TCT Mobile 166 GSM/GPRS dual bands mobile phone User Manual IP3393 356 QG Eng USA 03 110110 indd
TCT Mobile Limited GSM/GPRS dual bands mobile phone IP3393 356 QG Eng USA 03 110110 indd
one touch 356_UM
1234567
8 9 10 11 12 13 14
1 Your cellphone ...............
Voicemail
Sym key
Vibration alert
Del key
Memory card
Power on/off
End call
Answer/Send call
Navigation key (1):
Main menu,confirm
an option
Profiles
Calendar
New Messages
FM Radio
Shift key
Left softkey
Space key
Fn key
Enter key
Right softkey
Prolonged exposure to music at full volume on the music player may damage
the listener's hearing. Set your cellphone volume safely. Use only
headphones recommended by TCT Mobile Limited and its affiliates.
1.1 Keys
Navigation key
Confirm an option (press the middle of the key)
Access to menu (short keypress)
Show/hide shortlist menu(long keypress)
Answer
Send a call
Access call memory (short keypress)
Access to Fake call (long keypress)
Switch on/Switch off the cellphone (long keypress)
End call
Return to the idle screen
Left softkey
Right softkey
Access your voicemail (long keypress)
Input the "#" in Idle
In idle screen:
Long/short keypress: Lock/Unlock the keypad
In edit mode:
Short keypress: input space
Long keypress: switch language
Fn key + Space: switch input mode
In idle screen:
Press to access shortcuts
Fn + P: access to Profiles
Fn + Q: access to Clock
Fn + S: access to Notes
In edit mode:
Press once to input top-half character.
Press twice to lock top-half inputting mode, then press once to
unlock top-half inputting mode.
Long keypress: access to Dictionary.
In edit mode:
Short press: popup symbol page to select special character by
navigation key
Long press & Fn+SYM: popup smileys page to select special
smileys by navigation key
Delete one by one (short keypress)
Delete one by one quickly (long keypress)
Switch the uppercase and minuscule (in edit screen)
Return a cursor to the next line.
1.2 Main screen icons (1)
Battery charge level
Vibrate alert: Your cellphone vibrates, but does not ring or
beep with the exception of the alarm.
Headset connected.
Keypad locked.
Call forwarding activated: your calls are forwarded.
Alarm clock.
Level of network reception.
Voicemail message arrived.
Missed calls.
Radio is on.
Stopwatch is active.
WAP alerts (1).
Roaming.
Memory card scanning in progress.
Memory card scanning completed.
Line switching (2): indicates the selected line.
GPRS connection status (Blue - Activated).
GPRS connecting.
Message receipt in progress.
Sending a message.
Silence mode: your cellphone neither rings, beeps nor vibrates
except for the alarms.
Message unread.
Message list is full: your terminal cannot accept any new
messages. You must access the message list and delete at least
one message on your SIM card.
Flight mode.
(1) Depending on your network operator.
(2) Contact your network operator to check service availability.
Installing or removing the battery
2 Getting started ..............
2.1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card, press
the bottom and slide it out. Please power off your cellphone before you
remove the SIM card.
Charging the battery
Connect the battery charger to your phone and mains socket respectively
• The charging may take about 20 minutes to start if the battery is flat.
• Be careful not to force the plug into the socket.
• Make sure the battery is correctly inserted before connecting the
charger.
• The mains socket must be near to the phone and easily accessible (avoid
electric extension cables).
• When using your telephone for the first time, charge the battery fully
(approximately 3 hours).You are advised to fully charge the battery
( ).
• To reduce power consumption and energy waste, when battery is fully
charged, disconnect your charger from the plug; reduce the backlight
time, etc.
The charge is complete when the animation stops.
2.2 Power on your cellphone
Hold down the key until the cellphone powers on.
2.3 Power off your cellphone
Hold down the key until the cellphone power off.
3 Calls ...........................
3.1 Making a call
Dial the desired number then press the key to place the call. If you
make a mistake, you can delete the incorrect digits by pressing the right
softkey or key.
To hang up the call, press the key.
Making an emergency call
If your cellphone has network coverage, dial emergency number and press
the key to make an emergency call. This works even without a SIM card
and without typing the PIN code or unlocking the keypad.
3.2 Call memory
You can access your call memory by pressing the key from the idle
screen. Check "Outgoing calls", "Missed calls", "Answered calls".
4 Menu arrange ...........
Main Menu is designed to vary according to your preference.
Change the order
From main menu, press left softkey and select "Move" or long keypress
key till tick "√" is shown, then move the cursor to your favorite destination
and confirm with key.
Show/Hide
Access "Menu arrange", press key till tick ("√") show or off, it will
show/hide some main menu.
(1) The icons and illustrations in this guide are provided for informational purposes
only.
(1) Depending on your network operator.
(1) The quality of the radio depends on the coverage of the radio station in that
particular area.
5 Messages ..................
5.1 Messages: Text/Multimedia message
5.1.1 Create message
From the main menu select "Messages" to create text/multimedia
message.
You can type a message and you can also modify a predefined message in
Templates or customize your message by adding pictures, photos, sounds,
titles, etc (only available while editing a MMS). While writing a message,
select "Options" to access all the messaging options.You can save your
messages that you send often to Drafts or Templates (MMS only).
5.1.2 Inbox
All received messages (read and unread) are stored in the same Inbox.
Group by sender/Group by receiver (1)
Messages can be grouped by sender/receiver ("Options\Group by
sender"/"Options\Group by receiver"). And you are enabled to quick
search the messages by pressing the key associated with the first letter of
sender/receiver’s name.
5.2 SMS Conversation (chat) (2)
Access to "Advanced" and select "Switch view mode", keep the
conversation going in real time using SMS chat. You may separate chat for
every contact with whom you exchange short text messages.
5.3 Email (3)
Your cellphone has an email client with the settings predefined for a few
popular email services like – GoogleMail, Windows live, Yahoo, AOL, etc.
6 Directory ..................
6.1 Consulting your directory
To access the Directory from the main screen, press the key and
select the icon.
6.2 Adding a contact
Select the contacts list in which you wish to add a contact to, press the
"Options" softkey, select "Add contact" then Save.
7 Fake Call ...................
Protect yourself from annoying situations with the "Fake Call". In this
meun, you can set "Caller name/nb", "Call time" and "Ringtone".
When the timer reaches, the cellphone will ring and display like receiving a
real cellphone call. Press key, pretend answering a call, the screen will
display just like have an ongoing call. Press key, pretend to reject the
call, the call will terminate automatically.
8 Radio .........................
Your cellphone is equipped with a Radio (1) with RDS functionality. You can
use the application as a traditional Radio with saved channels or with
parallel visual information related to the radio program on the display, if you
tune to stations that offer Visual Radio service. You can listen to it while
running other applications.
9 Internet(1) ........................
9.1 WAP ..............................................................
Access WAP options: Homepage, Bookmarks, Go to URL, Recent
pages, Offline pages.
9.2 Weather ........................................................
Your cellphone is equipped with a weather function for consulting up to
3-day forecast of favorite cities.
9.3 News..............................................................
It is a huge time saver providing news updates from a website in a simple
form. Once subscribed to a channel, it gives you the ability to track and
manage all your favorite RSS content on your cellphone at anytime,
anywhere!
Available options:
View Message title or message summary of a channel with URL
will be shown.
Update Refresh the content of a channel.
Create channel Create a new channel with name and URL.
Delete Delete the channel.
Edit Edit the name or URL of a channel.
Update all Refresh all channels.
Settings Select a regular interval to retrieve updates automatically,
set to show images or not, as well as a WAP account to
connect to.
Enable/Disable
all auto-update
Activate auto-update or not to all channels.
Send Share a channel with your friend by sending it by SMS,
MMS or Email.
10 ICE .........................
ICE (in case of emergency) are 3 numbers emergency services can call if
you have an accident, you can also add useful information such as blood
type, allergy. Access to "ICE" menu from main menu and below options are
available: View, Add/Edit, Delete.
11 Games ....................
Your cellphones includes some games, Select "Game settings", it allows
you to manage settings, in which you may set background audio and
vibration alert.
12 Camera ..................
Your cellphone is fitted with a camera for taking photos that you can use in
different ways:
• Store them in your “Media album\My creations”.
• Send them in a multimedia message (MMS) to a cellphone or an
email address.
• Send them directly by Email.
• Customize your main screen.
• Select them as incoming call image to a contact in your directory.
• Transfer them by microSD card to your computer.
13 Profiles ...................
With this menu, you may personalise ringtones for different events and
environments.
14 Media album. .........
You will have an access to all audio and visual files stored in cellphone or in
Medium Album. You can access a number of items with this option: My
audios, My images, Unknown files and Memory status.
Inserting the memory card
• Unclip the cover and insert the MicroSD card with golden contact
downwards into the slot.
• Unclip the cover and gently push the memory card until unlocked.
• Take out your MicroSD card and clip the cover closed.
15 Music Player ..........
Access this feature from the main menu by selecting “Music player”. You
will have full flexibility of managing music both on your cellphone and
memory card.
16 Services..................
Contact your network operator to check service availability.
17 Others ..........................
17.1 Calendar .......................................................
Once you enter this menu from main menu, there is a monthly-view
calendar for you to keep track of important meetings, appointments, etc.
Days with events entered will be marked in color.
17.2 Calculator .....................................................
Access this feature by selecting "Calculator" from the main menu.
Enter a number, select the type of operation to be performed using the
navigation keys, and enter the second number, then press key or left
softkey to display the result.
17.3 Notes .............................................................
You can create a note in text or voice format by accessing "Notes" from
main menu.
17.4 Tasks ..............................................................
Enables you to easily manage and track the progress of an task with
priorities. All the tasks will be sorted by due date.
17.5 Clock .............................................................
17.5.1 Alarm
Your cellphone has a built-in alarm clock with a snooze feature.
17.5.2 Clock
Allows you to have settings of date and time, including 12/24h format.
17.5.3 World clock
The World clock shows current local time and the time zone in different
cities.
17.5.4 Stopwatch
The stopwatch is a simple application for measuring time with the possibility
to register several results and suspend/resume measurement.
17.6 Converter .....................................................
Unit converter and Currency converter.
18 Settings ..................
From the main menu, select the menu icon and select the function of
your choice in order to customize your cellphone: Display, Languages,
Headset, Input mode, Vocabulary, Keys, Security, Networks, Connectivity,
Restore default set, Call settings.
18.1 Keys
You may set the keypad to which you prefer to.
Fn + Keys: you may define the combined Fn key function and to get
shortcuts with below options: Edit/Add/Delete.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2011
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior notice.
(1) The option of Group by receiver is available in Outbox, Sent, and Draft folders
only.
(2) Depending on your network operator.
(3) HTML email and image in email not supported.
www.sar-tick.com
This product meets applicable national SAR limits
of 1.6 W/kg. The specific maximum SAR values can
be found on page 19 of this user guide.
When carrying the product or using it while worn
on your body, either use an approved accessory
such as a holster or otherwise maintain a distance
of 1.5 cm from the body to ensure compliance
with RF exposure requirements. Note that the
product may be transmitting even if you are not
making a phone call.
(1) Depending on your network operator. May cause additional network charges for
data flow to provide this service. Extra fees might also be charged in roaming
states.
For more information about how to use the phone, please go to www.
alcatel-mobilephones.com to download complete user manual. Moreover,
from the website you can also consult FAQ.
English - CJB22D1ALAAA
IP3393_356_QG_Eng_USA_03_110110.indd 1IP3393_356_QG_Eng_USA_03_110110.indd 1 2011-1-10 18:13:262011-1-10 18:13:26
15 16 17 18 19 20 21
27 2822 23 24 25 26
Safety and use .......................
We recommend that you read this chapter carefully before using your cellphone.
The manufacturer disclaims any liability for damage, which may result as a
consequence of improper use or use contrary to the instructions contained
herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle constitutes a
real risk, even when the hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their cellphone when the vehicle is not parked.
Check the laws and regulations on the use of wireless cellphones and their
accessories in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas.
When driving, do not use your cellphone and headphone to listen to music or to
the radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your cellphone emits electromagnetic waves that can interfere
with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To
ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that the car’s
electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its
performance.
Switch the cellphone off before boarding an aircraft to avoid prosecution.
Switch the cellphone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, cellphones can
interfere with other electrical or electronic devices, or equipment using radio
frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly obey
all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in
any potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump. In particular
when using the cellphone you should hold it against the ear on the opposite side
to the device, if any.
To avoid hearing impairment, answer the call before holding your cellphone to your
ear. Also move the handset away from your ear while using the "hands-free" option
because the amplified volume might cause hearing damage.
Do not let children use the cellphone and/or play with the cellphone and
accessories without supervision.
When replacing the cover please note that your cellphone may contain substances
that could create an allergic reaction.
This warranty shall not apply to defects to your cellphone and/or
accessory due to (without any limitation):
1) Non-compliance with the instructions for use or installation, or
with technical and safety standards applicable in the geographical
area where your cellphone is used,
2) Connection to any equipment not supplied or not recommended
by TCT Mobile Limited,
3) Modification or repair performed by individuals not authorized by
TCT Mobile Limited or its affiliates or your vendor,
4) Inclement weather, lightning, fire, humidity, infiltration of liquids or
foods, chemical products, download of files, crash, high voltage,
corrosion, oxidation…
Your cellphone will not be repaired in case labels or serial numbers
(IMEI) have been removed or altered.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your country or jurisdiction.
“In no event shall TCT Mobile Limited or any of its affiliates be liable
for indirect, incidental or consequential damages of any nature
whatsoever, including but not limited commercial or financial loss or
damage, loss of data or loss of image to the full extent those damages
can be disclaimed by law.
Some countries/states do not allow the exclusion or limitation of
indirect, incidental or consequential damages, or limitation of the
duration of implied warranties, so the preceding limitations or
exclusions may not apply to you.”
Cellphone warranty .............
Your cellphone is warranted against any defect or malfunctioning
which may occur in conditions of normal use during the warranty
period of twelve (12) months (1) from the date of purchase as shown
on your original invoice.
Batteries (2) and accessories sold with your cellphone are also
warranted against any defect which may occur during the first six (6)
months (1) from the date of purchase as shown on your original
invoice.
In case of any defect of your cellphone which prevents you from
normal use thereof, you must immediately inform your vendor and
present your cellphone with your proof of purchase.
If the defect is confirmed, your cellphone or part thereof will be
either replaced or repaired, as appropriate. Repaired cellphone and
accessories are entitled to a one (1) month warranty for the same
defect. Repair or replacement may be carried out using reconditioned
components offering equivalent functionality.
This warranty covers the cost of parts and labor but excludes any
other costs.
Hearing Aid Compatibility
Your cellphone is rated: "For Hearing Aid", to assist hearing device users in
finding cellphones that may be compatible with their hearing devices.
This device is HAC M3 compatible.
For more information please refer to "Hearing Aid Compatibility with Mobile
Phones" leaflet or visit our website http://www.alcatel-mobilephones.com/
General information ............
• Website: www.alcatel-mobilephones.com
• Hot Line Number: see "TCT Mobile Services" leaflet or go to
our Internet site.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatel-mobilephones.
com
Your cellphone is a transceiver that operates on GSM networks with 850
and 1900 MHz bands.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number) shown on
the packaging label and in the product’s memory. We recommend that you
note the number the first time you use your cellphone by entering * # 0 6 #
and keep it in a safe place. It may be requested by the police or your
operator if your cellphone is stolen. This number allows your cellphone to
be blocked preventing a third person from using it, even with a different SIM
card.
Disclaimer
There may be certain differences between the user manual description and
the cellphone’s operation, depending on the software release of your
cellphone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if any,
nor for their potential consequences, which responsibility shall be borne by
the operator exclusively.
Always handle your cellphone with care and keep it in a clean and dust-free place.
Do not allow your cellphone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The
manufacturer’s recommended operating temperature range is -10°C (14°F) to
+55°C (131°F) (the max value depends on device, materials and housing paint/
texture).
Over 55°C (131°F) the legibility of the cellphone’s display may be impaired, though
this is temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your cellphone
model.TCT Mobile Limited and its affiliates disclaim any liability for damage caused
by the use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check local
regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing
lights, or when playing video games. These seizures or blackouts may occur even if a
person never had a previous seizure or blackout. If you have experienced seizures
or blackouts, or if you have a family history of such occurrences, please consult
your doctor before playing video games on your cellphone or enabling a flashing-
lights feature on your cellphone. Parents should monitor their children’s use of
video games or other features that incorporate flashing lights on the cellphones. All
persons should discontinue use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms, please take
the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a well lit environment.
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow
these instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or
other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest
for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop
the game and see a doctor.
Prolonged exposure to music at full volume on the music player may cause the
listener’s hearing impairment. Adjust the volume before placing headphones
on or in your ear.Only use headphones recommended by TCT Mobile
Limited and its affiliates.
Troubleshooting....................
Before contacting the aftersales department, you are advised to follow the
instructions below:
• You are advised to switch off the cellphone from time to time to
optimize its performance.
• You are advised to fully charge ( ) the battery for optimal
operation.
• Avoid storing large amounts of data in your cellphone as this may
affect the performance of your cellphone.
and carry out the following checks:
My cellphone will not switch on
• Press until the screen comes on
• Check the battery charge level
• Check the battery contacts, remove and reinstall your battery, then
turn your cellphone back on
My cellphone has not responded for several minutes
• Press the key
•
Remove the battery and re-insert it, then switch the cellphone back
on
My screen is difficult to read
• Clean your screen
• Use your cellphone in accordance with the recommended conditions
of use
My cellphone turns off by itself
• Check that your keypad is locked when you are not using your
cellphone
• Check the battery charge level
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your cellphone regarding
taking photographs and recording sounds with your cellphone. Pursuant to such laws
and regulations, it may be strictly forbidden to take photographs and/or to record the
voices of other people or any of their personal attributes, and reproduce or distribute
them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained, if
necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
cellphone (including the operator) disclaim any liability which may result from the
improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable environmental
regulations. Only use the battery for the purpose for which it was designed. Never
use damaged batteries or those not recommended by TCT Mobile Limited and/or
its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at
the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign
must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead
they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
My cellphone will not charge properly
• Make sure that your battery is not completely discharged; the
battery charge indicator can take several minutes and may be
accompanied by a quiet whistling sound
• Make sure charging is carried out under normal conditions 0°C
(32°F) - +40°C (104°F)
• Make sure your battery is inserted. It must be inserted before
plugging in the charger
• Make sure you are using an Alcatel battery and charger in the box
• When abroad, check that the electrical current is compatible
My cellphone will not connect to a network
• Try connecting in another location
• Verify the network coverage with your operator
• Check with your operator that your SIM card is valid
• Try selecting the available network(s) manually
• Try connecting at a later time if the network is overloaded
SIM card error
• Make sure the SIM card has been correctly inserted
• Verify with your operator that your SIM card is 3V or 1.8V
compatible; the old 5V SIM cards cannot be used
• Make sure the chip on your SIM card is not damaged or scratched
Unable to make outgoing calls
• Make sure you have dialled a valid number and press the key
• For international calls, check the country and area codes
• Make sure your cellphone is connected to a network, and that the
network is not overloaded or unavailable
• Check your subscription status with your operator (credit, SIM card
valid, etc.)
• Make sure you have not barred outgoing calls
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C (32°F) to
40°C (104°F)
The chargers designed for your cellphone meet with the standard for safety of
information technology equipment and office equipment use. Due to different
applicable electrical specifications, a charger you purchased in one jurisdiction may
not work in another jurisdiction. They should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5 V, 400 mA
Battery: Lithium 750 mAh
• RADIO WAVES:
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO
RADIOWAVES
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines were developed by an
independent scientific organization (ICNIRP) and include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands.
The highest SAR values under the ICNIRP guidelines for this device model are:
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR GSM 850 1.17 W/kg
Body-worn SAR GSM 850 1.19 W/kg
During use, the actual SAR values for this device are usually well below the values
stated above. This is because, for purposes of system efficiency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out at a separation distance of 1.5 cm. To
meet RF exposure guidelines during body-worn operation, the device should be
positioned at least this distance away from the body. If you are not using an
approved accessory ensure that whatever product is used is free of any metal and
that it positions the cellphone the indicated distance away from the body.
The World Health Organization has stated that present scientific information does
not indicate the need for any special precautions for the use of mobile devices.
They recommend that if you are interested in further reducing your exposure then
you can easily do so by limiting your usage or simply using a hands-free kit to keep
the device away from the head and body.
Unable to receive incoming calls
• Make sure your cellphone is switched on and connected to a
network (check for overloaded or unavailable network)
• Check your subscription status with your operator (credit, SIM card
valid, etc.)
• Make sure you have not forwarded incoming calls
• Make sure that you have not barred certain calls
The caller’s name does not appear when a call is received
• Check that you have subscribed to this service with your operator
• Your caller has concealed his/her number
The sound quality of the calls is not optimal
• You can adjust the volume during a call by means of the key
• Check the network strength
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription
includes this service
• Make sure this feature does not require an Alcatel accessory
When I select a number from my directory, the number is
not dialled
• Make sure that you have correctly recorded the number in your
file
• Make sure that you have selected the country prefix when calling a
foreign country
I am unable to create a file in my directory
• Make sure that your SIM card directory is not full; delete some files
or save the files in the product directory (i.e. your professional or
personal directories)
For more information you can go to www.alcatel-mobilephones.com
Additional information about electromagnetic fields and public health are available
on the following site: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio service
(e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Your cellphone is equipped with a built-in antenna. For optimal operation, you
should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other
than against your ear. In such circumstances the device will be compliant with the
guidelines when used with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any metal and that it
positions the cellphone at least 1.5 cm away from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
eZiText™ and Zi™ are trademarks of Zi Corporation and/or its
Affiliates.
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability
I cannot access my voicemail
• Make sure your operator’s voicemail number is correctly entered in
“My numbers”
• Try later if the network is busy
I am unable to send and receive messages MMS, Vox MMS
• Check your cellphone memory available as it might be full
• Contact your network operator to check service availability and
check MMS parameters
• Verify the server center number or your MMS profile with your
operator
• The server center may be saturated; try again later
The icon is displayed on my standby screen
• You have saved too many short messages on your SIM card; delete
some of them or archive them in the product memory
“No service” is displayed
• You are outside of the network coverage area
I have already entered 3 incorrect PIN codes
• Contact your network operator to obtain the PUK code (Personal
Unblocking Key)
I am unable to download new files
• Check for free space
• Delete some files
• Check your subscription status with your operator
(1) The warranty period may vary depending on your country.
(2) The life of a rechargeable cellphone battery in terms of conversation time
standby time, and total service life, will depend on the conditions of use and
network configuration. Batteries being considered expendable supplies, the
specifications state that you should obtain optimal performance for your
cellphone during the first six months after purchase and for approximately 200
more recharges.
(1) Contact your network operator for service availability.
18.2 Call settings
My numbers
Type in or modify your cellphone number and confirm by pressing .
Your cellphone number is usually written on your SIM card.
Billings (1)
You can access different items with this option: Amount, Duration, GPRS
counter, Beep duration.
19 Latin input mode ........
To write messages, there are two writing methods:
- Normal: this mode allows you to type a text by choosing a letter or a
sequence of characters associated with a key.
- Predictive with the Zi mode: This mode speeds up the writing of your text.
Fn key :Press once: input top-half character,
Press twice: lock top-half character inputting mode, then
press once to unlock top-half character inputting mode.
Long press: access to Dictionary
Sym key :Short keypress: access the Symbols table
Long keypress & Fn + Sym: popup smileys page
Space key
:
Short press: input space
Long press: press to switch language
Fn+Space: switch input mode
Shift key :In abc (Multitapabc) input mode (no Abc mode):
Short press once: only switch one character from
minuscule to uppercase
Short press twice: lock uppercase input mode
Short press once: unlock the uppercase
In eZiabc (Smartabc) input mode:
Short press once: to eZi ABC
Short press twice: to eZi Abc
Del key :Short keypress: delete one by one
Long keypress: delete one by one quickly
My cellphone is frozen, can’t power on
• Make sure your battery is not completely used up or damaged.
• Remove your battery, remove your SIM card then reinstall them to
power on again, if still does not work;
• Hold down # key and press Power on/off key for a while to reset
the cellphone.
ALL User cellphone data: contacts, photos, messages and files, downloade
applications like Java games will be lost permanently.
How to make your battery last longer
•
Make sure you follow the complete charge time (minimum 3 hours)
• After a partial charge, the battery level indicator may not be exact.
Wait for at least 20 minutes after removing the charger to obtain
an exact indication.
• Switch on the backlight upon request.
• Extend email auto-check interval to as long as possible.
• Update weather info. upon demand manually or set its auto-check
interval longer.
(1) Depending on your network operator.
IP3393_356_QG_Eng_USA_03_110110.indd 2IP3393_356_QG_Eng_USA_03_110110.indd 2 2011-1-10 18:13:272011-1-10 18:13:27
