Tatung AT1C Music transmitter User Manual WHP210 UG F
Tatung Company Music transmitter WHP210 UG F
Tatung >
Manual
Product Introduction
and Safety Approvals Unique Features
Specification
Product Accessories
Parts Introduction
Length
adjustment
LED Indicator
Pair
Power On/Off
Charging Port
Reset
1
2
3
4
5
6
7
900
900
User Guide Symbols
123
4 5 7
1
2
3
4
5
6
7
6
Steady red light
Steady greed light
Flashing green light
Devices are waiting for pairing
Devices are paired
Devices are not pairedȮ
The headphone is charging
FCC Statement
Both the headphone and the trarnsmitter are compliant with
part 15 of the FCC rules. Operation is subject to the following
two conditions: (1)These devices may not cause harmful
interference, and (2)These devices must accept any
interference received, including interference that may cause
undesired operation.
CE
This product is CE marked according to the provisions
of the R&TTE Directive. (99/5/EC)
The SoundOn WHP-210 is a high performance wireless
headphone delivering ultra clear sound with extended bass
effects. The headphone comes with a wireless music
transmitter that can be connected to any type of audio
source via a standard 3.5 mm audio jack. Also included is a
RCA cable with 3.5 mm adapter that can be used to
accommodate a separate 2-channel audio output port. The
transmitter can be powered by a power adapter, or by 3 AAA
batteries. You may find the battery cabinet located at the
bottom of the transmitter. The headphone has a built-in
Li-Polymer battery. When fully charged the battery offers up
to 12 hours of usage. To charge the headphone simply plug
into the power adapter. Please read the following certification
and safety approvals.
Based on advanced WiStereoTM digital wireless
technology for reliable transmission of music in
the 2.4 GHz band.
Effective within 100 feet range from source.
Patented dual-speakers in each of the ear-cups
delivering a full range of sounds as well as a
soft, deep bass.
The transmitter can be powered by the power
adapter, or by 3 AAA batteries making it perfect
for on-the-go lifestyles.
Connects to any type of music input via a
standard stereo jack, such as iPod, Zune
player, DVD players, TV audio out, CD players,
etc.
Fast working, easy to use, automatic Pair
function.
Extended battery life lasts up to 12 hours when
fully charged.
Ultra comfortable headband design for long
wear hours.
WHP-210
Reset
If headphone is functioning improperly, poke
the reset hole by a paper clip.
Power On/Off
Press this button to control power on/off.
Charging Port
Connect to the AC power adapter for charging.
LED Indicator
A red indicator represents charging functions.
A green indicator represents signal connections.
Press to increase the headphone volume.
Press to decrease the headphone volume.
1
2
3
4
5
6
7
Pair
Press “pair” button to connect the
wireless headphone and the USB Puck.
1.0
SoundOn WHP-210
Wireless Headphone
Noise-resistant Digital Wireless Technology
Patented Dual-Speaker Design in Each Ear-cup
Superior Sound Quality and Extended Bass
Wireless Transmitter Key Adapts To Every Music Player
Re-chargable Headphones Provide up tp 12 Hours Use
Unique Comfortable Headband Design
Wireless Technology
Headphone Listen Time
Transmitter Usage Time
Standby Time
Charge Time (full charge)
Distance of Use
Headphone Weight
Transmitter Weight
Charging Method
Headphone Battery Type
Frequency Response
Audio Quality
Distortion (T.H.D.)
Speaker Drivers
WiStereoTM for advanced 2-way digital
transmission in the 2.4 GHz frequency
band
Up to 12 hours (per charge)
Up to 4 hours
Up to 3 months
Up to 3.5 hours
100 feet
7.9 ounces
1.6 ounces
AC Power Adapter
Lithium Polymer
20Hz ~30,000Hz (perfect for all
music, game, and voice)
Uncompressed audio for music
(CD-quality) and voice (extra clarity)
<0.08% (professional grade audio
performance)
2 on each side for full-range audio and
sub-woofer enhancement with SafeBass
technology
30mm Neodymium for left/right channels
40mm Neodymium for subwoofer
Model
R
User Guide * 1pc
Wireless Headphone * 1pc
AC Power Adapter * 1pc
Wireless Transmitter * 1pc
RCA Plugs with 3.5mm
Adapter* 1pc
AAA Batteries * 3pcs
AAA
AAA
AAA
AAA
3.5mm Stereo Cable * 1pc
Headphones Made In China
Handling the headphone
Do not bend, drop, crush, puncture,
incinerate, or open the headphone.
Repairing the headphone
Never attempt to repair the headphone
yourself. The headset does not contain any
user serviceable parts. For service
information, read the “Help” section from the
warranty card. The headphone should be
replaced only by authorized service
providers.
Important
User Information
118
12 13
Getting Started
To ensure this headphone to work properly, please avoid
recharging while using.
AC Power Adapter is used to both charge the headphone and the
transmitter( if batteries are not powering the transmitter).
Steady red light is turned off when the headphone is fully charged.
The headphone is charging
9
Power offřPress and hold the power button for 2 sec. to turn off
the headphone.
Power onřPress the power button to turn on the headphone.
Turning the headphone on/off
10
First time use : Charge 3.5 hours before using
headphone for the first time.
Charging
Plug in to charge Unplug when finished
AC Power adapter
Avoiding hearing damage
Permanent hearing loss may occur if the
headphone is used at too high a volume. Set
the volume to a safe level. Warning: Over
time it is possible to become accustomed to
high volumes that may be damaging to your
hearing. If you experience a ringing in your
ears or your own voice and other sounds
appear muffled, stop using the headphone
and consult a hearing professional.
Hearing experts suggest that in order to
protect your hearing:
Limit the amount of time you use the
headphone at high volume.
Avoid turning up the volume to block out
noisy surroundings.
Turn down the volume if you can't hear
people speaking near you.
Maintaining battery life
Due to the physical nature of the battery,
required charging time may increase while
the actual capacity of the batter may
decrease. If you have any questions
regarding the replacement of the built-in
battery, please contact our service center.
15
No sound emitting from the Headphone
Make sure the headphone is charged,
and the transmitter is powered either by
the AC power adapter, or by 3*AAA
batteries. Try new batteries if you think
these batteries have run out of power.
Check if the music is being played from
your music players.
When transmitting music from a PC or
DVD player, check to see that the audio
out is correctly selected and is not muted.
Simultaneously press the PAIR keys,
both on the transmitter as well as on the
headphone, for 2-3 seconds until sound
returns.
In case the music player/source has a
low volume output, try pressing the
volume up key on the headphone.
15
Sound break-up
First move around and get closer to the Transmitter.
The constant sound break-up may have occurred
because of the range and radio-wave transmission
obstacles, such as walls and large objects that
exist between the Transmitter and the headphone.
If you are using AAA batteries, the batteries could
be running low. Plug in the power adapter of the
Transmitter, and check if the sound break-up
improves. If that is the case, replace the batteries.
No connection signal visible
Make sure the headphone is charged and the
transmitter is properly connected to the audio
source/player. Also, stand within close range
of the source/player and try the power button
on the headphone once more.
The headphone automatically shuts off
Check to see if the battery life is too low or the
indicator light on the headphone is off.
Unexpected behavior
Reset the headphone. (See Step 6 )
Troubleshooting
14
Connect the Transmitter
AC Power adapter
Audio Left/Right Output Port
MP3,
CD Player
or DVD Player
Transmitter Battery cabinet with 3 AAA batteries.
AAA
AAA
AAA
AAA
AAA
AAA
Unplug the headphone charging cord if
any of the following conditions exist
The charging cord became frayed or
damaged.
The charging cord has been exposed to
rain, liquids, or excessive moisture.
The headphone or the AC power adapter
might needs service or repair.
When cleaning the headphone.
When using the headphone.
[Note: The headphone does not work
when it is being charged.]
Simultaneously press the PAIR buttons of both the headphone
and the transmitter to connect the signal transmission.
When light is steady
devices are paired
Pairing the headphone to the transmitter
When light is flashing
devices are waiting for pairing
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
This equipment must not be co-located or operating in conjunction with any other antenna
or transmitter.
