TCT Mobile 186 GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth User Manual
TCT Mobile Limited GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth
User Manual
1
10
2
11
3
12
4
13
5
14
6
15
7
16
89
1817
1 Your cellphone ..............
Flick to go left/right/up/down•
Press to confirm an option•
(1) Answer/Send a call•
Enter Call Log•
Press: End a call •
Return to the Home screen
Press n hold: Power on/off•
Press n hold: Access your voicemail•
Press once: Input a capitalized character•
Press twice: Lock the keyboard in capital letter input •
mode
Press once: Input a top-half character•
Press twice: Lock the keyboard in top-half key input mode•
Fn+ B: Access Bluetooth
Fn+ M: Access Music
Fn + P: Access Profiles
Fn + J: Access Java applications
Press: Enter a space (on edit mode)•
Unlock the keypad (on Home screen)
Press n hold: Access language list (on edit mode)•
Lock the keypad (on Home screen)
Hold down Fn key, then press Space key to select input •
method
Enter symbol table•
Hold down Fn key, then press SYM key to enter •
emotion table
Confirm an option•
Enter the next line•
Vibrate alert•
Volume up/down •
Scroll up/down•
Press to enter One Touch Mail/WAP function • (1)
1.1 Status bar icons (2)
Battery charge level
Vibrate alert: your cellphone vibrates, but does not
ring or beep with the exception of the alarm.
Bluetooth status (Activated).
Bluetooth status (Connected to an audio device).
Java status (Activated).
Headset connected.
Call forwarding activated: your calls are forwarded.
Alarm or appointments programmed.
Level of network reception.
Wi-Fi connected.
Wi-Fi disconnected.
Voicemail message arrived.
Missed calls.
Call in progress.
Stopwatch is active.
Radio is on.
Email unread.
WAP messages (1).
Roaming.
SD card scanning in progress.
SD card scanning completed.
SIM card unavailable.
Line switching (1): indicates the selected line.
GPRS connection status (Activated).
GPRS connecting.
EDGE connecting.
EDGE attached.
2G network available.
3G network available.
Music active.
(1) Depending on your network operator.
Sending a MMS.
MMS receipt in progress.
Sending a SMS.
Silence mode: your cellphone does not ring, beep or
vibrate with the exception of the alarm.
SMS unread.
MMS unread.
(Flickering) Message list is full: your cellphone
cannot accept any new messages. You must access the
message list and delete at least one message on your
SIM card.
Flight mode.
1.2 Home screen
You can customize your Home screen by selecting through Right
softkey.
1.2.1 Widget bar
Widgets are convenient shortcuts for quick access from the Home
screen.
1.2.2 Change wallpaper
You can select a folder to choose one image as favorite wallpaper by
selecting "Change wallpaper".
Charging the battery
Connect the battery charger to your cellphone and outlet
respectively.
To reduce power consumption and energy waste, when
battery is fully charged, disconnect your charger from the
plug; switch off Wi-Fi (1), Bluetooth or background-running
applications when not in use; reduce the backlight time, etc.
2.2 Power on your cellphone
Hold down the key until the cellphone powers on.
2.3 Power off your cellphone
Hold down the key from the Home screen.
3 Making a call ................
Dial the desired number then press the key to place the call.
The number you entered can be saved to Contacts by selecting
"Save". If you make a mistake, you may short press Right softkey
to delete the incorrect digits one by one, or you may long press
Right softkey to delete all.
To hang up the call, press the key.
Muting the ringtone
To mute ringtone of current incoming call, press Right softkey.
Answer the call by pressing the key.
Rejecting a call
Press the key once, or reject it by SMS (Options\Reject call
with SMS).
4 Menu arrange ..............
It is designed to vary according to your preference.
Change the order
Access the main menu, focus on the main menu item you want to
move, select "Options\Move", and tick "√" will be shown on the
item you selected, then release it to your favorite destination.
Show/Hide
Access the main menu, select "Options\Add and remove menu",
and select the left check box of the selected menu once to show/
hide, and then select "Done" to save the operation.
5 Messages ................
5.1 Access
You may access this menu using the following options:
Access from the main menu by selecting "• Messages".
Select • from widget bar, and then enter the sub-menu you
require.
(1) Depending on your network operator.
(2) The icons and illustrations in this guide are provided for informational
purposes only.
(1) The key mentioned on the following chapters stands for Send key
only..
(1) Contact your network operator to check service availability.
(1) The quality of the radio depends on the coverage of the radio station in
that particular area.
(2) Depending on your network operator and market.
(3) Depending on your network operator. May cause additional network
charges for data flow to provide this service. Extra fees might also be
charged in roaming states.
(1) Depending on the software release of your cellphone and your network
operator.
(2) Depending on your country or your operator.
(1) Depending on your model.
2 Getting started ..............
2.1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off
your cellphone and remove battery before inserting or removing the
SIM card.
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card,
press the bottom and slide it out.
Installing or removing the battery
Insert and click the battery into place, then close the cellphone cover.
Unclip the cover, then remove the battery.
5.2 Conversational On (Off) mode
In conversational on mode, you can view chat history in chronological
order. In conversational off mode, you may have access to the
following folders: Inbox, Outbox, Sent, Drafts, Voicemail,
Broadcast SMS, Empty folder, Templates, Settings, etc.
Conversational view mode is set as default. You may switch to
conventional mode by selecting "Options\Settings\Conversational
mode\On(Off)".
5.3 Write message
You can select "Messages\Write message" from the main menu or
access from widget to write text/multimedia message. One or
more recipients can be added from contact list and you can remove a
recipient by pressing . Press "Contacts" through key to multi-
select recipients from Contacts.
An SMS will be converted to MMS automatically when images, videos,
audio, slides or attachments are inserted, Subject, CC/BCC/email
address is added; or the message contains more than 8 pages of text.
Timer send
Schedule a SMS/MMS to be sent out at predefined time (“Options\
Timer send”).
6 E-mail .....................
Your cellphone has an email client with the settings pre-defined for a
few popular email services like – GoogleMail, Yahoo, AOL, etc.
Besides this, you can set up other POP3 or IMAP4 email accounts that
you may be using.
7 Palringo (1)
..................
Palringo Instant messaging (IM) allows you to chat with other people
using Palringo account. You can also connect to other popular IM
services through Palringo, like Yahoo, AIM, GG, ICQ, GTalk, iChat
etc.
Please note that the services accessible to you will depend on your
client version and dynamic Palringo server options.
8 Contacts ..................
8.1 Consulting your contacts
You can access to this function from the main menu by selecting
"Contacts" or select from widget bar, and then enter the sub-
menu you require.
8.2 Adding a contact
You can add a new contact by selecting "Options\Create new".
Adding birthday reminder
You can set a birthday reminder when editing contact information.
This will remind you at regular intervals during the day prior to the
set date.
9 Call log .....................
9.1 Access
You can access the function using the following options:
Select • from main menu
Press • key from Home screen
Select • from widget bar, and then enter the sub-menu you
require.
9.2 Available options
When you press "Options", you can have access to Delete, Send
message, Save to Contacts, Edit before call, etc.
9.2.1 Call settings (1)
You can access a number of items with this option: Call waiting,
Call forwarding, Call barring, Caller ID, Line switching, Auto
redial.
Billing (1)
You can access different items with this option: Last call cost, Total
cost, Max cost, Reset cost, Price per unit, Duration, GPRS
counter, Beep duration.
10 Media applications .....
10.1 Music ...............................................
You can access this feature from the main menu by selecting "Music".
You will have full flexibility of managing music both on your cellphone
and SD card.
10.2 Image ..............................................
A library links to the images in "My creations" in cellphone to be
shown in list, slide, set as wallpaper, power on/off display and incoming
call image or sent by MMS, Email, Bluetooth.
10.3 Video ..............................................
Contains all video clips both in cellphone and SD card and enables you
to play, send, set as power on/off display, delete, rename, sort, etc.
10.4 Radio ...............................................
Your cellphone is equipped with a Radio (1) with RDS (2) functionality.
You can use the application as a traditional Radio with saved channels
or with parallel visual information related to the radio program on the
display, if you tune to stations that offer Visual Radio service. You can
listen to it while running other applications.
11 Internet (3)
...................
11.1 My friends ......................................
It migrates self-contained sub-trees of the websites to let you stay in
touch with your friends by flicking through Bebo, Friendster, Hi5,
Myspace, Flickr, etc.
11.2 Opera ..............................................
Not only does Opera Mini give you the full Web experience where
you stay in touch with your friends, obtain information, do your online
banking etc., but it is also designed to save time by using compressed
web pages.
11.3 WAP ...............................................
Access WAP options: Homepage, Bookmarks, Go to URL, Last
web address, Recent pages, Offline pages, Service inbox,
Settings.
11.4 News ................................................
It is a huge time saver providing news updates from a website in a
simple form.
Once subscribed to a channel, it gives you the ability to track and
manage all your favorite RSS content on your cellphone at anytime,
anywhere!
11.5 Weather .........................................
Your cellphone is equipped with a weather function for consulting up
to 3-day forecast of favorite cities.
11.6 Facebook ........................................
Facebook is a social utility that connects people with friends and
others who work, study and live around them. It provides a number of
features with which users may interact: Wall, a space on every user's
profile page that allows friends to post messages for the user to see;
Pokes, which allow users to send a virtual "poke" to each other; Gifts,
a feature allowing users to send virtual gifts which appear on the
recipient’s profile; Market places, which lets users post free classified
goods, etc.
To open an account online, please go to: http://www.facebook.com/.
11.7 mTweet .........................................
Twitter is a social networking and microblogging service that has
gained notability and popularity worldwide. This feature enables
cellphone users to exchange news updates and ideas with a community
in the form of messages or posts. Posts are displayed on the author's
profile page and delivered to the author's subscribers or followers.
To open an account online, please go to: http://twitter.com/.
11.8 Shozu (1) ...........................................
Shozu means you can share the moment, whether it's a photo, video
or a blog. You can send your stuff to friends and family, email or social
networks simply by pressing the button. Add tags, titles and
descriptions before or after uploading them. Then see in real time
what your friends are saying about your uploads, and reply to them
from your cellphone anywhere and anytime.
To open an account online, please go to: http://www.shozu.com/.
12 Entertainment ............
12.1 Stopwatch ......................................
The stopwatch is a simple application for measuring time with the
possibility to register several results and suspend/resume
measurement.
12.2 Ebook .............................................
A bookshelf contains the electronic books (.txt and .pdb file only).
While reading the book, you may add bookmark, or reach the text by
searching words, phrases (Options\Find, Options\Jump to).
12.3 Java .................................................
Your Alcatel cellphone may include (2) some Java™ applications and
games. You can also download new applications and games to your
cellphone.
13 Camera ................
Your cellphone is fitted with a camera for taking photos and shooting
videos that you can use in different ways:
(1) Depending on your network operator.
English - CJB31N1ALAAA
Prolonged exposure to music at full volume on the music player
may damage the listener's hearing. Set your cellphone volume
safely. Use only headphones recommended by TCT Mobile
Limited and its affiliates.
Quick Start Guide
For more information about how to use the cellphone, please go
to www.alcatelonetouch.com to download complete user manual.
Moreover, from the website you can also consult FAQ, realize
software upgrade via PC suite, etc.
Table of contents
1 Your cellphone ...................................................................................................3
2 Getting started ...................................................................................................8
3 Making a call ........................................................................................................9
4 Menu arrange .................................................................................................... 10
5 Messages............................................................................................................. 10
6 E-mail .................................................................................................................. 11
7 Palringo ...............................................................................................................12
8 Contacts .............................................................................................................12
9 Call log ................................................................................................................ 13
10 Media applications ............................................................................................ 13
11 Internet .............................................................................................................14
12 Entertainment ................................................................................................... 16
13 Camera ............................................................................................................... 16
14 Profiles ................................................................................................................ 17
15 File manager ...................................................................................................... 17
16 Bluetooth
TM ....................................................................................................... 19
17 Wi-Fi ...................................................................................................................19
18 Others ................................................................................................................ 19
19 Settings ............................................................................................................... 20
20 Making the most of your cellphone ............................................................ 21
21 Latin input mode ..............................................................................................22
Side key Volume key
Headset connector
Micro-USB connector
Vibration key
Left softkey
Send key Right softkey
Navigation key/
OK key
End key
Status bar
LED light
Home screen
Shift key
Fn key
Delete key
Enter key
SYM key
Voicemail key
Space key
store them in your "• File manager\My creations".
send them in a multimedia message (MMS) to a cellphone or an •
email address.
send them directly by Email or Bluetooth.•
customize your Home screen.•
select them as incoming call image to a contact in your Contacts.•
transfer them by data cable or microSD card to your computer.•
14 Profiles ..................
With this menu, you may personalize ringtones for different events
and environments.
15 File manager .......
You will have an access to all audio and visual files stored in cellphone
or SD card in File manager. You can access a number of items with
this option: My audios, My images, My videos, Ebook, My
creations, Others, Phone, SD card and Memory status.
Inserting the SD card:
To release the microSD card holder, slide it in the direction of the
arrow and lift it. Then insert the microSD card with the golden
contact downward. Finally, turn down the microSD holder and slide it
in the opposite direction to lock it.
Prolonged exposure to music at full volume on the music player
may damage the listener's hearing. Set your cellphone volume
safely. Use only headphones recommended by TCT Mobile Limited
and its affiliates.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2011
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior
notice.
IP3474_900M_QG_Eng_USA_For Certification_00_110415.indd 1IP3474_900M_QG_Eng_USA_For Certification_00_110415.indd 1 2011-4-15 16:26:472011-4-15 16:26:47
19
28
20
29
21
30
22
31
23
32
24
33
25
34
26 27
3635
18.4 Tasks ...............................................
Enables you to easily manage and track the progress of a task with
priorities. All the tasks will be sorted by due date.
18.5 Clock ..............................................
18.5.1 Alarm
Your cellphone has a built-in alarm clock with a snooze feature.
18.5.2 World clock
The World clock shows current local time and the time zone in
different cities.
18.5.3 Date and time
Allows you to have settings of date and time, including 12/24h format.
18.6 Converter ......................................
You can use the Weight and Length conversion by selecting the unit
you wish to convert, then press to input the digits. Finally confirm
with "OK".
19 Settings ...............
From the main menu, select the menu icon and select the
function of your choice in order to customize your cellphone: Phone
settings, Call settings, Security, Network, Connectivity.
Service selection (1)
GSM/GPRS • Only GSM/GPRS network service is available.
WCDMA • Only WCDMA network service is available.
Dual mode • Both GSM/GPRS and WCDMA network service are
available, with priority to WCDMA.
Safety and use .......................
We recommend that you read this chapter carefully before using your
cellphone. The manufacturer disclaims any liability for damage, which may
result as a consequence of improper use or use contrary to the instructions
contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a cellphone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit, headset...),
drivers are requested to refrain from using their cellphone when the vehicle
is not parked. Check the laws and regulations on the use of wireless
cellphones and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted in certain
areas.
When driving, do not use your cellphone and headphone to listen to music or
to the radio. Using a headphone can be dangerous and forbidden in some
areas.
When switched on, your cellphone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or
airbags. To ensure that there is no problem:
- do not place your cellphone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that the
car’s electronic devices are shielded from cellphone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the cellphone from time to time to optimize its
performance.
Remember to abide by local authority rules of cellphone use on aircrafts.
Operational Warnings: Obey all posted signs when using mobile devices in public
areas.
Follow Instructions to Avoid Interference Problems: Turn off your mobile device in
any location where posted notices instruct you to do so. In an aircraft, turn off
your mobile device whenever instructed to do so by airline staff. If your mobile
device offers an airplane mode or similar feature, consult airline staff about using it
in flight.
Switch the cellphone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, cellphones can
interfere with other electrical or electronic devices, or equipment using radio
frequency.
Switch the cellphone off when you are near gas or flammable liquids. Strictly
obey all signs and instructions posted in a fuel depot, gas station, or chemical
plant, or in any potentially explosive atmosphere.
When the cellphone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump. In particular
when using the cellphone you should hold it against the ear on the opposite
side to the device, if any.
Read and follow the directions from the manufacturer of your implantable
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your jurisdiction. In no event shall TCT Mobile or any of
its affiliates be liable for incidental or consequential damages of any
nature whatsoever, including but not limited to commercial loss, to
the full extent those damages can be disclaimed by law. Some states
do not allow the exclusion or limitation of incidental or consequential
damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer care center by calling
(877-702-3444) or going to www.alcatelonetouch.com. We have
placed many self-help tools that may help you to isolate the problem
and eliminate the need to send your wireless device in for service. In
the case that your wireless device is no longer covered by this limited
warranty due to time or condition we have other options that you
may utilize our out of warranty repair options.
To obtain hardware repairs or replacement within the terms of this
warranty, contact TCT Mobile to get an RMA number, include a copy
of the original proof of warranty coverage (e.g. original copy of the
dated bill of sale, invoice), the consumer's return address, your
wireless carrier’s name, alternate daytime cellphone number, and email
address with a complete problem description. Only ship the wireless
device. Do not ship the SIM card, memory cards, or any other
accessories such as the power adapter. You must properly package
and ship the wireless device to the repair center. TCT Mobile is not
responsible for wireless devices that do not arrive at the service
center. Upon receipt, the service center will verify the warranty
conditions, repair, and return your wireless device to the address
provided.
Alcatel Mobile Phones
Limited Warranty ............
TCT Mobile North America LTD warrants to the original retail
purchaser of this wireless device, that should this product or part
thereof during normal consumer usage and condition, be proven to be
defective in material or workmanship that results in product failure
within the first twelve (12) months from the date of purchase as
shown on your original sales receipt. Such defect(s) will be repaired or
replaced (with new or rebuilt parts) at the company’s option without
charge for parts or labor directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box items
are also warranted against defects and workmanship that results in
product failure within the first six (6) months period from the date of
purchase as shown on your original sales receipt. Such defect(s) will
be repaired or replaced (with new or rebuilt parts) and the company’s
option without charge for parts or labor directly related to the
defect(s).
The limited warranty for your wireless device will be voided if any of
the following conditions occur:
• Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area
where your cellphone is used;
• Connection to any equipment not supplied or not recommended by
TCT Mobile;
• Modification or repair performed by individuals not authorized by
TCT Mobile or its affiliates;
• Acts of god such as Inclement weather, lightning, power surges, fire,
humidity, infiltration of liquids or foods, chemical products, download
of files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless devices event labels or serial
numbers (IMEI);
• Damage from exposure to water or other liquids, moisture, humidity,
excessive temperatures or extreme environmental conditions, sand,
excess dust and any condition outside the operating guidelines;
• Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts.
Hearing Aid Compatibility
Your cellphone is rated: "For Hearing Aid", to assist hearing device users in
finding cellphones that may be compatible with their hearing devices.
This device is HAC M3 compatible.
For more information please refer to "Hearing Aid Compatibility with Mobile
Phones" leaflet or visit our website http://www.alcatelonetouch.com
General information ........
• Website: www.alcatelonetouch.com
• Facebook: www.facebook.com/alcatelmobilephones
• Twitter: http://www.twitter.com/alcatel1touch
• Hot Line Number: In the United States, call 877-702-3444 for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.com
Your cellphone is a transceiver that operates on GSM/GPRS/EDGE in quad-
band with 850/900/1800/1900 MHz or UMTS in dual-band with 850/2100
MHz.
Protection against theft (1)
Your cellphone is identified by an IMEI (cellphone serial number)
shown on the packaging label and in the product’s memory. We
recommend that you note the number the first time you use your
cellphone by entering *#06# and keep it in a safe place. It may be
requested by the police or your operator if your cellphone is stolen.
Disclaimer
There may be certain differences between the user manual description and
the cellphone’s operation, depending on the software release of your
cellphone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if any,
nor for their potential consequences, which responsibility shall be borne by
the operator exclusively.
medical device. If you have any questions about using your mobile device with
your implantable medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding your cellphone to
your ear. Also move the handset away from your ear while using the “hands-
free” option because the amplified volume might cause hearing damage.
It is recommended to have proper supervision while small children use your
cellphone.
When replacing the cover please note that your cellphone may contain
substances that could create an allergic reaction.
Always handle your cellphone with care and keep it in a clean and dust-free place.
Do not allow your cellphone to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of liquids, dust,
sea air, etc.). The manufacturer’s recommended operating temperature range
is -10°C (14°F) to +55°C (131°F) (the max value depends on device, materials
and housing paint/texture).
Over 55°C (131°F) the legibility of the cellphone’s display may be impaired,
though this is temporary and not serious.
Do not open or attempt to repair your cellphone yourself.
Do not drop, throw or try to bend your cellphone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended
by TCT Mobile Limited and its affiliates and are compatible with your
cellphone model.TCT Mobile Limited and its affiliates disclaim any liability for
damage caused by the use of other chargers or batteries.
Your cellphone should not be disposed of in a municipal waste. Please check
local regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your cellphone.
Some people may suffer epileptic seizures or blackouts when exposed to
flashing lights, or when playing video games. These seizures or blackouts may
occur even if a person never had a previous seizure or blackout. If you have
experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult your doctor before playing video games on your
cellphone or enabling a flashing-lights feature on your cellphone. Parents
should monitor their children’s use of video games or other features that
incorporate flashing lights on the cellphones. All persons should discontinue
use and consult a doctor if any of the following symptoms occur: convulsion,
eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. To limit the likelihood of such symptoms, please take the
following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your cellphone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body.
Follow these instructions to avoid problems such as tendinitis, carpal tunnel
syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and
rest for several hours before playing again.
Troubleshooting ...............
Before contacting the aftersales department, you are advised to follow
the instructions below:
• You are advised to switch off the cellphone from time to time
to optimize its performance.
• You are advised to fully charge ( ) the battery for optimal
operation.
• Avoid storing large amounts of data in your cellphone as this
may affect the performance of your cellphone.
and carry out the following checks:
My cellphone will not switch on
• Press until the screen comes on
• Check the battery charge level
• Check the battery contacts, remove and reinstall your battery,
then turn your cellphone back on
My cellphone has not responded for several minutes
• Press the key
•
Remove the battery and re-insert it, then switch the cellphone
back on
My screen is difficult to read
• Clean your screen
• Use your cellphone in accordance with the recommended
conditions of use
My cellphone turns off by itself
• Check that your keypad is locked when you are not using your
cellphone
• Check the battery charge level
- If you continue to have sore hands, wrists, or arms during or after playing,
stop the game and see a doctor.
Prolonged exposure to music at full volume using the music player may
damage your hearing. Set your cellphone’s volume to it’s lowest setting
prior to inserting headphones in your ears and adjust the volume to your
preference. Only use headphones that are recommended by TCT Mobile
Limited and it’s affiliates.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your cellphone
regarding taking photographs and recording sounds with your cellphone.
Pursuant to such laws and regulations, it may be strictly forbidden to take
photographs and/or to record the voices of other people or any of their
personal attributes, and reproduce or distribute them, as this may be
considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be
obtained, if necessary, in order to record private or confidential conversations
or take a photograph of another person; the manufacturer, the seller or
vendor of your cellphone (including the operator) disclaim any liability which
may result from the improper use of the cellphone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your cellphone, please make sure that the
cellphone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and
burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for which it
was designed. Never use damaged batteries or those not recommended by
TCT Mobile Limited and/or its affiliates.
This symbol on your cellphone, the battery and the accessories
means that these products must be taken to collection points at
the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this
sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if
My cellphone will not charge properly
• Make sure that your battery is not completely discharged; If the
battery is flat, it may take around 20 minutes to display the
battery charger indicator on the screen
• Make sure charging is carried out under normal conditions
(0°C – +40°C)
• Make sure your battery is inserted. It must be inserted before
plugging in the charger
• Make sure you are using an Alcatel battery and charger in the
box
• When abroad, check that the electrical current is compatible
My cellphone will not connect to a network
• Try connecting in another location
• Verify the network coverage with your operator
• Check with your operator that your SIM card is valid
• Try selecting the available network(s) manually
• Try connecting at a later time if the network is overloaded
SIM card error
• Make sure the SIM card has been correctly inserted
• Verify with your operator that your SIM card is 3V or 1.8V
compatible; the old 5V SIM cards cannot be used
• Make sure the chip on your SIM card is not damaged or
scratched
Unable to make outgoing calls
• Make sure you have dialled a valid number and press the
key
• For international calls, check the country and area codes
• Make sure your cellphone is connected to a network, and that
the network is not overloaded or unavailable
• Check your subscription status with your operator (credit, SIM
card valid, etc.)
• Make sure you have not barred outgoing calls
your jurisdiction or your region has suitable recycling and collection facilities;
instead they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at
www.recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C
(32°F) to 40°C (104°F).
The chargers designed for your cellphone meet with the standard for safety
of information technology equipment and office equipment use. Due to
different applicable electrical specifications, a charger you purchased in one
jurisdiction may not work in another jurisdiction. They should be used for this
purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 400/550 mA
Battery: Lithium 850 mAh
• RADIO WAVES:
THIS CELLPHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your cellphone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio-
frequency (RF) energy. These limits are part of comprehensive guidelines and
establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. These guidelines include a substantial safety margin designed to ensure
the safety of all persons, regardless of age and health.
The exposure standard for cellphones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by public
authorities such as the Federal Communications Commission of the US
Government (FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram
of body tissue. Tests for SAR are conducted using standard operating positions
with the cellphone transmitting at its highest certified power level in all tested
frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the cellphone while operating can be well below the
maximum value. This is because the cellphone is designed to operate at
multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the
lower the power output of the cellphone. Before a cellphone model is
available for sale to the public, compliance with national regulations and
standards must be shown.
Unable to receive incoming calls
• Make sure your cellphone is switched on and connected to a
network (check for overloaded or unavailable network)
• Check your subscription status with your operator (credit, SIM
card valid, etc.)
• Make sure you have not forwarded incoming calls
• Make sure that you have not barred certain calls
The caller’s name does not appear when a call is
received
• Check that you have subscribed to this service with your
operator
• Your caller has concealed his/her number
The sound quality of the calls is not optimal
• You can adjust the volume during a call by means of the
key
• Check the network strength
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription
includes this service
• Make sure this feature does not require an Alcatel accessory
When I select a number from my contacts, the number
is not dialled
• Make sure that you have correctly recorded the number in
your file
• Make sure that you have selected the country prefix when
calling a foreign country
I am unable add a contact in my contacts
• Make sure that your SIM card contacts is not full; delete some
files or save the files in the cellphone contacts (i.e. your
professional or personal contacts)
The highest SAR value for this model cellphone when tested is 1.16 W/Kg
for use at the ear and 0.866 W/Kg, for use close to the body.
While there may be differences between the SAR levels of various
cellphones and at various positions, they all meet the government
requirement for RF exposure. For body-worn operation, the cellphone
meets FCC RF exposure guidelines provided that it is used with a non-
metallic accessory with the handset at least 1.5 cm from the body. Use of
other accessories may not ensure compliance with FCC RF exposure
guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site: http://www.
phonefacts.net
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for use
of cellphones. If individuals are concerned, they might choose to limit their
own or their children’s RF exposure by limiting the length of calls, or using
“hands-free” devices to keep cellphones away from the head and body.
(fact sheet n°193). Additional WHO information about electromagnetic
fields and public health are available on the following website: http://www.
who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference to radio
or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio
service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject
to the condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference
that may cause undesired operation.
My callers are unable to leave messages on my
voicemail
• Contact your network operator to check service availability
I cannot access my voicemail
• Make sure your operator’s voicemail number is correctly
entered in “My numbers”
• Try later if the network is busy
I am unable to send and receive MMS
• Check your cellphone memory available as it might be full
• Contact your network operator to check service availability
and check MMS parameters
• Verify the server center number or your MMS profile with
your operator
• The server center may be saturated; try again later
The flickering icon is displayed on my standby
screen
• You have saved too many short messages on your SIM card;
delete some of them or archive them in the cellphone
memory
“No service” is displayed
• You are outside of the network coverage area
I have already entered 3 incorrect PIN codes
• Contact your network operator to obtain the PUK code
(Personal Unblocking Key)
I am unable to connect my cellphone to my computer
• Install first of all Alcatel’s PC suite
• Use “Install the connection” and perform the installation
• Check that your computer meets the requirements for
Alcatel’s PC Suite installation
20 Making the most of
your cellphone ...........
PC suite
You can download software upgrade for free from the website. The
PC suite includes:
• Backup/restore
You can backup the important data in your cellphone and restore
them when needed.
• 3G (WCDMA)/EDGE/GPRS modem
Use your cellphone to connect PC to the internet.
• Multimedia Personalization
Customize your cellphone with images, animations and melodies.
• Messages
You can compose SMS/MMS easily on your PC and transfer them to
your cellphone.
Supported Operating Systems
Windows XP/Vista/Windows 7.
One Touch Upgrade
Using One Touch Upgrade tool you can update your cellphone’s
software from your PC.
Download One Touch Upgrade from ALCATEL website (www.
alcatelonetouch.com) and install it on your PC. Launch the tool and
update your cellphone by following the step by step instructions (refer
to the User Guide provided together with the tool).
Your cellphone’s software will now have the latest software.
All personal information will be permanently lost
following the update process. We recommend you
backup your personal data using PC Suite before
upgrading.
Webcam (1)
You can use your cellphone as a webcam for instant messaging on
your PC.
(1) The using of webcam may vary according to the operating system of your
PC.
(1) 3G network only.
• Connect your cellphone to PC via USB cable.
• Go to "My computer" folder on your PC and find USB video device
(Under Scanners & Cameras).
21 Latin input mode .......
There are two text entry methods that can be used to write
messages:
- Normal: this mode allows you to type a text by choosing a letter or
a sequence of characters associated with a key.
- TouchPal mode: this mode can perform predictive input in hardware
keypad and supports multi-language input.
Keypad inputting:
Shift key :Press once: Input a capitalized characte
Press twice: Lock the keyboard in capital letter input
mode
Fn key :Press once: Input a top-half character
Press twice: Lock the keyboard in capital letter input
mode
Del key : Press: Delete one by one
Press n hold: Delete all
Space key
:
Press: Enter a space
Press n hold: Access language list
Hold down Fn key, then press space key to select
input method
Enter key :Confirm an option
Enter the next line
SYM key
:
Enter symbol table
Hold down Fn key, then press sym key to enter
emotion table
Your cellphone is equipped with a built-in antenna. For optimal operation,
you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions
other than against your ear. In such circumstances the device will be
compliant with the guidelines when used with headset or usb data cable. If
you are using another accessory ensure that whatever product is used is
free of any metal and that it positions the cellphone at least 1.5 cm away
from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
by TCT Mobile Limited and its affiliates is under
license. Other trademarks and trade names are
those of their respective owners.
one touch 900M Bluetooth QD
ID B017901
TouchPal™ and CooTek™ are trademarks of
Shanghai HanXiang (CooTek)Information
Technology Co., Ltd. and/or its Affiliates.
Java™ and all Java™ based trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
is a registered trademark of Opera Mini.
Facebook and the f Logo are trademarks of
Facebook, Inc., and are used under license.
Twitter and the T Logo are trademarks of Twitter,
Inc., and are used under license.
The Wi-Fi Logo is a certification mark of the Wi-Fi
Alliance.
Shozu is trademark of Shozu, Inc, and is used under
license.
I am unable to download new files
• Check for free space
• Delete some files
• Select the MicroSD Card to store the files you downloaded
• Check your subscription status with your operator
The cellphone can’t be detected by others via
Bluetooth
• Make sure that Bluetooth is turned on and your cellphone is
visible to other users
My cellphone is frozen, can’t power on
• Make sure your battery is not completely used up or
damaged
• Remove your battery, remove your SIM card then reinstall
them to power on again
• Hold down # and press power on/off key at same time to
reset it
ALL User cellphone data: contacts, photos, messages
and files, downloaded applications like Java games
will be lost permanently.
How to make your battery last longer
•
Make sure you follow the complete charge time (minimum 3
hours)
• After a partial charge, the battery level indicator may not be
exact. Wait for at least 20 minutes after removing the
charger to obtain an exact indication.
• Switch on the backlight upon request.
• Extend email auto-check interval to as long as possible.
• Update news, weather information upon demand manually
or set its auto-check interval longer.
• Exit Java background-running applications if unused for a long
time.
• Deactivate Bluetooth when not in use.
(1) Depending on the model.
16 Bluetooth™ ........
Access this feature by pressing through Left softkey from the
Home screen to enter the main menu, then selecting "Bluetooth".
17 Wi-Fi
(1) ................
To access this function, press to enter the main menu, and
select .
18 Others ........................
18.1 Calendar ......................................
Once you enter this menu from main menu, there is a monthly-
view calendar for you to keep track of important meetings,
appointments, etc. Days with events entered will be marked in
color.
18.2 Calculator ....................................
Access this feature by selecting "Calculator" from the main menu.
Enter a number, select the type of operation to be performed using
the navigation keys, and enter the second number, then select "="
to display the result.
18.3 Notes ...........................................
You can create a note in text or voice format by accessing “Notes”
from main menu.
(1) Contact your network operator for service availability.
IP3474_900M_QG_Eng_USA_For Certification_00_110415.indd 2IP3474_900M_QG_Eng_USA_For Certification_00_110415.indd 2 2011-4-15 16:26:482011-4-15 16:26:48
