TCT Mobile 160 GSM/GPRS Dual-band mobile phone User Manual IP3465 506A QG Eng USA 07 110420 indd
TCT Mobile Limited GSM/GPRS Dual-band mobile phone IP3465 506A QG Eng USA 07 110420 indd
one touch 506A_UM rev1
1
9
2
10
3
11
4
12
5
13
6
14
7
15
8
16
1 Your cellphone .........
1.1 Keys
Navigation key
Confirm an option (press the middle of the key)
Activate music player (long press the middle of key)
Scroll widget bar (press the right or left of the key)
Answer
Send a call
In idle screen:
Access call log (Redial) (press)
Activate fake call (press n hold)
During MP3 Playing:
Switch between Headset and speaker (press n
hold)
Switch on/Switch off the cellphone (press n hold)
End call
Return to idle screen
Left softkey
Right softkey
Access your voicemail (press n hold)
In Edit mode:
- Press: access the language list
- Press n hold: enter zero
In Edit mode:
- Press: change input methods
- Press n hold: access the Symbols table
In idle screen:
- Press: #
- Press n hold: activate/deactivate the vibrate mode
In Edit mode:
- Press: (space)
Camera key: access "Camera" (press)
1.2 Main screen icons (1)
Battery charge level
Vibrate alert: your cellphone vibrates, but does not ring
or beep.
Bluetooth status (Activated).
Bluetooth status (Connected to an audio device).
Headset connected.
Keypad locked.
Call forwarding activated: your calls are forwarded.
2 Getting started .........
2.1 Set-up
Removing and installing the back cover
Removing and installing the battery
Inserting and removing the SIM card
Place the SIM card with the chip facing downwards and slide it
into its housing. Make sure that it is correctly inserted. To
remove the card, press it and slide it out.
Charging the battery
Connect the battery charger to your cellphone and mains socket
respectively.
The charging may take about 20 minutes to start if the •
battery is flat.
Be careful not to force the plug into the socket.•
Make sure the battery is correctly inserted before •
connecting the charger.
The mains socket must be near to the cellphone and easily •
accessible (avoid electric extension cables).
When using your cellphone for the first time, charge the •
battery fully (approximately 3 hours). You are advised to
fully charge the battery ( ).
To reduce power consumption and energy waste, when •
battery is fully charged, disconnect your charger from the
plug; switch off Bluetooth when not in use; reduce the
backlight time, etc.
The charge is complete when the animation stops.
2.2 Power on your cellphone
Hold down the key until the cellphone powers on.
2.3 Power off your cellphone
Hold down the key from the main screen.
6 Email ....................
Your cellphone has an email client with the settings predefined
for a few popular email services like – GoogleMail, Windows
live, Yahoo, AOL, etc. Besides this, you can set up other POP3
or IMAP4 email accounts that you may be using.
7 Opera Mini ..........
Not only does Opera Mini give you the full Web experience
where you stay in touch with your friends, obtain information,
do your online banking etc., but it is also designed to save time
by using compressed web pages.
8 Facebook .............
Facebook is a social utility that connects people with friends and
others who work, study and live around them. It provides a
number of features with which users interact, such as Wall,
Pokes, etc.
To open an account online, please go to: http://www.facebook.
com/.
Quick Start Guide
For more information about how to use the cellphone, please
go to www.alcatelonetouch.com to download complete user
manual (English version only). Moreover, from the website
you can also consult FAQ (English version only).
Prolonged exposure to music at full volume on the
music player may damage the listener's hearing. Set
your cellphone volume safely. Use only headphones
recommended by TCT Mobile Limited and its affiliates.
(1) Depending on your network operator.
(1) The icons and illustrations in this guide are provided for information
purposes only.
4 Contacts .............
4.1 Consulting your contacts
To access the contacts from the main screen, press the
key and select the icon from the menu.
4.2 Adding a contact
Select the directory in which you wish to add contact, press
the "Options" softkey, select "Add contact".
5 Messaging ...........
5.1 Create message
From the main menu select "Messaging" to create text/
multimedia message. You can type a message and you can also
modify a predefined message in Templates or customize
your message by adding pictures, photos, sounds, titles, etc
(only available while editing a MMS). While writing a message,
select "Options" to access all the messaging options. You can
save your messages that you send often to Draft or
Templates (MMS only).
Specific letters (accent) will increase the size of the
SMS, this may cause multiple SMS to be sent to
your recipient.
Alarm or appointments programmed.
Level of network reception.
Voicemail message arrived.
Missed calls.
Radio is on.
WAP alerts (1).
Roaming.
SIM card missing.
GPRS connection status (Activated).
GPRS connecting.
Sending a MMS.
MMS receiving.
Silence mode: your cellphone does not ring, beep or
vibrate with the exception of the alarm.
SMS unread.
MMS unread.
Flight mode.
(1) Depending on your network operator.
9 mTweet ................
Twitter is a social networking and microblogging service that has
gained notability and popularity worldwide. This feature enables
cellphone users to exchange news updates and ideas with a
community in the form of messages or posts. Posts are displayed
on the author's profile page and delivered to the author's
subscribers or followers.
To open an account online, please go to: http://twitter.com/.
10 Camera .............
Your cellphone is fitted with a camera for taking photos and
shooting videos that you can use in different ways:
store them in your “• File manager\My creations”.
send them in a multimedia message (MMS) to a cellphone or •
an email address.
send them directly by Email or Bluetooth.•
customize your main screen.•
select them as incoming call image to a contact in your •
directory.
11 Media .................
11.1 Music
Access this feature from the main menu by selecting “Music”.
You will have full flexibility of managing music both on your
cellphone and memory card.
11.2 Video
“My videos” album contains video clips recorded, received or
downloaded.
11.3 Radio
Your cellphone is equipped with a radio (1) with RDS functionality.
You can use the application as a traditional radio with saved
channels or with parallel visual information related to the radio
program on the display if you tune to stations that offer Visual
Radio service. You can listen to it while running other
applications.
12 My friends............
It migrates self-contained sub-trees of the websites to let you
stay in touch with your friends by flicking through Friendster,
Hi5, etc.
13 Settings ...............
From the main menu, select the menu icon and select the
function of your choice in order to customize your cellphone:
Phone settings, Call settings, Security, Network,
Connectivity.
14 Call log ................
You can access your call memory by pressing from the idle
screen, and you will see Outgoing call(s), Missed call(s) and
Answered call(s).
15 Tools ....................
15.1 Calendar
Once you enter this menu from the main menu, there is a
monthly-view calendar for you to keep track of important
meetings, appointments, etc. Days with events entered will be
marked in color.
15.2 Alarm
Your cellphone has a built-in alarm clock with a snooze feature.
15.3 Fake call
This program enables you to call yourself by simulating a caller
number/name, ringtone, contact photo at a scheduled time. It
helps you to politely escape from social situations at any time
you wish. This call can be rejected by key.
Settings Predefined settings of Caller name/number, •
Call time, Ringtone, Image (Contact photo).
Activate Activate a fake call by "• Tools\Fake call\
Activate" or by a long press of the key
on the main screen. The call will then be made
at the predetermined time.
15.4 Notes
You can create a note in text or voice format by accessing
“Notes” from the main menu.
15.5 Calculator
Enter a number, select the type of operation to be performed,
and enter the second number, then press “=” to display the
result.
15.6 File manager
You will have access to all audio and visual files stored in
cellphone or memory card in File manager. You can access a
number of items with this option: My audios, My images, My
videos, My creations, Other files, Phone, Memory card
and Memory status.
(1) The quality of the radio depends on the coverage of the radio station in
that particular area.
Voicemail
(press n hold)
Switch on/
Switch off
End call
Left softkey
Answer/Send call
Call log
Activate fake call
(press n hold)
Navigation key (1):
Menu/Confirm an
option
if widget bar is
hide:
Messaging
Contacts
Alarm
Calendar
Vibration alert
(press n hold)
Camera
Lock/Unlock
keypad
Right softkey
Inserting the memory card:
To release the microSD card holder, slide it in the direction of
the arrow and lift it. Then insert the microSD card with the
golden contact downward. Finally, turn down the microSD
holder and slide it in the opposite direction to lock it.
15.7 World clock
The World clock shows current local time and the time zone in
different cities.
15.8 Converter
Unit converter and Currency converter.
15.9 Stopwatch
The stopwatch is a simple application for measuring time with
the possibility to register several results and suspend/resume
measurement.
16 Java ..................
Your Alcatel cellphone may include
(1) some Java™ applications
and games. You can also download new applications and games
to your cellphone.
(1) Depending on your network operator.
3 Calls ..........................
3.1 Making a call
Dial the desired number then press the key to place the
call. If you make a mistake, you can delete the incorrect digits
by pressing the right softkey.
To hang up the call, press the key.
Making an emergency call
If your cellphone is covered by the network, dial emergency
number and press the key to make an emergency call.
This works even without a SIM card and without typing the
PIN code or unlocking the keypad.
3.2 Calling your voicemail (1)
To access your voicemail, hold down the key.
3.3 Receiving a call
When you receive an incoming call, press the key to talk
and then hang up using the key.
3.4 Available functions during the call
During a call, you can use your directory, your calendar, short
messages, etc. without losing your correspondent.
(1) Contact your network operator to check service availability.
English - CJB22B1ALAAA
16.1 Java applications
Select “Java applications” to launch applications.
16.2 Java settings
This menu allows you to manage Java settings, in which you
may set Audio, Backlight, Vibration and Heap size.
16.3 Java network
This menu allows you to select the network for Java.
16.4 Trusted certificates
View detailed information of the trusted certificates supported
by your cellphone.
17 Applications .....
17.1 WAP
Access Wap options: Homepage, Bookmarks, Recent
pages, Offline pages, Go to URL, Service inbox,
Settings.
17.2 Bluetooth™
Access this feature by pressing to enter the main menu,
then selecting “Applications\Bluetooth”.
17.3 Local games
Your Alcatel cellphone may include some games.
IP3465_506A_QG_Eng_USA_07_110420.indd 1IP3465_506A_QG_Eng_USA_07_110420.indd 1 2011-4-20 14:36:542011-4-20 14:36:54
17
25
18
26
19
27
20
28
21
29
22
30
23
31
24
32
Troubleshooting ...............
Before contacting the aftersales department, you are advised to
follow the instructions below:
You are advised to switch off the cellphone from time to •
time to optimize its performance.
You are advised to fully charge ( • )
the battery for
optimal operation.
Avoid storing large amounts of data in your cellphone as •
this may affect the performance of your cellphone.
and carry out the following checks:
My cellphone will not switch on
Press • until the screen comes on
Check the battery charge level•
Check the battery contacts, remove and reinstall your •
battery, then turn your cellphone back on
My cellphone has not responded for several minutes
Press the • key
Remove the battery and re-insert it, then switch the •
cellphone back on
My screen is difficult to read
Clean your screen•
Use your cellphone in accordance with the recommended •
conditions of use
My cellphone turns off by itself
Check that your keypad is locked when you are not using •
your cellphone
Check the battery charge level•
My cellphone has a low level of autonomy
Make sure you respected the complete charge timing •
(minimum 3 hours)
After a partial charge, the battery level indicator may not be •
exact. Wait for at least 20 minutes after removing the
charger to obtain an exact indication
My cellphone will not charge properly
Make sure that your battery is not completely discharged; If •
the battery is flat, it may take around 20 minutes to display
the battery charger indicator on the screen
Make sure charging is carried out under normal conditions •
(0°C - +40°C)
Make sure your battery is inserted. It must be inserted •
before plugging in the charger
Make sure you are using an Alcatel battery and charger in •
the box
When abroad, check that the electrical current is •
compatible
My cellphone will not connect to a network
Try connecting in another location•
Verify the network coverage with your operator•
Check with your operator that your SIM card is valid•
Try selecting the available network(s) manually•
Try connecting at a later time if the network is overloaded•
SIM card error
Make sure the SIM card has been correctly inserted•
Verify with your operator that your SIM card is 3V or 1.8V •
compatible; the old 5V SIM cards cannot be used
Make sure the chip on your SIM card is not damaged or •
scratched
Unable to make outgoing calls
Make sure you have dialled a valid number and press the•
key
For international calls, check the country and area codes•
Make sure your cellphone is connected to a network, and •
that the network is not overloaded or unavailable
Check your subscription status with your operator (credit, •
SIM card valid, etc.)
Make sure you have not barred outgoing calls•
Unable to receive incoming calls
Make sure your cellphone is switched on and connected to •
a network (check for overloaded or unavailable network)
Check your subscription status with your operator (credit, •
SIM card valid, etc.)
Make sure you have not forwarded incoming calls•
Make sure that you have not barred certain calls•
The caller's name does not appear when a call is
received
Check that you have subscribed to this service with your •
operator
Your caller has concealed his/her number•
The sound quality of the calls is not optimal
You can adjust the volume during a call by means of the •
key
Check the network strength •
I am unable to use the features described in the manual
Check with your operator to make sure that your •
subscription includes this service
Make sure this feature does not require an Alcatel •
accessory
When I select a number from my directory, the number
is not dialled
Make sure that you have correctly recorded the number in •
your file
Make sure that you have selected the country prefix when •
calling a foreign country
I am unable to add contact in my directory
Make sure that your SIM card directory is not full; delete •
some files or save the files in the product directory (i.e.
your professional or personal directories)
My callers are unable to leave messages on my
voicemail
Contact your network operator to check service availability•
I cannot access my voicemail
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio
service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions
other than against your ear. In such circumstances the device will be compliant
with the guidelines when used with headset or usb data cable. If you are using
another accessory ensure that whatever product is used is free of any metal
and that it positions the cellphone at least 1.5 cm away from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
by TCT Mobile Limited and its affiliates is under
license. Other trademarks and trade names are
those of their respective owners.
one touch 506A Bluetooth
QD ID B016876
eZiText™ and Zi™ are trademarks of Zi
Corporation and/or its Affiliates.
Java™ and all Java™ based trademarks and logos
are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
is a registered trademark of Opera Mini.
Facebook and the f Logo are trademarks of
Facebook, Inc., and are used under license.
Make sure your operator's voicemail number is correctly •
entered in "My number"
Try later if the network is busy•
I am unable to send and receive MMS
Check your cellphone memory available as it might be full•
Contact your network operator to check service availability •
and check MMS parameters
Verify the server center number or your MMS profile with •
your operator
The server center may be saturated; try again later•
The icon is displayed on my standby screen
You have saved too many short messages on your SIM card; •
delete some of them or archive them in the product
memory
"No service" is displayed
You are outside of the network coverage area•
I have already entered 3 incorrect PIN codes
Contact your network operator to obtain the PUK code •
(Personal Unblocking Key)
I am unable to download new files
Check for free space•
Delete some files•
Check your subscription status with your operator•
My cellphone is frozen, can't power on
Make sure your battery is not completely used up or •
damaged
Remove your battery, remove your SIM card then reinstall •
them to power on again, if still does not work
Hold down # key and press Power on/off key for a while to •
reset the cellphone
ALL User cellphone data: contacts, photos, messages
and files, downloaded applications like Java games will
be lost permanently.
17.4 News
It is a huge time saver providing news updates from a website
in a simple form. Once subscribed to a channel, it gives you
the ability to track and manage all your favourite RSS content
on your cellphone at anytime, anywhere!
17.5 Weather
Your cellphone is equipped with a weather function for
consulting up to 3-day forecasts of favourite cities.
17.6 Services
Contact your network operator to check service availability.
18 Profiles .............
With this menu, you may personalize ringtones for different
events and environments.
19 Latin input mode ..
To write messages, there are two writing methods:
Normal: this mode allows you to type a text by choosing •
a letter or a sequence of characters associated with a
key.
Predictive with the eZi mode: this mode speeds up the •
writing of your text.
• key in edit mode
Press: access the language list
Press n hold: enter zero
How to make your battery last longer
Make sure you followed the complete charge time •
(minimum 3 hours).
After a partial charge, the battery level indicator may not be •
exact. Wait for at least 20 minutes after removing the
charger to obtain an exact indication.
Switch on the backlight upon request.•
Extend email auto-check interval as long as possible.•
Update news, weather info. upon demand manually or set •
its auto-check interval longer.
Exit Java background-running applications if they are not •
being used for a long time.
Deactivate Bluetooth when not in use. •
One Touch Upgrade
Using One Touch Upgrade tool you can update your cellphone’s
software from your PC.
Download One Touch Upgrade from ALCATEL website (www.
alcatelonetouch.com) and install it on your PC.Launch the tool
and update your cellphone by following the step by step
instructions (refer to the User Guide provided together with the
tool).
Your cellphone’s software will now have the latest software.
All personal information will be permanently lost
following the update process. We recommend you
backup your personal data using PC Suite before
upgrading.
Safety and use .......................
We recommend that you read this chapter carefully before using your
cellphone. The manufacturer disclaims any liability for damage, which may
result as a consequence of improper use or use contrary to the instructions
contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit, headset...),
drivers are requested to refrain from using their cellphone when the vehicle is
not parked. Check the laws and regulations on the use of wireless cellphones
and their accessories in the areas where you drive. Always obey them. The use
of these devices may be prohibited or restricted in certain areas.
When driving, do not use your cellphone and headphone to listen to music
or to the radio. Using a headphone can be dangerous and forbidden in some
areas.
When switched on, your cellphone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or
airbags. To ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize
its performance.
Remember to abide by local authority rules of cellphone use on aircrafts.
Operational Warnings: Obey all posted signs when using mobile devices in public
areas.
Follow Instructions to Avoid Interference Problems: Turn off your mobile device
in any location where posted notices instruct you to do so. In an aircraft, turn off
your mobile device whenever instructed to do so by airline staff. If your mobile
device offers an airplane mode or similar feature, consult airline staff about using
it in flight.
Switch the cellphone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, cellphones can
interfere with other electrical or electronic devices, or equipment using radio
frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly
obey all signs and instructions posted in a fuel depot, gas station, or chemical
plant, or in any potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump. In particular
when using the cellphone you should hold it against the ear on the opposite
side to the device, if any.
Read and follow the directions from the manufacturer of your implantable
medical device. If you have any questions about using your mobile device with
your implantable medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding your cellphone to
your ear. Also move the handset away from your ear while using the “hands-
free” option because the amplified volume might cause hearing damage.
It is recommended to have proper supervision while small children use your
cellphone.
When replacing the cover please note that your cellphone may contain
substances that could create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free
place.
Do not allow your cellphone to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of liquids, dust,
sea air, etc.). The manufacturer’s recommended operating temperature range
is -10°C (14°F) to +55°C (131°F) (the max value depends on device, materials
and housing paint/texture).
Over 55°C (131°F) the legibility of the cellphone’s display may be impaired,
though this is temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended
by TCT Mobile Limited and its affiliates and are compatible with your cellphone
model.TCT Mobile Limited and its affiliates disclaim any liability for damage
caused by the use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check
local regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to
flashing lights, or when playing video games. These seizures or blackouts may
occur even if a person never had a previous seizure or blackout. If you have
experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult your doctor before playing video games on your
cellphone or enabling a flashing-lights feature on your cellphone. Parents should
monitor their children’s use of video games or other features that incorporate
flashing lights on the cellphones. All persons should discontinue use and consult
a doctor if any of the following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary movements, or disorientation. To limit
the likelihood of such symptoms, please take the following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body.
Follow these instructions to avoid problems such as tendinitis, carpal tunnel
syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest
for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop
the game and see a doctor.
Prolonged exposure to music at full volume using the music player may
damage your hearing. Set your cellphone’s volume to it’s lowest setting
prior to inserting headphones in your ears and adjust the volume to your
preference. Only use headphones that are recommended by TCT Mobile
Limited and it’s affiliates.
• PRIVACY:
Please note that you must respect the laws and regulations in force in
your jurisdiction or other jurisdiction(s) where you will use your cellphone
regarding taking photographs and recording sounds with your cellphone.
Pursuant to such laws and regulations, it may be strictly forbidden to take
photographs and/or to record the voices of other people or any of their
personal attributes, and reproduce or distribute them, as this may be
considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be
obtained, if necessary, in order to record private or confidential conversations
or take a photograph of another person; the manufacturer, the seller or vendor
of your cellphone (including the operator) disclaim any liability which may
result from the improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and
burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for which
it was designed. Never use damaged batteries or those not recommended by
TCT Mobile Limited and/or its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at
the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign
must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if
your jurisdiction or your region has suitable recycling and collection facilities;
instead they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at
www.recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C
(32°F) to 40°C (104°F).
The chargers designed for your cellphone meet with the standard for safety
of information technology equipment and office equipment use. Due to
different applicable electrical specifications, a charger you purchased in one
jurisdiction may not work in another jurisdiction. They should be used for
this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100~240 V, 50~60 Hz, 150 mA
Output: 4.75~5.0 V, 350~550 mA
Battery: Lithium 650 mAh/750 mAh/850 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio-
frequency (RF) energy. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. These guidelines include a substantial safety margin designed to ensure
the safety of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities
such as the Federal Communications Commission of the US Government
(FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram of body
tissue. Tests for SAR are conducted using standard operating positions with
the cellphone transmitting at its highest certified power level in all tested
frequency bands.
Although the SAR is determined at the highest certified power level, the actual
SAR level of the cellphone while operating can be well below the maximum
value. This is because the cellphone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general,
the closer you are to a wireless base station antenna, the lower the power
output of the cellphone. Before a cellphone model is available for sale to the
public, compliance with national regulations and standards must be shown.
The highest SAR value for this model cellphone when tested is 1.02 W/Kg for
use at the ear and 0.997 W/Kg for use close to the body.
While there may be differences between the SAR levels of various cellphones
and at various positions, they all meet the government requirement for RF
exposure. For body-worn operation, the cellphone meets FCC RF exposure
guidelines provided that it is used with a non-metallic accessory with the
handset at least 1.5 cm from the body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular Telecommunications
& Internet Association (CTIA) Web site: http://www.phonefacts.net
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for use of
cellphones. If individuals are concerned, they might choose to limit their own or
their children’s RF exposure by limiting the length of calls, or using “hands-free”
devices to keep cellphones away from the head and body. (fact sheet n°193).
Additional WHO information about electromagnetic fields and public health
are available on the following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
ALCATEL is a trademark of
Alcatel-Lucent and used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2011
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior
notice.
Hearing Aid Compatibility
Your cellphone is rated: "For Hearing Aid", to assist hearing device users in
finding cellphones that may be compatible with their hearing devices.
This device is HAC M3 & T3 compatible.
For more information please refer to "Hearing Aid Compatibility with
Mobile Phones" leaflet or visit our website http://www.alcatelonetouch.
com
General information .......
• Website: www.alcatelonetouch.com
• Facebook: http://www.facebook.com/alcatelonetouchtribe
• Twitter: http://www.twitter.com/Alcateltribeus
• Hot Line Number: In the United States, call 877-702-3444 for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked
Questions) section. You can also contact us by e-mail to ask any
questions you may have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.
com
Your cellphone is a transceiver that operates on GSM networks with
850 and 1900 MHz bands.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number)
shown on the packaging label and in the product’s memory. We
recommend that you note the number the first time you use your
cellphone by entering *#06# and keep it in a safe place. It may
be requested by the police or your operator if your cellphone is
stolen.
Disclaimer
There may be certain differences between the user manual description
and the cellphone’s operation, depending on the software release of
your cellphone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences,
if any, nor for their potential consequences, which responsibility shall
be borne by the operator exclusively.
(1) Contact your network operator for service availability.
Alcatel Mobile Phones
Limited Warranty ..........
TCT Mobile North America LTD warrants to the original retail
purchaser of this wireless device, that should this product or
part thereof during normal consumer usage and condition, be
proven to be defective in material or workmanship that results
in product failure within the first twelve (12) months from the
date of purchase as shown on your original sales receipt. Such
defect(s) will be repaired or replaced (with new or rebuilt parts)
at the company’s option without charge for parts or labor
directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box
items are also warranted against defects and workmanship that
results in product failure within the first six (6) months period
from the date of purchase as shown on your original sales
receipt. Such defect(s) will be repaired or replaced (with new or
rebuilt parts) and the company’s option without charge for parts
or labor directly related to the defect(s).
The limited warranty for your wireless device will be voided if
any of the following conditions occur:
• Non-compliance with the instructions for use or installation,
or with technical and safety standards applicable in the
geographical area where your cellphone is used;
• Connection to any equipment not supplied or not
recommended by TCT Mobile;
• Modification or repair performed by individuals not authorized
by TCT Mobile or its affiliates;
• Acts of god such as Inclement weather, lightning, power surges,
fire, humidity, infiltration of liquids or foods, chemical products,
download of files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless devices event labels or
serial numbers (IMEI);
• Damage from exposure to water or other liquids, moisture,
humidity, excessive temperatures or extreme environmental
conditions, sand, excess dust and any condition outside the
operating guidelines;
• Defects in appearance, cosmetic, decorative or structural items
such as framing and non-operative parts.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your jurisdiction. In no event shall TCT Mobile or any
of its affiliates be liable for incidental or consequential damages of
any nature whatsoever, including but not limited to commercial
loss, to the full extent those damages can be disclaimed by law.
Some states do not allow the exclusion or limitation of incidental
or consequential damages, or limitation of the duration of implied
warranties, so the preceding limitations or exclusions may not
apply to you.
How to obtain Support: Contact the customer care center by
calling (877-702-3444) or going to www.alcatelonetouch.com. We
have placed many self-help tools that may help you to isolate the
problem and eliminate the need to send your wireless device in for
service. In the case that your wireless device is no longer covered
by this limited warranty due to time or condition we have other
options that you may utilize our out of warranty repair options.
To obtain hardware repairs or replacement within the terms
of this warranty, contact TCT Mobile to get an RMA number,
include a copy of the original proof of warranty coverage (e.g.
original copy of the dated bill of sale, invoice), the consumer's
return address, your wireless carrier’s name, alternate daytime
cellphone number, and email address with a complete problem
description. Only ship the wireless device. Do not ship the SIM
card, memory cards, or any other accessories such as the power
adapter. You must properly package and ship the wireless device
to the repair center.
TCT Mobile is not responsible for wireless devices that do not
arrive at the service center. Upon receipt, the service center will
verify the warranty conditions, repair, and return your wireless
device to the address provided.
Prolonged exposure to music at full volume on the music
player may damage the listener's hearing. Set your cellphone
volume safely. Use only headphones recommended by TCT
Mobile Limited and its affiliates.
IP3465_506A_QG_Eng_USA_07_110420.indd 2IP3465_506A_QG_Eng_USA_07_110420.indd 2 2011-4-20 14:36:552011-4-20 14:36:55
