Welcome!ThismanualbriefistheprofileofyourHSPAUSB‐Modem,aboutthedetailsofthemanagement

program(Dashboard)andsafetyusing,pleasereferstoappropriateUserManual.Whenyouclick“”onthe

Dashboard,theUserManualwillbedisplayed.

1.GettingtoKnowYourModem

1. USBInterface



2. SIM/USIMCardSlot



3. Micro‐SDCardSlot



4. StrapHole



5. IndicatorLED

2.Howtostartyourmodem



Note:

1. YoucangetdetailinstallationguideinformationinUserManual(PDFversion).Oncesoftwarehasbeen

installed,theHSPAUSBmodemwillstartautomatically.Ifinstallation“auto‐run”doesnotbegin,youwill

needtoDouble‐Clickthe“”iconindevicepathof“MyComputer”toruntheinstallation

manually.



3.LEDIndicates

(FollowingtablearelistedtheLEDIndicatesforeachstatus.)

LEDIndicator Description

FlashingGreen&RedmulticolorcircularlyNetworkSearching

InsertSIMcard

Intomodem

Pluginto

computer

Followonscreen

InstallationSW



Ready!

Let’sGO!!!

QuicklyFlashingGreen&RedmulticolorcircularlyOutoforder

GreenLightSlowFlashing RegisteringintoHSPAorUMTSnetwork

ConstantGreenLight RegisteredtoHSPAorUMTSnetwork

RedLightSlowFlashing RegisteringintoGPRSorEDGEnetwork

ConstantRedLightRegisteredtoGPRSorEDGEnetwork



4.SafetyandUse

WerecommendthatyoureadthischaptercarefullybeforeusingtheHSPAUSB‐Modem.Themanufacturer

disclaimsanyliabilityfordamage,whichmayresultasaconsequenceofimproperuseoftheHSPAUSB‐Modem

orofusecontrarytotheinstructionscontainedherein.



TrafficSafety

Whendriving,donotusetheHSPAUSB‐Modem

 Whenswitchedon,theHSPAUSB‐Modememitselectromagneticwavesthatcaninterferewiththe

vehicle’selectronicsystemssuchasABSanti‐lockbrakesorairbags.Toensurethatthereisnoproblem,do

notplacetheHSPAUSB‐Modemontopofthedashboardorwithinanairbagdeploymentarea.

 Checkwithyourcardealerorthecarmanufacturertomakesurethatthedashboardisadequatelyshielded

frommodemRFenergy.



ConditionsofUse

 SwitchtheHSPAUSB‐Modemoffbeforeboardinganaircraft.

 SwitchtheHSPAUSB‐Modemoffwhenyouareinhealthcarefacilities,exceptindesignatedareas.Aswith

manyothertypesofequipmentnowinregularuse,theHSPAUSB‐ caninterferewithotherelectricalor

electronicdevices,orequipment‐usingradiofrequencies.

 SwitchtheHSPAUSB‐Modemoffwhenyouareneargasorflammableliquids.Strictlyobeyallsignsand

instructionspostedinafueldepot,petrolstation,chemicalplant,orinanypotentiallyexplosiveatmosphere.

 WhentheHSPAUSB‐Modemisswitchedon,itshouldbekeptatleast15cmfromanymedicaldevicesuchas

apacemaker,ahearingaidorinsulinpump,etc.

 DonotletchildrenusetheHSPAUSB‐Modemwithoutsupervision.

 Whenreplacingthecover,pleasenotethattheHSPAUSB‐Modemmaycontainsubstancesthatcouldcreate

anallergicreaction.

 AlwayshandletheHSPAUSB‐Modemwithcareandkeepitinacleananddust‐freeplace.

 DonotallowtheHSPAUSB‐Modemtobeexposedtoadverseweatherorenvironmentalconditions

(moisture,humidity,rain,infiltrationofliquids,dust,seaair,etc).Themanufacturer’srecommended

operatingtemperaturerangeis‐10°Cto+50°C.

 Donotopen,dismantleorattempttorepairtheHSPAUSB‐Modemyourself.

 Donotdrop,throworbendtheHSPAUSB‐Modem.

 Donotpaintit.



WEEEApproval

TheHSPAUSB‐Modemisincompliancewiththeessentialrequirementsandotherrelevantprovisionsofthe

WasteElectricalandElectronicEquipmentDirective2002/96/EC(WEEEDirective).



RoHsApproval

TheHSPAUSB‐Modemisincompliancewiththerestrictionoftheuseofcertainhazardoussubstancesin

electricalandelectronicequipmentDirective2002/95/EC(RoHsDirective).



RadioWaves

Proofofcompliancewithinternationalstandards(ICNIRP)(1)orwithEuropeanDirective1999/5/EC(R&TTE)is

requiredofallmodemmodelsbeforetheycanbeputonthemarket.Theprotectionofthehealthandsafetyfor

theuserandanyotherpersonisanessentialrequirementofthesestandardsorthisdirective.

ThisHSPAUSB‐MODEMcomplieswithinternationalandEuropeanrequirementsregardingexposuretoradio

waves

TheHSPAUSB‐Modemisaradiotransmitter/receiver.Itwasdesignedandmanufacturedtocomplywiththe

radiofrequency(RF)exposurethresholdsrecommendedbyinternationalrequirements(ICNIRP)andbythe

CounciloftheEuropeanUnion(Recommendation1999/519/EC)(2).

Theselimitsarepartofasetofrequirementsandestablishauthorizedradiofrequencylevelsforthepublic.These

limitswereestablishedbyindependentgroupsofexpertsonthebasisofregularanddetailedscientific

assessments.Theyincludeasignificantsafetymarginintendedtoensurethesafetyofall,regardlessofageor

stateofhealth.

TheexposurestandardformodemsisdeterminedbyameasurementunitknownastheSpecificAbsorptionRate

or“SAR”.TheSARlimitissetbyinternationalrequirementsorbytheCounciloftheEuropeanUnionat2

watts/kilogram(W/kg)averagedover10gramsofbodytissue.

ThetestsusedtodetermineSARlevelswerecarriedoutonthebasisofstandardusagemodeswiththemodems

phonestransmittingattheirmaximumpowerlevelovertheentirerangeoffrequencybands.

AlthoughtheSARwasestablishedatthehighestcertifiedlevel,theactualSARlevelforthemodemsduringuseis

generallymuchlowerthanthemaximumvalues.Infact,sincemodemsaredesignedtooperateatmany

differentpowerlevels,theyonlyusetheminimumlevelofpowerrequiredtoprovideaconnectiontothe

network.Intheory,thecloseryouaretoabasestationantenna,thelowerthepowerlevelrequiredbythe

modem.



(1)TheICNIRPrequirementsareapplicableinthefollowingregions:CentralAmerica(exceptMexico),SouthAmerica,Northand

SouthAfrica,PacificAsia(exceptKorea),Australia.

(2)TheEuropeanrecommendation(1999/519/EC)isapplicableinthefollowingregions:Europe,Israel.



ThehighestSARvaluereportedunderthisstandardduringproductcertificationforusewhenproperlywornon

thebodyis0.783W/kg.



Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwoconditions:(1)this

devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.



NOTE:ThemanufacturerisnotresponsibleforanyradioorTVinterferencecausedbyunauthorized

modificationstothisequipment.Suchmodificationscouldvoidtheuser’sauthoritytooperatetheequipment.



NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant

topart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful

interferenceinaresidentialinstallation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.If

thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby

turningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:

‐Reorientorrelocatethereceivingantenna.

‐Increasetheseparationbetweentheequipmentandreceiver.

‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp



TheWorldHealthOrganization(WHO)considersthatpresentscientificinformationdoesnotindicatetheneed

foranyspecialprecautionsforuseofmodems.Ifindividualsareconcerned,theymightchoosetolimittheirown

ortheirchildren’sRFexposurebylimitingthelengthofcalls,orusing“hands‐free”devicestokeepmodems

awayfromtheheadandbody(factsheetn°193).Additionalinformationaboutelectromagneticfieldsandpublic

healthareavailableonthefollowingsite:http://www.who.int/peh‐emf.

Althoughnodangerrelatingtotheuseofmodemswaseverproved,theWorldHealthOrganizationadvisesasa

precautionarymeasuretousemodemswithagoodlevelofnetworkreceptionasindicatedontheHSPA

USB‐Modemsoftwaredisplay(4to5bars).Itisalsoadvisedtokeepthemodem,duringcommunications,away

fromthebellyofpregnantwomenandfromthelowerabdomenforteenagers.

TheHSPAUSB‐Modemisequippedwithabuilt‐inantenna.Foroptimaloperation,youshouldavoidtouchingitor

degradingit.



Thisequipmentisincompliancewiththeessentialrequirementsandother

relevantprovisionsofDirective1999/5/EC.TheentirecopyoftheDeclarationof

Conformityforyourtelephonecanbeobtainedthroughour

Website:www.alcatelonetouch.com.


