TCT Mobile 142 GSM/GPRS/EDGE dualband mobile phone User Manual IP3223 806A 807A QG Eng USA 02 100929 indd
TCT Mobile Limited GSM/GPRS/EDGE dualband mobile phone IP3223 806A 807A QG Eng USA 02 100929 indd
Manual
1234567
8 9 10 11 12 13 14
Your cellphone
1 ..................
OT-806A OT-807A
Status bar icons1.1 (1)
Battery charge level
Vibrate alert: your cellphone vibrates, but does not ring or
beep with the exception of the alarm.
Bluetooth status (Activated).
Bluetooth status (Connected to an audio device).
Java status (Activated).
Headset connected.
Keypad & LCD touch locked.
Keypad& LCD touch unlocked.
Call forwarding activated: your calls are forwarded.
Alarm or appointments programmed.
Level of network reception.
Wi-Fi connected.
Wi-Fi disconnected.
Voicemail message arrived.
Missed calls.
Stopwatch is active.
Radio is on.
WAP alerts (1).
Roaming.
Memory card scanning in progress.
Memory card scanning completed.
SIM card unavailable.
Line switching (1): indicates the selected line.
GPRS connection status (Activated).
GPRS connecting.
EDGE attached.
EDGE connecting.
Music player active.
Message receipt in progress.
Sending a SMS.
Sending a MMS.
Silence mode: your cellphone does not ring, beep or vibrate
with the exception of the alarm.
SMS unread.
(In red) Message list is full: your cellphone cannot accept
any new messages. You must access the message list and delete
at least one message on your SIM card.
Flight mode.
A2DP connected.
Broadcast is on.
Status list1.2
Tap the status bar and drag down to open, drag up to close.
To open an application, tap it from the list.
Desktop1.3
Adding items
To add an item from the main menu, you can select one of the following
ways:
Tap and hold an item from the main menu list.•
Tap • from the tool bar and select an item.
Touch and hold an empty area from the main screen, select “• Add
widgets” from the window that opens, then tap the item you want to
add to desktop.
Removing items
Touch and hold the widget you want to remove from the desktop to
enter the edit mode, and then tap to remove it, finally tap “Done”
to confirm.
Re-organizing items
Touch and hold the widget you want to move from the desktop editing
screen until a location frame shows up, then drag it to the desired location,
finally tap “Done” to confirm.
Wallpaper
To personalize your wallpaper, you can select one of the following two
ways:
Touch and hold an empty area from the desktop, select “• Wallpaper”,
then tap a folder that displayed to select an image as your wallpaper.
Tap • from the tool bar, then tap a folder to select an image as your
wallpaper.
Toolbar1.4
Tool bar with menu items by default as a shortcut for quick access. Scrolling
left and right, you can view more items.
Getting started
2 .................
Set-up2.1
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off your
cellphone and remove battery before inserting or removing the SIM card.
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card, press
and slide it out.
Installing or removing the battery
Insert and click the battery into place, then close the cellphone cover.•
Unclip the cover, then remove the battery.•
Power on your cellphone2.2
Hold down the key until the cellphone powers on.
Power off your cellphone2.3
Hold down the key from the main screen.
Using the touchscreen2.4
Tap To access an application, tap it with your finger.
Drag Place your finger on the screen to drag the object to the
destination.
Scroll Slide the screen to scroll up and down the applications, images,
web pages... at your convenience.
Making a call
3 ......................
Enter the desired number on the on-screen keypad directly or select a
contact from Call log or Directory by tapping or respectively, then
tap or press key to place the call. The number you entered can be
saved to Directory by selecting . If you make a mistake, you can delete
the incorrect digits by tapping .
To hang up the call, press the key.
Menu arrange
4 ............
The main menu is designed to vary according to your preference. To access
this function, select to enter the main menu, then tap .
Change the order
Access “Menu arrange”, focus on the main menu item you want to move,
and then tap “Options\Move”, it will go to the main menu screen and tick
“√” will be shown on the main menu you selected, then release it to your
favourite destination.
Show/Hide
Access “Menu arrange”, tap the left check box of the selected menu once
to show/hide, then tap “Options\Save” to save the operation.
Restore default
From main menu, select “Menu arrange”, then tap “Options\Restore
default settings” to return to the default menu display.
Messages
5 ..................
Conversational On (Off) mode5.1
In conversational on mode, you can view chat history in chronological order.
In conversational off mode, you may have access to the following folders:
Inbox, Outbox, Sent, Broadcast SMS, Voicemail, Drafts, etc. You can
switch between these two modes by selecting “Settings\Conversational
mode\On (Off)”. Conversational mode is set as the default mode and
following instructions are based on this mode.
Create message5.2
Select “Messages\Write msg” to create text/multimedia message. An SMS
will be converted to MMS automatically when: images, videos, audio, slides
or attachments are inserted; Subject, CC/BCC/email address is added; or the
message contains more than 8 pages of text.
Timer send
Schedule a SMS/MMS to be sent out at predefined time (“Option\Timer
send”).
Email
6 ..........................
Your cellphone has an email client with the settings predefined for a few
popular email services like – GoogleMail, Yahoo, AOL, etc. Besides this, you
can set up other POP3 or IMAP4 email accounts that you may be using.
Palringo
7 (1) ....................
Palringo Instant messaging (IM) allows you to chat with other people using
Palringo account. You can also connect to other popular IM services through
Palringo, like Yahoo, AIM, GG, ICQ, GTalk, iChat etc. Please note that the
services accessible to you will depend on your client version and dynamic
Palringo server options.
Directory
8 ..................
Consulting your directory8.1
To access the Directory, tap from tool bar on main screen, or select
“Directory” from main menu.
Adding a contact8.2
You can add a new contact by tapping .
Birthday reminder
You can set a birthday reminder when editing contact information. This will
remind you at regular intervals during the day prior to the set date.
Call log
9 .......................
Access9.1
You may access this function from the main menu “Call log” or by pressing
from the main screen.
Available options9.2
When you tap , you may have access to Delete, Send message, Save
to directory, Edit before call, etc.
Billing9.2.1 (1)
You can access different items with this option: Last call cost, Total cost,
Max cost, Reset cost, Price per unit, Duration, GPRS counter,
Beep duration.
Call settings 9.2.2 (1)
You can access a number of items with this option: Call waiting, Call
forwarding, Call barring, Caller ID, Line switching, Auto redial, etc.
Media applications
10 .......
Music10.1 ..................................................
To access this function, tap to enter the main menu and select . You
will have full flexibility of managing music both on your cellphone and
memory card.
Image10.2 ...............................................
A library links to the images in “My creations” in cellphone to be shown in
list, slide, or thumbnail, set as Wallpaper, Power on/off display, and Contact
ID, or sent by MMS, Email, Bluetooth.
Video10.3 ..................................................
“My videos” album contains video clips recorded, received or downloaded.
All video clips in this folder can be played, set as Power on/off display, sent,
deleted, renamed, sorted.
Radio10.4 ..................................................
Your cellphone is equipped with a radio (1) with RDS functionality. You can
use the application as a traditional radio with saved channels or with parallel
visual information related to the radio program on the display if you tune
to stations that offer Visual Radio service. You can listen to it while running
other applications.
Internet
11 (2) ......................
My friends11.1 ..........................................
It migrates self-contained sub-trees of the websites to let you stay in touch
with your friends by flicking through Bebo, Friendster, Hi5, Myspace, etc.
Opera11.2 ..................................................
Not only does Opera Mini give you the full Web experience where you stay
in touch with your friends, obtain information, do your online banking etc.,
but it is also designed to save time by using compressed web pages.
Wap11.3 ...................................................
Access Wap options: Homepage, Bookmarks, Go to URL, Last web
address, Recent pages, Offline pages, Service inbox, Settings.
News11.4 ...................................................
It is a huge time saver providing news updates from a website in a simple
form. Once subscribed to a channel, it gives you the ability to track and
manage all your favourite RSS content on your cellphone at anytime,
anywhere!
Weather11.5 ............................................
Your cellphone is equipped with a weather function for consulting up to
3-day forecasts of favourite cities.
Facebook11.6 ............................................
Facebook is a social utility that connects people with friends and others
who work, study and live around them. It provides a number of features
with which users may interact: Wall, a space on every user's profile page
that allows friends to post messages for the user to see; Pokes, which allow
users to send a virtual “poke” to each other; Gifts, a feature allowing users
to send virtual gifts which appear on the recipient’s profile; Market places,
which lets users post free classified goods, etc.
To open an account online, please go to: http://www.facebook.com/.
mTweet11.7 ..............................................
Twitter is a social networking and microblogging service that has gained
notability and popularity worldwide. This feature enables cellphone users to
exchange news updates and ideas with a community in the form of messages
or posts. Posts are displayed on the author's profile page and delivered to
the author's subscribers or followers.
To open an account online, please go to: http://twitter.com/.
Entertainment
12 ..............
Stopwatch12.1 ..........................................
The stopwatch is a simple application for measuring time with the possibility
to register several results and suspend/resume measurement.
Ebook12.2 ..................................................
A bookshelf contains the electronic books (.txt and .pdb file only). While
reading the book, you may add bookmark, or reach the text by searching
words, phrases (Options\Find, Options\Jump to).
Java12.3 ......................................................
Your Alcatel cellphone may include (1) some Java™ applications and games.
You can also download new applications and games to your cellphone.
Camera
13 .................
Your cellphone is fitted with a camera for taking photos and shooting videos
that you can use in different ways:
store them in your “• File manager\My creations”.
send them in a multimedia message (MMS) to a cellphone or an email •
address.
send them directly by Email or Bluetooth.•
customize your main screen.•
select them as incoming call image to a contact in your directory.•
transfer them by data cable or microSD card to your computer.•
Profiles
14 ....................
With this menu, you may personalize ringtones for different events and
environments.
File manager
15 ..........
You will have access to all audio and visual files stored in cellphone or
memory card in File manager. You can access a number of items with this
option: My audios, My images, My videos, Ebook, My creations,
Others, Phone, Memory card and Memory status.
Inserting the memory card:
Unclip the cover and insert the MicroSD card into the slot.•
Unclip the cover and gently push the memory card until unlocked.Take •
out your MicroSD card and clip the cover closed.
Bluetooth™
16 ...........
Access this feature by tapping to enter the main menu, then selecting
“Bluetooth”.
Wi-Fi
17 .......................
To access this function, tap to enter the main menu, and select .
English - CJB31E1ALAAA
Others
18 ...........................
Calendar18.1 .............................................
Once you enter this menu from the main menu, there is a monthly-view
calendar for you to keep track of important meetings, appointments, etc.
Days with events entered will be marked in color.
Calculator18.2 ...........................................
Access this feature by selecting “Calculator” from the main menu. Enter a
number, select the type of operation to be performed, and enter the second
number, then press “=” to display the result.
Notes18.3 ...................................................
You can create a note in text or voice format by accessing “Notes” from
the main menu.
Tasks18.4 ...................................................
Enables you to easily manage and track the progress of a task with priorities.
All the tasks will be sorted by due date.
Clock18.5 ..................................................
Alarm18.5.1
Your cellphone has a built-in alarm clock with a snooze feature.
World clock18.5.2
The World clock shows current local time and the time zone in different
cities.
Clock18.5.3
Allows you to have settings of date and time, including 12/24h format.
Converter18.6 ..........................................
You can use the Weight and Length conversion by selecting the unit you
wish to convert via , then tap to input the digits. Finally confirm with
“OK”.
Answer/Send a call•
Enter Call log•
Short key press: End a call•
Lock the screen
Return to the main screen
Long key press: Power on/off•
Long key press: Access your voicemail•
Press once: Input a capitalized character•
Press twice: Lock the keyboard in capital letter input mode•
Short key press: Press once: Input a top-half character•
Press twice: Lock the keyboard in top-half
key input mode
Fn + B: Access Bluetooth•
Fn+ M: Access Music player•
Fn + P: Access Profiles•
Fn + J: Access Java applications•
/Press to go left and right•
Short key press: Enter a space•
Long key press: Access language list•
Hold down Fn key, then press space key to select input •
method
Enter a dot•
Hold down Fn key, then press sym key to enter symbol table•
Confirm an option•
Enter the next line•
Vibration alert•
Volume up/down•
Scroll up/down•
Press to enter Wi-Fi function•
(1) Depending on your network operator.
(1) The icons and illustrations in this guide are provided for information purposes
only.
(1) Depending on your network operator. (1) Contact your network operator to check service availability.
(1) The quality of the radio depends on the coverage of the radio station in that
particular area.
(2) Depending on your network operator. May cause additional network charges
for data flow to provide this service. Extra fees might also be charged in
roaming states. (1) Depending on your network operator.
1 Information bar
2 Desktop
3 Send key
4 Voicemail key
5 Shift key
6 Fn key
7 Left/right navigation key
8 Space key
9 Tool bar
10 Status bar
11 End key
12 Vibration key
13 Delete key
14 Enter key
15 Sym key
16 Wi-Fi key
17 Micro-USB connector
18 Headset connector
19 Volume key
1
2
77
3
9
11
10
13
12
14
15
6
8
5
4
1
2
77
3
9
11
10
13
12
14
15
68
5
4
16
17
18
19
A
A
IP3223_806A_807A_QG_Eng_USA_02_100929.indd 1IP3223_806A_807A_QG_Eng_USA_02_100929.indd 1 2010-9-29 16:28:352010-9-29 16:28:35
15 16 17 18 19 20 21
22 23 24 25 26 27 28
My cellphone is frozen, can’t power on
Make sure your battery is not completely used up or damaged•
Remove your battery, remove your SIM card then reinstall them to •
power on again, if still does not work
Hold down # key and press Power on/off key for a while to reset the •
cellphone
ALL User cellphone data: contacts, photos, messages and files,
downloaded applications like Java games will be lost permanently.
How to make your battery last longer
Make sure you followed the complete charge time (minimum 3 hours)•
After a partial charge, the battery level indicator may not be exact. Wait •
for at least 20 minutes after removing the charger to obtain an exact
indication
Switch on the backlight upon request.•
Extend email auto-check interval as long as possible.•
Update news, weather information upon demand manually or set its •
auto-check interval longer.
Exit Java background-running applications if they are not being used for •
a long time.
Deactivate Bluetooth when not in use.•
Settings
19 .................
From the main menu, select the menu icon and select the function of
your choice in order to customize your cellphone: phone settings, Call
settings, Security, Network, Connectivity.
Touch settings
LCD Touch •
Calibration
To calibrate the touch screen, tap anywhere on
the screen to start calibration.
Touch Vibration• When “On”, the cellphone vibrates when the
screen is touched.
Screen lock during call
Select “On”/“Off” to activate/deactivate screen lock during call.
Making the most of
20 your cellphone ..............
PC suite
You can download software upgrade for free from the website.
Webcam
You can use your cellphone as a webcam for instant messaging on your
PC.
Latin input mode
21 .........
There are two text entry methods that can be used to write messages
Normal: this mode allows you to type a text by choosing a letter or a •
sequence of characters associated with a key.
TouchPal mode: This mode can perform predictive input on both hardware •
keypad and on-screen soft keypad, and supports multi-languages input.
Keyboard inputting
Key: Press once: Input a capitalized character
Press twice: Lock the keyboard in capital letter input mode
Key: Press once: Input a top-half character
Press twice: Lock the keyboard in top-half key input mode
Key: Short key press: Enter a space
Long key press: Access language list
Hold down Fn key, then press space key to select input
mode
key: Short key press: Delete one by one
Long key press: Delete all
key: Confirm an option
Enter the next line
Key: Enter a dot
Hold down Fn key, then press sym key to enter symbol
table
Safety and use ...........................
We recommend that you read this chapter carefully before using your cellphone. The
manufacturer disclaims any liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle constitutes
a real risk, even when the hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their cellphone when the vehicle is not parked.
Check the laws and regulations on the use of wireless cellphones and their
accessories in the areas where you drive. Always obey them. The use of these devices
may be prohibited or restricted in certain areas.
When driving, do not use your cellphone and headphone to listen to music or to the
radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your cellphone emits electromagnetic waves that can interfere
with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To
ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its
performance.
Remember to abide by local authority rules of cellphone use on aircrafts.
Switch the cellphone off when you are in health care facilities, except in designated areas.
As with many other types of equipment now in regular use, cellphones can interfere with
other electrical or electronic devices, or equipment using radio frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly obey all
signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any
potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump. In particular
when using the cellphone you should hold it against the ear on the opposite side
to the device, if any.
To avoid hearing impairment, answer the call before holding your cellphone to your
ear. Also move the handset away from your ear while using the “hands-free” option
because the amplified volume might cause hearing damage.
It is recommended to have proper supervision while small children use your cellphone.
When replacing the cover please note that your cellphone may contain substances
that could create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free place.
Do not allow your cellphone to be exposed to adverse weather or environmental
• Damage from exposure to water or other liquids, moisture, humidity,
excessive temperatures or extreme environmental conditions, sand,
excess dust and any condition outside the operating guidelines;
• Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your jurisdiction. In no event shall TCT Mobile or any
of its affiliates be liable for incidental or consequential damages of any
nature whatsoever, including but not limited to commercial loss, to the
full extent those damages can be disclaimed by law. Some states do not
allow the exclusion or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties, so the preceding
limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer care center by calling
(877-702-3444) or going to www.alcatel-mobilephones.com. We have
placed many self-help tools that may help you to isolate the problem
and eliminate the need to send your wireless device in for service. In
the case that your wireless device is no longer covered by this limited
warranty due to time or condition we have other options that you may
utilize our out of warranty repair options.
To obtain hardware repairs or replacement within the terms of this
warranty, contact TCT Mobile to get an RMA number, include a copy
of the original proof of warranty coverage (e.g. original copy of the
dated bill of sale, invoice), the consumer's return address, your wireless
carrier’s name, alternate daytime phone number, and email address
with a complete problem description. Only ship the wireless device.
Do not ship the SIM card, memory cards, or any other accessories
such as the power adapter. You must properly package and ship the
wireless device
to the repair center. TCT Mobile is not responsible for wireless devices
that do not arrive at the service center. Upon receipt, the service
center will verify the warranty conditions, repair, and return your
wireless device to the address provided.
Alcatel Mobile Phones
Limited Warranty ................
TCT Mobile North America LTD warrants to the original retail
purchaser of this wireless device, that should this product or part
thereof during normal consumer usage and condition, be proven to
be defective in material or workmanship that results in product failure
within the first twelve (12) months from the date of purchase as shown
on your original sales receipt. Such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the company’s option without charge for
parts or labor directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box items
are also warranted against defects and workmanship that results in
product failure within the first six (6) months period from the date
of purchase as shown on your original sales receipt. Such defect(s)
will be repaired or replaced (with new or rebuilt parts) and the
company’s option without charge for parts or labor directly related
to the defect(s).
The limited warranty for your wireless device will be voided if any of
the following conditions occur:
• Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area
where your phone is used;
• Connection to any equipment not supplied or not recommended by
TCT Mobile;
• Modification or repair performed by individuals not authorized by
TCT Mobile or its affiliates;
• Acts of god such as Inclement weather, lightning, power surges, fire,
humidity, infiltration of liquids or foods, chemical products, download
of files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless devices event labels or serial
numbers (IMEI);
Java™ and all Java™ based trademarks and logos are
trademarks or registered trademarks of Sun Microsystems,
Inc. in the U.S. and other countries.
is a registered trademark of Opera Mini.
Facebook and the f Logo are trademarks of Facebook,
Inc., and are used under license.
Twitter and the T Logo are trademarks of Twitter, Inc.,
and are used under license.
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.
Hearing Aid Compatibility
Your cellphone is rated: "For Hearing Aid", to assist hearing device users in
finding cellphones that may be compatible with their hearing devices.
This device is HAC M3 compatible.
For more information please refer to "Hearing Aid Compatibility with Mobile
Phones" leaflet or visit our website http://www.alcatel-mobilephones.com/
General information ............
• Website: www.alcatel-mobilephones.com
• Facebook: http://www.facebook.com/alcatelonetouchtribe
• Twitter: http://www.twitter.com/Alcateltribeus
• Hot Line Number: In the United States, call 877-702-3444 for technical
support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other languages
according to availability on our server: www.alcatel-mobilephones.com
Your cellphone is a transceiver that operates on GSM networks with 850
and 1900 MHz bands.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number) shown
on the packaging label and in the product’s memory. We recommend that
you note the number the first time you use your cellphone by entering
*#06# and keep it in a safe place. It may be requested by the police or your
operator if your cellphone is stolen.
Disclaimer
There may be certain differences between the user manual description
and the cellphone’s operation, depending on the software release of your
cellphone or specific operator services.
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The
manufacturer’s recommended operating temperature range is -10°C to +55°C (the
max value depends on device, materials and housing paint/texture).
Over 55°C the legibility of the cellphone’s display may be impaired, though this is
temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your cellphone model.
TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the
use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check local
regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing
lights, or when playing video games. These seizures or blackouts may occur even
if a person never had a previous seizure or blackout. If you have experienced
seizures or blackouts, or if you have a family history of such occurrences, please
consult your doctor before playing video games on your cellphone or enabling a
flashing-lights feature on your cellphone. Parents should monitor their children’s use
of video games or other features that incorporate flashing lights on the cellphones.
All persons should discontinue use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms, please take
the following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional discomfort
in your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest
for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop
the game and see a doctor.
Prolonged exposure to music at full volume using the music player may damage
your hearing. Set your cellphone’s volume to it’s lowest setting prior to inserting
headphones in your ears and adjust the volume to your preference. Only use
headphones that are recommended by TCT Mobile Limited and it’s affiliates.
Troubleshooting .......................
Before contacting the aftersales department, you are advised to follow the
instructions below:
You are advised to switch off the cellphone from time to time to •
optimize its performance.
You are advised to fully charge (• ) the battery for optimal operation.
Avoid storing large amounts of data in your cellphone as this may affect •
the performance of your cellphone.
and carry out the following checks:
My cellphone will not switch on
Press• until the screen comes on
Check the battery charge level•
Check the battery contacts, remove and reinstall your battery, then turn •
your cellphone back on
My cellphone has not responded for several minutes
Press the• key
Remove the battery and re-insert it, then switch the cellphone back on•
My screen is difficult to read
Clean your screen•
Use your cellphone in accordance with the recommended conditions •
of use
My cellphone turns off by itself
Check that your keypad is locked when you are not using your cellphone•
Check the battery charge level•
My cellphone will not charge properly
Make sure that your battery is not completely discharged; the battery •
charge indicator can take several minutes and may be accompanied by a
quiet whistling sound
Make sure charging is carried out under normal conditions (0°C +40°C)•
Make sure your battery is inserted. It must be inserted before plugging •
in the charger
Make sure you are using an Alcatel battery and charger in the box•
When abroad, check that the electrical current is compatible•
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your cellphone regarding
taking photographs and recording sounds with your cellphone. Pursuant to such laws
and regulations, it may be strictly forbidden to take photographs and/or to record
the voices of other people or any of their personal attributes, and reproduce or
distribute them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained,
if necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
cellphone (including the operator) disclaim any liability which may result from the
improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental
regulations. Only use the battery for the purpose for which it was designed. Never
use damaged batteries or those not recommended by TCT Mobile Limited and/
or its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at
the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign must
be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead they
are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
My cellphone will not connect to a network
Try connecting in another location•
Verify the network coverage with your operator•
Check with your operator that your SIM card is valid•
Try selecting the available network(s) manually•
Try connecting at a later time if the network is overloaded•
SIM card error
Make sure the SIM card has been correctly inserted•
Verify with your operator that your SIM card is 3V or 1,8V compatible; •
the old 5V SIM cards cannot be used
Make sure the chip on your SIM card is not damaged or scratched•
Unable to make outgoing calls
Make sure you have dialled a valid number and press the • key
For international calls, check the country and area codes•
Make sure your cellphone is connected to a network, and that the •
network is not overloaded or unavailable
Check your subscription status with your operator (credit, SIM card •
valid, etc.)
Make sure you have not barred outgoing calls•
Unable to receive incoming calls
Make sure your cellphone is switched on and connected to a network •
(check for overloaded or unavailable network)
Check your subscription status with your operator (credit, SIM card •
valid, etc.)
Make sure you have not forwarded incoming calls•
Make sure that you have not barred certain calls•
The caller’s name does not appear when a call is received
Check that you have subscribed to this service with your operator•
Your caller has concealed his/her number•
The sound quality of the calls is not optimal
You can adjust the volume during a call by means of the Volume key•
Check the network strength •
I am unable to use the features described in the manual
Check with your operator to make sure that your subscription includes •
this service
Make sure this feature does not require an Alcatel accessory•
When I select a number from my directory, the number is not
dialled
Make sure that you have correctly recorded the number in your file•
Make sure that you have selected the country prefix when calling a •
foreign country
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C
to 40°C.
The chargers designed for your cellphone meet with the standard for safety of
information technology equipment and office equipment use. Due to different
applicable electrical specifications, a charger you purchased in one jurisdiction may
not work in another jurisdiction. They should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 350/400 mA
Battery: Lithium 850 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to radio-frequency (RF) energy.
These limits are part of comprehensive guidelines and establish permitted levels
of RF energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. These guidelines include a substantial safety
margin designed to ensure the safety of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such
as the Federal Communications Commission of the US Government (FCC), or by
Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are
conducted using standard operating positions with the cellphone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR
level of the cellphone while operating can be well below the maximum value. This
is because the cellphone is designed to operate at multiple power levels so as to
use only the power required to reach the network. In general, the closer you are
to a wireless base station antenna, the lower the power output of the cellphone
Before a cellphone model is available for sale to the public, compliance with national
regulations and standards must be shown.
The highest SAR value for this model cellphone when tested is 0.636 W/Kg for use
at the ear and 1.17 W/Kg for use close to the body.
While there may be differences between the SAR levels of various cellphones and
at various positions, they all meet the government requirement for RF exposure.
For body-worn operation, the cellphone meets FCC RF exposure guidelines
provided that it is used with a non-metallic accessory with the handset at least 1.5
cm from the body. Use of other accessories may not ensure compliance with FCC
RF exposure guidelines.
The World Health Organization (WHO) considers that present scientific information
does not indicate the need for any special precautions for use of cellphones. If
individuals are concerned, they might choose to limit their own or their children’s
RF exposure by limiting the length of calls, or using “hands-free” devices to keep
cellphones away from the head and body. (fact sheet n°193). Additional WHO
information about electromagnetic fields and public health are available on the
following website: http://www.who.int/peh-emf.
I am unable to add a contact in my directory
Make sure that your SIM card directory is not full; delete some contacts •
or save the contacts in the cellphone directory (i.e. your professional or
personal directories)
My callers are unable to leave messages on my voicemail
Contact your network operator to check service availability•
I cannot access my voicemail
Make sure your operator’s voicemail number is correctly entered in •
“My numbers”
Try later if the network is busy•
I am unable to send and receive MMS
Check your cellphone memory available as it might be full•
Contact your network operator to check service availability and check •
MMS parameters
Verify the server center number or your MMS profile with your operator•
The server center may be swamped; try again later•
The red icon is displayed on my standby screen
You have saved too many short messages on your SIM card; delete some •
of them or archive them in the cellphone memory
“No service” is displayed
You are outside of the network coverage area•
I have already entered 3 incorrect PIN codes
Contact your network operator to obtain the PUK code (Personal •
Unblocking Key)
I am unable to connect my cellphone to my computer
Install first of all Alcatel’s PC suite•
Use “Install the connection” and perform the installation•
Check that your computer meets the requirements for Alcatel’s PC Suite •
installation
I am unable to download new files
Check for free space•
Delete some files•
Select the MicroSD Card to store the files you downloaded•
Check your subscription status with your operator•
The cellphone can’t be detected by others via Bluetooth
Make sure that Bluetooth is turned on and your cellphone is visible to •
other users
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service
(e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you should
avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other
than against your ear. In such circumstances the device will be compliant with the
guidelines when used with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any metal and that it
positions the cellphone at least 2cm away from the body.
LICENCES •
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by TCT
Mobile Limited and its affiliates is under license. Other
trademarks and trade names are those of their respective
owners.
OT-806A/OT-807A Bluetooth QD ID B016239
TouchPal™ and CooTek™ are trademarks of Shanghai
HanXiang (CooTek) Information Technology Co., Ltd. and/
or its Affiliates.
Prolonged exposure to music at full volume on the music player may
damage the listener's hearing. Set your cellphone volume safely. Use
only headphones recommended by TCT Mobile Limited and its
affiliates.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
© Copyright 2010 TCT Mobile Limited
All rights reserved
TCT Mobile Limited reserves
the right to alter material
or technical specification
without prior notice.
(1) Contact your network operator for service availability.
IP3223_806A_807A_QG_Eng_USA_02_100929.indd 2IP3223_806A_807A_QG_Eng_USA_02_100929.indd 2 2010-9-29 16:28:372010-9-29 16:28:37
