Introduction ................................

TCT Mobile Limited would like to thank you for purchasing this cellphone.

Power multimedia player/video player

• With playlist, lyrics display and equalizer

• Full screen video playback (1)

• View videos on the 1.8" CSTN landscape display

USB mass storage

Simply a USB key for storing/accessing data.

Webcam

The best companion for PC instant messaging.

Bluetooth (1)

• Bluetooth 2.0

• A2DP profile (Bluetooth stereo)

(1) OT-S621A only.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 1

12 Media album ................................................................56

12.1 My Audio..............................................................................................56

12.2 My images ............................................................................................57

12.3 My videos ............................................................................................57

12.4 My creations........................................................................................57

12.5 Unknown files ....................................................................................57

12.6 Memory card ......................................................................................58

12.7 Managing audio, images, videos and creations ............................59

12.8 Compatible formats ..........................................................................60

12.9 Memory status....................................................................................60

13 Camera ........................................................................61

13.1 Access ..................................................................................................61

13.2 Camera ................................................................................................61

14 Multimedia player ........................................................65

14.1 Multimedia player ..............................................................................65

14.2 Settings ................................................................................................66

14.3 Playing with lyrics ..............................................................................66

15 Games & Applications ................................................67

15.1 Launch an application........................................................................67

15.2 Java settings ........................................................................................67

15.3 Java downloading................................................................................67

16 Profiles ..........................................................................69

17 Making the most of your mobile................................70

17.1 PC suite................................................................................................70

18 Latin input mode/character table..............................71

19 Telephone warranty ....................................................75

20 Accessories ....................................................................77

21 Troubleshooting ............................................................78

7 Messages ......................................................................36

7.1 Messages:Text/Multimedia message ..............................................36

7.2 Voice message ....................................................................................38

7.3 Photo message....................................................................................38

7.4 Email......................................................................................................39

7.5 Voicemail..............................................................................................39

7.6 Settings ................................................................................................39

8 My settings....................................................................41

8.1 Ringtones ............................................................................................41

8.2 Colour ..................................................................................................42

8.3 Theme ..................................................................................................42

8.4 Antenna off/Airplane mode ............................................................43

8.5 Equalizer ..............................................................................................43

8.6 Display ..................................................................................................43

8.7 Clock ....................................................................................................44

8.8 Keys ......................................................................................................44

8.9 More settings......................................................................................45

9 Tools ..............................................................................48

9.1 Bluetooth™ ........................................................................................48

9.2 Organizer ............................................................................................49

9.3 Alarm ....................................................................................................50

9.4 Calculator ............................................................................................50

9.5 Converter............................................................................................51

9.6 Voice memo ........................................................................................51

9.7 Memory status....................................................................................52

10 My shortcuts ................................................................53

11 WAP ..............................................................................54

11.1 Homepage............................................................................................54

11.2 Bookmarks ..........................................................................................54

11.3 Recent pages ......................................................................................54

11.4 Go to URL ..........................................................................................54

11.5 Profiles..................................................................................................54

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 3

Do not open or attempt to repair your cellphone yourself.

Do not drop, throw or try to bend your cellphone.

Do not paint it.

Use only batteries, battery chargers, and accessories which are recommended by TCT Mobile

Limited and its affiliates and are compatible with your cellphone model (see Accessories List page

77).TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the use of other

chargers or batteries.

Your cellphone should not be disposed of in a municipal waste. Please check local regulations for

disposal of electronic products.

Remember to make back-up copies or keep a written record of all important information stored

in your cellphone.

Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when

playing video games.These seizures or blackouts may occur even if a person never had a previous

seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history

of such occurrences, please consult your doctor before playing video games on your cellphone or

enabling a flashing-lights feature on your cellphone. Parents should monitor their children’s use of

video games or other features that incorporate flashing lights on the cellphones.All persons should

discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or

muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the

likelihood of such symptoms, please take the following safety precautions:

- Do not play or use a flashing-lights feature if you are tired or need sleep.

- Take a minimum of a 15 minute break.

- Play in a well lit environment.

- Play at the farthest distance possible from the screen.

When you play games on your cellphone, you may experience occasional discomfort in your hands,

arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems

such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders:

- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours

before playing again.

- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see

a doctor.

Prolonged exposure to music at full volume when listening to music may cause hearing

impairment. Adjust the volume before placing headphones on or in your ear. Only use

headphones recommended by TCT Mobile Limited and its affiliates.

•PRIVACY:

Please note that you must respect the laws and regulations in force in your jurisdiction or other

jurisdiction(s) where you will use your cellphone regarding taking photographs and recording

sounds with your cellphone. Pursuant to such laws and regulations, it may be strictly forbidden to

take photographs and/or to record the voices of other people or any of their personal attributes,

and reproduce or distribute them, as this may be considered to be an invasion of privacy. It is the

user's sole responsibility to ensure that prior authorization be obtained, if necessary, in order to

record private or confidential conversations or take a photograph of another person; the

manufacturer, the seller or vendor of your cellphone (including the operator) disclaim any liability

which may result from the improper use of the cellphone.

Safety and use ............................

We recommend that you read this chapter carefully before using your cellphone.The manufacturer

disclaims any liability for damage, which may result as a consequence of improper use or use

contrary to the instructions contained herein.

•TRAFFIC SAFETY:

Given that studies show that using a cellphone while driving a vehicle constitutes a real risk, even

when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their

cellphone when the vehicle is not parked. Check the laws and regulations on the use of wireless

telephones and their accessories in the areas where you drive.Always obey them.The use of these

devices may be prohibited or restricted in certain areas.

When driving, do not use your cellphone and headphone to listen to music or to the radio. Using

a headphone can be dangerous and forbidden in some areas.

When switched on, your cellphone emits electromagnetic waves that can interfere with the

vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no

problem:

- do not place your cellphone on top of the dashboard or within an airbag deployment area,

- check with your car dealer or the car manufacturer to make sure that the car’s electronic devices

are shielded from cellphone RF energy.

•CONDITIONS OF USE:

You are advised to switch off the telephone from time to time to optimize its performance.

Switch the cellphone off before boarding an aircraft.

Switch the cellphone off when you are in health care facilities, except in designated areas.As with

many other types of equipment now in regular use, cellphones can interfere with other electrical

or electronic devices, or equipment using radio frequency.

Switch the cellphone off when you are near gas or flammable liquids. Strictly obey all signs and

instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive

atmosphere.

When the cellphone is switched on, it should be kept at least 15 cm from any medical device such

as a pacemaker, a hearing aid or insulin pump. In particular when using the cellphone you should

hold it against the ear on the opposite side to the device, if any.

To avoid hearing impairment, answer the call before holding your cellphone to your ear.Also move

the handset away from your ear while using the “hands-free” option because the amplified volume

might cause hearing damage.

Do not let small children use your cellphone without supervision.

When replacing the cover please note that your cellphone may contain substances that could

create an allergic reaction.

Always handle your cellphone with care and keep it in a clean and dust-free place.

Do not allow your cellphone to be exposed to adverse weather or environmental conditions

(moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.).The manufacturer’s recommended

operating temperature range is -10°C to +55°C (the max value depends on device, materials and

housing paint/texture). Over 55°C the legibility of the cellphone’s display may be impaired, though

this is temporary and not serious.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 5

•RADIO WAVES:

THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO

WAVES.

Your cellphone is a radio transmitter and receiver. It is designed and manufactured not to exceed

the emission limits for exposure to radio-frequency (RF) energy. These limits are part of

comprehensive guidelines and establish permitted levels of RF energy for the general population.

The guidelines are based on standards that were developed by independent scientific organizations

through periodic and thorough evaluation of scientific studies.These guidelines include a substantial

safety margin designed to ensure the safety of all persons, regardless of age and health.

The exposure standard for cellphones employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal

Communications Commission of the US Government (FCC), or by Industry Canada, is 1.6 W/kg

averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating

positions with the cellphone transmitting at its highest certified power level in all tested frequency

bands.

Although the SAR is determined at the highest certified power level, the actual SAR level of the

cellphone while operating can be well below the maximum value.This is because the cellphone is

designed to operate at multiple power levels so as to use only the power required to reach the

network. In general, the closer you are to a wireless base station antenna, the lower the power

output of the cellphone Before a cellphone model is available for sale to the public, compliance with

national regulations and standards must be shown.

The highest SAR value for this model cellphone when tested is

OT-S520A : 1.15 W/Kg for use at the ear and 1.17 W/Kg for use close to the body.

OT-S621A : XXX W/Kg for use at the ear and XXX W/Kg for use close to the body.

While there may be differences between the SAR levels of various cellphones and at various

positions, they all meet the government requirement for RF exposure. For body-worn operation,

the cellphone meets FCC RF exposure guidelines provided that it is used with a non-metallic

accessory with the handset at least 1.5 cm from the body. Use of other accessories may not ensure

compliance with FCC RF exposure guidelines.

The World Health Organization (WHO) considers that present scientific information does not

indicate the need for any special precautions for use of cellphones. If individuals are concerned, they

might choose to limit their own or their children's RF exposure by limiting the length of calls, or

using "hands-free" devices to keep cellphones away from the head and body. (fact sheet n°193).

Additional WHO information about electromagnetic fields and public health are available on the

following website: http://www.who.int/peh-emf.

•BATTERY:

Before removing the battery from your cellphone, please make sure that the cellphone is switched

off.

Observe the following precautions for battery use:

- Do not attempt to open the battery (due to the risk of toxic fumes and burns).

- Do not puncture, disassemble or cause a short-circuit in a battery,

- Do not burn or dispose of a used battery in the garbage or store it at temperatures above 60

°C.

Batteries must be disposed of in accordance with locally applicable environmental regulations. Only

use the battery for the purpose for which it was designed. Never use damaged batteries or those

not recommended by TCT Mobile Limited and/or its affiliates.

This symbol on your telephone, the battery and the accessories means that these

products must be taken to collection points at the end of their life:

- Municipal waste disposal centers with specific bins for these items of equipment

- Collection bins at points of sale.

They will then be recycled, preventing substances being disposed of in the environment, so that

their components can be reused.

In European Union countries:

These collection points are accessible free of charge.All products with this sign must be brought

to these collection points.

In non European Union jurisdictions:

Items of equipment with this symbol are not be thrown into ordinary bins if your jurisdiction or

your region has suitable recycling and collection facilities; instead they are to be taken to collection

points for them to be recycled.

In the United States you may learn more about CTIA’s Recycling Program at

www.recyclewirelessphones.com

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

•CHARGERS

Home A.C. chargers will operate within the temperature range of: 0°C to 40°C.

The chargers designed for your cellphone meet with the standard for safety of information

technology equipment and office equipment use.

Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may

not work in another jurisdiction.

They should be used for this purpose only.

Characteristics of power supply (depending on the country):

110 V charger (used in Mexico/USA):

Input : 100-240 V, 50/60 Hz, 0.15 A

Output : 5 V, 400mA

Battery: Lithium 700 mAh

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 7

General information ..................

•Website: www.alcatel-mobilephones.com

•Hot Line Number: see “TCT Mobile Services” leaflet or go to our

Internet site.

On our Internet site, you will find our FAQ (Frequently Asked Questions)

section. You can also contact us by e-mail to ask any questions you may

have.

Your telephone is a transceiver that operates on GSM networks with 850

and 1900 MHz bands.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid

touching it or degrading it.

•LICENCES

Obigo® is a registered trademark of Obigo AB.

microSD Logo is a trademark.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any

use of such marks by TCT Mobile Limited and its affiliates is under license. Other

trademarks and trade names are those of their respective owners.

OT-S621A Bluetooth QG ID B014013.

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos.

5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548,

6,307,549, and 6,636,162, 6,646,573; European Pat. Nos. 0 842 463 (96927260.8), 1

010 057 (98903671.0), 1 018 069 (98950708.2); and additional patents are pending

worldwide.

Java™ and all Java™ based trademarks and logos are trademarks or registered

trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 9

1Your mobile ..........................

OT-S520A

Protection against theft (1)

Your cellphone is identified by an IMEI (cellphone serial number) shown

on the packaging label and in the product’s memory.We recommend that

you note the number the first time you use your telephone by entering

*#06# and keep it in a safe place. It may be requested by the police or

your operator if your telephone is stolen.

Disclaimer

There may be certain differences between the user manual description

and the cellphone’s operation, depending on the software release of your

telephone or specific operator services.

Voicemail

Switch on/

Switch off

End call

Left softkey

Right softkey

Answer/Send Call

Call memory

Navigation key (1):

Menu/Confirm an

option

Messages

Directory

Messages

Organizer

Services (1)

Voice memo (record your current call).

You may also switch from handset to a BT device when connected.

(1) Contact your network operator to check service availability.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 23

4Menu ......................................

From the menu interface, you may directly access features by pressing the

corresponding key (number keys and and keys).

1. GAMES (1)

1. GAMES & APPS (2)

2. MEDIA ALBUM

- My Audio

- My images

- My videos (2)

- My creations

- Unknown files

- Memory card (2)

- Memory status

3. TOOLS

- Bluetooth (2)

- Organizer

- Alarm

- Calculator

- Converter

- Voice memo

- Memory status

4. CAMERA

- Camera

- My creations

5. DIRECTORY

6. MESSAGES

- Messages

- Voice message

- Photo message

- Email

- Voicemail

- Settings

7. CALL REGISTER

- Call memory

- My numbers

- Billing

- Call settings

3.6 Line switching (1)

Your SIM card can contain two distinct telephone numbers. Under “Call

outgoing calls will be made from this number. Incoming calls will still be

received from both lines despite the default set.

The services programmed on the default line do not impact those

selected on the other line.

(1) Contact your network operator to check service availability.

(1) OT-S520A only.

(2) OT-S621A only.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 25

5Call register ....................

5.1 Call memory

You can access your call memory by pressing the key from the main

screen. Choose the option of the desired list:

Unanswered calls

Outgoing calls (Redial)

Answered calls

Select a number of the call memory and press the “Options” softkey to

View call details, Create text/multimedia message,Save or Delete

the selected number or clear the entire list (Delete all).

5.2 My numbers

Type in or modify your telephone number or the number to access your

voicemail and confirm by pressing . Your telephone number is usually

written on your SIM card.

2827

8. MY SETTINGS

- Ringtones

- Colour

- Theme

- Antenna off/Airplane mode

- Equalizer

- Display

- Clock

-Keys

- More settings...

9. MY SHORTCUTS

*. SERVICES (1)

-VAS

- Service dial number

- Data account

- My One Touch

0. MULTIMEDIA PLAYER (2)

- All songs

- All videos

- Playlist

- Update songs

- Album

- Artist

- Genre

- My star list

0. PROFILES (3)

#. WAP

- Homepage

- Bookmarks

- Recent pages

- Go to URL

- Profiles

(1) Contact your network operator to check service availability.

(2) OT-S621A.

(3) OT-S520A.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 27

•Conditional: forward calls if your line is busy, unavailable, or outside of

the network coverage area.

5.4.3 Call barring

You can activate or deactivate call barring for outgoing and incoming calls.

The various options are:

Outgoing calls •The following configurations are possible:

•All calls •All outgoing calls are barred.

•All calls except •All outgoing calls except those in SIM directory are

SIM directory barred.

•International calls •Outgoing international calls are barred.

•International •Outgoing international calls except those to your

except home country of subscription are barred.

Incoming calls •The following configurations are possible:

•All calls •All incoming calls are barred.

•All calls except •All incoming calls except those in SIM directory are

SIM directory barred.

•Roaming •Incoming calls are barred when you are abroad.

Cancel all •Deactivate all call barring.

barring

Change barring •Change the original PW for activating call barring.

5.3 Billing

In the billing menu, you may access the following items:

Amount •You can view the total cost of charged calls, modify

it or reset it and enter the cost of a Telecom Unit in

the currency of your choice.

Duration •You can view the total duration of all outgoing calls

or reset it.

GPRS counter •Management of the volume of data communications

charged for (in kilobytes).

Beep duration •You can activate or cancel the beep emitted during

a call with a specified frequency (enter the

frequency and confirm by ).

5.4 Call settings (1)

In the call settings menu, you may access the following items:

5.4.1 Call waiting

Activate/Deactivate the audible tone when an incoming call is received.

5.4.2 Call forwarding

You may activate, cancel or verify call forwarding status to voicemail, or a

specified number. The following call forwarding options are available:

•Unconditional: systematic forwarding of all incoming calls. The icon

is displayed.

(1) Contact your network operator to check service availability.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 29

6Directory ........................

6.1 Accessing your directory/phone book

To access the directory from the main screen, press the key (1) or

press the key and select the icon from the menu.

You may also create a shortcut for quick access to your directory (see

page 45).

You have 4 directories:

SIM directory

General

Phone directory

Group

In addition to the directories already provided, you can create up to 5

groups (maximum 100 entries per group).

(1) Depending on your network operator.

5.4.4 Caller ID

Query CLIP status and activate/deactivate CLIP.

5.4.5 Conceal ID

Query CLIR status and activate/deactivate CLIR.

5.4.6 Line switching (1)

Line switch between line 1 and line 2.

5.4.7 Auto redial

You can activate or deactivate the automatic callback of your party for

calls that do not connect the first time.

(1) Depending on your SIM card.

520-621_UM_USA_16-05-08 16/05/08 9:20 Page 31

6.2 Creating a file

Select the directory in which you wish to create a file, press the

"Options" softkey, select "Create file" then .

When you create a new contact in the product directory, at least one of

the following fields must be filled in: First name, Last name,

Group, Mobile, Home, Ringtone, Image, Video, Work,

Fax, Email, Birthday, Company.

You can move from one field to another using the key.

If you use your phone abroad, store the numbers in your

directories in international format “+” followed by the country

code (see page 21).

6.3 Available options

From the list of names in SIM directory, General directory or Group you

can access the following options via left softkey:

View •View a complete file:name, numbers, address, e-mail,

etc.

Create file •Create a file (name, numbers, address, e-mail, etc.) in

the desired directory.

Create text/ •Send an SMS/MMS to a contact you selected from

multimedia the directory.

message

Edit •Modify the contents of a file: name, number,

ringtone, image, etc.

Delete •Delete the selected file.

Searching for a name by its first letter

You can search for the person’s name by pressing the key associated with

the first letter of his/her name.

Read a file

Select a name from your directory, then press to read the file.

Sending Vcard via Bluetooth

Selecting the Vcard you wish to transfer ("Options\Send vCard\By

Bluetooth").

Making a call

Press the key once the name is selected. If several numbers are

associated with the name to be called, you must first choose the number

from the list (Mobile, Home, Office, etc.) using the key. Press the

key to make the call.

Information in the directory and the diary may be managed using

the PC suite.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 33

7Messages..........................

You may create, edit and receive SMS, MMS and email with this phone.

MMS is a message whereby you can send video clips, images, photos,

animations and sounds to other compatible mobiles and e-mail addresses.

The MMS function can only be used if the service is provided by

your operator, and if your contract includes the MMS option and

if all the parameters for MMS have been entered (see page 40).

7.1 Messages:Text/Multimedia message (1)

7.1.1 Create message

From the main menu select "Messages" to create text/multimedia

message.

You may type a message, but may also modify a predefined message in

Templates for future access. You may customize messages by adding

pictures, photos, sounds, titles, etc (only available while editing a MMS).

While writing a message, select “Options” to access all messaging

options.

(1) Depending on your network operator.

Copy •Copy a file from SIM directory to Phone directory,

vice versa.

Move •Move a file from SIM directory to Phone directory,

vice versa.

Delete all •Delete all files in the current directory.

Copy all •Copy the whole directory to the SIM or General

directory if memory allows.

Send vCard •Exchange data via MMS or Bluetooth (see page 48).

Settings •More information and setting.

Create group •Create a group of files.

Delete group •The group and its files will be completely deleted.

Associate/ •If the contact is modified on the SIM or general

Not associate directory, the entry in the group will be modified

accordingly.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 35

7.1.3 Unsent

All messages failed to send.

7.1.4 Sent

All sent messages.

7.1.5 Drafts

All drafts messages.

7.1.6 WAP alerts

Store WAP push messages.

7.1.7 Empty folder

Delete all messages in “Inbox/Unsent/Sent/Drafts”.

7.1.8 Templates

A list of predefined messages is available. Select one, edit it if required, and

then send it.You can also create your own predefined text messages.

7.2 Voice message

Record voice and send as MMS.

7.3 Photo message

Take a photo and send as MMS.

You can save your messages that you send often to Drafts or Templates.

An SMS message of more than 160 characters (the number of

characters depends on the languages you writing in) will be

charged as several SMS. An MMS message containing photos

and/or sounds may also be billed as more than one message.

7.1.2 Inbox

All received messages (read and unread) are stored in the inbox.

When viewing your messages, you will find the following status icons,

depending on the type of message: unread SMS in phone, unread

SMS in SIM card, read SMS in phone, read SMS in SIM card,

unread MMS in phone, read MMS in phone, message reception in

progress and message sending in progress.

Receiving and reading SMS/MMS

When your receive a new message, the following message is displayed:“X

new message!”, a beep sounds, the icon appears with the # of unread

messages. Select this line and press to read it directly from the main

screen.

Once you have read the message, the following options are given: Reply,

Forward the message to another person, Edit,Delete,Delete all and

extract number or URL (Use number/Use URL).

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 37

Preferred •Select default message storage, SIM or phone.

storage

Pref. Bearer •Bearer preference.

7.6.2 Multimedia message

Edit •Set edit mode, image size and signature.

Sending •Set the values for validity period, Read report, etc.

Retrieve •Set the values for Home network, Roaming

network, etc.

Filter •Set criteria for filtering.

Profiles •Follow the same procedure as for setting your WAP

connection.

Memory status •Memory used on the phone.

7.6.3 Broadcast SMS (1)

Receive mode •Enable to receive broadcast SMS.

Read message •Store the received messages.

Language •Language selection.

Channel setting •Add/Edit channels.

(1) Depending on your network operator.

7.4 Email (1)

Send and •To connect the email server in order to launch

Receive sending/receiving email manually.

Create Email •Create a new email.

Inbox •Folder of all received emails.

Unsent •Folder of all emails failed to be sent.

Sent •Folder of all sent emails.

Drafts •Folder of all draft emails.

Templates •A list of predefined messages.

Delete all •Delete all email in the folder specified.

Delete marked •Delete all marked files.

Email profile •Edit or activate email profiles.

7.5 Voicemail

Access voicemail received.

7.6 Settings

7.6.1 Text message

Profile settings •Profiles can be retrieved directly from SIM card.

Alternatively, you can create your own profile.

General setting •Delivery report, request for acknowledgement of

delivery report On/Off. Reply path (1) show reply

path.

Memory status •Memory used on the phone.

(1) Depending on version, this feature may not be available.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 39

8.1.2 Mode

You may set your phone ringtone to Normal, Discreet (ring with beep),

Vibrate (all sounds are replaced by vibrations except for alarms),Vibrate

and ring,Vibrate then ring, Beep and vibrate, Silence (no sounds except for

alarms, the icon will be displayed).

Ringtones sound with increasing volume.

8.2 Colour

This function enables you to customize the graphic style and the colours

of your phone’s menu display.

8.3 Theme

The “Theme” menu allows you to customize your telephone to suit your

own taste.You can modify several customizable items at the same time.

When using the telephone for the first time, a default “Theme” is

activated.

Even if you choose a Theme, you can still modify the elements in it one by

one.You can reactivate any Theme at any time.

When changing a Theme, an installation screen appears until the eight

elements are installed.

The installation of the Theme can be stopped and cancelled if you

receive an incoming call or if you press the right softkey; the

previously selected Theme will remain.

8My settings ......................

From the main screen, select the icon menu and select the function

of your choice in order to customize your telephone.

8.1 Ringtones (1)

8.1.1 Available functions

To modify the sound settings, select an option using the key:

A group of predefined settings that allows you to quickly adapt

your phone to your environment.

Select a melody from the list using the key then confirm by

pressing (see page 65).

Mode (normal, discreet, vibrate...).

Adjust the volume using the key.

Select the type of key beep.

Select a melody for a new incoming message.

Select a melody for an alarm or appointment.

Power on beep.

Power off beep.

(1) OT-S621A only.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 41

8.6.3 Power On/Off (1)

You can customize your welcome animation or image that appears when

you switch on your phone.

You can also customize your OFF screen with an image or animation.

8.6.4 Menu display

Board •All the main menu icons displayed on one screen.

Image •One full-screen icon displayed at a time.

List •Main menus displayed line by line.

8.6.5 Special effects

Energize your menu entry by selecting "On".

8.7 Clock

Manage time and date settings, including: 12/24h format. You may also

adjust daylight savings time settings.

8.8 Keys

8.8.1 Softkeys

These keys have predefined functions, which vary from one model to

another (operator services, games access, or Games & Applications, ...).You

can customize (2) them by assigning functions, setting speed dial entries, or

associate a URL with each key.

(1) Depending on the model.

(2) Depending on your network operator.

(1) Depending on the operator.

8.4 Antenna off/Airplane mode

In antenna off mode, your phone will not be able to make or receive calls,

Bluetooth, or message transmissions. This mode also prolongs music

listening time.

8.5 Equalizer

Choose and select different sound styles preset.

8.6 Display

8.6.1 Main screen

The main screen is displayed when you switch on your telephone.

You can access the main functions from the main screen either with the

navigation key or by pressing and by selecting the icons displayed on

the screen (1).

By selecting “Main screen” you can customize it by replacing the default

image or animation displayed on your telephone.

When you receive an event (incoming call, SMS/MMS,

notifications, etc.) the icon, type and number of events will be

displayed on your main screen allowing you to view them directly.

8.6.2 Screen saver

If you activate this option, the screen saver will be enabled after a short

preset time. You can choose a picture, an animation, or a video as your

screen saver.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 43

8.9.3 Languages (1)

Display language for messages (select using ).The “Automatic” option

selects the language according to the home network (if available).

8.9.4 Dictionary

You have a dictionary to which you can add your own words in addition

to those suggested by the predictive input system.When you consult your

dictionary, you can add, modify or erase words by using the “Options”

softkey.

8.9.5 Input method (2)

Please see chapter “Latin input mode”, page 71. In addition to the specific

characters table for Cyrillic, Chinese, other data input modes are also

available in your telephone. This feature allows you to write short

messages and add names with special characters to your directory.

8.9.6 Security

Activate PIN •The SIM card protection code is requested each

time as the phone is powered on if this code is

activated.

Change PIN •Change PIN code.

Change PIN2 •A protection code for certain SIM card features

(Billing/Cost/FDN, etc.) will be requested if you

attempt to access it, if the code is activated. Select

to update it with a new one (between 4 and 8

digits).

(1) Contact your network operator to check service availability.

(2) Depending on the language.

8.8.2 Keys

By customizing your keys, you can access any function directly from the

main screen.

8.9 More settings…

8.9.1 Auto lock

Your keypad would be locked automatically or you may also lock it

manually by holding down the key.

Unlock the keypad

Hold down the key when locked.

The keypad will be unlocked automatically when receiving a call

or plugging in the charger.

8.9.2 Backlight

Screen •Adjusting the backlight allows to reduce brightness

to conserve battery consumption.You may also set

screen duration for inactivity; 5s, 10s, 30s, or 1 min.

Keypad •You may customize your keypad light by selecting

On/Off when activated.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 45

9Tools ................................

9.1 Bluetooth™ (1)

Access this feature by selecting “Tools” from the main menu, then

“Bluetooth”.

To use your phone with a Bluetooth device, follow the following

procedures:

- Pair and register the device to your phone,

- Select it to use hands-free communication. Only one Bluetooth audio

device (your Bluetooth headset or your Bluetooth car kit) can be

connected during the communication.

Pair and register your Bluetooth device

Activate the Bluetooth feature by selecting the “Tools\Bluetooth\

Activation\On” option. Then enter the “Device list” menu to search

for connectable Bluetooth devices and select the device you want to be

paired with in the list. If the bluetooth device has no keyboard, enter its

default password to register it with your phone. If the Bluetooth device

has keyboard/keypad, enter the same set of password on both handset and

the device to get it registered.

From the list,press the “Options” softkey to connect/disconnect, rename,

search for new devices or delete an unconnected device from the list.

(1) You are highly recommended to use Alcatel OT-BM81 (mono) and

OT-BS83 (stereo) Bluetooth headsets, which have been tested and

proved fully compatible with OT-S621A.

Activate phone •It is requested each time as the phone is powered

code on if this code is activated.

Change phone •Change phone password, default is 1234.

code

Fixed dialed •It allows the phone to be "locked" so that it can only

number dial certain numbers, or numbers with certain

prefixes. To activate this function, PIN2 code is

mandatory.

8.9.7 Networks

Network selection

•Preferred •List of networks to which you wish to be connected

networks in order of priority (update this list using ).

•Select network •Manually select your preferred network.

•Search mode •Network connection switching between "Manual"

and "Automatic".

GPRS connection (1)

•When needed •GPRS mode active depending on connection

requirements.

•Always •GPRS mode continuously active.

(1) Depending on network availability.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 47

Available options:

Create •Create an appointment.

View •See today's appointments.

appointments

List all •See created appointments.

appointments

Jump to date •Input the required date and it will be immediately

highlighted.

9.3 Alarm

Your cellphone has a built-in alarm clock with a snooze feature. You can

set up to five separate alarms and choose whether or not the alarm should

repeat.

Repeat •You may select Once (default)/Every day/Days.

Snooze •The alarm will repeat at regular intervals.

9.4 Calculator

You can use it to perform basic calculations. Hold down the key to

input a decimal point. Confirm with the key or the left softkey.

Don’t forget to turn on your Bluetooth device and activate the

pairing mode while pairing it with your phone.

Available functions

Data transmit •Exchange files with another bluetooth device.

Handle a call •Initiate or receive a phone call with a Bluetooth

headset.

Listen to music •Support A2DP profile.

Settings

•Visibility: Select whether you want to hide (“Hidden”) or show to all

(“Shown to all”) your phone.

•My phone's name: you may change your phone name, which is visible

to the others.

Always activate Bluetooth in your phone first before connecting

it to a Bluetooth device. Be aware that Bluetooth activation will

slightly affect battery life of your phone.

Bluetooth technology allows free wireless connections between all

Bluetooth-compliant devices within short range. Please make sure that the

Bluetooth headset or the Bluetooth car kit and your cellphone are in this

range and set as "Visibility".

Your phone is Bluetooth™ v1.1, v1.2 and v2.0 compatible.

9.2 Organizer

Once you enter this menu from “Tools”, there is a monthly-view calendar

for you to keep track of important meetings, appointments, etc. Days with

events entered will be marked in colour.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 49

9.7 Memory status

It will indicate how much space is used and how much is currently free on

your phone and memory card (if any).

9.7.1 Phone memory

View available memory.

Your phone’s memory is shared among several functions: directory,

scheduler, messages, voice messages, images, melodies, games, applications

and video clips.

9.7.2 Memory card (MicroSD card) (1)

View the memory available on your MicroSD card.

You are advised to save large files (like videos, songs,…) on your

microSD card. File names up to 35 characters will be supported.

9.5 Converter

9.5.1 Unit converter

You can use the Weight and Length conversion by selecting the unit you

wish to convert via , then press to input the digits. Finally confirm

with key or left softkey.

9.5.2 Currency converter

The currency converter allows you to:

•Convert a currency directly into euros and vice versa (1).

•Convert between international currencies, both currencies must be

selected by keys. You are requested to input the appropriate

exchange rate.

9.6 Voice memo

This feature enables you to record a call by selecting “Voice memo”

while communicating. To record a sound, select “Voice memo”, then

“New record”.

(1) For the former European national currencies, the currency converter

uses the final Euro conversion rates set on 31/12/1998, which are

used in accordance with official conversion rules. (1) OT-S621A only.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 51

11WAP ..............................

11.1 Homepage

Launch the WAP browser with the homepage of the default profile.

11.2 Bookmarks

Access your favorite sites.

11.3 Recent pages

Pages which you recently browsed.

11.4 Go to URL

Enter the URL of WAP site.

11.5 Profiles

11.5.1 Edit profile

Edit existing profile or create new profile.

11.5.2 Browser options

Set timeout values and image loading options.

10 My shortcuts ................

Accessing and creating new shortcuts.

To program new shortcuts: select "My shortcuts" to create quick access

to a function, Directory, or WAP Bookmarks, etc.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 53

12 Media album ................

You will have an access to all audio and visual files stored in phone or

memory card in Media Album.

12.1 My Audio

Choose an audio for the ON/OFF screen, for an incoming call, a message

alert, power on/off ringtone or an alarm and scheduler.

The “My Audio” album contains the following folders (1):

- Music: full track music.

- Melodies: melodies that can be set as a ringtone.

- Recorded: all recorded sounds.

- General: contains all audio files stored in phone or memory card.

DRM: Digital Rights Management feature allows sounds and

images to be played while protecting the associated copyright.

DRM counter-based files and files with expired rights will not be

automatically played when scrolling the list.

(1) The embedded folder names cannot be modified. However, in certain

cases, you can modify, delete and add items included in these folders.

11.5.3 Push message settings

Enable or disable receiving service message from WAP.

11.5.4 Clear cache

Empty the phone’s cache memory.

11.5.5 Clear cookies

Clear cookies from website.

11.5.6 Trusted certificates

Certificates of trusted sites.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 55

12.6 Memory card (1)

You will have access to all files stored in memory card here.

When a memory card is inserted for the first time, it will be

scanned and the default folders will be created.

Insert the memory card Remove the memory card

Available options

New folder •Create more folders.

Delete folder •Remove folders.

Rename folder •Rename folder's name.

Empty folder •Delete all files in one folder.

Memory card •To format it or check available memory.

Unclip the back cover and insert

the MicroSD card into the slot.

Unclip the back cover and gently

push the memory card until

unlocked.Take out your MicroSD

card and clip the back cover.

12.2 My images

You can select an image or a photo as main screen or the ON/OFF screen.

You may also change it, send it by MMS, Bluetooth, or assign it to a contact

in the directory.

Images are displayed in alphabetical order.

12.3 My videos (1)

The "My videos" album contains all video clips embedded and

downloaded in phone or memory card.

In My Audio, My images and My videos: only files transferred via

PC suite will be saved in the pre-defined folder and recognized by

the multimedia player. However, the files copied to other

directories are still accessible in “Media album\Memory

card”.

12.4 My creations

This feature stores all photos captured by your cellphone.

Thumbnails are displayed for preview. In addition, you can use “Mark”

function, to select multiple files.

12.5 Unknown files

Store files of unsupported format.

(1) OT-S621A only. (1) OT-S621A only.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 57

Move to phone/ •Move a file from the product memory to the

memory card memory card and vice-versa.

Properties •Display part of the ID3 Tag content of an MP3 file.

Activate •DRM file option.

Copy to phone/ •Copy a file to the phone memory or the memory

memory card card.

Delete •Delete files except those that are embedded.

Delete all •Delete all files except those that are embedded.

List view •View files in the selected list.

Slideshow (1) •Show the images continuously.

Capture •Access “Camera” function directly.

Mark/Unmark •Mark/Unmark a click on a file for further operation.

Mark/Unmark all •Mark/Unmark a click on all files.

Delete marked •Delete all the marked files.

12.8 Compatible formats (2)

- Sounds: mp3, m4a, aac, midi, wav, amr

- Images: jpg, gif

- Videos: 3gp, mp4

12.9 Memory status

See page 52.

(1) Only applies to images that can be cleared but not for copyrighted

files.

(2) Depending on product and market.

12.7 Managing audio, images, videos and

creations

Below are the available functions for applicable files:

View •View the selected image. If you want to view all the

pictures in your folder in a slideshow hold down

on the current picture.

Play •Play the selected video.

Send (1) •Send the audio/image/video.

Delete •Delete the audio/image/video selected (Not

applicable for embedded items).

Set as •- Image->main screen, screen saver, switch ON/OFF,

assign it to a contact.

- Sound->ringtone, message beep, switch ON/OFF,

assign it to a contact.

- Video->Screen saver, switch ON/OFF or assign it

to a contact,

Modify •Modify an image (2).

Download •Download new items.

Rename •Rename the audio/image/video.

Sort •Sort the files by name, type, time and size.

(1) Files marked with cannot be sent.

(2) Only applies to images that can be cleared but not for copyrighted

files.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 59

13.2.2 Settings in framing mode

Before taking a photo, you may adjust several settings by using the

following shortcuts below:

OT-S520A

Navigation key:

: take the picture

: exposure – or +

: zoom in or out

Key : Quality: High/

Standard/Economy

Key : White balance

Key : Capture mode

1 / 3 / 5 shot / Off / Mosaic

Key : Scene mode:

Auto/ Night

Left softkey: Options

Key : Hide/Unhide all

icons

Right softkey: Back, return

to sub-menus previous

screen

Selected options bar:

Image size

Quality

White balance

Capture mode

Exposure

Timer

Scene mode

Key : Colour mode:

colour or black&white

Key : Image size:

128x160, 160x120, 320x240,

640x480

Key : Timer: 5 / 10 /

15 sec / Off

Key : Add frame (only

available to size 128x160)

13 Camera ........................

Your cellphone is fitted with a camera for taking photos that you can use

in different ways:

- store them in your “Media album”.

- send them in a multimedia message (MMS) to a cellphone or an email

address.

- customize your main screen (see page 43).

- select them as incoming call image to a contact in your directory.

- transfer them by data cable or microSD card to your computer.

- modify your photos by adding frames (see page 63).

13.1 Access

To access photo and video from the main screen, press the key to

access the menu and select the icon.

13.2 Camera

13.2.1 Take a photo, save or delete

The screen acts as the viewfinder. Position the object or landscape in the

viewfinder and press to take the picture and the picture will be

automatically saved. If you prefer not to save, you may delete it by pressing

the right softkey “Delete”.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 61

From the photo shot screen, press the “Options” softkey not only to

access: “Image size”, “Capture mode”, “Quality”, “Timer”, “White

balance”,“Colour mode”, “Add frame”, but also the following:

Media album •Go to the media album feature.

Saving location •You may choose saving location if MicroSD card is

inserted.

Restore default •Make all settings recover as default value.

Hotkeys •List all hotkeys.

13.2.3 Options available after taking the photo

Once you have taken a photo, you can Send your photo, assign it to a

contact or to the main screen, etc, or Delete it, Modify it (see below),

or access your Media album.

13.2.4 Modifying images

Access the “Media album\My creations” after taking a photo, and then

select “Modify”.

6463

OT-S621A

Navigation key:

: take the picture

: exposure – or +

: zoom in or out

Key : Quality: High/

Standard/Economy

Key : White balance

Key : Capture

mode (1): 1 / 3 / 5 shot /

Off / Mosaic

Key : Scene mode:

Auto/ Night

Left softkey: Options

Key : Hide/Unhide all

icons

Right softkey: Back, return

to sub-menus previous

screen

Selected options bar:

Image size

Quality

White balance

Capture mode

Exposure

Timer

Scene mode

Key : Colour mode:

colour or black&white

Key : Image size:

128x160, 160x120, 320x240,

640x480, 1280x1024 Key : Timer: 5 / 10 /

15 sec / Off

Key : Add frame (only

available to size 128x160)

(1) No "3 shot / 5 shot" for the image size of "1280x1024".

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 63

Use keys to manage the Multimedia player:

- : Set the volume level

- : Go to previous/next title (short keypress)

Fast play backward/forward (long keypress)

- : Switch sound between handset and Bluetooth.

14.2 Settings

Access by pressing the right navigation key for following options:

Play mode •Normal, Repeat current, Repeat all, Shuffle and

Repeat shuffle. You may also customize it simply by

pressing during playing music.

Equalizer •Different music style presets in the phone.You may

also customize it simply by pressing during

playing music.

Play in Bluetooth•In playing screen, press the key to shift

between play in speaker and play in BT stereo

bluetooth.

Colour •Change the skin of your Multimedia player.

Display •Enable your player to display spectrum, song info. or

lyric.

14.3 Playing with lyrics

Lyrics can be displayed in synchronization with the music. You need a

separate .Irc file with the same name of music file.

14 Multimedia player (1) ....

Access this feature from the main menu by selecting “Multimedia

player” or directly by holding down the key. You will have full

flexibility of managing music both on your mobile and memory card.

14.1 Multimedia player (2)

Access your audio files through the following menus:

All songs •Contains all songs both on phone memory and

memory card.

All videos •Contains all videos in the prefined folder both on

the phone memory and memory card.

Playlist •List created on the PC.

Update songs •Update the information of songs saved in memory

card.

Album/Artist/ •Music files are categorized by Album, Artist or

Genre Genre based on information stored in the tags.

Those missing such information will be classified as

“Unknown files”.

My star list •You can simply add your favorite songs to "My star

list" by holding down during playing music

(max 100).

(1) OT-S621A only.

(2) Only music files in mp3, m4a and aac format will be visible in

Multimedia player.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 65

Disclaimer

Downloading or running applications will not damage or alter any

software already in your mobile telephone designed to support Java™

technology.

TCT Mobile Limited and its affiliates waive any responsibility and refuse to

guarantee applications that are subsequently used, as well as for all

applications not embedded in the handset upon purchase.

The purchaser alone bears the risk of loss, damage or defect of the

handset, or of applications/software, and generally of any damage or

consequence resulting from the use of the said applications/software. In

the event that the said applications/software, or the subsequent setup of

any function are lost due to technical reasons resulting from the handset

being replaced/repaired, the cellphone owner should repeat the operation

and download or set up again.TCT Mobile Limited and its affiliates grant

no guarantee and disclaim any responsibility if the operation cannot be

repeated or cannot be performed without incurring some cost.

15 Games & Applications

Your Alcatel phone may include (1) some Java™ applications (2) and

games (3). You may also download other compatible Java applications (2) and

games from your service provider or other third party providers.

15.1 Launch an application (2)

Select "Java" to launch applications.

15.2 Java settings (2)

The “Games & Apps” menu allows you to manage Java settings, in which

you may set Java audio, Java vibration and view free/heap size.

15.3 Java downloading (2)

You can download new Java™ applications in the "Games & Apps" menu

by selecting the “Download” from “Options”. The list of available WAP

bookmarks dedicated to the application download will then be displayed.

Select the appropriate bookmark to go to the desired WAP page.

(1) Depending on your country or your operator.

(2) OT-S621A only.

(3) OT-S520A only.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 67

17 Making the most of your

mobile..................................

17.1 PC suite

PC suite is provided on our website. You may download applicable updates

for free via our website. PC suite allows you to:

- Backup/restore

•You can backup the important data in your mobile and restore them

when needed.

- GPRS Modem

•Use your cellphone to connect a PC to the internet.

- Multimedia Personalization

•Customize your mobile with images, animations, videos and melodies.

- Music management

•Create and transfer playlists with music files and provide edited lyrics.

- Messaging

•You can compose SMS/MMS easily on your PC and transfer them to

phone.

Supported Operating Systems

- Windows 2000/XP/Vista

16 Profiles (1) ............................

See page 41 “8.1.1 Available functions”

(1) OT-S520A only.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 69

Predictive T9 mode

Predictive T9 mode predicts words for quick selection based on

predefined words in the phone's dictionary.

Write the word by pressing a key between and . Press the key

once and the word will be modified each time you press a key. As you go

on, the word will keep changing.

Example: For “Tomorrow”, press on the following keys:

, , = Too -> -> tomorrow

Write message

Options Back

Write message

Options Back

18 Latin input mode/

character table (1) ................

To write messages, there are two writing methods:

•Normal

•Predictive with the T9 mode

Normal

This mode allows you to type a text by choosing a letter or a sequence of

characters associated with a key. Press the key several times until the

desired letter is highlighted.

When you release the key the highlighted character is inserted into the

text.

(1) For specific languages as Chinese, please see specific input leaflets.

Write message

Options Back

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 71

This characters table is generic. All available characters are not displayed.

Available letters will vary according to languages.

Symbol table

Hold down the key to display the symbols table; the cursor is

positioned in the centre. Use the navigation key to move it and the

key to select.

Key Latin uppercase Latin lower case

Symbols table

Select Back

Key

- Long keypress: insert 1

Key

- Short keypress: Access

the language list

- Long keypress: Enter

zero

Key

- Short keypress:

(space)

- Long keypress: add a

word

Navigation key:

- : RIGHT/LEFT:

Validate the word

- : UP: Previous word

in the dictionary

- : DOWN: Next

word in the dictionary

Keypad

- Short keypress: alpha

input (a, b)

- Long keypress: numeric

input (1, 2, 3)

Key

- Short keypress: change

input methods

- Switch from T9

predictive mode to

Normal mode

- Long keypress: access

the Symbols table

OT-S520A

Key

- Long keypress: insert 1

Key

- Short keypress: Access

the language list

- Long keypress: Enter

zero

Key

- Short keypress:

(space)

- Long keypress: add a

word

Navigation key:

- : RIGHT/LEFT:

Validate the word

- : UP: Previous word

in the dictionary

- : DOWN: Next

word in the dictionary

Keypad

- Short keypress: alpha

input (a, b)

- Long keypress: numeric

input (1, 2, 3)

Key

- Short keypress: change

input methods

- Switch from T9

predictive mode to

Normal mode

- Long keypress: access

the Symbols table

OT-S621A

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 73

3) improper maintenance of batteries and other sources of energy, and of the overall

electric installation,

4) accidents or consequences of theft of the vehicle in which the telephone is

transported, acts of vandalism, lightning, fire, humidity, infiltration of liquids,

inclement weather,

5) connecting or integrating the cellphone into equipment not supplied or not

recommended by TCT Mobile Limited or its affiliates, without their express

written consent for such,

6) any servicing, modification or repair performed by individuals not authorized by

TCT Mobile Limited or its affiliates, the vendor or the approved maintenance

center,

7) use of the equipment for a purpose other than that for which it was designed,

8) normal wear,

9) malfunctions caused by external causes (e.g., radio interference from other

equipment, power or telephone line voltage fluctuations),

10)modifications made to the equipment even if required by changes in regulations

and/or modification of network parameters,

11)faulty connections resulting from unsatisfactory radio transmission or caused by

the absence of radio relay coverage.

In accordance with the applicable law,TCT Mobile Limited or its affiliates guarantee

your product against hidden defects (defects inherent in the design, manufacture,

etc.).

The above provisions constitute the only claims enforceable against the manufacturer

and vendor in the event of defects in the cellphone or accessory.

There are no express warranties, whether written or oral, other than this printed

limited warranty. All implied warranties, including without limitation the implied

warranties of merchantability or fitness for a particular purpose, are limited to the

duration of this limited warranty. In no event shall TCT Mobile Limited or its affiliates

be liable for incidental or consequential damages of any nature whatsoever, including

but not limited to loss of profits, commercial loss, to the full extent those damages

can be disclaimed by law. Some countries/states do not allow the exclusion or

limitation of incidental or consequential damages, or limitation of the duration of

implied warranties, so the preceding limitations or exclusions may not apply to you.

19Telephone warranty............

Congratulations on choosing this cellphone - we hope that you will be completely

satisfied with it.

Your cellphone is guaranteed against any deviation from technical specifications for a

period of twelve (12) months from the date specified on your original invoice (1).

The warranty terms defined in the manual also apply to the battery and accessories

but for a period of six (6) months (2) from the date of purchase shown on your

original invoice.

Under the terms of this warranty, you must inform your vendor (or any maintenance

center approved by TCT Mobile Limited or its affiliates) without delay, of any defect

and present the invoice given to you at the time of purchase. The vendor or

maintenance center will decide whether to replace or repair, as appropriate, all or

any part of the telephone or accessory found to be defective; this warranty covers

the cost of parts and labour but excludes any other costs. Repair or replacement may

be carried out using reconditioned components offering equivalent functionality.

Servicing under the terms of this warranty, especially repair, modification or

replacement of products, shall entitle to a THREE (3) month warranty unless there

are statutory provisions to the contrary.

This warranty shall not apply to damage or defects to your telephone and/or

accessory caused by:

1) failure to follow the instructions for use or installation,

2) failure to comply with technical and safety standards applicable in the

geographical area where the equipment is used,

(1) The warranty period may vary if overriding statutory provisions are

applicable in your country.

(2) The life of a rechargeable telephone battery in terms of conversation

time, standby time, and total service life, will depend on the

conditions of use and network configuration. Batteries being

considered expendable supplies, the specifications state that you

should obtain optimal performance for your Playboy phone during

the first six months after purchase and for approximately 200 more

recharges.

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 75

21Troubleshooting ..................

Before contacting your retailer or service center, please try the following

procedures below:

•You are advised to switch off the telephone from time to time to

optimize its performance.

•You are advised to fully charge ( ) the battery for optimal operation.

•Avoid storing large amounts of data in your telephone as this may affect

the performance of your telephone.

My cellphone will not switch on

•Press until the screen comes on

•Check the battery charge level

•Check the battery contacts, remove and reinstall your battery, then turn

your telephone back on

My screen is difficult to read

•Clean your screen

•Use your cellphone in accordance with the recommended conditions of

use

My cellphone turns off by itself

•Check that your keypad is locked when you are not using your cellphone

•Check the battery charge level

My cellphone has a low level of autonomy

•Make sure you respected the complete charge timing (minimum 3 hours)

•After a partial charge, the battery level indicator may not be exact.Wait

for at least 20 minutes after removing the charger to obtain an exact

indication

7877

20Accessories ..........................

The latest generation of Alcatel GSM cellphones offers a built-in handsfree

feature that allows you to use the telephone from a distance, placed on a

table for example. For those who prefer to keep their conversations

confidential, an earpiece is also available known as the headset.

Only use your telephone with Alcatel batteries, chargers and

accessories compatible with your model.

Battery

Stereo headset

Standard charger

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 77

Unable to receive incoming calls

•Make sure your cellphone is switched on and connected to a network

(check for busy or unavailable networks)

•Check your subscription status with your operator (credit, account

status etc.)

•Make sure you have not forwarded incoming calls (see page 30)

•Make sure that you have not barred certain calls

The caller’s name does not appear when a call is received

•Check that you have subscribed to this service with your operator

•Your caller has concealed his/her number

The sound quality of the calls is not optimal

•You can adjust the volume during a call by means of the key

•Check the network signal strength indicator

I am unable to use the features described in the manual

•Check with your operator to make sure that your subscription includes

this service

•Make sure this feature does not require an Alcatel accessory

When I select a number from my directory, the number is not

dialed

•Make sure that you have correctly recorded the number

•Make sure that you have selected the country prefix when calling a

foreign country

I am unable to create a file in my directory

•Make sure that your SIM card directory is not full; delete some files or

save the files in the phone's directory (i.e. your professional or personal

directories)

My callers are unable to leave messages on my voicemail

•Contact your network operator to check service availability

My cellphone will not charge properly

•Make sure that your battery is not completely discharged; the battery

charge indicator can take several minutes and may be accompanied by a

quiet whistling sound

•Make sure charging is carried out under normal conditions (0°C +40°C)

•Make sure your battery is inserted. It must be inserted beforeplugging

in the charger

•Make sure you are using an Alcatel battery and charger

•When abroad, check that the electrical current is compatible

My cellphone will not connect to a network

•Try connecting in another location

•Verify the network coverage with your operator

•Check with your operator that your SIM card is valid

•Try selecting the available network(s) manually (see page 47)

•Try connecting at a later time if the network is busy or unavailable.

SIM card error

•Make sure the SIM card has been correctly inserted (see page 17)

•Verify with your operator that your SIM card is 3V compatible; ; old 5V

SIM cards are not compatible.

•Make sure the chip on your SIM card is not damaged or scratched

Unable to make outgoing calls

•Make sure you have dialed a valid number and press the key

•For international calls, check the country and area codes

•Make sure your cellphone is connected to a network, and that the

network is not busy or unavailable.

•Check your subscription status with your operator (credit, account

status etc.)

•Make sure you have not barred outgoing calls (see page 30)

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 79

ALCATEL is a trademark of Alcatel-Lucent

and used under license by

TCT Mobile Limited.

TCT Mobile Limited reserves

the right to alter material or technical

specification without prior notice.

English - CJA3031ALAAA

I cannot access my voicemail

•Make sure your operator’s voicemail number is correctly entered in “My

Numbers”

•Try later if the network is busy

I am unable to send and receive messages MMS,Vox MMS

•Check your phone’s memory available as it might be full

•Contact your network operator to check service availability and check

MMS parameters (see page 40)

•Verify the server centre number or your MMS profile with your

operator

•The server centre may be saturated; try again later

The icon is displayed on my standby screen

•You have too many SMS messages on your SIM card; delete some, or

archive them in your phone's memory

The << - >> icon is displayed

•You are outside of the network coverage area

I have already entered 3 incorrect PIN codes

•Contact your network operator to obtain the PUK code (Personal

Unblocking Key)

I am unable to connect my telephone to my computer

•Install first of all Alcatel’s PC suite

•Use “Install the connection” and perform the installation

•Check that your computer meets the requirements for Alcatel’s PC Suite

installation

I am unable to download new files

•Check required/available memory

•Delete some files

•Select the MicroSD Card to store the files you downloaded

•Check your subscription status with your operator

The phone can’t be detected by others via Bluetooth

•Make sure that Bluetooth is turned on and your cellphone is visible to

other users (see page 48)

520-621_UM_USA_16-05-08 16/05/08 9:21 Page 81

TCT Mobile 070 GSM/GPRS 850/1900 dual band mobile phone User Manual 520 621 UM USA 16 05 08

TCT Mobile Limited GSM/GPRS 850/1900 dual band mobile phone 520 621 UM USA 16 05 08

User Manual

Navigation menu

Namespaces

Views

Navigation
