TTE Technology BT3DG Blue Tooth module User Manual
TTE Technology, Inc. Blue Tooth module
Users Manual
PRODUCTSUSERMANUAL3DG‐001‐TDM
Blue Tooth Module
Module Name: 3DG-001-TDM
PRODUCT DESCRIPTION
VDisaBluetoothadapterwhichworkwithBluetooth3DGproductandembedded
3DvideoreadyTVset.TVDgetsynchsignalfromTVsetandsendsynchpackageto
3DG,let3DGhavesynchactiveshutteropen/closeaction.
PRODUCT OUTLINE
BluetoothisanISMband(2.4GHz)radiofrequencycommunicationtechnology.
Bettercommunicationperformanceinsuresthesynchpackageto3DG,not
limitedbytheangleandlightinterference.
LittleenvironmentinterferencealsoinsuresthenicesynchtimingbetweenTV
and3DG.
GoodRFtechnologyinsuresthefewerpowerconsume,andgoodbatterylife.
Multipleprofilesupportformoreaccessoryupdateandadded
PRODUCT Operating conditions
PRODUCTSUSERMANUAL3DG‐001‐TDM
FCC Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment.
This equipment complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
The devices must be installed and used in strict accordance with the
manufacturer’s instructions as described in the user documentation that
comes with the product. Modular could be only used in mobile or fix device,
and could not be used in any portable device. The module must be installed in
TV set.
In the event that these conditions can not be met (for example certain
laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on
the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization
PRODUCTSUSERMANUAL3DG‐001‐TDM
Caution!
The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modifications to this equipment. Such modifications could void
the user authority to operate the equipment.
Regulation information
(1) This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
(2) This compliance to FCC radiation exposure limits for an uncontrolled
environment, and minimum of 20cm separation between antenna and body.
(3) Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end
user regarding how to install or remove this module in the user’s manual of end
product which integrates this module.
(4) The end product must carry a label stating “Contains TX FCC ID:
W8UBT3DG”
