ThismoduleislimitedtoOEMInstallationonly.

Welcome!Thismanualbriefistheprofileofyourmodem,itisaremovabledeviceforwirelessinternetaccessand

dataservice.

1. GettingtoKnowYourModem



A. SIM/USIMCard

B. Antenna

C. PCIEInterface



 

2.Howtostartyourmodem



3. Yourmodemkeyfeatures

a) Upto21MbpsDLand5.76MbpsUL

b) RxDiversity

c) SMS

d) Phonebook

e) SupportAndroid2.2/2.3/3.0/4.0

4.SafetyandUse

Werecommendthatyoureadthischaptercarefullybeforeusingthemodem.Themanufacturerdisclaimsany

liabilityfordamage,whichmayresultasaconsequenceofimproperuseofthemodemorofusecontrarytothe

instructionscontainedherein.



TrafficSafety

Whendriving,donotusethemodem

 Whenswitchedon,themodememitselectromagneticwavesthatcaninterferewiththevehicle’s

electronicsystemssuchasABSanti‐lockbrakesorairbags.Toensurethatthereisnoproblem,donotplace

InsertSIMcard

Intomodem

Poweroffyour

Tablet

Plugthemodem

intoyourTablet

Poweronyour

Tablet

yourtabletwiththemodemontopofthedashboardorwithinanairbagdeploymentarea.

 Checkwithyourcardealerorthecarmanufacturertomakesurethatthedashboardisadequatelyshielded

frommodemRFenergy.

ConditionsofUse

 Switchthemodemoffbeforeboardinganaircraft.

 Switchthemodemoffwhenyouareinhealthcarefacilities,exceptindesignatedareas.Aswithmanyother

typesofequipmentnowinregularuse,themodemcaninterferewithotherelectricalorelectronicdevices,

orequipment‐usingradiofrequencies.

 Switchthemodemoffwhenyouareneargasorflammableliquids.Strictlyobeyallsignsandinstructions

postedinafueldepot,petrolstation,chemicalplant,orinanypotentiallyexplosiveatmosphere.

 Whenthemodemisswitchedon,itshouldbekeptatleast15cmfromanymedicaldevicesuchasa

pacemaker,ahearingaidorinsulinpump,etc.

 Donotletchildrenusethemodemwithoutsupervision.

 Whenreplacingthecover,pleasenotethatthemodemmaycontainsubstancesthatcouldcreateanallergic

reaction.

 Alwayshandlethemodemwithcareandkeepitinacleananddust‐freeplace.

 Donotallowthemodemtobeexposedtoadverseweatherorenvironmentalconditions(moisture,humidity,

rain,infiltrationofliquids,dust,seaair,etc).Themanufacturer’srecommendedoperatingtemperaturerange

is‐10°Cto+50°C.

 Donotopen,dismantleorattempttorepairthemodemyourself.

 Donotdrop,throworbendthemodem.

 Donotpaintit.

5.HostInformation

 Hostmanufactureris:TCTMobileLimitedHostBrandnameis:ALCATEL;Host

modelnumberis:OneTouchT70.



WEEEApproval

ThemodemisincompliancewiththeessentialrequirementsandotherrelevantprovisionsoftheWaste

ElectricalandElectronicEquipmentDirective2002/96/EC(WEEEDirective).



Theywillthenberecycled,preventingsubstancesbeingdisposedofintheenvironment,sothattheir

componentscanbereused.

InEuropeanUnioncountries:

Thissymbolondevicemeansthattheseproductsmustbetakento

collectionpointsattheendoftheirlife:

‐Municipalwastedisposalcentreswithspecificbinsfor

theseitemsofequipment

‐Collectionbinsatpointsofsale.

Thesecollectionpointsareaccessiblefreeofcharge.

Allproductswiththissignmustbebroughttothesecollectionpoints.

InnonEuropeanUnionjurisdictions:

Itemsofequipmentwiththissymbolarenottobethrownintoordinarybinsifyourjurisdictionoryourregion

hassuitablerecyclingandcollectionfacilities;insteadtheyaretobetakentocollectionpointsforthemtobe

recycled.

RoHsApproval

Themodemisincompliancewiththerestrictionoftheuseofcertainhazardoussubstancesinelectricaland

electronicequipmentDirective2002/95/EC(RoHsDirective).



Certification

Federal Communications Commission Notice (United States):

TheendproductwithanembeddedM70ModulemayalsoneedtopasstheFCCPart

15unintentionalemissiontestingrequirementsandbeproperlyauthorizedperFCC

Part15.



ThisdevicecomplieswithPart15oftheFCCRules.

Operationissubjecttothefollowingtwoconditions:

(1)thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat

maycauseundesiredoperation.



ChangesormodificationsmadetothisequipmentnotexpresslyapprovedbyTCL

mayvoidtheFCCauthorizationtooperatethisequipment.

Pleasebenoticedfollowinginformationandinstructions

shouldbeplacedintheend‐user’soperatingmanual



TheM70Modulehasbeengrantedaslimitedmodularapproval,whichwasdesigned

tobefixedtospecifiedhostonlyinthismanual.



1.Separateapprovalisrequiredforallotheroperatingconfigurations,including

portableconfigurationswithrespectto2.1093anddifferentantennaconfigurations.



2. AlabelmustbeaffixedtotheoutsideoftheendproductintowhichtheM70

moduleisincorporated,withastatementsimilartothefollowing:Thisdevice

containsFCCID:RAD312.



3. Thismoduleistobeinstalledonlyinspecifiedhostasspecifiedinthismanual

only.ThehostwiththisLMAmodulehasbeentestedagainstthisSARlimit.The

highestSARvaluereportedforproperlywornonthebodyis1.176W/kg.This

devicewastestedfortypicalbody‐wornoperationswiththebackofthehost

whichis5mmdistancewiththebody.TomaintaincompliancewithFCCRF

exposurerequirements,useaccessoriesthatitwastesteddirectlywiththeuser's

bodyandthebackofthehost.Theuseofbeltclips,holstersandsimilar

accessoriesshouldnotcontainmetalliccomponentsinitsassembly.Theuseof

accessoriesthatdonotsatisfytheserequirementsmaynotcomplywithFCCRF

exposurerequirements,andshouldbeavoided.



4. Separateapprovalisrequiredforallotheroperatingconfigurations,including

portableconfigurationswithrespecttoFCCPart2.1093anddifferentantenna

configurations.



5.Acertifiedmodularhastheoptiontouseapermanentlyaffixedlabel,oran

electroniclabel.Forapermanentlyaffixedlabel,themodulemustbelabelledwith

anFCCID:RAD312.TheOEMmanualmustprovideclearinstructionsexplainingto

theOEMthelabellingrequirements,optionsandOEMusermanualinstructionsthat

arerequired



ForahostusingathisFCCcertifiedmodularwithastandardfixedlabel,if(1)the

module’sFCCIDisnotvisiblewheninstalledinthehost,or(2)ifthehostismarketed

sothatendusersdonothavestraightforwardcommonlyusedmethodsforaccessto

removethemodulesothattheFCCIDofthemoduleisvisible;thenanadditional

permanentlabelreferringtotheenclosedmodule:

“ContainsTransmitterModuleFCCID:RAD312”or“ContainsFCCID:RAD312”must

beused.ThehostOEMusermanualmustalsocontainclearinstructionsonhow

enduserscanfindand/oraccessthemoduleandtheFCCID.



6.HostproductisrequiredtocomplywithallapplicableFCCequipment

authorizationsregulations,requirementsandequipmentfunctionsnotassociated

withthetransmittermoduleportion.compliancemustbedemonstratedto

regulationsforothertransmittercomponentswithinthehostproduct;to

requirementsforunintentionalradiators(Part15B).Toensurecompliancewithall

non‐transmitterfunctionsthehostmanufacturerisresponsibleforensuring

compliancewiththemodule(s)installedandfullyoperational.Ifahostwas

previouslyauthorizedasanunintentionalradiatorundertheDeclarationof

Conformityprocedurewithoutatransmittercertifiedmoduleandamoduleisadded,

thehostmanufacturerisresponsibleforensuringthattheafterthemoduleis

installedandoperationalthehostcontinuestobecompliantwiththePart15B

unintentionalradiatorrequirements.Sincethismaydependonthedetailsofhowthe

moduleisintegratedwiththehost,wesuggestthehostdevicetorecertifypart15B

toensurecompletecompliancewithFCCrequirement:Part2SubpartJEquipment

AuthorizationProcedures,KDB784748D01v07,andKDB997198aboutimportation

ofradiofrequencydevicesintotheUnitedStates.



9.TocomplywithFCCregulationslimitingbothmaximumRFoutputpowerand

humanexposuretoRFradiation,themaximumantennagainincludingcablelossina

mobile‐onlyexposureconditionmustnotexceed0.3dBiinthe850bandand1.2dBi

inthe1900band.



10.Ausermanualwiththeendproductmustclearlyindicatetheoperating

requirementsandconditionsthatmustbeobservedtoensurecompliancewith

currentFCCRFexposureguidelines.



11.ThisFCCApprovalisaLimitedModularApprovalsubmissionforaspecifichost

device(TabletPC)only.ThemanufacturerofthishostdeviceisTCTMobileLimited

withBrandName:ALCATEL;ModelNumber:OneTouchT70;FCCID:RAD310.This

WwanModulehasnoitswonpowersupplyanditmustbeconnectedwiththishost

devicewhileworking;andthePMUofthisHostDeviceisTPS659102A1RSLRwhich

willcontrolthepowersupplyregulation.



GeneralInformation

*Internetaddress:www.alcatelonetouch.com

*CustomerSupport/HotLineNumber:see“TCTMobileServices”leafletorgoto

ourInternetsite


