TCT Mobile 558 HSUPA/HSDPA/UMTS tribands / GSM quadbands/LTE 6-band mobile phone User Manual Go Play NA 7048W UM V1

TCT Mobile Limited HSUPA/HSDPA/UMTS tribands / GSM quadbands/LTE 6-band mobile phone Go Play NA 7048W UM V1

Go Play NA_7048W UM_V1

English - CJB64HCALAAA
Quick Start Guide
Important:
Your phone is a unibody device, so the back cover and battery are
not removable. Unauthorized personnel are strictly prohibited from
disassembling the phone.
For more information about how to use your cellphone, please visit
www.alcatelonetouch.us to download the complete user manual and
for answers to frequently asked questions.
Thank you for purchasing the ALCATEL ONETOUCH GO PLAYTM.
We hope you will enjoy your high-quality mobile communication
experience.
7048W
TM
BC
1
1 Your mobile ������������������
1�1 Keys and connectors
Micro-USB Connector
Front camera
Headset connector
LED indicator
Home key
Touch screen
Back key
Recents key
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when holding
your device near your ear while the loudspeaker is in use.
www.sar-tick.com
This product meets applicable national SAR
limits of 1.6 W/kg. The specific maximum SAR
values can be found on page 27 of this user
guide.
When carrying the product or using it while
worn on your body, either use an approved
accessory such as a holster or otherwise
maintain a distance of 1.0 cm from the body
to ensure compliance with RF exposure
requirements. Note that the product may
be transmitting even if you are not making a
phone call.
Table of contents
1 Your mobile ��������������������������������������������������������������������� 1
2 Text input ���������������������������������������������������������������������� 11
3 Phone call ���������������������������������������������������������������������� 12
4 Contacts ������������������������������������������������������������������������ 14
5 Messaging����������������������������������������������������������������������� 15
6 Email ������������������������������������������������������������������������������ 16
7 Getting connected �������������������������������������������������������� 17
8 Find my location using GPS satellites ������������������������ 19
9 Data backup ������������������������������������������������������������������ 20
10 Factory data reset �������������������������������������������������������� 20
11 Applications & Internal storage ���������������������������������� 21
12 Making the most of your phone ���������������������������������� 21
Safety and use ������������������������������������������������������������������������� 23
General information �������������������������������������������������������������� 31
12 MONTH LIMITED WARRANTY ������������������������������������ 32
Troubleshooting���������������������������������������������������������������������� 33
2 3
Camera
Camera Flash/Flashlight
SIM card/
SD card
slot
Volume key
Power key
Recents key
• Touch to view recently used applications.
Home key
• From any application or screen, touch to return to the
Home screen.
• Long press to pop up Google search icon. Slide your
finger to the icon to open Google search.
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.
These keys are visible when the phone is unlocked.
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the popup menu to select from
Power off/Restart/Aeroplane mode.
• Press and hold the Power key and Volume up key
to reset.
• Press and hold the Power key and Volume down key
to capture a screenshot.
• Press and hold the Power key for at least 8 seconds to
force reboot or hold it longer to power off.
Volume Keys
• In call mode, adjusts the earpiece or headset volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.
• In camera preview mode, press Volume up or down
key to enter burst shoot.
• When underwater, press the Power key to unlock the
phone and hold the Volume key (up or down) to
enter the underwater camera mode.
• In underwater camera mode, press the Volume key
(up or down) to take pictures.
• In underwater camera mode, long press the Volume
down to enter burst mode.
• In underwater camera mode, long press the Volume
up to record videos. Long press the Volume up again
to stop recording.
• In underwater camera mode, press the Volume down
to take a picture while recording.
1�2 Getting started
1�2�1 Set up
Inserting or removing the SIM card/SD card
You must insert your SIM card to make phone calls. You do not need
to power off your phone before inserting or removing the SIM card
as this phone can support hot swap.
4 5
Before you install or remove the SIM card or microSD card, use a
pin to press the small cavity until the SIM/microSD cassette pops out.
Your phone only supports nano-SIM cards. Do not attempt
to insert other SIM types like mini and micro cards;
otherwise this may cause damage to your phone.
To avoid data loss and SD card damage, before removing
the SD card, ensure that the SD card is unmounted
(Settings\Storage\Unmount SD card).
Charging the battery
Connect the battery charger to your phone and power source
respectively, the LED indicator will light while charging.
To reduce power consumption and energy waste, when the
battery is fully charged, disconnect your charger; switch off
Wi-Fi, GPS, Bluetooth or background-running applications
when not in use; reduce the backlight time, etc.
1�2�2 Power on your phone
Hold down the Power key until the phone powers on. It will take a
few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: Language, Google account, etc.
Even if no SIM card is installed, your phone will still power on and you
will be able to connect to a Wi-Fi network, sign in to your Google
account and use some of the phone's features.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
1�3 Home screen
You can move all of the items (applications, shortcuts, folders and
widgets) you use most frequently to your Home screen for quick
access. Touch the Home key to switch to the Home screen.
Touch to enter application list.
Status bar
• Status/Notification indicators
• Touch and drag down to open
the notification panel.
Touch an icon to open an application,
folder, etc.
Favourite tray applications
• Touch to enter the application.
• Touch and hold to move or
change applications.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts etc. Slide the Home screen
horizontally left and right to get a complete view.
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Long press
Long press the item to enter the available options.
6 7
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen up and down to scroll through the applications,
images, web pages, etc.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can view both phone status (to the right
side) and notification information (to the left side).
Status icons
GPRS connected No signal
GPRS in use Alarm is set
EDGE connected Bluetooth is on
EDGE in use Headset connected
3G connected Speakerphone is on
3G in use Phone microphone
muted
HSPA (3G+) connected Roaming
HSPA (3G+) in use No SIM card installed
HSPA+ connected Vibrate mode
HSPA+ in use Battery is very low
4G LTE connected Battery is low
4G LTE in use Battery is partially
drained
Signal strength Battery is full
Wi-Fi is on Battery is charging
Connected to a Wi-Fi
network GPS is on
Aeroplane mode
8 9
Notification icons
New Gmail message Missed call
New Email message Call forwarding is on
New text or multimedia
message Song is playing
Problem with SMS or
MMS delivery Connected to VPN
New Google Hangouts
message Radio is on
New voicemail Uploading data
Upcoming event Download finished
Screenshot captured Select input method
Both USB tethering and
portable hotspot are on
An open Wi-Fi network
is available
USB tethering is on Phone is connected via
USB cable
Portable Wi-Fi hotspot
is on System update available
Operator data use
threshold approaching or
exceeded
More notifications are
hidden
Touch and drag down the Status bar to open the Quick settings panel
or Notification panel. Touch and drag up to close it. When there are
notifications, you can touch them to access notifications directly.
Notification panel
When there are notifications, touch and drag down the Status bar
to open the Notification panel to read more detailed information.
Touch to clear all event–based notifications
(other ongoing notifications will remain).
Touch to switch to the Quick settings
panel.
Quick settings panel
Touch Notification panel to open the Quick settings panel. You can
enable or disable functions or change modes by touching the icons.
Touch to enter user screen.
Touch to access Settings, where you can
set more items.
10 11
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�4 Personalise your Home screen
Add
You can long press a folder, an application, or a widget to activate
the Move mode and drag the item to any Home screen you prefer.
Reposition
Long press the item to be repositioned to activate the Move mode,
drag the item to the desired position and then release. You can
move items both on the Home screen and the Favourite tray. Hold
the icon on the left or right edge of the screen to drag the item to
another Home screen.
Remove
Long press the item to be removed to activate the Move mode,
drag the item up to the top of the icon, and release after the
item turns red.
Create folders
To improve the organisation of items (shortcuts or applications) on
the Home screen, you can add them to a folder by stacking one item
on top of another. To rename a folder, open it and touch the folder’s
title bar to input the new name.
Wallpaper customisation
Long press the empty space in the Home screen and choose
WALLPAPERS to customise wallpaper or you could access this
function by Settings\Display\Wallpaper to customise wallpaper.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching
Settings\Sound & notification\Media volume to set the volume.
2 Text input ����������������������
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch Settings\Language & input, touch the keyboard you want to
set up and a series of settings will become available for your selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can adjust it by changing the settings (Touch
Settings\Display\When device is rotated\Rotate screen
contents).
2�1�1 Keyboard
Touch to switch
between symbol and
numeric keyboard.
Long press to
select symbols.
Touch to enter
text or numbers.
Touch to input comma.
Long press to show input options.
Touch to switch "abc/
Abc" mode; Touch &
hold to switch "abc/
ABC" mode.
2�2 Text editing
You can edit the text you have entered.
• Long press or double touch within the text you would like to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: Select all , Cut , Copy
and Paste .
• Touch the icon to go back without any action.
12 13
3 Phone call �����������������
3�1 Placing a call
You can easily place a call using Call. Touch the Application tab from
the Home screen and select Call.
Touch to send
message to the
previewed number.
Touch to call
the previewed
number. Slide to access the
RECENTS and
CONTACTS.
Touch to hide/
display keyboard.
Display the
suggested
number(s).
Long press to
access voicemail.
Enter the desired number from the keyboard directly and touch
to place the call, or select a contact from CONTACTS or
RECENTS by sliding or touching tabs to make the call.
The number you entered can be saved to Contacts by touching
and then touching Create new contact.
If you make a mistake, you can delete the incorrect digits by
touching .
To hang up a call, touch .
3�2 Answering or rejecting a call
When you receive a call:
• Slide the icon to the right to answer;
• Slide the icon to the left to reject;
• Slide the icon upwards to reject the call by sending a preset
message.
To mute the ringtone volume of an incoming call, press the Volume
up/down key or turn the phone over (when the Settings\
Gestures\Turn over to mute option is activated).
3�3 Consulting your call memory
You can access your call memory by touching RECENTS tab
from the Phone screen to view Missed calls, Outgoing calls and
Incoming calls.
14 15
4 Contacts �������������������
You can view and create contacts on your phone and synchronise
these with your Gmail contacts or other applications on the web
or on your phone.
4�1 Adding a contact
Touch the Application tab from the Home screen, select Contacts,
then touch the icon in the contacts list to create a new contact.
4�2 Importing, exporting and sharing
contacts
From the Contacts screen, touch the icon to open the options
menu, touch Import/Export, then select Import from SIM
card, Export to SIM card, Import from SD storage/phone
storage, Export to SD storage/phone storage or Share
visible contacts.
To import/export a single contact from/to your SIM card, select
the contact you want to import/export, and touch the /
icon to confirm.
To import/export all contacts from/to your SIM card, touch the
icon and then the / icon to confirm.
You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.
Touch a contact you want to share, touch the icon and Share
from the contact details screen, and then select the application to
perform this action.
4�3 Synchronising contacts in multiple
accounts
Contacts, data or other information can be synchronised from multiple
accounts, depending on the applications installed on your phone.
5 Messaging �����������������
You can create, edit and receive SMS and MMS with this phone.
To access this feature, touch the Application tab from the Home
screen, then select Messaging.
To check messages stored in your SIM card, touch the
icon from the Messaging screen, then touch Settings\
Manage SIM messages.
5�1 Write message
On the message list screen, touch the new message icon to write
text/multimedia messages.
Touch to create a new message.
• Touch to view the whole message thread.
• Long press to activate delete mode.
Sending a text message
Enter the mobile phone number of the recipient in the To bar or
touch to add recipients and touch the Send message bar to
enter the text of the message. Touch the icon to insert emotions
or icons. When finished, touch to send the text message.
An SMS of more than 160 characters will be charged as
several SMS. Specific letters (accent) will also increase the
size of the SMS. This may cause multiple SMS to be sent to
your recipient.
16 17
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations,
slides, and sounds to other compatible phones and email addresses.
An SMS will be converted to MMS automatically when media files
(image, video, audio, slides, etc.) are attached or Subject or email
addresses added.
6 Email �������������������������
Besides your Gmail account, you can also set up external POP3 or
IMAP email accounts in your phone.
To access this feature, touch the Application tab from the Home
screen, then select Email.
An email setup wizard will guide you through the steps to set up
an email account.
• Enter the email address and password of the account you want
to set up.
• Touch Next. If the account you entered is not provided by your
service provider in the phone, you will be prompted to go to
the email account settings screen to enter settings manually.
Alternatively, you can touch MANUAL SETUP to directly enter
the incoming and outgoing settings for the email account you are
setting up.
• Enter the account name and display name in outgoing emails.
• To add another email account, you can touch the icon and
Settings. Touch Add account to create.
To create and send emails
• Touch the icon from the Inbox screen.
• Enter recipient(s) email address (es) in the To field.
• If necessary, touch the icon beside To field to add Cc/Bcc to
add a copy or a blind carbon copy to the message.
• Enter the subject and the content of the message.
• Touch to add an attachment.
• Finally, touch to send�
• If you do not want to send the mail right away, you can touch the
icon and Save draft keys or touch the Back key to save a copy.
7 Getting connected �������
To connect to the Internet with this phone, you can use GPRS/
EDGE/3G/4G networks or Wi-Fi, whichever is most convenient.
7�1 Connecting to the Internet
7�1�1 GPRS/EDGE/3G/4G
The first time you turn on your phone with your SIM card inserted,
it will automatically configure your network service: GPRS, EDGE,
3G or 4G.
To check the network connection you are using, touch Settings\
More���\Mobile networks, and touch Access Point Names or
Network operators.
7�1�2 Wi-Fi
Using Wi-Fi, you can connect to the Internet when your phone is
within range of a wireless network. Wi-Fi can be used on your phone
even without a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
• Touch Settings\Wi-Fi.
• Touch the switch to turn on/off Wi-Fi.
• The detailed information of detected Wi-Fi networks is displayed in
the Wi-Fi networks section.
• Touch a Wi-Fi network to connect. If the network you selected is
secured, you are required to enter a password or other credentials
(you can contact the network operator for details). When finished,
touch CONNECT.
18 19
7�2 Chrome ��������������������������������������
Using the Chrome, you can enjoy surfing the Web.
To access this feature, touch the Application tab from the Home
screen, then select Chrome.
To go to a web page
On the Browser screen, touch the URL box at the top, enter the
address of the web page, and then confirm.
7�3 Connecting to a computer(1)
With the USB cable, you can transfer media files and other files
between your microSD card/internal storage and the computer.
To connect your phone to the computer:
• Use the USB cable that came with your phone to connect
the phone to a USB port on your computer. You will receive a
notification that the USB is connected.
• If you use MTP or PTP, your phone will be automatically connected.
Before using MTP, make sure that the driver (Windows
Media Player 11 or higher version) has been installed.
To locate data you have transferred or downloaded in your
microSD card/internal storage:
• Touch to open the applications list.
• Touch File Manager.
All data you have downloaded is stored in the File Manager. Here
you can view media files (videos, photos, music and others), rename
files, install applications into your phone, etc.
7�4 Sharing your phone's mobile data
connection
You can share your phone's mobile data connection with a single
computer via USB cable (USB tethering) or with up to eight devices
at once by turning your phone into a portable Wi-Fi hotspot.
(1) You can change your default connection mode via Settings\Storage\
touch the icon\USB computer connection.
To turn on USB tethering or Portable Wi-Fi hotspot
• Touch Settings\More���\Tethering & portable hotspot.
• Touch the switch of USB tethering or Portable Wi-Fi
hotspot to activate this function.
These functions may incur additional network charges from
your network operator. Extra fees may also be charged in
roaming areas.
8 Find my location using
GPS satellites ����������������
To activate your phone’s global positioning system (GPS) satellite
receiver:
• Touch Settings\Location.
• Touch the switch to turn on Google's location service.
You can then open Maps to find your location:
Use your phone’s GPS satellite receiver to pinpoint your location
within an accuracy as close as several meters (“street level”). The
process of accessing the GPS satellite and setting your phone's
precise location for the first time will require up to 5 minutes. You
will need to stand in a place with a clear view of the sky and avoid
moving. After this, GPS will only need 20-40 seconds to identify your
precise location.
20 21
9 Data backup ������������������
This phone enables you to back up your phone’s settings and other
application data to Google servers, with your Google account.
If you replace your phone, the settings and data you’ve backed up
are restored onto the new phone the first time you sign in with
your Google account.
To activate this function:
• Touch Settings\Backup and reset.
• Touch the switch of Back up my data.
When this function is activated, a wide variety of settings and data
is backed up, including your Wi-Fi passwords, bookmarks, a list of
the applications you’ve installed, the words you’ve added to the
dictionary used by the onscreen keyboard, and most of the settings
that you configure with the Settings application. If you deactivate this
option, you stop backing up your settings, and any existing backups
are deleted from Google servers.
10 Factory data reset��
To activate factory data reset:
• Touch Settings\Backup and reset\Factory data reset.
• Touch the RESET PHONE.
Resetting the phone will erase all of your personal data from internal
phone storage, including information about your Google account,
any other accounts, your system and application settings, and any
downloaded applications. If you reset the phone in this way, you’re
prompted to re-enter the same kind of information as when you
first started Android.
When you are unable to power on your cellphone, you can perform
a factory data reset by pressing the Power key and the Volume up
key at the same time until the screen lights up.
11 Applications &
Internal storage ������
11�1 Applications
With this phone, some built-in Google applications and other third
party applications are available for your convenience.
With the built-in applications, you can
• Communicate with friends.
• Exchange messages or emails with friends.
• Track your location, view traffic situations, search for locations and
get navigation information to your destination.
• Download more applications from the Google Play Store and
more.
For more information about these applications, check the online user
manual at: www.alcatelonetouch.us.
11�2 Internal storage
Touch Settings\Storage to display the amount of internal phone
storage used by the operating system, its components, applications
(including those you downloaded), permanent and temporary data.
If a warning message comes up saying that phone memory
is limited, you are required to free up space by deleting
some unwanted applications, downloaded files, etc.
12 Making the most of
your phone ��������������
You can download software upgrades for free from the website
(www.alcatelonetouch.us).
22 23
12�1 Smart Suite
Smart Suite includes:
• Contacts
Allows you to back up contact entries so that you don't have
to worry about losing, breaking, switching phones or changing
service providers.
• Messages
Frees you from painstakingly inputting text on the keypads. All of
your messages are easily accessible and well-organised.
• Calendar
Allows you to sync events freely between your phone and Outlook
and create and edit new events from a PC.
• Photos
Allows you to easily import photos from your PC or the handset
and organise them in different albums for better management.
• Videos
Allows you to insert video files from your PC for playback and then
upload them to a handset folder.
• Music
Quickly search for your favourite songs on your PC, manage the
ultimate Library, and enjoy the easiest digital jukebox in your
own way.
• Application
Allows you to import downloaded mobile applications and have
them installed into your handset upon synchronisation.
• Backup
Allows you to back up your contacts, messages, calendar, photos
and applications, then import the backup files to your phone.
Supported Operating Systems
Windows XP/Vista/Windows 7/Windows 8.
12�2 Upgrade
12�2�1 FOTA Upgrade
Using the FOTA Upgrade tool you can update your phone's software.
To access System updates, touch icon to open the applications
list, then touch Settings\About phone\System updates. When
there is a new version can be updated, one indicator will be shown
on System updates menu. If you want to update the system, touch
System updates and then the button Download, after it is done
touch Install to complete the upgrade. Now your phone's software
will be the latest version.
You should turn on data connection before searching for updates.
Settings for auto-check intervals is also available once you restart
the phone.
If you have chosen auto-check, when the system discovers the
new version, dialog will pop up to choose download or ignore, the
notification also will show in status bar.
Safety and use ����������������������
We recommend that you read this chapter carefully before using
your phone. The manufacturer disclaims any liability for damage, which
may result as a consequence of improper use or use contrary to the
instructions contained herein.
Your device has been tested in a controlled environment and certified to
be water and dust-resistant in specific situations (meets requirements of
classification IP67 as described by the international standard IEC 60529 -
Degrees of Protection provided by Enclosures [IP Code]; test conditions:
15 - 35 °C, 86 - 106 kPa, 1 meter, 30 minutes). Despite this classification,
your device is not impervious to water damage in any situation.
Make sure SIM/SD cover is tightly closed for IP67 features. Otherwise,
they may not provide protection from water and dust.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit,
headset...), drivers are requested to refrain from using their mobile when
the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music
or the radio. Using a headphone can be dangerous and forbidden in
some areas.
When switched on, your phone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock
brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag
deployment area,
24 25
- check with your car dealer or the car manufacturer to make sure that
the dashboard is adequately shielded from mobile phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the telephone from time to time to
optimise its performance.
Switch the phone off before boarding an aircraft.
Switch the phone off when you are in health care facilities, except in
designated areas. As with many other types of equipment now in regular
use, mobile telephones can interfere with other electrical or electronic
devices, or equipment using radio frequency.
Switch the phone off when you are near gas or flammable liquids. Strictly
obey all signs and instructions posted in a fuel depot, petrol station, or
chemical plant, or in any potentially explosive atmosphere.
When the phone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump, etc. In
particular when using the phone, you should hold it against the ear on
the opposite side to the device, if any.
To avoid hearing impairment, pick up the call before holding your phone
to your ear. Also move the handset away from your ear while using the
“hands-free” mode because the amplified volume might cause hearing
damage.
Do not let children use the phone and/or play with the telephone and
accessories without supervision.
Note that your phone is a unibody device, the back cover and battery
are not removable. Do not attempt to disassemble your phone. If you
disassemble your phone the warranty will not apply. Also disassembling
the phone may damage the battery, and may cause leakage of substances
that could create an allergic reaction.
Always handle your phone with care and keep it in a clean and dust-
free place.
Do not allow your phone to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of
liquids, dust, sea air, etc.). The manufacturer’s recommended operating
temperature range is -10°C to +45°C.
At over 45°C the legibility of the phone’s display may be impaired, though
this is temporary and not serious.
Emergency call numbers may not be reachable on all cellular networks.
You should never rely only on your phone for emergency calls.
Do not open, dismantle or attempt to repair your mobile phone yourself.
Do not drop, throw or bend your mobile phone.
Do not use the phone if the glass made screen, is damaged, cracked or
broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are
recommended by TCT Mobile Limited and its affiliates and are compatible
with your phone model. TCT Mobile Limited and its affiliates disclaim any
liability for damage caused by the use of other chargers or batteries.
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
Some people may suffer epileptic seizures or blackouts when exposed to
flashing lights, or when playing video games. These seizures or blackouts
may occur even if a person never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, consult your doctor before playing video
games on your phone or enabling a flashing-lights feature on your phone.
Parents should monitor their children’s use of video games or other
features that incorporate flashing lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms,
take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop
and rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after
playing, stop the game and see a doctor.
When you play games on your phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your
body. Follow the instructions to avoid problems such as tendinitis, carpal
tunnel syndrome, or other musculoskeletal disorders.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
26 27
• PRIVACY:
Note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your mobile
phone regarding taking photographs and recording sounds with your
mobile telephone. Pursuant to such laws and regulations, it may be strictly
forbidden to take photographs and/or to record the voices of other
people or any of their personal attributes, and duplicate or distribute
them, as this may be considered to be an invasion of privacy. It is the
user's sole responsibility to ensure that prior authorisation be obtained,
if necessary, in order to record private or confidential conversations
or take a photograph of another person; the manufacturer, the seller
or vendor of your mobile phone (including the operator) disclaim any
liability which may result from the improper use of the mobile phone.
• BATTERY:
Note your phone is a unibody device, the back cover and battery are not
removable. Observe the following precautions:
- Do not attempt to open the back cover,
- Do not attempt to eject, replace and open battery,
- Do not punctuate the back cover of your phone,
- Do not burn or dispose of your phone in household rubbish or store
it at temperature above 60°C.
Phone and battery as a unibody device must be disposed of in accordance
with locally applicable environmental regulations.
This symbol on your telephone, the battery and the
accessories means that these products must be taken to
collection points at the end of their life:
- Municipal waste disposal centres with specific bins for
these types of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.
In non-European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary
bins if your jurisdiction or your region has suitable recycling and
collection facilities; instead they are to be taken to collection points for
them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
• CHARGERS
Home A.C./ Travel chargers will operate within the temperature range of:
0°C (32°F) to 40°C (104°F).
The chargers designed for your mobile phone meet with the standard
for safety of information technology equipment and office equipment
use. Due to different applicable electrical specifications, a charger you
purchased in one jurisdiction may not work in another jurisdiction. They
should be used for this purpose only.
Characteristics of power supply (depending on the country):
Travel charger: Input: 100-240 V, 50/60 Hz, 0.2 A
Output: 5 V, 1A
Battery: Lithium 2500 mAh
• RADIO WAVES:
THIS MOBILE PHONE MEETS THE GOVERNMENT’S REQUIREMENTS
FOR EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radio-frequency (RF) energy. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed
by independent scientific organizations through periodic and thorough
evaluation of scientific studies. These guidelines include a substantial
safety margin designed to ensure the safety of all persons, regardless
of age and health.
The exposure standard for mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by
public authorities such as the Federal Communications Commission of
the US Government (FCC), or by Industry Canada, is 1.6 W/kg averaged
over 1 gram of body tissue. Tests for SAR are conducted using standard
operating positions with the mobile phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the
actual SAR level of the mobile phone while operating can be well below
the maximum value. This is because the mobile phone is designed to
operate at multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the mobile phone. Before
a mobile phone model is available for sale to the public, compliance with
national regulations and standards must be shown.
The highest SAR value for this model mobile phone when tested is
1.01 W/kg for use at the ear and 1.01 W/kg for use close to the body.
28 29
While there may be differences between the SAR levels of various
mobile phones and at various positions, they all meet the government
requirement for RF exposure. For body-worn operation, the mobile
phone meets FCC RF exposure guidelines provided that it is used with
a non-metallic accessory with the handset at least 10 mm from the
body. Use of other accessories may not ensure compliance with FCC
RF exposure guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.ctia.org/
The World Health Organization (WHO) considers that present scientific
information does not indicate the need for any special precautions for
use of mobile phones. If individuals are concerned, they might choose
to limit their own or their children’s RF exposure by limiting the length
of calls, or using “hands-free” devices to keep mobile phones away from
the head and body. Additional WHO information about electromagnetic
fields and public health are available on the following Website: http://
www.who.int/peh-emf.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
For the receiver devices associated with the operation of a licensed radio
service (e.g. FM broadcast), they bear the following statement:
This device complies with Part 15 of the FCC Rules and Industry Canada
licence-exempt RSS standard(s). Operation is subject to the condition
that this device does not cause harmful interference.
For other devices, they bear the following statement:
This device complies with Part 15 of the FCC Rules and Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Your mobile phone is equipped with a built-in antenna. For optimal
operation, you should avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions
other than against your ear. In such circumstances the device will be
compliant with the guidelines when used with headset or usb data cable.
If you are using another accessory ensure that whatever product is used
is free of any metal and that it positions the mobile phone at least 10
mm away from the body.
Please note by using the device some of your personal data may be shared
with the main device. It is under your own responsibility to protect your
own personal data, not to share with it with any unauthorized devices
or third party devices connected to yours. For products with Wi-Fi
features, only connect to trusted Wi-Fi networks. Also when using your
product as a hotspot (where available), use network security. These
precautions will help prevent unauthorized access to your device. Your
product can store personal information in various locations including a
SIM card, memory card, and built-in memory. Be sure to remove or clear
all personal information before you recycle, return, or give away your
product. Choose your apps and updates carefully, and install from trusted
sources only. Some apps can impact your product’s performance and/or
have access to private information including account details, call data,
location details and network resources.
Note that any data shared with TCT Mobile Limited is stored in
accordance with applicable data protection legislation. For these purposes
TCT Mobile Limited implements and maintains appropriate technical and
organizational measures to protect all personal data, for example against
unauthorized or unlawful processing and accidental loss or destruction
of or damage to such personal data whereby the measures shall provide
a level of security that is appropriate having regard to
(i) the technical possibilities available,
(ii) the costs for implementing the measures,
(iii) the risks involved with the processing of the personal data, and
(iv) the sensitivity of the personal data processed.
You can access, review and edit your personal information at any time by
logging into your user account, visiting your user profile or by contacting
us directly. Should you require us to edit or delete your personal data,
we may ask you to provide us with evidence of your identity before we
can act on your request.
30 31
• LICENCES
microSD Logo is a trademark.
The Bluetooth® word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
TCT Mobile Limited and its affiliates is under license.
Other trademarks and trade names are those of their
respective owners.
ALCATEL ONETOUCH GO PLAY
Bluetooth Declaration ID
D025403
The Wi-Fi Logo is a certification mark of the Wi-Fi
Alliance.
Google, the Google logo, Android, the Android logo,
Google SearchTM, Google MapsTM, GmailTM, YouTube,
Google Play Store, Google LatitudeTM and HangoutsTM
are trademarks of Google Inc.
The Android robot is reproduced or modified from work created
and shared by Google and used according to terms described in the
Creative Commons 3.0 Attribution License (the text will show when
you touch and hold Google legal in Settings\About phone\Legal
information). (1)
You have purchased a product which uses the open source
(http://opensource.org/) programmes mtd, msdosfs, netfilter/iptables and
initrd in object code and other open source programmes licensed under
the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding source
codes upon request within a period of three years from the distribution
of the product by TCT.
You may download the source codes from http://sourceforge.net/
projects/alcatel/files/. The provision of the source code is free of charge
from internet.
Hearing Aid Compatibility
Your mobile phone is rated: «For Hearing Aid», to assist hearing device
users in finding mobile phones that may be compatible with their
hearing devices.
This device is HAC M3 and T3 compatible.
FCC ID: RAD558
(1) May not be available in all countries.
For more information please visit our Website
http://www.alcatelonetouch.us
General information �����������
• Website: www.alcatelonetouch.us
• Facebook: www.facebook.com/alcatelonetouchusa
www.facebook.com/alcatelonetouchcanada
• Twitter: http://m.twitter.com
• Hot Line Number: In the United States, call 855-368-0829
for technical support. In Canada, call 855-844-6058 for technical
support.
On our Website, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you
may have.
An electronic version of this user guide is available in English and other
languages according to availability on our server:
www�alcatelonetouch�us
Your telephone is a transceiver that operates on GSM in quad-band
(850/900/1800/1900MHz), WCDMA in tri-band (B2/4/5) and LTE FDD
(B2/4/5/7/12/17).
Protection against theft(1)
Your telephone is identified by an IMEI (phone serial number) shown
on the packaging label and in the phone’s memory. We recommend that
you note the number the first time you use your telephone by entering
* # 0 6 # and keep it in a safe place. It may be requested by the police
or your operator if your telephone is stolen. This number allows your
mobile telephone to be blocked preventing a third person from using it,
even with a different SIM card.
Disclaimer
There may be certain differences between the user manual description
and the phone’s operation, depending on the software release of your
telephone or specific operator services.
TCT Mobile Limited shall not be held legally responsible for such
differences, if any, nor for their potential consequences, which
responsibility shall be borne by the operator exclusively.
(1) Contact your network operator to check service availability.
32 33
12 MONTH LIMITED
WARRANTY �����������������������
TCT Mobile Limited warrants to the original retail purchaser of this
wireless device that should this product or part thereof during normal
consumer usage and condition be proven to be defective in material
or workmanship that results in product failure within the first twelve
(12) months from the date of purchase as shown on your original sales
receipt from an authorized sales agent. Such defect(s) will be repaired
or replaced (with new or rebuilt parts) at the company’s option without
charge for parts or labor directly related to the defect(s). Batteries,
power adapters, and other accessories sold as in box items are also
warranted against defects and workmanship that results in product
failure within the first twelve (12) month period from the date of
purchase. This warranty extends to products purchased and sold within
the United States.
The limited warranty for your wireless device will be voided if any of the
following conditions occur:
• Non-compliance with the instructions for use or installation, or
with technical and safety standards applicable in the geographical
area where your phone is used;
• Connection to any equipment not supplied or not recommended
by TCT Mobile Inc.;
• Modification or repair performed by individuals not authorized by
TCT Mobile Inc. or its affiliates;
• Changes to the device operating system by the user or third party
applications;
• Acts of god such as inclement weather, lightning, power surges,
fire, humidity, infiltration of liquids or foods, chemical products,
download of files, crash, high voltage, corrosion, oxidation;
• Removal or altering of the wireless device’s event labels or serial
numbers (IMEI);
• Damage from exposure to water or other liquids, moisture,
humidity, excessive temperatures or extreme environmental
conditions, sand, excess dust and any condition outside the
operating guidelines;
• Rooted devices;
• Damage as result of physical abuse regardless of cause.
There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided
by your jurisdiction. In no event shall TCT Mobile Limited or any of its
affiliates be liable for incidental or consequential damages of any nature
whatsoever, including but not limited to commercial loss, to the full
extent those damages can be disclaimed by law. Some states do not
allow the exclusion or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties, so the preceding
limitations or exclusions may not apply to you.
How to obtain Support: Contact the customer care center by calling
(855-368-0829) or going to (http://www.alcatelonetouch. us). We have
placed many self-help tools that may help you to isolate the problem
and eliminate the need to send your wireless device in for service. In
the case that your wireless device is no longer covered by this limited
warranty due to time or condition, you may utilize our out of warranty
repair options.
How to obtain Hardware Service within the terms of this warranty:
Create a user profile (alcatel.finetw.com) and then create an RMA for
the defective device. Ship the device with a copy of the original proof
of purchase (e.g. original copy of the dated bill of sale, invoice) with the
owner's return address (No PO Boxes accepted), wireless carrier’s name,
alternate daytime phone number, and email address with a complete
problem description. Only ship the device. Do not ship the SIM card,
memory cards, or any other accessories such as the power adapter. You
must properly package and ship the wireless device to the repair center.
TCT Mobile Limited is not responsible for devices that do not arrive at
the service center or are damaged in transit. Insurance is recommended
with proof of delivery. Upon receipt, the service center will verify the
warranty conditions, repair, and return your device to the address
provided in the RMA.
Troubleshooting�������������������
Before contacting the service centre, you are advised to follow the
instructions below:
• You are advised to fully charge ( ) the battery for optimal
operation.
• Avoid storing large amounts of data in your phone as this may
affect its performance.
34 35
• Use Factory data reset and the upgrade tool to perform phone
formatting or software upgrading (to reset factory data, hold down
the Power key and the Volume up key at the same time). ALL
User phone data: contacts, photos, messages, files, and downloaded
applications will be permanently lost. It is strongly advised to fully
back up the phone data and profile before doing formatting or
upgrading.
and carry out the following checks:
My phone can't be switched on or is frozen
• When the phone can't be switched on, charge for at least 20
minutes to ensure the minimum battery power needed, and then
try to switch on again.
• When the phone falls into a loop during power on-off animation
and the user interface can't be accessed, press and hold the Volume
down key to enter Safe Mode. This eliminates any abnormal OS
booting issues caused by 3rd party APKs.
• If neither method is effective, reset the phone using the Power key
and the Volume up key, (holding both together).
My phone has not responded for several minutes
• Restart your phone by pressing and holding the Power key for
more than 8s.
My phone turns off by itself
• Check that your screen is locked when you are not using your
phone, and make sure the Power key is not mis-contacted due
to unlocked screen.
• Check the battery charge level.
My phone can't charge properly
• Make sure you are using the ALCATEL ONETOUCH charger
included in the box.
• Make sure that your battery is not completely discharged; if the
battery power is empty for a long time, it may take around 20
minutes to display the battery charger indicator on the screen.
• Make sure charging is carried out under normal conditions (0°C
to +40°C).
• When abroad, check that the voltage input is compatible.
My phone can't connect to a network or “No service” is
displayed
• Try connecting in another location.
• Verify the network coverage with your operator.
• Check with your operator that your SIM card is valid.
• Try selecting the available network(s) manually.
• Try connecting at a later time if the network is overloaded.
My phone can't connect to the Internet
• Check that the IMEI number (press *#06#) is the same as the one
printed on your warranty card or box.
• Make sure that the internet access service of your SIM card is
available.
• Check your phone's Internet connecting settings.
• Make sure you are in a place with network coverage.
• Try connecting at a later time or another location.
Invalid SIM card
• Make sure the SIM card has been correctly inserted (see
"Inserting or removing the SIM card").
• Make sure the chip on your SIM card is not damaged or scratched.
• Make sure the service of your SIM card is available.
Unable to make outgoing calls
• Make sure you have dialled a valid number and have touched .
• For international calls, check the country and area codes.
• Make sure your phone is connected to a network, and the network
is not overloaded or unavailable.
• Check your subscription status with your operator (credit, SIM
card valid, etc.).
• Make sure you have not barred outgoing calls.
• Make sure that your phone is not in flight mode.
Unable to receive incoming calls
• Make sure your phone is switched on and connected to a network
(check for overloaded or unavailable network).
• Check your subscription status with your operator (credit, SIM
card valid, etc.).
• Make sure you have not forwarded incoming calls.
• Make sure that you have not barred certain calls.
• Make sure that your phone is not in flight mode.
The caller’s name/number does not appear when a call is
received
• Check that you have subscribed to this service with your operator.
• Your caller has concealed his/her name or number.
I can't find my contacts
• Make sure your SIM card is not broken.
• Make sure your SIM card is inserted properly.
• Import all contacts stored in SIM card to phone.
36 37
The sound quality of the calls is poor
• You can adjust the volume during a call by pressing the Volume
Up/Down key.
• Check the network strength .
• Make sure that the receiver, connector or speaker on your phone
is clean.
• Make sure that the microphone, receiver or speaker is clean and
dry, if the device has been immersed in water.
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription
includes this service.
• Make sure this feature does not require an ALCATEL ONETOUCH
accessory.
When I select a number from my contacts, the number
can't be dialled
• Make sure that you have correctly recorded the number in your
file.
• Make sure that you have selected the country prefix when calling
a foreign country.
I am unable to add a contact in my contacts
• Make sure that your SIM card contacts are not full; delete some
files or save the files in the phone contacts (i.e. your professional
or personal directories).
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability.
I can't access my voicemail
• Make sure your operator’s voicemail number is correctly entered
in "Voicemail number".
• Try later if the network is busy.
I am unable to send and receive MMS
• Check your phone memory availability as it might be full.
• Contact your network operator to check service availability and
check MMS parameters.
• Verify the server centre number or your MMS profile with your
operator.
• The server centre may be busy, try again later.
SIM card PIN locked
• Contact your network operator to obtain the PUK code (Personal
Unblocking Key).
I am unable to connect my phone to my computer
• Install Smart Suite.
• Check that your USB driver is installed properly.
• Open the Notification panel to check if the Smart Suite Agent
has activated.
• Check that your computer meets the requirements for Smart
Suite Installation.
• Make sure that you’re using the cable included in the box.
I am unable to download new files
• Make sure there is sufficient phone memory for your download.
• Select the microSD card as the location to store downloaded files.
• Check your subscription status with your operator.
The phone can't be detected by others via Bluetooth
• Make sure that Bluetooth is turned on and your phone is visible
to other users .
• Make sure that the two phones are within Bluetooth’s detection
range.
How to make your battery last longer
• Make sure you follow the complete charge time (minimum 3
hours).
• After a partial charge, the battery level indicator may not be exact.
Wait for at least 20 minutes after removing the charger to obtain
an exact indication.
• Adjust the brightness of screen as appropriate.
• Extend the email auto-check interval for as long as possible.
• Update news and weather information on manual demand, or
increase their auto-check interval.
• Exit background-running applications if they are not being used
for a long time.
• Deactivate Bluetooth, Wi-Fi, or GPS when not in use.
The phone will become warm following prolonged calls,
game playing, internet surfing or running other complex
applications�
• This heating is a normal consequence of the CPU handling
excessive data. Ending above actions will make your phone return
to normal temperatures.
How to properly care for my phone for water resistance
The device may be damaged if water or dust enters the device.
Follow these tips carefully to prevent damage to the device:
• Make sure SIM/SD cover and other covers are tightly closed.
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited
© Copyright 2015 TCT Mobile Limited
All rights reserved
TCT Mobile Limited reserves
the right to alter material
or technical specification
without prior notice.
All "Signature" ringtones embedded in this phone have been
composed, arranged and mixed by NU TROPIC (Amar Kabouche).
• Do not immerse the device in water deeper than 1 meter and keep
it submerged for more than 30 minutes.
• Do not immerse the device to water moving with force, such as
ocean waves, or waterfalls.
• Do not open the device’s covers when the device is in water or in
very humid places, such as swimming pools or bathrooms.
• The touch screen and other functions may not work properly if the
device is used in water.

Navigation menu
