TCT Mobile 298 GSM MOBILE PHONE User Manual
TCT Mobile Limited GSM MOBILE PHONE
User Manual
User Manual
1.1
One touch 639D
2.1
1 Your mobile…………………………………………………………………………………...x
2 Getting started……………………………………………………………………………….x
3 Making a call………………………………………………………………………………....x
4 mTweet……………………………………………………………………………………….x
5 Audio Player………………………………………………………………………………….x
6 Video Player………………………………………………………………………………….x
7 Image Browser…………………………………………………………………..………….x
8 Facebook…………………………………………………………………………………….x
9 Messages………………………..………………………………………………………..….x
10 Contacts………………………………………………………….…………………….…….x
11 Call Center………………………………………………………………………………..….x
12 Camera……………………………………………………………………………………….x
13 TV………………………….………………………………………………………………….x
14 WLAN……………………………………………………………………………………...…x
15 Bluetooth……………………………………………………………………………………..x
16 Settings……………………………………………………………………………………….x
17 Profiles……………………….……………………………………………………………….x
18 File Manager………………………………………………………………………………....x
19 Email………………………………………………………………………………………….x
20 Opera…………………………………………………………………………………………x
21 WAP…………………………………………………………………………………………..x
22 Yahoo Weather…………………...………………………………………………………….x
23 Apps…………………………………………………………………………………………..x
24 Java…………………………………………………………………………………………..x
25 Services……………………………………………………………………………………...x
26 World Clock…………………………………………………………………………………..x
27 Tasks………………………………………………………………………………………….x
28 Alarm………………………………………………………………………………………….x
29 Calculator…………………………………………………………………………………….x
30 Ebook Reader……………………..………………………………………………………...x
31 Unit Converter…………………………………………………………………………….….x
32 FM Radio…………...………………………………………………………………………...x
33 Sound Recorder……………………...……………………………………………………...x
34 Calendar………………………………………………………………………………..…….x
35 Stopwatch…………………………………………………………………………………….x
36 Torch…………………………………………………………………………………………..x
37 Latin input mode……………………………………………………………………..………x
2.2
3.1
4.1
• Press to go left/right/up/down
• Select the widgets list on the screen (Press the left or right key)
• Adjust volume during a call (Press up or down key)
• Press to confirm an option (Press the middle of the key)
• Pick up/Send a call
• View call records
• Press once: End a call
Return to the Home screen
• Press and hold: Power on/off
Left soft key
Right soft key
• Vibration alert
• Press and hold: Access your voicemail
• Press once: Input a capital letter
• Press twice: Lock the keypad in capital letter input mode
• Press once: Input a top-half key character
• Press twice: Lock the keypad in top-half key input mode
• Press once: Enter a space and confirm an option ( on edit mode)
• Hold down Fn key, then press Space key to switch input mode
• Press and hold: Lock keypad
• Press to enter Facebook main menu
• Enter symbol list
• Enter the next line (on edit mode)
• Press once: Delete entered character
• Press and hold: Delete all entered characters
1.2 Status bar icons (1)
Level of network reception
Flight mode activated
SMS unread
MMS unread
Sending or receiving MMS
Music is playing
General profile activated
Silence profile activated
Meeting profile activated
Outdoor profile activated
Headset connected
Alarm clock activated
Stopwatch is active
Bluetooth activated
WLAN activated
Missed calls
Call divert activated
/ Java activated
Keypad is locked
Batter charge level
SD card inserted
GPRS connection status (Activated)
(1) The icons and illustrations in this guide are provided for informational purposes only.
1.3 Home screen
You can customize your Home screen by select “Phone settings” in Settings menu.
1.3.1 Widget bar
Widgets are convenient shortcuts for quick access from the Home screen.
1.3.2 Change wallpaper
You can select a System or User defined images as favorite wallpaper by select
“Wallpaper”.
8.1
8.2
Inserting and removing the SD card:
To release the microSD card holder, slide it in the direction of the arrow and lift it. Then
insert the microSD card with the golden contact downward. Finally, turn down the microSD
holder and slide it in the opposite direction to lock it.
8.3
9.1
9.2
9.3
9.4
Dial the desired number then press the key and select SIM1/2 voice call to place the
call. The number you entered can be saved to Contacts by selecting “Save to
Phonebook”. If you make a mistake, you may press key or key (Clear) to
delete the incorrect digits one by one, or you may press and hold key (Clear) to
delete all.
To hang up the call, press the key.
10.1
4 mTweet…………………………………………….………………………...
Twitter is a social networking and microblogging service that has gained notability and
popularity worldwide. This feature enables phone users to exchange news updates and
ideas with a community in the form of messages or posts. Posts are displayed on the
author's profile page and delivered to the author's subscribers or followers. To open an
account online, please go to: http://m.twitter.com.
5 Audio Player……………………………………………………………..….
You can access this feature from the main menu by select “Audio Player”.
You will have full flexibility or managing music on your SD card.
6 Video Player…………………………………………...……………………
Contains all video clips on SD card and enables you to play, send, rename, delete, or sort
by.
7 Image Browser……………………………………………………………..
A library links to the images in “Photos” on SD card and can select to view, check image
information, set browse style, send, to use as (wallpaper, power on/off display), rename,
delete, sort by, or choose storage.
8 Facebook……………………………………………………………………
Facebook is a social utility that connects people with friends and others who work, study
and live around them. You can select “Facebook” in main menu or press key on the
keypad to enter the Facebook page.
9 Messages………………………………………………………………..…..
9.1 Access
You may access this menu by using the following options:
Access from the main menu by selecting “Messages”.
Select from widget bar, and then enter the sub-menu you require.
9.2 Write message
You can select “Messages\Write message” from the main menu and then select Text
message to write text message. One or more recipients can be added from phonebook or
input manually.
Select “Messages\Write message\Multimedia message” to write multimedia message.
You can add images, videos, audio or other attachments to the message.
An SMS message of more than a certain number of characters (the number of
characters depends on your language) will be charged as several SMS. An MMS
message containing photos and/or sounds may also be billed as more than one
message. Specific letters (accent) will increase the size of the SMS, this may cause
multiple SMS to be sent to your recipient.
10 Contacts……………………………………………………………………
10.1 Consulting your phonebook
You can access to this function by selecting “Contacts” from the main menu.
10.2 Adding a contact
You can add a new contact to phone or SIM card by select “Add new contact”.
11 Call Center…………………………………………………………………
11.1 Call logs
11.1.1 Access
You can access the function by using the following options:
Select from main menu
Press key from Home screen
11.1.2 Available options
When you press “Options”, you can have access to View, Call, Send text message,
Send multimedia message, Save to Phonebook, Edit before call, and Delete.
The operations for Missed calls, Dialled calls, Received calls are the same.
You can also select to Delete call logs and check Call timers.
11.2 Call settings
Set call waiting, call divert, call barring, and line switching for SIM1/2 call settings, and set
auto redial, IP dial, call time reminder, and answer mode for Advanced settings.
12 Camera……………………………………………………………………..
Your mobile phone is fitted with a camera for taking photos and shooting videos that you
can use in different ways:
Store them in your “File Manager\Photos (Videos)”.
Send them directly as multimedia message, Email, or via Bluetooth.
Customize your Home screen.
Select them as power on/off display.
Transfer them by data cable or SD card to your computer.
13 TV………………………………………………………………..………….
You can use your phone as a mobile terminal to watch TV programs. Select “TV” in main
menu and then select location. When the phone completes scanning, you can change
channels to watch programs.
14 WLAN……………………………………………………………………….
To access this function, enter the main menu and select . Your phone will
automatically search available networks. When link to an available network, you may
need to input password.
15 Bluetooth…………………………………………………………………..
By using the Bluetooth function, you can synchronize data between a PC and your phone,
exchange data with other Bluetooth devices, and connect a Bluetooth headset to your
phone.
16 Settings…………………………………………………………………….
From the main menu, select the menu icon and select the function of your choice in
order to customize your telephone: Dual SIM settings, Phone settings, Network
settings, Security settings, Connectivity, and Restore factory settings.
17 Profiles……………………………………………………………………..
With this menu, you may personalize ringtones or vibration for different events and
environments.
18 File Manager………………………………………………………………
You will have an access to all audio and visual files, images, or other files stored on SD
card in File Manager.
19 Email………………………………………………………………………..
Your phone has an email client with the settings pre-defined for a few popular email
services link – Gmail, Yahoo, Hotmail, etc. Besides this, you can set up other POP3 or
IMAP4 email accounts that you may be using.
20 Opera……………………………………………………………………….
You can use Opera Mini to browse WAP pages.
21 WAP…………………………………………………………………………
21.1 Internet service
Access WAP options: Homepage, Bookmarks, Search or input URL, Recent pages,
and Settings.
21.2 SIM service
The SIM Tool Kit (STK) function is a value-added service provided by your service
provider; you can use it to send text messages, view news, and use other applications.
For more information, contact your service provider.
22 Yahoo Weather………………………………………………………...….
Input location and press “Options\Search” to consult up the forecast of favorite cities.
23 Apps………………………………………………………...……………...
Apps store is an online software store, where you can download and install applications
and games to your phone.
24 Java……………………………………………………………………...….
Your phone includes some Java TM applications and games. You can also download new
applications and games to your phone.
25 Services……………………………………………………………………
You can select My One Touch to connect the WAP page and use the services.
26 World clock………………………………………………………………..
The World clock shows current local time and the time zone in different cities.
27 Tasks……………………………………………………………………..…
Enables you to easily manage and track the progress of a task with priorities. All the tasks
will be sorted by due date.
28 Alarm…………………………………………………………………….…
Your mobile phone has several built-in alarm clocks with a snooze feature.
29 Calculator……………………………………………………………….…
Access this feature by selecting “Calculator” from the main menu. Enter a number, select
the type of operation to be performed using the keys, and enter the second number,
then press key to display the result.
30 Ebook Reader……………………………………………………………..
A bookshelf contains the electronic books (.txt file only). While reading the book, you may
add bookmark, or reach the text you want.
31 Unit Converter…………………………..………………………………
You can use the Weight and Length conversion by selecting the unit you wish to convert,
and then press to input the digits. Finally confirm with key (OK) or key.
32 FM Radio…………………………..………………………..……………
Your phone is equipped with a radio (1). You can use the application as a traditional radio
with saved channels. You can listen to it while running other applications.
(1) The quality of the radio depends on the coverage of the radio station in that particular
area.
33 Sound Recorder………………………………………………………...
The sound recorder functions as a digital recorder.
34 Calendar………………………………………………………………...…
Once you enter this menu from main menu, there is a monthly-view calendar for you to
keep track of important meetings, course, etc. Days with events entered will be marked in
color.
35 Stopwatch……………………………………………….……………...…
The stopwatch is a simple application for measuring time with the possibility to register
several results and suspend/resume measurement.
36 Torch……………………………………………….……………...……….
Your phone can be used as a torch. Enter the menu and select On/Off to turn on/off the
torch.
22.1
37 Latin input mode…………………………………………………………………
There are two text entry methods that can be used to write messages:
– Normal: this mode allows you to type a text by choosing a letter or
a sequence of characters associated with a key.
– Predictive with the predictive mode: This mode speeds up the writing of your text.
• Press once: Input a capital letter
• Press twice: Lock the keypad in capital letter input mode
• Press once: Input a top-half key character
• Press twice: Lock the keypad in top-half key input mode
• Press once: Enter a space and confirm an option ( on edit mode)
• Hold down Fn key, then press Space key to switch input mode
• Enter symbol list
• Enter the next line (on edit mode)
• Press once: Delete entered character
• Press and hold: Delete all entered characters
FCC Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types
one touch 639G/ one touch 639D(FCC ID: RAD298) has also been tested against this
SAR limit. The highest SAR value reported under this standard during product certification
for use at the ear is 0.814 W/kg and when properly worn on the body is 1.263 W/kg. This
device was tested for typical body-worn operations with the back of the handset kept
1.5cm from the body. To maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5cm separation distance between the user's body and the
back of the handset. The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF exposure requirements, and should be
avoided.
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help
