TG703
Entry-level Integrated Access Device
TELECOM
VOICE
DATA
VIDEO
Triple Play Box at Entry-Level Cost
The Technicolor TG703 is an entry-level Integrated Access Device
allowing ADSL2+ connectivity while providing Voice over IP
functions for residential users. It is also backwards compatible with
ADSL oering autonegotiation capability. For local networking, the
Technicolor TG703 oers next to 4 Ethernet ports, a wireless LAN
interface (1x1 11n for enhanced b/g performance).
Triple Play
This VoIP gateway can manage full triple play service: high-speed
Internet access and video service together with telephony.
The Technicolor TG703 oers one phone connector to accommodate
a phone or fax. Once the gateway is registered with a VoIP service,
regular phone calls can be conducted over the Internet with all the
benefits of IP Telephony. The gateway oers a wide rage of services
like caller ID, CLIR, call waiting, call forwarding, 3-way conference and
message waiting notification.
Features at a Glance
Integrated ADSL2+ modem
4 Fast Ethernet ports to connect multiple devices, such as
PCs, laptops, set top boxes...
Wireless networking on-board: 1x1 11n for enhanced b/g
performance
Wi-Fi Protected Setup
Voice over IP
1 FXS port for phone and/or fax
Remotely manageable - TR-069, TR-104, TR-098, TR-111
CoCv3 compliant
Very low power consumption
Advanced in Security
The integrated firewall guarantees users ultimate network security.
The firewall minimizes undesired service impact and provides stateful
inspection of packets. An integrated Denial of Service (DoS) engine
monitors a wide range of attack patterns, and logs potential security
breaches to a local cache or remote server.
The Technicolor TG703 also supports powerful wireless security
mechanisms, such as Wi-Fi Protected Access (WPA), and a Wi-Fi
Protected Setup (WPS) button. This allows users to communicate
and access data with ecient link quality and the highest level of
network security. Unwanted content filtering on the Internet is also
integrated.
WPS
With Wi-Fi Protected Setup your wireless home network is set up
automatically with the highest level of security by just pushing a
button.
It allows home users who know little of wireless security to configure a
secure network, without any problems.
Home Networking with Easy
Installation
Like all Technicolor gateways, the Technicolor TG703 interoperates
seemlessly with the Technicolor Gateway Setup Wizard, making the
setup of a wireless home network as easy as clicking a button. No
more helpdesk calls, just click and you are ready to go. The Technicolor
Gateway Setup Wizard performs comprehensive system checks
before and during the installation and setup process, and validates all
user inputs to guarantee the end user a secured wireless connection
to the Internet.
Easily Manageable
The Technicolor TG703 is completely designed according to the
TR-069 Data Model, through which the device can be configured
remotely. In addition, TR-104 for VoIP is implemented for the
configuration and management of all voice services.
TR-037 and TR-069 enable auto-configuration of network bandwidth
according to service needs, allowing seamless integration with the
network’s provisioning system.
TG703
Entry-level Integrated Access Device
Technical Specifications
Hardware Specifications
Interfaces WAN RJ11 DSL line port
Interfaces LAN 4-port autosensing 10/100Base-T auto-MDI/
MDI-X Ethernet switch
Wi-Fi IEEE 802.11b/g/n 1x1 on board
1 FXS POTS port
Extras WPS button
Reset button
Dimensions 41 x 167 x 223 mm (1.6 x 6.6 x 8.8 in.)
(h x d x w)
AC Voltage 100-240 VAC (switched mode power supply)
Temperature 0° - 40° C (32 - 104 F)
Humidity 20% to 80%
DSL Modem Specifications
Supports Multi Mode Standard
ADSL ANSI T1.413 Issue 2, ITU-T G.992.1 Annex A,
B (G.dmt), ITU-T G.992.2 Annex A, B (G.lite),
ITU-T G.994.1 (G.hs)
ADSL2 ITU-T G.992.3 Annex A, B, L, M (G.dmt.bis),
ITU-T G.992.4 Annex A, B, L, M (G.lite.bis)
ADSL2+ ITU-T G.992.5 Annex A, B
Management
User Friendly GUI via HTTP and HTTPS
GUI-embedded Easy Setup wizard
On demand Remote GUI assistence (helpdesk)
Web-browsing Intercept (install / diagnostics)
PC (Wireless) Technicolor Gateway Setup Wizard
TR-069 CPE WAN Management Protocol
TR-104 Voice Service Provisioning
TR-098 Internet Gateway Device Management
TR-111 Home Network Device Management
TR-140 Storage Service Provisioning
TR-064 LAN Side Configuration
Zero-Touch Auto-Provisioning
Wireless Performance and Security
Wi-Fi IEEE 802.11b/g/n 1x1 access point
Wi-Fi CERTIFIED®
WPA™-Personal / WPA2™-Personal , WEP™
Wi-Fi Multimedia (WMM®)
Wi-Fi Protected Setup (WPS
)
Up to 4 virtual SSID APs support
Security and service segregation per SSID
Dynamic rates switching for optimal wireless rates
Manual/auto radio channel support
Firewall Security
Stateful Packet Inspection Firewall (SPIF)
Customizable firewall security levels
Intrusion detection and prevention (DoS, SYN Flood, Ping of Death,
Fraggle, LAND, Teardrop, etc.)
Website URL and Content-based filtering
DMZ
Enabling Technologies
Quality of Service: ATM, Ethernet, Wi-Fi, IP
FLEXIBundLE: Multi Role User Authorization
Hyper-Nat: Symmetrical NAT with Application Helpers
Game and Application Sharing NAT PortMaps
«SIM-lock» Provider Locking
DHCP Conditional serving & relay, DNS server & relay
IGMPv3 proxy (FastLeave)
IGMP snooping (Full routed)
Flexiport (any Ethernet port bridged IPTV)
IEEE802.1q VLAN bridging, Multiple bridge instances
TG703
Entry-level Integrated Access Device
© Copyright 2010 Technicolor. All rights reserved. Photos
and specifications subject to change without notice. All
trade names referenced are service marks, trademarks, or
registered trademarks of their respective companies.
E-DOC-DAT-20100630-0001 v1.0
DS-136-v01-1006
Technical Specifications
Voice over IP Features
Voice
Functionality
Signalling: SIP, MGCP (optional), H.323 (optional)
Codecs: G.711, G.726, G.729, T.38
Interopable with main market softswitches
Supplementary
and Advanced
Services
Call waiting (on call basis)
Caller Identification
Call forwarding (No answer/Busy/Unconditional)
Call transferring
Call hold, call return
CLIP (Calling Line Identification Presentation)
CLIR (Calling Line Identification Restriction)
CNIP (Calling Name Identifiation Presentation)
CNIR (Calling Name Identifiation Restriction)
Fax transparency
3-way conference
MWI (Message Waiting Indicator)
Missed call e-mail
Click to dial
Warm line
Call Completion to Busy Subscriber
Abbreviated number
Common number in/outgoing call
Anonymous Call Rejection
Distinctive Ringing
Voice Mail on No Reply
Support for Secondary Outbound Proxy
DNS NAPTR, DNS SRV
Content of the Box
Entry-level wireless-n VoIP Multi-User ADSL2+ Gateway
Power supply unit
ADSL cable (RJ11)
Ethernet cable (RJ45)
Setup CD and Leaflet
Filter or splitter (optional)
Technicolor TG703 back panel
TG703
Entry-level Integrated Access Device
TECHNICOLOR WORLDWIDE HEADQUARTERS
1, rue Jeanne d’Arc
92443 Issy-les-Moulineaux France
Tel. : 33(0)1 41 86 50 00 - Fax : 33 (0) 1 41 86 58 59
www.technicolor.com
SALES CONTACT
For more information please get in touch with your usual
sales representative or use the following email:
telcosales@technicolor.com
Technicolor Professional Services are available to address your demands for qualified technical support & warranty,
product maintenance, access to training courses and tailor-made solutions to specific product evolution. For more
information, please ask your usual contact person.
DRAFT
3
SAFETY INSTRUCTIONS AND REGULATORY NOTICES
BEFORE YOU START INSTALLATION OR USE OF THIS PRODUCT, CAREFULLY READ THESE
INSTRUCTIONS
Wireless
In case this product is equipped with a wireless transceiver, it uses Direct Sequence Spread Spectrum (DSSS) /
Orthogonal Frequency Division Modulation (OFDM) radio technology. As such it is designed to be inter-operable with
any other wireless DSSS/OFDM type product that:
Complies with the IEEE802.11b/IEEE802.11g/IEEE802.11n Standard on Wireless LANs, as defined and approved
by the Institute of Electrical and Electronics Engineers.
Is Wi-Fi® CERTIFIED™ as defined by the Wi-Fi® Alliance.
Directive
Unless express and prior approval by Technicolor in writing, you may not:
Disassemble, de-compile, reverse engineer, trace or otherwise analyse the equipment, its content, operation, or
functionality,
or otherwise attempt to derive source code (or the underlying ideas, algorithms, structure or organization) from the
equipment,
or from any other information provided by Technicolor, except to the extent that this restriction is expressly
prohibited by local law;
Copy, rent, loan, re-sell, sub-license, or otherwise transfer or distribute the equipment to others;
Modify, adapt or create a derivative work of the equipment;
Remove from any copies of the equipment any product identification, copyright or other notices;
Disseminate performance information or analysis (including, without limitation, benchmarks) from any source
relating to the equipment.
Such acts not expressly approved by Technicolor will result in the loss of product warranty and may invalidate the user's
authority to operate this equipment in accordance with FCC Rules.
Technicolor disclaims all responsibility in the event of use that does not comply with the present instructions.
!
When using this product, always follow the basic safety precautions to reduce the risk of fire, electric shock and
injury to persons, including the following:
Always install the product as described in the documentation that is included with your product.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from
lightning.
Do not use this product to report a gas leak in the vicinity of the leak.
DRAFT
4
Environmental information
WEEE directive
Energy consumption
Energy savings - You have a role to play...
Learn how you can use and explore ways for using your electronic equipment
Safety Instructions
Climatic conditions
This product:
Is intended for in-house stationary desktop use; the maximum ambient temperature may not exceed 40°C (104°F).
Must not be mounted in a location exposed to direct or excessive solar and/or heat radiation.
Must not be exposed to heat trap conditions and must not be subjected to water or condensation.
Must be installed in a Pollution Degree 2 environment (Environment where there is no pollution or only dry,
nonconductive pollution).
Cleaning
Unplug this product from the wall socket and computer before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
This symbol means that your inoperative electronic appliance must be collected separately and not mixed
with the household waste.The European Union has implemented a specific collection and recycling system for
which producers are responsible.
This appliance has been designed and manufactured with high quality materials and components that can be
recycled and reused.
Electrical and electronic appliances are liable to contain parts that are necessary in order for the system to
work properly but which can become a health and environmental hazard if they are not handled or disposed of
in the proper way. Consequently, please do not throw out your inoperative appliance with the household
waste.
If you are the owner of the appliance, you must deposit it at the appropriate local collection point or leave it
with the vendor when buying a new appliance.
If you are a professional user, please follow your supplier's instructions.
If the appliance is rented to you or left in your care, please contact your service provider.
The notice detailed useful information on all the features of your product but also on energy comsumption.
We strongly encourage you to carefully read the notice before putting your equipment in service to get the
best service it can offer you.
By working together, we can reduce the impact we have on the earth!
DRAFT
5
Water and moisture
Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement
or near a swimming pool. Transition of the product from a cold environment to a hot one, may cause condensation on
some of its internal parts. Allow it to dry by itself before re-starting the product.
Interface classifications
The external interfaces on the rear panel of the product are classified as follows:
DSL, ADSL, SHDSL, VDSL, Line: TNV circuit, subjected to over voltages (TNV-3)
ISDN: SELV circuit
PSTN, FXO: TNV circuit, subjected to over voltages (TNV-3)
Phone, VoIP, FXS: TNV circuit, not subjected to over voltages (TNV-2)
All other interface ports (e.g. Ethernet, 10/100Base-T/MDI(-X), USB, Console, Craft, etc.), including the low
voltage power input from the AC mains power supply: SELV circuits.
Electrical powering
The powering of the product must adhere to the power specifications indicated on the marking labels.
The power supply must be Class II and a Limited Power Source in accordance with the requirements of IEC60950-1/
EN60950-1, Clause 2.5 and rated as indicated on the label on your product. It must be tested and approved to national
or local standards.
For US and Canada: This product is intended to be supplied by a Listed Direct Plug-in, or Desktop Power Unit marked
"Class 2" and rated as indicated on the label on your product.
The use of other types of supplies is prohibited. If you are not sure of the type of power supply needed, consult the
product's user documentation or contact your local product dealer.
ISDN
USB
The device is to be connected to an identified USB port complying with the requirements of a Limited Power Source.
!
WARNING
The Phone, VoIP, FXS port will be classified as a TNV-3 circuit when connected internally to the PSTN,
FXO port, for example, when the device is powered off.
If the product is equipped with a USB interface (slave and/or master) or any type of connector with
metallic shielding, then it is not allowed to connect the Phone, VoIP, FXS port with the PSTN, FXO or the
DSL, ADSL, SHDSL, VDSL, Line port by any means, for example with an external telephone cable.
!
WARNING
For US and Canada: Do not use the ISDN port; do not attempt to connect this port to the network at anytime.
DRAFT
6
Telephone cable
Connect the telecommunication line cord only in the PSTN, FXO, DSL, ADSL, SHDSL, VDSL or Line port of the
product. Never plug the telecommunication line cord in another receptacle of the product.
Follow the installation instructions in the sequence as outlined in the installation guide.
Central splitter / distributed filter(s) (if applicable)
If telephone service is required on the same line, a central splitter or distributed filter(s) must be installed for optimal
DSL performance.
Depending on your DSL configuration and type of splitter / filters, installation must be carried out by qualified service
personnel. Consult your telephone service company or DSL service provider for instructions.
Accessibility
The Direct Plug-in power supply, or the plug on the power supply cord serves as disconnect device. Be sure that the
power socket outlet you plug the power supply into is easily accessible and located as close to the equipment as
possible.
Overloading
Do not overload mains supply socket outlets and extension cords as this increases the risk of fire or electric shock.
Servicing
To reduce the risk of electric shock, do not disassemble this product. None of its internal parts are user-replaceable;
therefore, there is no reason to access the interior. Opening or removing covers may expose you to dangerous voltages.
Incorrect reassembly could cause electric shock if the appliance is subsequently used.
If service or repair work is required, take it to a qualified service dealer.
Damage requiring service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
When the power supply or its plug are damaged.
When the attached cords are damaged or frayed.
If liquid has been spilled into the product.
If the product has been exposed to rain or water.
If the product does not operate normally.
If the product has been dropped or damaged in any way.
There are noticeable signs of overheating.
If the product exhibits a distinct change in performance.
!
CAUTION
To reduce the risk of fire, use only No 26 AWG wire size or larger telecommunication line cord.
DRAFT
7
Immediately disconnect the product if you notice it giving off a smell of burning or smoke. Under no circumstances
must you open the equipment yourself; you run the risk of electrocution.
Regulatory Information
You must install and use this device in strict accordance with the manufacturer's instructions as described in the user
documentation that is included with your product.
Before you start installation or use of this product, carefully read the contents of this document for device specific
constraints or rules that may apply in the country where you want to use this product.
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or
responsible representatives of the organization.
If you are uncertain of the policy that applies on the use of wireless equipment in a specific organization or environment
(e.g. airports), you are encouraged to ask for authorization to use this device prior to turning on the equipment.
Technicolor is not responsible for any radio or television interference caused by unauthorized modification of the device,
or the substitution or attachment of connecting cables and equipment other than specified by Technicolor. The
correction of interference caused by such unauthorized modification, substitution or attachment will be the
responsibility of the user.
Technicolor and its authorized resellers or distributors are not liable for any damage or violation of government
regulations that may arise from failing to comply with these guidelines.
Europe - European Union
European Community Declaration of Conformity
This equipment can be used in all countries that are member of the European Union and that are member of the
European Free Trade Association.
The Declaration of Conformity can be found on www.technicolor.com.
In case this product is equipped with a wireless transceiver:
it is restricted to indoor use only.
it complies with the basic restrictions and limits as defined in the European Council Recommendation (1999/519/
EC) on the limitation of exposure of the general public to Electromagnetic fields.
This product complies with:
Commission Regulation (EC) No 1275/2008 implementing Directive 2005/32/EC: Ecodesign requirements for
standby and off mode electric power consumption of electrical and electronic household and office equipment.
Commission Regulation (EC) 278/2009: Ecodesign requirements for no-load condition electric power
consumption and average active efficiency of external power supplies.
!
Hereby, Technicolor, declares that this product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC of the European Parliament and of the Council.
DRAFT
8
North-America - Canada
Notification of Canadian Radio Frequency Interference Statement
This Class B digital apparatus complies with Canadian ICES-003.
NOTICE: This product meets the applicable Industry Canada technical specifications.
NOTICE: The ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the
maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does
not exceed five.
Canada - Industry Canada (IC)
In case this product is equipped with an IEEE802.11b/IEEE802.11g/IEEE802.11n wireless transceiver, complying with
RSS 210 and/or RSS 213 of Industry Canada, operation is subject to the following two conditions:
1This device may not cause harmful interference.
2This device must accept any interference received, including interference that may cause undesired operation
of the device.
Restricted Frequency Band
In case this product is equipped with an IEEE802.11b/IEEE802.11g/IEEE802.11n wireless transceiver, it only uses
channels 1 to 11 (2412 to 2462 MHz) on Canada territory.
North-America - United States of America
Federal Communications Commission (FCC) Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
!
IMPORTANT NOTE: Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
DRAFT
9
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment.
Responsible Party: Technicolor Inc., 10330 North Meridian Street, Indianapolis, IN 46290 USA, (580) 634-0151.
This equipment complies with Part 68 of the FCC Rules.
The customer information required for Telephone Terminal Equipment ("TTE") approved for connection to the Public
Switched Telephone Network ("PSTN"), pursuant to 47 CFR §68.218(b)(1) can be found at www.technicolor.com.
RF-Exposure Statement
When the product is equipped with a wireless interface, then it becomes a mobile or fixed mounted modular transmitter
and must have a separation distance of at least 20cm between the antenna and the body of the user or nearby persons.
In practice, this means that the user or nearby persons must have a distance of at least 20cm from the modem and must
not lean on the modem in case it is wall-mounted.
With a separation distance of 20cm or more, the M(aximum) P(ermissible) E(xposure) limits are well above the
potential this module is capable to produce.
The transmitter shall not be collocated with other transmitters or antennas.
Restricted Frequency Band
In case this product is equipped with an IEEE802.11b/IEEE802.11g/IEEE802.11n wireless transceiver, it may only use
channels 1 to 11 (2412 to 2462 MHz) on U.S.A. territory.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1This device may not cause harmful interference, and
2This device must accept any interference received, including interference that may cause undesired
operation.

Navigation menu
