TCT Mobile 120 GSM/GPRS 850/1900 dual-band mobile phone User Manual 090731 Crystal QG USA
TCT Mobile Limited GSM/GPRS 850/1900 dual-band mobile phone 090731 Crystal QG USA
Crystal A UM
1 Your telephone ...............
1.1 Keys
Navigation key
Confirm an option (press the middle of the key)
Access slide show and music player (long keypress)
Answer
Send a call
Access call memory (Redial) (short keypress)
Access events (long keypress)
Switch on/Switch off the telephone (long keypress)
End call
Return to the main screen
Left softkey
Right softkey
Access your voicemail (long keypress)
In Edit mode:
- Short keypress: change input methods
- Switch from T9 predictive mode to Normal mode
- Long keypress: access the Symbols table
In Edit mode:
- Short keypress: access the language list
- Long keypress: enter zero
From main screen
- Short keypress: #
- Long keypress: activate/deactivate the vibrator
In edit mode:
- Short keypress:
(space)
- Long keypress: add a word
Short keypress: Play/pause music, Radio off.
Long keypress: Lock/Unlock the side keys (flip off).
Short keypress: Previous/next song (in the playing mode)
Previous/next channel (Radio on)
Long keypress: Volume up/down
8.3 Alarm
Your cellphone has a built-in alarm clock with a snooze feature.
8.4 Calculator
Hold down the key to get the decimal point. Confirm with the
key or the left softkey.
8.5 Converter
Unit converter and Currency converter.
8.6 Voice memo
This feature enables you to record a call by selecting “Voice memo”
while communicating. To record a sound, select “Voice memo”,
then “New record”.
8.7 Memory status
It will indicate how much space is used and how much is currently
free on your phone and memory card (if any).
8.8 Directory backup
It maintains copy of contacts between Phone Directory and memory
card, in case of phone errors, theft or disasters.
8.9 My shortcuts
Access the shortcuts already programmed. To program new shortcuts:
select “My shortcuts” if you want to create a quick access to a function,
Directory, or WAP Bookmarks, etc.
9 WAP .........................
Access Wap options: Homepage, Bookmarks, Recent pages, Go to
URL and Profiles.
1.2 Main screen icons
, Battery charge level
Vibrate alert: your phone vibrates, but neither rings nor beeps
except for the alarms.
Bluetooth status (Blue - Activated).
Bluetooth status (Connected to an audio device).
Headset connected.
Call forwarding activated: your calls are forwarded.
Alarm clock programmed.
Level of network reception.
Voicemail message arrived.
Unanswered calls.
WAP alerts (1).
Roaming.
Memory card scanning in progress.
Memory card scanning completed.
Line switching (1): indicates the selected line.
GPRS connection status (Blue - Activated).
Shown only in no ciphering mode while calling, sending/
receiving SMS.
Multimedia player active.
USB cable connected.
Reception of a message in progress.
Sending a message.
Silence mode: your phone neither rings, beeps nor vibrates
except for the alarms.
Message unread
Message list is full: your terminal cannot accept any new
messages. You must access the message list and delete at
least one message on your SIM card.
Antenna off mode.
A2DP connected.
10 File manager .............
You will have an access to all audio and visual files stored in phone
or memory card in File manager.
10.1 My audios
Choose an audio for the ON/OFF screen, for an incoming call, a
message alert, power on/off ringtone or an alarm and scheduler.
10.2 My images
You can select an image or a photo as wallpaper, ON/OFF screen,
or assign it to a contact in the directory.
10.3 My videos
The “My videos” album contains all video clips embedded and
downloaded in phone or memory card.
10.4 My creations
This feature stores all the photos captured by your cellphone.
10.5 Unknown files
Store files of unsupported format.
10.6 Memory card
You will have access to all files stored in memory card here.
2 Getting started
2.1 Set-up
Removing and installing the back cover
Installing and removing the battery
Inserting and removing the SIM Card
Place the SIM card with the chip facing downwards and slide it into
its housing. Make sure that it is correctly inserted. To remove the
card, press it and slide it out. Please power off your phone before
you remove the SIM card.
2.2 Power on your phone
Hold down the key until the telephone powers on.
2.3 Power off your phone
Hold down the key from the main screen.
Insert the memory card
10.7 Formats and compatibility
- Sounds: mp3, m4a, aac, midi, wav, amr
- Images: jpg, gif, bmp
- Videos: 3gp, mjpg
11 Camera ....................
Your cellphone is fitted with a camera for taking photos and
shooting videos that you can use in different ways:
- store them in your “File manager”.
- send them in a multimedia message (MMS) to a cellphone or an
email address.
- customize your main screen.
- select them as incoming call image to a contact in your directory.
- transfer them by data cable or microSD card to your computer.
- modify your photos through adding frames.
12 Multimedia player .....
Access this feature from the main menu by selecting “Multimedia
player”. You will have full access to “Music player”, “Video player”,
“Image viewer” and “FM radio”.
3 Calls
3.1 Making a call
Dial the desired number then press the key to place the call. If
you make a mistake, you can delete the incorrect digits by pressing
the right softkey.
To hang up the call, press the key.
Making an emergency call
If your phone is covered by the network, dial emergency number
and press the key to make an emergency call. This works even
without a SIM card and without typing the PIN code or unlocking
the keypad.
3.2 Calling your voicemail (1)
To access your voicemail, hold down the key.
3.3 Receiving a call
When you receive an incoming call, press the key to talk and
then hang up using the key.
3.4 Available functions during the call
During a call, you can use your directory, your diary, short messages,
etc. without losing your correspondent by pressing the key.
13
Games & Applications
Your Alcatel phone may include (1) some Java™ applications and
games. You can also download new applications and games to
your phone.
14 Profiles ....................
With this menu, you may personalise ringtones for different events
and environments.
15 Making the most of
your cellphone ................
PC suite is provided on www.branddesignlab.com .
You can download software upgrade for free from this website.
16 Latin input mode .............
To write messages, there are two writing methods:
- Normal: this mode allows you to type a text by choosing a letter
or a sequence of characters associated with a key.
- Predictive with the T9 mode: this mode speeds up the writing of
your text.
- key in edit mode:
Short keypress: Access the language list
Long keypress: Enter zero
4 Call register ..............
4.1 Call memory
You can access your call memory by pressing the key from the
main screen.
4.2 Events
By holding down he key from main screen or accessing from
main menu, it allows you to view a list of your all latest 20 events
(SMS, MMS, WAP Alerts, Voicemail and unanswered calls).
4.3 Billing
You can access different items with this option: Amount, Duration,
GPRS counter, Beep duration.
4.4 Call settings
You can access a number of items with this option: Call waiting, Call
forwarding, Call barring, Caller ID, Line switching, Auto redial.
5 Directory ...................
5.1 Consulting your directory
To access the directory from the main screen, press the key or
press the key and select the icon from the menu.
5.2 Creating a file
Select the directory in which you wish to create a file, press the
“Options” softkey, select “Create file” then .
12
(1) Contact your network operator to check service availability.
3456
6 Messages .................
6.1 Create message
From the main menu select “Messages” to create text/multimedia
message. You can type a message and you can also modify a
predefined message in Templates or customize your message by
adding pictures, photos, sounds, titles, etc (only available while
editing a MMS). While writing a message, select “Options” to access
all the messaging options. You can save your messages that you
send often to Drafts or Templates (MMS only).
6.2 Inbox
All received messages (read and unread) are stored in the same
Inbox.
7 My settings ...............
From the main screen, select the icon menu and select the
function of your choice in order to customize your telephone: Color,
Theme, Clamshell, Equalizer, Display, Clock, Keys, More settings…
8 Tools ........................
8.1 Bluetooth
Access this feature by selecting “Tools” from the main menu, then
“Bluetooth”.
8.2 Organizer
Once you enter this menu from “Tools”, there is a monthly-view
calendar for you to keep track of important meetings, appointments,
etc. Days with events entered will be marked in color.
78910
ALCATEL is a trademark of
Alcatel-Lucent and used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2009
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior notice.
11 12
(1) Contact your network operator to check service availability.
English - CJB2111ALAAA
To release the microSD card holder, slide it in the direction of the
arrow and lift it. Then insert the microSD card with the golden
contact downward. Finally, turn down the microSD holder and
slide it in the opposite direction to lock it.
Prolonged exposure to music at full volume on the music player
may damage the listener’s hearing. Set your phone volume safely.
Use only headphones recommended by TCT Mobile Limited and
its affiliates.
(1) Depending on your network operator.
(2) Display events (call, SMS, MMS, alarm...) or current status.
(1) Depending on your country or your operator.
1
2
3
4
5
6
7
8
10
9
Sub-display (2)
Volume up
Play/Pause key
Volume down
Left softkey
Answer/Send call
Call memory
Voicemail
Right softkey
Switch on/Switch off
End call
Vibration alert
Navigation key (1):
Menu/Confirm an option
Messages
Directory
WAP
File manager
11
9
8
3
7
6
5
4
2
1
11
10
2) not being compliant with technical and safety standards applicable
in the geographical area where the equipment is used,
3) improper maintenance of sources of energy, and of the overall
electric installation,
4) accidents or consequences of theft of the vehicle in which
the cellphone is transported, acts of vandalism, lightning, fire,
humidity, infiltration of liquids, inclement weather,
5) connecting to or integrating into the cellphone any equipment
not supplied or not recommended by TCT Mobile Limited or its
affiliates, without their express written consent for such,
6) any servicing, modification or repair performed by individuals
not authorized by TCT Mobile Limited or its affiliates, the vendor
or the approved maintenance centre,
7) use of the cellphone and/or its accessory for a purpose other
than that for which it was designed,
8) normal wear,
9) malfunctions caused by external causes (e.g., radio interference
from other equipment, power voltage fluctuations),
10) modifications made to the equipment even if required by changes
in regulations and/or modification of network parameters,
11) faulty connections resulting from unsatisfactory radio transmission
or caused by the absence of radio relay coverage.
12) equipment on which markings or serial numbers have been
removed or altered, and handsets on which labels have been
removed or deteriorated shall be excluded from the warranty.
In accordance with the applicable law, your product is warranted
against hidden defects (defects inherent in the design, manufacture,
etc.).
There are no express warranties, whether written or oral, other
than this printed limited warranty, express or implied, of any nature
whatsoever.
In no event shall TCT Mobile Limited or its affiliates be liable for
incidental or consequential damages of any nature whatsoever,
including but not limited to trading loss, commercial loss, to the full
extent those damages can be disclaimed by law. Some countries/states
do not allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you.
Troubleshooting .......................
Before contacting the aftersales department, you are advised to
follow the instructions below:
• You are advised to switch off the telephone from time to time to
optimize its performance.
• You are advised to fully charge ( ) the battery for optimal
operation.
• Avoid storing large amounts of data in your telephone as this may
affect the performance of your telephone.
and carry out the following checks:
My cellphone will not switch on
• Press until the screen comes on
• Check the battery charge level
• Check the battery contacts, remove and reinstall your battery,
then turn your telephone back on
My phone has not responded for several minutes
• Press the key
• Remove the battery and re-insert it, then switch the phone back on
My screen is difficult to read
• Clean your screen
• Use your cellphone in accordance with the recommended
conditions of use
My cellphone turns off by itself
• Check that your keypad is locked when you are not using your
cellphone
• Check the battery charge level
My cellphone has a low level of autonomy
• Make sure you respected the complete charge timing (minimum
3 hours)
• After a partial charge, the battery level indicator may not be exact.
Wait for at least 20 minutes after removing the charger to obtain
an exact indication
My cellphone will not charge properly
• Make sure that your battery is not completely discharged; the
battery charge indicator can take several minutes and may be
accompanied by a quiet whistling sound
• Make sure charging is carried out under normal conditions (0°C
+40°C)
• Make sure your battery is inserted. It must be inserted before
plugging in the charger
• Make sure you are using an Alcatel battery and charger
• When abroad, check that the electrical current is compatible
My cellphone will not connect to a network
• Try connecting in another location
• Verify the network coverage with your operator
• Check with your operator that your SIM card is valid
• Try selecting the available network(s) manually
• Try connecting at a later time if the network is overloaded
SIM card error
• Make sure the SIM card has been correctly inserted
• Verify with your operator that your SIM card is 3V compatible; the
old 5V SIM cards cannot be used
• Make sure the chip on your SIM card is not damaged or scratched
Unable to make outgoing calls
• Make sure you have dialled a valid number and press the key
• For international calls, check the country and area codes
• Make sure your cellphone is connected to a network, and that the
network is not overloaded or unavailable
• Check your subscription status with your operator (credit, SIM
card valid, etc.)
• Make sure you have not barred outgoing calls
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service
(e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
As cellphone devices offer a range of functions, they can be used in positions
other than against your ear. In such circumstances the device will be compliant
with the guidelines when used with headset. If you are not using headset ensure
that whatever product is used is free of any metal and that it positions the phone
at least 2 cm away from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by TCT Mobile Limited
and its affiliates is under license. Other trade marks and trade
names are those of their respective owners.
CRYSTAL A Bluetooth QD ID B014211.
T9 Text Input is licensed under one or more of the following:
U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541,
6,011,554, 6,286,064, 6,307,548, 6,307,549, and 6,636,162,
6,646,573; European Pat. Nos. 0 842 463 (96927260.8), 1
010 057 (98903671.0), 1 018 069 (98950708.2); and
additional patents are pending worldwide.
Java™ and all Java™ based trademarks and logos are
trademarks or registered trademarks of Sun Microsystems, Inc.
in the U.S. and other countries.
Unable to receive incoming calls
• Make sure your cellphone is switched on and connected to a
network (check for overloaded or unavailable network)
• Check your subscription status with your operator (credit, SIM
card valid, etc.)
• Make sure you have not forwarded incoming calls
• Make sure that you have not barred certain calls
The caller’s name does not appear when a call is received
• Check that you have subscribed to this service with your operator
• Your caller has concealed his/her number
The sound quality of the calls is not optimal
• You can adjust the volume during a call by means of the key
• Check the radio reception icon level
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription
includes this service
• Make sure this feature does not require an Alcatel accessory
When I select a number from my directory, the number is not dialled
• Make sure that you have correctly recorded the number in your file
• Make sure that you have selected the country prefix when calling
a foreign country
I am unable to create a file in my directory
• Make sure that your SIM card directory is not full; delete
some files or save the files in the product directory (i.e. your
professional or personal directories)
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability
I cannot access my voicemail
• Make sure your operator’s voicemail number is correctly entered
in “My Numbers”
• Try later if the network is busy
I am unable to send and receive messages MMS, Vox MMS
• Check your phone memory available as it might be full
• Contact your network operator to check service availability and
check MMS parameters
• Verify the server center number or your MMS profile with your
operator
• The server center may be saturated; try again later
The icon is displayed on my standby screen
• You have saved too many short messages on your SIM card;
delete some of them or archive them in the product memory
“No service” is displayed
• You are outside of the network coverage area
I have already entered 3 incorrect PIN codes
• Contact your network operator to obtain the PUK code (Personal
Unblocking Key)
I am unable to connect my telephone to my computer
• Install first of all Alcatel’s PC suite
• Use “Install the connection” and perform the installation
• Check that your computer meets the requirements for Alcatel’s
PC Suite installation
I am unable to download new files
• Check for free space
• Delete some files
• Select the MicroSD Card to store the files you downloaded
• Check your subscription status with your operator
The phone can’t be detected by others via Bluetooth
• Make sure that Bluetooth is turned on and your cellphone is
visible to other users
13 14 15 16 17 18
Telephone warranty .................
Congratulations on choosing this cellphone - we hope that you will be
completely satisfied with it.
Your cellphone is guaranteed against any deviation from technical
specifications for a period of twelve (12) months from the date
specified on your original invoice, subject to any other specific
provisions (1).
The warranty terms defined in the manual also apply to the battery
and accessories sold with the cellphone but for a period of six (6)
months (2) from the date of purchase shown on your original invoice.
Under the terms of this warranty, you must immediately inform
your vendor (or any repair centre approved by TCT Mobile Limited
or its affiliates, which are listed on our website http://www.alcatel-
mobilephones.com) in case of a conformity defect on your cellphone,
and present the invoice given to you at the time of purchase.The
vendor or repair centre will decide whether to replace or repair, as
appropriate, all or any part of the cellphone or accessory found to
be defective; this warranty covers the cost of parts and labour but
excludes any other costs. Repair or replacement may be carried out
using reconditioned components offering equivalent functionality.
Servicing under the terms of this warranty, especially repair,
modification or replacement of products, shall entitle to a ONE (1)
month warranty unless there are statutory provisions to the contrary.
This warranty shall not apply to damage or defects to your cellphone
and/or accessory caused by:
1) not following the instructions for use or installation,
19 20 21 22 23 24
(1) The mandatory warranty period may vary if overriding statutory
provisions are applicable in your jurisdiction.
(2) The life of a rechargeable cellphone battery in terms of
conversation time, standby time, and total service life, will
depend on the conditions of use and network configuration.
Batteries being considered expendable supplies, the
specifications state that you should obtain optimal performance
for your cellphone during the first six months after purchase
and for approximately 200 more recharges.
(1) Contact your network operator for service availability.
Safety and use .........................
Thank you for buying Crystal mobile phone.
Made with CRYSTALLIZED
TM
- Swarovski Elements, your Crystal mobile phone is a unique
masterpiece of craftsmanship, designed to be the perfect gift for every occasion.
It is a delicate product and should be treated as a jewel. It should be handled carefully
and put into a protective case when not used, in order to avoid any damage, such as
scratching. Do not let your children play with it, it is not a toy.
In order to help maintain the beauty of your Crystal mobile phone over time, carefully
polish it with a soft, lint-free cloth when necessary. Avoid contact with harsh cleansers.
We wish you the most enjoyable experience with your new Crystal mobile phone.
We recommend that you read this chapter carefully before using your phone. The
manufacturer disclaims any liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle constitutes a real
risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to
refrain from using their cellphone when the vehicle is not parked. Check the laws and
regulations on the use of wireless telephones and their accessories in the areas where
you drive. Always obey them. The use of these devices may be prohibited or restricted
in certain areas.
When driving, do not use your cellphone and headphone to listen to music or to the
radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your cellphone emits electromagnetic waves that can interfere with
the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that
there is no problem:
-
do not place your cellphone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its performance.
Switch the cellphone off before boarding an aircraft to avoid prosecution.
Switch the cellphone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, cellphones can
interfere with other electrical or electronic devices, or equipment using radio frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly obey all
signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any
potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any medical
device such as a pacemaker, a hearing aid or insulin pump. In particular when using the
cellphone you should hold it against the ear on the opposite side to the device, if any.
To avoid hearing impairment, answer the call before holding your cellphone to your ear.
Also move the handset away from your ear while using the “hands-free” option because
the amplified volume might cause hearing damage.
Do not let small children use your cellphone without supervision.
When replacing the cover please note that your cellphone may contain substances that
could create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free place.
Do not allow your cellphone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The
manufacturer’s recommended operating temperature range is -10°C to +55°C (the max
value depends on device, materials and housing paint/texture).
Over 55°C the legibility of the cellphone’s display may be impaired, though this is
temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by TCT
Mobile Limited and its affiliates and are compatible with your cellphone model.TCT
Mobile Limited and its affiliates disclaim any liability for damage caused by the use of
other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check local
regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important information
stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing lights,
or when playing video games. These seizures or blackouts may occur even if a person
never had a previous seizure or blackout. If you have experienced seizures or blackouts,
or if you have a family history of such occurrences, please consult your doctor before
playing video games on your cellphone or enabling a flashing-lights feature on your
cellphone. Parents should monitor their children’s use of video games or other features
that incorporate flashing lights on the cellphones. All persons should discontinue use
and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary movements, or disorientation. To limit the
likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a well lit environment.
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional discomfort
in your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for
several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the
game and see a doctor.
Prolonged exposure to music at full volume on the music player may
cause the listener’s hearing impairment. Adjust the volume before placing
headphones on or in your ear. Only use headphones recommended by TCT
Mobile Limited and its affiliates.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your cellphone regarding
taking photographs and recording sounds with your cellphone. Pursuant to such
laws and regulations, it may be strictly forbidden to take photographs and/or to
record the voices of other people or any of their personal attributes, and reproduce
or distribute them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained,
if necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
cellphone (including the operator) disclaim any liability which may result from the
improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental
regulations. Only use the battery for the purpose for which it was designed. Never
use damaged batteries or those not recommended by TCT Mobile Limited and/or
its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at the
end of their life:
- Municipal waste disposal centers with specific bins for these items
of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign
must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead
they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
• CHARGERS
Home A.C. chargers will operate within the temperature range of: 0°C to 40°C.
The chargers designed for your cellphone meet with the standard for safety of information
technology equipment and office equipment use. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction may not work in another
jurisdiction. They should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 500 mA
Battery: Lithium 750 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE
TO RADIO WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and manufactured not
to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits
are part of comprehensive guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough evaluation of scientific
studies. These guidelines include a substantial safety margin designed to ensure the safety
of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the
Federal Communications Commission of the US Government (FCC), or by Industry
Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted
using standard operating positions with the cellphone transmitting at its highest certified
power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR
level of the cellphone while operating can be well below the maximum value. This is
because the cellphone is designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the cellphone Before a cellphone model
is available for sale to the public, compliance with national regulations and standards
must be shown.
The highest SAR value for this model cellphone when tested is 1.08 W/Kg for use at the
ear and 1.09 W/Kg for use close to the body.
While there may be differences between the SAR levels of various cellphones and at
various positions, they all meet the government requirement for RF exposure. For body-
worn operation, the cellphone meets FCC RF exposure guidelines provided that it is used
with a non-metallic accessory with the handset at least 1.5 cm from the body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines.
The World Health Organization (WHO) considers that present scientific information does
not indicate the need for any special precautions for use of cellphones. If individuals are
concerned, they might choose to limit their own or their children’s RF exposure by limiting
the length of calls, or using “hands-free” devices to keep cellphones away from the head
and body. (fact sheet n°193). Additional WHO information about electromagnetic fields
and public health are available on the following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
General information .................
• Website: www.alcatel-mobilephones.com
• Hot Line Number: see “TCT Mobile Services” leaflet or go to our
Internet site.
On our Internet site, you will find our FAQ (Frequently Asked
Questions) section. You can also contact us by e-mail to ask any
questions you may have.
An electronic version of this user guide is available in English and
other languages according to availability on our server: www.alcatel-
mobilephones.com
Your cellphone is a transceiver that operates on GSM networks with
850 and 1900 MHz bands.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number)
shown on the packaging label and in the product’s memory. We
recommend that you note the number the first time you use your
cellphone by entering *#06# and keep it in a safe place. It may be
requested by the police or your operator if your cellphone is stolen.
This number allows your cellphone to be blocked preventing a third
person from using it, even with a different SIM card.
Disclaimer
There may be certain differences between the user manual
description and the cellphone’s operation, depending on the
software release of your cellphone or specific operator services.
