99 mm
Weight Around 180 grams with battery
Display 5.5-inch touchscreen with
2560×1440 WQHD Capacity resolution
Network GSM:
Quad-band 850/900/1800/1900 MHz
WCDMA:
Tri-band B1/B5/B8
LTE:
Penta-band B1/B3/B5/B7/B8/B20
(Band frequency and data speed are
operator dependent.)
GPS Assisted GPS/Internal GPS antenna
Connectivity Bluetooth V4.2
Wi-Fi IEEE 802.11 a/b/g/n/ac
3.5 mm audio jack
Micro-USB
Camera 16 megapixel back camera
8 megapixel front camera
Audio supported
formats
AAC LC, AAC+, enhanced AAC+, AMR-NB,
AMR-WB, FLAC, MP3, MIDI, Vorbis, PCM/
WAVE
97 98
Video supported
formats H.263, H.264 AVC, MPEG-4 SP, VP8
Battery Rechargeable Lithium battery
Capacity: 3000 mAh
Expansion Slot microSD™ memory card (Maximum 128 GB)
Special Features G-sensor
Proximity sensor
Light sensor
E-Compass
Gyroscope
Note: Specifications are subject to change without prior notice.
99 100
