User Guide
![](/img.php?id=1515358&img=bg2.png)
Targus Laser Presentation Remote
2
Introduction
Thank you for your purchase of the Targus Laser Presentation Remote.
This combination remote with laser pointer, controls both Microsoft
PowerPoint® and Apple Keynote®. This cordless remote also offers true
plug-n-play capability with no need for software drivers, whilst long range
2.4 GHz technology allows for effective presentations up to 50 feet (15 m).
System Requirements
Hardware
• USB port
Operating System
• Microsoft Windows® 2000
• Microsoft Windows® XP
• Microsoft Windows Vista®
• Microsoft Windows 7®
• Mac OS® X 10.4 or later
Contents
• Targus Laser Presentation Remote
• Mini USB receiver
• 2 x AAA batteries
• User guide
![](/img.php?id=1515358&img=bg3.png)
Targus Laser Presentation Remote
3
Setting Up Your Remote
Installing the Batteries
Press the battery cover release button to open the battery cover and
carefully lift the cover as shown.
Battery
Cover
Insert the supplied batteries, making sure the positive (+) and negative
(-) ends of the batteries match the polarity indicators inside the battery
compartment.
Spare battery compartment
Battery cover
release button
![](/img.php?id=1515358&img=bg4.png)
Targus Laser Presentation Remote
4
NOTE: THE SPARE BATTERY COMPARTMENT PROVIDES CONVENIENT STORAGE FOR A
SEPARATE BATTERY (INCLUDED) WHICH CAN BE USED FOR EMERGENCY POWER.
Remove the mini USB receiver stored inside the center compartment.
Slide the battery cover back into position until it “clicks” firmly into place.
![](/img.php?id=1515358&img=bg5.png)
Targus Laser Presentation Remote
5
Using your remote
PC PowerPoint®
Mac KeyNote®
Mac PowerPoint®
Before using the remote, please select your computer type and preferred
presentation software. Locate the switch inside the battery compartment
as shown.
NOTE: SELECT “PC POWERPOINT” IF YOU USE A COMPUTER MADE BY: HP/
COMPAQ, DELL, TOSHIBA, GATEWAY, PANASONIC, FUJITSU, SONY, IBM/
LENOVO, ACER, ASUS, ETC.
![](/img.php?id=1515358&img=bg6.png)
Targus Laser Presentation Remote
6
This remote is a plug-n-play device. It will automatically operate when the
USB receiver is connected to the computer. Plug the mini USB receiver into
any available USB port on your computer.
Turn on the remote by pressing and holding the on/off power button for 3
seconds.
![](/img.php?id=1515358&img=bg7.png)
Targus Laser Presentation Remote
7
Keys and Functions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
![](/img.php?id=1515358&img=bg8.png)
Targus Laser Presentation Remote
8
1Power button
Press and hold for 3 seconds to turn on the remote.LED
ring will turn green.
Press and hold for 3 seconds to turn off the remote.LED
ring will shut off.
2Blank screen button The screen will become blank/dark.
3Slide show
Start - Press once to begin.
Stop - Press and hold for 2 seconds to stop the slide
show.
4Page Forward/Next slide Press once to go to next slide.
5Page
Backward/Previous slide Press once to go back one slide.
6Laser pointer Laser light is emitted from the opening.
7LED light ring Power and KeyLockTM indicator.
8KeyLock button
Press once to enable KeyLock function.
- Disables all keys except the laser, page forward/next
slide and page backward/previous slide buttons.
- LED ring will become RED.
Press once to disable the KeyLock function.
- LED ring will return to GREEN.
9Laser pointer button Press and hold to activate the laser pointer.
10 Volume up button Press to increase the volume.
11 Volume down button Press to decrease the volume.
![](/img.php?id=1515358&img=bg9.png)
Targus Laser Presentation Remote
9
Safety Measures
• To avoid possible eye damage, never point the remote’s laser at people,
especially their faces, or look directly into the remote’s laser beam.
• Avoid pointing the remote’s laser beam at a mirror or other highly-reective
surface.
• Keep the remote away from young children.
• Never view the remote’s laser beam using telescopic devices, such as a
microscope or binoculars.
• Any attempt to disassemble, adjust or repair the remote may result in exposure to
laser light or other safety hazards.
Troubleshooting
What do I do if the response time of the remote is slow or it intermittently
stops working?
• Make sure that the remote is within 50 feet (15 m) of the mini USB receiver and
computer.
• Increase the distance between the remote’s receiver and the base units of other
wireless devices.
• Turn off any wireless devices and their base units that are near the remote’s
receiver.
• Replace the battery.
![](/img.php?id=1515358&img=bga.png)
Targus Laser Presentation Remote
10
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
Technical Support
For technical questions, please visit:
US Internet: www.targus.com/support.asp
Australia Internet: www.targus.com/au
Email: infoaust@targus.com
Telephone: 1800-641-645
New Zealand Telephone: 0800-633-222
Product Registration
Targus recommends that you register your Targus accessory shortly after purchasing
it. Go to:
http://www.targus.com/registration.asp
You will need to provide your full name, email address, country of residence and
product information.
Warranty
Targus warrants this product to be free from defects in materials and workmanship
for one year. If your Targus accessory is found to be defective within that time, we will
promptly repair or replace it. This warranty does not cover accidental damage, wear
and tear, or consequential or incidental loss. Under no conditions is Targus liable for
loss of, or damage to devices; nor loss of, or damage to, programs, records, or data;
nor any consequential or incidental damages, even if Targus has been informed of
their possibility. This warranty does not affect your statutory rights.
![](/img.php?id=1515358&img=bgb.png)
Targus Laser Presentation Remote
11
FCC Statement
Tested to Comply
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected;
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not authorized by the party responsible for compliance
could void the user’s authority to operate this product.
Declaration of Conformity
Hereby, Targus, declares that this device is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. All trademarks and registered trademarks are the property of their respective owners.
All rights reserved. Features and specifications are subject to change without notice. © 2009. Targus Group International,
Inc. and Targus, Inc., Anaheim, CA 92806 USA
![](/img.php?id=1515358&img=bgc.png)
Targus Laser Presentation Remote
12
AVOID EXPOSURE--HAZARDOUS ELECTROMAGNETIC RADIATION EMITTED FROM THIS
APERTURE.
LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS. CLASS 2 LASER PRODUCT.
NEVER POINT A LASER BEAM INTO A PERSON’S EYES OR VIEW A LASER BEAM DIRECTLY,
AS PROLONGED EXPOSURE CAN BE HAZARDOUS TO THE EYES. MOMENTARY EXPOSURE
FROM A LASER POINTER, SUCH AS AN INADVERTENT SWEEP OF THE LIGHT ACROSS A
PERSON’S EYES, MAY CAUSE TEMPORARY FLASH BLINDNESS SIMILAR TO THE EFFECT
OF A CAMERA FLASH BULB. ALTHOUGH THIS CONDITION IS TEMPORARY, IT CAN BECOME
MORE DANGEROUS IF THE EXPOSED PERSON IS ENGAGED IN A VISION-CRITICAL ACTIVITY
SUCH AS DRIVING.
CAUTION: ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS DEVICE AND ITS ANTENNA(S) MUST NOT BE CO-LOCATED OR OPERATING IN
CONJUNCTION WITH ANY OTHER ANTENNA OR TRANSMITTER. YOUR DEVICE CONTAINS
A LOW POWER TRANSMITTER. WHEN DEVICE IS TRANSMITTED IT SENDS OUT RADIO
FREQUENCY (RF) SIGNAL. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY
RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
![](/img.php?id=1515358&img=bgd.png)
410-1681-001A / AMP13US
1 YEAR LIMITED WARRANTY: We pride ourselves
on the quality of our products. For complete warranty
details and a list of our worldwide offices, please visit
www.targus.com. Features and specifications are sub-
ject to change without notice. All trademarks and reg-
istered trademarks are the property of their respective
owners. All rights reserved. ©2009 Manufactured or
imported by Targus Group International, Inc. (for U.S.
sales: 1211 North Miller Street, Anaheim, CA 92806
USA) whose Australian sales representative is Targus
Australia Pty. Ltd., 117-119 Bowden Street, Meadow-
bank, NSW 2114 Australia
N2953
