TCT Mobile 106 GSM/GPRS/EDGE 850/1800/1900 Tri-band Mobile Phone User Manual 800 UM USA 20 05 091
TCT Mobile Limited GSM/GPRS/EDGE 850/1800/1900 Tri-band Mobile Phone 800 UM USA 20 05 091
Contents
- 1. Manual Part 1
- 2. Manual Part 2
Manual Part 1
1 2
Introduction ................................
TCT Mobile Limited would like to thank you for purchasing this
cellphone.
G-Sensor
- Fitness application
Used primarily by sports and physical fitness enthusiasts as an everyday
exercise motivator, including pedometer, stopwatch and exercise program
planner.
- Motion sensor
Easily skip to the previous/next song, channel or image, snooze an alarm
or mute an incoming call.
Power media applications
- Music player & Radio
- Video & Streaming
- Webcam
The 2.0 MegaPixel camera is the best companion for PC instant
messaging.
Bluetooth
With Bluetooth 2.0 supporting A2DP profiles, enjoy handsfree
conversations.
My friends
Popular websites (like bebo, Friendster, hi5, facebook, myspace, etc.) to
stay in touch with your friends wherever you are, whenever you want.
1
Table of contents ........................
Safety and use ...................................................................... 6
General information ......................................................... 11
1 Your telephone ............................................................ 13
1.1 Keys.......................................................................................................14
1.2 Main screen icons ..............................................................................16
2 Getting started ............................................................ 18
2.1 Set-up ...................................................................................................18
2.2 Power on your phone ......................................................................20
2.3 Power off your phone ......................................................................20
3 Calls .............................................................................. 21
3.1 Making a call........................................................................................21
3.2 Calling your voicemail ......................................................................21
3.3 Receiving a call ...................................................................................22
3.4 During the call ....................................................................................23
3.5 Conference calls ................................................................................24
3.6 Line switching .....................................................................................24
4 Menu arrange ............................................................... 25
5 Messages ....................................................................... 26
5.1 Messages: Text/Multimedia message .............................................26
5.2 Email .....................................................................................................29
5.3 Voice message ....................................................................................31
5.4 Photo message ...................................................................................31
5.5 Video message ....................................................................................31
5.6 Voicemail ..............................................................................................31
5.7 Broadcast SMS ....................................................................................31
5.8 WAP alerts ..........................................................................................31
5.9 Settings .................................................................................................31
2
6 Instant messaging ........................................................ 33
6.1 Access ..................................................................................................33
6.2 Open a Palringo account online ....................................................33
6.3 Sign in/Sign out ...................................................................................33
6.4 Add service .........................................................................................34
6.5 Chat ......................................................................................................34
6.6 Contacts ..............................................................................................34
6.7 Groups .................................................................................................34
7 Directory ...................................................................... 35
7.1 Consulting your directory .............................................................35
7.2 Creating a file .....................................................................................36
7.3 Available options ................................................................................37
8 Call register ................................................................. 39
8.1 Call memory .......................................................................................39
8.2 My numbers ........................................................................................39
8.3 Billing ....................................................................................................39
8.4 Call settings .........................................................................................40
9 Media applications ....................................................... 42
9.1 Music player ........................................................................................42
9.2 Image Viewer .......................................................................................43
9.3 Video player ........................................................................................44
9.4 Radio .....................................................................................................44
10 Internet ........................................................................ 46
10.1 My friends ............................................................................................46
10.2 Opera ...................................................................................................46
10.3 Web ......................................................................................................46
10.4 News ....................................................................................................47
10.5 Weather ...............................................................................................48
11 Entertainment ............................................................. 49
11.1 Fun ........................................................................................................49
11.2 Ebook ...................................................................................................50
11.3 Java ........................................................................................................50
3
12 Camera ......................................................................... 52
12.1 Access ..................................................................................................52
12.2 Camera ................................................................................................52
12.3 Video ....................................................................................................54
13 Profiles .......................................................................... 57
13.1 General ................................................................................................57
13.2 Meeting ................................................................................................58
13.3 Outdoor ..............................................................................................58
13.4 Indoor...................................................................................................58
13.5 Silence ..................................................................................................58
13.6 Antenna off mode .............................................................................58
14 File manager ................................................................ 59
14.1 My audios ............................................................................................59
14.2 My images ............................................................................................59
14.3 My videos ............................................................................................59
14.4 My creations .......................................................................................60
14.5 Unknown files .....................................................................................60
14.6 Ebook ...................................................................................................60
14.7 Phone....................................................................................................60
14.8 Memory card ......................................................................................60
14.9 Managing audios, images, videos and creations ...........................61
14.10 Formats and compatibility ...............................................................62
14.11 Memory status ...................................................................................62
15 Bluetooth ..................................................................... 63
16 Others ........................................................................... 65
16.1 Calendar ..............................................................................................65
16.2 Calculator ............................................................................................65
16.3 Notes ....................................................................................................66
16.4 Tasks .....................................................................................................66
16.5 Clock ....................................................................................................67
16.6 Converter .........................................................................................67
4
5
17 Settings ......................................................................... 68
17.1 Display ..................................................................................................68
17.2 Languages ...........................................................................................70
17.3 Headset mode ....................................................................................70
17.4 Input mode ..........................................................................................70
17.5 Vocabulary ...........................................................................................70
17.6 Motion sensor ....................................................................................70
17.7 Keypad ..................................................................................................71
17.8 Security ................................................................................................72
17.9 Network ..............................................................................................73
17.10 Connectivity ........................................................................................73
18 Making the most of your cellphone........................... 74
18.1 PC suite ...............................................................................................74
19 Latin input mode/character table ............................. 75
20 Telephone warranty .................................................... 78
21 Accessories................................................................... 80
22 Troubleshooting .......................................................... 81
Safety and use .............................
We recommend that you read this chapter carefully before using your cellphone. The manufacturer
disclaims any liability for damage, which may result as a consequence of improper use or use
contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle constitutes a real risk, even
when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their
cellphone when the vehicle is not parked. Check the laws and regulations on the use of wireless
telephones and their accessories in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas.
When driving, do not use your cellphone and headphone to listen to music or to the radio. Using
a headphone can be dangerous and forbidden in some areas.
When switched on, your cellphone emits electromagnetic waves that can interfere with the vehicle’s
electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s electronic devices
are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its performance.
Switch the cellphone off before boarding an aircraft to avoid prosecution.
Switch the cellphone off when you are in health care facilities, except in designated areas. As with
many other types of equipment now in regular use, cellphones can interfere with other electrical
or electronic devices, or equipment using radio frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly obey all signs and
instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive
atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any medical device such
as a pacemaker, a hearing aid or insulin pump. In particular when using the cellphone you should
hold it against the ear on the opposite side to the device, if any.
To avoid hearing impairment, answer the call before holding your cellphone to your ear. Also move
the handset away from your ear while using the “hands-free” option because the amplified volume
might cause hearing damage.
Do not let small children use your cellphone without supervision.
When replacing the cover please note that your cellphone may contain substances that could
create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free place.
Do not allow your cellphone to be exposed to adverse weather or environmental conditions
(moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The manufacturer’s recommended
operating temperature range is -10°C to +55°C (the max value depends on device, materials and
housing paint/texture).
6
Over 55°C the legibility of the cellphone’s display may be impaired, though this is temporary and
not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by TCT Mobile
Limited and its affiliates and are compatible with your cellphone model.TCT Mobile Limited and its
affiliates disclaim any liability for damage caused by the use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check local regulations for
disposal of electronic products.
Remember to make back-up copies or keep a written record of all important information stored
in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when
playing video games. These seizures or blackouts may occur even if a person never had a previous
seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history
of such occurrences, please consult your doctor before playing video games on your cellphone or
enabling a flashing-lights feature on your cellphone. Parents should monitor their children’s use
of video games or other features that incorporate flashing lights on the cellphones. All persons
should discontinue use and consult a doctor if any of the following symptoms occur: convulsion,
eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the
likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a well lit environment.
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems
such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours
before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see
a doctor.
Prolonged exposure to music at full volume on the music player may cause the listener’s
hearing impairment. Adjust the volume before placing headphones on or in your ear. Only
use headphones recommended by TCT Mobile Limited and its affiliates.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your jurisdiction or other
jurisdiction(s) where you will use your cellphone regarding taking photographs and recording
sounds with your cellphone. Pursuant to such laws and regulations, it may be strictly forbidden to
take photographs and/or to record the voices of other people or any of their personal attributes,
and reproduce or distribute them, as this may be considered to be an invasion of privacy.
7
It is the user’s sole responsibility to ensure that prior authorization be obtained, if necessary, in
order to record private or confidential conversations or take a photograph of another person; the
manufacturer, the seller or vendor of your cellphone (including the operator) disclaim any liability
which may result from the improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at temperatures above
60°C.
Batteries must be disposed of in accordance with locally applicable environmental regulations. Only
use the battery for the purpose for which it was designed. Never use damaged batteries or those
not recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your cellphone, the battery and the accessories means that these
products must be taken to collection points at the end of their life:
- Municipal waste disposal centers with specific bins for these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the environment, so that
their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign must be brought
to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your jurisdiction or
your region has suitable recycling and collection facilities; instead they are to be taken to collection
points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
• CHARGERS
Home A.C. chargers will operate within the temperature range of: 0°C to 40°C.
The chargers designed for your cellphone meet with the standard for safety of information
technology equipment and office equipment use. Due to different applicable electrical specifications,
a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be
used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 500 mA
Battery: Lithium 850 mAh
8
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general population.
The guidelines are based on standards that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. These guidelines include a substantial
safety margin designed to ensure the safety of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal
Communications Commission of the US Government (FCC), or by Industry Canada, is 1.6
W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating
positions with the cellphone transmitting at its highest certified power level in all tested frequency
bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of the
cellphone while operating can be well below the maximum value. This is because the cellphone is
designed to operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the lower the power
output of the cellphone Before a cellphone model is available for sale to the public, compliance with
national regulations and standards must be shown.
The highest SAR value for this model cellphone when tested is 1.17 W/Kg for use at the ear and
1.26 W/Kg for use close to the body.
While there may be differences between the SAR levels of various cellphones and at various
positions, they all meet the government requirement for RF exposure. For body-worn operation,
the cellphone meets FCC RF exposure guidelines provided that it is used with a non-metallic
accessory with the handset at least 1.5 cm from the body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
The World Health Organization (WHO) considers that present scientific information does not
indicate the need for any special precautions for use of cellphones. If individuals are concerned,
they might choose to limit their own or their children’s RF exposure by limiting the length of calls,
or using “hands-free” devices to keep cellphones away from the head and body. (fact sheet n°193).
Additional WHO information about electromagnetic fields and public health are available on the
following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
9
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service (e.g. FM
broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you should
avoid touching it or degrading it.
As cellphone devices offer a range of functions, they can be used in positions other than against
your ear. In such circumstances the device will be compliant with the guidelines when used with
headset. If you are not using headset ensure that whatever product is used is free of any metal and
that it positions the phone at least 2 cm away from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by TCT Mobile Limited and its affiliates is under license.
Other trade marks and trade names are those of their respective owners.
OT-800A Bluetooth QD ID B014211
T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos.
5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548,
6,307,549, and 6,636,162, 6,646,573; European Pat. Nos. 0 842 463 (96927260.8),
1 010 057 (98903671.0), 1 018 069 (98950708.2); and additional patents are
pending worldwide.
Java™ and all Java™ based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
10
®
General information ..................
• Website: www.alcatel-mobilephones.com
• Hot Line Number: see “TCT Mobile Services” leaflet or go to our
Internet site.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and
other languages according to availability on our server: www.alcatel-
mobilephones.com
11
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number) shown
on the packaging label and in the product’s memory. We recommend that
you note the number the first time you use your cellphone by entering
*#06# and keep it in a safe place. It may be requested by the police or your
operator if your cellphone is stolen. This number allows your cellphone to
be blocked preventing a third person from using it, even with a different
SIM card.
Disclaimer
There may be certain differences between the user manual description
and the cellphone’s operation, depending on the software release of your
cellphone or specific operator services.
12
(1) Contact your network operator for service availability.
Your cellphone is a transceiver that operates on GSM networks with 850,
1800 and 1900 MHz bands.
1 Your telephone......................
13
Voicemail
Camera key
Left softkey
Right softkey
Answer/Send call
Call memory
Navigation key (1):
Main menu, confirm
an option
Messages (2)
Directory (2)
Alarm
File manager
Volume
Ctrl key
(1) Depending on your network operator.
(2) Disabled when events (incoming call, SMS/MMS, news, weather,
appointments etc.) displayed on main screen.
Caps key
Message key
Lock/Unlock
Vibration alert
Del key
Switch on/
Switch off
End call
Side key
1.1 Keys
Navigation key
Confirm an option (press the middle of the key)
Answer
Send a call
Access call memory (Redial) (short keypress)
Switch on/Switch off the telephone (long keypress)
End call
Return to the main screen
Left softkey
Right softkey
Access your voicemail (long keypress)
Create message (short keypress)
Create email (long keypress)
Send a message to the contact (in Directory)
Take photos (short keypress)
Record videos (long keypress)
Side key
- Push: Access “Music player”, “Radio”, “World clock”,
“Image viewer”, “News”, “Weather forecast”,
“My friends”.
Confirm an option
- Scroll up/down: Volume up/down
Previous/next menu
14
15
Ctrl + B: Activate/Deactivate Bluetooth
Ctrl + M: Access Music player
Ctrl + P: Access Profiles
Ctrl + J: Access Java running application
Delete a contact (in Directory/Call memory)
Delete a message (in Inbox/Outbox…)
Delete a file (in File manager)
Delete a note (in Notes)
Shift sound play among Headset, Bluetooth and Headset &
Bluetooth (long keypress).
1.2 Main screen icons (1)
Battery charge level
Vibrate alert: your phone vibrates, but neither rings nor beeps
except for the alarms (see page 57).
Bluetooth status (Blue - Activated).
Bluetooth status (Connected to an audio device).
Headset connected.
Keypad locked.
Call forwarding activated: your calls are forwarded (see page 40).
Alarm clock or appointment(s) (see page 67).
Level of network reception.
Voicemail message arrived.
Missed calls.
Radio is on.
Motion sensor is active.
Pedometer is running in background.
Stopwatch is active.
WAP alerts (2).
Roaming.
Memory card scanning in progress.
16
(1) The icons and illustrations in this guide are provided for informational
purposes only.
(2) Depending on your network operator.
Memory card scanning completed.
Line switching (1): indicates the selected line.
GPRS connection status (Blue - Activated).
GPRS attached.
GPRS connecting.
Music player active.
Reception of a message in progress.
Sending a message.
Silence mode: your phone neither rings, beeps nor vibrates
except for the alarms (see page 57).
Message unread
Message list is full: your terminal cannot accept any new
messages. You must access the message list and delete at least one
message on your SIM card.
Antenna off mode.
A2DP connected.
17
(1) Contact your network operator to check service availability.
2 Getting started .....................
2.1 Set-up
Inserting and removing the SIM card (1)
You must insert your SIM card to make phone calls.
18
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card, press
the bottom and slide it out. Please power off your phone before you
remove the SIM card.
Installing and removing the battery
Insert and click the battery into place, then close the telephone cover.
Unclip the cover, then remove the battery.
(1) Check with your network operator to make sure that your SIM card
is 3V or 1.8V compatible. The old 5 Volt cards can no longer be used.
Please contact your operator.
