user manual
SHENZHEN GOODWIN TECHNOLOGY CO.,LTD
Wireless charger Mat
QIMATFB-T
1. Product introduction
1.1 profile
This product is a double charge. This is compatible with the QI
5W wireless charging of apple fast charging and samsung fast
charging.
The maximum output of each product is 10W.
1.2 features
* wireless charging, high working efficiency and long service
life, can realize charging time.
fragmentation
* low leakage and low radiation;
* multiple overload protection to ensure stable and reliable
operation of equipment;
* foreign body detection, automatic closing output when metal
foreign body is near;
2. Physical pictures
3. Technical parameters
working frequency: 125 -205kHz.
Weight: 320 + 10 g
Ambient temperature: - 20 ~ + 50 ℃
Storage temperature: - 30 ~ + 60 ℃
Dimensions:
4. Operation and function.
4.1 features
Power indicator function:
Power: The white light goes off after one second
Standby: The light is not bright
Charging: The white light normally on
Foreign body detection: white light flashing
5. Safety Instructions
1) Do not exposer to excessive heat such as sunshine or fire.
2) Do not charge in damp or wet conditions.
3) Do not user the unit near explosive gases or flammable
materials.
4) Do not touch the device with wet hands.
5) Do not drop, crush, impact, or mechanical abuse the unit.
Manufacturer: SHENZHEN GOODWIN TECHNOLOGY CO.,LTD
Address: 4/F,Buiding A, Huayuan Industrial park, Fenghuang
No.1 Industrial Area, Fuyong, Baoan Dist., Shenzhen,
China
Manufacturer: SHENZHEN GOODWIN TECHNOLOGY CO.,LTD
Address: 4/F,Buiding A, Huayuan Industrial park, Fenghuang
No.1 Industrial Area, Fuyong, Baoan Dist., Shenzhen,
China
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
