Techcool Industry Development D08 True wireless speaker User Manual
Techcool Industry Development Co., Ltd. True wireless speaker Users Manual
user_manual
适用 Apply： 蓝牙设备 Bluetooth Devices
名称 Appellation： 蓝牙对箱
型号 Model: D08
说明书
User manual
True wireless speaker
文件号：YG-SPE-3 版本：A页序 2
产品规格参数
No.
项目
参数特性 Specifications
型号 Model
1.00 一般参数
1.01 产品类型 Type 蓝牙对箱
1.02 配对名 Pairing Name D08
1.04 产品净重 N.W. 165g（单个）330g(双个)
1.05 产品尺寸 Products size Φ65.8x85mm
1.06 声道系统 Track system 立体声 Stereo
1.07 蓝牙方案
Bluetooth solutions
杰里 AC6905C
1.08 蓝牙版本 Bluetooth version Bluetooth V4..2
1.09 发射功率 Class 2 （-6dbm - +4dbm）
1.10 工作频段 2.4G ISM 波段（2.402-2.480GHZ）
1.11 收发距离 Bluetooth range 10M
2.00 喇叭参数
2.01 磁铁 Magnet Φ15.5*5
2.02 额定功率 Rated power 3W
2.03 共振频率 F
O
150±20%Hz Free air
2.04 灵敏度 105+/-3DB
2.05 频率范围 Frequency 110Hz-20kHz
2.07 欧姆数 4Ω
2.07 发声单元 45mm
3.00 电池参数
3.01 电池尺寸 Bass Battery Size 聚合物锂电池 603443
3.02 电池额定容量 Aggregate capability 800mAh, 3.7V
3.03 电池充电时间 Charging time 标准冲电（2.5 hours）
3.04 电池电池寿命 Battery life ≥300 cycles
3.05 工作温度 0~45 °C
3.06 存储湿度 ≤75%RH
3.07 工作时间 5小时
3.08 电池寿命 Battery life ≥300 cycles
3.09 电池重量 Battery N.W 18G
4.00 咪头
4.01 灵敏度 '42±3DB
4.02 尺寸 4015 全指向咪头
5.00 充电线 Charging cable 黑色 micro5pin 面条线长 200mm
D08
General parameters
Emissive power
Working frequency
Horn parameter
Sensitivity
Ohm number
Sound generating unit
Battery parameters
working temperature
Storage temperature
Working hours
IMI
sensitivity
size
文件号：YG-SPE-3 版本：A页序 3
产品使用
开机/关机
• 开机：关机状态下,长按电源键开机 3秒，伴有提示音，蓝灯快闪。
• 关机：开机状态下,长按电源键 3秒，伴有提示音，蓝灯熄灭。
Power on/Power off
Power on: Press and hold MFB for 3 seconds, the blue LED light flashes fast accompanied by a “Beep” prompt tone.
Power off:: Press and hold MFB for 3 seconds, the blue LED light goes out accompanied by a “Beep” prompt tone.
配对
1·音箱与音箱配对：两台音箱开机状态下 5秒后则会自动分配主副机进行配对，配对成功后蓝灯长亮并伴有提示音。
2·音箱与手机配对:两个音箱配对后，打开手机蓝牙搜索“D08”进行连接，连接成功后蓝灯长亮并伴有提示音。
备注：
1·不分主副机，任意两台音箱会自动分配主副机进行无线配对连接。
2· 音箱开机后若 5分钟内没有配对，则自动关机。
3· 苹果系统支持电量显示。
Paring:
1·Speakers pairing: Two speakers will pairing with each other automatically after 5 seconds if powered on. Speakers will deliver "beep" prompt tone and flash blue light if paired
successfully.
2·Speakers pair with smart phones: After finishing last step, select“Air Box”in BT list of your smartphone to get paired. Then the blue LED s keep on accompanied by a“Beep”
prompt tone, which means successful pairing.
Note :
1·Speakers automatically paired with each other, and one of them will be the primary device.
2·Speakers will power off in 5 minutes without any connection.
3·Support iPhone battery indicate.
播放/通话：
1. 音乐播放/暂停：单击电源键/手动打开手机音乐。
2. 电话接听/拒听：来电时/通话时单击开关键接听/拒听。
Music playing/Make calls:
1.Music play/pause: After paired, press MFB to play/pause music. You can also play or pause your music on your phone.
2.Answer/Reject calls: When call is coming, press the MFB to answer it; or press and hold the MFB for 2 seconds to reject it.
充电：
1. 音箱充电：充电时红灯亮，充电满后红灯熄灭.
Charge：
1. Charging: Red LED lights keep on.
2. Charged: Red LED lights go out.
文件号：YG-SPE-3 版本：A页序 4
音箱 LED 灯指示状态
开机 蓝灯闪烁
关机 蓝灯熄灭
配对 蓝灯长亮
待机（配对） 蓝灯长亮
来电/打电话 蓝灯闪烁
通话 蓝灯闪烁
播放音乐 蓝灯闪烁
充电 红灯长亮
充满电 红灯熄灭
Speakers LED Indicator
Power on Blue LED flash
Power off Blue LED close
Pairing Blue LED keeps on
Standby (paired) Blue LED keeps on
Incoming call / Dialing Blue LED flash
Talking / Playing music Blue LED flash
Charging Red lighting
Full charged Blue LED off
Speakers low battery Red flashes once every 6 seconds
文件号：YG-SPE-3 版本：A页序 5
产品包装
产品图片
Dimension Φ65x80mm
Product G.W 410G
Color box 213*71*71MM
Carton 445*370*375MM
QTY/CTN 50PCS/CTN
G.W 21.5KGS
Certification CE/FCC/MSDS/
Patent CN
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
