TCT Mobile 119 GSM/GPRS/EDGE 850/1900 dual band mobile phone User Manual IP2829 808A QG GEM Eng USA 05 100126 indd
TCT Mobile Limited GSM/GPRS/EDGE 850/1900 dual band mobile phone IP2829 808A QG GEM Eng USA 05 100126 indd
OT-808A UM
1234567
8 9 10 11 12 13 14
1 Your cellphone ............... 1.1 Keys
Navigation key
Confirm an option (press the middle of the key)
Answer
Send a call
Access call memory (Redial) (short keypress)
Switch on/Switch off the telephone (long keypress)
End a call
Return to the main screen
Left softkey
Right softkey
Access your voicemail (long keypress)
Side key
Short keypress:
- Scroll up/down "Home Screen" menus (Home Screen is on)
- Confirm an option
- Backlight on
- Access "Music player"
- Play/pause music (in music playing mode)
Long keypress:
- Scroll up/down "Home Screen" menus quickly
(Home Screen is on)
- Exit "Music player"
Ctrl + B: Activate/Deactivate Bluetooth
Ctrl + M: Access Music player
Ctrl + P: Access Profiles
Ctrl + J: Access Java applications
Delete a contact (in Directory/Call memory)
Delete a message (in Inbox/Outbox…)
Delete a file (in File manager)
Delete a note (in Notes)
Shift sound play among Headset, Bluetooth and Headset &
Bluetooth (long keypress).
1.2 Main screen icons (1)
Battery charge level
Vibrate alert: Your phone vibrates, but does not ring or beep
with the exception of the alarm.
Bluetooth status (Blue - Activated).
Bluetooth status (Connected to an audio device).
Headset connected.
Call forwarding activated: your calls are forwarded.
Alarm.
Level of network reception.
Voicemail message arrived.
Missed calls.
Radio is on.
Stopwatch is active.
WAP alerts (1).
Roaming.
Memory card scanning in progress.
Memory card scanning completed.
SIM card missing.
Line switching (2): indicates the selected line.
GPRS connection status (Blue - Activated).
EDGE attached.
EDGE connecting.
Shown only in no ciphering mode while calling, sending/receiving
SMS.
Music player active.
Message receipt in progress.
Sending a message.
Silence mode: your phone neither rings, beeps nor vibrates
except for the alarms.
Message unread.
Message list is full: your terminal cannot accept any new
messages. You must access the message list and delete at least
one message on your SIM card.
Flight mode.
A2DP connected.
(1) Depending on your network operator.
(2) Contact your network operator to check service availability.
Installing or removing the battery
2 Getting started ..............
2.1 Set-up
Removing or installing the back cover
3 Calls .................................
3.1 Making a call
Dial the desired number then press the key to place the call. If you
make a mistake, you can delete the incorrect digits by pressing the right
softkey or key.
To hang up the call, press the key.
Making an emergency call
If your phone has network coverage, dial emergency number and press the
key to make an emergency call. This works even without a SIM card
and without typing the PIN code.
4 Menu arrange ...........
Main Menu is designed to vary according to your preference.
Change the order
Press left softkey and select "Move" or long keypress Side key/ key till
tick "√" is shown, then move the cursor to your favorite destination and
confirm with key.
Show/Hide
Access "Menu arrange", press to show/hide the main menu items.
Restore default settings
From main menu, select "Menu arrange", press the "Options" softkey,
and then select "Restore default settings" to return back to the default
menu display.
5 Messages ..................
5.1 Create message
From the main menu select "Messages\Write msg" to create text/
multimedia message.
An SMS will be converted to MMS automatically when images, videos,
audios, slides, attachments inserted, Subject, CC/BCC/email address added,
or the message contains more than 8 pages of text.
5.2 Inbox
All received messages (read and unread) are stored in the same Inbox.
Group by sender/Group by receiver (1)
Messages can be grouped by sender/receiver ("Options\Group by
sender"/"Options\Group by receiver"). And you are enabled to quick
search the messages by pressing the key associated with the first letter of
sender/receiver's name.
Group unread message
Unread messages will always be be positioned above the read messages.
Timer send
Schedule a SMS/MMS to be sent out at predefined time (Create SMS/
MMSÆAdd numberÆOptions/Timer send).
Multi-mark
Mark/Unmark file(s) for further operations: Move to archive (2), Send (3),
Delete.
(1) The icons and illustrations in this guide are provided for informational purposes
only.
(1) Depending on your network operator.
(1) The quality of the radio depends on the coverage of the radio station in that
particular area.
(2) Depending on your network operator. May cause additional network charges for
data flow to provide this service. Extra fees might also be charged in roaming
states.
(1) This menu is hidden by default, you can make it visible in main menu (see
page 6).
(2) Depending on your country or your operator. (1) Depending on product and market.
(1) In Radio mode, you are required to plug in headset first. Your phone will power
on automatically before Radio is on.
Inserting or removing the SIM card
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card, press
the bottom and slide it out. Please power off your phone before you
remove the SIM card.
2.2 Power on your phone
Hold down the key until the telephone powers on.
2.3 Power off your phone
Hold down the key from the main screen.
6 Email .....................
Your phone has an email client with the settings pre-defined for a few
popular email services like – GoogleMail, Windows live, Yahoo, AOL, etc.
Besides this, you can set up other POP3 or IMAP4 email accounts that you
may be using.
7 Instant messaging (1)
..
Palringo Instant messaging (IM) allows you to chat with other people using
Palringo account. You can also connect to other popular IM services through
Palringo, like Yahoo, AIM, GG, ICQ, Google talk, iChat and etc. Please note
that the services may be upgraded upon your client version.
8 Directory ..................
8.1 Consulting your directory
To access the Directory from the main screen, press the key or press
the key and select the icon from the menu.
8.2 Adding a contact
Select the directory in which you wish to add a contact, press the
"Options" softkey, select "Add contact".
9 Call register ..............
9.1 Call memory
You can access your call memory by pressing the key from the main
screen.
9.2 Billing (1)
You can access different items with this option: Amount, Duration, GPRS
counter, Beep duration.
9.3 Call settings
You can access a number of items with this option: Call waiting, Call
forwarding, Call barring, Caller ID, Line switching, Auto redial.
10 Media applications ......
10.1 Music player ..................................................
Access this feature from the main menu by selecting "Music player". You
will have full flexibility of managing music both on your cellphone and
memory card.
Mark/Unmark
Mark/Unmark tick(s) on file(s) for further operations: Add to my star
list, Play, Send, Delete marked, etc.
10.2 Image Viewer ................................................
A library links to the pictures in "My creations" and "My images" in
phone to be shown in list, slide, or thumbnail, set as Wallpaper, Screen saver,
Power on/off display, and Contact ID, or sent by MMS, Email, Bluetooth.
10.3 Video player..................................................
Contains all video clips both in phone and memory card and enables you to
Play, Set as contact ID, Mark/Unmark, Send (by MMS, Email, or
Bluetooth), Delete, Delete all, Rename, Sort (by name, type, time or
size) and to Download/Capture new video clips.
Streaming URL
This feature enables the user to start watching video almost as soon as it
begins downloading from internet.
10.4 Radio .............................................................
Your phone is equipped with a Radio (1) with RDS functionality. You can use
the application as a traditional Radio with saved channels or with parallel
visual information related to the radio program on the display, if you tune
to stations that offer Visual Radio service. You can listen to it while running
other applications.
11 Internet
(2)
....................
11.1 My friends ....................................................
It migrates self-contained sub-trees of the websites to let you stay in touch
with your friends by flicking through Bebo, Friendster, Hi5, Myspace, etc.
11.2 Opera .............................................................
Not only does Opera Mini give you the full Web experience where you stay
in touch with your friends, obtain information, do your online banking etc.,
but it is also designed to save time by using compressed web pages.
11.3 Web ..............................................................
Access Web options: Homepage, Bookmarks, Go to URL, Last web
address, Recent pages, Offline pages, Service inbox, Settings.
11.4 News.............................................................
It is a huge time saver providing news updates from a website in a simple
form.
Once subscribed to a feed, it gives you the ability to track and manage all
your favorite RSS content on your cellphone at anytime, anywhere!
11.5 Weather .......................................................
Your phone is equipped with a weather function for consulting up to 3-day
forecast of favorite cities.
12 Entertainment ............
12.1 Fun ...............................................................
12.1.1 Stopwatch
The stopwatch is a simple application for measuring time with the possibility
to register several results and suspend/resume measurement.
12.1.2 Games
Your phone may include some JAVA TM games.
12.2 Ebook (1) .........................................................
A bookshelf contains the electronic books (.txt and .pdb file only). While
reading the book, you may add bookmarks, or reach the text by searching
words, phrases (Options\Search, Options\Jump to).
12.3 Java ................................................................
Your phone may include (2) some Java™ applications and games. You can also
download new applications and games to your phone.
13 Camera .................
Your cellphone is fitted with a camera for taking photos and shooting
videos that you can use in different ways:
- store them in your "File manager\My creations".
- send them in a multimedia message (MMS) to a cellphone or an email
address.
- send them directly by Email or Bluetooth.
- customize your main screen.
- select them as incoming call image to a contact in your directory.
- transfer them by data cable or microSD card to your computer.
- modify your photos by adding frames (only available to size 320x240).
14 Profiles ..................
With this menu, you may personalize ringtones for different events and
environments.
15 File manager ........
You will have an access to all audio and visual files stored in phone or
memory card in File manager. You can access a number of items with this
option: My audios, My images, My videos, My creations, Unknown
files, Ebook, Phone and Memory card.
15.1 Memory card
You can access all files stored in the memory card here.
Insert the memory card
To release the microSD card holder, slide it in the direction of the arrow
and lift it. Then insert the microSD card with the golden contact downward.
Finally, turn down the microSD holder and slide it in the opposite direction
to lock it.
15.2 Formats and compatibility (1)
- Sounds: mp3, m4a, aac, midi, wav, amr, wma
- Images: jpg, gif
- Videos: 3gp, mp4
16 Bluetooth™ ...........
Access this feature by pressing the key to enter the main menu, then
selecting "Bluetooth".
17 Others ..........................
17.1 Calendar .......................................................
Once you enter this menu from main menu, there is a monthly-view
calendar for you to keep track of important meetings, appointments, etc.
Days with events entered will be marked in color.
17.2 Calculator .....................................................
Access this feature by selecting "Calculator" from the main menu.
Enter a number, select the type of operation to be performed using the
navigation keys, and enter the second number, then press key or left
softkey to display the result.
17.3 Notes .............................................................
You can create a note in text or voice format by accessing "Notes" from
main menu.
17.4 Tasks .............................................................
Enables you to easily manage and track the progress of a task with
priorities. All the tasks will be sorted by due date.
17.5 Clock .............................................................
17.5.1 Alarm
Your cellphone has a built-in alarm clock with a snooze feature.
Mode
You may select the mode of Ringtone: Ring, Vibration only, Silence, Radio (1)
or Vibration and Ring.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2010
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior notice.
(1) Depending on your network operator.
(2) Disabled when "Home screen" is on or events (incoming call, SMS/MMS,
news, weather, appointments etc.) displayed on main screen.
(3) Display events (call, SMS, MMS, alarm...) or current status.
Side key
Sub-display (3)
Navigation key (1) (2):
Main menu, confirm
an option
Messages
Directory
WAP
Email
Volume
Left softkey
Right softkey
Answer/Send call
Call memory
Voicemail
Caps key
Switch on/Switch off
End call
Del key
Vibration alert
Ctrl key
(1) The option of "Group by receiver" is available in Outbox, Sent, and Draft folders
only.
(2) Inbox/Sent folder only.
(3) Outbox only.
English - CJB30W1ALAAA
Prolonged exposure to music at full volume on the music player may damage
the listener's hearing. Set your phone volume safely. Use only headphones
recommended by TCT Mobile Limited and its affiliates.
17.5.2 Clock
Allows you to have settings of date and time, including 12/24h format.
17.5.3 World clock
The World clock shows current local time and the time zone in different
cities.
IP2829_808A_QG_GEM_Eng_USA_05_100126.indd 1IP2829_808A_QG_GEM_Eng_USA_05_100126.indd 1 2010-1-26 13:49:522010-1-26 13:49:52
15 16 17 18 19 20 21
22 23 24 25 26 27 28
18 Settings .................
From the main menu, select the menu icon and select the function of
your choice in order to customize your telephone: Display, Languages,
Headset mode, Input mode, Vocabulary, Home screen, Keypad, Security,
Network, Connectivity.
18.1 Home screen (1)
From home screen, you can quickly access the features that you use the
most.
Quick access
When activated, press keys or Side key to scroll up/down application
shortcuts one by one, and press keys to access a list of available
actions of the selected applications. To close the list, press key.
Reorder
The order of the shortcuts can be varied as you wish. Access "Edit\
Reorder", select the application, and press keys to the desired
destination, then confirm with left softkey and save by selecting "Done".
Add/Delete (2)
You can add or delete an item via "Edit\Add" or "Edit\Delete".
19 Making the most of
your cellphone ............
You can download software upgrade for free from the website.
20 Latin input mode........
To write messages, there are two writing methods:
- Normal: this mode allows you to type a text by choosing a letter or a
sequence of characters associated with a key.
- Predictive with the eZi mode: this mode speeds up the writing of your
text.
Navigation key:
: Validate the word
: Previous/next word
: Page up/down
Key :Press once: input a top-half character
Press twice: top-half characters inputting mode
Caps key :In eZi predictive mode: switch among lowercase, initcap,
and uppercase
In normal mode: switch between lowercase and uppercase
SYM key :Short keypress: access the Symbols table
Long keypress: access the language list
Ctrl key :Short press: switch from eZi predictive mode to Normal
mode
Long press: add a word
Del key :Short keypress: delete one by one
Long keypress: delete all
Safety and use .......................
We recommend that you read this chapter carefully before using your cellphone.
The manufacturer disclaims any liability for damage, which may result as a
consequence of improper use or use contrary to the instructions contained
herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle constitutes a
real risk, even when the hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their cellphone when the vehicle is not parked.
Check the laws and regulations on the use of wireless telephones and their
accessories in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas.
When driving, do not use your cellphone and headphone to listen to music or to
the radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your cellphone emits electromagnetic waves that can interfere
with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To
ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its
performance.
Switch the cellphone off before boarding an aircraft to avoid prosecution.
Switch the cellphone off when you are in health care facilities, except in designated areas.
As with many other types of equipment now in regular use, cellphones can interfere
with other electrical or electronic devices, or equipment using radio frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly obey
all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in
any potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump. In particular
when using the cellphone you should hold it against the ear on the opposite side
to the device, if any.
To avoid hearing impairment, answer the call before holding your cellphone to your
ear. Also move the handset away from your ear while using the “hands-free” option
because the amplified volume might cause hearing damage.
Do not let small children use your cellphone without supervision.
When replacing the cover please note that your cellphone may contain substances
that could create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free place.
This warranty shall not apply to defects to your phone and/or
accessory due to (without any limitation):
1) Non-compliance with the instructions for use or installation, or
with technical and safety standards applicable in the geographical
area where your phone is used,
2) Connection to any equipment not supplied or not recommended
by TCT Mobile Limited,
3) Modification or repair performed by individuals not authorized by
TCT Mobile Limited or its affiliates or your vendor,
4) Inclement weather, lightning, fire, humidity, infiltration of liquids or
foods, chemical products, download of files, crash, high voltage,
corrosion, oxidation…
Your phone will not be repaired in case labels or serial numbers
(IMEI) have been removed or altered.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your jurisdiction.
In no event shall TCT Mobile Limited or any of its affiliates be liable
for incidental or consequential damages of any nature whatsoever,
including but not limited commercial loss, to the full extent those
damages can be disclaimed by law. Some countries/states do not
allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you.
Disclaimer
There may be certain differences between the user manual description and
the cellphone’s operation, depending on the software release of your
cellphone or specific operator services.
Telephone warranty .............
Your cellphone is warranted against any defect which may occur in
conditions of normal use during the warranty period of twelve (12)
months (1) from the date of purchase as shown on your original invoice.
Batteries (2) and accessories sold with your cellphone are also warranted
against any defect which may occur during the first six (6) months (1)
from the date of purchase as shown on your original invoice.
In case of any defect of your cellphone which prevents you from
normal use thereof, you must immediately inform your vendor and
present your phone with a proof of purchase.
If the defect is confirmed, your cellphone or part thereof will be
either replaced or repaired, as appropriate. Repaired Phone and
accessories are entitled to a one (1) month warranty for the same
defect. Repair or replacement may be carried out using reconditioned
components offering equivalent functionality.
This warranty covers the cost of parts and labor but excludes any
other costs.
Do not allow your cellphone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The
manufacturer’s recommended operating temperature range is -10°C to +55°C (the
max value depends on device, materials and housing paint/texture).
Over 55°C the legibility of the cellphone’s display may be impaired, though this is
temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your cellphone
model.TCT Mobile Limited and its affiliates disclaim any liability for damage caused
by the use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check local
regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing
lights, or when playing video games. These seizures or blackouts may occur even if a
person never had a previous seizure or blackout. If you have experienced seizures
or blackouts, or if you have a family history of such occurrences, please consult
your doctor before playing video games on your cellphone or enabling a flashing-
lights feature on your cellphone. Parents should monitor their children’s use of
video games or other features that incorporate flashing lights on the cellphones. All
persons should discontinue use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms, please take
the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a well lit environment.
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow
these instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or
other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest
for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop
the game and see a doctor.
Prolonged exposure to music at full volume using the music player may damage
your hearing. Set your phone’s volume to it’s lowest setting prior to inserting
headphones in your ears and adjust the volume to your preference. Only use
headphones that are recommended by TCT Mobile Limited and it’s affiliates.
Troubleshooting....................
Before contacting the aftersales department, you are advised to follow the
instructions below:
• You are advised to switch off the telephone from time to time to
optimize its performance.
• You are advised to fully charge ( ) the battery for optimal
operation.
• Avoid storing large amounts of data in your telephone as this may
affect the performance of your telephone.
and carry out the following checks:
My cellphone will not switch on
• Press until the screen comes on
• Check the battery charge level
• Check the battery contacts, remove and reinstall your battery, then
turn your telephone back on
My phone has not responded for several minutes
• Press the key
•
Remove the battery and re-insert it, then switch the phone back on
My screen is difficult to read
• Clean your screen
• Use your cellphone in accordance with the recommended conditions
of use
My cellphone turns off by itself
• Check that your keypad is locked when you are not using your
cellphone
• Check the battery charge level
My cellphone will not charge properly
• Make sure that your battery is not completely discharged; the
battery charge indicator can take several minutes and may be
accompanied by a quiet whistling sound
• Make sure charging is carried out under normal conditions (0°C –
+40°C)
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your cellphone regarding
taking photographs and recording sounds with your cellphone. Pursuant to such
laws and regulations, it may be strictly forbidden to take photographs and/or to
record the voices of other people or any of their personal attributes, and
reproduce or distribute them, as this may be considered to be an invasion of
privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained, if
necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
cellphone (including the operator) disclaim any liability which may result from the
improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental
regulations. Only use the battery for the purpose for which it was designed. Never
use damaged batteries or those not recommended by TCT Mobile Limited and/or
its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at
the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign
must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead
they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
• Make sure your battery is inserted. It must be inserted before
plugging in the charger
• Make sure you are using an Alcatel battery and charger
• When abroad, check that the electrical current is compatible
My cellphone will not connect to a network
• Try connecting in another location
• Verify the network coverage with your operator
• Check with your operator that your SIM card is valid
• Try selecting the available network(s) manually
• Try connecting at a later time if the network is overloaded
SIM card error
• Make sure the SIM card has been correctly inserted
• Verify with your operator that your SIM card is 3V compatible; the
old 5V SIM cards cannot be used
• Make sure the chip on your SIM card is not damaged or scratched
Unable to make outgoing calls
• Make sure you have dialled a valid number and press the key
• For international calls, check the country and area codes
• Make sure your cellphone is connected to a network, and that the
network is not overloaded or unavailable
• Check your subscription status with your operator (credit, SIM card
valid, etc.)
• Make sure you have not barred outgoing calls
Unable to receive incoming calls
• Make sure your cellphone is switched on and connected to a
network (check for overloaded or unavailable network)
• Check your subscription status with your operator (credit, SIM card
valid, etc.)
• Make sure you have not forwarded incoming calls
• Make sure that you have not barred certain calls
The caller's name does not appear when a call is received
• Check that you have subscribed to this service with your operator
• Your caller has concealed his/her number
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C to
40°C.
The chargers designed for your cellphone meet with the standard for safety of
information technology equipment and office equipment use. Due to different
applicable electrical specifications, a charger you purchased in one jurisdiction may
not work in another jurisdiction. They should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 350 mA
Battery: Lithium 850 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to radio-frequency (RF) energy.
These limits are part of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. These guidelines include a substantial safety
margin designed to ensure the safety of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such
as the Federal Communications Commission of the US Government (FCC), or by
Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR
are conducted using standard operating positions with the cellphone transmitting at
its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR
level of the cellphone while operating can be well below the maximum value. This is
because the cellphone is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output of the cellphone Before
a cellphone model is available for sale to the public, compliance with national
regulations and standards must be shown.
The highest SAR value for this model cellphone when tested is 0.983 W/Kg for use
at the ear and 1.02 W/Kg for use close to the body.
While there may be differences between the SAR levels of various cellphones and
at various positions, they all meet the government requirement for RF exposure.
For body-worn operation, the cellphone meets FCC RF exposure guidelines
provided that it is used with a non-metallic accessory with the handset at least 1.5
cm from the body. Use of other accessories may not ensure compliance with FCC
RF exposure guidelines.
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for use of
cellphones. If individuals are concerned, they might choose to limit their own or
The sound quality of the calls is not optimal
• You can adjust the volume during a call by means of the key
• Check the radio reception icon level
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription
includes this service
• Make sure this feature does not require an Alcatel accessory
When I select a number from my directory, the number is
not dialled
• Make sure that you have correctly recorded the number in your
file
• Make sure that you have selected the country prefix when calling a
foreign country
I am unable to add a contact in my directory
• Make sure that your SIM card directory is not full; delete some files
or save the files in the product directory (i.e. your professional or
personal directories)
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability
I cannot access my voicemail
• Make sure your operator's voicemail number is correctly entered in
"My numbers"
• Try later if the network is busy
I am unable to send and receive MMS
• Check your phone memory available as it might be full
• Contact your network operator to check service availability and
check MMS parameters
• Verify the server center number or your MMS profile with your
operator
• The server center may be saturated; try again later
The icon is displayed on my standby screen
• You have saved too many short messages on your SIM card; delete
some of them or archive them in the product memory
"No service" is displayed
• You are outside of the network coverage area
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by TCT Mobile Limited and
its affiliates is under license. Other trademarks and trade names
are those of their respective owners.
OT-808A Bluetooth QD ID B015352
eZiText™ and Zi™ are trademarks of Zi Corporation and/or its
Affiliates.
Java™ and all Java™ based trademarks and logos are trademarks
or registered trademarks of Sun Microsystems, Inc. in the U.S. and
other countries.
is a registered trademark of Opera Mini.
General information ............
• Website: www.alcatel-mobilephones.com
• Hot Line Number: In the United States, call 877-702-3444 for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatel-mobilephones.
com
Your cellphone is a transceiver that operates on GSM networks with 850
and 1900 MHz bands.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number) shown on
the packaging label and in the product’s memory. We recommend that you
note the number the first time you use your cellphone by entering *#06#
and keep it in a safe place. It may be requested by the police or your
operator if your cellphone is stolen.
I have already entered 3 incorrect PIN codes
• Contact your network operator to obtain the PUK code (Personal
Unblocking Key)
I am unable to connect my telephone to my computer
• Install first of all Alcatel's PC suite
• Use "Install the connection" and perform the installation
• Check that your computer meets the requirements for Alcatel's PC
Suite installation
I am unable to download new files
• Check for free space
• Delete some files
• Select the MicroSD Card to store the files you downloaded
• Check your subscription status with your operator
The phone can't be detected by others via Bluetooth
• Make sure that Bluetooth is turned on and your cellphone is visible
to other users
My cellphone is dead, can't power on
• Make sure your battery is not completely used up or damaged
• Remove your battery, remove your SIM card then power it on
again
• Hold down # + power on/off key at same time to reset it
ALL User phone data: contacts, photos, messages and files,
downloaded applications like Java games will be lost
permanently.
How to make your battery last longer
•
Make sure you follow the complete charge time (minimum 3 hours)
• After a partial charge, the battery level indicator may not be exact.
Wait for at least 20 minutes after removing the charger to obtain
an exact indication
• Switch on the backlight upon request
• Extend email auto-check interval as long as possible
• Update news, weather info. upon demand manually or set its auto-
check interval longer
• Exit Java background-running applications if unused for a long time
• Deactivate Bluethooth when not in use
their children’s RF exposure by limiting the length of calls, or using “hands-free”
devices to keep cellphones away from the head and body. (fact sheet n°193).
Additional WHO information about electromagnetic fields and public health are
available on the following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service
(e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other
than against your ear. In such circumstances the device will be compliant with the
guidelines when used with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any metal and that it
positions the phone at least 2cm away from the body.
(1) Contact your network operator for service availability.
(1) The warranty period may vary depending on your country.
(2) The life of a rechargeable cellphone battery in terms of conversation time
standby time, and total service life, will depend on the conditions of use and
network configuration. Batteries being considered expendable supplies, the
specifications state that you should obtain optimal performance for your phone
during the first six months after purchase and for approximately 200 more
recharges.
(1) It is activated by default. To exit this function, you can set it off from "Settings\
Home screen\Display\Off".
(2) Three predefined items (Calls, Contacts and Messages) can not be deleted.
IP2829_808A_QG_GEM_Eng_USA_05_100126.indd 2IP2829_808A_QG_GEM_Eng_USA_05_100126.indd 2 2010-1-26 13:49:542010-1-26 13:49:54
