TRENDNET TEW670APB 11n Draft dual band AP User Manual UG TEW 670APB

TRENDNET, INC. 11n Draft dual band AP UG TEW 670APB

UserManual.wiki >

TRENDNET >

TEW670APB User Manual HTML Version

Manual

Regulatory notes and statements

Wireless LAN, Health and Authorization for use

The use of Wireless LAN devices may be restricted in some situations or

environments for example:

·On board of airplanes, or

·In an explosive environment, or

·In case the interference risk to other devices or services is perceived or identified

as harmful

In case the policy regarding the use of Wireless LAN devices in specific

organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial

plants, private buildings etc.) is not clear, please ask for authorization to use these

devices prior to operating the equipment.

Regulatory Information/disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with

the instructions included in the user documentation provided with the product. Any

changes or modifications made to this device that are not expressly approved by the

manufacturer may void the user’s authority to operate the equipment. The

Manufacturer is not responsible for any radio or television interference caused by

unauthorized modification of this device, of the substitution or attachment.

Manufacturer and its authorized resellers or distributors will assume no liability for

any damage or violation of government regulations arising from failing to comply

with these guidelines.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

If this device is going to be operated in 5.15 ~ 5.25GHz frequency range, then it is

restricted in indoor environment only.

This transmitter must not be co-located or operating in conjunction with any other

antenna or transmitter.

The availability of some specific channels and/or operational frequency bands are

country dependent and are firmware programmed at the factory to match the

intended destination. The firmware setting is not accessible by the end user.

Europe – EU Declaration of Conformity

This device complies with the essential requirements of the R&TTE Directive

1999/5/EC. The following test methods have been applied in order to prove

presumption of conformity with the essential requirements of the R&TTE Directive

1999/5/EC:

EN60950-1: 2006

Safety of Information Technology Equipment

EN 50385: 2002

Product standard to demonstrate the compliance of radio base stations and fixed

terminal stations for wireless telecommunication systems with the basic restrictions

or the reference levels related to human exposure to radio frequency

electromagnetic fields (110MHz - 40 GHz) - General public

EN 300 328 V1.7.1 (2006-10)

Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband

transmission systems; Data transmission equipment operating in the 2,4 GHz ISM

band and using wide band modulation techniques; Harmonized EN covering

essential requirements under article 3.2 of the R&TTE Directive

EN 301 489-1 V1.6.1: (2005-09)

Electromagnetic compatibility and Radio Spectrum Matters (ERM);

ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;

Part 1: Common technical requirements

EN 301 489-17 V1.2.1 (2002-08)

Electromagnetic compatibility and Radio spectrum Matters (ERM);

ElectroMagnetic Compatibility (EMC) standard for radio equipment and services;

Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz

high performance RLAN equipment

This device is a 2.4 GHz wideband transmission system (transceiver), intended for

use in all EU member states and EFTA countries, except in France and Italy where

restrictive use applies.

In Italy the end-user should apply for a license at the national spectrum authorities

in order to obtain authorization to use the device for setting up outdoor radio links

and/or for supplying public access to telecommunications and/or network services.

This device may not be used for setting up outdoor radio links in France and in

some areas the RF output power may be limited to 10 mW EIRP in the frequency

range of 2454 – 2483.5 MHz. For detailed information the end-user should contact

the national spectrum authority in France.

0560

Česky

[Czech] TRENDnet tímto prohlašuje, že tento TEW-670APB je ve shodě se základními požadavky a

dalšími příslušnými ustanoveními směrnice 1999/5/ES.

Dansk

[Danish] Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW-670APB overholder de

væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.

Deutsch

[German] Hiermit erklärt TRENDnet, dass sich das Gerät TEW-670APB in Übereinstimmung mit den

grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie

1999/5/EG befindet.

Eesti

[Estonian] Käesolevaga kinnitab TRENDnet seadme TEW-670APB vastavust direktiivi 1999/5/EÜ

põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

English Hereby, TRENDnet, declares that this TEW-670APB is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

Español

[Spanish] Por medio de la presente TRENDnet declara que el TEW-670APB cumple con los requisitos

esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.

Ελληνική

[Greek]

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ TRENDnet ∆ΗΛΩΝΕΙ ΟΤΙ TEW-670APB ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ

ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ

1999/5/ΕΚ.

Français

[French] Par la présente TRENDnet déclare que l'appareil TEW-670APB est conforme aux exigences

essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.

Italiano

[Italian] Con la presente TRENDnet dichiara che questo TEW-670APB è conforme ai requisiti essenziali

ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.

Latviski

[Latvian] Ar šo TRENDnet deklarē, ka TEW-670APB atbilst Direktīvas 1999/5/EK būtiskajām prasībām

un citiem ar to saistītajiem noteikumiem.

Lietuvių

[Lithuanian] Šiuo TRENDnet deklaruoja, kad šis TEW-670APB atitinka esminius reikalavimus ir kitas

1999/5/EB Direktyvos nuostatas.

Nederlands

[Dutch] Hierbij verklaart TRENDnet dat het toestel TEW-670APB in overeenstemming is met de

essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.

Malti

[Maltese] Hawnhekk, TRENDnet, jiddikjara li dan TEW-670APB jikkonforma mal-ħtiġijiet essenzjali u ma

provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.

Magyar

[Hungarian] Alulírott, TRENDnet nyilatkozom, hogy a TEW-670APB megfelel a vonatkozó alapvetõ

követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.

Polski

[Polish] Niniejszym TRENDnet oświadcza, że TEW-670APB jest zgodny z zasadniczymi wymogami

oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.

Português

[Portuguese] TRENDnet declara que este TEW-670APB está conforme com os requisitos essenciais e outras

disposições da Directiva 1999/5/CE.

Slovensko

[Slovenian] TRENDnet izjavlja, da je ta TEW-670APB v skladu z bistvenimi zahtevami in ostalimi

relevantnimi določili direktive 1999/5/ES.

Slovensky

[Slovak] TRENDnet týmto vyhlasuje, že TEW-670APB spĺňa základné požiadavky a všetky príslušné

ustanovenia Smernice 1999/5/ES.

Suomi

[Finnish] TRENDnet vakuuttaa täten että TEW-670APB tyyppinen laite on direktiivin 1999/5/EY

oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Svenska

[Swedish] Härmed intygar TRENDnet att denna TEW-670APB står I överensstämmelse med de väsentliga

egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

vii

TABLE OF CONTENT

About This Guide...................................................................................................................................................................................... 1

Overview of this User’s Guide.............................................................................................................................................................. 1

Introduction............................................................................................................................................................................................... 2

Unpacking and Setup ................................................................................................................................................................................ 3

Unpacking............................................................................................................................................................................................. 3

Setup ..................................................................................................................................................................................................... 3

Hardware Instalation................................................................................................................................................................................. 4

Front panel............................................................................................................................................................................................ 4

Rear Panel............................................................................................................................................................................................. 5

Side Panel ............................................................................................................................................................................................. 6

Hardware connections........................................................................................................................................................................... 6

Connect to the Switch/Hub/Router ................................................................................................................................................... 7

Check the installation........................................................................................................................................................................ 7

Configuring the Wireless LAN Access Point ........................................................................................................................................... 7

Login to the Wireless AP through WLAN............................................................................................................................................ 7

Login..................................................................................................................................................................................................... 7

Main Screen of the Access Point .......................................................................................................................................................... 8

Wizard................................................................................................................................................................................................... 8

Status................................................................................................................................................................................................... 12

Basic Setting ....................................................................................................................................................................................... 14

IP Setting............................................................................................................................................................................................. 17

Advanced Wireless Setting ................................................................................................................................................................. 18

Access Point Mode ......................................................................................................................................................................... 18

Wireless Bridge mode..................................................................................................................................................................... 19

Repeater mode ................................................................................................................................................................................ 20

Security............................................................................................................................................................................................... 22

Tools ................................................................................................................................................................................................... 23

Technical Specifications ......................................................................................................................................................................... 25

ABOUT THIS GUIDE

Congratulations on your purchase of this 300Mbps Dual Band Wireless N Access

Point. This manual helps to describe the innovating wireless technology that can

help you build a wireless network easily! The manual contains detailed instructions

in operation of this product. Please keep this manual for future reference.

Overview of this User’s Guide

Introduction. Describes the 802.11a/b/g/n Dual Band WLAN Access Point and its

features.

Unpacking and Setup. Helps you get started with the basic installation of the

802.11a/b/g/n Dual Band WLAN Access Point.

Hardware Installation. Describes the LED indicators of the AP.

Configuring the Wireless LAN Access Point. Provides instructions on how to

configure the AP and it’s features.

Technical Specifications. Lists the technical (general, physical and environmental)

specifications of the 802.11a/b/g/n Dual Band WLAN Access Point.

INTRODUCTION

The 300Mbps Dual Band Wireless N Access Point (TEW-670APB) creates a high

performance dual band wireless n network with up to 14x the speed and 4x the

coverage of wireless g.

Create a wireless network using either the more common 2.4GHz or the

uncongested low-interference 5GHz wireless radio frequency with Dual Band

wireless n technology.

Extend your wireless network by adding additional wireless access points using the

Wireless Distribution System (WDS) feature. Monitor device status with SNMP v3

reporting. Advanced wireless encryption secures your wireless network. Provide

high speed Dual Band wireless coverage to stream HD media, download files and

surf the Internet.

Features

 Wi-Fi Compliant with IEEE 802.11n (Draft 2.0) , IEEE 802.11b, IEEE 802.11b

and IEEE 802.11a standards.

 Non-concurrent Dual Band architecture: create either a 2.4 or 5Ghz wireless

network.

 Add a wireless network with Access Point mode or expand your network with

Wireless Distribution System (WDS).

 Built in DHCP server allows for IP address distribution on the local network.

 1 x 10/100Mbps Auto-MDIX LAN port

 Supports 64/128-bit WEP(for 11b/g), WPA/WPA2, and WPA-PSK/WPA2-

PSK

 Allow or restrict wireless access with MAC filtering

 Easy wireless setup via WiFi Protection Setup.

UNPACKING AND SETUP

This chapter provides unpacking and setup information for the Access Point.

Unpacking

Open the box of the Access Point and carefully unpack it. The box should contain

the following items:

 TEW-670APB

 Multi-Language Quick Installation Guide

 Power Adapter

 CD-Rom (User’s guide)

If any item is found missing or damaged, please contact your local reseller for

replacement.

Setup

The setup of the Wireless Access Point can be performed using the following steps:

 Locate an optimum location for the Wireless LAN Access Point (AP). The best

place for your AP is usually the center of your wireless network, with line of

sight to all of your mobile stations.

 Visually inspect the Ethernet RJ45 port connector and make sure that it is fully

plugged in to the system’s Ethernet switch/hub port.

 Fix the direction of the antennas. Try to place the AP in a position that can best

cover your wireless network. Normally, the higher you place the antenna, the

better the performance will be. The antenna’s position enhances the receiving

sensitivity.

 Visually inspect if the Power Adapter was fully plugged to the device power

jack.

HARDWARE INSTALATION

Front panel

The figure below shows the LED Indicator of the Wireless LAN Access Point.

Power:

This indicator lights green when the Access Point is turned on.

Status:

This indicator blinkswhen the WLAN AP is working successfully. Otherwise, an on

or off means the function of the WLAN AP has failed.

LAN:

This indicator lights green when the LAN port has successfully connected to an

Ethernet network. Otherwise, the indicator blinks while transmitting and receiving

data on the Ethernet network.

WLAN:

This indicator blinks during Wireless LAN activity.

Rear Panel

The figure below shows the rear panel of the Access Point

Rear Panel

LAN

Ethernet port with 10/100Mbps Fast Ethernet connections, connect this port to a

switch/hub.

RESET

Press the “RESET” button for more than 5 seconds buttonto reset the settings back

to factory default.

Power

Connect the DC Power Adapter plug to the AP’s power jack.

Antenna

Two external 3 dBi dipole antennas.

Side Panel

The figure below shows the side panel of the IEEE 802.11b/g/n Wireless

Broadband Router.

Side Panel

WPS

Push this button to execute the Wi-Fi Protected Setup process.

Hardware connections

Connect to the Switch/Hub/Router

1. Plug in one end of the RJ45 network cable to a Switch/Hub port,

2. Plug in the other end of the RJ45 network cable to the Wireless Access Point.

Check the installation

The LEDs of the Access Point are clearly visible and the status of the network link

can be seen instantly:

1. With the power source on, once the device is connected, the Power, LAN and

WLAN port LEDs will light up indicating a normal status.

2. If the LAN Port’s Link indicator does not light up then check the RJ-45 cable if

it is firmly connected to the RJ45 port, while the LAN is linked up to the

Switch/Hub, the LAN port’s LED will light up.

CONFIGURING THE WIRELESS LAN ACCESS POINT

The Wireless Access Point has a Web GUI interface for easy configurations

through a Web Browser. A network manager can manage, control and monitor the

AP from the local LAN. This section indicates how to configure the AP to enable

its functions.

Before configuring the Wireless AP through WLAN, make sure that the SSID,

Channel and encryption settings are set properly.

The default setting of the Wireless AP that you will use:

 SSID: TRENDnet670

 Wireless Mode: Access point

 Channel: 6

 Channel Width: 20MHz

 Security: disabled

 IP address: 192.168.10.100

Before you configure this device, note that when the AP is configured through an

Ethernet connection, make sure the manager PC must be set on same the IP

network. For example, when the default network address of the default IP address

on the AP is 192.168.10.100, then the manager PC should be set at 192.168.10.x

(where x is a number excluding 100), and the default subnet mask is 255.255.255.0.

Open Internet Explorer 6.0 or above Web browser.

Enter IP address http://192.168.10.100 (the factory-default IP address setting) on

the address bar.

When the below screen appears enter your User name and Password, both of the

default Username and Password is “admin”

Main Screen of the Access Point

The screen will show the status of the AP when you login to the AP.

There are seven main functions in the main screen: Wizard, Status, Basic Setting,

IP Setting, Advanced Setting, Security and Tools.

Wizard

The setup wizard is provided as the part of the web configuration utility. Users can

simply follow the step-by-step process to configure the Access Point in 4 easy steps.

Click on the “Wizard” button and the following screen will appear. Please click

“Next” to continue.

Step 1: Set your new password

Enter a new password and click “Next” to continue.

Step2: Set the SSID, Channel, Operation Band, 802.11 mode and Channel

Width

Please type the name of SSID and select the Channel, Operation Band, 802.11

mode and Channel Width. Then, click “Next” to continue.

Step 3: Secure your Wireless Network

The default security setting is set to NONE. There are four options: BEST (WPA2),

BETTER (WPA), GOOD (WEP) and NONE. Please select the type of security and

click “Next” to continue.

BEST (WPA2 Personal)

Passphrase: The length should be at least 8 characters long and click “Next” to

continue.

BETTER (WPA Personal)

Passphrase: The length should be at least 8 characters long and click “Next” to

continue.

GOOD (WEP)

Key Type: Select the key format from the drop-down list HEX or ASCII.

Key Size: Select the level of encryption from the drop-down list.

Wireless Security Password: Enter your WEP security key and click “Next” to

continue.

Step 4: Save and Restart

The Setup wizard is now completed. The new settings will be take effect after the

Access Point has restarted. Please click “Restart” to save the new configuration

and reboot the Access Point. Click “Exit” to quit without making any changes.

Users also can go back to modify the setting by clicking “Back”.

Status

This page shows the following information.

Firmware Version: Shows the current firmware version and released date code.

LAN: Shows the Mac address, IP address (default: 192.168.10.100), Subnet Mask

and Gateway Address. The current LAN traffic calculated in terms of number of

packets sent and received by the AP through a wired connection is also displayed.

Wireless: Shows the Mac address, SSID, Encryption status (Enable or Disable) and

wireless channel. The current wireless traffic calculated in terms of the number of

packets sent and received is also displayed.

Wireless Station: Shows the connected wireless stations.

View Log: Click the “View Log” button to display the View Log page. The View

Log page records every event and the time that it happens to the AP.

Click “First Page” to view the first page of the log.

Click “Last Page” to view the final page of the log.

Click “Previous Page” to view the page just before the current page.

Click “Next Page” to view the page just after the current page.

Click “Clear Log” to delete the contents of the log and begin a new log.

Click “Refresh” to renew log statistics.

Basic Setting

This page allows users to set the AP’s Name, SSID, Channel, 802.11 Mode,

Channel Width and Authentication settings.

AP Name: Type the AP name in the text box. The AP name is required by

DHCP identify (host name).

SSID: Service Set Identifier, which is a unique name shared among all clients

and nodes in a wireless network. The SSID must be identical for each clients and

nodes in the wireless network.

Channel: Select a channel for wireless communications. The channel of any

wireless device must match the channel selected here in order for the wireless

device to access the network via the AP.

802.11 Mode: Select one of the following:

 2.4GHz 802.11 b/g mixed mode - Select if you are using both 802.11g

and 802.11b wireless clients in 2.4GHz operation band.

 2.4GHz 802.11 n only - Select if you are using only 802.11n wireless

clients only in 2.4GHz operation band.

 2.4GHz 802.11 b/g/n mixed mode - Select if you are using 802.11b,

802.11g and 802.11n wireless clients in 2.4GHz operation band.

 5GHz 802.11 a/n mixed mode - Select if you are using 802.11a and

802.11n wireless clients in 5GHz operation band.

Note: For FCC domain device, you can only select Channel 1~11

For ETSI domain device, you can only select Channel 1~13

Channel Width: Select the Channel Width:

 20MHz - Select if you are not using any 802.11n wireless clients.

 Auto 20/40 - This is the default setting. Select if you are using both

802.11n and non-802.11n wireless devices.

Authentication Type: The authentication type default is set to open system.

There are four options: Disabled, WEP, WPA, and WPA2.

WEP Encryption

Key Type: Open System and Shared Key requires the user to set a WEP key to

exchange data with other wireless clients that have the same WEP key.

WEP Key: Select the level of encryption from the drop-down list.

Mode: Select the key type: ASCII or HEX

Key 1 ~ Key 4: Enables users to create up to 4 different WEP keys. Manually

enter a set of values for each key. Select a key to use by clicking the radio button

next to the key.

WPA/WPA2-EAP Security

If WPA or WPA2 EAP is selected, the above screen is shown. Please set the

parameters of the RADIUS server.

Cipher Type: Select the cipher type for TKIP or AES encryption, Select Auto to

auto detect the cipher type.

RASIUS Server 1/2:

1. Enter the IP address, Port used and Shared Secret by the Primary Radius

Server.

2. Enter the IP address, Port used and Shared Secret by the Secondary Radius

Server. (optional)

WPA-PSK/WPA2-PSK Security

If WPA or WPA2Auto PSK is selected the below screen will appear.

Cipher Type: Select the cipher type for TKIP or AES encryption, Select Auto to

auto detect the cipher type.

Passphrase: The length should be at least 8 characters long.

IP Setting

This page allows users to set the LAN port properties, such as the IP address,

subnet mask, DNS and DHCP Server setting.

LAN IP: Select the LAN IP configuration type “Obtain IP Automatically” or Fixed

IP”. If the “Obtain IP Automatically” is selected, the IP address will be obtained by

a DHCP server. Otherwise, if the “Fixed IP” is selected you must enter the values

for the IP address, Subnet Mask and Gateway., The default IP address of this AP is

192.168.10.100 with the subnet mask of 255.255.255.0 and Gateway address of

192.168.10.254. Click the “Apply” button for the changes to be effective.

DHCP Server: Selected the “Enable” button to allow the AP to automatically

assign IP addresses to devices connecting to the WLAN.

Start IP / End IP: Enter the IP address range that the DHCP Server will use to

assign all WLAN devices connected to the AP.

Domain Name: Type the local domain name of the network in the text box. This

item is optional.

Lease Time: The lease time specifies the time a network user is assigned with

their current dynamic IP address.

Advanced Wireless Setting

This page contains configurations for advanced users, changes applied reflects the

wireless performance and operating modes.

Mode: The WLAN AP supports three operation modes for Access Point, Wireless

Bridge, Repeater modes.

Access Point Mode

Configure the AP to Access Point mode; with this mode, WLAN clients can

access LAN or other WLAN clients through this AP.

AP mode application

Wireless Bridge mode

Configure to the wireless bridge mode; the TEW-670APB will be a LAN to LAN

wireless Ethernet bridge between two separated Ethernet LAN segments.

Note: The Wireless Bridge mode only supports in using two more of the TEW-

670APB.

Wireless Bridge mode application

WDS Wireless Bridge mode configuration

Site Survey: This button allows user to enable the Site Survey function to scan

for the available wireless networks and establish wireless communications with

one. Select one of them listed to establish communications and click “Apply”

button.

Remote AP MAC/SSID: Enter the MAC address and SSID of the opposite AP

here.

Repeater mode

Configure the AP to Repeater mode; the AP will be a wireless LAN repeater that

will extend the WLAN coverage range.

Note: The Wireless Bridge mode only supports using two more of the TEW-

670APB.

Repeater mode application

Repeater mode configuration

Site Survey: This button allows user to enable the Site Survey function to scan

for the available wireless networks and establish wireless communications with

one. Selected one of them listed to establish communications and click “Apply”

button.

Remote AP MAC/SSID: Enter the MAC Address and SSID of the Remote AP

who will be repeated.

Beacon Interval: The period of time in milliseconds that AP sends out a beacon.

Default is 100 milliseconds.

RTS Threshold: The size of RTS/CTS packet size. Default is 2346 bytes.

Fragmentation Threshold: The number of bytes used for the fragmentation

boundary for directed messages. Default is 2346 bytes.

DTIM Interval: This value indicates the interval of the Delivery Traffic Indication

Message (DTIM). A DTIM field is a countdown field informing clients of the next

window for listening to broadcast and multicast messages. When the access point

has buffered broadcast or multicast messages for associated clients, it sends the

next DTIM with a DTIM interval value. Access point clients hear the beacons and

awaken to receive the broadcast and multicast messages.

SSID Broadcast: While SSID Broadcast is enabled, all wireless clients will be able

to locate the access point. For secure purpose, user may want to disable SSID

broadcast to allow only those wireless clients with the AP SSID to communicate

with the access point.

WDS: Enabled WDS function allows the TEW-670APB in Bridge mode or

Repeater mode to connect to this TEW-670APB.

WMM: Enable the WMM (QoS for wireless network) function to improve the

quality of video and voice applications for your wireless clients.

Security

This page is where users can configure the security features supported by this

Access Point.

Password: Allows user to change the login password. Here are the necessary steps:

1. Enter the new password in the “AP Password New:” field.

2. Enter the new password again in the “Confirm” field.

3. Click “Apply”

MAC Filter: MAC Filter function controls the MAC of the network devices that

are listed in this table for access authorization or denial. There have three choices:

 Enable / Disable MAC Filters

 Only allow PCs with MAC listed below to access device

 Only deny PCs with MAC listed below to access device

The maximum number of MAC addresses that can be stored is 20. User can browse

through the MAC address saved by selecting the MAC Filter List.

For any changes made in the security page, click “Apply” for the changes to be

effective.

Tools

Four functions are provided in this page, Backup, Restore Settings, Restore default

settings and Firmware Upgrade.

Backup Current Setting: Click on “Backup Current Setting” button, which will

open a FileSave Dialog box, where users can save the current settings and

configurations to a file.

Restore Configuration Settings: Click on the “Browse” button to open a

FileOpen Dialog box, where users can load previously saved settings and

configurations. Upon selecting the saved file, click “Upload” and complete the

restore process when the access point re-operates after it restarts.

Factory default settings: Click on “Restore” button to restore the access point

back to its manufacture default settings.

Firmware Upgrade: Click on the “Browse” button to open a FileOpen Dialog box,

where gets to select the firmware file, which download from the web for the latest

version. Upon selecting the firmware file, click “Upload” and complete the

firmware upgrade process when the Access Point re-operates after it restarts.

Wi-Fi Protected Setup

Wi-Fi Protected Setup: Enable or Disable the WPS (Wi-Fi Protected Setup)

function

Status: Display the state (Un-configured State/Configured State) information of

WPS.

Self-PIN Number: Displays the default PIN number of the Access Point.

Client PIN Number: Type the Client’s PIN number to negotiate with the Access

Point via WPS protocol. It is only used when users want their station to join the

WLAN’s network.

Push Button Configuration: Clicking the Start PBC button will invoke the Push

Button Configuration (PBC) method of WPS. It is only used when the Access

Point acts as a Registrar.

SNMP: Enable or Disable the SNMP function.

TECHNICAL SPECIFICATIONS

General

Standards IEEE 802.11a/b/g/n (Draft 2.0)

IEEE 802.3u 10/100BASE-TX Fast Ethernet

Signal Type: DSSS (802.11b)

OFDM (802.11a/g/n)

Modulation: QPSK / BPSK / CCK / OFDM

LED Indicators: Power, Status, LAN (Link/Activity), WLAN (Link/Activity)

Frequency 2.4G Band:

 802.11 b:2412 ~ 2484 MHz

 802.11 g/n:2412 ~ 2472 MHz

(2412 ~ 2462MHz for FCC)

5G Band:

 802.11a/n:5180~5240 MHz/5745-5825MHz

Channel IEEE802.11b/g/n(2.4G Band):

 USA: Channel 1 ~ 11

 Europe: Channel 1 ~ 13

IEEE802.11a/n(5G Band):

 USA: Channel 36~48/149~165

 Europe/Japan: Channel 36~48

Data Encryption: 64 bit / 128 bit WEP Encryption, WPA, WPA2, WPA-PSK,

WPA2-PSK

Data Transfer Rate Fast Ethernet: 10/100Mbps

802.11a: 6,9, 12,18, 24, 36, 48,54Mbps(auto sense)

802.11b: 1, 2, 5.5, 11Mbps (auto sense)

802.11g: 6,9, 12,18, 24, 36, 48,54Mbps(auto sense)

802.11n: up to 300Mbps

Receiver Sensitivity 2.4G Band:

 802.11b: typical -85dBm (11Mbps)

 802.11g: typical -75dBm (54Mbps)

 802.11n: typical -65dBm (300Mbps)

5G Band:

 802.11a: typical -76dBm (54Mbps)

 802.11n: typical -65dBm (300Mbps)

Transmit Power 2.4G Band: (Average Power)

 802.11b: typical 15dBm

 802.11g: typical 15dBm

 802.11n: typical 12dBm

5G Band: (Average Power)

 802.11a: typical 13dBm

 802.11n: typical 11dBm

Transmission Range Outdoor: 100~300M (depends on environment)

Indoor: 50~100M (depends on environment)

Network Cable 2-pair UTP/STP Cat. 3,4,5 (100 m)

Interface 1 x 10/100Mbps RJ45 port

Antenna: 2 x 3 dBi Dipole Antennas

Physical and Environmental

DC inputs DC 5V /2.5A

Power Consumption 6 W (Max)

Temperature Operating: 0 ~ 40

C, Storage: -10 ~ 70

Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%

Dimensions 145.1 x 107.8 x 35.5 mm (W x H x D) without Antenna

EMI: FCC Class B, CE Mark B,

NETWORK GLOSSARY

Access Point - A device that allows wireless-equipped computers and other devices to

communicate with a wired network. Also used to expand the range of a wireless network.

Ad-hoc - A group of wireless devices communicating directly with each other (peer-to-peer)

without the use of

an access point.

AES (Advanced Encryption Standard) - A security method that uses symmetric 128-bit block

data encryption.

Bandwidth - The transmission capacity of a given device or network.

Bit - A binary digit.

Boot - To start a device and cause it to start executing instructions.

Broadband - An always-on, fast Internet connection.

Browser - An application program that provides a way to look at and interact with all the

information on the World Wide Web.

Cable Modem - A device that connects a computer to the cable television network, which in

turn connects to the Internet.

Daisy Chain - A method used to connect devices in a series, one after the other.

DDNS (Dynamic Domain Name System) - Allows the hosting of a website, FTP server, or e-

mail server with a fixed domain name (e.g., www.xyz.com) and a dynamic IP address.

Default Gateway - A device that forwards Internet traffic from your local area network.

DHCP (Dynamic Host Configuration Protocol) - A networking protocol that allows

administrators to assign temporary IP addresses to network computers by “leasing” an IP

address to a user for a limited amount of time, instead of assigning permanent IP addresses.

DMZ (Demilitarized Zone) - Removes the Router's firewall protection from one PC, allowing

it to be “seen” from the Internet.

DNS (Domain Name Server) - The IP address of your ISP's server, which translates the names

of websites into IP addresses.

Domain - A specific name for a network of computers.

Download - To receive a file transmitted over a network.

DSL (Digital Subscriber Line) - An always-on broadband connection over traditional phone

lines.

Dynamic IP Address - A temporary IP address assigned by a DHCP server.

EAP (Extensible Authentication Protocol) - A general authentication protocol used to control

network access.

Many specific authentication methods work within this framework.

Encryption - Encoding data transmitted in a network.

Ethernet - IEEE standard network protocol that specifies how data is placed on and retrieved

from a common transmission medium.

Firewall - A set of related programs located at a network gateway server that protects the

resources of a network from users from other networks.

Firmware - The programming code that runs a networking device.

FTP (File Transfer Protocol) - A protocol used to transfer files over a TCP/IP network.

Full Duplex - The ability of a networking device to receive and transmit data simultaneously.

Gateway - A device that interconnects networks with different, incompatible communications

protocols.

Half Duplex - Data transmission that can occur in two directions over a single line, but only

one direction at a time.

HTTP (HyperText Transport Protocol) - The communications protocol used to connect to

servers on the World Wide Web.

Infrastructure - A wireless network that is bridged to a wired network via an access point.

IP (Internet Protocol) - A protocol used to send data over a network

IP Address - The address used to identify a computer or device on a network.

IPCONFIG - A Windows 2000 and XP utility that displays the IP address for a particular

networking device.

IPSec (Internet Protocol Security) - A VPN protocol used to implement secure exchange of

packets at the IP layer.

ISP (Internet Service Provider) - A company that provides access to the Internet.

LAN - The computers and networking products that make up your local network.

MAC (Media Access Control) Address - The unique address that a manufacturer assigns to

each networking device.

Mbps (MegaBits Per Second) - One million bits per second; a unit of measurement for data

transmission.

NAT (Network Address Translation) - NAT technology translates IP addresses of a local area

network to a different IP address for the Internet.

Packet - A unit of data sent over a network.

Passphrase - Used much like a password, a passphrase simplifies the WEP encryption process

by automatically generating the WEP encryption keys for Linksys products.

Ping (Packet Internet Groper) - An Internet utility used to determine whether a particular IP

address is online.

POP3 (Post Office Protocol 3) - A standard mail server commonly used on the Internet.

Port - The connection point on a computer or networking device used for plugging in cables or

adapters.

Power over Ethernet (PoE) - A technology enabling an Ethernet network cable to deliver both

data and power.

PPPoE (Point to Point Protocol over Ethernet) - A type of broadband connection that provides

authentication

(username and password) in addition to data transport.

PPTP (Point-to-Point Tunneling Protocol) - A VPN protocol that allows the Point to Point

Protocol (PPP) to be tunneled through an IP network. This protocol is also used as a type of

broadband connection in Europe.

RADIUS (Remote Authentication Dial-In User Service) - A protocol that uses an

authentication server to control network access.

RJ-45 (Registered Jack-45) - An Ethernet connector that holds up to eight wires.

Roaming - The ability to take a wireless device from one access point's range to another

without losing the connection.

Router - A networking device that connects multiple networks together.

Server - Any computer whose function in a network is to provide user access to files, printing,

communications, and other services.

SMTP (Simple Mail Transfer Protocol) - The standard e-mail protocol on the Internet.

SNMP (Simple Network Management Protocol) - A widely used network monitoring and

control protocol.

SPI (Stateful Packet Inspection) Firewall - A technology that inspects incoming packets of

information before allowing them to enter the network.

SSID (Service Set IDentifier) - Wireless network's name.

Static IP Address - A fixed assigned address to a computer or device that is connected to a

network.

Static Routing - Forwarding data in a network via a fixed path.

Subnet Mask - An address code that determines the size of the network.

Switch - 1. A data switch that connects computing devices to host computers, allowing a large

number of devices to share a limited number of ports. 2. A device for making, breaking, or

changing the connections in an electrical circuit.

TCP (Transmission Control Protocol) - A network protocol for transmitting data that requires

acknowledgement from the recipient of data sent.

TCP/IP (Transmission Control Protocol/Internet Protocol) - A set of instructions PCs use to

communicate over a network.

Telnet - A user command and TCP/IP protocol used for accessing remote PCs.

TFTP (Trivial File Transfer Protocol) - A version of the TCP/IP FTP protocol that has no

directory or password capability.

Throughput - The amount of data moved successfully from one node to another in a given

time period.

TKIP (Temporal Key Integrity Protocol) - a wireless encryption protocol that provides

dynamic encryption keys for each packet transmitted.

Topology - The physical layout of a network.

TX Rate - Transmission Rate.

Upgrade - To replace existing software or firmware with a newer version.

Upload - To transmit a file over a network.

URL (Uniform Resource Locator) - The address of a file located on the Internet.

VPN (Virtual Private Network) - A security measure to protect data as it leaves one network

and goes to another over the Internet.

WAN (Wide Area Network)- The Internet.

WEP (Wired Equivalent Privacy) - A method of encrypting network data transmitted on a

wireless network for

greater security.

WLAN (Wireless Local Area Network) - A group of computers and associated devices that

communicate with each other wirelessly.

WPA (Wi-Fi Protected Access) - a wireless security protocol using TKIP (Temporal Key

Integrity Protocol) encryption, which can be used in conjunction with a RADIUS server.

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the

following lengths of time from the date of purchase.

TEW-670APB 3 years

If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option

and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item. All

products that are replaced will become the property of TRENDnet. Replacement products may be new or reconditioned.

TRENDnet shall not be responsible for any software, firmware, information, or memory data of customer contained in,

stored on, or integrated with any products returned to TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to service the product through any

unauthorized service center. This warranty is voided if (i) the product has been modified or repaired by any unauthorized

service center, (ii) the product was subject to accident, abuse, or improper use (iii) the product was subject to conditions

more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within the applicable warranty period for a Return

Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to

TRENDnet must be pre-authorized by TRENDnet with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE

CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE

FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE,

INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET

NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN

CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE

THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY

THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO

REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,

FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO EXCLUDES FOR ITSELF

AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE),

FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS

OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL

LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,

PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS

LIABILITY TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION.

THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN

SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of California.

Note: AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry 1-Year Warranty

Some TRENDnet products include software code written by third party developers. These codes are subject to the GNU

General Public License ("GPL") or GNU Lesser General Public License ("LGPL").

Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section and look for the desired TRENDnet

product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject

to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to

http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/lgpl.txt for specific terms of each license.

TRENDNET TEW670APB 11n Draft dual band AP User Manual UG TEW 670APB

TRENDNET, INC. 11n Draft dual band AP UG TEW 670APB

Manual

Navigation menu

Namespaces

Views

Navigation
