THE LETTER QUALITY OFFICE PRINTER
MSP 345
136 col24 - wire 300 cpsl l
Fastest Speed - 300cps
Wide Operating Voltage - 150VAC~270VAC
Nine Letter Quality Fonts
Convertible Push & Pull Tractor
Flexible Paper Handling - Top, Rear & Bottom
CERTIFIED
Dealer / Channel Partner / Contact Note:
1. All specifications are at standard operating conditions.
2. Specifications are subject to change without notice.
3. Always use original TVS-E MaxiPrint ribbons for better
performance. Counterfeits can damage the printer.
MSP 345 Product Specifications
Ordering Information
SKU / FRU No. Description
1345MS05 MSP 345 Classic
Standard Configuration CD ROM, Quick Reference Manual
Insertion Plate,
Convertible Push / Push Tractor,
Black Ribbon Cartridge,
Parallel Interface Cable
Power Cord, Dust Cover.
Optional
1FMSSIB007 Serial Interface Unit
Consumables
3M011058 Black Ribbon
Print Method
Print Direction
Print Head - Type
Print Width
Print Head Life
Print Speed
Resident Printer Fonts
Paper Handling
Paper Size
Copy Capability**
Consumables - Ribbon
Serial Impact Dot Matrix
Bi-directional Logic Seeking
24 Wire
136 Column
100 Million Characters
10 12 15
High Speed Draft (cps) 300
Draft (cps) 250 300 375
Letter Quality (cps) 83 100 125
Draft Draft, High Speed Draft
Le tt er Q ua li ty Roman, Sans Serif, Courier, Prestige,
Script, Script-C, Orator, OCR-B, Orator-S
Lette r Qua lity Scala ble F onts Roman, Sans Serif (8 to 40 points)
Paper Path-Standard Top, Rear and Bottom
Continuous-Tractor Feed- Standard Conve rtibl e Push & Pull
Continuous Form Width 4 - 16”
Cutsheets Width 7.2 - 16.1”
Paper Thickness (max) - Tractor feed 0.3mm
Paper Thickness (max) - Friction feed 0.3mm
1+3 with carbon
Fabric-Ink Type High Density (Mobius Loop)
Fabric Life*** 3 Million Characters
Input Buffer (Kilo Bytes)
Reliability-MTBF (Power on Hours)
Acoustics - Noise Level
Emulation
Interface
Electrical Specifications
Environmental- Operating Conditions
Physical Dimensions
40
ESC P/2, Proprinter XL24e
KB
6,000 POH
55 dB(A)
Standard Centronics IEEE-P1284A Parallel
Optional RS 232C Serial
Operating Voltage 150 VAC ~ 270 VAC
Mains Frequency 47 - 63 Hz
Power (Standby) 12 W
o
Temperature +5 to +45 C
Relative Humidity 10% to 80%
Size (WxDxH) mm 608 x 379 x 147
Weight (Kg) 7
*** Ribbon Life @ Draft 10 cpi.
** Max. possible copy capability.
* LQ : Letter Quality.
1 kg = 2.2lbs; 1 inch = 2.54 cms.
Ver 0801
