TY‐16FRemoteControl  Page1



UserManual

BatteryInstallation

1. Removetheremotecontrolandbatteryfromthepolybag.

2. Openthebatterycoveronthebackoftheremotebyslidingthecovertowardsthebottomoftheremote

3. Cleanthebatterycontactsandalsothoseofthedevicepriortobatteryinstallation.

4. Useonly12Vbatterytype23Aforreplacement,useofotherbatteriesmaydamageremote.

5. Insertnegative(‐)endofthebattery(seemarkingonbattery)intothespringsideofthebatteryholder

andinsertpositive(+)endofthebatteryintootherside.

6. Closebatterycoverbyslidingbackintoplace.

   

RemoteControlOperation:

1. Theremotehastwobuttonsonthefrontside:

a. ON/OFF–thisisthelargerbutton.PresstoturnthesetOFF.PressagaintoturnthesetON.

Note:evenwhenthelightsareoff,thesetstillhaspowertoalllamps,todisconnectpower,you

mustunplugtheset.

1. FUNCTION–thisisthesmallerbutton.Presstochangethelightpatterntothenextfunctionmode.

NOTES:

1. Lightsetmustbepluggedintoworkingoutletforremotetofunction.

2. WhenusingtheremotetoturnyoursetON,theremaybeaslightdelaybeforethelightpatternstarts

working.

3. Tochangethelightpattern,itisrecommendedtowaitafewsecondsafterpressingtheFUNCTIONbutton

untilyoureachthedesiredpattern.

4. Ifthelightsdonotchangefunctionorthesetdoesnotturnonoroffwiththeremote,seethetrouble

shootingsection.

5. Ifthereisapowerinterruption,includingifusedonaswitchedoutlet,onatimer,orpowerfailure,the

system’smemorywillretainthelastlightpatterndisplayed.

6. Theeffectiveoperatingdistanceoftheremoteisupto150feet(45.72meters).

TY‐16FRemoteControl  Page2



WARNING:

Donotexposeremotetomoisture.

Removebatterywhennotusedforextendedperiodoftime,orwhendepleted.

Disposeofbatteriesproperlybyfollowingdirectionsonbatteries.

Useonly12Vbatterytype23Aforreplacement,useofotherbatteriesmaydamageremote.

CAUTION: Replaceonlywith23AAlkalinetypebatteries.

TroubleshootingInstructions:

Iflightsdonotchangefunctionorturnofforonwhenabuttonispushed:

1. Checkthatthelightontheremoteisilluminatingandnotdim:

a. Checkthatbatteryisinsertedproperly(+and‐)andmakingcontact(typicallyLEDwouldnot

beilluminatinginthiscondition).

b. Cleanbatteryandremoteterminals

c. Replacebattery

2. Makesureantennaisup.

3. Makesureyouarecloseenoughtothelightsetcontrolbox.

4. Moveawayfromotheritemsthatmaycauseinterference,suchascellphones,2‐wayradios,

microwaveovens,computers,etc.

5. Makesurelightstringhaspower:

a. Makesurepowerisonattheoutlet(tryadifferentproductontheoutlettoensurepoweris

on)

b. Makesureoutletisnotpoweredbyadimmer(movetoadifferentoutlet)

c. Makesureoutletisnotonatimer(moretoadifferentoutlet)

d. ResetGroundFaultCircuitInterrupter(GFCI)incaseitaccidentallytripped.

6. Unpluglightstringplugfor1minuteandplugbackintopoweredoutletandretry.

7. Ifusedonatimercontrolledcircuit,makesurethetimerisratedforusewithCompactFluorescent

bulbs(CFL)assometimerswillnotworkproperlywithelectronics.

Ifsetsdonotturnonwhenpoweristurnedontotheset(whenpluggedin,timerturnson,orswitchcontrolling

theoutletisturnedon),trypushingthe“On/Off”buttonasitmayhavebeenturnedoffviatheremotethelast

timeitwasused(remember,thisproductwillrememberthelastfunctionitwasturnedoffat,includingifthe

remotewasusedtoturnthesetoff).

TY‐16FRemoteControl  Page3



installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.

However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff

andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)this

devicemaynotcauseharmfulinterference;and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesirableoperation.

CAUTION:Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe

user’sauthoritytooperatetheequipment.



NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuantto

Part15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterference

inaresidentialinstallation.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergy,andifnot

FCCInformation
