TCL Technoly Electronics OH000022 Beacon User Manual TX Air DFU draft 0508
TCL Technoly Electronics (Huizhou) Co., Ltd. Beacon TX Air DFU draft 0508
User manual
007-AG0067
CCAJ 17LP934XXX CMIIT ID: XXXXXXXXX
FCC ID: ZVAOH000022
DXXXXX
WHERE EXTx
Model: EXTx Air
EXTx Air
User Guide
WHERE, Inc.
Type of Wireless Operating Frequency Maximum RF Power
Bluetooth 2402-2480MHz 2±3dBm
1. Declaration of Conformity ( DoC)
Hereby, WHERE, Inc, declares that this
equipment is in compliance with
the essential requirements and other
relevant provisions of Directive2014/53/EU;
Customers can download a copy of
the
DoCfor our radio
equipment from our website below:
Http://where123.jp
(You can refine and customize the
language used for this section)
original
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
The battery(battery or batteries or battery
pack) shall not be exposed to excessive heat
such as sunshine ,fire or the like.
WARNING :If battery compartment does not
close securely, stop using the product and keep
it away from children and pets
WARNING: Do not recharge non - rechargeable
batteries
WARNING : Please refer to the information on
exterior bottom enclosure for electrical and
Safety information before installing or
operating the apparatus
對含低功率射頻之設備：
根據NCC低功率管理辦法規定：
第十二條輕型式認證合格之低功率射頻電機，非經許可，公司，商號或
使用者均不得擅自變更頻率，加大功率或變更原設計之特性及功能。
第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經
發現有乾擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須
忍受合法通信或工業，科學及醫療用電波輻射性電機設備之干擾.
低功率電波輻射性電機管理辦法
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均
不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干
擾現象時，應改善至無干擾時方得繼續使用。前項合法通信，指依電信
法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科
學及醫療用電波輻射性電機設備之干擾。
74mm
296mm
材质：80g书纸，正反双面印刷
Top Cover
Back
ITEMS Specification
Dimension
Weight 12g
Platform CSR1012
Bluetooth Standard Version 4.2
Operating temperature
Operating humidity <=95%
Power (Battery)
Power (Battery Life) 3 months
Application ,Design and Materials Copyright
2018 WHERE , Inc
Bluetooth and Bluetooth Logo Property of Bluetooth SIG, Inc.
Visit http://where123.jp for more detail product information
EXTx Air is not a stand-alone product. For best performance it
should be used in conjunction with Gateway+ and EXTx Air as
a set. Depending on the use case, the firmware can be
updated. By tagging objects with EXTx Air in a Bluetooth-based
mesh network, it becomes easy to track and to find these
objects. Control and monitoring can be done from smartphones
and tablets.
Refer to as below image.
EXTx Air can be attached to objects or worn by people.
With location of EXTX Air, user can tracking any items/people
EX Array
正面
反面
WHERE,Inc.
Printed in China
85.6mm*54mm*1.2mm
-10~60
100mAh
FCC Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help important announcement
Important Note:
Radiation Exposure Statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance 0mm between the radiator and your
body.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
