TCT Mobile 511 Mobile phone with Bluetooth User Manual IP5020 BP61 QG Eng USA 03 140709 indd
TCT Mobile Limited Mobile phone with Bluetooth IP5020 BP61 QG Eng USA 03 140709 indd
User Manual
1
English - CJB2811ALAAA
Quick Start
Guide
For more information about how to use the
phone, please go to www.alcatelonetouch.com.
Also on our website you can find helpful FAQs,
realize software upgrade, etc.
IP5020_BP61_QG_Eng_USA_03_140709.indd 1IP5020_BP61_QG_Eng_USA_03_140709.indd 12014-7-9 17:36:122014-7-9 17:36:12
2
Table of Contents
1 Your BP61 ......................................................... 3
2 Getting started ................................................ 5
3 Pairing ................................................................ 6
4 Phone ................................................................. 7
5 Remote ..............................................................8
6 Tools ...................................................................9
7 Settings.............................................................10
IP5020_BP61_QG_Eng_USA_03_140709.indd 2IP5020_BP61_QG_Eng_USA_03_140709.indd 22014-7-9 17:36:122014-7-9 17:36:12
3
1 Your BP61 .........
1.1 Key and connectors
micro-USB
connector
Power key
Volume key
End key
Send key
Space key
IP5020_BP61_QG_Eng_USA_03_140709.indd 3IP5020_BP61_QG_Eng_USA_03_140709.indd 32014-7-9 17:36:122014-7-9 17:36:12
4
• Press: Lock the screen
• Press and hold: Power on/off
(Send key)
• Answer/Send a call
(End key)
• Press: End a call
Return to Home screen
Light on/off the screen
In Edit mode:
• Press: Add space
In Edit mode:
• Press: change input methods
• Press and hold: access the language
list
IP5020_BP61_QG_Eng_USA_03_140709.indd 4IP5020_BP61_QG_Eng_USA_03_140709.indd 42014-7-9 17:36:122014-7-9 17:36:12
5
2 Getting started
2.1 Charging the battery
Connect the battery charger to your phone and
outlet respectively.
To reduce power consumption and
energy waste when battery is fully
charged, disconnect your charger from
the plug.
2.2 Power on your phone
Hold down the key until the phone powers
on.
2.3 Power off your phone
Hold down the key from the Home screen.
IP5020_BP61_QG_Eng_USA_03_140709.indd 5IP5020_BP61_QG_Eng_USA_03_140709.indd 52014-7-9 17:36:122014-7-9 17:36:12
6
3 Pairing ..............
You can activate Bluetooth pairing in either the
BP61 or your Host. Please turn on Bluetooth first.
BP61 activated connection: From the main
menu, select Settings\Bluetooth\Pairing and
touch Search, all devices found will be listed, then
choose the device you want to pair.
Host activated connection: You can also
access the Bluetooth of your host and search
for ALCATEL ONETOUCH BP61 to pair with it.
When pairing is successful, the host name will be
visible on BP61.
You only need to pair your BP61 once. It will
automatically reconnect to your host once you
turn on the BP61 and host Bluetooth.
IP5020_BP61_QG_Eng_USA_03_140709.indd 6IP5020_BP61_QG_Eng_USA_03_140709.indd 62014-7-9 17:36:122014-7-9 17:36:12
7
4 Phone ............
4.1 Messaging
You can access this menu by selecting Phone\
Messaging in the main menu.
With the BP61 you can synchronize new
messages with the host, compose new messages
and reply to messages. Sent messages will be
synchronized with the host sent box.
4.2 Contacts
Contacts enables quick and easy access to the
people you want to reach. You can access this
function by selecting Phone\Contacts from
the main menu.
You can view contacts which are synchronized
with the host. Touch a contact to see details, make
a call or send messages.
4.3 Call log
You can access this function by selecting Phone\
Call log from the main menu.
Your BP61 can synchronize all missed calls,
outgoing and incoming calls with the host, but
you will not be able to delete this information
from the BP61.
You can select a contact in the call log list and
then press the send key to make a call or send
a text message.
4.4 Notifications
You can see all of the items and other reminders
displayed in the notification panel of the host,
but you can only delete local notifications in
your BP61.
IP5020_BP61_QG_Eng_USA_03_140709.indd 7IP5020_BP61_QG_Eng_USA_03_140709.indd 72014-7-9 17:36:122014-7-9 17:36:12
8
5 Remote ........
5.1 Music
The BP61 cannot install music directly, but it
can control the music player via the host. Select
Remote\Music from the main menu to access
this function.
You can also search through your music using the
following four categories: Artist, Albums, Songs,
Playlist.
5.2 Camera
You can take photos by controlling the host’s
camera with this function. Use the volume key
to zoom in/out and then touch the screen to
capture a shot. The pictures will then be saved
in your host.
5.3 Multimedia
The BP61 includes a Remote Control function.
You can remotely control a native video player,
music player, camera, etc. If it can be paired with
your BP61.
5.4 Presentation
If there are PPT files in your host, you can control
them remotely. Touch Remote\Presentation
from the main menu to access this function.
IP5020_BP61_QG_Eng_USA_03_140709.indd 8IP5020_BP61_QG_Eng_USA_03_140709.indd 82014-7-9 17:36:122014-7-9 17:36:12
9
6 Tools .............
6.1 Calculator
Access this feature by selecting “Calculator”
from “Tools”.
Enter a number, select the type of operation to
be performed, enter the second number and then
press “=” to display the result.
6.2 Find it
If you cannot locate your host, go to Tools\Find
it and the host will ring.
6.3 Calendar
You can view the events created in the Calendar
of your host to keep track of important meetings,
appointments, etc.
6.4 Recorder
To access this function, touch Tools\Recorder
from the main menu.
Recorder allows you to record voice/sound. Once
the recording is completed, you can choose to
discard or save it in your host.
IP5020_BP61_QG_Eng_USA_03_140709.indd 9IP5020_BP61_QG_Eng_USA_03_140709.indd 92014-7-9 17:36:132014-7-9 17:36:13
10
7 Settings ........
From the main menu, select Settings to select
various functions which will enable you to
customize your BP61.
7.1 Phone
7.1.1 Phone settings
You can customize the language, input mode, LCD
backlight and notifications for your BP61.
7.1.2 Security (1)
You can turn on or turn off your password on
boot and auto keypad lock. You can also change
the password.
7.1.2 Factory reset (1)
You can input a password to restore factory
settings.
7.2 Bluetooth
Turn on Visibility so that other Bluetooth
devices can find your BP61.
You can also refer to your device name and info
with this menu.
(1) The factory data reset password and first boot
password are 1234.
IP5020_BP61_QG_Eng_USA_03_140709.indd 10IP5020_BP61_QG_Eng_USA_03_140709.indd 102014-7-9 17:36:132014-7-9 17:36:13
11
7.3 Profiles
With this menu, you can personalize ringtones for
different events and environments.
7.4 Update (1)
You can use FOTA upgrade tool to update your
host's software.
(1) just for HERO2 and Phantom.
IP5020_BP61_QG_Eng_USA_03_140709.indd 11IP5020_BP61_QG_Eng_USA_03_140709.indd 112014-7-9 17:36:132014-7-9 17:36:13
12
Safety and use .........
We recommend that you read this chapter carefully
before using your mobile phone. The manufacturer
disclaims any liability for damage, which may result
as a consequence of improper use or use contrary
to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile
phone while driving a vehicle constitutes a real
risk, even when the hands-free kit is used (car kit,
headset...), drivers are requested to refrain from
using their mobile phone when the vehicle is not
parked. Check the laws and regulations on the use
of wireless mobile phones and their accessories
in the areas where you drive. Always obey them.
The use of these devices may be prohibited or
restricted in certain areas.
When driving, do not use your mobile phone
and headphone to listen to music or to the
radio. Using a headphone can be dangerous and
forbidden in some areas.
When switched on, your mobile phone emits
electromagnetic waves that can interfere with
the vehicle’s electronic systems such as ABS
anti-lock brakes or airbags. To ensure that there
is no problem:
- do not place your mobile phone on top of
the dashboard or within an airbag deployment
area,
- check with your car dealer or the car
manufacturer to make sure that the car’s
electronic devices are shielded from mobile
phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the mobile phone
from time to time to optimize its performance.
Remember to abide by local authority rules of
mobile phone use on aircrafts.
Operational Warnings: Obey all posted signs
when using mobile devices in public areas.
IP5020_BP61_QG_Eng_USA_03_140709.indd 12IP5020_BP61_QG_Eng_USA_03_140709.indd 122014-7-9 17:36:132014-7-9 17:36:13
13
Follow Instructions to Avoid Interference
Problems: Turn off your mobile device in any
location where posted notices instruct you to
do so. In an aircraft, turn off your mobile device
whenever instructed to do so by airline staff. If
your mobile device offers an airplane mode or
similar feature, consult airline staff about using
it in flight.
Switch the mobile phone off when you are in health
care facilities, except in designated areas. As with
many other types of equipment now in regular use,
mobile phones can interfere with other electrical
or electronic devices, or equipment using radio
frequency.
Switch the mobile phone off when you are near
gas or flammable liquids. Strictly obey all signs and
instructions posted in a fuel depot, gas station,
or chemical plant, or in any potentially explosive
atmosphere.
When the mobile phone is switched on, it should
be kept at least 15 cm from any medical device
such as a pacemaker, a hearing aid or insulin pump.
In particular when using the mobile phone you
should hold it against the ear on the opposite side
to the device, if any.
Read and follow the directions from the
manufacturer of your implantable medical device.
If you have any questions about using your mobile
device with your implantable medical device,
consult your healthcare provider.
To avoid hearing impairment, answer the call
before holding your mobile phone to your ear.
Also move the handset away from your ear
while using the “hands-free” option because the
amplified volume might cause hearing damage.
It is recommended to have proper supervision while
small children use your mobile phone.
Please note that your phone is a unibody device,
the back cover and battery are not removable.
Do not attempt to disassemble your phone. If
IP5020_BP61_QG_Eng_USA_03_140709.indd 13IP5020_BP61_QG_Eng_USA_03_140709.indd 132014-7-9 17:36:132014-7-9 17:36:13
14
you disassemble your phone the warranty will not
apply. Also disassembling the phone may damage
the battery, and may cause leakage of substances
that could create an allergic reaction.
Always handle your mobile phone with care and
keep it in a clean and dust-free place.
Do not allow your mobile phone to be
exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration
of liquids, dust, sea air, etc.). The manufacturer’s
recommended operating temperature range is
-10°C (14°F) to +55°C (131°F) (the max value
depends on device, materials and housing paint/
texture).
Over 55°C (131°F) the legibility of the mobile
phone’s display may be impaired, though this is
temporary and not serious.
Do not open or attempt to repair your mobile
phone yourself.
Do not drop, throw or try to bend your mobile
phone.
Do not use the mobile phone if the glass made
screen, is damaged, cracked or broken to avoid
any injury.
Do not paint it.
Use only batteries, battery chargers, and
accessories which are recommended by
TCT Mobile Limited and its affiliates and are
compatible with your mobile phone model.TCT
Mobile Limited and its affiliates disclaim any
liability for damage caused by the use of other
chargers or batteries.
Your mobile phone should not be disposed of in
a municipal waste. Please check local regulations
for disposal of electronic products.
Remember to make back-up copies or keep
a written record of all important information
stored in your mobile phone.
Some people may suffer epileptic seizures or
blackouts when exposed to flashing lights, or
when playing video games. These seizures or
IP5020_BP61_QG_Eng_USA_03_140709.indd 14IP5020_BP61_QG_Eng_USA_03_140709.indd 142014-7-9 17:36:132014-7-9 17:36:13
15
blackouts may occur even if a person never
had a previous seizure or blackout. If you have
experienced seizures or blackouts, or if you
have a family history of such occurrences, please
consult your doctor before playing video games
on your mobile phone or enabling a flashing-
lights feature on your mobile phone. Parents
should monitor their children’s use of video
games or other features that incorporate flashing
lights on the mobile phones. All persons should
discontinue use and consult a doctor if any
of the following symptoms occur: convulsion,
eye or muscle twitching, loss of awareness,
involuntary movements, or disorientation. To limit
the likelihood of such symptoms, please take the
following safety precautions:
- Play at the farthest distance possible from the
screen.
When you play games on your mobile phone, you
may experience occasional discomfort in your
hands, arms, shoulders, neck, or other parts of your
body. Follow these instructions to avoid problems
such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders:
- Take a minimum of a 15-minute break every
hour of game playing.
- If your hands, wrists, or arms become tired or
sore while playing, stop and rest for several
hours before playing again.
- If you continue to have sore hands, wrists, or
arms during or after playing, stop the game and
see a doctor.
PROTECT YOUR HEARING
To prevent possible hearing damage,
do not listen at high volume levels for
long periods. Exercise caution when
holding your device near your ear
while the loudspeaker is in use.
IP5020_BP61_QG_Eng_USA_03_140709.indd 15IP5020_BP61_QG_Eng_USA_03_140709.indd 152014-7-9 17:36:132014-7-9 17:36:13
16
• PRIVACY:
Please note that you must respect the laws
and regulations in force in your jurisdiction or
other jurisdiction(s) where you will use your
mobile phone regarding taking photographs
and recording sounds with your mobile phone.
Pursuant to such laws and regulations, it may be
strictly forbidden to take photographs and/or to
record the voices of other people or any of their
personal attributes, and reproduce or distribute
them, as this may be considered to be an invasion
of privacy.
It is the user’s sole responsibility to ensure that
prior authorization be obtained, if necessary,
in order to record private or confidential
conversations or take a photograph of another
person; the manufacturer, the seller or vendor
of your mobile phone (including the operator)
disclaim any liability which may result from the
improper use of the mobile phone.
• BATTERY AND ACCESSORIES:
Please note your phone is a unibody device,
the back cover and battery are not removable.
Observe the following precautions:
- Do not attempt to open the back cover,
- Do not attempt to eject, replace and open
battery,
- Do not punctuate the back cover of your
phone,
- Do not burn or dispose of your phone in
household rubbish or store it at temperature
above 60°C.
Phone and battery as a unibody device must be
disposed of in accordance with locally applicable
environmental regulations.
IP5020_BP61_QG_Eng_USA_03_140709.indd 16IP5020_BP61_QG_Eng_USA_03_140709.indd 162014-7-9 17:36:132014-7-9 17:36:13
17
This symbol on your mobile phone,
the battery and the accessories
means that these products must be
taken to collection points at the end
of their life:
- Municipal waste disposal centers
with specific bins for these items of
equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances
being disposed of in the environment, so that their
components can be reused.
In European Union countries:
These collection points are accessible free of
charge. All products with this sign must be
brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not be
thrown into ordinary bins if your jurisdiction or
your region has suitable recycling and collection
facilities; instead they are to be taken to collection
points for them to be recycled.
In the United States you may learn more
about CTIA’s Recycling Program at www.
recyclewirelessphones.com
CAUTION: RISK OF EXPLOSION IF BATTERY
IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
• CHARGERS
Home A.C./ Travel chargers will operate within
the temperature range of: 0°C (32°F) to 40°C
(104°F).
The chargers designed for your mobile phone
meet with the standard for safety of information
technology equipment and office equipment
use. Due to different applicable electrical
specifications, a charger you purchased in one
jurisdiction may not work in another jurisdiction.
They should be used for this purpose only.
IP5020_BP61_QG_Eng_USA_03_140709.indd 17IP5020_BP61_QG_Eng_USA_03_140709.indd 172014-7-9 17:36:132014-7-9 17:36:13
18
Characteristics of power supply (depending
on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 150 mA
Output: 5 V, 550 mA
Battery: Lithium 400 mAh
• RADIO WAVES:
THIS MOBILE PHONE MEETS THE
GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your mobile phone is equipped with a built-in
antenna. For optimal operation, you should avoid
touching it or degrading it.
As mobile devices offer a range of functions,
they can be used in positions other than against
your ear. In such circumstances the device will
be compliant with the guidelines when used with
headset or usb data cable. If you are using another
accessory ensure that whatever product is used is
free of any metal and that it positions the mobile
phone at least 10 mm away from the body.
FCC ID: RAD511
IP5020_BP61_QG_Eng_USA_03_140709.indd 18IP5020_BP61_QG_Eng_USA_03_140709.indd 182014-7-9 17:36:132014-7-9 17:36:13
19
• LICENCES
The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by TCT Mobile Limited
and its affiliates is under license. Other
trademarks and trade names are those of
their respective owners.
ALCATEL ONETOUCH
SIDEKICK2 Bluetooth
Declaration ID D022118
IP5020_BP61_QG_Eng_USA_03_140709.indd 19IP5020_BP61_QG_Eng_USA_03_140709.indd 192014-7-9 17:36:132014-7-9 17:36:13
20
General
information .........
• Website: www.alcatelonetouch.com
• Facebook: http://www.facebook.com/
alcatelonetouchusa
• Twitter: http://www.twitter.com/
alcatel1touch
• Hot Line Number: In the United States, call
877-702-3444 for technical support.
On our Internet site, you will find our FAQ
(Frequently Asked Questions) section. You can
also contact us by e-mail to ask any questions
you may have.
An electronic version of this user guide is available
in English and other languages according to
availability on our server: www.alcatelonetouch.com
Protection against theft (1)
Your mobile phone is identified by an IMEI
(mobile phone serial number) shown on the
packaging label and in the product’s memory.
We recommend that you note the number the
first time you use your mobile phone by entering
*#06# and keep it in a safe place. It may be
requested by the police or your operator if your
mobile phone is stolen.
Disclaimer
There may be certain differences between the
user manual description and the mobile phone’s
operation, depending on the software release of
your mobile phone or specific operator services.
TCT Mobile shall not be held legally responsible
for such differences, if any, nor for their potential
consequences, which responsibility shall be borne
by the operator exclusively.
(1) Contact your network operator to check service
availability.
IP5020_BP61_QG_Eng_USA_03_140709.indd 20IP5020_BP61_QG_Eng_USA_03_140709.indd 202014-7-9 17:36:132014-7-9 17:36:13
21
TCT Mobile (US),
Inc. Warranty .......
TCT Mobile (US), Inc. warrants to the original
retail purchaser of this wireless device that
should this product or part thereof during normal
consumer usage and condition be proven to be
defective in material or workmanship that results
in product failure within the first twelve (12)
months from the date of purchase as shown on
your original sales receipt from an authorized sales
agent. Such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the company’s
option without charge for parts or labor directly
related to the defect(s).
Batteries, power adapters, and other accessories
sold as in box items are also warranted against
defects and workmanship that results in product
failure within the first six (6) months period from
the date of purchase as shown on your original
sales receipt. Such defect(s) will be repaired
or replaced (with new or rebuilt parts) at the
company’s option without charge for parts or
labor directly related to the defect(s).
The limited warranty for your wireless device will
be voided if any of the following conditions occur:
• Non-compliance with the instructions for use or
installation, or with technical and safety standards
applicable in the geographical area where your
phone is used;
• Connection to any equipment not supplied or
not recommended by TCT Mobile (US), Inc.;
• Modification or repair performed by individuals
not authorized by TCT Mobile (US), Inc. or
its affiliates;
• Changes to the device operating system by the
user or third party applications;
• Acts of god such as inclement weather, lightning,
power surges, fire, humidity, infiltration of
liquids or foods, chemical products, download
of files, crash, high voltage, corrosion, oxidation;
IP5020_BP61_QG_Eng_USA_03_140709.indd 21IP5020_BP61_QG_Eng_USA_03_140709.indd 212014-7-9 17:36:132014-7-9 17:36:13
22
• Removal or altering of the wireless device’s event
labels or serial numbers (IMEI);
• Damage from exposure to water or other
liquids, moisture, humidity, excessive
temperatures or extreme environmental
conditions, sand, excess dust and any condition
outside the operating guidelines;
• Defects in appearance, cosmetic, decorative
or structural items such as framing and non-
operative parts;
• Damage as result of physical abuse regardless
of cause.
There are no express warranties, whether written,
oral or implied, other than this printed limited
warranty or the mandatory warranty provided
by your jurisdiction. In no event shall TCT
Mobile (US), Inc. or any of its affiliates be liable
for incidental or consequential damages of any
nature whatsoever, including but not limited to
commercial loss, to the full extent those damages
can be disclaimed by law. Some states do not
allow the exclusion or limitation of incidental
or consequential damages, or limitation of the
duration of implied warranties, so the preceding
limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer
care center by calling (877-702-3444) or going to
(http://www.alcatelonetouch.com/usa/). We have
placed many self-help tools that may help you to
isolate the problem and eliminate the need to send
your wireless device in for service. In the case that
your wireless device is no longer covered by this
limited warranty due to time or condition, you may
utilize our out of warranty repair options.
How to obtain Hardware Service within the terms
of this warranty: Create a user profile (alcatel.
finetw.com) and then create an RMA for the
defective device. Ship the device with a copy of
the original proof of purchase (e.g. original copy
of the dated bill of sale, invoice) with the owner’s
return address (No PO Boxes accepted), wireless
carrier’s name, alternate daytime phone number,
IP5020_BP61_QG_Eng_USA_03_140709.indd 22IP5020_BP61_QG_Eng_USA_03_140709.indd 222014-7-9 17:36:132014-7-9 17:36:13
23
and email address with a complete problem
description. Only ship the device. Do not ship the
SIM card, memory cards, or any other accessories
such as the power adapter. You must properly
package and ship the wireless device to the
repair center. TCT Mobile (US), Inc. is not
responsible for devices that do not arrive at the
service center or are damaged in transit. Insurance
is recommended with proof of delivery. Upon
receipt, the service center will verify the warranty
conditions, repair, and return your device to the
address provided in the RMA. Check the warranty
repair status by going online with the RMA number
on web portal.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/ TV
technician for help.
Caution: Changes or modifications not expressly
approved by the manufacturer could void the
user’s authority to operate the equipment.
IP5020_BP61_QG_Eng_USA_03_140709.indd 23IP5020_BP61_QG_Eng_USA_03_140709.indd 232014-7-9 17:36:132014-7-9 17:36:13
24
ALCATEL is a trademark of Alcatel-
Lucent
and is used under license by
TCT Mobile Limited.
© Copyright 2014 TCT Mobile
Limited
All rights reserved
TCT Mobile Limited reserves
the right to alter material
or technical specification
without prior notice.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
IP5020_BP61_QG_Eng_USA_03_140709.indd 24IP5020_BP61_QG_Eng_USA_03_140709.indd 242014-7-9 17:36:132014-7-9 17:36:13
