TCT Mobile 245 UMTS TriBand/GSM Quadband mobile phone User Manual IP4145 870A 871S QG Eng USA 05 120423 indd
TCT Mobile Limited UMTS TriBand/GSM Quadband mobile phone IP4145 870A 871S QG Eng USA 05 120423 indd
one touch 870A_QG_USA_23_04_12
1
10
2
11
3
12
4
13
5
14
6
15
7
16
89
1817
1 Your mobile ...................
1.1 Keys and connectors
Press to go left/right/up/down or adjust the volume•
Press to confirm an option •
Answer/Send a call•
Enter Call log•
Press: End a call •
Return to the Home screen
Press and hold: Power on/off•
Press to enter • Music
Press to enter • Email
Vibrate alert •
Press and hold: Access your voicemail•
Switch between ABC/abc/Abc•
Press once: Input a top-half character•
Press twice: Lock the keyboard in top-half key input •
mode
Press and hold: Input top-half characters only until key •
is released
Fn+ B: Access Bluetooth
Fn+ M: Access Music
Fn + P: Access Profiles
Fn + J: Access Java applications
Press: Enter a space (on edit mode)•
Confirm an option (on edit mode)
Unlock the keypad (on Home screen)
Press and hold: Access language list (on edit mode)•
Lock the keypad (on Home screen)
Hold down Fn key, then press Space key to select input •
method
Enter symbol table•
Hold down Fn key, then press SYM key to enter •
emotion table
Press: Confirm an option•
Enter the next line (on edit mode)
Press and hold: Turn on/off torch (on Home screen)•
Press to enter • Camera (1)
1.2 Status bar icons (2)
Battery charge level
Vibrate alert: your phone vibrates, but does not ring
or beep with the exception of the alarm.
Bluetooth status (Activated).
Java status (Activated).
Headset connected.
Call forwarding activated: your calls are forwarded.
Alarm or appointments programmed.
Level of network reception.
Missed calls.
Call in progress.
Stopwatch is active.
Radio is on.
Email unread.
WAP messages (1).
Roaming.
SD card scanning completed.
SIM card unavailable.
Line switching (1): indicates the selected line.
2G/3G connected.
GPRS connection status (Activated).
GPRS connecting.
EDGE connecting.
EDGE attached.
(1) Depending on your network operator.
Music active.
Sending an SMS.
Silence mode: your phone does not ring, beep or
vibrate with the exception of the alarm.
SMS unread.
MMS unread.
MMS busy.
Flight mode.
1.3 Home screen
You can customize your Home screen by selecting "Personalize"
through Right softkey.
1.3.1 Widget bar
Widgets are convenient shortcuts for quick access from the Home
screen.
1.3.2 Change wallpaper
You can select a folder to choose one image as favorite wallpaper by
selecting "Change wallpaper".
Charging the battery
Connect the battery charger to your phone and outlet respectively.
To reduce power consumption and energy waste, when
battery is fully charged, disconnect your charger from the
plug; switch off Bluetooth or background-running applications
when not in use; reduce the backlight time, etc.
2.2 Power on your phone
Hold down the key until the telephone powers on.
2.3 Power off your phone
Hold down the key from the Home screen.
3 Making a call ................
Dial the desired number then press the key to place the call. The
number you entered can be saved to Contacts by selecting "Save".
If you make a mistake, you may press Right softkey to delete the
incorrect digits one by one, or you may press and hold Right
softkey to delete all.
To hang up the call, press the key.
Muting the ringtone
To mute ringtone of current incoming call, press Right softkey
once.
Rejecting a call
Press the key once, or reject it by SMS (Options\Reject call
with SMS).
4 Menu arrange ..............
It is designed to vary according to your preference.
Change the order
Access the main menu, focus on the main menu item you want to
move, select "Options\Move", and tick "√" will be shown on the
item you selected, then release it to your favorite destination.
Show/Hide
Access the main menu, select "Options\Add and remove menu",
and select the left check box of the selected menu once to show/
hide, and then select "Done" to save the operation.
5 Messaging .............
5.1 Access
You may access this menu using the following options:
Access from the main menu by selecting "• Messaging".
Select • from widget bar, and then enter the sub-menu you
require.
(1) Depending on your network operator.
(2) The icons and illustrations in this guide are provided for informational
purposes only.
(1) Contact your network operator to check service availability.
(1) The quality of the radio depends on the coverage of the radio station in
that particular area.
(2) Depending on your network operator and market.
(3) Depending on your network operator. May cause additional network
charges for data flow to provide this service. Extra fees might also be
charged in roaming states. (1) Depending on your country or your operator.
2 Getting started ..............
2.1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off
your phone and remove battery before inserting or removing the SIM
card.
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card,
press the bottom and slide it out.
Installing or removing the battery
Insert and click the battery into place, then close the telephone cover.
Unclip the cover, then remove the battery.
5.2 Conversational On (Off) mode
In conversational on mode, you can view chat history in chronological
order. In conversational off mode, you may have access to the
following folders: Inbox, Outbox, Sent, Drafts, Voicemail,
Broadcast SMS, Empty folder, Templates, Settings, etc.
Conversational view mode is set as default. You may switch to
conventional mode by selecting "Options\Switch view mode".
5.3 Write message
You can select "Messaging\Write message" from the main menu
or access from widget to write text/multimedia message. One or
more recipients can be added from contact list and you can remove a
recipient by pressing . Press "Contacts" through key to multi-
select recipients from Contacts.
An SMS will be converted to MMS automatically when images, videos,
audio, slides or attachments are inserted, Subject, CC/BCC/email
address is added; or the message contains more than 8 pages of text.
An SMS message of more than a certain number of
characters (the number of characters depends on your
language) will be charged as several SMS. An MMS
message containing photos and/or sounds may also be
billed as more than one message. Specific letters
(accent) will increase the size of the SMS, this may
cause multiple SMS to be sent to your recipient.
6 Email .......................
Your phone has an email client with the settings pre-defined for a few
popular email services like – GoogleMail, Yahoo, AOL, etc. Besides
this, you can set up other POP3 or IMAP4 email accounts that you
may be using.
7 Palringo (1)
................
Palringo Instant messaging (IM) allows you to chat with other people
using Palringo account. You can also connect to other popular IM
services through Palringo, like Yahoo, AIM, GG, ICQ, GTalk, iChat
etc.
Please note that the services accessible to you will depend on your
client version and dynamic Palringo server options.
8 Contacts .................
8.1 Consulting your contacts
You can access to this function by selecting "Contacts" from the main
menu or widget bar.
8.2 Adding a contact
You can add a new contact to phone or SIM card by selecting
"Create new".
Birthday reminder
You can set a birthday reminder when editing contact information.
This will remind you at regular intervals during the day prior to the
set date.
9 Call log ....................
9.1 Access
You can access the function using the following options:
Select • from main menu
Press • key from Home screen
Select • from widget bar, and then enter the sub-menu you
require.
9.2 Available options
When you press "Options", you can have access to Send message,
Save to Contacts, Edit before call, Delete, etc.
9.2.1 Call settings (1)
You can access a number of items with this option: Call waiting,
Call forwarding, Call barring, Caller ID, Line switching, Auto
redial, etc.
10 Media applications .....
10.1 Music ................................................
You can access this feature from the main menu by selecting "Music"
or directly press from the Home screen.
You will have full flexibility of managing music both on your mobile
and SD card.
10.2 Image ..............................................
A library links to the images both in phone and SD card to be shown
in list, slide, set as wallpaper, power on/off display and incoming call
image or sent by MMS, Email, Bluetooth.
10.3 Video ..............................................
Contains all video clips both in phone and SD card and enables you to
play, send, set as power on/off display, delete, rename, sort, etc.
10.4 Radio ...............................................
Your phone is equipped with a radio (1) with RDS (2) functionality. You
can use the application as a traditional radio with saved channels or
with parallel visual information related to the radio program on the
display, if you tune to stations that offer Visual Radio service. You can
listen to it while running other applications.
11 Internet (3)
...................
11.1 Apps ...............................................
Apps is an online software store, where you can download and install
applications and games to your phone.
You can access to this function by selecting "Apps" from the main
menu.
11.2 Web .................................................
Web not only gives you the full Web experience where you stay in
touch with your friends, obtain information, do your online banking
etc., but also saves time by using compressed web pages.
11.3 WAP ................................................
Access WAP options: Homepage, Bookmarks, Go to URL, Open
file, Last web address, Recent pages, Offline pages, Service
inbox, Settings.
11.4 News ................................................
It is a huge time saver providing news updates from a website in a
simple form.
Once subscribed to a channel, it gives you the ability to track and
manage all your favorite RSS content on your mobile phone at
anytime, anywhere!
11.5 Weather ..........................................
Your phone is equipped with a weather function for consulting up to
3-day forecast of favorite cities.
11.6 Facebook .........................................
Facebook is a social utility that connects people with friends and
others who work, study and live around them. It provides a number of
features with which users may interact: Wall, a space on every user's
profile page that allows friends to post messages for the user to see;
Pokes, which allow users to send a virtual "poke" to each other; Gifts,
a feature allowing users to send virtual gifts which appear on the
recipient’s profile; Market places, which lets users post free classified
goods, etc.
To open an account online, please go to: http://www.facebook.com/.
11.7 mTweet ...........................................
Twitter is a social networking and microblogging service that has
gained notability and popularity worldwide. This feature enables phone
users to exchange news updates and ideas with a community in the
form of messages or posts. Posts are displayed on the author's profile
page and delivered to the author's subscribers or followers.
To open an account online, please go to: http://twitter.com/.
12 Entertainment ............
12.1 Stopwatch .....................................
The stopwatch is a simple application for measuring time with the
possibility to register several results and suspend/resume
measurement.
12.2 Ebook .............................................
A bookshelf contains the electronic books (.txt and .pdb file only).
While reading the book, you may add bookmark, or reach the text by
searching words, phrases (Options\Find, Options\Jump to).
12.3 Java ..................................................
Your Alcatel phone may include (1) some Java™ applications and games.
You can also download new applications and games to your phone.
13 Camera ................
Your mobile phone is fitted with a camera for taking photos and
shooting videos that you can use in different ways:
store them as your creations in SD card.•
send them in a multimedia message (MMS) to a mobile phone or •
an email address.
send them directly by Email or Bluetooth.•
customize your Home screen.•
select them as incoming call image to a contact in your Contacts.•
transfer them by data cable or microSD card to your computer.•
(1) Depending on your network operator.
English - CJB3251ALAAA
Prolonged exposure to music at full volume on the music player
may damage the listener's hearing. Set your phone volume safely.
Use only headphones recommended by TCT Mobile Limited
and its affiliates.
Quick Start Guide
For more information about how to use the phone, please go to
www.alcatelonetouch.com to download complete user manual.
Also on our website you can find helpful FAQs, realize software
upgrade, etc.
Table of contents
1 Your mobile ........................................................................................................3
2 Getting started ...................................................................................................8
3 Making a call ........................................................................................................9
4 Menu arrange .................................................................................................... 10
5 Messages............................................................................................................. 10
6 E-mail .................................................................................................................. 11
7 Palringo ...............................................................................................................12
8 Contacts .............................................................................................................12
9 Call log ................................................................................................................ 13
10 Media applications ............................................................................................ 13
11 Internet ............................................................................................................. 14
12 Entertainment ................................................................................................... 16
13 Camera ...............................................................................................................16
14 Profiles ................................................................................................................ 17
15 File manager ...................................................................................................... 17
16 Bluetooth
TM ....................................................................................................... 18
17 Others ................................................................................................................ 18
18 Settings ............................................................................................................... 20
19 Making the most of your mobile .................................................................. 20
20 Latin input mode ..............................................................................................22
870A
871S
14 Profiles ................
With this menu, you may personalize ringtones for different events
and environments.
15 File manager .......
You will have an access to all audio and visual files stored in phone or
SD card in File manager. You can access a number of items with this
option: My audios, My images, My videos, Ebook, My creations,
etc.
Inserting the SD card:
To release the microSD card holder, slide it in the direction of the
arrow and lift it. Then insert the microSD card with the golden
contact downward. Finally, turn down the microSD holder and slide it
in the opposite direction to lock it.
Prolonged exposure to music at full volume on the music player
may damage the listener's hearing. Set your phone volume safely.
Use only headphones recommended by TCT Mobile Limited and
its affiliates.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
All rights reserved © Copyright 2012
TCT Mobile Limited.
TCT Mobile Limited reserves the right to alter
material or technical specification without prior
notice.
Camera key
Micro-USB
connector
Headset connector
Vibration key
Left softkey
Status bar
Home screen
Send key
Email key
Right softkey
End key
Music key
Fn key
Voicemail key
Space key
Navigation key/
OK key
LED light
Shift key
Delete key
Enter key/Torch key
SYM key
16 Bluetooth™ .......
Access this feature by pressing "Menu" through Left softkey from
the Home screen to enter the main menu, then selecting
"Bluetooth".
17 Others ........................
17.1 Calendar .......................................
Once you enter this menu from main menu, there is a monthly-
view calendar for you to keep track of important meetings,
appointments, etc. Days with events entered will be marked in
color.
IP4145_870A_871S_QG_Eng_USA_05_120423.indd 1IP4145_870A_871S_QG_Eng_USA_05_120423.indd 1 2012-4-23 11:13:412012-4-23 11:13:41
19
28
20
29
21
30
22
31
23
32
24
33
25
34
26 27
3635
17.10 Torch ..............................................
Access the feature by selecting "Torch" from the main menu.
Torch provides a handy light source which you can turn on/off as
needed.
17.11 Zakat calculator ............................
Access the feature by selecting "Zakat calculator" from the main
menu.
You can easily calculate payable zakat with regard to cattle, minerals,
commodities, etc by inputting the total amount and confirming with
"OK".
18 Settings ..............
From the main menu, select the menu icon and select the function
of your choice in order to customize your telephone: Phone
settings, Call settings, Flight mode, Security, Networks,
Connectivity.
19 Making the most of
your mobile ................
PC suite
You can download PC Suite for free from the website (www.
alcatelonetouch.com). The PC suite includes:
• Backup/restore
You can backup the important data in your mobile and restore them
when needed.
• GPRS modem
Use your mobile phone to connect PC to the internet.
Safety and use .......................
We recommend that you read this chapter carefully before using your
mobile phone. The manufacturer disclaims any liability for damage,
which may result as a consequence of improper use or use contrary
to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a
vehicle constitutes a real risk, even when the hands-free kit is used
(car kit, headset...), drivers are requested to refrain from using their
mobile phone when the vehicle is not parked. Check the laws and
regulations on the use of wireless mobile phones and their accessories
in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas.
When driving, do not use your mobile phone and headphone to listen
to music or to the radio. Using a headphone can be dangerous and
forbidden in some areas.
When switched on, your mobile phone emits electromagnetic waves
that can interfere with the vehicle’s electronic systems such as ABS
anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your mobile phone on top of the dashboard or within
an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure
that the car’s electronic devices are shielded from mobile phone RF
energy.
• CONDITIONS OF USE:
You are advised to switch off the mobile phone from time to time to
optimize its performance.
Remember to abide by local authority rules of mobile phone use on
aircrafts.
Operational Warnings: Obey all posted signs when using mobile
devices in public areas.
Follow Instructions to Avoid Interference Problems: Turn off your
mobile device in any location where posted notices instruct you to do
so. In an aircraft, turn off your mobile device whenever instructed to
do so by airline staff. If your mobile device offers an airplane mode or
similar feature, consult airline staff about using it in flight.
Switch the mobile phone off when you are in health care facilities, except
in designated areas. As with many other types of equipment now in regular
use, mobile phones can interfere with other electrical or electronic devices,
or equipment using radio frequency.
Alcatel Mobile Phones
Limited Warranty ................
TCT Mobile North America LTD warrants to the original retail
purchaser of this wireless device, that should this product or part
thereof during normal consumer usage and condition, be proven to be
defective in material or workmanship that results in product failure
within the first twelve (12) months from the date of purchase as shown
on your original sales receipt. Such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the company’s option without charge for
parts or labor directly related to the defect(s).
Batteries, power adapters, and other accessories sold as in box items
are also warranted against defects and workmanship that results in
product failure within the first six (6) months period from the date of
purchase as shown on your original sales receipt. Such defect(s) will be
repaired or replaced (with new or rebuilt parts) and the company’s
option without charge for parts or labor directly related to the
defect(s).
The limited warranty for your wireless device will be voided if any of
the following conditions occur:
• Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area
where your mobile phone is used;
• Connection to any equipment not supplied or not recommended by
TCT Mobile;
• Modification or repair performed by individuals not authorized by TCT
Mobile or its affiliates;
• Acts of god such as Inclement weather, lightning, power surges, fire,
humidity, infiltration of liquids or foods, chemical products, download
of files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless devices event labels or serial
numbers (IMEI);
• Damage from exposure to water or other liquids, moisture, humidity,
excessive temperatures or extreme environmental conditions, sand,
excess dust and any condition outside the operating guidelines;
• Defects in appearance, cosmetic, decorative or structural items such as
framing and non-operative parts.
Hearing Aid Compatibility
Your mobile phone is rated: «For Hearing Aid», to assist hearing
device users in finding mobile phones that may be compatible with
their hearing devices.
This device is HAC M3 and T3 compatible.
For more information please refer to «Hearing Aid Compatibility with
Mobile Phones» leaflet or visit our website http://www.
alcatelonetouch.com
General information .......
• Website: www.alcatelonetouch.com
• Facebook: http://www.facebook.com/alcatelonetouchusa
• Twitter: http://www.twitter.com/alcatel1touch
• Hot Line Number: In the United States, call 877-702-3444 for
technical support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.com
Your cellphone is a transceiver that operates on following networks:
one touch 870A: GSM in quad-band (850/900/1800/1900 MHz) or UMTS in
tri-band (850/1900/2100 MHz)
one touch 871S: GSM in quad-band (850/900/1800/1900MHz) or UMTS in
tri-band (850/1700/2100 MHz)
Protection against theft (1)
Your mobile phone is identified by an IMEI (mobile phone serial
number) shown on the packaging label and in the product’s memory.
We recommend that you note the number the first time you use your
mobile phone by entering *#06# and keep it in a safe place. It may be
requested by the police or your operator if your mobile phone is
stolen.
Disclaimer
There may be certain differences between the user manual description
and the mobile phone’s operation, depending on the software release
of your mobile phone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if
any, nor for their potential consequences, which responsibility shall be
borne by the operator exclusively.
As mobile devices offer a range of functions, they can be used in
positions other than against your ear. In such circumstances the device
will be compliant with the guidelines when used with headset or usb
data cable. If you are using another accessory ensure that whatever
product is used is free of any metal and that it positions the mobile
phone at least 1,5 cm away from the body..
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by TCT
Mobile Limited and its affiliates is under license. Other
trademarks and trade names are those of their
respective owners.
one touch 870A/ one touch 871S
Bluetooth QD ID B018931
Java™ and all Java™ based trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
is a registered trademark of Opera Mini.
Facebook and the f Logo are trademarks of Facebook,
Inc., and are used under license.
Twitter and the T Logo are trademarks of Twitter, Inc.,
and are used under license.
Switch the mobile phone off when you are near gas or flammable
liquids. Strictly obey all signs and instructions posted in a fuel depot,
gas station, or chemical plant, or in any potentially explosive
atmosphere.
When the mobile phone is switched on, it should be kept at least 15
cm from any medical device such as a pacemaker, a hearing aid or
insulin pump. In particular when using the mobile phone you should
hold it against the ear on the opposite side to the device, if any.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using your
mobile device with your implantable medical device, consult your
healthcare provider.
To avoid hearing impairment, answer the call before holding your
mobile phone to your ear. Also move the handset away from your ear
while using the “hands-free” option because the amplified volume
might cause hearing damage.
It is recommended to have proper supervision while small children use
your mobile phone.
When replacing the cover please note that your mobile phone may
contain substances that could create an allergic reaction.
Always handle your mobile phone with care and keep it in a clean and
dust-free place.
Do not allow your mobile phone to be exposed to adverse weather
or environmental conditions (moisture, humidity, rain, infiltration of
liquids, dust, sea air, etc.). The manufacturer’s recommended operating
temperature range is -10°C (14°F) to +55°C (131°F) (the max value
depends on device, materials and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s display may be
impaired, though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are
recommended by TCT Mobile Limited and its affiliates and are
compatible with your mobile phone model.TCT Mobile Limited and its
affiliates disclaim any liability for damage caused by the use of other
chargers or batteries.
Your mobile phone should not be disposed of in a municipal waste.
Please check local regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all
important information stored in your mobile phone.
There are no express warranties, whether written, oral or implied,
other than this printed limited warranty or the mandatory warranty
provided by your jurisdiction. In no event shall TCT Mobile or any of its
affiliates be liable for incidental or consequential damages of any nature
whatsoever, including but not limited to commercial loss, to the full
extent those damages can be disclaimed by law. Some states do not
allow the exclusion or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties, so the preceding
limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer care center by calling
(877-702-3444) or going to www.alcatelonetouch.com. We have placed
many self-help tools that may help you to isolate the problem and
eliminate the need to send your wireless device in for service. In the
case that your wireless device is no longer covered by this limited
warranty due to time or condition we have other options that you may
utilize our out of warranty repair options.
To obtain hardware repairs or replacement within the terms of this
warranty, contact TCT Mobile to get an RMA number, include a copy
of the original proof of warranty coverage (e.g. original copy of the
dated bill of sale, invoice), the consumer’s return address, your wireless
carrier’s name, alternate daytime mobile phone number, and email
address with a complete problem description. Only ship the wireless
device. Do not ship the SIM card, memory cards, or any other
accessories such as the power adapter. You must properly package and
ship the wireless device to the repair center.
TCT Mobile is not responsible for wireless devices that do not arrive at
the service center. Upon receipt, the service center will verify the
warranty conditions, repair, and return your wireless device to the
address provided.
Some people may suffer epileptic seizures or blackouts when exposed
to flashing lights, or when playing video games. These seizures or
blackouts may occur even if a person never had a previous seizure or
blackout. If you have experienced seizures or blackouts, or if you have
a family history of such occurrences, please consult your doctor
before playing video games on your mobile phone or enabling a
flashing-lights feature on your mobile phone. Parents should monitor
their children’s use of video games or other features that incorporate
flashing lights on the mobile phones. All persons should discontinue
use and consult a doctor if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such
symptoms, please take the following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may experience
occasional discomfort in your hands, arms, shoulders, neck, or other parts
of your body. Follow these instructions to avoid problems such as
tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after
playing, stop the game and see a doctor.
Prolonged exposure to music at full volume using the music player
may damage your hearing. Set your mobile phone’s volume to it’s
lowest setting prior to inserting headphones in your ears and
adjust the volume to your preference. Only use headphones that
are recommended by TCT Mobile Limited and it’s affiliates.
• PRIVACY:
Please note that you must respect the laws and regulations in force in
your jurisdiction or other jurisdiction(s) where you will use your
mobile phone regarding taking photographs and recording sounds with
your mobile phone. Pursuant to such laws and regulations, it may be
strictly forbidden to take photographs and/or to record the voices of
other people or any of their personal attributes, and reproduce or
distribute them, as this may be considered to be an invasion of
privacy.
It is the user’s sole responsibility to ensure that prior authorization be
obtained, if necessary, in order to record private or confidential
conversations or take a photograph of another person; the
manufacturer, the seller or vendor of your mobile phone (including
the operator) disclaim any liability which may result from the improper
use of the mobile phone.
Troubleshooting ...............
Before contacting the service center, you are advised to follow the
instructions below:
You are advised to fully charge ( • ) the battery for optimal
operation.
Avoid storing large amounts of data in your phone as this may affect •
its performance.
Use User Data Format and the one touch Upgrade tool to perform •
phone formatting or software upgrading, (to reset User Data
format, hold down # while simultaneously pressing the power on/
off key). ALL User phone data: contacts, photos, messages and files,
downloaded applications like Java games will be lost permanently. It
is strongly advised to fully backup the phone data and profile via PC
suite before doing formatting and upgrading.
and carry out the following checks:
My phone is frozen or cannot switch on
Check the battery contacts, remove and reinstall your battery, then •
turn your phone on
Check the battery power level, charge for at least 20 minutes•
If it still does not work, please use User Data Format to reset •
the phone
My phone has not responded for several minutes
Restart your phone by pressing and holding the • key
Remove the battery and re-insert it, then restart the phone•
My phone turns off by itself
Check whether your phone is locked when not in use, and make sure •
you don't accidentally turn off your phone when locking it by pressing
the power key.
Check the battery charge level•
My phone cannot charge properly
Make sure you are using an Alcatel battery and the charger from •
the box
Make sure your battery is inserted properly and clean the battery •
contact if it’s dirty. It must be inserted before plugging in the
charger
Make sure that your battery is not completely discharged; if the •
battery power is empty for a long time, it may take around 20
minutes to display the battery charger indicator on the screen.
• BATTERY AND ACCESSORIES:
Before removing the battery from your mobile phone, please make
sure that the mobile phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes
and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it
at temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for
which it was designed. Never use damaged batteries or those not
recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your mobile phone, the battery and the
accessories means that these products must be taken
to collection points at the end of their life:
- Municipal waste disposal centers with specific bins
for these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in
the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with
this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary
bins if your jurisdiction or your region has suitable recycling and
collection facilities; instead they are to be taken to collection points
for them to be recycled.
In the United States you may learn more about CTIA’s Recycling
Program at www.recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range
of: 0°C (32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the standard
for safety of information technology equipment and office equipment
use. Due to different applicable electrical specifications, a charger you
purchased in one jurisdiction may not work in another jurisdiction.
They should be used for this purpose only.
Make sure charging is carried out under normal conditions (0°C •
to +40°C)
When abroad, check that the voltage input is compatible•
My phone cannot connect to a network or “No service” is
displayed
Try connecting in another location•
Verify the network coverage with your operator•
Check with your operator that your SIM card is valid•
Try selecting the available network(s) manually •
Try connecting at a later time if the network is overloaded•
My phone cannot connect to the Internet
Check that the IMEI number (press *#06#) is the same as the one •
printed on your warranty card or box.
Make sure that the internet access service of your SIM card is •
available.
Check your phone's Internet connecting settings•
Make sure you are in a place with network coverage•
Try connecting at a later time or another location•
Invalid SIM card
Make sure the SIM card has been correctly inserted •
Make sure the chip on your SIM card is not damaged or scratched•
Make sure the service of your SIM card is available•
Unable to make outgoing calls
Make sure you have dialed a valid number and press • key
For international calls, check the country and area codes•
Make sure your phone is connected to a network, and the network •
is not overloaded or unavailable
Check your subscription status with your operator (credit, SIM •
card valid, etc.)
Make sure you have not barred outgoing calls•
Make sure that your phone is not in flight mode•
Unable to receive incoming calls
Make sure your phone is switched on and connected to a network •
(check for overloaded or unavailable network)
Check your subscription status with your operator (credit, SIM •
card valid, etc.)
Make sure you have not forwarded incoming calls •
Make sure that you have not barred certain calls•
Make sure that your phone is not in flight mode•
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.15 A
Output: 5 V, 550 mA
Battery: Lithium 850 mAh
• RADIO WAVES:
THIS MOBILE PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radio-frequency (RF) energy. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that were
developed by independent scientific organizations through periodic
and thorough evaluation of scientific studies. These guidelines
include a substantial safety margin designed to ensure the safety of
all persons, regardless of age and health.
The exposure standard for mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by public authorities such as the Federal
Communications Commission of the US Government (FCC), or by
Industry Canada, is 1.6 W/kg averaged over 1 gram of body tissue.
Tests for SAR are conducted using standard operating positions
with the mobile phone transmitting at its highest certified power
level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the mobile phone while operating can be well below
the maximum value. This is because the mobile phone is designed to
operate at multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the mobile phone.
Before a mobile phone model is available for sale to the public,
compliance with national regulations and standards must be shown.
The
highest SAR value for this model mobile phone when tested is 1.19
W/Kg (one touch 870A), 1.15 W/Kg (one touch 871S) for use at the
ear and 1.03 W/Kg (one touch 870A), 1.09 W/Kg (one touch 871S)
for use close to the body. While there may be differences between
the SAR levels of various mobile phones and at various positions,
they all meet the government requirement for RF exposure. For
body-worn operation, the mobile phone meets FCC RF exposure
guidelines provided that it is used with a non-metallic accessory with
the handset at least 1,5 cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site: http://
www.phonefacts.net
The caller’s name/number does not appear when a call is
received
Check that you have subscribed to this service with your operator•
Your caller has concealed his/her name or number•
I cannot find my contacts
Make sure your SIM card is not broken•
Make sure your SIM card is inserted properly•
Import all contacts stored in SIM card to phone•
The sound quality of the calls is poor
You can adjust the volume during a call by pressing the navigation •
key
Check the network strength •
Make sure that the receiver, connector or speaker on your phone •
is clean
I am unable to use the features described in the manual
Check with your operator to make sure that your subscription •
includes this service
Make sure this feature does not require an Alcatel accessory•
When I select a number from my contacts, the number
cannot be dialed
Make sure that you have correctly recorded the number in your •
file
Make sure that you have selected the country prefix when calling •
a foreign country
I am unable to add a contact in my contacts
Make sure that your SIM card contacts are not full; delete some •
files or save the files in the phone contacts (i.e. your professional or
personal directories)
My callers are unable to leave messages on my voicemail
Contact your network operator to check service availability•
I cannot access my voicemail
Make sure your operator’s voicemail number is correctly entered •
in "My numbers"
Try later if the network is busy•
I am unable to send and receive MMS
Check your phone memory availability as it might be full•
Contact your network operator to check service availability and •
check MMS parameters
• Multimedia Personalization
Customize your mobile with images, animations and melodies.
• Messages
You can compose SMS/MMS easily on your PC and transfer them to
your phone.
Supported Operating Systems
Windows XP/Vista/Windows 7.
One touch Upgrade
Using One Touch Upgrade tool you can update your phone’s software
from your PC.
Download One Touch Upgrade from ALCATEL website (www.
alcatelonetouch.com) and install it on your PC. Launch the tool and
update your phone by following the step by step instructions (refer to
the User Guide provided together with the tool).
Your phone’s software will now have the latest software.
All personal information will be permanently lost
following the update process. We recommend you
backup your personal data using PC Suite before
upgrading.
Supported Operating Systems
Windows XP/Vista/Windows 7.
Webcam (1)
You can use your phone as a webcam for instant messaging on your
PC.
• Connect your phone to PC via USB cable.
• Go to "My computer" folder on your PC and find USB video device
(Under Scanners & Cameras).
(1) The using of webcam may vary according to the operating system of your
PC.
20 Latin input mode .......
There are two text entry methods that can be used to write
messages:
- Normal: this mode allows you to type a text by choosing a letter or
a sequence of characters associated with a key.
- CooTek mode: this mode can perform predictive input in hardware
keypad and supports multi-language input.
Keypad inputting:
: Switch between ABC/abc/Abc
: Press once: Input a top-half character
Press twice: Lock the keyboard in top-half key input
mode
Press and hold: Input top-half characters only until key
is released
: Press: Delete one by one
Press and hold: Delete all
: Press: Enter a space (on edit mode)
Confirm an option (on edit mode)
Unlock the keypad (on Home screen)
Press and hold: Access language list (on edit mode)
Lock the keypad (on Home screen)
Hold down Fn key, then press Space key to select
input method
: Press: Confirm an option
Enter the next line (on edit mode)
Press and hold: Turn on/off torch (on Home screen)
: Enter symbol table
Hold down Fn key, then press SYM key to enter
emotion table
The World Health Organization (WHO) considers that present
scientific information does not indicate the need for any special
precautions for use of mobile phones. If individuals are concerned,
they might choose to limit their own or their children’s RF
exposure by limiting the length of calls, or using “hands-free”
devices to keep mobile phones away from the head and body. (fact
sheet n°193). Additional WHO information about electromagnetic
fields and public health are available on the following website: http://
www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
For the receiver devices associated with the operation of a licensed
radio service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For optimal
operation, you should avoid touching it or degrading it.
Verify the server center number or your MMS profile with your •
operator
The server center may be swamped, try again later•
The flickering icon is displayed on my standby screen
You have saved too many short messages on your SIM card; delete •
some of them or archive them in the phone memory
SIM card PIN locked
Contact your network operator to obtain the PUK code (Personal •
Unblocking Key)
I am unable to connect my phone to my computer
Install Alcatel’s PC suite first of all•
Check that your computer meets the requirements for Alcatel’s •
PC Suite installation
Make sure that you’re using the right cable from the box.•
I am unable to download new files
Make sure there is sufficient phone memory for your download•
Select the Micro-SD card as the location to store downloaded •
files
Check your subscription status with your operator•
The phone cannot be detected by others via Bluetooth
Make sure that Bluetooth is turned on and your phone is visible •
to other users
Make sure that the two phones are within Bluetooth’s detection •
range
How to make your battery last longer
Make sure you follow the complete charge time (minimum 3 •
hours)
After a partial charge, the battery level indicator may not be exact. •
Wait for at least 20 minutes after removing the charger to obtain
an exact indication
Switch on the backlight upon request.•
Extend the email auto-check interval for as long as possible.•
Update news and weather information on manual demand, or •
increase their auto-check interval.
Exit background-running Java applications if they are not being •
used for a long time.
Deactivate Bluetooth when not in use.•
17.2 Calculator .....................................
Access this feature by selecting "Calculator" from the main menu.
Enter a number, select the type of operation to be performed using
the navigation keys, and enter the second number, then select "="
to display the result.
17.3 Notes ............................................
You can create a note in text format by accessing “Notes” from
the main menu.
17.4 Sound recorder .............................
Accessing "Sound recorder" from the main menu allows you to
make voice or sound recordings.
17.5 Tasks .............................................
Enables you to easily manage and track the progress of a task with
priorities. All the tasks will be sorted by due date.
17.6 Alarm ...........................................
Your mobile phone has a built-in alarm clock with a snooze feature.
17.7 World clock .................................
The World clock shows current local time and the time zone in
different cities.
17.8 Converter ...................................
You can use the Weight and Length conversion by selecting the unit
you wish to convert, then press to input the digits. Finally confirm
with "OK".
17.9 Currency converter .....................
You can easily calculate foreign values by setting the currency rate
you wish to convert, then inputting the local value. Finally confirm
with "OK".
(1) Contact your network operator for service availability.
IP4145_870A_871S_QG_Eng_USA_05_120423.indd 2IP4145_870A_871S_QG_Eng_USA_05_120423.indd 2 2012-4-23 11:13:442012-4-23 11:13:44
