TCT Mobile 352 HSDPA/HSUPA/UMTS dual band / GSM quad bands mobile phone User Manual IP4497 VF975 VF975N QG Eng USA 05 130320 indd
TCT Mobile Limited HSDPA/HSUPA/UMTS dual band / GSM quad bands mobile phone IP4497 VF975 VF975N QG Eng USA 05 130320 indd
Contents
- 1. IP4497_VF975_VF975N_QG_USA_20_03_13.pdf
- 2. Confidential_IP4497_VF975_VF975N_QG_USA_20_03_13.pdf
Confidential_IP4497_VF975_VF975N_QG_USA_20_03_13.pdf
Quick start guide
Vodafone Smart III
Some services and apps may not be available in all
countries. Please ask instore for details.
Facebook is a trademark of Facebook, Inc.
Google, Android, YouTube and other marks are
trademarks of Google, Inc.
© Vodafone Group 2013. Vodafone and the
Vodafone logos are trade marks of Vodafone Group.
Any product or company names mentioned herein
may be the trade marks of their respective owners.
English - CJB26P001AAA
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd 2-3 2013-3-20 17:01:47
1 2
For more information about how to use the phone, please go to
www.vodafone.com/smart3 to download full user manual. At this website
you can also view the FAQs, check for software updates, and more.
Your mobile1
Keys and connectors1.1
Power key Micro-USB connector
Headset connector
Touchscreen
Receiver
Multitask key
LED light
Back key
Home key
Flash
Camera
Loudspeaker
Volume key
Back key
Go back to the previous menu or screen.•
Multitask key
On the Home screen, press quickly to show all running •
tasks.
Quick menu: pressing and holding the Multitask key can •
bring up a quick menu for settings and managing apps. To
enable this, go to Settings > Display > Menu appearance
and select
Home key
Return to the Home screen or back to the central Home •
screen if it is extended.
Press and hold the Home key to access "Google Now" and •
"Voice Search".
Power key
Press: Lock the screen•
Light up the screen
Press and hold: When phone is off, power on the phone.•
When phone is on, enter Phone options:
Power off, Restart, Airplane mode.
Volume key
Press to adjust the Volume (in call/media playing mode)•
Press to adjust the ring tone volume in general mode.•
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:1-Sec1:2IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:1-Sec1:2 2013-3-20 16:59:212013-3-20 16:59:21
3 4
Getting started1.2
Set-up1.2.1
Removing or installing the back cover
If you have Vodafone 975, you can insert one of the supplied graphic
sheet under the translucent cover before closing it. You can also use the
template provided to make your own graphics.
Graphic sheet Battery cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off
your phone and remove the battery before inserting or removing the
SIM card.
Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card, press
and slide it out.
Installing or removing the battery
Insert and click the battery into place, then close the phone cover.•
Unclip the cover, then remove the battery.•
Installing and removing the microSD card
To release the microSD card holder, slide it in the direction of the
arrow and lift it. Then insert the microSD card with the golden contact
downward. Finally, fold down the microSD holder and slide it in the
opposite direction to lock it.
Charging the battery
Connect the battery charger to your phone and outlet respectively.
To reduce energy wastage, disconnect your charger from the
plug when the battery is fully charged.
To reduce your phone's power consumption switch off Wi-Fi,
GPS, Bluetooth or applications running in the background when
not needed. You can also reduce the backlight brightness, and
shorten the time before the phone goes into sleep mode.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:3-Sec1:4IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:3-Sec1:4 2013-3-20 16:59:212013-3-20 16:59:21
5 6
Power on your phone1.2.2
Hold down the Power key until the phone turns on. It will take some
seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you are asked to touch "Location
consent" to begin. And then do below settings: Language, Mobile data,
Set up Google account and Data & time (1).
If you don't have a SIM card inserted you can still connect to a Wi-Fi
network from the Power on screen, which will let you sign on to your
Google account and use some features.
Power off your phone1.2.3
Hold down the Power key until the phone options appear. Tap Power
off, then tap OK.
Sleep mode1.2.4
After a set time, your phone will go into a sleep mode to save power. You
can also press the Power key once to send the phone to sleep mode.
To wake your phone from sleep mode, just press the Power key.
Lock/Unlock the screen1.2.5
When you wake your phone from sleep mode you'll see a Lock screen,
which prevents accidental key presses.
To unlock the screen, touch and slide the to the right. You can also
slide it in other directions to perform other actions, such as search or
starting the camera.
You can change the type of lock screen so that in unlocks with a
password or by drawing a pattern by pressing and holding the Multitask
key and touching System settings > Security > Set up screen
lock > PIN or Password or Slide.
(1) Application availability depends on country and operator.
Home screen1.3
You can bring all the items (applications, shortcuts, folders and widgets)
you love or use most frequently to your Home screen for quick access.
Press the Home key to switch to the Home screen.
Status bar
Status/Notification indicators •
Touch and Drag down to open •
the Notification panel.
Application tab
Touch to open applications list.
Touch to access Messaging.
Touch to access Browser.
Touch to access Call log if you have missed
calls. Touch to access dial screen.
Touch to access People.
Search bar
Touch a to enter Search options:
All, Web, Apps, Contacts, etc.
Touch b to enter voice search
screen.
Touch an icon to open an
application, folder, etc.
ab
The Home screen extends on either side of the screen to allow more
space for adding applications, shortcuts etc. Slide the Home screen
horizontally left and right to get a complete view of the Home screen.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:5-Sec1:6IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:5-Sec1:6 2013-3-20 16:59:212013-3-20 16:59:21
7 8
Using the touchscreen1.3.1
Touch
To access an application, touch it with your finger.
Touch and Hold
To enter the available options for an item, touch and hold the item. For
example, select a contact in Contacts, touch and hold this contact, an
options list will then appear on screen.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen to scroll up and down applications, images, web
pages…
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to landscape
by turning the phone sideways.
Status bar1.3.2
From the Status bar, you can view both phone status (on the right side) and
notification information (on the left side).
Status icons
GPRS connected GPS is on
GPRS in use Receiving location data
from GPS
EDGE connected Roaming
EDGE in use No signal
3G connected No SIM card installed
3G in use Vibrate mode
HSPA (3G+) connected Ringer is silenced
HSPA (3G+) in use Phone microphone is
muted
Connected to a Wi-Fi
network Battery is very low
Bluetooth is on Battery is low
Connected to a Bluetooth
device
Battery is partially
drained
Airplane mode Battery is full
Alarm is set Battery is charging
Signal strength Headset connected
NFC is on (1)
(1) Vodafone 975N only.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:7-Sec1:8IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:7-Sec1:8 2013-3-20 16:59:212013-3-20 16:59:21
9 10
Notification icons
New Gmail TM message Both USB tethering and
portable hotspot are on
New text or multimedia
message Call in progress (green)
Problem with text or
multimedia message
delivery
Call in progress using
Bluetooth headset (blue)
New Google Talk TM
message Missed call
New voicemail Call on hold
Upcoming event Call forwarding is on
Data is synchronising Uploading data
Problem with sign-in or
synchronisation
Downloading data
microSD card is full Download finished
No microSD card
installed
An open Wi-Fi network is
available
Connected to VPN Phone is connected via
USB cable
Disconnected from VPN Radio is on
Song is playing System update available
USB tethering is on Portable Wi-Fi hotspot
is on
Notification panel
Touch and drag down the Status bar to open the Notification panel.
Touch and drag up to close it. From the Notification panel, you can
open items and other reminders indicated by notification icons or view
wireless service information.
Widget bar: swipe left to see
more widgets. Touch an icon
to change its function.
Settings
Touch to clear all event–based notifications (other ongoing
notifications will remain).
Search bar1.3.3
The phone provides a Search bar on the main Home screen which can be
used to locate information within applications, the phone or the web.
a Touch or press the keypads to
searce by text
b Touch to search by voice
c Touch to enter the suggested
text for quick search
d Touch to search the web
a
c
b
d
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:9-Sec1:10IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:9-Sec1:10 2013-3-20 16:59:212013-3-20 16:59:21
11 12
Personalize your home screen1.3.4
Add
You can add shortcuts, widgets or folders to the Home screen by
pressing the key. Touch and hold the item you want to add and then
release it. You will see it in current home screen.
Reposition
Touch and hold the item to be repositioned to activate the Move mode:
drag the item to desired position, then release. Hold the icon on the
left or right edge of the screen to drag the item to another Home
screen page.
Remove
Touch and hold the item to be removed to activate the Move mode: drag
the item to the top of , which will then turn red, and release.
Wallpaper customization
Touch and hold an empty area on the Home screen or press and hold the
Multitask key in the Home screen, then select System settings/
Display/Wallpaper to customize wallpaper.
Application tab1.3.5
Touch from the Home screen to enter the applications list.
To return to the Home screen, press the Home key.
View Default/Most used/Recently installed applications
To view your Default/Most used/Recently installed applications, press
the option icon at the top of the applications list and choose your
option.
Volume adjustment1.3.6
You can set ringer, media and phone ringtone volume to your preference
using the Volume up/down key, or in the Settings menu.
Applications list1.4
The Applications list contains all pre-embedded and newly installed
applications.
To access the Applications list, touch the Application tab from the Home
screen. To return to the Home screen, press the Home key.
Text input2
Using the onscreen keyboard2.1
An onscreen keyboard will display automatically when a program
requires you to enter text or numbers.
Onscreen keyboard settings
Press and hold the Multitask key in the Home screen, then select
System settings > Language & input > Google voice typing (or
Android keyboard) to see the various keyboard settings. Scroll to select
the keyboard style you want to change keyboard style.
Adjust the onscreen keyboard orientation
Turn the phone sideways or upright to adjust the onscreen keyboard
orientation. You can also adjust it by settings (press the Application tab
key in the Home screen, then Settings > Display).
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:11-Sec1:12IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:11-Sec1:12 2013-3-20 16:59:222013-3-20 16:59:22
13 14
Android keyboard2.1.1
Touch to lock in capital letter input mode.
Touch to switch to symbol and numeric
keyboard.
Touch to enter Voice input.
Press and hold to enter an accent of the
letter.
Touch to enter text or numbers,
touch and hold for one or two
seconds to select input method.
Text editing2.2
You can edit the text you have entered.
Touch and hold text you have entered.•
For large group words, you may touch and hold the beginning word
and move the end points to the place which you want.
An options list pops up.•
Select the operation you need (• Paste, Replace, Cut, etc.)
Phone call3
Placing a call3.1
You can easily launch a call using Phone. Enter this menu using one of
the following two ways:
Touch • from the Home screen.
Touch the Application tab from the Home screen and select • Phone.
Touch and hold to
access Voicemail
Search contacts
Call log
Options
Contacts
Enter the desired number from the keyboard directly or select a contact
from Contacts, Call log by touching tabs, then touch to place the
call. The number you entered can be saved to Contacts by pressing the
key and touching Add to Contacts.
If you make a mistake, you can delete the incorrect digits by touching
.
To hang up a call, press .
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:13-Sec1:14IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:13-Sec1:14 2013-3-20 16:59:222013-3-20 16:59:22
15 16
Answering or rejecting a call3.2
When you receive an incoming call, slide the green phone icon to
answer. Hang up the call by pressing the icon.
When you receive an incoming call but don't want to answer, you can
reject it by dragging up to select messages. The caller is sent directly
to your voicemail box to leave a message.
Consulting your call memory3.3
You can access your call memory by touching the from the Home
screen and touching to view call history in categories of Missed
calls, Outgoing calls, and Incoming calls.
People4
You can view and create contacts on your phone and synchronize
these with your Gmail contacts or other applications on the web or
on your phone.
When using People for the first time you are asked to add new
contacts, import contacts from the SIM card or synchronize
contacts from other application accounts to phone.
Adding a contact4.1
Touch the Application tab on the Home screen, select People, You
may select Groups and Favorites to manage your contacts. Press
to add a contact.
Importing , exporting and sharing 4.2
contacts
From the Contacts screen, press the icon to open the contacts list
option menu, touch Import/Export, then select Import from SIM
card, Export to SIM card, Import from SD card or Export to SD card
or Share visible contacts.
To import/export a single contact from/to the SIM card, touch the •
contact you want to import/export, then press the Menu key and
touch OK to confirm.
To import/export all contacts from/to the SIM card, mark • Select all
check box, then touch OK to confirm.
You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, MMS, Email, etc.
Touch a contact you want to share, press the Menu key and touch
Share from the contact details screen, then select the application to
perform this action.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:15-Sec1:16IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:15-Sec1:16 2013-3-20 16:59:222013-3-20 16:59:22
17 18
Synchronizing contacts in multiple 4.3
accounts
Contacts, data or other information can be synchronized from multiple
accounts, depending on the applications installed on your phone.
Messaging5
You can create, edit and receive SMS and MMS messages with this
mobile phone.
To access this feature, touch the Application tab from the Home screen,
then select Messaging.
All messages you receive or send out can only be saved in
phone memory. To view messages stored on the SIM card,
press the icon in the Messaging screen, then touch Settings
> Manage SIM card messages.
Write a message5.1
On the message list screen, touch to write text/multimedia
messages.
Touch to create a new message
Touch to view the whole
message thread
Sending a text message
Enter the mobile number of the recipient on the To bar or touch to
add recipients, then touch Type message bar to enter the text of the
message. When finished, touch to send the text message.
An SMS of more than 160 characters will be charged as several
SMS messages. Specific letters (like accents) will also increase
the size of the SMS, so this may cause multiple SMS messages
to be sent to your recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations, slides
and sounds to other compatible mobiles and e-mail addresses.
An SMS will be converted to MMS automatically when media files
(image, video, audio, slides, etc.) are attached or Subject or email
addresses added.
Email6
Besides your Gmail account, you can also set-up external POP3 or IMAP
email accounts on your phone.
To access this function, touch the Application tab from the Home screen,
then select Email.
An email wizard will guide you through the steps to set-up an email
account.
a Enter the email address and password of the account you want to
set-up.
b Touch Next. If the account you entered is not provided by your
service provider in the phone, you will be prompted to go to the email
account settings screen to enter settings manually. Or you can touch
Manual setup to directly enter the incoming and outgoing settings
for the email account you are setting up.
c Enter the account name and display name in outgoing emails.
d Touch Done.
e To add another email account, you can touch and press "Settings",
touch Add account.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:17-Sec1:18IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:17-Sec1:18 2013-3-20 16:59:222013-3-20 16:59:22
19 20
To create and send emails
a Press the icon in the Inbox screen, and touch Compose.
b Enter the recipient(s)’s email address in the To field, and if necessary,
press the key and touch Add Cc/Bcc to include a copy or a blind
copy to the message.
c Enter the subject and content of the message.
d Press the icon, touch Attach file to send an attachment to the
receiver.
e Finally, touch to send.
f If you do not want to send the mail right away, you can touch and
Save as draft or press the Back key to save a copy.
NFC Task Launcher 7 (1)
Near Field Communication (NFC) is a new, short-range wireless
connectivity technology which allows mobile users to read and write
NFC tags, pair with other NFC devices, and even make fast and secure
mobile payments. With NFC activated, you can use this application to
open, act on and organize the tags you've scanned.
To access this function, touch the Application tab from Home screen,
then select NFC Task Launcher.
Getting connected8
To connect to the Internet with this phone, you can use GPRS/EDGE/3G
networks or Wi-Fi, whichever is most convenient.
Connecting to the Internet8.1
GPRS/EDGE/3G8.1.1
The first time you turn on your phone with the SIM card inserted, it will
automatically configure network service: GPRS, EDGE or 3G.
To check the network connection you are using, press the Menu key in
the Home screen, then touch Settings > More > Mobile networks >
Network operators or Access Point Names.
(1) Vodafone 975N
Wi-Fi8.1.2
Using Wi-Fi, you can connect to the Internet when your phone is within
range of a wireless network. Wi-Fi can be used on phone even without
a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
a Press and hold the Multitask key in the Home screen.
b Touch System settings.
c Touch the On/Off toggle next to the Wi-Fi icon to turn Wi-Fi on or off.
d Touch Wi-Fi. The detailed information of detected Wi-Fi networks is
displayed in the Wi-Fi networks section.
e Touch a Wi-Fi network to connect. If the network you selected is
secured, you are required to enter a password or other credentials
(you may contact network operator for details). When finished, touch
Connect.
Browser 8.2
Using Browser, you can enjoy surfing the Web.
To open the web browser, tap on the Home screen.
To go to a web page
In the Browser screen, touch the URL box at the top, enter the address of
the web page, then touch Go.
Connecting to a computer via USB8.3
With the USB cable, you can transfer media files and other files between
your phone’s microSD card and the computer.
To connect/disconnect your phone to/from the computer
To connect your phone to the computer:
a Use the USB cable that came with your phone to connect the phone
to a USB port on your computer. You will receive a notification that the
USB is connected.
b Open the Notifications panel and touch USB connected.
c Touch Mount in the dialog that opens to confirm that you want to
transfer files.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:19-Sec1:20IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:19-Sec1:20 2013-3-20 16:59:222013-3-20 16:59:22
21 22
To disconnect:
a Unmount the microSD card on your computer.
b Open the Notifications panel and touch Turn off USB storage.
c Touch Turn off in the dialog that opens.
To locate data you have transferred or downloaded in your
microSD card:
a Touch the Application tab in the Home screen to open the applications
list.
b Touch File Manager.
All data you have downloaded are stored in File Manager, where you
can view media files (videos, photos, music and others), rename files,
install applications onto your phone, etc.
Sharing your phone's mobile data 8.4
connection
You can share your phone's mobile data connection with a single
computer via a USB cable (USB tethering) or with up to eight devices at
once by turning your phone into a portable Wi-Fi hotspot.
To turn on USB tethering or Portable Wi-Fi hotspot
a Press and hold the Multitask key in the Home screen.
b Touch System settings > More > Tethering & portable hotspot.
c Mark the check box USB tethering or Portable Wi-Fi hotspot to
activate this function.
Sharing data may incur additional network charges from
your network operator. Extra fees may also be charged in
roaming areas.
Find my location9
To activate your phone’s global positioning system (GPS) satellite Receiver:
a Press the Menu key in the Home screen.
b Touch Settings > Location services > GPS satellites.
c Mark the checkbox.
To find your location, go to the application list and touch Maps.
Your phone uses GPS and mobile cell-tower data to provide a quick and
accurate location - sometimes as close as several metres. The process of
accessing the GPS satellite and setting your phone's precise location for the
first time can require up to 5 minutes. You will need to stand in a place with
a clear view of the sky and avoid moving. After this, GPS will only need 20-40
seconds to identify your precise location.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:21-Sec1:22IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:21-Sec1:22 2013-3-20 16:59:232013-3-20 16:59:23
23 24
Data backup10
This phone enables you to back up your phone’s settings and other
application data to Google Servers, with your Google Account.
If you replace your phone, the settings and data you’ve backed up
are restored onto the new phone the first time you sign in with your
Google Account.
To activate this function:
a Press the Menu key in the Home screen
b Touch Settings > Personal > Backup & reset > Back up my data
c Mark the checkbox
When data backup is activated, a wide variety of settings and data are
backed up, including your Wi-Fi passwords, bookmarks, a list of the
applications you’ve installed, the words you’ve added to the dictionary
used by the onscreen keyboard, and most of the settings that you
configure with the Settings application. If you deactivated this option,
you stop backing up your settings, and any existing backups are deleted
from Google Servers.
Factory data reset11
To activate factory data reset:
a Press and hold the Multitask key in the Home screen.
b Touch System settings > Backup & reset > Factory data reset
c Mark the checkbox
A phone reset will erase all of your personal data from internal
phone storage, including information about your Google Account,
any other accounts, your system and application settings, and
any downloaded applications. Resetting the phone does not erase
any system software updates you’ve downloaded or any files on your
microSD card, such as music or photos. If you reset the phone in this
way, you’re prompted to re-enter the same kind of information as when
you first started Android.
When you are unable to power on your phone, there is another way to
perform a factory data reset by using hardware keys. Hold down the
the Volume up key and press the Power key at same time until the
screen lights up.
Applications12
Your phone comes with some built-in Google TM applications, and more
third-party applications can be downloaded onto it.
With the built-in applications, you can
Communicate with friends•
Exchange messages or emails with friends•
Track you location, view traffic situations, search for locations and get •
navigation information to your destination
Download more applications from Android Market •
and more.
For more information about these applications, please check the user
manual online: www.vodafone.com/smart3.
Making the most of your 13
phone
Android Manager13.1
You can download the Android Manager PC suite software for free from
the website:www.vodafone.com/smart3
The PC suite includes:
Contacts•
It allows you to back up contact entries so that you don't have to worry
about losing, breaking, or changing your phone.
Messages•
It allows you to write messages from your computer instead of using the
phone's onscreen keyboard. It also manages your messages.
Photos•
It allows you to easily import photos from either your PC or your phone,
and organize them in different albums.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:23-Sec1:24IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:23-Sec1:24 2013-3-20 16:59:232013-3-20 16:59:23
25 26
Videos•
It allows you to playback video files from your PC and upload them to a
folder on your phone.
Music•
It allows you to quickly find your favorites on your PC, manage your
library, and set up playlists for your phone's music player.
Application •
It allows you to import downloaded mobile applications and have them
installed onto your phone upon synchronization.
File •
It allows you to organize your phone's files with just a few clicks, so they
will appear on your phone where you want them.
Sync•
It allows you to synchronize the Contacts and Calendar in Outlook/
Outlook Express and handset.
Supported Operating Systems
Windows XP/Vista/Windows 7.
FOTA Upgrade13.2
Using FOTA Upgrade tool you can update your phone's software.
To access Software updates, please open notification panel and
touch icon , then press About phone/Software updates. Or
you touch icon and access Settings/About phone/Software
updates. Touch Check for updates, and the phone will search for the
latest software. If you want to update the system, please touch the
button Download, after it done please touch Install to complete the
upgrade. Now your phone's software will have the latest version.
You should turn on data connection before searching for updates.
Settings for auto-check intervals and reminders about upgrades are
also available once you restart the phone.
If you have chosen auto-check, when the system discovers the
new version, the icon will appear in the status bar. Touch the
notification to access the Software Updates directly.
During FOTA downloading or updating,to avoid errors in
locating the correct update packages, do not change your
default storage location.
Safety and use
We recommend that you read this chapter carefully before using your mobile
phone. The manufacturer disclaims any liability for damage, which may
result as a consequence of improper use or use contrary to the instructions
contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit, headset...),
drivers are requested to refrain from using their mobile phone when the
vehicle is not parked. Check the laws and regulations on the use of wireless
mobile phones and their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or restricted in
certain areas.
When driving, do not use your mobile phone and headphone to listen to
music or to the radio. Using a headphone can be dangerous and forbidden
in some areas.
When switched on, your mobile phone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or
airbags. To ensure that there is no problem:
- do not place your mobile phone on top of the dashboard or within an
airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the
car’s electronic devices are shielded from mobile phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the mobile phone from time to time to optimize
its performance.
Remember to abide by local authority rules of mobile phone use on aircrafts.
Operational Warnings: Obey all posted signs when using mobile devices in
public areas.
Follow Instructions to Avoid Interference Problems: Turn off your mobile device
in any location where posted notices instruct you to do so. In an aircraft, turn
off your mobile device whenever instructed to do so by airline staff. If your
mobile device offers an airplane mode or similar feature, consult airline staff
about using it in flight.
Switch the mobile phone off when you are in health care facilities, except in
designated areas. As with many other types of equipment now in regular use,
mobile phones can interfere with other electrical or electronic devices, or
equipment using radio frequency.
Switch the mobile phone off when you are near gas or flammable liquids.
Strictly obey all signs and instructions posted in a fuel depot, gas station, or
chemical plant, or in any potentially explosive atmosphere.
When the mobile phone is switched on, it should be kept at least 15 cm from
any medical device such as a pacemaker, a hearing aid or insulin pump. In
particular when using the mobile phone you should hold it against the ear on
the opposite side to the device, if any.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:25-Sec1:26IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:25-Sec1:26 2013-3-20 16:59:232013-3-20 16:59:23
27 28
Read and follow the directions from the manufacturer of your implantable
medical device. If you have any questions about using your mobile device with
your implantable medical device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding your mobile
phone to your ear. Also move the handset away from your ear while using
the “hands-free” option because the amplified volume might cause hearing
damage.
It is recommended to have proper supervision while small children use your
mobile phone.
When replacing the cover please note that your mobile phone may contain
substances that could create an allergic reaction.
Always handle your mobile phone with care and keep it in a clean and dust-
free place.
Do not allow your mobile phone to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of liquids, dust,
sea air, etc.). The manufacturer’s recommended operating temperature range
is -10°C (14°F) to +55°C (131°F) (the max value depends on device, materials
and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s display may be impaired,
though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is damaged, cracked or
broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your mobile phone
model.TCT Mobile Limited and its affiliates disclaim any liability for damage
caused by the use of other chargers or batteries.
Your mobile phone should not be disposed of in a municipal waste. Please
check local regulations for disposal of electronic products.
Remember to make back-up copies or keep a written record of all important
information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts when exposed to
flashing lights, or when playing video games. These seizures or blackouts
may occur even if a person never had a previous seizure or blackout. If you
have experienced seizures or blackouts, or if you have a family history of
such occurrences, please consult your doctor before playing video games
on your mobile phone or enabling a flashing-lights feature on your mobile
phone. Parents should monitor their children’s use of video games or other
features that incorporate flashing lights on the mobile phones. All persons
should discontinue use and consult a doctor if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms,
please take the following safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body.
Follow these instructions to avoid problems such as tendinitis, carpal tunnel
syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game playing.
- If your hands, wrists, or arms become tired or sore while playing, stop and
rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing,
stop the game and see a doctor.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker is
in use.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your mobile phone
regarding taking photographs and recording sounds with your mobile phone.
Pursuant to such laws and regulations, it may be strictly forbidden to take
photographs and/or to record the voices of other people or any of their personal
attributes, and reproduce or distribute them, as this may be considered to be
an invasion of privacy.
It is the user’s sole responsibility to ensure that prior authorization be obtained,
if necessary, in order to record private or confidential conversations or take a
photograph of another person; the manufacturer, the seller or vendor of your
mobile phone (including the operator) disclaim any liability which may result
from the improper use of the mobile phone.
• BATTERY AND ACCESSORIES:
Before removing the battery from your mobile phone, please make sure that
the mobile phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and
burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in the garbage or store it at
temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for which it
was designed. Never use damaged batteries or those not recommended by
TCT Mobile Limited and/or its affiliates.
This symbol on your mobile phone, the battery and the
accessories means that these products must be taken to
collection points at the end of their life:
- Municipal waste disposal centers with specific bins for these
items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:27-Sec1:28IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:27-Sec1:28 2013-3-20 16:59:232013-3-20 16:59:23
29 30
In European Union countries:
These collection points are accessible free of charge. All products with this
sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into ordinary bins if
your jurisdiction or your region has suitable recycling and collection facilities;
instead they are to be taken to collection points for them to be recycled.
In the United States you may learn more about CTIA’s Recycling Program at
www.recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of: 0°C
(32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the standard for
safety of information technology equipment and office equipment use. Due
to different applicable electrical specifications, a charger you purchased in
one jurisdiction may not work in another jurisdiction. They should be used
for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5.0 V, 550 mA
Battery: Lithium 1500 mAh
• RADIO WAVES:
THIS MOBILE PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio-
frequency (RF) energy. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. These guidelines include a substantial safety margin designed to
ensure the safety of all persons, regardless of age and health.
The exposure standard for mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by public
authorities such as the Federal Communications Commission of the US
Government (FCC), or by Industry Canada, is 1.6 W/kg averaged over 1 gram
of body tissue. Tests for SAR are conducted using standard operating positions
with the mobile phone transmitting at its highest certified power level in all
tested frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the mobile phone while operating can be well below
the maximum value. This is because the mobile phone is designed to
operate at multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the mobile phone.
Before a mobile phone model is available for sale to the public,
compliance with national regulations and standards must be shown.
The highest SAR value for this model mobile phone when tested is
0.70 W/Kg for use at the ear and 1.02 W/Kg for use close to the body.
While there may be differences between the SAR levels of various mobile
phones and at various positions, they all meet the government requirement
for RF exposure. For body-worn operation, the mobile phone meets
FCC RF exposure guidelines provided that it is used with a non-metallic
accessory with the handset at least 10 mm from the body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for use of
mobile phones. If individuals are concerned, they might choose to limit their own
or their children’s RF exposure by limiting the length of calls, or using “hands-
free” devices to keep mobile phones away from the head and body. (fact sheet
n°193). Additional WHO information about electromagnetic fields and public
health are available on the following website: http://www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For the receiver devices associated with the operation of a licensed radio
service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
condition that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference
that may cause undesired operation.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:29-Sec1:30IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:29-Sec1:30 2013-3-20 16:59:232013-3-20 16:59:23
31 32
Your mobile phone is equipped with a built-in antenna. For optimal operation,
you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions
other than against your ear. In such circumstances the device will be compliant
with the guidelines when used with headset or usb data cable. If you are using
another accessory ensure that whatever product is used is free of any metal
and that it positions the mobile phone at least 10 mm away from the body.
Licences
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
TCT Mobile Limited and its affiliates is under license.
Other trademarks and trade names are those of their
respective owners.
Vodafone 975/975N Bluetooth
QD ID B020261
The Wi-Fi Logo is a certification mark of the Wi-Fi
Alliance.
Your device uses non-harmonized frequency and is
intended for use in all European countries.
The WLAN can be operated in the EU without
restriction indoors, but cannot be operated outdoors
in France.
You have purchased a product which uses the open source (http://
opensource.org/) programs mtd, msdosfs, netfilter/iptables and initrd in
object code and other open source programs licensed under the GNU
General Public License and Apache License.
We will provide you with a complete copy of the corresponding source
codes upon request within a period of three years from the distribution of
the product by TCT.
You may download the source codes from http://sourceforge.net/projects/
alcatel/files/. The provision of the source code is free of charge from
internet.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:31-Sec1:32IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:31-Sec1:32 2013-3-20 16:59:232013-3-20 16:59:23
33 34
General information
• Website: www.alcatelonetouch.com
• Facebook: http://www.facebook.com/alcatelonetouchusa
• Twitter: http://www.twitter.com/alcatel1touch
• Hot Line Number: In the United States, call 877-702-3444 for technical
support.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelonetouch.com
Your telephone is a transceiver that operates on GSM in quad-band (850/
900/1800/1900MHz) or UMTS in dual-band (900/2100MHz).
Protection against theft (1)
Your mobile phone is identified by an IMEI (mobile phone serial number) shown
on the packaging label and in the product’s memory. We recommend that you
note the number the first time you use your mobile phone by entering *#06# and
keep it in a safe place. It may be requested by the police or your operator if your
mobile phone is stolen.
Disclaimer
There may be certain differences between the user manual description and
the mobile phone’s operation, depending on the software release of your
mobile phone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if any,
nor for their potential consequences, which responsibility shall be borne by
the operator exclusively.
(1) Contact your network operator to check service availability.
ALCATEL ONE TOUCH
Limited Warranty
TCT Mobile North America LTD warrants to the original retail purchaser of
this wireless device, that should this product or part thereof during normal
consumer usage and condition, be proven to be defective in material or
workmanship that results in product failure within the first twelve (12)
months from the date of purchase as shown on your original sales receipt.
Such defect(s) will be repaired or replaced (with new or rebuilt parts) at
the company’s option without charge for parts or labor directly related
to the defect(s).
Batteries, power adapters, and other accessories sold as in box items are
also warranted against defects and workmanship that results in product
failure within the first six (6) months period from the date of purchase
as shown on your original sales receipt. Such defect(s) will be repaired
or replaced (with new or rebuilt parts) and the company’s option without
charge for parts or labor directly related to the defect(s).
The limited warranty for your wireless device will be voided if any of the
following conditions occur:
• Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area where
your mobile phone is used;
• Connection to any equipment not supplied or not recommended by
TCT Mobile;
• Modification or repair performed by individuals not authorized by TCT
Mobile or its affiliates;
• Acts of god such as Inclement weather, lightning, power surges, fire,
humidity, infiltration of liquids or foods, chemical products, download of
files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless devices event labels or serial
numbers (IMEI);
• Damage from exposure to water or other liquids, moisture, humidity,
excessive temperatures or extreme environmental conditions, sand,
excess dust and any condition outside the operating guidelines;
• Defects in appearance, cosmetic, decorative or structural items such as
framing and non-operative parts.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:33-Sec1:34IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:33-Sec1:34 2013-3-20 16:59:232013-3-20 16:59:23
35
There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided
by your jurisdiction. In no event shall TCT Mobile or any of its affiliates be
liable for incidental or consequential damages of any nature whatsoever,
including but not limited to commercial loss, to the full extent those
damages can be disclaimed by law. Some states do not allow the exclusion
or limitation of incidental or consequential damages, or limitation of the
duration of implied warranties, so the preceding limitations or exclusions
may not apply to you.
How to obtain Support: Contact the customer care center by calling (877-
702-3444) or going to www.alcatelonetouch.com. We have placed many
self-help tools that may help you to isolate the problem and eliminate
the need to send your wireless device in for service. In the case that your
wireless device is no longer covered by this limited warranty due to time or
condition we have other options that you may utilize our out of warranty
repair options.
To obtain hardware repairs or replacement within the terms of this
warranty, contact TCT Mobile to get an RMA number, include a copy of
the original proof of warranty coverage (e.g. original copy of the dated
bill of sale, invoice), the consumer’s return address, your wireless carrier’s
name, alternate daytime mobile phone number, and email address with
a complete problem description. Only ship the wireless device. Do not
ship the SIM card, memory cards, or any other accessories such as the
power adapter. You must properly package and ship the wireless device
to the repair center.
TCT Mobile is not responsible for wireless devices that do not arrive
at the service center. Upon receipt, the service center will verify the
warranty conditions, repair, and return your wireless device to the address
provided.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:35IP4497_VF975_VF975N_QG_Eng_USA_05_130320.indd Sec1:352013-3-20 16:59:232013-3-20 16:59:23
