TEKSUN TECHNOLOGY 521075BT Bluetooth Speaker User Manual 5210753
SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Bluetooth Speaker 5210753
User Manual
1
521075BT
Bluetooth Speaker
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE USE
2
Getting started
Remove the Ornament Speaker & accessories from the box.
Remove all packaging from the Ball Speaker.
Place the packaging inside the box to either store or dispose of safely.
In the Box
Bluetooth Ornament Speaker
Hanging Ribbon
Hanging Hook
USB Charging Cable
Instruction Manual
Features
Handsome glitter finish that blends perfectly with your other ornaments
Streams wireless music from up to 30 feet away
Rich, crisp sound. Perfect for your favorite holiday tunes!
Works with all Bluetooth-enabled devices: smart phones, tablets and more
Rechargeable batteries built-in (Charging cable included)
Safety Instructions
Keep the unit away from heat sources, direct sunlight, humidity, water and any other
liquids.
Do not operate the unit if it has been exposed to water, moisture or any other liquids to
prevent against electric shock, explosion and/or injury to yourself and damage to the unit.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualified electrician.
Improper repairs may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended use.
Keep the unit out of reach of children.
This product is not a toy.
3
Description of Parts
Important: Bluetooth Antenna is an extremely important component to stream wireless music.
Any damage to it will deteriorate streaming & sound quality, significantly.
INSTRUCTIONS FOR USE
Charging Instructions
The speaker is built in with rechargeable battery. Please charge the battery fully, before its
first use.
Insert the USB end of the charging cable (included) to a computer USB port or USB wall
charger, and the Micro USB end to the charging port located on the back of the speaker.
LED light turns red while the speaker is being charged. It takes around 2 hours for the
speaker to charge fully. When the battery is fully charged the red LED light turns off. When
the battery is low, please recharge the speaker.
Turning On/Off the speaker
There is an on/off switch at the back of the speaker. You can turn the speaker on/off by
pressing this switch. In order to save power, turn the speaker off, when not in use.
1 Hanging Ribbon
2 Speaker
3 USB Charging Port
4 ON/OFF Switch
5 Hanging Hook
6 LED Indicator
7 Bluetooth Antenna (Do not fold or cut)
4
Playing Music from your Bluetooth Devices:
Turn on the speaker.
Place the speaker and Bluetooth device (phone or music device) not more than 3 feet
apart from each other.
Activate the Bluetooth function on your Bluetooth device (phone or music device). Please
refer to the manufacturer’s instructions for instructions on enabling Bluetooth on your
device.
Once you have activated Bluetooth on your device, select the speaker “SL Holiday
Tunes” from the list of available Bluetooth devices.
If required, enter the password ‘0000’ to confirm pairing.
Once paired successfully, blue LED flashes every second.
You can play music from your paired device (phone or music device) through the speaker.
If pairing is unsuccessful, turn off the speaker and then re-pair following the above steps.
Once speaker has been paired with your mobile phone etc, it will automatically pair with it,
the next time your device is in proximity with the speaker. Hence above steps are likely to
be followed only while pairing with a device for the first time.
Function Summary
Listening to Music
Once the speaker is paired with your device you can stream music wirelessly through the
speaker.
Select the track you wish to listen to and it will be streamed to your Bluetooth speaker.
Adjust the sound volume from your device.
Should you encounter any problems while streaming please refer your device’s user
manual for further information.
LED indicator
Please refer to the below tables for a list of the LED statuses whilst using the speaker.
Battery Charging Indication
LED indicator Status of the speaker
Red LED Charging
Red LED turns off Charging Completed
LED Indication
LED indicator Status of the speakers
Blue LED flashes rapidly Pairing mode On (searching for Bluetooth device)
Blue LED flashes every one
second
Paired successfully
5
Specifications
Bluetooth specification Bluetooth V2.1
Operating distance 33 Feet, Class II
Speaker 3W
Speaker output 2.5W
Working time Up to 1.5 hour
Charging input voltage DC 5V
Charging time About 2 hours
Dimensions 2.76” x 2.76” x 3.19”
Weight 2.8 Oz
Note: Battery life & charging time may vary based on individual handling & other conditions.
Troubleshooting
Problem Possible Cause Solution
Low sound level Source (Tablet, Mobile Phone,
Laptop, etc.) volume too low.
Battery dead
Adjust source volume.
Charge speaker battery.
Sound distorted Battery nearly dead Charge speaker battery
No sound Source (Tablet, Mobile Phone,
and Laptop.) turned off.
Speaker turned off.
Media paused on source.
Turn the source on.
Turn the speaker on.
Play media from source.
Unable to Pair Bluetooth Disconnected Turn OFF and then turn ON the Speaker; after
about 30 seconds.
Keep your Bluetooth Speaker and Bluetooth
enabled device within 3 feet of each other
during the pairing process.
After a successful pairing, the Blue LED
indicator light will flash every one second.
Care and Maintenance
Read the following recommendations before using the speaker. Following these you will be
able to enjoy the product for many years.
Do not expose the speaker to liquid, moisture or humidity to avoid the product’s internal
circuit being affected.
Don’t use abrasive cleaning solvents to clean the speaker.
Do not expose the speaker to extremely high or low temperature as this will shorten the life
of electronic devices, destroy the battery or distort certain plastic parts.
Don’t dispose of the speaker in a fire as it will result in an explosion.
Don’t expose the speaker to contact with sharp objects as this will cause scratches and
damage.
6
Don’t let the speaker fall on the floor. The internal circuit might get damaged.
Don’t attempt to disassemble the speaker as it may get damaged if you are not
professional.
In case the speaker doesn’t function properly, send it to the store you bought it. The staff will
help you to the problem.
FCC statements:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct theinterference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions: (1)This device may not cause harmful interference, and (2)This device
must accept any interference received, including interference that may cause undesired
operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. such modifications could void the user’s
authority to operate this equipment. Any Changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This device is measured RF output power is less than the SAR exclusion threshold value
for human head and body . Therefore, SAR test is not necessary.
