ILLUSTRATED PARTS LIST

MODEL

TL25P

OUTPUT

25cc

PRODUCT

Talon 2 stroke 25cm³ Petrol String Trimmer

Page 1 of 5

Est. 1979

CREATIVE EQUIPMENT CC

18 Main Road, Fishers Hill, Germiston, 1401

Tel: 011 828 5085 Fax: 011-828-5085

crequip@global.co.za www.creativelp.co.za

ILLUSTRATED PARTS LIST

MODEL

TL25P

OUTPUT

25cc

PRODUCT

Talon 2 stroke 25cm³ Petrol String Trimmer

Page 2 of 5

Est. 1979

CREATIVE EQUIPMENT CC

18 Main Road, Fishers Hill, Germiston, 1401

Tel: 011 828 5085 Fax: 011-828-5085

crequip@global.co.za www.creativelp.co.za

ILLUSTRATED PARTS LIST

MODEL

TL25P

OUTPUT

25cc

PRODUCT

Talon 2 stroke 25cm³ Petrol String Trimmer

Page 3 of 5

#

PART #

DESCRIPTION

QTY

#

PART #

DESCRIPTION

QTY

1-1

908003

screw M5X25

4

2-7

600112160

ignition apparatus

1

1-2

918007

bolt M5*18

5

2-8

600573010

wire

1

1-3

901052

clutch cover

1

2-9

600113330

spark plug

1

1-4

600138350

coach nut M5

1

2-12

908012

bolt M5X23

2

1-5

600112060

bolt,crosshead M5X23

5

3-1

600113310

cylinder

1

1-6

901088

front cover

1

3-2

905005

gasket of cylinder

1

1-7

600118050

starter handle

1

3-3

600113260

piston ring

1

1-8

903011

spacer

1

3-4

600113250

piston

1

1-9

907803

heat protecting film

1

3-5

600113240

piston pin

1

1-10

600118040

starter spring

1

3-6

600113270

piston pin retainer

2

1-11

600118010

spring seat

1

3-8

900032

rod asm

1

1-12

600118030

starter wheel

1

3-10

600113200

piston and rod , asm

1

1-13

600118021

starter rope φ2.5X1080

1

4-1

600113110

crank case

1

1-14

903017

starter retainer

1

4-2

600113130

ball bearing 6001LLU

1

1-15

600118070

screw M4X12

3

4-3

600113140

oil seal TC28X12X7

1

1-16

901051

back cover

1

4-4

600113120

ball bearing 6201

1

1-17

908002

bolt 4.5*16

4

4-5

600113340

bolt M6X20

3

1-18

600118090

starter spring ,asm

1

4-6

600141000

crank shaft assembly

1

1-20

front cover,asm

1

4-7

915003

gasket of crank case A

1

1-21

907801

heat protecting film

1

4-8

911009

crankcase cover

1

1-22

907800

heat protecting film

2

4-10

crankcase asm

1

1-23

907802

heat protecting film

1

5-1

911019

fuel tank

1

2-1

600112040

connection socket

1

5-2

600116050

oil pipe

2

2-2

600142010

wash 8

1

5-3

600116020

oil pipe seat

1

2-3

600133120

tube

1

5-4

600116030

oil filter

1

2-4

600133130

washer 10

1

5-5

911030

ring of tank cover

1

2-5

600132000

flywheel,asm

1

5-6

600116070

cushion of fuel tank

4

2-6

600112060

bolt M5X23

2

5-7

931006

air/oil valve

1
