User Manual

FM REMOTE SIGNAL TORQUE WRENCH

FM96MCU

OPERATION MANUAL

Precaution

1. Place the Unit apart form the metallic structure.

2. Do not place the receiver and the transmitter where the antenna contacts

with metal or electric wire.

3. Do not cut or curl the antenna or the receiver.

4. Do not use the Unit where the electromagnetic noise takes place by

welding machines, electrical discharge machines, PC, etc.

5. If there are any questions, place contact Tohnichi sales office or Tohnichi

authorized distributor.

FCC Regulatory Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) This device

must accept any interference received, including interference that may cause undesired

operation.

Caution:

Any changes or modifications not expressly approved by the party responsible for product

compliance could void the user's authority to operate the equipment.

Canada Regulatory Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numériqué de la classe B est conformé à la norme NMB-003 du

Canada.

For Customers in Canada

This device complies with RSS 210 of Industry Canada (IC).

Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired

operation of this device.

L’ utilisation de ce dispositif est autorisée seulement aux conditions suivantes :

(1) il ne doit pas produire de brouillage et

(2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu,

même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif..

<INDEX>

１. Outline ................................................................................................ 3

２. Features .............................................................................................. 3

３. Construction ...................................................................................... 3

４. Specifications ..................................................................................... 4

５. Transmitter-appearance and components .................................. 5

６. Receiver-appearance and components ......................................... 6

７. Precaution .......................................................................................... 7

-１ Power supply .............................................................................. 7

-２ Placing the receiver ................................................................... 7

-３ Connection with other apparatus .......................................... 7

８. Operation ........................................................................................... 8

-１ Precaution ................................................................................... 8

-２ Replacing battery for transmitter .......................................... 8

-３ Setting the Time to avoid Double Counting .................................. 8

-４ Battery Check ............................................................................. 9

-５ Changing channel ...................................................................... 9

９. Connection to CNA-4mk2 ......................................................... 10

１０. Applicable Frequency .................................................................... 11

１１. Setting the Channel of the Transmitter .................................... 12

１２. Setting the Channel of the Receiver .......................................... 13

１３. Receiver Board ................................................................................ 14

１４. FM Board Replacement Procedure ..................................................... 15

１５. Optional Unit .................................................................................. 17

１６. Troubleshooting .............................................................................. 18

1. Outline

The FM Remote Signal Torque Wrench integrates a wireless signal

generator that counts down the number of bolts or nuts after tightened.

The signal transmitter can be installed onto TOHNICHI torque wrenches,

such as Models QSP, CSP, PQL, PCL, SP, RSP, etc.

It is easy to set the required channel on customer side. 96 channels are

available for the Receiver and 16 channels for the Transmitter.

The receiver can be connected to the CNA-4mk2 Count Checker to

provide complete tightening assurance system to eliminate missed

tightening.

2. Features

This Remote Signal Type torque wrench sends the tightening completion

signal to the Receiver far from the wrench through FM-wave. Tone

frequency of FM-wave can be easily set. This feature reduces the number

of the Remote Signal torque wrenches for spare and a few torque

wrenches enable the more tightening control applications.

3. Construction

Receiver R-FM96D 1 Set

Antenna 1 Set

Transmitter Torque Wrench+F-FM96MCU 1 Set

(Battery Incorporated)

Instruction manual 1 Set

4. Specification

Table 1 FM96MCU Specification

Transmitter Receiver

Model F-FM96MCU R-FM96D

Frequency Band 41MHz Band

(41.025~41.300MHz、25kHz Space、12 Types)

Wave Type FM (F3E)

Channel Change

(by DIP Switch)

Radio Frequency (Fixed) 1ch

Tone Frequency 16 Channels Selection

Radio Frequency

A series: 6 Channels Selection

B series: 6 Channels Selection

Tone Frequency

A, B series: 6 Channels Selection

Channel ／Unit 16ch 96ch

Total Channel 192ch

Identification Signal Dual Tone System

Signal Output No-Voltage Contact Output(1a)

DC30V 1A, AC125V 0.3A

Power DC1.5V R3 (Alkaline Battery) AC100∼115V±10%

Antenna Wire 1/4λwhip

Operating Temperature

Range 0~40℃

LED Lamp Operating Check Lamp Power, Receiving Lamp

Check Function Battery Check Terminal

Transmitting

Dimension 18.2×36×68(H×W×D) 51×150×210(H×W×D)

Note 1 : A series frequency of the Receiver is not compatible with B series

frequency of the Receiver.

Note 2 : Refer to the bale 3, 4 & 5 for the combination for radio frequency

and tone frequency.

5. Transmitter-appearance and components

Tone Frequency Setting Switch

Battery

OPERATION CHECK

MODEL NAME

BATTERY CHECK TERMINAL

TRANSMITTER-RECEIVER CHECK SWITCH

CHANNEL PLATE

6. Receiver-appearance and components

ＰＯＷＥＲ

ｍｏｄｅｌ

ＰＯＷＥＲ

ＯＵＴＰＵＴ

ＳＩＧＮＡＬ

Ｒ−ＦＭ９６Ｄ

ＣＨ

ＧＮＤ

Ａ１−１

ＡＣ１００Ｖ

ANTENNA CONNECTOR

POWER LAMP RECEIVER LAMP

POWER

SWITCH GND TERMINA

POWER CABLE

CHANNEL PLATE

SERIAL No.

7. Precaution

1 Power Supply

Use 100∼115VAC±10％(50/60Hz)power source for the Receiver.

Use the constant-voltage transformer where the power supply is not

constant.

Always use LR03 Alkaline battery for the Transmitter.

2. Placing FM Receiver

Avoid placing the antenna near the steel columns or other metal pipes,

which will affect the receiving condition.

Press the Transmission check Button, then confirm that operation

check LED for Transmission turns on and the “SIGNAL” lamp for

Receiver turns on.

3. Connection with Other Apparatus.

Verify that both the Receiver and the equipment are turned off.

Connect the equipment to the output terminal of the Receiver with a

two-core shielded wire.

(Connect a separate shielded wire to the GND terminal.)

First, turn on the Receiver, and then the equipment.

8. Operation

1. Precaution

Handle the torque wrench with care.

Read the Operation Manual before operation.

2. Replacing Battery for Transmitter

Loosen two screws of top cover and remove the Transmitter.

Remove the empty Battery, and insert a new one.

Always use an R3 Alkaline Battery.

Install the Transmitter, and tighten the screws. Tightening torque T=270cN･m）

※ Stud, which comes from wrench, should not be between plate spring and the

Battery case when installing the Transmitter.

OK NG

3. Setting the Time to Avoid Double Counting

The Timer is set to 1 second when delivered.

To change the time setting, turn the variable resistance (VR2) on the Receiver

board. (Refer to 13. Circuit Diagram for the Receiver in page 14.)

The time can be set between 0.2 sec. and 2.2 sec. as shown below.

0.2sec

2.2sec

VR2

TIMER

Stud is between plate

spring and Battery case

Stud

4. Battery Check

Set the switch of the Battery Checker FM-BCY (Option) to BC side.

Insert the plug of the Battery Checker to the battery terminal of the

Transmitter. The battery should be serviceable if within “OK” range.

If the indicator shows the yellow range, replace the battery. If the

indicator shows “NG”, replace the battery. Refer to 8-2 Replacing the

Transmitter Battery when replace the battery.

5. Channel Setting

Turn off the receiver. To change the current channel, change the position of the

dip switches on the board of the Transmitter and the Receiver. (Refer to the

Table 3∼5.) Channel indication is as follows.

Transmitter：F-FM96MCUA1-16

Receiver：R-FM96DA1-16

Ex. 1：Change of the Transmitter Channel (only tone frequency)

(1) Remove the Transmitter cover.

(2) Change the position of the DIP switches, referring to the Table 3.

(3) Put the transmitter back.

Ex. 2：Change of the Receiver Channel

(1) Remove the front cover.

(2) Change the position of the DIP switches located upper part of the Transmitter

for the radio frequency, referring to the table4. (6 DIP switches)

(3) Change the position of the DIP switch SW 2 located lower part of the

Transmitter for the tone frequency, referring to the table 5. (4 DIP switches)

(4) Put the front cover back.

Channel number of tone frequency

(1∼16ch)

Channel number of radio frequency

(A1toA6 or B1toB6)

Channel number of tone frequency

(1∼16ch)

Channel number of radio frequency

(A1toA6 or B1toB6)

9. Connecting to CNA-4mk2

The CNA-4mk2 Count Checker can be used together with the Receiver,

using a two-core shielded wire, which is connected between the output

terminals of the Receiver and the “WRENCH No.” and “COM” terminals.

(Connect separate shielded wire to the GND terminals。)

ｍｏｄｅｌ

ＰＯＷＥＲ

Ｒ−ＦＭ９６Ｄ

ＯＵＴＰＵＴ

ＳＩＧＮＡＬ

ＣＨＡ１−１ＯＫ

ＲＥＳＥＴ

ＮＧ

ＳＥＴＵＰ

ＳＥＴ

ＳＥＬＥＣＴ

１２３４

ＷＲＥＮＣＨＮｏ．

ＯＫ／ＮＧ

ＣＯＭ

１２３

１

ｍｏｄｅｌ

２

ＳＥＬ

１２

ＣＯＵＮＴ

３

ＷＲＥＮＣＨＮｏ．

ＷＯＲＫＮｏ．

ＲＳＴ

ＥＮＤ

４

ＣＮＡ−４ｍｋ２

ＣＯＭ４

Separate shielded wire GND

GND

10. Frequency list

Table 2 Applicable frequency

CHANNEL FREQUENCY (MHz)

A1 41.025

A2 41.050

A3 41.075

A4 41.100

A5 41.125

A6 41.150

B1 41.175

B2 41.200

B3 41.225

B4 41.150

B5 41.275

B6 41.300

11. Setting Channel of the Transmitter

NOTE : OFF position unless stated.

Table 3 Tone Frequency Setting

CH DS-1 DS-2 DS-3 DS-4 DS-5 DS-6 DS-7 DS-8

1 ON ON

2 ON ON

3 ON ON

4 ON ON

5 ON ON

6 ON ON

7 ON ON

8 ON ON

9 ON ON

10 ON ON

11 ON ON

12 ON ON

13 ON ON

14 ON ON

15 ON ON

16 ON ON

12. Setting Channel of the Receiver

NOTE : OFF position unless stated.

Table 4 Radio Frequency Setting

CH SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6

1 ON

2 ON

3 ON

4 ON

5 ON

6 ON

Table 5 Tone Frequency Setting

CH SW2-1 SW2-2 SW2-3 SW2-4

1 ON ON ON

2 ON ON ON

3 ON ON

4 ON ON ON

5 ON ON

6 ON ON

7 ON

8 ON ON ON

9 ON ON

10 ON ON

11 ON

12 ON ON

13 ON

14 ON

16 ON ON ON ON

13. Receiver Board

SW1

SW2

VR2

OFF

Antenna

Connector

Power supply connector

OUTPUT Terminal

Radio Frequency Setting

DIP SW

Tone frequency

Setting SW

Timer Setting VR

Lift up

14. FM Board Replacement Procedure

Preparation

1. RTD500CN

2. Hexagon Bit, size 3mm

3. F-FM96MCU, FM transmitter

5. R-FM96D, FM receiver

1 Loosen two bots and remove the outer cover.

Note : Covered bolt will not leave from cover.

2 Remove antenna connector.

3 Set Antenna Connector.

Insert the antenna connector, as open side must face to torque wrench

body.

Open side

Insert

Pull

Antenna Connector

Set to Outer Case

LED

4 Set Antenna Connector

Set AAA battery in the cell, and fit the outer cover with two screws.

Tightening Torque : 270cN.m

Note : FM stud must be located as below drawing shown.

OK NG

5 Check of Operation

Check to make sure that the Light Emitting Diode turns on when the toggle

is depressed and it makes a “click “sound, then perform the following tests.

A. Twist the torque wrench right and left in a no load state to make sure the LED

does not light up.

B. Twist the torque wrench right and left in the state in which the goggle

is the LED should remain ON.

6 Final Check

Perform test to check whether or not the receiver unit, R-FM96D receives

the FM transmission when a bolt is tightened and wrench clicks.

Stud is wrongly stayed between

plate spring and Battery case

Stud

15. Optional Unit

1. FM-ANT, whip antenna

Antenna, directly connected to the receiver

2. FM-CNT, connector

Connector, in order to use the antenna away from the receiver.

Ex. Where the separate antenna is required due to bad receiving

condition.

3. FM-MBX, magnet for fixing the antenna

Magnet, in order to fix the antenna away from the receiver.

4. FM-COD, antenna extension wire

5. FM-BCY, battery checker

Checker, in order to check the battery and the condition of

FM-wave transmission.

Ex.1 Turn the FM-BCY switch to BC side and insert the plug of the

FM-BCY into the check terminal of the transmitter to check

the battery condition.

Ex.2 Turn the FM-BCY switch to RC side, insert the plug of the

FM-BCY into the check terminal of the transmitter and press

the transmission check bottom. If the FM-Wave is transmitted,

the red lamp on the FM-BCY lights.

16. Trouble Shooting

Phenomenon Possible Cause Check Point Action

Wrong channel setting on

transmitter or receiver

Dip Switch on receiver

and transmission

Correct the channel

Low battery of the

transmission

Check by battery

checker

Replace battery if NG

Battery installed in a wrong

position

Check the polarity of the

battery

Battery misplaced in the

case

Check the battery

position

Set the battery in the right

position horizontally in the

case.

Not Receiving

Noise Check the receiving

condition

Keep away the transmitter

and the receiver from the

noise source.

Loose or disconnected

transmitter antenna and

connector.

Plug the antenna firmly.

Replace the antenna if

disconnected.

Insulation failure of the

transmitter antenna and

connector.

Check the antenna and

connectors.

Failure of receiver placing Any steel columns or

metal pipes near the

receiver?

Remove the receiver or use

FM-COD and FM-MBX

Short

Transmission

distance

Noise Check the receiving

condition

Keep away the transmitter

and the receiver from the

noise source.

Please check a transceiver state periodically.

If there are any questions, please contact a Tohnichi authorized distributor or

Tohnichi office.

TOHNICHI MFG RFM96D FM Receiver User Manual

TOHNICHI MFG. CO., LTD FM Receiver

User Manual

Navigation menu

Namespaces

Views

Navigation
