Some services and apps may not be available in all
countries. Please ask in-store for details.
Android is a trademark of Google Inc. The Android robot
is reproduced or modied from work created and shared
by Google and used according to terms described in the
Creative Commons 3.0 Attribution Licence.
© Vodafone Group 2014. Vodafone and the Vodafone
logos are trade marks of Vodafone Group. Any product
or company names mentioned herein may be the trade
marks of their respective owners.
English - CJB27B5VDAAA
Smart 4 mini
Quick start guide
IP4776_VF785_QG_Eng_USA_00_131231.indd 1-2 2013-12-31 15:39:14
12
For more information about how to use this phone, please
visit the website: vodafone.com/smart4mini to download the
full user manual. Here, you can also view the FAQs, check for
software updates, and more.
Your phone1
Keys and connectors1.1
Power key
Micro-USB connector
Back key
Home key
Menu key
Touch screen
LED light
Headset connector
Volume up
Volume down
Camera
Menu key
Touch: display menu options. On the Home •
screen, touch to access Wallpaper, Manage apps
and Settings.
Touch & hold: this shows you images of your •
most recently-used apps. Touch an image to open
the associated app, or swipe it up or down to
remove it from the list. Touch Clear All to clear
all the apps and go back to the Home screen
directly. Touching Memory Manager will go to the
memory manager main screen.
Home key
While on any app or screen, touch the • Home key
to return to the main Home screen.
Touch & hold this key to access • Google Now &
Voice Search.
Back key
Touch to go back to the previous screen, or to close •
a dialogue box, options menu, the Notification
panel, etc.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:1-Sec1:2IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:1-Sec1:2 2013-12-31 17:14:332013-12-31 17:14:33
34
Power key
Press: activate the lock screen/wake up the screen.•
Press and hold: show the pop-up menu to select •
from Power off, Restart, Airplane mode, Quick
start, and icons for ringing modes.
Press and hold: power on.
Press and hold the • Power key and the Volume
down key to capture a screenshot.
Volume keys
During a call, they adjust the earpiece or headset •
volume.
In Music/Video/Streaming mode, they adjust the •
media volume.
In general mode, they adjust the ringtone •
volume.
Mute the ringtone of an incoming call.•
On the lock screen, press and hold either volume •
key to open the Camera.
In Camera mode, pressing either volume key •
captures a photo.
Getting started1.2
Set-up1.2.1
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please
power off your phone before inserting or removing the SIM
card.
Place the SIM card with the chip facing downwards and slide
it into its housing. Make sure that it is correctly inserted. To
remove the SIM card, press and slide it out.
Your phone only supports mini-SIM cards. Do not
attempt to insert other SIM card types, like micro-SIMs
or nano-SIMs, otherwise this may cause damage to
your phone.
Installing or removing the battery
Please power off your phone before removing the battery.
Insert the battery and click it into place, then close the cover.•
Unclip the cover, then remove the battery.•
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:3-Sec1:4IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:3-Sec1:4 2013-12-31 17:14:332013-12-31 17:14:33
56
Installing the microSD card
First remove the battery. Slide the microSD holder to the
left to unlock it, then lift it up. Place the microSD card in the
space provided, with the gold contacts facing down. Then
fold the microSD holder down again and slide it to the right
until it locks.
Charging the battery
To charge the battery, connect the charger to your phone and
outlet. You can also charge your phone via a USB cable.
To reduce energy wastage, disconnect your charger
from the plug when the battery is fully charged.
To reduce your phone’s power consumption, switch off
Wi-Fi, GPS, Bluetooth or apps running in the background
when not needed. In Settings you can also lower the
brightness of the screen, and shorten the length of
time before the screen goes to sleep.
Power on your phone1.2.2
Hold down the Power key until the phone powers on. It will
take a few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone you will be asked to set
the following options: language, mobile data, Google account,
date & time, etc.
If you power on your phone with no SIM card inserted you will
still be able to connect to a Wi-Fi network to sign into your
Google account and to use some features.
Power off your phone1.2.3
Hold down the Power key from the Home screen until the
Phone options appear, then select Power off.
Home screen1.3
You can bring all your favorite items (apps, shortcuts, folders
and widgets) to your Home screen for quick access. Touch the
Home key to switch to the Home screen.
Status bar
Status/Notification indicators•
Touch and drag down to open the •
Notification panel
Application tab
Touch to open All apps•
Slide left or right to view other panels on
the Home screen
Google Search bar
Touch • a to enter text search screen
Touch • b to enter voice search screen
Favorite tray apps
Touch to enter the app•
Touch and hold to move or change apps•
ab
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:5-Sec1:6IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:5-Sec1:6 2013-12-31 17:14:332013-12-31 17:14:33
78
The Home screen extends on either side of the screen to allow
more space for adding apps, shortcuts, etc. Slide the Home
screen horizontally left and right to get a complete view of the
Home screen. The white spot in the lower part of the screen
indicates which screen you are viewing.
Using the touchscreen1.3.1
Touch
To access an app, touch it with your finger.
Touch and hold
Touch and hold the Home screen to access the available
options for setting the wallpaper.
Drag
Touch and hold an item to be able to drag it to another
location.
Slide/Swipe
Slide the screen to scroll up and down lists, screens of apps,
images, web pages, etc.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw
them apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways.
Status bar1.3.2
From status bar, you can view both phone status (on the right
side) and notification information (on the left side).
Status icons
GPRS connected GPS is on
GPRS in use Roaming
EDGE connected No SIM card inserted
EDGE in use Vibrate mode
3G connected Ringer is silenced
3G in use Phone microphone
is mute
HSPA (3G+)
connected Battery is very low
HSPA (3G+) in use Battery is low
HSPAP (3G+)
connected Battery is partially
drained
HSPAP (3G+) in use Battery is full
Connected to a Wi-Fi
network Battery is charging
Bluetooth is on Headset connected
Connected to a
Bluetooth device No signal
Airplane mode Signal strength
Alarm is set
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:7-Sec1:8IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:7-Sec1:8 2013-12-31 17:14:332013-12-31 17:14:33
910
Notification icons
New GmailTM message Call in progress
New text or
multimedia message Missed call
Problem with SMS or
MMS delivery Call on hold
New Hangouts
message Call forwarding is on
New voicemail Uploading data
Upcoming event Downloading data
Data is synchronising Download finished
No microSD card
installed
An open Wi-Fi network
is available
Song is playing Phone is connected
via USB cable
Screenshot error Radio is on
USB tethering is on System update
available
Portable Wi-Fi hotspot
is on Connected to VPN
Screenshot captured International Roaming
is enabled
Carrier data use
threshold approaching
or exceeded
International Roaming
is disabled
Notification panel
Touch and drag down the Status bar to open the Notification
panel. Touch and drag up to close it. From the Notification
panel, you can open items and other reminders indicated by
notification icons or view wireless service information.
Touch to access Quick setting bar
Touch a notification and slide it sideways to delete it.
Touch the icon to clear all event–based notifications (other
ongoing notifications will remain).
Touch and then the Settings icon to access Settings.
Quick setting bar
• Touch icons to enable/disable functions
or to change modes
• Touch & hold to show the settings
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:9-Sec1:10IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:9-Sec1:10 2013-12-31 17:14:342013-12-31 17:14:34
11 12
Personalize your Home screen1.3.3
Add an app or widget
Touch the Application tab , then touch and hold the app
or widget to activate the Move mode, and drag the item to
any Home screen.
Reposition an app or widget
Touch and hold the item to be repositioned to activate the
Move mode, drag the item to the desired position and then
release. You can move items both on the Home screen and
the Favorite tray. Hold the icon on the left or right edge of the
screen to drag the item to another Home screen.
Remove
Touch and hold the item to be removed to activate the Move
mode, drag the item up to the top of the Remove icon, and
release after the item turns red.
Create folders
To make it easier to organize apps and shortcuts on the Home
screen and the Favorite tray, you can add them to a folder by
stacking one item on top of another. To rename a folder, open
it and touch the folder’s title bar to input the new name.
Wallpaper customisation
Touch and hold an empty area on the Home screen or go to
Settings > Display > Wallpaper to customize your wallpaper.
Application tab1.3.4
Touch from the Home screen to show a list of all your
apps.
To return to the Home screen, touch the Home key.
View Default/Most used/Recently installed apps
To view your Default/Most used/Recently installed apps,
touch key in apps list screen and choose your option.
Volume adjustment1.3.5
You can set the ringer, media and phone ringtone volume
by pressing the Volume up/down key or go to Settings >
Sound.
Apps and widgets list1.4
The list contains all pre-installed and newly installed apps
and widgets.
To open the list, touch from the Home screen. To return to
the Home screen, touch the Home key or the Back key.
Touch the icon to access the Play Store.
Text input2
Using the onscreen keyboard2.1
Onscreen keyboard settings
Touch the Application tab from the Home screen, select
Settings > Language & input, then touch the Settings icon
on the right of Google keyboard.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:11-Sec1:12IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:11-Sec1:12 2013-12-31 17:14:342013-12-31 17:14:34
13 14
Adjust the onscreen keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen
Keyboard orientation. You can also adjust it by changing the
settings (go to Settings > Display > Auto rotate screen).
Google keyboard2.1.1
Touch to switch between the symbol and numeric keyboard
Touch & hold, then select to enter
symbols/emoticons
Touch to enter text or numbers
Touch & hold to show input options; when Wi-Fi or data connection
is on, touch to enter voice input
Touch to switch between "abc/Abc"
mode; Touch & hold to switch between
"abc/ABC" mode
Text editing2.2
You can edit the text you have entered.
Touch and hold or double-tap on the text you would like •
to edit.
Drag the end points to change the highlighted selection.•
The following options will show: • Select all , Cut ,
Copy and Paste .
Touch the icon • to confirm.
Phone call 3
Placing a call3.1
You can easily make a call using Phone. Touch the Application
tab from the Home screen and select Phone.
Touch and hold to
access voicemail
Slide to access Call
log and Contacts
Contacts
Call log
Touch to hide the
dialpad
Enter the number you want from the dialpad directly or select
a contact from Contacts or Call log by sliding or touching
tabs, then touch to place the call.
The number you entered can be saved to Contacts by
touching key and selecting Add to Contacts.
If you make a mistake, you can delete the incorrect digits by
touching .
To hang up a call, touch .
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:13-Sec1:14IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:13-Sec1:14 2013-12-31 17:14:342013-12-31 17:14:34
15 16
Answering or rejecting a call3.2
When you receive a call, touch .
Slide the icon right to answer the call;•
Slide the icon left to reject the call;•
Slide the icon up to reject the call by sending a preset •
message.
To mute incoming calls, press the Volume up/down key
or turn the phone face down if Turn over to mute is active
(to turn this on, go to Settings > Gestures > Turn over to
mute).
View your call history3.3
You can view your call history by touching from the Dial
screen to view call history in categories of Incoming calls,
Outgoing calls, and Missed calls.
Speed dial settings3.4
You can access this screen by touching key and then
Speed Dial on Dial screen, then select contacts to define 2-9
screen keys as a speed dialer. Touch to remove contacts
from speed dial.
People 4
You can view and create contacts on your phone and
synchronize these with your Gmail contacts or other apps on
the web or on your phone.
When using People for the first time you are asked
to add new contacts, import contacts from your
SIM card or synchronize contacts from other app
accounts to your phone.
Adding a contact4.1
Touch the Application tab on the Home screen, select the
People, then touch the icon in the contact list to create
a new contact.
Contact group
list
Touch to search
contacts in contact list
Favorites
Contact list
Touch to add
contact
Importing, exporting and sharing 4.2
contacts
From the Contacts screen, touch key to open the options
menu, touch Import/Export, then select to import/export
contacts from/to your SIM card, Phone, microSD card, Phone
storage, Accounts, etc.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:15-Sec1:16IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:15-Sec1:16 2013-12-31 17:14:352013-12-31 17:14:35
17 18
To import/export a single contact from/to your SIM card,
choose an account and target SIM card(s), select the contact
you want to import/export, and touch to confirm.
To import/export all contacts from/to your SIM card, choose
an account and target SIM card(s), touch Select all and touch
to confirm.
You can share a single contact or contacts with others by
sending the contact’s vCard to them via Bluetooth, Gmail, etc.
To do this, touch a contact you want to share, touch key
and Share from contact details screen, then select the app to
perform this action.
Synchronising contacts in multiple 4.3
accounts
Contacts, data or other information can be synchronized
from multiple accounts, depending on the apps installed on
your phone.
Messaging 5
Your phone can create, edit and receive SMS and MMS
messages.
Touch the Application tab from the Home screen, then select
Messaging.
All messages you receive or send out can be saved
in your phone memory or SIM card. To view SMS
messages stored on your SIM card, touch key
from Messaging screen, then touch Settings > Text
messages (SMS) > Manage SIM messages.
Write message5.1
On the message list screen, touch the new message icon to
write new text/multimedia messages.
Touch to create a new message
Touch to search in all messages
Touch to view the whole message •
thread
Touch & hold message threads to •
delete messages or to add shortcut
Sending a text message
Enter the mobile phone number of the recipient on the
Type name or number bar or touch to add recipients,
then touch the Enter message bar to enter the text of the
message. When you’ve finished, touch to send the text
message.
An SMS of more than 160 characters will be charged
as several SMS. Specific letters (like accents, for
example) will also increase the size of the SMS,
so this may cause multiple SMS to be sent to your
recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos,
animations, slides and audio to other compatible phones and
e-mail addresses.
An SMS will be converted to MMS automatically when media
files (image, video, audio, slides, etc.) are attached or Subject
or email addresses are added.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:17-Sec1:18IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:17-Sec1:18 2013-12-31 17:14:352013-12-31 17:14:35
19 20
Email 6
Besides your Gmail account, you can also set-up external
email accounts on your phone.
Touch the Application tab from the Home screen, then select
Email.
An email wizard will guide you through the steps to set up an
email account.
1 Enter the email address and password of the account you
want to set up.
2 Touch Next. If the account you entered is not provided by
your service provider in the phone, you will be prompted to
go to the email account settings screen to enter settings
manually. Or you can touch Manual setup to directly enter
the incoming and outgoing settings for the email account
you are setting up.
3 Enter the account name and display name in outgoing
emails.
4 To add another email account, you can touch key and
Settings. Touch ADD ACCOUNT on the right of the title to
create a new account.
To create and send emails
1 Touch the icon on Inbox screen.
2 Enter recipient(s) email address(es) in the To field.
3 If necessary, touch key and touch Add Cc/Bcc to add a
copy or a blind copy to other recipients.
4 Enter the subject and the content of the message.
5 Touch key, then touch Attach file to add an
attachment.
6 Finally, touch to send.
7 If you do not want to send the mail right away, you can touch
key and Save draft or touch the Back key to save a copy.
Getting connected 7
Your phone can connect to the Internet using either GPRS/
EDGE/3G or Wi-Fi.
Connecting to the Internet7.1
GPRS/EDGE/3G7.1.1
The first time you turn on your phone with the SIM card
inserted, it will automatically configure a mobile network
service: GPRS, EDGE or 3G. If the network is not connected,
you can touch on the Quick setting bar.
To check the network connection you are using, touch the
Application tab on the Home screen, then touch Settings >
More... > Mobile networks > Access Point Names or Network
operators.
Wi-Fi7.1.2
You can connect to the Internet when your phone is within
range of a wireless network. Wi-Fi can be used on the phone
even without a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
1 Touch on Quick setting bar to go to Settings.
2 Touch the switch beside Wi-Fi to turn on/off Wi-Fi.
3 Touch Wi-Fi: detailed information of all detected Wi-Fi
networks is displayed in the Wi-Fi networks section.
4
Touch a Wi-Fi network to connect to it. If the network you
selected is secured, you are required to enter a password
or other credentials (contact network operator for details).
When you’re finished, touch Connect.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:19-Sec1:20IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:19-Sec1:20 2013-12-31 17:14:352013-12-31 17:14:35
21 22
Browser 7.2
Using the Browser you can enjoy surfing the Web.
To get onto the Web, touch the Application tab from the Home
screen, then touch Browser.
To go to a web page
On Browser screen, touch the URL box at the top, enter the
address of the web page, then touch to confirm.
Connecting to a computer via USB7.3
With the USB cable, you can transfer media files and other files
between your phone and computer.
To connect/disconnect your phone to/from the computer:
Use the USB cable that came with your phone to connect
the phone to a USB port on your computer. You will receive a
notification that the USB is connected.
If you want to change the USB connection type, open the
Notifications panel and touch .
To locate data you have transferred or downloaded in the
internal storage:
1 Touch the Application tab from the Home screen to open
the apps list.
2 Touch File Manager.
All data you have downloaded is stored in File Manager,
where you can view media files (videos, photos, music and
others), rename files, install apps onto your phone, etc.
Sharing your phone’s mobile data 7.4
connection
You can share your phone’s mobile data connection with a
single computer via a USB cable (USB tethering) or with up to
eight devices at once by turning your phone into a portable
Wi-Fi hotspot.
To turn on USB tethering or Portable Wi-Fi hotspot:
1 Touch on Quick setting bar to go to Settings.
2 Touch More... > Tethering & portable hotspot.
3 Mark the checkbox of USB tethering or turn on Wi-Fi
hotspot to activate this function.
Sharing data may incur additional charges from
your network operator. Extra fees may also be
charged in roaming areas.
Find my location (GPS)8
To turn on your phone’s global positioning system (GPS)
satellite receiver:
1 Touch on Quick setting bar to go to Settings.
2 Touch Location services.
3 Mark the checkbox of Access to my location, then GPS
satellites will be automatically on.
Find your location by opening Maps:
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:21-Sec1:22IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:21-Sec1:22 2013-12-31 17:14:352013-12-31 17:14:35
23 24
Use your phone’s GPS satellite receiver to determine your
approximate location. The process of accessing the GPS
satellite and setting your phone’s location for the first time may
take require up to 5 minutes. You will need to stand in a place
with a clear view of the sky and avoid moving. After initial set up,
GPS will only require 20-40 seconds to identify your location.
You can then start the process of finding the best route to
another location.
Data backup9
This phone enables you to back up your phone’s settings and
other app data to Google Servers, using your Google Account.
If you replace your phone, the settings and data you’ve backed
up can be restored onto the new phone the first time you sign
in with your Google Account.
To activate this function:
1 Touch on Quick setting bar to go to Settings.
2 Touch Backup and reset > Back up my data.
3 Mark the checkbox.
If you’ve turned on this function, a wide variety of settings
and data are backed up, including your Wi-Fi passwords,
bookmarks, a list of the apps you’ve installed, the words you’ve
added to the dictionary used by the onscreen keyboard, and
most of the settings that you configure with the Settings app.
If you turn this option off, it will stop backing up your settings,
and any existing backups are deleted from Google Servers.
Factory data reset 10
To activate a factory data reset:
1 Touch on Quick setting bar to go to Settings.
2 Touch Backup and reset > Factory data reset.
3 Touch Reset phone > Erase everything.
Reset phone will erase all of your personal data from
internal phone storage, including information about your
Google Account, any other accounts, your system and
app settings, and any downloaded apps. Resetting the
phone does not erase any system software updates you
have downloaded. If you reset the phone in this way, you are
prompted to re-enter the same kind of information as when
you first started Android.
If you’re unable to turn your phone on, there is another
alternative to perform a factory data reset by pressing the
Volume up key and the Power key at same time under power
off mode until the screen lights up.
Apps 11
Your phone is preloaded with some Google apps, and more
third-party apps can be downloaded onto it.
With the built-in apps, you can
Communicate with friends.•
Exchange messages or emails with friends.•
Track your location, view traffic situations, search for locations •
and get navigation information to your destination.
You can download more apps from the Play Store.•
For more information about these apps, please check user
manual online: vodafone.com/smart4mini.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:23-Sec1:24IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:23-Sec1:24 2013-12-31 17:14:352013-12-31 17:14:35
25 26
Update your phone’s 12
software
Using the FOTA (Firmware Over The Air) Upgrade tool you can
update your phone’s software.
To access Software Updates, open the Notification panel and
touch and then , then touch About phone > Software
updates. Or you can directly touch and access Settings >
About phone > Software updates. Touch Check for updates,
and the phone will search for the latest software. If you want to
update the system, please touch Download, and when that’s
finished, touch Install to complete the upgrade. Now your
phone will have the latest version of the software.
You should turn on data connection before searching for
updates. Settings for auto-check intervals and reminders about
upgrades are also available once you restart the phone.
If you have chosen auto-check, when the system discovers the
new version, the icon will appear in the status bar. Touch
the notification to access the Software Updates directly.
During FOTA downloading or updating, to avoid
errors in locating the correct update packages, do
not change your default storage location.
Safety and use13
We recommend that you read this chapter carefully before
using your mobile phone. The manufacturer disclaims any
liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained
herein.
TRAFFIC SAFETY
Given that studies show that using a mobile phone while
driving a vehicle constitutes a real risk, even when the hands-
free kit is used (car kit, headset...), drivers are requested to
refrain from using their mobile phone when the vehicle is not
parked. Check the laws and regulations on the use of wireless
mobile phones and their accessories in the areas where you
drive. Always obey them. The use of these devices may be
prohibited or restricted in certain areas.
When driving, do not use your mobile phone and headphone
to listen to music or to the radio. Using a headphone can be
dangerous and forbidden in some areas.
When switched on, your mobile phone emits electromagnetic
waves that can interfere with the vehicle’s electronic systems
such as ABS anti-lock brakes or airbags. To ensure that there
is no problem:
- do not place your mobile phone on top of the dashboard or
within an airbag deployment area,
- check with your car dealer or the car manufacturer to make
sure that the car’s electronic devices are shielded from
mobile phone RF energy.
CONDITIONS OF USE
You are advised to switch off the mobile phone from time to
time to optimize its performance.
Remember to abide by local authority rules of mobile phone
use on aircrafts.
Operational Warnings: Obey all posted signs when using
mobile devices in public areas.
Follow Instructions to Avoid Interference Problems: Turn off
your mobile device in any location where posted notices
instruct you to do so. In an aircraft, turn off your mobile device
whenever instructed to do so by airline staff. If your mobile
device offers an airplane mode or similar feature, consult
airline staff about using it in flight.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:25-Sec1:26IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:25-Sec1:26 2013-12-31 17:14:352013-12-31 17:14:35
27 28
Switch the mobile phone off when you are in health care
facilities, except in designated areas. As with many other types
of equipment now in regular use, mobile phones can interfere
with other electrical or electronic devices, or equipment using
radio frequency.
Switch the mobile phone off when you are near gas or
flammable liquids. Strictly obey all signs and instructions
posted in a fuel depot, gas station, or chemical plant, or in any
potentially explosive atmosphere.
When the mobile phone is switched on, it should be kept at
least 15 cm from any medical device such as a pacemaker,
a hearing aid or insulin pump. In particular when using the
mobile phone you should hold it against the ear on the
opposite side to the device, if any.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about
using your mobile device with your implantable medical
device, consult your healthcare provider.
To avoid hearing impairment, answer the call before holding
your mobile phone to your ear. Also move the handset away
from your ear while using the “hands-free” option because the
amplified volume might cause hearing damage.
It is recommended to have proper supervision while small
children use your mobile phone.
When replacing the cover please note that your mobile
phone may contain substances that could create an allergic
reaction.
Always handle your mobile phone with care and keep it in a
clean and dust-free place.
Do not allow your mobile phone to be exposed to adverse
weather or environmental conditions (moisture, humidity, rain,
infiltration of liquids, dust, sea air, etc.). The manufacturer’s
recommended operating temperature range is -10°C (14°F)
to +55°C (131°F) (the max value depends on device, materials
and housing paint/texture).
Over 55°C (131°F) the legibility of the mobile phone’s display
may be impaired, though this is temporary and not serious.
Do not open or attempt to repair your mobile phone yourself.
Do not drop, throw or try to bend your mobile phone.
Do not use the mobile phone if the glass made screen, is
damaged, cracked or broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are
recommended by TCT Mobile Limited and its affiliates and are
compatible with your mobile phone model.TCT Mobile Limited
and its affiliates disclaim any liability for damage caused by
the use of other chargers or batteries.
Your mobile phone should not be disposed of in a municipal
waste. Please check local regulations for disposal of electronic
products.
Remember to make back-up copies or keep a written record of
all important information stored in your mobile phone.
Some people may suffer epileptic seizures or blackouts when
exposed to flashing lights, or when playing video games.
These seizures or blackouts may occur even if a person never
had a previous seizure or blackout. If you have experienced
seizures or blackouts, or if you have a family history of such
occurrences, please consult your doctor before playing video
games on your mobile phone or enabling a flashing-lights
feature on your mobile phone. Parents should monitor their
children’s use of video games or other features that incorporate
flashing lights on the mobile phones. All persons should
discontinue use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. To limit
the likelihood of such symptoms, please take the following
safety precautions:
- Play at the farthest distance possible from the screen.
When you play games on your mobile phone, you may
experience occasional discomfort in your hands, arms,
shoulders, neck, or other parts of your body.
Follow these instructions to avoid problems such as tendinitis,
carpal tunnel syndrome, or other musculoskeletal disorders:
- Take a minimum of a 15-minute break every hour of game
playing.
- If your hands, wrists, or arms become tired or sore while
playing, stop and rest for several hours before playing
again.
- If you continue to have sore hands, wrists, or arms during or
after playing, stop the game and see a doctor.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:27-Sec1:28IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:27-Sec1:28 2013-12-31 17:14:362013-12-31 17:14:36
29 30
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen
at high volume levels for long periods. Exercise
caution when holding your device near your ear
while the loudspeaker is in use.
PRIVACY
Please note that you must respect the laws and regulations
in force in your jurisdiction or other jurisdiction(s) where you
will use your mobile phone regarding taking photographs
and recording sounds with your mobile phone. Pursuant to
such laws and regulations, it may be strictly forbidden to take
photographs and/or to record the voices of other people or
any of their personal attributes, and reproduce or distribute
them, as this may be considered to be an invasion of privacy.
It is the user’s sole responsibility to ensure that prior
authorization be obtained, if necessary, in order to record
private or confidential conversations or take a photograph of
another person; the manufacturer, the seller or vendor of your
mobile phone (including the operator) disclaim any liability
which may result from the improper use of the mobile phone.
BATTERY AND ACCESSORIES
Before removing the battery from your mobile phone, please
make sure that the mobile phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic
fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a
battery,
- Do not burn or dispose of a used battery in the garbage or
store it at temperatures above 60°C (140°F).
Batteries must be disposed of in accordance with locally
applicable environmental regulations. Only use the battery
for the purpose for which it was designed. Never use damaged
batteries or those not recommended by TCT Mobile Limited
and/or its affiliates.
This symbol on your mobile phone, the battery and
the accessories means that these products must be
taken to collection points at the end of their life:
- Municipal waste disposal centers with specific bins
for these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being
disposed of in the environment, so that their components
can be reused.
In European Union countries:
These collection points are accessible free of charge. All
products with this sign must be brought to these collection
points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be thrown into
ordinary bins if your jurisdiction or your region has suitable
recycling and collection facilities; instead they are to be taken
to collection points for them to be recycled.
In the United States you may learn more about CTIA’s
Recycling Program at http://www.gowirelessgogreen.org/
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
CHARGERS
Home A.C./ Travel chargers will operate within the temperature
range of: 0°C (32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the
standard for safety of information technology equipment and
office equipment use. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction
may not work in another jurisdiction. They should be used for
this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5 V, 550 mA
Battery: Lithium 1400 mAh
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:29-Sec1:30IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:29-Sec1:30 2013-12-31 17:14:362013-12-31 17:14:36
31 32
RADIO WAVES
THIS MOBILE PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission
limits for exposure to radio-frequency (RF) energy. These
limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by
independent scientific organizations through periodic and
thorough evaluation of scientific studies. These guidelines
include a substantial safety margin designed to ensure the
safety of all persons, regardless of age and health.
The exposure standard for mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by public authorities such as the Federal
Communications Commission of the US Government (FCC), or
by Industry Canada, is 1.6 W/kg averaged over 1 gram of body
tissue. Tests for SAR are conducted using standard operating
positions with the mobile phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power
level, the actual SAR level of the mobile phone while operating
can be well below the maximum value. This is because the
mobile phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station antenna,
the lower the power output of the mobile phone.
Before a mobile phone model is available for sale to the
public, compliance with national regulations and standards
must be shown.
The highest SAR value for this model mobile phone when tested is
0.6 W/Kg for use at the ear and 0.81 W/Kg for use close to
the body.
While there may be differences between the SAR levels of
various mobile phones and at various positions, they all
meet the government requirement for RF exposure. For body-
worn operation, the mobile phone meets FCC RF exposure
guidelines provided that it is used with a non-metallic
accessory with the handset at least 10 mm from the body.
Use of other accessories may not ensure compliance with FCC
RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
www.ctia.org/
The World Health Organization (WHO) considers that present
scientific information does not indicate the need for any
special precautions for use of mobile phones. If individuals
are concerned, they might choose to limit their own or
their children’s RF exposure by limiting the length of calls,
or using “hands-free” devices to keep mobile phones away
from the head and body. (fact sheet n°193). Additional WHO
information about electromagnetic fields and public health
are available on the following website: http://www.who.int/
peh-emf.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician
for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:31-Sec1:32IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:31-Sec1:32 2013-12-31 17:14:362013-12-31 17:14:36
33 34
For the receiver devices associated with the operation of
a licensed radio service (e.g. FM broadcast), they bear the
following statement:
This device complies with Part 15 of the FCC Rules. Operation
is subject to the condition that this device does not cause
harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For
optimal operation, you should avoid touching it or degrading
it.
As mobile devices offer a range of functions, they can be used
in positions other than against your ear. In such circumstances
the device will be compliant with the guidelines when used
with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any
metal and that it positions the mobile phone at least 10 mm
away from the body.
FCC ID: RAD439
Licences
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by TCT Mobile Limited and its affiliates
is under license. Other trademarks and trade
names are those of their respective owners.
Vodafone 785 Bluetooth
QD ID B021282
The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.
Google, the Google logo, Android, the Android
logo, Google Search TM, Google MapsTM, Gmail TM,
YouTube, Google Play Store, Google Latitude TM
and Hangouts TM are trademarks of Google Inc.
The Android robot is reproduced or modified from work
created and shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution License
(the text will show when you touch and hold Google legal in
Settings > About phone > Legal information) (1).
(1) This may not be available depending on your country.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:33-Sec1:34IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:33-Sec1:34 2013-12-31 17:14:362013-12-31 17:14:36
35 36
You have purchased a product which uses the open source
(http://opensource.org/) programs mtd, msdosfs, netfilter/
iptables and initrd in object code and other open source
programs licensed under the GNU General Public License and
Apache License.
We will provide you with a complete copy of the corresponding
source codes upon request within a period of three years from
the distribution of the product.
You may download the source codes from http://vodafone.
com/smart4mini. The provision of the source code is free of
charge from the internet.
Notice
The information in this manual is subject to change without
notice.
Every effort has been made in the preparation of this manual
to ensure accuracy of the contents, but all statements,
information, and recommendations in this manual do not
constitute a warranty of any kind, expressed or implied. Read
the safety precautions and safety information carefully to
ensure that you use this wireless device in a correct and safe
manner.
TCT Mobile Limited Address:
Room 1910-12A, Tower 3, China HK City, 33 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
General information14
• Website: www.alcatelonetouch.com
• Facebook: http://www.facebook.com/alcatelonetouchusa
• Twitter: http://www.twitter.com/alcatel1touch
• Hot Line Number: In the United States, call 877-702-3444
for technical support.
On our Internet site, you will find our FAQ (Frequently Asked
Questions) section. You can also contact us by e-mail to ask
any questions you may have.
An electronic version of this user guide is available in English
and other languages according to availability on our server:
www.alcatelonetouch.com
Your telephone is a transceiver that operates on GSM in triple-
band (900/1800/1900 MHz) or UMTS in dual-band (900/2100
MHz).
Protection against theft (1)
Your mobile phone is identified by an IMEI (mobile phone
serial number) shown on the packaging label and in the
product’s memory. We recommend that you note the number
the first time you use your mobile phone by entering *#06#
and keep it in a safe place. It may be requested by the police
or your operator if your mobile phone is stolen.
Disclaimer
There may be certain differences between the user manual
description and the mobile phone’s operation, depending on
the software release of your mobile phone or specific operator
services.
TCT Mobile shall not be held legally responsible for such
differences, if any, nor for their potential consequences, which
responsibility shall be borne by the operator exclusively.
(1) Contact your network operator to check service availability.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:35-Sec1:36IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:35-Sec1:36 2013-12-31 17:14:362013-12-31 17:14:36
37 38
TCT Mobile (US), Inc. 15
Warranty
TCT Mobile (US), Inc. warrants to the original retail purchaser
of this wireless device that should this product or part thereof
during normal consumer usage and condition be proven
to be defective in material or workmanship that results in
product failure within the first twelve (12) months from the
date of purchase as shown on your original sales receipt from
an authorized sales agent. Such defect(s) will be repaired
or replaced (with new or rebuilt parts) at the company’s
option without charge for parts or labor directly related to
the defect(s).
Batteries, power adapters, and other accessories sold as in box
items are also warranted against defects and workmanship
that results in product failure within the first six (6) months
period from the date of purchase as shown on your original
sales receipt. Such defect(s) will be repaired or replaced (with
new or rebuilt parts) at the company’s option without charge
for parts or labor directly related to the defect(s).
The limited warranty for your wireless device will be voided if
any of the following conditions occur:
• Non-compliance with the instructions for use or installation,
or with technical and safety standards applicable in the
geographical area where your phone is used;
• Connection to any equipment not supplied or not
recommended by TCT Mobile (US), Inc.;
• Modification or repair performed by individuals not
authorized by TCT Mobile (US), Inc. or its affiliates;
• Changes to the device operating system by the user or third
party applications;
• Acts of god such as inclement weather, lightning, power
surges, fire, humidity, infiltration of liquids or foods, chemical
products, download of files, crash, high voltage, corrosion,
oxidation;
• Removal or altering of the wireless device’s event labels or
serial numbers (IMEI);
• Damage from exposure to water or other liquids, moisture,
humidity, excessive temperatures or extreme environmental
conditions, sand, excess dust and any condition outside the
operating guidelines;
• Defects in appearance, cosmetic, decorative or structural
items such as framing and non-operative parts;
• Damage as result of physical abuse regardless of cause.
There are no express warranties, whether written, oral or
implied, other than this printed limited warranty or the
mandatory warranty provided by your jurisdiction. In no
event shall TCT Mobile (US), Inc. or any of its affiliates be
liable for incidental or consequential damages of any nature
whatsoever, including but not limited to commercial loss, to
the full extent those damages can be disclaimed by law. Some
states do not allow the exclusion or limitation of incidental
or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions
may not apply to you.
How to obtain Support: Contact the customer care center
by calling (877-702-3444) or going to (http://www.
alcatelonetouch.com/usa/). We have placed many self-help
tools that may help you to isolate the problem and eliminate
the need to send your wireless device in for service. In the
case that your wireless device is no longer covered by this
limited warranty due to time or condition, you may utilize our
out of warranty repair options.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:37-Sec1:38IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:37-Sec1:38 2013-12-31 17:14:362013-12-31 17:14:36
39
How to obtain Hardware Service within the terms of this
warranty: Create a user profile (alcatel.finetw.com) and then
create an RMA for the defective device. Ship the device with
a copy of the original proof of purchase (e.g. original copy of
the dated bill of sale, invoice) with the owner’s return address
(No PO Boxes accepted), wireless carrier’s name, alternate
daytime phone number, and email address with a complete
problem description. Only ship the device. Do not ship the
SIM card, memory cards, or any other accessories such as
the power adapter. You must properly package and ship the
wireless device to the repair center. TCT Mobile (US), Inc. is not
responsible for devices that do not arrive at the service center
or are damaged in transit. Insurance is recommended with
proof of delivery. Upon receipt, the service center will verify
the warranty conditions, repair, and return your device to the
address provided in the RMA. Check the warranty repair status
by going online with the RMA number on web portal.
IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:39IP4776_VF785_QG_Eng_USA_01_131231.indd Sec1:39 2013-12-31 17:14:362013-12-31 17:14:36
